V 1.23
SilverCrest SDJ 100 A1 |
|
Content |
|
Introduction........................................................................................................... |
3 |
Intended use.......................................................................................................... |
3 |
Supplied items ....................................................................................................... |
3 |
Technical data ....................................................................................................... |
4 |
System requirements................................................................................................................................. |
4 |
Safety instructions ................................................................................................. |
4 |
Operating environment ............................................................................................................................ |
4 |
Cables ....................................................................................................................................................... |
5 |
Children and persons with disabilities..................................................................................................... |
6 |
Copyright .................................................................................................................................................. |
6 |
Back up ..................................................................................................................................................... |
6 |
Control elements ................................................................................................... |
7 |
Prior to use ............................................................................................................ |
9 |
Installing the software .............................................................................................................................. |
9 |
The Cross DJ software.............................................................................................................................. |
9 |
Connecting the USB Mixer ................................................................................................................... |
10 |
Set-up .................................................................................................................. |
10 |
Players .................................................................................................................................................... |
10 |
Loading a track...................................................................................................................................... |
10 |
Track playback ...................................................................................................................................... |
11 |
Adjusting the player volume ................................................................................................................. |
11 |
Adjusting the master volume ................................................................................................................. |
11 |
Mixing tracks ......................................................................................................................................... |
11 |
Scratch and search functions................................................................................................................ |
11 |
Varying the speed ................................................................................................................................. |
12 |
Automatic track synchronisation........................................................................................................... |
12 |
High frequencies.................................................................................................................................... |
12 |
Low frequencies ..................................................................................................................................... |
12 |
Reversing the playback direction ......................................................................................................... |
13 |
Using a CUE point................................................................................................................................. |
13 |
Using the HOT points ............................................................................................................................ |
13 |
Effects ..................................................................................................................................................... |
14 |
2 - English
|
SilverCrest SDJ 100 A1 |
Servicing/cleaning .............................................................................................. |
15 |
Environmental and disposal information............................................................. |
15 |
Conformity information....................................................................................... |
15 |
Troubleshooting .................................................................................................. |
16 |
Warranty and servicing information ................................................................... |
17 |
Introduction
Thank you for purchasing the SilverCrest SDJ 100 A1 USB Mixer. Before using this device for the first time please read the following instructions carefully and take note of the safety warnings, even if you are familiar with the use of electronic devices. Please keep this manual safe for future reference. If you sell or pass on this device, always include this user guide.
Intended use
The SilverCrest SDJ 100 A1 USB Mixer allows you to mix and scratch digital music on a computer. You can add your own style to your favourite music or create your own mixes at parties.
This is an information technology device. It is only designed for private use and not for industrial or commercial purposes. Furthermore, the device may not be used outdoors or in tropical climates. This device fulfills all relevant norms and standards related to CE conformity. In the event of any modification to the device that was not approved by the manufacturer, compliance with these standards is no longer guaranteed. Only use accessories specified by the manufacturer.
Please observe the regulations and laws in the country of use.
Supplied items
Please check that all the following items are contained in the packaging:
-USB Mixer SilverCrest SDJ 100 A1
-USB cable
-Software CD
-This User Manual
If parts are missing or damaged, please call our hotline. The telephone number can be found in the last chapter: "Warranty and servicing information".
English - 3
SilverCrest SDJ 100 A1
Technical data
Dimensions (WxHxD) |
approx. 48.5 x 5.5 x 21 cm |
Weight |
approx. 1300 g |
USB cable length |
approx. 150 cm |
Input voltage |
5 V |
Power consumption |
1W max. |
System requirements
Computer |
PC or notebook with sound output |
Processor |
Intel® Core 2 Duo with 1.8 GHz or higher |
Operating system |
Windows® XP/Vista or Windows® 7 |
RAM |
1 GB or more |
Connection |
USB 1.1, USB 2.0 or USB 3.0 interface |
Safety instructions
Before using this device for the first time please read the following instructions carefully and take note of the safety warnings, even if you are familiar with the use of electronic devices. Please keep this manual safe for future reference. If you sell the device or pass it on, always include this manual.
This symbol indicates important information for safe operation of the device and the safety of the user.
This symbol indicates other important information on the topic.
Operating environment
Place the device on a stable, even surface and do not place any heavy objects on the device. The device is not designed for use in environments with a high temperature or humidity (e.g. bathrooms) or in extremely dusty conditions. Operating temperatures and operating air humidity: 5 °C to 35 °C, max. 75 % rel. air humidity.
4 - English
SilverCrest SDJ 100 A1
Ensure that
air can always circulate freely (do not place the device on shelves, on a thick carpet or a bed or anywhere where ventilation slots are covered, and always leave at least 10 cm clearance on all sides);
no direct heat sources (e.g. heating) can affect the device;
no direct sunlight or bright artificial light reaches the device;
contact with sprayed and dripping water and corrosive liquids is prevented and the device is never operated near water; in particular it should never be immersed (do not place any objects filled with liquids such as vases or drinks on or near the device);
the device is not in the immediate vicinity of magnetic fields (e.g. speakers);
no fire sources (e.g. burning candles) are placed on or near the device;
no foreign objects penetrate the device;
the device is not subjected to any extreme temperature fluctuations, as this may result in moisture caused by condensation and therefore a short circuit;
the device is never subjected to excessive shocks and vibrations.
Cables
Always handle the cables by the plug and do not pull on the cables themselves. Never place the device, any furniture or other heavy objects on the cable and take care that the cable is not kinked, especially near the plug and connection sockets. Never make knots in any of the cables or tie them together with other cables. Ensure that all cables are placed so that no one can trip over them and they do not cause an obstruction.
English - 5
SilverCrest SDJ 100 A1
Children and persons with disabilities
Electrical devices do not belong in the hands of children. Persons with disabilities should also only use electrical devices appropriately. Never allow children or persons with disabilities to use electrical devices unsupervised. They may not recognise potential risks. Small parts can be fatal if swallowed. Also always keep plastic packaging out of reach, as it poses a suffocation risk.
Copyright
All information contained in this User Manual is subject to copyright and is provided for information purposes only. It is only permitted to copy or duplicate data and information with the express and written consent of the author. This also includes commercial use of the content and data. The text and illustrations are based on the state of the art at the time of printing.
Back up
Please note: Please ensure that you back up your data after every update to external storage media. Damage claims for lost data or for consequential losses as a result of lost data are excluded.
6 - English
SilverCrest SDJ 100 A1
Control elements
1BROWSE
2PITCH
3FX
4JOG WHEEL
Use this control to scroll through the tracks loaded in the software.
Turn this control to vary the track speed. You can set the minimum and maximum speed here in the software.
Select the required effect by turning the SEL ON/OFF control. The selected effect is shown here in the software. To activate the selected effect, press the SEL ON/OFF control. Press the SEL ON/OFF control again to deactivate the effect. You can vary the intensity of the effect by turning the GAIN control.
With the JOG WHEELs you can "scratch" the track or fast forward to a specific place in the track. You can select the required function with the SCRATCH/SEARCH [10] button.
5 |
TREBLE |
This control serves for damping or amplifying high frequencies. |
6 |
LOAD |
Press the A button to load the selected track in player A or the B |
|
|
button to load the selected track in player B. Please note that the |
|
|
track is only loaded if you have not already loaded a track into the |
|
|
respective player and if the player is paused. |
7MASTER VOLUME Use this control to adjust the volume for both players.
8 |
BASS |
This control serves for damping or amplifying low frequencies (bass). |
9 |
VOLUME |
This control only varies the volume of the required player. |
10 |
SCRATCH/SEARCH |
Press this button to set the JOG WHEEL [4] to SCRATCH mode or |
|
|
to SEARCH mode. |
English - 7
SilverCrest SDJ 100 A1
11CROSSFADER
12SYNC
13REV
14CUE
15II
16HOT1
17HOT2
To seamlessly crossfade between both players, push the CROSSFADER from one player to the other.
Press this button to automatically synchronise the track with the beat of the other track.
Press this button to reverse the playback direction (forwards/backwards).
Press this button to set a CUE point at a specific point of a track.
Play or pause the track.
Press this button to mark the current position of the track. If a mark has been set, this button lights up. You can jump to the mark by pressing the button again during playback. Playback of the track is then started from this mark.
Press this button to mark the current position of the track. If a mark has been set, this button lights up. You can jump to the mark by pressing the button again during playback. Playback of the track is then started from this mark.
8 - English
SilverCrest SDJ 100 A1
Prior to use
Installing the software
First connect the device to the computer before installing the necessary software. Important files can be overwritten and altered during installation of programs or drivers. You should back up the contents of your hard drive before installing the program so that you can still access your original files if there is a problem with the installation.
Insert the enclosed CD ROM into the drive and the installation menu opens automatically.
Install the software (Cross DJ) according to the directions on the screen.
If the device has been correctly connected to the computer, the window for entering the product key opens:
Now enter the product key shown on the CD case.
Confirm the entry by clicking "Submit".
If the setup wizard does not automatically start when the CD-ROM is inserted, then the auto run function of your CD drive is deactivated. Then proceed as follows:
Click on the 'Start' button to open the Start Menu.
Click on the option 'Run...'
Insert the drive letter of your CD-ROM drive, followed by a colon and the program name 'Autorun' (e.g. D:autorun).
Click on the 'OK' button to confirm the entry.
The Cross DJ software
A detailed description of the software functions such as the recording function is given on the enclosed CD-ROM. Please note that the "Preview" function is not supported by the SilverCrest SDJ 100 A1 USB Mixer.
English - 9
SilverCrest SDJ 100 A1
Connecting the USB Mixer
Connect the USB Mixer to the computer. To this purpose insert the small plug of the supplied USB cable into the USB port on the rear of the USB Mixer. Insert the wide plug of the USB cable into a free USB port of your computer.
Set-up
When you have connected the USB Mixer to your computer and have installed the Cross DJ software, the device is ready for use. Start the supplied software to create your mixes. A detailed User Manual for the use of the software is provided on the enclosed CD-ROM.
Players
With the USB Mixer you can control two players. The USB Mixer is designed so that the left-hand controls are used to control the left-hand player (player A) and the right-hand controls for controlling the right-hand player (player B).
The MASTER VOLUME control [7] located in the centre controls the volume of both players (players A and B). Use the CROSSFADER [11] to seamlessly crossfade between both players. The
BROWSE control [1] is used to select a track. For more information, read the following section.
Loading a track
You can highlight a track in the software with the BROWSE control [1]. To this purpose turn the control either clockwise or anti-clockwise. To load the highlighted track into a player, use the LOAD buttons A or B [6] . Press the LOAD A button [6] to load the highlighted track into player A. To load the highlighted track into player B, press the LOAD B button [6].
Please note that a track can only be loaded into a player when the player is paused and if you have not previously loaded a track into the player.
When a track is loaded into the player for the first time, it is analysed. The track speed and the full track information is displayed after this analysis.
10 - English
SilverCrest SDJ 100 A1
Track playback
Press the II button [15] of the respective player to start playback of the loaded track. The II button [15] lights up green during playback. To pause the track, press the II button [15] again.
Adjusting the player volume
You can adjust the player volume with the VOLUME control [9]. To this purpose use the VOLUME control [9] of the respective player.
You can use this control, for example, to adjust the volume of two tracks to the same level during mixing.
Adjusting the master volume
You can adjust the master volume with the MASTER VOLUME control [7]. The volume of both players is then adjusted accordingly.
Mixing tracks
The CROSSFADER [11] permits crossfading of the tracks. If you move the CROSSFADER [11] to the far left, only the track in player A is audible. If you only wish to listen to the track in player B, move the CROSSFADER [11] to the far right. Set the CROSSFADER [11] to the centre position to listen to both tracks (players A and B) at the same time.
If, for example, you want to crossfade from player A to player B, move the
CROSSFADER [11] from the left to the right.
Scratch and search functions
You can use the JOG WHEEL [4] to scratch the track or search for a position in the track. You can also adjust the speed of a track. Press the SCRATCH/SEARCH button [10] to switch from SCRATCH to SEARCH mode. If the SCRATCH/SEARCH button [10] lights up, SCRATCH mode is activated. If the SCRATCH/SEARCH button [10] does not light up, SEARCH mode is activated.
English - 11
SilverCrest SDJ 100 A1
SCRATCH mode (button lights up):
In this mode the track is scratched when the JOG WHEEL [4] is moved. Please note that when you release the JOG WHEEL [4], the track continues to run normally or is paused. If the JOG WHEEL [4] runs on, the track remains unaffected.
SCRATCH mode is available when the player is running or paused.
SEARCH mode (button does not light up):
If the player is paused, a position in the track can be searched for by moving the JOG WHEEL [4]. If the player is playing a track, the speed can be varied by moving the JOG WHEEL [4]. The track is played at the normal speed once more when the JOG WHEEL [4] is released.
The SEARCH mode is only available when a track is paused.
Varying the speed
Use the PITCH control [2] to vary the track speed. You can set the minimum and maximum possible speed here in the software. Set the PITCH control [2] to the centre position until it engages to play the track at the normal speed. Also refer to the software documentation on the enclosed CD.
Automatic track synchronisation
Use the SYNC button [12] to automatically synchronise the beat of the track with the beat of the other track. When you press the SYNC button [12], it lights up briefly. Both tracks then run synchronously and can be crossfaded without interrupting the rhythm.
High frequencies
You can adjust the high frequencies with the TREBLE control [5]. Turn the TREBLE control [5] anticlockwise to dampen the high frequencies. To amplify the high frequencies, turn the TREBLE control [5] clockwise. Set the TREBLE control [5] to the centre position until it engages to ensure an unchanged frequency response.
Low frequencies
You can adjust the low frequencies (bass) with the BASS control [8]. Turn the BASS control [8] anticlockwise to dampen the low frequencies. To amplify the low frequencies, turn the BASS control [8]
12 - English
SilverCrest SDJ 100 A1
clockwise. Set the BASS control [8] to the centre position until it engages to ensure an unchanged frequency response.
Reversing the playback direction
Press the REV button [13] to reverse the playback direction. You can therefore use this function to play a track backwards. To play the track forwards again, press the REV button [13] again. When the track is playing backwards, the REV button [13] lights up red.
Using a CUE point
First set a CUE point at the point in the track from which playback should be started. To this purpose pause playback near the position at which you want to set the CUE point by pressing the II button [15]. Now use the JOG WHEEL [4] to find the exact position on the track.
Ensure that the JOG WHEEL [4] is in SEARCH mode during this function. For further information for setting the SEARCH mode, turn to page 11 in the "Scratch and search functions" section.
The CUE button [14] now flashes and shows that a new CUE point can be set. Now press the CUE button [14] to set the CUE point to the current track position. The CUE button [14] stops flashing and the CUE point was set.
If you press the CUE button [14] during playback, playback is stopped immediately and the player jumps to the CUE point. If no CUE point has been set, the player jumps to the beginning of the track. If you hold down the CUE button [14], the track is played from the CUE point. When you release the
CUE button [14], playback is stopped and the player jumps back to the CUE point.
Using the HOT points
You can set two HOT points for each player. To this purpose use the HOT1 button [16] and the
HOT2 button [17].
Pause playback near the position at which you want to set the HOT point by pressing the II button [15]. Now use the JOG WHEEL [4] to find the exact position on the track.
Ensure that the JOG WHEEL [4] is in SEARCH mode during this function. For further information for setting the SEARCH mode, turn to page 11 in the "Scratch and search functions" section.
Now press the HOT1 button [16] to set the HOT1 point at the current position of the track or the
HOT2 button [17] to set the HOT2 point at the current position of the track. The HOT1 button [16] or HOT2 button [17] now lights up and shows that a HOT point has been set.
English - 13
SilverCrest SDJ 100 A1
If you press the HOT1 button [16] or the HOT2 button [17] during playback, the player jumps to the HOT point and continues playback from this point.
When playback is paused, briefly press the HOT1 button [16] or the HOT2 button [17] to jump to the HOT point. If you press the HOT1 button [16] or the HOT2 button [17] for longer than two seconds (the track is played during this time), the HOT point is deleted and the player jumps to the position of the deleted HOT point. Playback is then paused.
Press the HOT1 button [16] or the HOT2 button [17] several times in quick succession to create a stuttering effect.
The created HOT points are permanently saved. If you load a track into the player, the previously created HOT points are immediately available.
Effects
A wide range of effects are at your disposal that you can integrate into your tracks. Select the desired effect by turning the FX SEL ON/OFF control [3]. The currently selected effect is displayed in the software. Press the FX SEL ON/OFF control [3] to activate the effect. If an effect has been activated, the red LED below the FX SEL ON/OFF control [3] lights up. You can vary the intensity of the effect by turning the FX GAIN control [3]. Press the FX SEL ON/OFF control [3] again to deactivate the effect. Also refer to the software documentation on the enclosed CD.
14 - English
SilverCrest SDJ 100 A1
Servicing/cleaning
Maintenance work is necessary when the device has been damaged in any way, for example if the housing was damaged, if liquid or objects have penetrated the device, if the product has been exposed to rain or moisture or if it does not work correctly or has been dropped. If smoke is produced, or there are any unusual sounds or smells, disconnect the device from your computer immediately. In these cases the device should not be used until it has been inspected by authorised service personnel. Only have the device serviced by qualified personnel. Never open the housing of the device. Only use a clean, dry cloth for cleaning and never use any corrosive liquids. Never try to open the housing of the device as this would void your warranty.
Environmental and disposal information
When this symbol appears on a product, it indicates that the product is subject to the European Directive 2002/96/EC. All electrical and electronic devices must be disposed of separately from household waste at designated disposal points. The correct disposal of old devices in this manner will prevent environmental pollution and human health hazards. For further information about proper disposal contact your local authorities, waste disposal office or the shop where you bought the device.
Dispose of the packaging in an environmentally compatible manner. Cardboard can be put out for municipal paper collections or brought to public collection points for recycling. Films and plastic used for packaging the device are collected by your local disposal services and disposed of in an environmentally compatible manner.
Conformity information
This device conforms with the basic requirements and other required provisions of the EMC Directive 2004/108/EC and RoHS II Directive 2011/65/EU. The conformity declaration is to be found at the end of this instruction manual.
English - 15
SilverCrest SDJ 100 A1
Troubleshooting
The USB Mixer is connected but is not recognised by the operating system.
Check the USB connection.
Are you using a supported operating system? A track is played but there is no audio output.
Check the MASTER VOLUME control [7] and turn it clockwise to increase the master volume.
Check the VOLUME control [9] of the respective player and turn it clockwise to increase the player volume.
Check the position of the CROSSFADER [11] and if necessary move it to the centre position to hear both players.
A selected track is not loaded into the player.
Check whether the player is playing a track. Then pause playback before loading a new track.
16 - English
SilverCrest SDJ 100 A1
Warranty and servicing information
Warranty of Targa GmbH
Dear Customer,
This device is sold with three years warranty from the date of purchase. In the event of product defects, you have legal rights towards the seller. These statutory rights are not restricted by our warranty as described below.
Warranty conditions
The warranty period commences upon the date of purchase. Please keep the original receipt in a safe place as it is required as proof of purchase. If any material or manufacturing faults occur within three years of purchase of this product, we will repair or replace the product free of charge as we deem appropriate.
Warranty period and legal warranty rights
The warranty period is not extended in the event of a warranty claim. This also applies to replaced and repaired parts. Any damage or defects discovered upon purchase must be reported immediately when the product has been unpacked. Any repairs required after the warranty period will be subject to charge.
Scope of warranty
The device was carefully manufactured in compliance with stringent quality guidelines and subjected to thorough testing before it left the works. The warranty applies to material and manufacturing faults. This warranty does not cover product components which are subject to normal wear and which can therefore be regarded as wearing parts, or damage to fragile components such as switches, rechargeable batteries or components made of glass. This warranty is void if the product is damaged, incorrectly used or serviced. To ensure correct use of the product, always comply fully with all instructions contained in the user manual. The warnings and recommendations in the user manual regarding correct and incorrect use and handling of the product must always be observed and complied with. The product is solely designed for private use and is not suitable for commercial applications. The warranty is rendered void in the event of incorrect handling and misuse, if it is subjected to force, and also if any person other than our authorised service technicians interfere with the device. No new warranty period commences if the product is repaired or replaced.
Submitting warranty claims
To ensure speedy handling of your complaint, please note the following:
English - 17
SilverCrest SDJ 100 A1
-Before using your product for the first time, please read the enclosed documentation or online help carefully. Should any problems arise which cannot be solved in this way, please call our hotline.
-Always have your receipt, the product article number as well as the serial number (if available) to hand as proof of purchase.
-If it is not possible to solve the problem on the phone, our hotline support staff will initiate further servicing procedures depending on the fault.
Service
Phone: |
0207 – 36 50 744 |
E-Mail: service.GB@targa-online.com
Phone: |
01 – 242 15 83 |
E-Mail: service.IE@targa-online.com
Phone: |
800 – 62 175 |
E-Mail: service.MT@targa-online.com
Phone: |
800 – 92 496 |
E-Mail: service.CY@targa-online.com
IAN: 76095
Manufacturer
Please note that the following address is not a service address. First contact the service point stated above.
TARGA GmbH
Postfach 22 44
D-59482 Soest
www.targa.de
18 - English
|
SilverCrest SDJ 100 A1 |
Spis treści |
|
Wprowadzenie ................................................................................................... |
20 |
Użytkowanie zgodne z przeznaczeniem............................................................. |
20 |
Zakres dostawy .................................................................................................. |
20 |
Dane techniczne .................................................................................................. |
21 |
Wymagania systemowe ....................................................................................................................... |
21 |
Instrukcje bezpieczeństwa .................................................................................. |
21 |
Warunki otoczenia................................................................................................................................ |
21 |
Przewody ............................................................................................................................................... |
22 |
Dzieci i osoby niepełnosprawne .......................................................................................................... |
23 |
Prawa autorskie ..................................................................................................................................... |
23 |
Zabezpieczanie danych ....................................................................................................................... |
23 |
Elementy obsługi................................................................................................. |
24 |
Przed pierwszym uruchomieniem ....................................................................... |
26 |
Instalacja oprogramowania ................................................................................................................. |
26 |
Program Cross DJ .................................................................................................................................. |
26 |
Podłączanie miksera USB..................................................................................................................... |
27 |
Uruchomienie ...................................................................................................... |
27 |
Odtwarzacze......................................................................................................................................... |
27 |
Wczytanie utworu ................................................................................................................................. |
27 |
Odtwarzanie utworu ............................................................................................................................. |
28 |
Regulacja głośności odtwarzacza ....................................................................................................... |
28 |
Ogólna regulacja głośności ................................................................................................................. |
28 |
Miksowanie utworów............................................................................................................................ |
28 |
Scratch i wyszukiwanie ......................................................................................................................... |
28 |
Regulacja prędkości .............................................................................................................................. |
29 |
Automatyczne dopasowanie utworów ................................................................................................ |
29 |
Wysokie częstotliwości ......................................................................................................................... |
29 |
Niskie częstotliwości ............................................................................................................................. |
30 |
Zmiana kierunku odtwarzania.............................................................................................................. |
30 |
Użycie punktu CUE ............................................................................................................................... |
30 |
Użycie punktów HOT............................................................................................................................ |
30 |
Efekty ...................................................................................................................................................... |
31 |
Polski - 19
SilverCrest SDJ 100 A1 |
|
Konserwacja / czyszczenie.................................................................................. |
32 |
Informacje dotyczące ochrony środowiska i usuwania odpadów ....................... |
32 |
Deklaracja zgodności .......................................................................................... |
32 |
Usuwanie usterek ............................................................................................... |
33 |
Informacje dotyczące gwarancji i serwisowania ................................................. |
34 |
Wprowadzenie
Dziękujemy za zakup miksera USB SilverCrest SDJ 100 A1. Przed pierwszym użyciem urządzenia należy dokładnie zapoznać się z poniższymi instrukcjami. Należy stosować się do wszystkich ostrzeżeń o zagrożeniach, nawet jeśli obsługa urządzeń elektronicznych jest Ci znana. Niniejszą instrukcję należy starannie przechowywać do wykorzystania w przyszłości. W razie sprzedaży lub przekazania urządzenia należy koniecznie dołączyć do niego niniejszą instrukcję.
Użytkowanie zgodne z przeznaczeniem
Mikser USB SilverCrest SDJ 100 A1 umożliwia miksowanie i scratch muzyki cyfrowej na komputerze. Pozwala nadać ulubionej muzyce własny styl lub własnoręcznie miksować nagrania na imprezach.
Jest to urządzenie należące do kategorii elektroniki informatycznej. Urządzenie może być stosowane wyłącznie do użytku prywatnego; wykorzystanie w zastosowaniach przemysłowych i komercyjnych jest zabronione. Oprócz tego nie wolno używać urządzenia poza zamkniętymi pomieszczeniami i w regionach o klimacie tropikalnym. Niniejsze urządzenie spełnia wymagania wszystkich odnośnych norm i dyrektyw, związanych ze zgodnością CE. W przypadku nieuzgodnionych z producentem modyfikacji urządzenia nie można zagwarantować spełnienia wymagań tych norm. Należy stosować tylko akcesoria zalecane przez producenta.
Należy przestrzegać przepisów krajowych lub przepisów kraju użytkowania.
Zakres dostawy
Należy sprawdzić kompletność zawartości opakowania na podstawie poniższej listy:
-Mikser USB SilverCrest SDJ 100 A1
-Kabel USB
-Płyta CD
-Niniejszy podręcznik użytkownika
Jeśli brakuje poszczególnych elementów lub są one uszkodzone, należy skontaktować się z infolinią. Numer telefonu podano w ostatnim rozdziale "Informacje dotyczące gwarancji i serwisowania".
20 - Polski
SilverCrest SDJ 100 A1
Dane techniczne
Wymiary (SxWxG) |
ok. 48,5 x 5,5 x 21 cm |
Masa |
ok. 1300 g |
Długość kabla USB |
ok. 150 cm |
Napięcie wejściowe |
5 V |
Pobór mocy |
maks. 1W |
Wymagania systemowe
Komputer |
PC lub notebook z kartą dźwiękową |
Typ procesora |
Intel® Core 2 Duo z procesorem 1.8 GHz lub wyższym |
System operacyjny |
Windows® XP/Vista lub Windows® 7 |
Pamięć RAM |
1 GB lub więcej |
Złącze |
USB 1.1, USB 2.0 lub USB 3.0 |
Instrukcje bezpieczeństwa
Przed pierwszym użyciem urządzenia należy dokładnie zapoznać się z poniższymi instrukcjami. Należy stosować się do wszystkich ostrzeżeń o zagrożeniach, nawet jeśli obsługa urządzeń elektronicznych jest Ci znana. Niniejszą instrukcję należy starannie przechowywać do wykorzystania w przyszłości. W razie sprzedaży lub przekazania urządzenia należy koniecznie dołączyć do niego niniejszą instrukcję.
Ten symbol oznacza ważne informacje dotyczące bezpiecznej pracy urządzenia i bezpieczeństwa użytkownika.
Ten symbol oznacza dodatkowe informacje na ten temat.
Warunki otoczenia
Urządzenie należy ustawić na stabilnej, poziomej powierzchni. Nie wolno kłaść na nim żadnych ciężkich przedmiotów. Urządzenia nie należy użytkować w pomieszczeniach o wysokiej
Polski - 21
SilverCrest SDJ 100 A1
temperaturze lub wilgotności (np. w łazience) lub w warunkach silnego zapylenia. Temperatura otoczenia i wilgotność podczas pracy: 5 °C do 35 °C, maks. 75 % wilgotności względnej.
Należy zadbać o to, by...
zapewnić swobodną cyrkulację powietrza (nie stawiać urządzenia w regale, na grubym dywanie, na łóżku lub w miejscu, w którym otwory wentylacyjne będą zasłonięte; należy pozostawić co najmniej 10 cm wolnego miejsca z każdej strony);
na urządzenie nie działały bezpośrednie źródła ciepła (kuchenki, grzejniki itp.);
na urządzenie nie padało bezpośrednie światło słoneczne lub silne oświetlenie sztuczne;
unikać kontaktu z wodą rozpryskową i opadową oraz cieczami o agresywnym działaniu. Nie wolno także użytkować urządzenia w pobliżu wody, a w szczególności nie wolno go nigdy zanurzać w wodzie (nie należy umieszczać na urządzeniu lub obok niego naczyń z płynami, np. wazonów czy kubków z napojami);
nie ustawiać urządzenia w bezpośrednim sąsiedztwie źródeł pól magnetycznych (na przykład głośników);
obok lub na urządzeniu nie znajdowały się źródła otwartego ognia (np. palące się świece);
do urządzenia nie dostały się żadne ciała obce;
urządzenie nie było narażone na duże wahania temperatury, gdyż mogłoby to spowodować kondensację pary wodnej wewnątrz urządzenia i zwarcie elektryczne;
urządzenie nie było narażone na nadmierne wstrząsy i drgania.
Przewody
Wszystkie przewody należy chwytać za wtyk; nie należy ciągnąć za sam przewód. Nie stawiać na przewodzie samego urządzenia, mebli ani innych ciężkich przedmiotów i nie zaginać przewodu, w szczególności przy wtyku i przy gniazdach przyłączeniowych. Nigdy nie należy wiązać węzłów na przewodach ani skręcać ich z innymi przewodami. Wszystkie przewody należy prowadzić tak, by nie były narażone na nadepnięcie oraz by nie stanowiły przeszkody.
22 - Polski
SilverCrest SDJ 100 A1
Dzieci i osoby niepełnosprawne
Urządzenia elektryczne powinny znajdować się poza zasięgiem dzieci. Także osoby niepełnosprawne powinny posługiwać się urządzeniami elektrycznymi tylko w odpowiedni sposób. Nigdy nie należy pozwalać dzieciom i osobom niepełnosprawnym używać urządzeń elektrycznych bez nadzoru. Te grupy osób nie zawsze mogą prawidłowo rozpoznać ewentualne zagrożenia. Drobne części mogą w razie połknięcia stanowić zagrożenie dla życia. Folie z opakowań należy także przechowywać poza zasięgiem dzieci. Istnieje niebezpieczeństwo uduszenia.
Prawa autorskie
Cała zawartość niniejszej instrukcji jest chroniona prawem autorskim i jest udostępniana czytelnikowi wyłącznie jako źródło informacji. Wszelkie kopiowanie lub powielanie danych i informacji jest zabronione bez wyraźnej pisemnej zgody autora. Dotyczy to również komercyjnego wykorzystania treści i danych. Tekst i ilustracje są zgodne ze stanem technicznym w chwili oddania do druku.
Zabezpieczanie danych
Należy pamiętać: po każdej aktualizacji danych należy wykonać kopie bezpieczeństwa na zewnętrznych nośnikach danych. Nie istnieją żadne roszczenia regresowe z tytułu utraconych danych czy szkód pośrednich na skutek utraty danych.
Polski - 23
SilverCrest SDJ 100 A1
Elementy obsługi
1 |
BROWSE |
To pokrętło służy do przeglądania utworów cyfrowych wczytanych |
|
|
do urządzenia. |
2 |
PITCH |
To pokrętło służy do zmiany prędkości utworu. Program umożliwia |
|
|
ustawienie prędkości minimalnej i maksymalnej. |
3 |
FX |
Za pomocą pokrętła SEL ON/OFF można wybrać określony efekt. |
|
|
Wybrany efekt wyświetlany jest w programie. Aby aktywować |
|
|
wybrany efekt, należy nacisnąć pokrętło SEL ON/OFF. Ponowne |
naciśnięcie pokrętła SEL ON/OFF powoduje dezaktywowanie wybranego efektu. Intensywność efektu można zmieniać obracając pokrętłem GAIN.
4JOG WHEEL
5TREBLE
6LOAD
Tarcza JOG WHEEL służy do "scratchowania" utworu lub "przewijania" do określonego miejsca utworu. Do regulowania wybranej funkcji służy przycisk SCRATCH/SEARCH [10].
To pokrętło służy do tłumienia lub wzmacniania wysokich częstotliwości.
Aby wczytać wybrany utwór do odtwarzacza A, należy wcisnąć przycisk A, aby wczytać utwór do odtwarzacza B – wcisnąć przycisk B. Należy pamiętać o tym, że utwór zostanie wczytany jedynie wówczas, gdy w wybranym odtwarzaczu nie ma jeszcze żadnego utworu lub odtwarzanie jest zatrzymane.
7MASTER VOLUME To pokrętło służy do regulowania głośności w obu odtwarzaczach.
8 |
BASS |
To pokrętło służy do tłumienia lub wzmacniania niskich |
|
|
częstotliwości (bas). |
24 - Polski
|
|
SilverCrest SDJ 100 A1 |
9 |
VOLUME |
Za pomocą tego pokrętła można zmienić poziom głośności |
|
|
wybranego odtwarzacza. |
10SCRATCH/SEARCH Ten przycisk należy wcisnąć, aby przełączyć tarczę JOG WHEEL
[4]na tryb SCRATCH lub SEARCH.
11CROSSFADER Suwak CROSSFADER służy do płynnego przenikania dźwięku
między jednym i drugim odtwarzaczem.
12 |
SYNC |
Ten przycisk należy wcisnąć, aby automatycznie dopasować rytm |
|
|
jednego utworu do drugiego. |
13 |
REV |
Ten przycisk należy wcisnąć, aby odwrócić kierunek odtwarzania |
|
|
(do tyłu/do przodu). |
14CUE
15II
16HOT1
Ten przycisk służy do ustawiania punktu CUE w wybranym miejscu utworu.
Odtwarzanie lub zatrzymanie utworu.
Ten przycisk należy wcisnąć, aby ustawić zaznaczenie w bieżącym miejscu utworu. Po ustawieniu zaznaczenia przycisk się świeci. Podczas odtwarzania utworu można przejść do zaznaczonego miejsca poprzez ponowne wciśnięcie przycisku. Odtwarzanie utworu rozpocznie się od zaznaczonego miejsca.
17 HOT2 |
Ten przycisk należy wcisnąć, aby ustawić zaznaczenie w bieżącym |
|
miejscu utworu. Po ustawieniu zaznaczenia przycisk się świeci. |
|
Podczas odtwarzania utworu można przejść do zaznaczonego |
|
miejsca poprzez ponowne wciśnięcie przycisku. Odtwarzanie |
|
utworu rozpocznie się od zaznaczonego miejsca. |
Polski - 25
Loading...
