SilverCrest SED 3.7 D2 User Manual

CORDLESS EPILATOR SED 3.7 D2

CORDLESS EPILATOR	EPILATOR, GENOPLADELIGT
Operating instructions	BATTERI/STRØMFORSYNING
	Betjeningsvejledning
EPILIERER, AKKU/NETZ
Bedienungsanleitung

IAN 273035

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

GB	Operating instructions	Page	1
DK	Betjeningsvejledning	Side	17
DE / AT / CH	Bedienungsanleitung	Seite	33

A

1

2

33

4

5

6

7

B	9	0
	8

Table of Contents

GB

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Items supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Disposal of packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Operating Elements. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Mains power operation . . . . . . . . . . . . . . . . . . . . . . . . 8 Battery operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Tips and Tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Epilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Cleaning and Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Disposal of the appliance . . . . . . . . . . . . . . . . . . . . . . 14 Warranty and Service . . . . . . . . . . . . . . . . . . . . . . . . 15 Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

SED 3.7 D2

1

Introduction

GB

Congratulations on the purchase of your new appliance.

You have clearly decided in favour of a quality product. These operating instructions are a part of this product. They contain important information in regard to safety, use and disposal. Before using the product, familiarise yourself with all of these operating and safety instructions. Use the product only as described and only for the specified areas of application. In addition, pass these documents on, together with the product, to any future owner.

Copyright

This documentation is copyright protected.

Any copying or reproduction, including as extracts, as well as the reproduction of images, also in an altered state, is only permitted with the written authorisation of the manufacturer.

Intended Use

This appliance is intended exclusively for the epilation of human hair in domestic households. Do not use it for commercial purposes! This appliance is not intended for any other use or for uses beyond those mentioned.

Claims of any kind resulting from damage caused by improper use, incompetent repairs, unauthorised modifications or the use of nonapproved spare parts will not be acknowledged.

The operator alone bears the risk.

2	SED 3.7 D2

Items supplied

GB

The appliance is supplied with the following components as standard:

■Cordless Epilator

■Mains adapter

■Cleaning brush

■Storage pouch

■Operating Instructions

Extract all parts of the appliance from the carton and remove all packaging material. Check the contents to ensure everything has been supplied, and for signs of visible damage.

TIPS

►As delivered, the storage pouch is located under the plastic shell containing the device itself. You must remove the cardboard under the plastic shell in order to take the storage pouch out.

►If the delivery is incomplete, or has been damaged due to defective packaging or transportation, contact the Service Hotline (see chapter Warranty and Service).

Disposal of packaging

The packaging protects the appliance against transport damage. The packaging materials are selected from the point of view of their environmental friendliness and disposal technology and are therefore recyclable.

The recirculation of packaging into the material circuit saves on raw material and reduces generated waste. Dispose of packaging material that is no longer needed as per the regionally established regulations .

SED 3.7 D2

3

Operating Elements

GB

Figure A:

Protective cap Epilator head

Restraint fixtures for epilator head Travel lock

Speed switch

Control lamps red/green Socket for mains adapter

Figure B:

Mains power adapter

Storage pouch

Cleaning brush

Technical data

Mains adapter

Type	ZDJ045100EU
Input voltage	100 - 240 V ~, 50/60 Hz
Power consumption		0.2 A Max.
Output voltage		4.5 V
Output current		1000 mA
Protection class			II/
Polarity

4	SED 3.7 D2

Device						GB
Input voltage			4.5 V
Power consumption			1000 mA
Batteries	3,7 V		700mAh Lithium ion battery

Safety instructions

RISK OF ELECTRIC SHOCK

►Connect the appliance only to correctly installed mains power sockets supplying a current rating of 100 - 240 V ~ / 50/60 Hz.

►The power cable on this appliance cannot be replaced. In the event of it being damaged the whole appliance must be disposed of.

►In the event of operational malfunction, and for cleaning, always remove the plug from the mains power socket.

►To disconnect the power cable, always pull the plug itself from the mains power socket, do not pull on the cable.

►Do not kink or crimp the power cable and place it in such a way as to prevent anyone from stepping on or tripping over it.

SED 3.7 D2

5

GB	RISK OF ELECTRIC SHOCK

►Ensure that the power cable cannot become wet or moist during operation. Place it such that it cannot be squashed or damaged.

►To avoid risks, should the appliance be damaged discontinue the use of it immediately.

►Do not use the appliance outdoors.

►Do not wrap the power cable around the appliance and protect it from being damaged.

►NEVER grasp the appliance, power cable or plug with wet hands.

►TAKE NOTE! Keep the appliance dry.

Never use the appliance near water, particularly not near sinks, baths or other vessels. The proximity of moisture presents a danger, even when the appliance is switched o . After use, always remove the plug from the mains power socket. As additional protection, the installation of a faulty-current protection unit with an activation power rating of not more than 30 mA is recommended for the power circuit in the bathroom.

Consult your electrician for advice.

6	SED 3.7 D2

WARNING! RISK OF INJURY!

GB

►Do not operate the appliance if it has sustained a fall or is damaged. Arrange for the appliance to be checked and/or repaired by qualified technicians.

►Do not open the housing or attempt to repair the appliance yourself. Should you do so, appliance safety can no longer be assured and the warranty will become void. Permit only authorised technicians to repair a defective appliance if repairs should be necessary.

►Use the appliance only with the supplied power adapter.

►Charge the appliance only with the supplied power adapter.

►This appliance may be used by children aged 8 over and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have been told how to use the appliance safely and are aware of the potential risks.

►Children must not play with the appliance.

►Cleaning and user maintenance tasks must not be carried out by children unless they are supervised.

SED 3.7 D2

7

	GB	WARNING - PROPERTY DAMAGE!
		► Use the appliance only indoors.

Mains power operation

1)	Insert the connector plug of the mains power adapter				into the
	socket for mains adapter		on the appliance. Ensure that the
	speed switch	is set at “0”.
2)	Connect the mains power adapter			to a mains power socket.
	The control lamp	glows red to indicate that the charging
	process is active.

The appliance is ready for immediate use.

Battery operation

1)	Insert the connector plug of the mains power adapter				into the
	socket for mains adapter		on the appliance. Ensure that the
	speed switch	is set at “0”.
2)	Connect the mains power adapter			to a mains power socket.
	The control lamp	glows red to indicate that the charging
	process is active.
As soon as the control lamp			glows green the appliance is fully

charged and you can disconnect it from the mains power supply.

NOTICE

►For the initial charging, the appliance requires about 80 minutes to fully charge.

► First recharge the appliance when the control lamps indicate, by alternately flashing red and green, that the battery charge level is low..

8	SED 3.7 D2

Tips and Tricks

GB

NOTICE

►Do not use the appliance if...

―You have a sunburn on the specific part of the body.

―Skin irritation or redness is extant.

―You have a skin disease such as, for example, neurodermatitis.

―You have pimples, moles or warts on the specific parts of the body.

―You have wounds, open sores or raised scars on the specific parts of the body.

►First test the appliance on a small hidden location to establish the skin compatibility.

■The hairs should be between 0.3 cm and 0.5 cm long. Shorter hairs are not gripped by the tweezers and plucking out longer hairs is very painful. If needs be, shorten long hair.

■The skin must be free of grease or cream residues. Otherwise, the tweezers will stick/soil and the e ciency of the appliance will be reduced.

■The skin must be completely dry.

■The best time for epilation is in the evening after a shower. Then the skin is somewhat softened, so that the hairs can be plucked out easily. In addition, the skin can recover overnight, and any skin reddening will recede.

SED 3.7 D2

9

■ Before epilation, treat the skin with a peeling or a massage glove. GB This helps remove dead skin cells, ingrowing hairs are avoided,

and fine hairs stand proud. This enables the appliance to grip the hairs better.

■After epilation, nurture the skin with a moisturising lotion or cream. Ideally, the cream will contain aloe vera or camomile extracts to soothe and maintain the skin.

Epilation

When the appliance is charged and the body part to be epilated is prepared:

1)Rub your hand once more against the growth direction of the hairs to be removed. Through this the hairs will be raised so that they can be better captured by the tweezers.

2)	Remove the protective cap		from the epilator head .
3)	Press the travel lock	and slide the speed switch		upwards to
	the desired speed level:

―Level 1: for sensitive areas (armpits and bikini line)

―Level 2: for legs

4)Hold the skin tight with one hand.

5)Place the epilator perpendicular to the skin and, without exerting any pressure, move it against the direction of the hair growth.

Thereby, the side with the speed switch must face towards you. Do not make back and forth or circular movements. Always start anew and pass over the body part to be epilated several times, so that all of the hair is removed.

10	SED 3.7 D2

NOTICE

GB

►It may be that the hair grows back after a few days. The reason for this is that these hairs were too short to be removed during the last epilation session.

6)When you are finished with the treatment, place the speed switch to “0”.

7)	Clean the epilator head	as described in the section “Cleaning
	and Care”.
8)	Replace the protective cap	on the epilator head .

NOTICE

► If the epilator head is damaged, discontinue all further use! To order a new epilator head , please contact the service department (see chapter “Guarantee and service”). Please have the IAN number ready (see operating manual cover).

To replace the epilator head , please proceed as follows:

―	Press the two restraint fixtures		together and at the
	same time pull the epilator head		upwards.
―	Press the new epilator head	onto the appliance.
	Ensure that the gears on the epilator head			and on
	the appliance mesh with each other. The epilator head
	must audibly engage.

SED 3.7 D2

11

Cleaning and Care

GB

RISK OF ELECTRIC SHOCK

► Before cleaning, disconnect the appliance from the mains power adapter and the mains power adapter from the main power supply.

WARNING - PROPERTY DAMAGE!

► NEVER submerse the appliance in water or other liquids!

■	After every use clean the epilator head				with the supplied
	cleaning brush to remove loose hairs.
■	Disinfect the epilator head		regularly by spraying and cleaning
	it with disinfectant spray.
■	To thoroughly clean the epilator head				you can remove it from
	the appliance:
	―	Press the two restraint fixtures		together and at the same
		time pull the epilator head		upwards.
	―	Clean the epilator head	under running water and then
		allow it to dry.
	―	Place the epilator head	back onto the appliance. Ensure
		that the gears on the epilator head			and on the appliance
		mesh with each other. The epilator head				must audibly
		engage.

■Clean the appliance housing and the mains power adapter

with a moist cloth. If required, use some mild detergent on the cloth. Ensure that the appliance is completely dry before the next use.

12	SED 3.7 D2

Storage

				GB
■	Always protect the epilator head		with the supplied protective
	cap .
■	Store the appliance, the cleaning brush			and the mains power
	adapter	in the storage pouch .

■ Store the appliance at a dry and dustfree location.

Troubleshooting

	Problem	Cause	Solution
		The battery is	Recharge the
	The appliance	drained.	appliance.
	does not function.	The appliance	In this case, contact
		is defective.	Customer Services.
	The appliance	The battery is	Recharge the
	only runs slowly.	drained.	appliance.
	The plucking of		Shorten the hairs to
		The hairs may be	about 0.3 - 0.5 cm.
	the hairs is very
		too long.	See also the section
	painful.
			"Tips and Tricks".
		It is possible that the	The hairs should
			have a length of
		hairs are too short.
	Not all hairs are		0.3 - 0.5 cm.
	plucked.	You are working	Move the appliance
			more slowly over your
		too fast.
			skin.

SED 3.7 D2

13
