Machine and setting data |
1 |
|
This List Manual provides information on all the machine and setting data.
A functional description of the data is provided in the Function Manual indicated in the cross reference.
For additional descriptions
Further detailed information is available direclty through the online help of the control system.
Standard table
The standard table contains all the important information about a SINUMERIK machine data.
MD number |
Identifier |
|
|
Display filter |
Reference |
|
Units |
Name |
|
|
Data type |
Effectiveness |
|
Attributes |
|
|
|
|
|
|
System |
Dimension |
Default value |
Minimum value |
Maximum value |
Protection |
Class |
|
|
(LIN/RED) |
(LIN/RED) |
(LIN/RED) |
|
|
Expanded table
The expanded table includes data from the standard table plus additional rows with systemspecific values.
MD number |
Identifier |
|
|
Display filter |
Reference |
|
Units |
Name |
|
|
Data type |
Effectiveness |
|
Attributes |
|
|
|
|
|
|
- |
Dimension |
Default value |
Minimum value |
Maximum value |
Protection |
Class |
|
|
(LIN/RED) |
(LIN/RED) |
(LIN/RED) |
|
|
<System 1> |
- |
- |
- |
- |
-/- |
|
<System 2> |
- |
- |
- |
- |
-1/- |
|
Machine data and parameters |
7 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
A minus sign "-" in a field means that the same value as for <System 1> applies for the specified system.
The entry "-/-" in the "Protection" field means that the machine data is not available for the specified system.
Example:
18353 |
MM_M_FILE_MEM_SIZE |
|
EXP, N02 |
S7 |
|
|
- |
Memory size for cycles/files of the machine |
DWORD |
POWER ON |
|
||
|
manufacturer |
|
|
|
|
|
|
|
|
|
|
|
|
840dsl-71 |
3 |
512,0,0 |
0 |
9216 |
1/1 |
M |
840dsl-72 |
3 |
512,0,0 |
0 |
15360 |
1/1 |
M |
840dsl-73 |
3 |
512,0,0 |
0 |
15360 |
1/1 |
M |
MD number
The "MD number" field contains the machine data number. This number is displayed in the data lists on the user interface of the control.
Identifier
The "Identifier" field contains the unique alphanumeric identifier of the machine data. The machine data is, for example, addressed by means of this identifier (with an additional label) for programming in the part program.
This identifier is displayed in the data lists on the user interface of the control.
Reference
As a cross reference to the functional description of the data, the "Reference" field contains the short designation of the corresponding submanual of a function manual.
Reference is made to the following submanuals:
•Function Manual Basic Functions, submanuals: A2, A3, B1, B2, D1, F1, G2, H2, K1, K2, N2, P1, P3, P4, R1, S1, V1, W1, Z1
•Function Manual Extended Functions, submanuals: A4, B3, B4, H1, K3, K5, M1, M5, N3, N4, P2, P5, R2, S3, S7, T1, W3, W4, Z2
•Function Manual Special Functions, supporting manuals: F2, G1, G3, K6, M3, R3, S9, T3, TE01, TE02, TE1, TE3, TE4, TE6, TE7, TE8, TE9, V2, W5, W6, Z3
•Function Manual Safety Integrated, FBSI
8 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
•
•
Function Manual Tool Management, FBWsl
Function description, ISO Dialects for SINUMERIK, FBFA
Units/system of units
Depending on MD10240 $MN_SCALING_SYSTEM_IS_METRIC, the physical units differ as follows:
MD10240=1 |
MD10240=0 |
mm |
inch |
mm/min |
inch/min |
m/sec2 |
inch/sec2 |
m/sec3 |
Inch/sec3 |
mm/rev. |
inch/rev. |
If the MD is not based on any physical unit, the field is marked with "-".
Note
The default setting is MD10240 $MN_SCALING_SYSTEM_IS_METRIC = 1 (metric)
Name
The "Name" field contains the name of the data in plain text.
Effectiveness
The "Activation" field contains the action that must be performed by the user in order for a change to take effect.
Effectiveness |
User action |
||
po |
POWER ON |
Alternatively: |
|
|
|
• |
"Reset(po)" softkey |
|
|
• |
Switch voltage off/on |
cf |
NEW_CONF |
Alternatively: |
|
|
|
• |
Softkey: "Activate MD" |
|
|
|
New values will be effective only if all the channels of the mode |
|
|
|
group to which the axis belongs to are in the "Reset" state. |
|
|
• Part program command: NEWCONF |
|
|
|
|
New values for position-controlled axs/spindles will be effective only |
|
|
|
if the affected axis/spindle is stationary. |
|
|
|
For non-position-controlled spindles new values take effect |
|
|
|
immediately. |
re |
RESET |
Alternatively: |
|
|
|
• |
"Reset(po)" softkey |
|
|
• Program end reset (M02/M30) |
|
so |
IMMEDIATELY |
After entering the value |
Machine data and parameters |
9 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
The activation levels are listed according to their priority.
•
•
po = highest priority so = lowest priority
Protection
The "Protection" field contains the protection level for reading or writing to the data in the form: Read/write.
Value |
Protection level |
0 or 10 |
System |
1 or 11 |
Manufacturer |
2 or 12 |
Service |
3 or 13 |
User |
4 or 14 |
Key-operated switch position 3 |
5 or 15 |
Key-operated switch position 2 |
6 or 16 |
Key-operated switch position 1 |
7 or 17 |
Key-operated switch position 0 |
The protection level for user data (GUD) is defined with the numbers 10 to 17.
Class
The data class attributes of machine, setting and option data are normally derived from the write rights of the corresponding data.
The following data classes are available:
Data class |
Write rights |
Access right |
S (System) |
System |
Protection level 0 (password: System) |
M (Manufacturer) |
Manufacturer/Service |
Protection levels 1 and 2 (password: Service) |
I (Individual) |
Manufacturer/Service |
Protection levels 1 and 2 (password: Service) |
Note: |
or |
or |
Individual machine data are grouped in |
User |
Protection level 3 (user password) |
this data class, e.g. the leadscrew error |
|
|
compensation values. |
|
|
Depending on the contents, these are |
|
|
accessible via different protection |
|
|
levels. |
|
|
U (User) |
User |
Protection level 3 (password: User) |
|
|
Protection levels 4 and 7 (key-operated switch) |
10 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Display filter
The "Display filter" field contains the identifier of the data filter setting that enables the data to be seen. Using the filter setting, the exact data areas required at a given time can be selected for display.
ID |
Data area |
EXP |
Expert mode |
Drive machine data |
|
D00 |
Display signals |
D01 |
Controller data |
D02 |
Monitoring/limiting functions |
D03 |
Message data |
D04 |
Status data |
D05 |
Motor/power unit |
D06 |
Measuring system |
D07 |
Safety Integrated |
D08 |
Standard machine |
General machine data |
|
N01 |
Configuration/scaling |
N02 |
Memory configuration |
N03 |
PLC machine data |
N04 |
Drive control |
N05 |
Status data/diagnostics |
N06 |
Monitoring/limiting functions |
N07 |
Auxiliary functions |
N08 |
Corrections/compensations |
N09 |
Technological functions |
N10 |
I/O configuration |
N11 |
Standard machine |
A12 |
NC language, ISO dialect |
Channel-specific machine data |
|
C01 |
Configuration |
C02 |
Memory configuration |
C03 |
Initial states |
C04 |
Auxiliary functions |
C05 |
Velocities |
C06 |
Monitoring/limiting functions |
C07 |
Transformations |
C08 |
Corrections/compensations |
C09 |
Technological functions |
C10 |
Standard machine |
C11 |
NC language, ISO dialect |
Machine data and parameters |
11 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
ID |
Data area |
Axis-specific machine data |
|
A01 |
Configuration (including memory) |
A02 |
Measuring system |
A03 |
Machine geometry |
A04 |
Velocities / accelerations |
A05 |
Monitoring/limiting functions |
A06 |
Spindle |
A07 |
Controller data |
A08 |
Status data |
A09 |
Corrections/compensations |
A10 |
Technological functions |
A11 |
Standard machine |
A12 |
NC language, ISO dialect |
Display machine data |
|
H01 |
ShopMill |
H02 |
ShopTurn |
H03 |
ManualTurn |
H04 |
Access levels |
H05 |
Standard machine |
System
In the "System" field, the control system is specified for which the data with the correspondingly entered values applies.
The following entries are possible:
840dsl-71 NCU710
840dsl-72 NCU720
840dsl-73 NCU730
If this field is empty, the data is valid for all systems.
Dimension
The "Dimension" field contains the number of elements of a data field.
Default value
The "Default value" field contains the value that is used to preset the machine data.
12 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Some machine data is preset with different default values, depending on the NCU that is used.
Note
When input via the user interface, this is limited to ten digits plus comma and sign.
In the bracket "LIN/RED" the linear axis or rotary axis value is specified.
Range of values
The "Minimum value" and "Maximum value" fields contain the lower limit and upper limit, respectively, of the permissible range of the data.
If the "Minimum value" and "Maximum value" fields contain the string " *** ", an explicit range is not defined for this data. In this case, the range is determined by the specified data type.
SINUMERIK data types
The "Data type" field contains the following data types:
Data type |
Range of values |
BOOLEAN |
Machine data bit (1 or 0) |
BYTE |
Integer values ( -128 to 127 ) |
DOUBLE |
Real values ( ± ( 2.2 * 10-308 to 1.8 * 10+308 ) ) |
DWORD |
Integer values ( -2147483648 to +2147483647 ) |
DWORD |
Hex values ( 0 to FFFF FFFF ) |
STRING |
Character string (max. 16 characters) consisting of upper-case letters |
|
with digits and underscore |
UNSIGNED WORD |
Integer values ( 0 to 65536 ) |
SIGNED WORD |
Integer values ( -32768 to 32767 ) |
UNSIGNED DWORD |
Integer values ( 0 to 4294967300 ) |
SIGNED DWORD |
Integer values ( -2147483650 to 2147483649 ) |
WORD |
Hex values ( 0000 to FFFF ) |
FLOAT DWORD |
Real values ( ± ( 8.43 x 10-37 to "3.37 x 1038 ) |
UBYTE |
Integer values ( 0 to 255 ) |
LONG |
Integer values ( 4294967296 to 4294967295 ) |
Attributes
The "Attributes" field contains additional attributes of the data:
Attribute |
Meaning |
NBUP |
No Back UP: The data is not backed up as part of the data backup. |
ODLD |
Only DownLoaD: The data can only be written to via an ini file, archive, |
|
or from the part program. |
NDLD |
No DownLoaD: The data can only be written to via the user interface. |
Machine data and parameters |
13 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Attribute |
Meaning |
SFCO |
SaFety COnfiguration: Component of the "Safety Integrated". |
SCAL |
SCaling ALarm: Scaling data; when changed, alarm 4070 is displayed |
LINK |
LINK description: The data describes a link cluster, component of the |
|
"NCU Link" function |
CTEQ |
ConTainer EQual: The data must be the same for all axes in an axis |
|
container, component of the "Axis container" function |
CTDE |
ConTainer DEscription: The data describes an axis container, |
|
component of the "Axis container" function |
Number ranges SINUMERIK
The machine and setting data are divided into number ranges.
The identifier specified in the data description is displayed on the user interface. However, if the data is addressed in the part program, for example, the identifier of the relevant data area must precede the data identifier.
Data area |
|
Identifier |
Description |
From |
to |
|
|
9000 |
9999 |
$MM_ |
Display machine data |
10000 |
18999 |
$MN_ |
General NC machine data and |
|
|
|
general machine data for Safety Integrated |
|
|
|
|
19000 |
19999 |
$ON_ |
Option data |
20000 |
28999 |
$MC_ |
Channel-specific machine data |
29000 |
29999 |
$OC_ |
Channel-specific option data |
30000 |
38999 |
$MA_ |
Axis-specific machine data and |
|
|
|
axis-specific machine data for Safety Integrated |
39000 |
39999 |
|
Reserved |
41000 |
41999 |
$SN_ |
General setting data |
42000 |
42999 |
$SC_ |
Channel-specific setting data |
43000 |
43999 |
$SA_ |
Axis-specific setting data |
51000 |
51299 |
$MNS_ |
General configuration machine data |
51300 |
51999 |
|
General cycle machine data |
52000 |
52299 |
$MCS_ |
Channel-specific configuration machine data |
52300 |
52999 |
|
Channel-specific cycle machine data |
53000 |
53299 |
$MAS_ |
Axis-specific configuration machine data |
53300 |
53999 |
|
Axis-specific cycle machine data |
54000 |
54299 |
$SNS_ |
General configuration setting data |
54300 |
54999 |
|
General cycle setting data |
14 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
|
|
|
|
Machine and setting data |
|
|
|
|
1.1 Explanation of the machine/setting data |
|
|
|
|
|
|
Data area |
|
Identifier |
Description |
|
From |
to |
|
|
|
55000 |
55299 |
$SCS_ |
Axis-specific configuration setting data |
|
55300 |
55999 |
|
Axis-specific cycle setting data |
|
56000 |
56299 |
$SAS_ |
Axis-specific configuration setting data |
|
56300 |
56999 |
|
Axis-specific cycle setting data |
Data Identifiers
Characters Meanings
$System variables
MMachine data (first letter)
SSetting data (first letter)
OOption data (first letter)
M, N, C, A |
Subarea (second letter) |
SSiemens data (third letter)
Note
Axis-specific data can also be addressed with the axis name as an index. The internal axis identifier (AX1, AX2, AX3, etc.) or the identifier specified in
MD10000 $MN_AXCONF_MACHAX_NAME_TAB can be used as the axis name.
Example: $MC_JOG_VELO[Y1]=2000
The JOG velocity of axis Y1 is 2000 mm/min.
Example: $MA_FIX_POINT_POS[0,X1]=500.000
The value 500 is assigned to the first fixed point position on axis 1.
Examples: $MN_AUXFU_GROUP_SPEC[2]='H41'
If the content of a machine data is a STRING (e.g. Y1) or a hexadecimal value (e.g. H41) the contents must lie between " ' " (e.g. 'H41').
Output instant in time of the auxiliary functions of the 3rd auxiliary function group.
$MN_AXCONF_MACHAX_NAME_TAB[0]='X1'
String "X1" is assigned as name for the first machine axis. $MA_REFP_SET_POS[0,X1]=100.00000
A value of 100 mm is assigned to the first reference point of axis X1.
Machine data and parameters |
15 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Examples:
Assignment to channel-specific machine data:
CHANDATA(1) $MC_CHAN_NAME='CHAN1' $MC_AXCONF_GEOAX_NAME_TAB[1]='Y'
;Selection of the first channel
;Name of the first channel
;Name of the 2nd geometry axis
;of the first channel 'Y'
R10=33.75 |
; R10 of the first channel |
Basic structure of the parameter description
The tables of SINAMICS parameters all have the following standard structure:
Parameter |
BICO: Full parameter name / short parameter name |
|
|
number |
|
|
|
Drive object |
Can be changed: |
Calculated: |
Access level: |
(function module) |
|
|
|
Data type: |
Dynamic index: |
Function diagram: |
|
|
P group: |
Unit group: |
Unit selection: |
|
Not for motor type: |
Normalizing |
Expert list: |
|
Min. |
Max. |
Factory setting |
Example
r0025[0...3] |
CO: Input voltage, smoothed |
|
|
A_INF, S_INF |
Can be changed: - |
Calculated: - |
Access level: 2 |
|
Data type: FloatingPoint32 |
Dynamic index: |
Function diagram: 8850, 8950 |
|
P group: Display, signals |
Unit group: - |
Unit selection: - |
|
Not for motor type: - |
Normalization p2001 |
Expert list: 1 |
|
Min |
Max |
Factory setting |
|
- [Vrms] |
- [Vrms] |
- [Vrms] |
References
You can find a detailed description of SINAMICS parameters in the following document: SINAMICS S120/S150 List Manual
16 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Parameter number pxxxx[0...n]
The "parameter number" field contains the number of the parameter.
The number consists of a leading "p" or "r", followed by the parameter number and the index (optional).
p... |
Adjustable parameter (read and write parameter) |
r... |
Display parameter (read-only) |
p0918 |
Adjustable parameter 918 |
p0099[0...3] |
Adjustable parameter 99, indices 0 to 3 |
p1001[0...n] |
Adjustable parameter 1001, indices 0 to n (n = configurable) |
r0944 |
Display parameter 944 |
BICO: Full parameter name / short parameter name
The following abbreviations can appear in front of the parameter name:
BI |
Binector Input |
|
This parameter selects the source of a digital signal. |
BO |
Binector Output |
|
This parameter is available as an digital signal for interconnection with other |
|
parameters. |
CI |
Connector Input |
|
This parameter selects the source of an "analog" signal. |
CO |
Connector Output |
|
This parameter is available as an "analog" signal for interconnection with other |
|
parameters. |
CO/BO |
Connector/Binector Output |
|
This parameter is available as both an "analog" and also as digital signals for |
|
interconnection with other parameters. |
Drive object (function module)
A drive object (DO) is an independent, "self-contained" functional unit with its own parameters, faults messages, and alarms.
The parameter list specifies the associated drive object and function module for each individual parameter.
Machine data and parameters |
17 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Can be changed
The "-" sign indicates that the parameter can be changed in any object state and that the change will be effective immediately.
The information C1(x), C2(x), T, U ((x): optional) means that the parameter can be changed only in the specified drive object state and that the change will not take effect until the object switches to another state. This can be one or more states.
The following states are available:
C1(x) |
Commissioning device C1 |
C1: Commissioning 1 |
Device is in the process of being commissioned (p0009 > 0). The pulses cannot be enabled.
The parameter can only be changed in the following device commissioning settings (p0009 > 0):
C1: can be changed for all settings p0009 > 0. C1(x): can only be changed for the settings p0009 = x.
A modified parameter value does not take effect until the device commissioning mode is exited with p0009 = 0.
C2(x) |
Drive object commissioning |
C2: Commissioning 2 |
The drive is in the process of being commissioned (p0009 = 0 and p0010 > 0). The pulses cannot be enabled.
The parameter can only be changed in the following device commissioning settings (p0010 > 0):
C2: can be changed for all settings p0010 > 0. C2(x): can be changed for the settings p0010 = x.
A modified parameter value does not take effect until drive commissioning mode is exited with p0010 = 0
U |
Operation |
U: Run |
|
The pulses are enabled |
|
T |
Ready |
T: Ready to run |
The pulses are not enabled Status "C1(x)" or "C2(x)" is not active.
Calculated
Specifies whether the parameter is influenced by automatic calculations. The calculation attribute defines which activities influence the parameter.
Access level
Specifies the access level required to be able to display and change this parameter. The required access level can be set using p0003.
Parameters with the following access level are password-protected:
1.Standard
2.Extended
18 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
3.Expert
4.Service
Parameters with this access level are protected by a password.
Data type
The information on the data type can consist of the following two items (separated by a slash).
•First information
Data type of the parameter.
•Second information (for binector or connector input only)
Data type of the signal source to be interconnected (binector/connector output).
Parameters can have the following data types:
I8 |
Integer8 |
8-bit integer number |
I16 |
Integer16 |
16-bit integer number |
I32 |
Integer32 |
32-bit integer number |
U8 |
Unsigned8 |
8 bits without sign |
U16 |
Unsigned16 |
16 bits without sign |
U32 |
Unsigned32 |
32 bits without sign |
Float |
FloatingPoint32 |
32-bit floating point number |
Dynamic index
For parameters with a dynamic index [0 to n], the following information is specified:
•
•
Data set (if available).
Parameter for the number of indices (n = number -1).
Function diagram
The parameter is included in this function diagram. The structure of the parameter function and its relationship with other parameters are shown in the function diagram.
P group
Specifies the functional group to which this parameter belongs. The required parameter group can be set via p0004.
Unit, unit group, unit selection
The standard unit of a parameter is specified in square brackets after the values for "Min", "Max", and "Factory setting".
For parameters where the unit can be changed, "Unit Group" and "Unit Selection" specify which group this parameter belongs and which parameter can be used to change the unit.
Machine data and parameters |
19 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Not for motor type
Specifies for which motor type this parameter has no significance
ASM |
Induction motor |
FEM |
Separately excited synchronous motor |
PEM |
Permanent-magnet synchronous motor |
REL |
Reluctance motor/SIEMOSYN motor |
Normalizing
Specification of the reference variable with which a signal value is automatically converted for a BICO interconnection.
The following reference variables are possible:
p2000 ... p2007: |
Reference speed, reference voltage, etc. |
TEMP: |
100°C = 100% |
PERCENT: |
1.0 = 100 % |
4000H: |
4000 hex = 100 % |
Expert list
Specifies whether this parameter is available in the expert list of the specified drive objects in the commissioning software.
1:Parameter does exist in the expert list.
0:Parameter does not exist in the expert list.
Min, max, factory setting
Min. |
Minimum value of the parameter [unit] |
Max. |
Maximum value of the parameter [unit] |
Factory setting |
Value when supplied [unit] |
20 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Number ranges
Parameters are grouped into the following number ranges:
Range |
|
Description |
From |
to |
|
0000 |
0099 |
Display and operation |
0100 |
0199 |
Commissioning |
0200 |
0299 |
Power unit |
0300 |
0399 |
Motor |
0400 |
0499 |
Encoder |
0500 |
0599 |
Technology and units, motor-specific data, probes |
0600 |
0699 |
Thermal monitoring, maximum current, operating hours, motor data, |
|
|
central probe |
0700 |
0799 |
Control Unit terminals, measuring sockets |
0800 |
0839 |
CDS, DDS data sets, motor changeover |
0840 |
0879 |
Sequence control (e.g. signal source for ON/OFF1) |
0880 |
0899 |
ESR, parking, control and status words |
0900 |
0999 |
PROFIBUS/PROFIdrive |
1000 |
1199 |
Setpoint channel (e.g. ramp-function generator) |
1200 |
1299 |
Functions (e.g. motor holding brake) |
1300 |
1399 |
U/f control |
1400 |
1799 |
Closed-loop control |
1800 |
1899 |
Gating unit |
1900 |
1999 |
Power unit and motor identification |
2000 |
2009 |
Reference values |
2010 |
2099 |
Communication (fieldbus) |
2100 |
2139 |
Faults and alarms |
2140 |
2199 |
Signals and monitoring |
2200 |
2359 |
Technology controller |
2360 |
2399 |
Staging, hibernation |
2500 |
2699 |
Position control (LR) and basic positioning (EPOS) |
2700 |
2719 |
Reference values, display |
2720 |
2729 |
Load gearbox |
2800 |
2819 |
Logic operations |
2900 |
2930 |
Fixed values (e.g. percent, torque) |
3000 |
3099 |
Motor identification results |
3100 |
3109 |
Real-time clock (RTC) |
3110 |
3199 |
Faults and alarms |
3200 |
3299 |
Signals and monitoring |
Machine data and parameters |
21 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.1 Explanation of the machine/setting data
Range |
|
Description |
From |
to |
|
3400 |
3659 |
Infeed closed-loop control |
3660 |
3699 |
Voltage Sensing Module (VSM), Braking Module internal |
3700 |
3779 |
Advanced Positioning Control (APC) |
3780 |
3819 |
Synchronization |
3820 |
3849 |
Friction characteristic |
3850 |
3899 |
Functions (e.g. long stator) |
3900 |
3999 |
Management |
4000 |
4599 |
Terminal Board, Terminal Module (e.g. TB30, TM31) |
4600 |
4699 |
Sensor Module |
4700 |
4799 |
Trace |
4800 |
4849 |
Function Generator |
4950 |
4999 |
OA application |
5400 |
5499 |
Line droop control (e.g. shaft generator) |
5500 |
5599 |
Dynamic grid support (solar) |
5900 |
6999 |
SINAMICS GM/SM/GL/SL |
7000 |
7499 |
Parallel connection of power units |
7500 |
7599 |
SINAMICS SM120 |
7700 |
7729 |
External messages |
7770 |
7789 |
NVRAM, system parameters |
7800 |
7839 |
EEPROM read/write parameters |
7840 |
8399 |
Internal system parameters |
8400 |
8449 |
Real-time clock (RTC) |
8500 |
8599 |
Data and macro management |
8600 |
8799 |
CAN bus |
8800 |
8899 |
Communication Board Ethernet (CBE), PROFIdrive |
8900 |
8999 |
Industrial Ethernet, PROFINET, CBE20 |
9000 |
9299 |
Topology |
9300 |
9399 |
Safety Integrated |
9400 |
9499 |
Parameter consistency and storage |
9500 |
9899 |
Safety Integrated |
9900 |
9949 |
Topology |
9950 |
9999 |
Diagnostics, internal |
10000 |
10199 |
Safety Integrated |
11000 |
11299 |
Free technology controller 0, 1, 2 |
20000 |
20999 |
Free function blocks (FBLOCKS) |
21000 |
25999 |
Drive Control Chart (DCC) |
50000 |
53999 |
SINAMICS DC MASTER (DC closed-loop control) |
61000 |
61001 |
PROFINET |
22 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.2Display machine data
Product: Handbuch_Sinumerik, Version: V14.0, Language: eng
Objects:
Number |
Identifier |
|
|
Display filters |
Reference |
|
|
|
|
|
|
|
|
|
|
Unit |
Name |
|
|
Data type |
Active |
|
|
|
|
|
|
|
|
|
|
Attributes |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
System |
Dimension |
Default value |
Minimum |
Maximum |
Protection |
Class |
|
|
|
(LIN/ROT) |
value |
value |
|
|
|
|
|
|
(LIN/ROT) |
(LIN/ROT) |
|
|
|
|
|
|
|
|
|
|
|
Description: |
Description |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
9006 |
DISPLAY_SWITCH_OFF_INTERVAL |
|
- |
- |
|
|
|
|
|
|
|
|
|
|
|
- |
Time for screen saver |
|
|
DWORD |
PowerOn |
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
60 |
0 |
180 |
7/3 |
- |
|
|
|
|
|
|
|
|
|
Description: |
This machine data defines the time in minutes after which the screen automat- |
||||||
|
ically |
|
|
|
|
|
|
|
switches to dark if no key has been pressed on the keyboard in the meantime. |
||||||
|
The value 0 disables automatic light/dark switching. |
|
|
||||
|
Note: |
|
|
|
|
|
|
|
The screen is only switched light/dark automatically when IS screen dark = 0. |
||||||
|
Related to: |
|
|
|
|
|
|
|
IS screen dark (DB19, ... DBX0.1) |
|
|
|
|
||
|
|
|
|
|
|
|
|
9009 |
KEYBOARD_STATE |
|
|
- |
- |
|
|
|
|
|
|
|
|
|
|
- |
Keyboard shift behavior at booting |
|
BYTE |
PowerOn |
|
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
0 |
0 |
2 |
7/3 |
- |
|
|
|
|
|
|
|
|
|
Description: This machine date defines the Shift behavior (SW-CAPSLOCK) of the keyboard. Basic configuration of the Shift behavior of the keyboard
0: SW-CAPSLOCK OFF
2: SW-CAPSLOCK ON
9032 |
HMI_MONITOR |
|
- |
- |
|
|
|
|
|
|
|
|
|
- |
Define PLC data for HMI screen info |
|
STRING |
PowerOn |
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
- |
- |
7/1 |
- |
|
|
|
|
|
|
|
Description: |
Pointer, with offset, to a PLC data block. This is required to report |
|||||
|
HMI monitor information to the PLC, e.g active HMI task. |
|
Format: PLC-specific format for specifying a data block with byte offset, e.g. DB60.DBB10 for data block 60, byte 10.
The monitor information reported by the HMI has a maximum length of 8 bytes.
Machine data and parameters |
23 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data 1.2 Display machine data
9056 |
ALARM_ROTATION_CYCLE |
|
- |
- |
|
||
|
|
|
|
|
|
||
- |
Rotation cycle time for alarm display |
|
DWORD |
PowerOn |
|
||
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0 |
0 |
10000 |
7/3 |
- |
|
|
|
|
|
|
|
|
Description: |
|
Rotation cycle time in the alarm display: |
|
|
|||
|
|
<500: no rotation in the alarm line |
|
|
|
500 - 10000: cycle duration of alarm rotation in milliseconds
If a valid cycle time has been set, all alarms are displayed in the alarm line one after the other.
Each alarm is displayed for the specified time until it is replaced by the next alarm.
If no alarm is present, cycle alarms or program messages are displayed, if required. However, these do not rotate.
9100 |
CHANGE_LANGUAGE_MODE |
|
- |
- |
|
|
|
|
|
|
|
|
|
- |
Language selection mode |
|
BYTE |
Immediately |
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
1 |
1 |
2 |
7/3 |
- |
|
|
|
|
|
|
|
Description: |
|
Language selection mode is defined: |
|
|
|
|
|
||
|
|
1 = directly via selection list |
|
|
|
|
|
||
|
|
2 = via setting of the 1st and 2nd language |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
9102 |
SHOW_TOOLTIP |
|
- |
- |
|
|
|
||
|
|
|
|
|
|
|
|
||
- |
Display tooltip |
|
BYTE |
Immediately |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
1 |
0 |
1 |
7/3 |
- |
|
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
If the MD has been set to 1, tooltips will be displayed. |
|
|
|
||||
|
|
|
|
|
|
|
|
||
9103 |
TOOLTIP_TIME_DELAY |
|
- |
- |
|
|
|
||
|
|
|
|
|
|
|
|
||
s |
Time delay tooltip display |
|
BYTE |
Immediately |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
1 |
0 |
60 |
7/3 |
- |
|
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
Time delay for display of the tooltips in seconds. |
|
|
|
|
|||
|
|
|
|
|
|
|
|
||
9105 |
HMI_WIDE_SCREEN |
|
- |
- |
|
|
|
||
|
|
|
|
|
|
|
|||
- |
Display of the HMI as wide screen with OEM area always |
BYTE |
PowerOn |
|
|
|
|||
|
visible |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0 |
0 |
1 |
7/2 |
- |
|
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
Display of the HMI as wide screen. Above the HMI there is a separate applica- |
|||||||
|
|
tion field that is designed by the machine manufacturer. |
|
|
|
||||
|
|
|
|
|
|
|
|
||
9106 |
SERVE_EXTCALL_PROGRAMS |
|
- |
- |
|
|
|
||
|
|
|
|
|
|
|
|
||
- |
Process EXTCALL calls |
|
BYTE |
PowerOn |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
1 |
0 |
1 |
7/3 |
- |
|
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
HMI processes reload requirements of the NC for EXTCALL calls. |
24 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
|
|
|
|
|
|
|
Machine and setting data |
||
|
|
|
|
|
|
|
1.2 Display machine data |
||
|
|
|
|
|
|
|
|
|
|
9107 |
DRV_DIAG_DO_AND_COMP_NAMES |
|
- |
- |
|
|
|
||
|
|
|
|
|
|||||
- |
Expanded drive diagnostics: DO and components |
BYTE |
Immediately |
|
|||||
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0 |
0 |
3 |
7/3 |
|
- |
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
0: DO and component type names |
|
|
|
|
|
1:Real DO names and component type names
2:DO type names and real component names
3:Reale DO names and real component names
9108 |
SINUMERIK_INTEGRATE |
|
- |
- |
|
|
|
|
|
|
|
|
|
- |
Activating SINUMERIK Integrate products |
|
BYTE |
Immediately |
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
0 |
0 |
1 |
7/3 |
- |
|
|
|
|
|
|
|
Description: |
|
If the machine data has been set to 1, the SINUMERIK Integrate softkey |
|||||||
|
|
appears as the operating area. |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
9110 |
ACCESS_HMI_EXIT |
|
- |
- |
|
|
|
||
|
|
|
|
|
|
|
|
||
- |
Protection level of exit softkey |
|
BYTE |
PowerOn |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
1 |
0 |
7 |
7/2 |
- |
|
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
Protection level for the exit softkey (HMI restart) in the operating area |
|||||||
|
|
menu |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
9900 |
MD_TEXT_SWITCH |
|
- |
- |
|
|
|
||
|
|
|
|
|
|
|
|
||
- |
Plaintexts instead of MD identifier |
|
BOOLEAN |
Immediately |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0 |
- |
- |
7/3 |
- |
|
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
If the MD has been set to 1, clear text is displayed on the operator panel |
|||||||
|
|
instead of the machine data identifiers. |
|
|
|
|
|||
|
|
|
|
|
|
|
|
||
9990 |
SW_OPTIONS |
|
- |
- |
|
|
|
||
|
|
|
|
|
|
|
|
||
- |
Enable HMI software options |
|
DWORD |
Immediately |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0 |
- |
- |
1/1 |
- |
|
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
Here you can enable the HMI software options |
|
|
|
|
Machine data and parameters |
25 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data 1.3 NC machine data
Number |
Identifier |
|
|
Display filters |
Reference |
|
|
|
|
|
|
|
|
Unit |
Name |
|
|
Data type |
Active |
|
|
|
|
|
|
|
|
Attributes |
|
|
|
|
|
|
|
|
|
|
|
|
|
System |
Dimension |
Default value |
Minimum |
Maximum |
Protection |
Class |
|
|
(LIN/ROT) |
value |
value |
|
|
|
|
|
(LIN/ROT) |
(LIN/ROT) |
|
|
|
|
|
|
|
|
|
Description: |
Description |
|
|
|
|
|
|
|
|
|
|
||
10000 |
AXCONF_MACHAX_NAME_TAB |
|
N01, N11 |
K2,F1,G2,F2,K5,M1 |
||
|
|
|
|
|
|
|
- |
Machine axis name |
|
|
STRING |
PowerOn |
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
31 |
X1, Y1, Z1, A1, B1, |
- |
- |
7/2 |
M |
|
|
C1, U1... |
|
|
|
|
|
|
|
|
|
|
|
Description: |
List of the machine axis identifiers. |
|
|
|
The name of the machine axis is entered in this MD.
In addition to the fixed, defined machine axis identifiers "AX1", "AX2" ..., user-defined identifiers for the machine axes can also be assigned in this data.
The identifiers defined here can be used parallel to the fixed, defined identifiers for addressing axial data (e.g. MD) and machine axis-related NC functions (reference point approach, axial measurement, travel to fixed stop).
Special cases:
•The input machine axis name must not conflict with the names and assignments of the geometry axes (MD20060 $MC_AXCONF_GEOAX_NAME_TAB, MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB) or channel axes (MD20080 $MC_AXCONF_CHANAX_NAME_TAB, MD20070 $MC_AXCONF_MACHAX_USED).
•The input machine axis name must not be the same as the names for Euler angles (MD10620 $MN_EULER_ANGLE_NAME_TAB), names for path-relevant orientation (MMD10624 $MN_ORIPATH_LIFT_VECTOR_TAB), names for normal vectors (MD10630 $MN_NORMAL_VECTOR_NAME_TAB), names for directional vectors (MD10640 $MN_DIR_VECTOR_NAME_TAB), names for rotation vectors (MD10642 $MN_ROT_VECTOR_NAME_TAB), names for intermediate vector components (MD10644 $MN_INTER_VECTOR_NAME_TAB), names for intermediate circle point coordinates with CIP (MD10660 $MN_INTERMEDIATE_POINT_NAME_TAB) or the names for interpolation parameters (MD10650 $MN_IPO_PARAM_NAME_TAB).
•The input machine axis name must not include any of the following reserved address letters:
D Tool offset |
(D function) |
E Reserved |
F Feedrate |
(F function) |
G Preparatory function |
H Auxiliary function |
(H function) |
L Subroutine call |
M Miscellaneous function (M function) |
N Subblock |
|
P Subroutine number of passes |
R Arithmetic parameters |
|
S Spindle speed |
(S function) |
T Tool (T function) |
The name must not include any keywords (e.g. DEF, SPOS etc.) or pre-defined identifiers (e.g. ASPLINE, SOFT).
26 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.3 NC machine data
The use of an axis identifier consisting of a valid address letter (A, B, C, I, J, K, Q, U, V, W, X, Y, Z), followed by an optional numerical extension (1-99) gives slightly better block cycle times than a general identifier.
If no identifier is assigned to a machine axis, then the predefined name ("AXn") applies to the nth machine axis.
Related to:
MD20060 $MC_AXCONF_GEOAX_NAME_TAB (geometry axis name in the channel [GEOAxisno.]
MD20080 $MC_AXCONF_CHANAX_NAME_TAB (channel axis name in the channel [Channelaxisno.]
10002 |
AXCONF_LOGIC_MACHAX_TAB |
N01 |
B3,K2 |
|
||
|
|
|
|
|
||
- |
Logical NCK machine axis image |
STRING |
PowerOn |
|
||
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
31 |
AX1, AX2, AX3, AX4, |
- |
- |
3/2 |
M |
|
|
AX5, AX6... |
|
|
|
|
|
|
|
|
|
|
|
Description: List of machine axes available on an NCU. (Logical NCK machine axis image)
MD10002 $MN_AXCONF_LOGIC_MACHAX_TAB creates another NCK global, logical layer between the channel axis layer and the machine axes in an NCU or NCU grouping. This layer is called the "Logic NckMachineAxImage", abbreviation: LAI ).
Axes can only be assigned between different NCUs via this new intermediate layer!
The entry $MN_AXCONF_LOGIC_MACHAX_TAB[ n] = NCj_AXi assigns the machine axis i on the NCU j to the axis index "n" in the LAI.
This makes the following assignments possible:
1.Local axes (default setting: AX1, AX2 ... AX31)
The entry $MN_AXCONF_LOGIC_MACHAX_TAB[n] = AX3 assigns the local axis AX3 to axis index n. (Default setting AX3 is present for n = 3 . Thus there is compatibility in software version 5 for MD blocks for software versions up to 4).
2. Link axes (axes that are physically connected to another NCU). The entry $MN_AXCONF_LOGIC_MACHAX_TAB[n] = NCj_AXi assigns axis AXi (link axis) on NCU j to axis index n.
Limits:
n Machine axis address (of the local NCU)1 ... 31
j NCU number1 ... 16
i Machine axis address (of the local/remote NCU)1 ... 31
3. Axis container in which there are once again either local or link axes. The entry $MN_AXCONF_LOGIC_MACHAX_TAB[n] = CTr_SLs assigns container r and slot s to axis index n.
Limits:
n Machine axis address (of the local NCU)1 ... 31
rContainer number1 ... 16
sSlot number (location) in the container1 ... 32
The channel layer is formed via the related machine data $MD20070 $MC_AXCONF_MACHAX_USED and no longer points (small P5) directly to the machine axes but to the new LAI layer.
$MC_AXCONF_MACHAX_USED [k]=n assigns the LAI axis number "n" to the axis index "k" in the channel layer.
The machine axis and the corresponding NCK can then be determined from the LAI axis number.
Machine data and parameters |
27 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data 1.3 NC machine data
If a number of NCUs point to the same machine axis in the cluster as a result of MD10002 $MN_AXCONF_LOGIC_MACHAX_TAB, then the axial machine data MD30554 $MA_AXCONF_ASSIGN_MASTER_NCU must define which NCU generates the master NCU and the setpoint values for the position controller after startup.
Related to:
MD12... $MN_AXCT_AXCONF_ASSIGN_TABi (make entries in containers i)
10010 |
ASSIGN_CHAN_TO_MODE_GROUP |
N01, N02, N11 |
K1,K5 |
|
||
|
|
|
|
|
||
- |
Channel valid in mode group |
DWORD |
PowerOn |
|
||
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
10 |
1, 0, 0, 0, 0, 0, 0, 0... |
0 |
10 |
7/2 |
M |
|
|
|
|
|
|
|
Description: This MD assigns the channel to a mode group Entry value 1 => Assigned to 1st mode group Entry value 2 => Assigned to 2nd mode group etc.
From software version 4, it is permissible not to assign a mode group number to individual channels.
Channel gaps are allowed, in order to favor uniform configuration in similar types of machines. In this case, the number 0 is assigned to the channel instead of assigning a mode group number equal to or greater than 1. The channel is not activated, however it is handled like an active channel when counting the channels.
|
|
E.g. |
|
|
|
|
|
|
|
|
|
ASSIGN_CHAN_TO_MODE_GROUP[0] = |
1 |
|
|
|
|
||
|
|
ASSIGN_CHAN_TO_MODE_GROUP[1] = |
1 |
|
|
|
|
||
|
|
ASSIGN_CHAN_TO_MODE_GROUP[2] = |
0 |
; gap |
|
|
|||
|
|
ASSIGN_CHAN_TO_MODE_GROUP[3] = |
1 |
|
|
|
|
||
|
|
Application example: |
|
|
|
|
|
|
|
|
|
Select desired channel via HMI |
and enter with MD10010 |
|
|||||
|
|
$MN_ASSIGN_CHAN_TO_MODE_GROUP = 1. |
|
|
|
|
|||
|
|
Note: |
|
|
|
|
|
|
|
|
|
This MD must still be entered even when only one mode group is present. |
|||||||
|
|
|
|
|
|
|
|
|
|
10050 |
SYSCLOCK_CYCLE_TIME |
|
|
|
N01, N05, N11, |
G3,G2,R1 |
|
||
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
||
s |
System clock cycle |
|
|
|
DOUBLE |
PowerOn |
|
||
|
|
|
|
|
|
|
|
|
|
SFCO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0.002 |
0.001 |
|
|
0.008 |
7/2 |
M |
|
|
|
|
|
|
|
|
|
|
Description: |
|
Basic cycle time of the system |
software |
|
|
The cycle times settings of cyclical tasks (position controller/IPO ) are multiples of this basic cycle. Apart from special applications in which MD10060 $MN_POSCTRL_SYSCLOCK_TIME_RATIO is set greater than 1, the basic cycle corresponds to the position controller cycle.
For PROFIBUS/PROFINET:
In the case of systems with a PROFIBUS DP connection, this MD corresponds to the PROFIBUS DP cycle time. This time is read from the configuration file (SDB-Type-2000) during startup and written to the MD.
This MD can only be changed via the configuration file.
28 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data
1.3 NC machine data
Note:
Reducing this MD can result in an automatic correction of MD10062 $MN_POSCTRL_CYCLE_DELAY and MD10064 $MN_POSCTRL_CYCLE_DESVAL_DELAY that cannot be undone by a subsequent increase!
Details:
The basic cycle is incremented in multiples ( MD10080 $MN_SYSCLOCK_SAMPL_TIME_RATIO ) of units of the measured value sampling cycle. During system startup, the entered value is automatically rounded up to a multiple of this incrementation.
Note:
Discrete timer division ratios can give rise to the entered value producing a value that is not an integer after a Power OFF/ON.
|
|
For example: |
|
|
|
|
|
|
|
|
|
|
Input |
|
|
= 0.005s |
|
|
|
||
|
|
|
|
|
|
after Power OFF/ON |
=0.00499840 |
|||
|
|
|
|
or |
|
|
|
|
|
|
|
|
Input |
|
|
= 0.006s |
|
|
|
||
|
|
|
|
|
|
after Power OFF/ON |
=0.0060032 |
|
||
|
|
|
|
|
|
|
|
|
|
|
10059 |
PROFIBUS_ALARM_MARKER |
|
|
|
N05 |
G3 |
|
|||
|
|
|
|
|
|
|||||
- |
PROFIBUS/PROFINET alarm flag (internal only) |
|
BYTE |
PowerOn |
|
|||||
|
|
|
|
|
|
|
|
|
|
|
NBUP, NDLD |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0 |
|
- |
|
- |
0/0 |
|
M |
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
PROFIBUS/PROFINET alarm flag: |
|
|
|
|
|
In this machine data, alarm requests for the PROFIBUS/PROFINET layer are stored beyond a reboot.
If conflicts arise between machine data 10050, 10060, 10070 and the data in the SDB on startup, the machine data are matched according to SDB, and an alarm is output on the next start up. These alarm requests are stored here.
Related to:
MD10050 $MN_SYSCLOCK_CYCLE_TIME,
MD10080 $MN_SYSCLOCK_SAMPL_TIME_RATIO
10060 |
POSCTRL_SYSCLOCK_TIME_RATIO |
|
N01, N05 |
G3 |
|
|
|
|
|
|
|
|
|
- |
Factor for position control cycle |
|
DWORD |
PowerOn |
|
|
|
|
|
|
|
|
|
SFCO |
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
1 |
1 |
31 |
7/2 |
M |
|
|
|
|
|
|
|
Description: The position-control cycle is stated as a multiple of the time units of the system basic cycle MD10050 $MN_SYSCLOCK_CYCLE_TIME.
For PROFIBUS/PROFINET:
In the case of systems with a PROFIBUS DP connection, this MD represents the ratio between the PROFIBUS DP cycle and the position controller cycle, which is based on the PLC configuration.
10061 |
POSCTRL_CYCLE_TIME |
|
N01, N05 |
G3 |
|
||
|
|
|
|
|
|
||
- |
Position control cycle |
|
DOUBLE |
PowerOn |
|
||
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0.0 |
- |
- |
ReadOnly |
M |
|
|
|
|
|
|
|
|
Description: |
|
Position controller cycle time: |
|
|
|
Display of the position controller cycle time (not modifiable !).
Machine data and parameters |
29 |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
Machine and setting data 1.3 NC machine data
It is compiled internally from MD10050 $MN_SYSCLOCK_CYCLE_TIME and MD10060 $MN_POSCTRL_SYSCLOCK_TIME_RATIO.
10062 |
POSCTRL_CYCLE_DELAY |
|
N01, N05 |
G3 |
|
||
|
|
|
|
|
|
||
s |
Position control cycle offset |
|
DOUBLE |
PowerOn |
|
||
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0.0 |
0.000 |
0.008 |
7/2 |
M |
|
|
|
|
|
|
|
|
Description: |
|
For PROFIdrive only: |
|
|
|
|
Only relevant to operation with PROFIBUS drives.
Position controller cycle offset in relation to the PROFIBUS DP cycle.
Offsets that exceed the set DP cycle or are smaller than the maximum Tdx, are automatically corrected to a substitute value half the size of the DP cycle.
MD10062 $MN_POSCTRL_CYCLE_DELAY > 0:Default for position controller offset
MD10062 $MN_POSCTRL_CYCLE_DELAY = 0:Automatic determination of the position controller offset with max. Tdx from STEP7 project
Tdx_max is determined through all equidistant buses.
The actually active offset value is displayed in MD 10063[1] $MN_POSCTRL_CYCLE_DIAGNOSIS.
Note:
MD10062 $MN_POSCTRL_CYCLE_DELAY > 0 can reduce MD10050 $MN_SYSCLOCK_CYCLE_TIME to the automatic correction of this MD that cannot be undone by a subsequent increase.
Recommendation:
In this case set the original value or default value once again.
10063 |
POSCTRL_CYCLE_DIAGNOSIS |
EXP, N01, N05 |
- |
|
|||
|
|
|
|
|
|||
s |
Active timing |
DOUBLE |
PowerOn |
|
|||
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
6 |
|
0.0, 0.0, 0.0, 0.0, 0.0, |
- |
- |
ReadOnly |
M |
|
|
|
0.0 |
|
|
|
|
|
|
|
|
|
|
|
|
Description: |
|
Diagnostic data related to the PROFIBUS/PROFINET cycle. |
|
[0]: Latest time at which the actual values should be available (Tdx)
[1]: Actually active position controller cycle offset (Tm)
[2]: Latest time at which the setpoints were output by the position controller
[3]: Time at which the setpoint transfer to the drive via DMA was started for SOC-based modules
[4]: Time at which the setpoint transfer to the drive via DMA was finished for SOC-based modules.
[5]: 'Worst case' time since voltage on, at which the setpoint transfer to the drive via DMA was finished for SOC-based modules.
Diagnostic data are initialized with ZERO with each NCK power up
10064 |
POSCTRL_CYCLE_DESVAL_DELAY |
|
N01, N05 |
G3 |
|
|
||
|
|
|
|
|
|
|
||
s |
Clock skew of the DMA for the setpoints |
|
DOUBLE |
PowerOn |
|
|
||
|
|
|
|
|
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
- |
|
0.0 |
0.000 |
0.008 |
7/2 |
M |
|
|
|
|
|
|
|
|
|
|
Description: |
|
For SINAMICS-Integrated only: |
|
|
|
|
||
|
|
Only relevant to operation with SINAMICS-Integrated drives on SOC modules. |
Offset of the output of the setpoints via DMA in relation to the PROFIBUS DP cycle.
30 |
Machine data and parameters |
Parameter Manual, 03/2013, 6FC5397-7AP40-3BA1 |
