IPS-Beacon™
Condition monitoring and alert system for vibration and temperature
PCN = 26999949 03-13 (E). Original instructions.
USER INSTRUCTIONS
Installation
Operation
Maintenance
These instructions must be read prior to installing, operating, using and maintaining this equipment.
CONTENTS |
|
|
|
Page |
|
1 INTRODUCTION AND SAFETY ........................... |
3 |
|
1.1 |
General............................................................ |
3 |
1.2 |
CE Marking and approvals.............................. |
3 |
1.3 |
Disclaimer ....................................................... |
3 |
1.4 |
Copyright......................................................... |
3 |
1.5 |
Duty conditions................................................ |
3 |
1.6 |
Safety .............................................................. |
4 |
1.7 |
Specific machine performance........................ |
4 |
2 TRANSPORT AND STORAGE ............................. |
4 |
|
2.1 |
Consignment receipt and unpacking .............. |
4 |
2.2 |
Handling .......................................................... |
5 |
2.3 |
Storage............................................................ |
5 |
2.4 |
Recycling and end of product life.................... |
5 |
2.5 |
Disposal Instructions ....................................... |
5 |
3 DESCRIPTION ...................................................... |
5 |
|
3.1 |
Configurations ................................................. |
5 |
3.2 |
Alarm mode..................................................... |
6 |
3.3 |
Performance and operation limits ................... |
6 |
3.4 |
Power-up module (PUM) ................................ |
7 |
3.5 |
Take away memory module (TAM)................. |
7 |
4 MAINTENANCE..................................................... |
7 |
|
4.1 |
Tools required ................................................. |
7 |
4.2 |
Turning unit on/off ........................................... |
7 |
4.3 |
Low battery...................................................... |
7 |
5 CUSTOM CONFIGURATION PROGRAMMING... |
7 |
|
5.1 |
User configurable settings .............................. |
7 |
5.2 |
Connecting to IPS Beacon unit ....................... |
8 |
5.3 |
Setting alarm set points .................................. |
8 |
5.4 |
Setting time and date on IPS Beacon unit ...... |
8 |
5.5 |
Reloading factory configuration ...................... |
8 |
6 INSTALLATION ..................................................... |
8 |
|
6.1 |
Tools required ............................................... |
10 |
6.2 |
Unpacking ..................................................... |
10 |
6.3 |
Preliminary operational check....................... |
10 |
6.4 |
Attachment options ....................................... |
10 |
6.5 |
LED Indications ............................................. |
10 |
IPS BEACON ENGLISH 26999949 03-13
|
|
Page |
7 |
ACTIVATE THE IPS-BEACON ............................ |
10 |
|
7.1 Power-up module (PUM) ............................... |
10 |
|
7.2 Take away memory module (TAM) ............... |
11 |
8 |
PARTS LIST AND DRAWINGS ........................... |
11 |
9 |
CERTIFICATION.................................................. |
11 |
10 TROUBLE-SHOOTING GUIDE ......................... |
11 |
|
|
10.1 No flashing LEDs ......................................... |
11 |
|
10.2 Inaccurate or missing data .......................... |
12 |
11 DECLARATION OF CONFORMITY .................. |
13 |
|
Page 2 of 16 |
flowserve.com |
1 INTRODUCTION AND SAFETY
1.1 General
These instructions must always be kept close to the product's operating location or directly with the product.
Flowserve products are designed, developed and manufactured with state-of-the-art technologies in modern facilities. The unit is produced with great care and commitment to continuous quality control, utilizing sophisticated quality techniques, and safety requirements.
Flowserve is committed to continuous quality improvement and being at your service for any further information about the product in its installation and operation or about its support products, repair and diagnostic services.
These instructions are intended to facilitate familiarization with the product and its permitted use. Operating the product in compliance with these instructions is important to help ensure reliability in service and avoid risks. The instructions may not take into account local regulations; ensure such regulations are observed by all, including those installing the product. Always coordinate repair activity with operations personnel, and follow all plant safety requirements and applicable safety and health laws and regulations.
These instructions must be read prior to installing, operating, using and maintaining the equipment in any region worldwide. The equipment must not be put into service until all the conditions relating to safety, noted in the instructions, have been met. Failure to follow and apply the present user instructions is considered to be misuse. Personal injury, product damage, delay or failure caused by misuse are not covered by the Flowserve warranty.
1.2 CE Marking and approvals
It is a legal requirement that machinery and equipment put into service within certain regions of the world shall conform with the applicable CE Marking Directives covering Machinery and, where applicable, Low Voltage Equipment, Electromagnetic Compatibility (EMC), Pressure Equipment Directive (PED) and Equipment for Potentially Explosive Atmospheres (ATEX).
Where applicable, the Directives and any additional Approvals, cover important safety aspects relating to
Page 3 of 16
IPS BEACON ENGLISH 26999949 03-13
machinery and equipment and the satisfactory provision of technical documents and safety instructions. Where applicable this document incorporates information relevant to these Directives and Approvals.
To confirm the Approvals applying and if the product is CE marked, check the serial number plate markings and the Certification. (See section 9, Certification.)
1.3 Disclaimer
Information in these User Instructions is believed to be complete and reliable. However, in spite of all of the efforts of Flowserve Corporation to provide comprehensive instructions, good engineering and safety practice should always be used.
Flowserve manufactures products to exacting International Quality Management System Standards as certified and audited by external Quality Assurance organizations. Genuine parts and accessories have been designed, tested and incorporated into the products to help ensure their continued product quality and performance in use. As Flowserve cannot test parts and accessories sourced from other vendors the incorrect incorporation of such parts and accessories may adversely affect the performance and safety features of the products. The failure to properly select, install or use authorized Flowserve parts and accessories is considered to be misuse. Damage or failure caused by misuse is not covered by the Flowserve warranty. In addition, any modification of Flowserve products or removal of original components may impair the safety of these products in their use.
1.4 Copyright
All rights reserved. No part of these instructions may be reproduced, stored in a retrieval system or transmitted in any form or by any means without prior permission of Flowserve.
1.5 Duty conditions
This product has been selected to meet the specifications of your purchase order. The acknowledgement of these conditions has been sent separately to the Purchaser. A copy should be kept with these instructions.
The product must not be operated beyond the parameters specified for the application. If there is any doubt as to the suitability of the product for the application intended, contact Flowserve for advice.
If the conditions of service on your purchase order are going to be changed (for example liquid pumped, temperature or duty) it is requested that the user seeks the written agreement of Flowserve before start up.
flowserve.com
1.6 Safety
1.6.1 Summary of safety markings
These User Instructions contain specific safety markings where non-observance of an instruction would cause hazards. The specific safety markings are:
This symbol indicates electrical safety instructions where non-compliance will involve a high risk to personal safety or the loss of life.
This symbol indicates safety instructions where non-compliance would affect personal safety and could result in loss of life.
This symbol indicates “hazardous and toxic fluid” safety instructions where non-compliance would affect personal safety and could result in loss of life.
This symbol indicates safety instructions where non-compliance will involve some risk to safe operation and personal safety and would damage the equipment or property.
This symbol indicates explosive atmosphere zone marking according to ATEX. It is used in safety instructions where non-compliance in the hazardous area would cause the risk of an explosion.
This symbol is used in safety instructions to remind not to rub non-metallic surfaces with a dry cloth; ensure the cloth is damp. It is used in safety instructions where non-compliance in the hazardous area would cause the risk of an explosion.
This sign is not a safety symbol but indicates an important instruction in the assembly process.
1.6.2 Personnel qualification and training
All personnel involved in the operation, installation, inspection and maintenance of the unit must be qualified to carry out the work involved. If the personnel in question do not already possess the necessary knowledge and skill, appropriate training and instruction must be provided. If required the operator may commission the manufacturer/supplier to provide applicable training.
Always coordinate repair activity with operations and health and safety personnel, and follow all plant safety requirements and applicable safety and health laws and regulations.
Page 4 of 16
IPS BEACON ENGLISH 26999949 03-13
1.6.3 Safety action
This is a summary of conditions and actions to help prevent injury to personnel and damage to the environment and to equipment. For products used in potentially explosive atmospheres section 1.6.4 also applies.
NEVER DO MAINTENANCE WORK WHEN THE UNIT IS CONNECTED TO POWER (Lock out.)
HANDLING COMPONENTS
Many precision parts have sharp corners and the wearing of appropriate safety gloves and equipment is required when handling these components. To lift heavy pieces above 25 kg (55 lb) use a crane appropriate for the mass and in accordance with current local regulations.
1.6.4 Products used in potentially explosive atmospheres
Measures are required to:
Avoid excess temperature
Prevent buildup of explosive mixtures
Prevent the generation of sparks
1.7 Specific machine performance
For performance parameters see section 1.5 Duty conditions. Where performance data has been supplied separately to the purchaser these should be obtained and retained with these User Instructions if required.
2 TRANSPORT AND STORAGE
Make sure that hazardous substances are disposed of safely and that the correct personal protective equipment is used. The safety specifications must be in accordance with the current local regulations at all times.
2.1 Consignment receipt and unpacking
Immediately after receipt of the equipment it must be checked against the delivery/shipping documents for its completeness and that there has been no damage in transportation. Any shortage and/or damage must be reported immediately to Flowserve and must be received in writing within ten days of receipt of the equipment. Later claims cannot be accepted.
Check any crate, boxes or wrappings for any accessories or spare parts that may be packed separately with the equipment or attached to side walls of the box or equipment.
flowserve.com
Each product has a unique serial number. Check that this number corresponds with that advised and always quote this number in correspondence as well as when ordering spare parts or further accessories.
2.2 Handling
Boxes, crates, pallets or cartons may be unloaded using fork lift vehicles or slings dependent on their size and construction.
2.3 Storage
Store the equipment in a clean, dry location away from vibration. Leave protective covers in place to keep dirt and other foreign material out of casing.
2.3.1 Storage and packaging
Normal packaging is designed to protect the unit and parts during shipment and for dry, indoor storage.
After unpacking, protection will be the responsibility of the user.
2.4 Recycling and end of product life
At the end of the service life of the product or its parts, the relevant materials and parts should be recycled or disposed of using an environmentally acceptable method and in accordance with local regulations. If the product contains substances that are harmful to the environment, these should be removed and disposed of in accordance with current local regulations.
2.5 Disposal Instructions
At the end of the product’s life, do not dispose of any electronic component or instrument in the domestic waste. Disposal should be done in accordance with applicable regulations, which vary from state to state and country to country. The IPS Beacon unit includes a built-in battery and should be disposed of in accordance with applicable battery disposal regulations. Batteries should not be incinerated, unless suitable procedures are followed and qualified handlers have taken appropriate precautions. Exposure of these cells to high temperatures or fire can cause the cells to vent and/or rupture. These cells do not contain dangerous substances. The reaction products are inorganic and do not represent environmental hazards, once the decomposition or neutralization process has terminated.
Page 5 of 16
IPS BEACON ENGLISH 26999949 03-13
Disposal in Europe
Batteries for disposal should not be transported by air. For road transport of dangerous goods ADR special provision 636 and packing instruction 903a apply.
Disposal in US
Hazardous waste of spent batteries can be disposed after they are first neutralized through an approved secondary treatment prior to disposal. Disposal of spent batteries should be performed by authorized, professional disposal company, which has the knowledge in the requirements of the Federal, the State and the Local authorities regarding hazardous materials, transportation and waste disposal. In any case it is recommended to contact the local EPA office.
3 DESCRIPTION
The IPS Beacon is a cost effective means of measuring the basic health of equipment. It is designed to quickly convey the health of any equipment it is attached to, based on vibration and temperature measurements.
The IPS Beacon is a battery powered unit that offers the ability to measure 3-axis vibration and temperature of any equipment it is attached to. The IPS Beacon is completely encapsulated including battery, electronics and sensor packaged inside a 316L SS case. The IPS Beacon also provides two LED indicator lights for a quick visualization of equipment health.
3.1 Configurations
Base IPS Beacon unit is provided with preset factory set points. Each unit also offers optional upgrades to allow for data logging [see section 3.5 Take away memory module (TAM)], data downloads to a PC format and unit configuration.
The IPS Beacon offers the ability to program alarm levels for each of the vibration axes (see Figure 3: X-Y- Z axis orientation) and temperature values. If those alarm levels are exceeded, the IPS Beacon will provide a visual indication using the LED indicator lights and also log the last alarm value for each of the data parameters.
3.1.1 Factory preset alarm settings
The IPS Beacon comes pre-programmed with the following default settings for the user-configurable options:
