D-link DCS-2330L User Manual

0 (0)

Version 1.0 | 01/16/2014

User Manual

Outdoor HD Wireless Network Camera

Cloud Camera

DCS-2330L

Preface

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Information in this document may become obsolete as our services and websites develop and change. Please refer to the www.mydlink.com website for the most current information.

Manual Revisions

Revision

Date

Description

1.0January 16, 2014 DCS-2330L Revision A1 with firmware version 1.00

Trademarks

© 2014 D-Link Systems, Inc. All Rights Reserved. D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries. All other third-party marks mentioned herein may be trademarks of their respective owners. This publication may not be reproduced, in whole or in part, without prior express written permission from D-Link Systems, Inc.

D-Link DCS-2330L User Manual

Table of Contents

Product Overview........................................................	4
Package Contents.................................................................	4
Introduction............................................................................	5
System Requirements..........................................................	5
Features....................................................................................	6
Hardware Overview..............................................................	7
Front.......................................................................................	7
Rear: External......................................................................	8
Rear: Internal.......................................................................	9
Removing the Top Panel...............................................	10
Replacing the Ethernet Cable.....................................	11
Reattaching the Top Panel...........................................	12
Removing the Bottom Panel.......................................	13
Using the Reset Button..................................................	13
Installing an SD Memory Card....................................	14
Reattaching the Bottom Panel...................................	14
Installation.................................................................	15
Zero Configuration Setup................................................	16
Mount the Camera..............................................................	19
mydlink.......................................................................	20
Camera Status.......................................................................	21
Configuration.............................................................	22
Using the Configuration Interface................................	22
Live Video...............................................................................	23
Setup........................................................................................	25
Setup Wizard.....................................................................	25
Network Setup.................................................................	31

Wireless Setup..................................................................	34
Dynamic DNS....................................................................	35
Image Setup......................................................................	36
Audio and Video..............................................................	38
Preset...................................................................................	40
Motion Detection............................................................	42
Time and Date..................................................................	44
Event Setup.......................................................................	45
SD Card................................................................................	53
Advanced...............................................................................	54
ICR and IR...........................................................................	54
HTTPS..................................................................................	55
Access List..........................................................................	56
Maintenance.........................................................................	57
Device Management......................................................	57
System.................................................................................	58
Firmware Upgrade..........................................................	59
Status.......................................................................................	60
Device Info.............................................................................	60
Logs......................................................................................	61
Help......................................................................................	62
Technical Specifications............................................	63
Contacting Technical Support...................................	66
Warranty.....................................................................	67
Registration................................................................	72

D-Link DCS-2330L User Manual

Section 1: Product Overview

Product Overview

Package Contents

Outdoor HD Wireless Network Camera

CAT5 Ethernet cable

Power adapter (Pre-Attached)

Quick Install Guide

If any of the above items are missing, please contact your reseller.

Note: Using a power supply with a different voltage than the one included with your product will cause damage and void the warranty for this product.

D-Link DCS-2330L User Manual

Section 1: Product Overview

Introduction

Congratulations on your purchase of the DCS-2330L Outdoor HD Wireless Network Camera. The DCS-2330L is a versatile and unique solution for your small office or home. Unlike a standard webcam, the DCS-2330L is a complete system with a built-in CPU and web server that transmits high quality video images for security and outdoor surveillance. The DCS-2330L can be accessed remotely, and controlled from any computer or mobile device over your local network or through the Internet via a web browser or apps. The simple installation and intuitive web-based interface offer easy integration with your Ethernet/Fast Ethernet or 802.11n/g wireless network. The DCS-2330L also comes with remote monitoring and motion and sound detection features for a complete and cost-effective home security solution.

System Requirements

•Computer with Windows® 8/7/Vista®/XP (SP3), or Mac OS® X (10.5 or higher)

•PC with 1.3GHz or above and at least 128MB RAM

•Internet Explorer 8, Firefox 12, Safari 4, or Chrome 20 or higher version with Java installed and enabled

•Existing 10/100 Ethernet-based network or 802.11g/n wireless network

•Internet connection (for mydlink services)

D-Link DCS-2330L User Manual

Section 1: Product Overview

Features

Simple to Use

The DCS-2330L is a stand-alone system with a built-in CPU, requiring no special hardware or software. The DCS-2330L supports both ActiveX mode for Internet Explorer and Java mode for other browsers such as Firefox® and Safari®.

Supports a Variety of Platforms

Supporting TCP/IP networking, HTTP, and other Internet related protocols. The DCS-2330L can also be integrated easily into other Internet/Intranet applications because of its standards-based features.

Web Configuration

Using a standard Web browser, administrators can configure and manage the Network Camera directly from its own Web page via Intranet or Internet. This means you can access your DCS-2330L anytime, anywhere in the world.

Broad Range of Applications

With today’s high-speed Internet services, the Network Camera can provide the ideal solution for delivering live video images over the Intranet and Internet for remote monitoring. The Network Camera allows remote access using a Web browser for live image viewing, and allows the administrator to manage and control the Network Camera anytime, anywhere in the world. Many applications exist, including industrial and public monitoring of homes, offices, banks, hospitals, child-care centers, and amusement parks.

Remote Monitoring Utility

The D-ViewCam application adds enhanced features and functionality for the Network Camera and allows administrators to configure and access the Network Camera from a remote site via Intranet or Internet. Other features include image monitoring, recording images to a hard drive, viewing up to 32 cameras on one screen, and taking snapshots.

IR LED for Day and Night Functionality

The built-in infrared LEDs enables night time viewing of up to 16 feet (5 meters).

IP65 Weatherproof Housing

The DCS-2330L uses an IP65 weatherproof housing, allowing you to rest assured that in the toughest of conditions, it will continue to provide round-the-clock surveillance.

802.11n Wireless or Ethernet/Fast Ethernet Support

The DCS-2330L offers wireless 802.11n and Ethernet/Fast Ethernet connectivity, making the DCS-2330L easy to integrate into your existing network environment. The DCS-2330L works with a 10Mbps Ethernet based network or 100Mbps Fast Ethernet based network for traditional wired environments, and works with 802.11n routers or access points for added flexibility. The Site Survey feature also allows you to view and connect to any available wireless networks.

D-Link DCS-2330L User Manual

Section 1: Product Overview

Hardware Overview

Front

2 5

	1	Camera Lens	Records video of the surrounding area

	2	Light Sensor	The light sensor measures the lighting conditions and switches between color
	2	Light Sensor	and infrared accordingly
			and infrared accordingly

	3	Microphone	Records audio from the surrounding area

	4	PIR	Passive Infrared sensor for motion detection

	5	IR LED	Infrared LED illuminates the camera's field of view at night

	6	WPS Status LED	Indicates the WPS connection status of the camera

	7	Power/Status LED	Indicates the camera's current status

	8	Antenna	Outdoor wireless antenna


D-Link DCS-2330L User Manual			7

Section 1: Product Overview

Rear: External

1
2	5
	6

1	Weatherproof Cover	Weatherproof protective panel

2	Protective Cable Cover	Weatherproof cable connection cover

3	Weatherproof Cover	Weatherproof cover for the microSD Card slot and reset button

4	Weatherproof Screw Covering	Weatherproof protective covering for enclosure screws

5	Power Cable Receptacle	Connects to the included DC 5V power adapter

6	WPS Button	Press this button, then press the WPS button for 5 seconds on your
6	WPS Button	router to set up a wireless connection automatically
		router to set up a wireless connection automatically

7	Adjustment Ring	Tighten or loosen the adjustment ring to adjust the camera's position

D-Link DCS-2330L User Manual

Section 1: Product Overview

Rear: Internal

3 4

1	DC Power Connector	Connected to the included DC 5V power adapter

2	RJ45 Ethernet Port	RJ-45 connector for Ethernet

3	Reset Button	Use a paperclip or similar tool to press and hold the recessed button for
3	Reset Button	10 seconds to reset the camera
		10 seconds to reset the camera

4	SD Memory Card Slot	Insert a microSD card for storing recorded images and video

D-Link DCS-2330L User Manual

Section 1: Product Overview

Removing the Top Panel

2 3 4

Step 1:

Place the camera face down on a non-slip flat surface.

Step 2:

Carefully pry out the two protective rubber screw coverings using a thin flat blade.

Step 3:

Undo the two screws using a Phillips #00 Screwdriver.

Step 4:

Lift off the protective panel.

Note: To ensure that the camera stays weatherproof, users are advised to ensure that all the rubber seals are secured firmly in place.

D-Link DCS-2330L User Manual

Section 1: Product Overview

Replacing the Ethernet Cable

3 2

Step 1:

Follow the steps outlined in "Removing the Top Panel" on page 10.

Step 2:

Unplug the Ethernet cable from the RJ-45 connector.

Step 3:

Carefully remove the weatherproof cable connection cover.

Step 4:

Attach the weatherproof cable connection cover to the new Ethernet cable.

Step 5:

Plug the new Ethernet cable into the RJ-45 connector.

Step 6:

Follow the steps outlined in "Reattaching the Top Panel" on page 12.

Note: To avoid damage to the weatherproof aspects of the camera, users are advised not to remove the rear cable connection covering. To use a longer Ethernet cable install a coupling adaptor.

D-Link DCS-2330L User Manual

Section 1: Product Overview

Reattaching the Top Panel

3 2 1

Step 1:

Seat the protective panel, ensuring a tight fit with the inlaid rubber seal.

Step 2:

Replace the two screws. Ensure that the screws are tightened firmly.

Step 3:

Firmly replace the protective rubber screw coverings.

Note: To ensure that the camera stays weatherproof, users are advised to ensure that all the rubber seals are secured firmly in place.

D-Link DCS-2330L User Manual

Section 1: Product Overview

Removing the Bottom Panel

Step 1:

Place the camera face down on a non-slip flat surface.

Step 2:

Carefully pry out the two protective rubber screw coverings using a thin flat blade.

Step 3:

Undo the two screws using a Phillips #00 Screwdriver.

Step 4:

Lift off the protective panel.

If you need to install an microSD memory card please skip to "Installing an SD Memory Card" on page 14.

Using the Reset Button

If you need to use the Reset Button follow these steps.
Step 1:
Follow the steps outlined in "Removing the Bottom Panel" on page 13.
Step 2:
Using a paperclip or similar tool, press and hold the Reset Button for 10 seconds.
This will reset the device to it's factory settings.
Step 3:	2
Follow the steps outlined in "Reattaching the Bottom Panel" on page 14.	2

D-Link DCS-2330L User Manual

Section 1: Product Overview

Installing an SD Memory Card

Step 1:

Follow the steps outlined in "Removing the Bottom Panel" on page 13.

Step 2:

Insert a microSD memory card into the slot, with the notch facing right.

Step 3:

Follow the steps outlined in "Reattaching the Bottom Panel" on page 14.

Reattaching the Bottom Panel

Step 1:

Seat the protective panel, ensuring a tight fit with the inlaid rubber seal.

Step 2:	3
Replace the two screws. Ensure that the screws are tightened firmly.

Step 3:	4
	4

Firmly replace the protective rubber screw coverings.

Note: To ensure that the camera stays weatherproof, users are advised to ensure that all the rubber seals are secured firmly in place.

D-Link DCS-2330L User Manual

Section 2: Installation

Installation

If you have a D-Link Cloud Router, skip to page 16 and follow the steps. You do not have to download and run the setup wizard software.

If you do not have a cloud router, open a web browser and go to http://www.mydlink.com/download. Click your camera model and then under Wizard, click the link of the version (Windows or Mac) you want to download. Depending on your web browser, you may need to right-click the link and select Save link as. Once downloaded, launch the wizard and follow the on-screen instructions.

Note: If you experience issues registering this camera with your mydlink account, try performing a hard reset by using an unfolded paperclip to press and hold the reset button for 10 seconds while the camera is powered on. This may be necessary if you have purchased an open box or resold unit.

Once the wizard is complete, log in to your mydlink account and skip to "mydlink" on page 20.

D-Link DCS-2330L User Manual

Section 2: Installation

Zero Configuration Setup

If you have a mydlink-enabled Cloud Router, you can take advantage of Zero Configuration. Zero Configuration automatically configures your camera's settings for you, and adds it to your mydlink account automatically. This type of setup allows you to set up your camera by simply plugging it in and connecting it to your router. Your Cloud Router will automatically assign your network settings (both wired and wireless) to your camera.

Note: The Zero Configuration Setup will only work with a registered D-Link Cloud Router and an active mydlink account.

Step 1:

Connect the power adapter to a wall outlet or power strip. Power is confirmed when the Power LED is lit.

Step 2:

You can either connect an Ethernet cable from the camera to your router or useWPS. If you want to use an Ethernet connection, Carefully remove the rubber seal on the back of the camera and connect the included Ethernet cable to the Ethernet port on the camera and connect it to your router.

If you want to use a wireless connection, press and hold the WPS button on the camera for five seconds.The WPS status LED will start to blink.Then, press the WPS button on your Cloud Router within 2 minutes.

D-Link DCS-2330L User Manual

Section 2: Installation

Step 3:

From any computer, open a web browser, go to http://www.mydlink.com and log into your account. Once mydlink detects your camera, a New Device Found! notice will appear in the bottom-right corner. Click the notification to continue.

Step 4:

A summary and confirmation notification will appear with the automatically configured details. Enter a password for your camera (next to Device Password) and click Yes to add the camera to your account.

D-Link DCS-2330L User Manual

Section 2: Installation

Step 5:

Zero Configuration will navigate to the mydlink Live View tab for your camera where you will see a screen similar to the following.

If you wish to connect your camera to your router wirelessly, you can simply disconnect the Ethernet cable and move the camera to its intended location; your router's wireless settings have been automatically transferred to the camera, and no further configuration is required.

Your camera is now set up, and you can skip to "mydlink" on page 20 to learn more about the mydlink features of this camera, or to "Configuration" on page 22 for advanced configuration of your camera.

Your setup is complete!

D-Link DCS-2330L User Manual

Section 2: Installation

Mount the Camera

We suggest that you configure the camera before mounting.

1.Place the mounting base where you want to position the camera and use a pencil to mark the holes.

2.Depending on the material of the wall or ceiling, use proper tools to drill two holes or screws where you marked. If the wall is made out of concrete, drill the holes first, insert the plastic anchors and then the screws.

The space between the camera and the screwheads should be 3mm.

3.When you place the mounting plate over the holes that you drilled in the wall, make sure you align the holes. Use the supplied screws to attach the mounting base to the surface of the wall.

4.Place the mounting base cover on the mounting plate. Reattach the camera mount onto the mounting base by holding the camera mount and twisting the camera mount clockwise into the mounting base.

5.Adjust the direction of the camera as desired, then tighten the collar on the cameara mount to lock it in place.

D-Link DCS-2330L User Manual

Section 2: Installation

mydlink

After registering your DCS-2330L camera with a mydlink account in the Camera Installation Wizard, you will be able to remotely access your camera from the www.mydlink.com website. After signing in to your mydlink account, you will see a screen similar to the following:

For more details on using your camera with mydlink, go to the Support section of the mydlink website and check the User Manual section for your product to find the latest instruction guide for your camera's mydlink features.

D-Link DCS-2330L User Manual

Section 2: Installation

Camera Status

Here, you can see the online status of each of your cameras. Your online status may be one of the following:

A green checkmark indicates that your camera is online and ready to use.

A yellow exclamation point indicates that your camera is online, but the camera password has changed. You will need to enter your new camera password to access your camera again.

A red X indicates that your camera is offline and currently cannot be accessed remotely.

If your camera is offline, try the following:

•Check to make sure that the Internet connection to your camera is working properly.

•Try restarting your Internet router.

•Check your camera’s cable connections and make sure they are secure.

•Check to make sure that the LED on your camera is lit solid green.

If you still cannot access your camera, reset your camera and run the Camera Installation Wizard again from http://www. mydlink.com/support.

D-Link DCS-2330L User Manual

Section 3: Configuration

Configuration

Using the Configuration Interface

After completing the Camera Installation Wizard, you are ready to use your camera. The camera’s built-in Web configuration utility is designed to allow you to easily access and configure your DCS-2330L. At the end of the wizard, enter the IP address of your camera into a web browser (Internet Explorer, Firefox, Chrome, or Safari).To log in, use the User name admin and the password you created in the Installation Wizard. If you did not create a password, the default password is blank. After entering your password, click OK.

D-Link DCS-2330L User Manual

+ 50 hidden pages
