ST ST72324J6, ST72324K6, ST72324J4, ST72324K4, ST72324J2 User Manual

ST72324Jx ST72324Kx

5V RANGE 8-BIT MCU WITH 8 TO 32K FLASH, 10-BIT ADC, 4 TIMERS, SPI, SCI INTERFACE

NOT FOR NEW DESIGN

■Memories

–8 to 32K dual voltage High Density Flash (HDFlash) with read-out protection capability. InApplication Programming and In-Circuit Programming for HDFlash devices

–384 to 1K bytes RAM

–HDFlash endurance: 100 cycles, data retention: 20 years at 55°C

■Clock, Reset And Supply Management

–Enhanced low voltage supervisor (LVD) for main supply with programmable reset thresholds and auxiliary voltage detector (AVD) with interrupt capability

–Clock sources: crystal/ceramic resonator oscillators, internal RC oscillator, clock security system and bypass for external clock

–PLL for 2x frequency multiplication

–Four Power Saving Modes: Halt, Active-Halt, Wait and Slow

■Interrupt Management

–Nested interrupt controller

–10 interrupt vectors plus TRAP and RESET

–9/6 external interrupt lines (on 4 vectors)

■Up to 32 I/O Ports

–32/24 multifunctional bidirectional I/O lines

–22/17 alternate function lines

–12/10 high sink outputs

■4 Timers

–Main Clock Controller with: Real time base, Beep and Clock-out capabilities

–Configurable watchdog timer

–16-bit Timer A with: 1 input capture, 1 output compare, external clock input, PWM and pulse generator modes

–16-bit Timer B with: 2 input captures, 2 output compares, PWM and pulse generator modes

Device Summary

TQFP32 7 x 7

TQFP44 10 x 10

	SDIP42	SDIP32
		400 mil
	600 mil

■2 Communication Interfaces

–SPI synchronous serial interface

–SCI asynchronous serial interface

■1 Analog Peripheral (low current coupling)

–10-bit ADC with up to 12 robust input ports

■Instruction Set

–8-bit Data Manipulation

–63 Basic Instructions

–17 main Addressing Modes

–8 x 8 Unsigned Multiply Instruction

■Development Tools

–Full hardware/software development package

–In-Circuit Testing capability

Features	ST72324J6		ST72324J4		ST72324J2
	ST72324K61		ST72324K41		ST72324JK21
Program memory -	Flash 32K		Flash 16K		Flash 8K
bytes
RAM (stack) - bytes	1024 (256)		512 (256)		384 (256)
Voltage Range			3.8V to 5.5V
Temp. Range			up to -40°C to +125°C
Packages		SDIP42, TQFP44 10x10,SDIP32, TQFP32 7x7

1For new designs in standard and industrial applications, use ST72324B(J/K) order codes, refer to separate datasheet

April 2008

Rev. 5

1/164

1

Table of Contents

1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2 PIN DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 3 REGISTER & MEMORY MAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 4 FLASH PROGRAM MEMORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 4.2 MAIN FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 4.3 STRUCTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 4.3.1 Read-out Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 4.4 ICC INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4.5 ICP (IN-CIRCUIT PROGRAMMING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 4.6 IAP (IN-APPLICATION PROGRAMMING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 4.7 RELATED DOCUMENTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 4.7.1 Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

5 CENTRAL PROCESSING UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

5.1	INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	20
5.2	MAIN FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	20
5.3	CPU REGISTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	20

6 SUPPLY, RESET AND CLOCK MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

6.1 PHASE LOCKED LOOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

6.2 MULTI-OSCILLATOR (MO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6.3 RESET SEQUENCE MANAGER (RSM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

6.3.1	Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	25
6.3.2 Asynchronous External RESET pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .		25
6.3.3	External Power-On RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	26
6.3.4 Internal Low Voltage Detector (LVD) RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . .		26
6.3.5	Internal Watchdog RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	26
6.4 SYSTEM INTEGRITY MANAGEMENT (SI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .		27

6.4.1 Low Voltage Detector (LVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 6.4.2 Auxiliary Voltage Detector (AVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 6.4.3 Low Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 6.4.4 Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

7 INTERRUPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

7.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 7.2 MASKING AND PROCESSING FLOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 7.3 INTERRUPTS AND LOW POWER MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 7.4 CONCURRENT & NESTED MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 7.5 INTERRUPT REGISTER DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 7.6 EXTERNAL INTERRUPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7.6.1 I/O Port Interrupt Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 7.7 EXTERNAL INTERRUPT CONTROL REGISTER (EICR) . . . . . . . . . . . . . . . . . . . . . . . 38

8 POWER SAVING MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

40

8.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 8.2 SLOW MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 8.3 WAIT MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

2/164

2

Table of Contents

8.4 ACTIVE-HALT AND HALT MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

42

8.4.1 ACTIVE-HALT MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 8.4.2 HALT MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

9 I/O PORTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

9.1	INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .		45
9.2	FUNCTIONAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .		45
	9.2.1	Input Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	45
	9.2.2	Output Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	45
	9.2.3	Alternate Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	45
9.3	I/O PORT IMPLEMENTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .		48
9.4	LOW POWER MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .		48
9.5	INTERRUPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .		48
	9.5.1	I/O Port Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	49

10 ON-CHIP PERIPHERALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

10.1 WATCHDOG TIMER (WDG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

10.1.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 10.1.2 Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 10.1.3 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 10.1.4 How to Program the Watchdog Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 10.1.5 Low Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 10.1.6 Hardware Watchdog Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 10.1.7 Using Halt Mode with the WDG (WDGHALT option) . . . . . . . . . . . . . . . . . . . . . . . 54 10.1.8 Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 10.1.9 Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

10.2 MAIN CLOCK CONTROLLER WITH REAL TIME CLOCK AND BEEPER (MCC/RTC) . 56

10.2.1 Programmable CPU Clock Prescaler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

10.2.2 Clock-out Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

10.2.3 Real Time Clock Timer (RTC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

10.2.4 Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

10.2.5 Low Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

10.2.6 Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

10.2.7 Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

10.3 16-BIT TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

10.3.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 10.3.2 Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 10.3.3 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 10.3.4 Low Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 10.3.5 Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 10.3.6 Summary of Timer modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 10.3.7 Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

10.4 SERIAL PERIPHERAL INTERFACE (SPI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

10.4.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

10.4.2 Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

10.4.3 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

10.4.4 Clock Phase and Clock Polarity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

10.4.5 Error Flags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

10.4.6 Low Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

3/164

1

Table of Contents
10.4.7 Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	. 86
10.4.8 Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	87
10.5 SERIAL COMMUNICATIONS INTERFACE (SCI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	90
10.5.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	90
10.5.2 Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	90
10.5.3 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	90
10.5.4 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	92
10.5.5 Low Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	99
10.5.6 Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	99
10.5.7 Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	100
10.6 10-BIT A/D CONVERTER (ADC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	106

10.6.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

10.6.2 Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

10.6.3 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

10.6.4 Low Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

10.6.5 Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

10.6.6 Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

11 INSTRUCTION SET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	110
11.1 CPU ADDRESSING MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	110

11.1.1 Inherent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 11.1.2 Immediate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 11.1.3 Direct . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 11.1.4 Indexed (No Offset, Short, Long) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 11.1.5 Indirect (Short, Long) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 11.1.6 Indirect Indexed (Short, Long) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112 11.1.7 Relative mode (Direct, Indirect) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

11.2 INSTRUCTION GROUPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

12 ELECTRICAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

12.1 PARAMETER CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

12.1.1 Minimum and Maximum values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116 12.1.2 Typical values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116 12.1.3 Typical curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116 12.1.4 Loading capacitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116 12.1.5 Pin input voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

12.2 ABSOLUTE MAXIMUM RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

12.2.1 Voltage Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	117
12.2.2 Current Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	117
12.2.3 Thermal Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	118
12.3 OPERATING CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	118

12.3.1 Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

12.4 LVD/AVD CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

12.4.1 Operating Conditions with Low Voltage Detector (LVD) . . . . . . . . . . . . . . . . . . . . 119 12.4.2 Auxiliary Voltage Detector (AVD) Thresholds . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119 12.5 SUPPLY CURRENT CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

12.5.1 CURRENT CONSUMPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

12.5.2 Supply and Clock Managers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

12.5.3 On-Chip Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

4/164

1

Table of Contents

12.6 CLOCK AND TIMING CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

12.6.1 General Timings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	124
12.6.2 External Clock Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	124
12.6.3 Crystal and Ceramic Resonator Oscillators . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	125
12.6.4 RC Oscillators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	127
12.6.5 PLL Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	128
12.7 MEMORY CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	129

12.7.1 RAM and Hardware Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

12.7.2 FLASH Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

12.8 EMC CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

12.8.1 Functional EMS (Electro Magnetic Susceptibility) . . . . . . . . . . . . . . . . . . . . . . . . 130 12.8.2 Electro Magnetic Interference (EMI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131 12.8.3 Absolute Maximum Ratings (Electrical Sensitivity) . . . . . . . . . . . . . . . . . . . . . . . . 132 12.9 I/O PORT PIN CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

12.9.1 General Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

12.9.2 Output Driving Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

12.10 CONTROL PIN CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

12.10.1Asynchronous RESET Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136 12.10.2ICCSEL/VPP Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138 12.11 TIMER PERIPHERAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

12.11.116-Bit Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

12.12 COMMUNICATION INTERFACE CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . 140

12.12.1SPI - Serial Peripheral Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

12.13 10-BIT ADC CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

12.13.1Analog Power Supply and Reference Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	144
12.13.2General PCB Design Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	144
12.13.3ADC Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	145
13 PACKAGE CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	146

13.1 PACKAGE MECHANICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146 13.2 THERMAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148 13.3 SOLDERING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

14 ST72324 DEVICE CONFIGURATION AND ORDERING INFORMATION . . . . . . . . . . . . . . . 150

14.1	FLASH OPTION BYTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	150
14.2	FLASH DEVICE ORDERING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	152
14.3	SILICON IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	154
14.4	DEVELOPMENT TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	155
	14.4.1 Socket and Emulator Adapter Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	156
14.5	ST7 APPLICATION NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	157

15 KNOWN LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

15.1 ALL DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

15.1.1 External RC option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 15.1.2 CSS Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 15.1.3 Safe Connection of OSC1/OSC2 Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 15.1.4 Unexpected Reset Fetch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 15.1.5 Clearing active interrupts outside interrupt routine . . . . . . . . . . . . . . . . . . . . . . . . 159 15.1.6 External Interrupt Missed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

5/164

1

Table of Contents

15.1.7 16-bit Timer PWM Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161 15.1.8 SCI Wrong Break duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161 15.2 FLASH DEVICES ONLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

15.2.1 Internal RC Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

16 IMPORTANT NOTES ON ST72F324B FLASH DEVICES: . . . . . . . . . . . . . . . . . . . . . . . . . . 162

16.1 RESET PIN LOGIC LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

16.2 WAKE-UP FROM ACTIVE HALT MODE USING EXTERNAL INTERRUPTS . . . . . . . 162

16.3 PLL JITTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

16.4 ACTIVE HALT POWER CONSUMPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

16.5 TIMER A REGISTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

17 REVISION HISTORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

To obtain the most recent version of this datasheet,

please check at www.st.com>products>technical literature>datasheet.

Please also pay special attention to the Section “KNOWN LIMITATIONS” on page 159.

6/164

1

ST72324Jx ST72324Kx

1 INTRODUCTION

The ST72324 devices are members of the ST7 microcontroller family designed for the 5V operating range.

–The 32-pin devices are designed for mid-range applications

–The 42/44-pin devices target the same range of applications requiring more than 24 I/O ports.

For a description of the differences between ST72324 and ST72324B devices refer to Section 14.2 on page 152

All devices are based on a common industrystandard 8-bit core, featuring an enhanced instruc-

Figure 1. Device Block Diagram

tion set and are available with FLASH program memory.

Under software control, all devices can be placed in WAIT, SLOW, ACTIVE-HALT or HALT mode, reducing power consumption when the application is in idle or stand-by state.

The enhanced instruction set and addressing modes of the ST7 offer both power and flexibility to software developers, enabling the design of highly efficient and compact application code. In addition to standard 8-bit data management, all ST7 microcontrollers feature true bit manipulation, 8x8 unsigned multiplication and indirect addressing modes.

									8-BIT CORE
									ALU
	RESET								CONTROL
	VPP
	VSS
	VDD								LVD

OSC1

OSC2

PF7:6,4,2:0 (6 bits on J devices) (5 bits on K devices)

PE1:0 (2 bits)

PD5:0 (6 bits on J devices) (2 bits on K devices)

VAREF

OSC

MCC/RTC/BEEP

PORT F

TIMER A

BEEP

PORT E

SCI

PORT D

10-BIT ADC

VSSA

BUS DATA AND ADDRESS

PROGRAM

MEMORY

(8K - 32K Bytes)

RAM

(384 - 1024 Bytes)

WATCHDOG

PORT A

PORT B

PORT C

TIMER B

SPI

PA7:3

(5 bits on J devices) (4 bits on K devices)

PB4:0

(5 bits on J devices) (3 bits on K devices)

PC7:0 (8 bits)

7/164

3

ST72324Jx ST72324Kx

2 PIN DESCRIPTION

Figure 2. 42-Pin SDIP and 44-Pin TQFP Package Pinouts

PE0/ TDO

2

OSC1

OSC2

2

RESET

/ ICCSEL

PA7(HS)

PA6(HS)

PA5(HS)

PA4(HS)

V

V

V

DD

SS

PP

RDI / PE1

44 43 42 41 40 39 38 37 36 35 34

VSS_1

1

33

PB0

2

32

VDD_1

PB1

3

ei2

ei0

31

PA3 (HS)

PB2

4

30

PC7 / SS / AIN15

PB3

5

29

PC6 / SCK / ICCCLK

(HS) PB4

6

ei3

28

PC5 / MOSI / AIN14

AIN0 / PD0

7

27

PC4 / MISO / ICCDATA

AIN1 / PD1

8

26

PC3 (HS) / ICAP1_B

AIN2 / PD2

9

25

PC2 (HS) / ICAP2_B

AIN3 / PD3

10

ei1

24

PC1 / OCMP1_B / AIN13

AIN4 / PD4

11

23

PC0 / OCMP2_B / AIN12

12 13 14 15 16 17 18 19 20 21 22

AIN5 / PD5		AREF	SSA	MCO/ AIN8 / PF0	BEEP / (HS) PF1	(HS) PF2	OCMP1A / AIN10 / PF4	ICAP1A / (HS) PF6	EXTCLKA / (HS) PF7
		V	V
(HS) PB4					ei3				42
			1
AIN0 / PD0			2				ei2		41
AIN1 / PD1			3						40
AIN2 / PD2			4						39
AIN3 / PD3			5						38
AIN4 / PD4			6						37
AIN5 / PD5			7						36
VAREF			8						35
VSSA			9						34
MCO / AIN8 / PF0			10						33
BEEP / (HS) PF1			11		ei1				32
(HS) PF2			12						31
AIN10 / OCMP1_A / PF4			13						30
ICAP1_A / (HS) PF6			14						29
EXTCLK_A / (HS) PF7			15						28
AIN12 / OCMP2_B / PC0			16						27
AIN13 / OCMP1_B / PC1			17						26
ICAP2_B/ (HS) PC2			18						25
ICAP1_B / (HS) PC3			19				ei0		24
ICCDATA / MISO / PC4			20						23
AIN14 / MOSI / PC5			21						22

DD 0	SS 0
V	V

PB3

PB2

PB1

PB0

PE1 / RDI

PE0 / TDO

VDD_2

OSC1

OSC2

VSS_2

RESET

VPP / ICCSEL

PA7 (HS)

PA6 (HS)

PA5 (HS)

PA4 (HS)

VSS_1

VDD_1

PA3 (HS)

PC7 / SS / AIN15

PC6 / SCK / ICCCLK

(HS)	20mA high sink capability
eix	associated external interrupt vector

8/164

ST72324Jx ST72324Kx

PIN DESCRIPTION (Cont’d)

Figure 3. 32-Pin SDIP Package Pinout

(HS) PB4

PB3

1

ei3

ei2

32

AIN0 / PD0

PB0

2

31

AIN1 / PD1

PE1 / RDI

3

30

VAREF

4

29

PE0 / TDO

VSSA

5

28

VDD_2

MCO / AIN8 / PF0

6

ei1

27

OSC1

BEEP / (HS) PF1

7

26

OSC2

OCMP1_A / AIN10 / PF4

8

25

VSS_2

ICAP1_A / (HS) PF6

9

24

RESET

EXTCLK_A / (HS) PF7

10

23

VPP / ICCSEL

AIN12 / OCMP2_B / PC0

11

22

PA7 (HS)

AIN13 / OCMP1_B / PC1

12

21

PA6 (HS)

ICAP2_B / (HS) PC2

13

20

PA4 (HS)

ICAP1_B / (HS) PC3

14

ei0

19

PA3 (HS)

ICCDATA/ MISO / PC4

PC7 /

/ AIN15

15

18

SS

AIN14 / MOSI / PC5

16

17

PC6 / SCK / ICCCLK

(HS)

20mA high sink capability

eix

associated external interrupt vector

Figure 4. 32-Pin TQFP 7x7 Package Pinout

/ AIN1

/ AIN0

(HS)

PB3 PB0

/ RDI

/ TDO

_2

PD1

PD0

PB4

PE1

PE0

V

DD

VAREF

32 31 30

29 28 27 26 25

OSC1

1

ei3

ei2

24

VSSA

2

23

OSC2

MCO / AIN8 / PF0

3

22

VSS_2

BEEP / (HS) PF1

ei1

21

4

RESET

OCMP1_A / AIN10 / PF4

5

20

VPP / ICCSEL

ICAP1_A / (HS) PF6

6

19

PA7 (HS)

EXTCLK_A / (HS) PF7

7

18

PA6 (HS)

AIN12 / OCMP2_B / PC0

8

ei0 17

PA4 (HS)

9

10 11 12 13 14 15 16

AIN13 / OCMP1 B / PC1	ICAP2 B / (HS) PC2	ICAP1 B / (HS) PC3	ICCDATA / MISO / PC4	AIN14 / MOSI / PC5	ICCCLK / SCK / PC6		AIN15 / SS / PC7	(HS) PA3

(HS) 20mA high sink capability

eix associated external interrupt vector

9/164

1

ST72324Jx ST72324Kx

PIN DESCRIPTION (Cont’d)

For external pin connection guidelines, refer to See “ELECTRICAL CHARACTERISTICS” on page 116.

Legend / Abbreviations for Table 1:

Type:		I = input, O = output, S = supply
Input level:		A = Dedicated analog input
In/Output level: C = CMOS 0.3VDD/0.7VDD
Output level:		CT= CMOS 0.3VDD/0.7VDD with input trigger
		HS = 20mA high sink (on N-buffer only)
Port and control configuration:
–	Input:	float = floating, wpu = weak pull-up, int = interrupt 1), ana = analog ports
–	Output:	OD = open drain 2), PP = push-pull

Refer to “I/O PORTS” on page 45 for more details on the software configuration of the I/O ports.

The RESET configuration of each pin is shown in bold. This configuration is valid as long as the device is in reset state.

Table 1. Device Pin Description

Pin n°

Level

Port

Main

Type

TQFP44

SDIP42

TQFP32

SDIP32

Pin Name

Input

Output

float

Input

ana

Output

function

Alternate Function

wpu

int

OD

PP

(after

reset)

6

1

30

1

PB4 (HS)

I/O

CT

HS

X

ei3

X

X

Port B4

7

2

31

2

PD0/AIN0

I/O

CT

X

X

X

X

X

Port D0

ADC Analog Input 0

8

3

32

3

PD1/AIN1

I/O

CT

X

X

X

X

X

Port D1

ADC Analog Input 1

9

4

PD2/AIN2

I/O

CT

X

X

X

X

X

Port D2

ADC Analog Input 2

10

5

PD3/AIN3

I/O

CT

X

X

X

X

X

Port D3

ADC Analog Input 3

11

6

PD4/AIN4

I/O

CT

X

X

X

X

X

Port D4

ADC Analog Input 4

12

7

PD5/AIN5

I/O

CT

X

X

X

X

X

Port D5

ADC Analog Input 5

13

8

1

4

VAREF

S

Analog Reference Voltage for ADC

14

9

2

5

VSSA

S

Analog Ground Voltage

15

10

3

6

PF0/MCO/AIN8

I/O

CT

X

ei1

X

X

X

Port F0

Main clock

ADC Analog

out (fCPU)

Input 8

16

11

4

7

PF1 (HS)/BEEP

I/O

CT

HS

X

ei1

X

X

Port F1

Beep signal output

17

12

PF2 (HS)

I/O

CT

HS

X

ei1

X

X

Port F2

PF4/OCMP1_A/

X

Timer A Out-

ADC Analog

18

13

5

8

AIN10

I/O

CT

X

X

X

X

Port F4

put Com-

Input 10

pare 1

19

14

6

9

PF6 (HS)/ICAP1_A

I/O

CT

HS

X

X

X

X

Port F6

Timer A Input Capture 1

20

15

7

10

PF7 (HS)/

I/O

CT

HS

X

X

X

X

Port F7

Timer A External Clock

EXTCLK_A

Source

21

VDD_0

S

Digital Main Supply Voltage

22

VSS_0

S

Digital Ground Voltage

PC0/OCMP2_B/

X

Timer B Out-

ADC Analog

23

16

8

11

AIN12

I/O

CT

X

X

X

X

Port C0

put Com-

Input 12

pare 2

10/164

1

ST72324Jx ST72324Kx

Pin n°

Level

Port

Main

Type

TQFP44

SDIP42

TQFP32

SDIP32

Pin Name

Input

Output

float

Input

ana

Output

function

Alternate Function

wpu

int

OD

PP

(after

reset)

PC1/OCMP1_B/

X

Timer B Out-

ADC Analog

24

17

9

12

AIN13

I/O

CT

X

X

X

X

Port C1

put Com-

Input 13

pare 1

25

18

10

13

PC2 (HS)/ICAP2_B

I/O

CT

HS

X

X

X

X

Port C2

Timer B Input Capture 2

26

19

11

14

PC3 (HS)/ICAP1_B

I/O

CT

HS

X

X

X

X

Port C3

Timer B Input Capture 1

PC4/MISO/ICCDA-

SPI Master

ICC Data In-

27

20

12

15

I/O

CT

X

X

X

X

Port C4

In / Slave

TA

put

Out Data

SPI Master

ADC Analog

28

21

13

16

PC5/MOSI/AIN14

I/O

CT

X

X

X

X

X

Port C5

Out / Slave

Input 14

In Data

29

22

14

17

PC6/SCK/ICCCLK

I/O

CT

X

X

X

X

Port C6

SPI Serial

ICC Clock

Clock

Output

SPI Slave

ADC Analog

30

23

15

18

PC7/SS/AIN15

I/O

CT

X

X

X

X

X

Port C7

Select (ac-

Input 15

tive low)

31

24

16

19

PA3 (HS)

I/O

CT

HS

X

ei0

X

X

Port A3

32

25

VDD_1

S

Digital Main Supply Voltage

33

26

VSS_1

S

Digital Ground Voltage

34

27

17

20

PA4 (HS)

I/O

CT

HS

X

X

X

X

Port A4

35

28

PA5 (HS)

I/O

CT

HS

X

X

X

X

Port A5

36

29

18

21

PA6 (HS)

I/O

C

HS

X

T

Port A6 1)

T

37

30

19

22

PA7 (HS)

I/O

C

HS

X

T

Port A7 1)

T

Must be tied low. In the flash pro-

38

31

20

23

VPP /ICCSEL

I

gramming mode, this pin acts as the

programming voltage input VPP. See

Section 12.10.2 for more details.

39

32

21

24

I/O

CT

Top priority non maskable interrupt.

RESET

40

33

22

25

VSS_2

S

Digital Ground Voltage

41

34

23

26

OSC2

O

Resonator oscillator inverter output

42

35

24

27

OSC1

I

External clock input or Resonator os-

cillator inverter input

43

36

25

28

VDD_2

S

Digital Main Supply Voltage

44

37

26

29

PE0/TDO

I/O

CT

X

X

X

X

Port E0

SCI Transmit Data Out

1

38

27

30

PE1/RDI

I/O

CT

X

X

X

X

Port E1

SCI Receive Data In

Caution: Negative current

2

39

28

31

PB0

I/O

CT

X

ei2

X

X

Port B0

injection not allowed on this

pin5)

3

40

PB1

I/O

CT

X

ei2

X

X

Port B1

4

41

PB2

I/O

CT

X

ei2

X

X

Port B2

5

42

29

32

PB3

I/O

CT

X

ei2

X

X

Port B3

Notes:

1. In the interrupt input column, “eiX” defines the associated external interrupt vector. If the weak pull-up

11/164

1

ST72324Jx ST72324Kx

column (wpu) is merged with the interrupt column (int), then the I/O configuration is pull-up interrupt input, else the configuration is floating interrupt input.

2.In the open drain output column, “T” defines a true open drain I/O (P-Buffer and protection diode to VDD are not implemented). See See “I/O PORTS” on page 45. and Section 12.9 I/O PORT PIN CHARACTERISTICS for more details.

3.OSC1 and OSC2 pins connect a crystal/ceramic resonator, or an external source to the on-chip oscillator; see Section 1 INTRODUCTION and Section 12.6 CLOCK AND TIMING CHARACTERISTICS for more details.

4.On the chip, each I/O port has 8 pads. Pads that are not bonded to external pins are in input pull-up configuration after reset. The configuration of these pads must be kept at reset state to avoid added current consumption.

5.For details refer to Section 12.9.1 on page 133

12/164

1

ST72324Jx ST72324Kx

3 REGISTER & MEMORY MAP

As shown in Figure 5, the MCU is capable of addressing 64K bytes of memories and I/O registers.

The available memory locations consist of 128 bytes of register locations, up to 1024 bytes of RAM and up to 32 Kbytes of user program memory. The RAM space includes up to 256 bytes for the stack from 0100h to 01FFh.

Figure 5. Memory Map

The highest address bytes contain the user reset and interrupt vectors.

IMPORTANT: Memory locations marked as “Reserved” must never be accessed. Accessing a reserved area can have unpredictable effects on the device.

0000h		0080h
	HW Registers		Short Addressing
	(see Table 2)
007Fh			RAM (zero page)
		00FFh
0080h
	RAM	0100h	256 Bytes Stack
	(1024,
		01FFh
	512 or 384 Bytes)
047Fh		0200h	16-bit Addressing
0480h
	Reserved		RAM
		027Fh
7FFFh
		or 047Fh
8000h
	Program Memory			8000h	32 KBytes
	(32K, 16K or 8K)			C000h
FFDFh					16 KBytes
FFE0h	Interrupt & Reset Vectors			E000h
					8 Kbytes
	(see Table 8)
FFFFh				FFFFh

13/164

1

ST72324Jx ST72324Kx

Table 2. Hardware Register Map

Address	Block	Register	Register Name	Reset	Remarks
		Label		Status
0000h	Port A 2)	PADR	Port A Data Register	00h1)	R/W
0001h		PADDR	Port A Data Direction Register	00h	R/W
0002h		PAOR	Port A Option Register	00h	R/W
0003h	Port B 2)	PBDR	Port B Data Register	00h1)	R/W
0004h		PBDDR	Port B Data Direction Register	00h	R/W
0005h		PBOR	Port B Option Register	00h	R/W
0006h		PCDR	Port C Data Register	00h1)	R/W
0007h	Port C	PCDDR	Port C Data Direction Register	00h	R/W
0008h		PCOR	Port C Option Register	00h	R/W
0009h	Port D 2)	PDADR	Port D Data Register	00h1)	R/W
000Ah		PDDDR	Port D Data Direction Register	00h	R/W
000Bh		PDOR	Port D Option Register	00h	R/W
000Ch		PEDR	Port E Data Register	00h1)	R/W
000Dh	Port E 2)	PEDDR	Port E Data Direction Register	00h	R/W2)
000Eh		PEOR	Port E Option Register	00h	R/W2)
000Fh	Port F 2)	PFDR	Port F Data Register	00h1)	R/W
0010h		PFDDR	Port F Data Direction Register	00h	R/W
0011h		PFOR	Port F Option Register	00h	R/W
0012h
to			Reserved Area (15 Bytes)
0020h
0021h		SPIDR	SPI Data I/O Register	xxh	R/W
0022h	SPI	SPICR	SPI Control Register	0xh	R/W
0023h		SPICSR	SPI Control/Status Register	00h	R/W
0024h		ISPR0	Interrupt Software Priority Register 0	FFh	R/W
0025h		ISPR1	Interrupt Software Priority Register 1	FFh	R/W
0026h	ITC	ISPR2	Interrupt Software Priority Register 2	FFh	R/W
0027h		ISPR3	Interrupt Software Priority Register 3	FFh	R/W
0028h		EICR	External Interrupt Control Register	00h	R/W
0029h	FLASH	FCSR	Flash Control/Status Register	00h	R/W
002Ah	WATCHDOG	WDGCR	Watchdog Control Register	7Fh	R/W
002Bh	SI	SICSR	System Integrity Control Status Register	xxh	R/W
002Ch	MCC	MCCSR	Main Clock Control / Status Register	00h	R/W
002Dh		MCCBCR	Main Clock Controller: Beep Control Register	00h	R/W
002Eh
to			Reserved Area (3 Bytes)
0030h
14/164

1

ST72324Jx ST72324Kx

Address	Block	Register	Register Name	Reset	Remarks
		Label		Status
0031h		TACR2	Timer A Control Register 2	00h	R/W
0032h		TACR1	Timer A Control Register 1	00h	R/W
0033h		TACSR	Timer A Control/Status Register3)4)	xxxx x0xxb	R/W
0034h		TAIC1HR	Timer A Input Capture 1 High Register	xxh	Read Only
0035h		TAIC1LR	Timer A Input Capture 1 Low Register	xxh	Read Only
0036h		TAOC1HR	Timer A Output Compare 1 High Register	80h	R/W
0037h		TAOC1LR	Timer A Output Compare 1 Low Register	00h	R/W
0038h	TIMER A	TACHR	Timer A Counter High Register	FFh	Read Only
0039h		TACLR	Timer A Counter Low Register	FCh	Read Only
003Ah		TAACHR	Timer A Alternate Counter High Register	FFh	Read Only
003Bh		TAACLR	Timer A Alternate Counter Low Register	FCh	Read Only
003Ch		TAIC2HR	Timer A Input Capture 2 High Register3)	xxh	Read Only
003Dh		TAIC2LR	Timer A Input Capture 2 Low Register3)	xxh	Read Only
003Eh		TAOC2HR	Timer A Output Compare 2 High Register4)	80h	R/W
003Fh		TAOC2LR	Timer A Output Compare 2 Low Register4)	00h	R/W
0040h			Reserved Area (1 Byte)
0041h		TBCR2	Timer B Control Register 2	00h	R/W
0042h		TBCR1	Timer B Control Register 1	00h	R/W
0043h		TBCSR	Timer B Control/Status Register	xxxx x0xxb	R/W
0044h		TBIC1HR	Timer B Input Capture 1 High Register	xxh	Read Only
0045h		TBIC1LR	Timer B Input Capture 1 Low Register	xxh	Read Only
0046h		TBOC1HR	Timer B Output Compare 1 High Register	80h	R/W
0047h		TBOC1LR	Timer B Output Compare 1 Low Register	00h	R/W
0048h	TIMER B	TBCHR	Timer B Counter High Register	FFh	Read Only
0049h		TBCLR	Timer B Counter Low Register	FCh	Read Only
004Ah		TBACHR	Timer B Alternate Counter High Register	FFh	Read Only
004Bh		TBACLR	Timer B Alternate Counter Low Register	FCh	Read Only
004Ch		TBIC2HR	Timer B Input Capture 2 High Register	xxh	Read Only
004Dh		TBIC2LR	Timer B Input Capture 2 Low Register	xxh	Read Only
004Eh		TBOC2HR	Timer B Output Compare 2 High Register	80h	R/W
004Fh		TBOC2LR	Timer B Output Compare 2 Low Register	00h	R/W
0050h		SCISR	SCI Status Register	C0h	Read Only
0051h		SCIDR	SCI Data Register	xxh	R/W
0052h		SCIBRR	SCI Baud Rate Register	00h	R/W
0053h	SCI	SCICR1	SCI Control Register 1	x000 0000h	R/W
0054h		SCICR2	SCI Control Register 2	00h	R/W
0055h		SCIERPR	SCI Extended Receive Prescaler Register	00h	R/W
0056h			Reserved area	---
0057h		SCIETPR	SCI Extended Transmit Prescaler Register	00h	R/W
0058h
to			Reserved Area (24 Bytes)
006Fh
0070h		ADCCSR	Control/Status Register	00h	R/W
0071h	ADC	ADCDRH	Data High Register	00h	Read Only
0072h		ADCDRL	Data Low Register	00h	Read Only
0073h			Reserved Area (13 Bytes)
007Fh
					15/164

1

ST72324Jx ST72324Kx

Legend: x=undefined, R/W=read/write

Notes:

1.The contents of the I/O port DR registers are readable only in output configuration. In input configuration, the values of the I/O pins are returned instead of the DR register contents.

2.The bits associated with unavailable pins must always keep their reset value.

3.The Timer A Input Capture 2 pin is not available (not bonded).

– In Flash devices:

The TAIC2HR and TAIC2LR registers are not present. Bit 5 of the TACSR register (ICF2) is forced by hardware to 0. Consequently, the corresponding interrupt cannot be used.

4.The Timer A Output Compare 2 pin is not available (not bonded).

–The TAOC2HR and TAOC2LR Registers are write only, reading them will return undefined values. Bit 4 of the TACSR register (OCF2) is forced by hardware to 0. Consequently, the corresponding interrupt cannot be used.

Caution: The TAIC2HR and TAIC2LR registers and the ICF2 and OCF2 flags are not present in Flash devices but are present in the emulator. For compatibility with the emulator, it is recommended to perform a dummy access (read or write) to the TAIC2LR and TAOC2LR registers to clear the interrupt flags.

16/164

1

ST72324Jx ST72324Kx

4 FLASH PROGRAM MEMORY

4.1 Introduction

The ST7 dual voltage High Density Flash (HDFlash) is a non-volatile memory that can be electrically erased as a single block or by individual sectors and programmed on a Byte-by-Byte basis using an external VPP supply.

The HDFlash devices can be programmed and erased off-board (plugged in a programming tool) or on-board using ICP (In-Circuit Programming) or IAP (In-Application Programming).

The array matrix organisation allows each sector to be erased and reprogrammed without affecting other sectors.

4.2 Main Features

■Three Flash programming modes:

–Insertion in a programming tool. In this mode, all sectors including option bytes can be programmed or erased.

–ICP (In-Circuit Programming). In this mode, all sectors including option bytes can be programmed or erased without removing the device from the application board.

–IAP (In-Application Programming) In this mode, all sectors except Sector 0, can be programmed or erased without removing the device from the application board and while the application is running.

■ICT (In-Circuit Testing) for downloading and executing user application test patterns in RAM

■Read-out protection

■Register Access Security System (RASS) to prevent accidental programming or erasing

4.3 Structure

The Flash memory is organised in sectors and can be used for both code and data storage.

Figure 6. Memory Map and Sector Address

Depending on the overall Flash memory size in the microcontroller device, there are up to three user sectors (see Table 3). Each of these sectors can be erased independently to avoid unnecessary erasing of the whole Flash memory when only a partial erasing is required.

The first two sectors have a fixed size of 4 Kbytes (see Figure 6). They are mapped in the upper part of the ST7 addressing space so the reset and interrupt vectors are located in Sector 0 (F000hFFFFh).

Table 3. Sectors available in Flash devices

Flash Size (bytes)	Available Sectors
4K	Sector 0
8K	Sectors 0,1
> 8K	Sectors 0,1, 2

4.3.1 Read-out Protection

Read-out protection, when selected, provides a protection against Program Memory content extraction and against write access to Flash memory. Even if no protection can be considered as totally unbreakable, the feature provides a very high level of protection for a general purpose microcontroller.

In flash devices, this protection is removed by reprogramming the option. In this case, the entire program memory is first automatically erased.

Read-out protection selection depends on the device type:

–In Flash devices it is enabled and removed through the FMP_R bit in the option byte.

–In ROM devices it is enabled by mask option specified in the Option List.

4K

8K

10K

16K

24K

32K

48K

60K

FLASH

MEMORY SIZE

1000h

3FFFh

7FFFh

9FFFh

SECTOR 2

BFFFh

D7FFh

52 Kbytes

DFFFh

2 Kbytes

8 Kbytes

16 Kbytes

24 Kbytes

40 Kbytes

EFFFh

4 Kbytes

SECTOR 1

FFFFh

4 Kbytes

SECTOR 0

17/164

1

ST72324Jx ST72324Kx

FLASH PROGRAM MEMORY (Cont’d)

4.4 ICC Interface

ICC needs a minimum of 4 and up to 6 pins to be connected to the programming tool (see Figure 7). These pins are:

–RESET: device reset

–VSS: device power supply ground

–ICCCLK: ICC output serial clock pin

–ICCDATA: ICC input/output serial data pin

–ICCSEL/VPP: programming voltage

–OSC1(or OSCIN): main clock input for external source (optional)

–VDD: application board power supply (optional, see Figure 7, Note 3)

Figure 7. Typical ICC Interface

PROGRAMMING TOOL

ICC CONNECTOR

ICC Cable

APPLICATION BOARD

(See Note 3)

APPLICATION CL2

POWER SUPPLY

		OSC2
V
DD

		OPTIONAL
		IN SOME CASES										9				7			5			3			1
		(See Note 4)
													10			8			6			4			2
										10kΩ
					CL1
OSC1									SS							ICCSEL/VPP			RESET			ICCCLK			ICCDATA
					ST7
								V

ICC CONNECTOR

HE10 CONNECTOR TYPE

APPLICATION

RESET SOURCE

See Note 2

See Note 1

APPLICATION

I/O

Notes:

1.If the ICCCLK or ICCDATA pins are only used as outputs in the application, no signal isolation is necessary. As soon as the Programming Tool is plugged to the board, even if an ICC session is not in progress, the ICCCLK and ICCDATA pins are not available for the application. If they are used as inputs by the application, isolation such as a serial resistor has to implemented in case another device forces the signal. Refer to the Programming Tool documentation for recommended resistor values.

2.During the ICC session, the programming tool must control the RESET pin. This can lead to conflicts between the programming tool and the application reset circuit if it drives more than 5mA at high level (push pull output or pull-up resistor<1K). A schottky diode can be used to isolate the application RESET circuit in this case. When using a classical RC network with R>1K or a reset management IC with open drain output and pull-up re-

sistor>1K, no additional components are needed. In all cases the user must ensure that no external reset is generated by the application during the ICC session.

3.The use of Pin 7 of the ICC connector depends on the Programming Tool architecture. This pin must be connected when using most ST Programming Tools (it is used to monitor the application power supply). Please refer to the Programming Tool manual.

4.Pin 9 has to be connected to the OSC1 or OSCIN pin of the ST7 when the clock is not available in the application or if the selected clock option is not programmed in the option byte. ST7 devices with multi-oscillator capability need to have OSC2 grounded in this case.

18/164

1

ST72324Jx ST72324Kx

FLASH PROGRAM MEMORY (Cont’d)

4.5 ICP (In-Circuit Programming)

To perform ICP the microcontroller must be switched to ICC (In-Circuit Communication) mode by an external controller or programming tool.

Depending on the ICP code downloaded in RAM, Flash memory programming can be fully customized (number of bytes to program, program locations, or selection serial communication interface for downloading).

When using an STMicroelectronics or third-party programming tool that supports ICP and the specific microcontroller device, the user needs only to implement the ICP hardware interface on the application board (see Figure 7). For more details on the pin locations, refer to the device pinout description.

4.6 IAP (In-Application Programming)

This mode uses a BootLoader program previously stored in Sector 0 by the user (in ICP mode or by plugging the device in a programming tool).

This mode is fully controlled by user software. This allows it to be adapted to the user application, (us- er-defined strategy for entering programming mode, choice of communications protocol used to fetch the data to be stored, etc.). For example, it is

possible to download code from the SPI, SCI, USB or CAN interface and program it in the Flash. IAP mode can be used to program any of the Flash sectors except Sector 0, which is write/erase protected to allow recovery in case errors occur during the programming operation.

4.7 Related Documentation

For details on Flash programming and ICC protocol, refer to the ST7 Flash Programming Reference Manual and to the ST7 ICC Protocol Reference Manual.

4.7.1 Register Description

FLASH CONTROL/STATUS REGISTER (FCSR)

Read/Write

Reset Value: 0000 0000 (00h)

7							0
0	0	0	0	0	0	0	0

This register is reserved for use by Programming Tool software. It controls the Flash programming and erasing operations.

Table 4. Flash Control/Status Register Address and Reset Value

	Address	Register	7	6	5	4	3	2	1	0
	(Hex.)	Label
	0029h	FCSR
		Reset Value	0	0	0	0	0	0	0	0

19/164

1

ST72324Jx ST72324Kx

5 CENTRAL PROCESSING UNIT

5.1 INTRODUCTION

This CPU has a full 8-bit architecture and contains six internal registers allowing efficient 8-bit data manipulation.

5.2 MAIN FEATURES

■Enable executing 63 basic instructions

■Fast 8-bit by 8-bit multiply

■17 main addressing modes (with indirect addressing mode)

■Two 8-bit index registers

■16-bit stack pointer

■Low power HALT and WAIT modes

■Priority maskable hardware interrupts

■Non-maskable software/hardware interrupts

5.3 CPU REGISTERS

The 6 CPU registers shown in Figure 8 are not present in the memory mapping and are accessed by specific instructions.

Accumulator (A)

The Accumulator is an 8-bit general purpose register used to hold operands and the results of the arithmetic and logic calculations and to manipulate data.

Index Registers (X and Y)

These 8-bit registers are used to create effective addresses or as temporary storage areas for data manipulation. (The Cross-Assembler generates a precede instruction (PRE) to indicate that the following instruction refers to the Y register.)

The Y register is not affected by the interrupt automatic procedures.

Program Counter (PC)

The program counter is a 16-bit register containing the address of the next instruction to be executed by the CPU. It is made of two 8-bit registers PCL (Program Counter Low which is the LSB) and PCH (Program Counter High which is the MSB).

Figure 8. CPU Registers

											7											0
																									ACCUMULATOR
													RESET VALUE = XXh
											7											0
																									X INDEX REGISTER
												RESET VALUE = XXh
											7											0
																									Y INDEX REGISTER
												RESET VALUE = XXh
					PCH			8				7				PCL						0			PROGRAM COUNTER
	15
	RESET VALUE = RESET VECTOR @ FFFEh-FFFFh
											7											0
													1	1	I1	H		I0	N		Z	C			CONDITION CODE REGISTER
				RESET VALUE = 1										1	1 X			1 X			X	X
		15						8														0			STACK POINTER
											7
RESET VALUE = STACK HIGHER ADDRESS

X = Undefined Value

20/164

1

ST72324Jx ST72324Kx

CENTRAL PROCESSING UNIT (Cont’d)

Condition Code Register (CC)

Read/Write

Reset Value: 111x1xxx

7							0
1	1	I1	H	I0	N	Z	C

The 8-bit Condition Code register contains the interrupt masks and four flags representative of the result of the instruction just executed. This register can also be handled by the PUSH and POP instructions.

These bits can be individually tested and/or controlled by specific instructions.

Arithmetic Management Bits

Bit 4 = H Half carry.

This bit is set by hardware when a carry occurs between bits 3 and 4 of the ALU during an ADD or ADC instructions. It is reset by hardware during the same instructions.

0:No half carry has occurred.

1:A half carry has occurred.

This bit is tested using the JRH or JRNH instruction. The H bit is useful in BCD arithmetic subroutines.

Bit 2 = N Negative.

This bit is set and cleared by hardware. It is representative of the result sign of the last arithmetic, logical or data manipulation. It’s a copy of the result 7th bit.

0:The result of the last operation is positive or null.

1:The result of the last operation is negative

(i.e. the most significant bit is a logic 1).

This bit is accessed by the JRMI and JRPL instructions.

Bit 1 = Z Zero.

This bit is set and cleared by hardware. This bit indicates that the result of the last arithmetic, logical or data manipulation is zero.

0:The result of the last operation is different from zero.

1:The result of the last operation is zero.

This bit is accessed by the JREQ and JRNE test instructions.

Bit 0 = C Carry/borrow.

This bit is set and cleared by hardware and software. It indicates an overflow or an underflow has occurred during the last arithmetic operation.

0:No overflow or underflow has occurred.

1:An overflow or underflow has occurred.

This bit is driven by the SCF and RCF instructions and tested by the JRC and JRNC instructions. It is also affected by the “bit test and branch”, shift and rotate instructions.

Interrupt Management Bits

Bit 5,3 = I1, I0 Interrupt

The combination of the I1 and I0 bits gives the current interrupt software priority.

Interrupt Software Priority		I1	I0
Level 0	(main)	1	0
Level 1		0	1
Level 2		0	0
Level 3	(= interrupt disable)	1	1

These two bits are set/cleared by hardware when entering in interrupt. The loaded value is given by the corresponding bits in the interrupt software priority registers (IxSPR). They can be also set/ cleared by software with the RIM, SIM, IRET, HALT, WFI and PUSH/POP instructions.

See the interrupt management chapter for more details.

21/164

1

ST72324Jx ST72324Kx

CENTRAL PROCESSING UNIT (Cont’d)

Stack Pointer (SP)

Read/Write

Reset Value: 01 FFh

15							8
0	0	0	0	0	0	0	1
7							0
SP7	SP6	SP5	SP4	SP3	SP2	SP1	SP0

The Stack Pointer is a 16-bit register which is always pointing to the next free location in the stack. It is then decremented after data has been pushed onto the stack and incremented before data is popped from the stack (see Figure 9).

Since the stack is 256 bytes deep, the 8 most significant bits are forced by hardware. Following an MCU Reset, or after a Reset Stack Pointer instruction (RSP), the Stack Pointer contains its reset value (the SP7 to SP0 bits are set) which is the stack higher address.

Figure 9. Stack Manipulation Example

The least significant byte of the Stack Pointer (called S) can be directly accessed by a LD instruction.

Note: When the lower limit is exceeded, the Stack Pointer wraps around to the stack upper limit, without indicating the stack overflow. The previously stored information is then overwritten and therefore lost. The stack also wraps in case of an underflow.

The stack is used to save the return address during a subroutine call and the CPU context during an interrupt. The user may also directly manipulate the stack by means of the PUSH and POP instructions. In the case of an interrupt, the PCL is stored at the first location pointed to by the SP. Then the other registers are stored in the next locations as shown in Figure 9.

–When an interrupt is received, the SP is decremented and the context is pushed on the stack.

–On return from interrupt, the SP is incremented and the context is popped from the stack.

A subroutine call occupies two locations and an interrupt five locations in the stack area.

CALL	Interrupt	PUSH Y	POP Y	IRET	RET
Subroutine	Event				or RSP

@ 0100h

SP

SP

SP

Y

CC

CC

CC

A

A

A

X

X

X

SP

PCH

PCH

PCH

SP

PCL

PCL

PCL

PCH

PCH

PCH

PCH

PCH

SP

@ 01FFh PCL

PCL

PCL

PCL

PCL

Stack Higher Address = 01FFh

Stack Lower Address = 0100h

22/164

1

ST72324Jx ST72324Kx

6 SUPPLY, RESET AND CLOCK MANAGEMENT

The device includes a range of utility features for securing the application in critical situations (for example in case of a power brown-out), and reducing the number of external components. An overview is shown in Figure 11.

For more details, refer to dedicated parametric section.

Main features

■Optional PLL for multiplying the frequency by 2 (not to be used with internal RC oscillator in order to respect the max. operating frequency)

■Reset Sequence Manager (RSM)

■Multi-Oscillator Clock Management (MO)

–5 Crystal/Ceramic resonator oscillators

–1 Internal RC oscillator

■System Integrity Management (SI)

–Main supply Low voltage detection (LVD)

–Auxiliary Voltage detector (AVD) with interrupt capability for monitoring the main supply

6.1 PHASE LOCKED LOOP

If the clock frequency input to the PLL is in the range 2 to 4 MHz, the PLL can be used to multiply

the frequency by two to obtain an fOSC2 of 4 to 8 MHz. The PLL is enabled by option byte. If the PLL

is disabled, then fOSC2 = fOSC/2.

Caution: The PLL is not recommended for applications where timing accuracy is required.

Caution: The PLL must not be used with the internal RC oscillator.

Figure 10. PLL Block Diagram

fOSC			PLL x 2		0			fOSC2
			/ 2		1

PLL OPTION BIT

Figure 11. Clock, Reset and Supply Block Diagram

OSC2	MULTI-	f							f	MAIN CLOCK	fCPU
		OSC							OSC2	CONTROLLER
	OSCILLATOR		PLL
										WITH REALTIME
OSC1			(option)
	(MO)									CLOCK (MCC/RTC)
			SYSTEM INTEGRITY MANAGEMENT
	RESET SEQUENCE				AVD Interrupt Request					WATCHDOG
RESET	MANAGER		SICSR							TIMER (WDG)
	(RSM)		0	AVD AVD LVD 0			0	0	WDG
				IE	F	RF			RF
						LOW VOLTAGE
VSS						DETECTOR
VDD						(LVD)
					AUXILIARY VOLTAGE
						DETECTOR
						(AVD)

23/164

1

ST72324Jx ST72324Kx

6.2 MULTI-OSCILLATOR (MO)

The main clock of the ST7 can be generated by three different source types coming from the multioscillator block:

■an external source

■4 crystal or ceramic resonator oscillators

■an internal high frequency RC oscillator

Each oscillator is optimized for a given frequency range in terms of consumption and is selectable through the option byte. The associated hardware configurations are shown in Table 5. Refer to the electrical characteristics section for more details.

Caution: The OSC1 and/or OSC2 pins must not be left unconnected. For the purposes of Failure Mode and Effect Analysis, it should be noted that if the OSC1 and/or OSC2 pins are left unconnected, the ST7 main oscillator may start and, in this configuration, could generate an fOSC clock frequency in excess of the allowed maximum (>16MHz.), putting the ST7 in an unsafe/undefined state. The product behaviour must therefore be considered undefined when the OSC pins are left unconnected.

External Clock Source

In this external clock mode, a clock signal (square, sinus or triangle) with ~50% duty cycle has to drive the OSC1 pin while the OSC2 pin is tied to ground.

Crystal/Ceramic Oscillators

This family of oscillators has the advantage of producing a very accurate rate on the main clock of the ST7. The selection within a list of 4 oscillators with different frequency ranges has to be done by option byte in order to reduce consumption (refer to Section 14.1 on page 150 for more details on the frequency ranges). In this mode of the multioscillator, the resonator and the load capacitors have to be placed as close as possible to the oscillator pins in order to minimize output distortion and start-up stabilization time. The loading capacitance values must be adjusted according to the selected oscillator.

These oscillators are not stopped during the RESET phase to avoid losing time in the oscillator start-up phase.

Internal RC Oscillator

This oscillator allows a low cost solution for the main clock of the ST7 using only an internal resistor and capacitor. Internal RC oscillator mode has the drawback of a lower frequency accuracy and should not be used in applications that require accurate timing.

In this mode, the two oscillator pins have to be tied to ground.

In order not to exceed the max. operating frequency, the internal RC oscillator must not be used with the PLL.

Table 5. ST7 Clock Sources

	Hardware Configuration
External Clock	ST7
	OSC1	OSC2
	EXTERNAL
	SOURCE
Resonators	ST7
	OSC1	OSC2
Crystal/Ceramic	CL1	CL2
	LOAD
	CAPACITORS
Internal RC Oscillator	ST7
	OSC1	OSC2

24/164

1

ST72324Jx ST72324Kx

6.3 RESET SEQUENCE MANAGER (RSM)

6.3.1 Introduction

The reset sequence manager includes three RESET sources as shown in Figure 13:

■External RESET source pulse

■Internal LVD RESET (Low Voltage Detection)

■Internal WATCHDOG RESET

These sources act on the RESET pin and it is always kept low during the delay phase.

The RESET service routine vector is fixed at addresses FFFEh-FFFFh in the ST7 memory map.

The basic RESET sequence consists of 3 phases as shown in Figure 12:

■Active Phase depending on the RESET source

■256 or 4096 CPU clock cycle delay (selected by option byte)

■RESET vector fetch

The 256 or 4096 CPU clock cycle delay allows the oscillator to stabilise and ensures that recovery has taken place from the Reset state. The shorter or longer clock cycle delay should be selected by option byte to correspond to the stabilization time of the external oscillator used in the application.

Figure 13. Reset Block Diagram

The RESET vector fetch phase duration is 2 clock cycles.

Figure 12. RESET Sequence Phases

RESET

	Active Phase	INTERNAL RESET	FETCH
		256 or 4096 CLOCK CYCLES	VECTOR

6.3.2 Asynchronous External RESET pin

The RESET pin is both an input and an open-drain output with integrated RON weak pull-up resistor. This pull-up has no fixed value but varies in accordance with the input voltage. It can be pulled low by external circuitry to reset the device. See Electrical Characteristic section for more details.

A RESET signal originating from an external

source must have a duration of at least th(RSTL)in in order to be recognized (see Figure 14). This de-

tection is asynchronous and therefore the MCU can enter reset state even in HALT mode.

VDD

RON

Filter

INTERNAL

RESET

RESET

PULSE

WATCHDOG RESET

GENERATOR

LVD RESET

25/164

1

ST72324Jx ST72324Kx

RESET SEQUENCE MANAGER (Cont’d)

The RESET pin is an asynchronous signal which plays a major role in EMS performance. In a noisy environment, it is recommended to follow the guidelines mentioned in the electrical characteristics section.

6.3.3 External Power-On RESET

If the LVD is disabled by option byte, to start up the microcontroller correctly, the user must ensure by means of an external reset circuit that the reset signal is held low until VDD is over the minimum level specified for the selected fOSC frequency.

A proper reset signal for a slow rising VDD supply can generally be provided by an external RC network connected to the RESET pin.

6.3.4 Internal Low Voltage Detector (LVD)

RESET

Two different RESET sequences caused by the internal LVD circuitry can be distinguished:

■Power-On RESET

■Voltage Drop RESET

The device RESET pin acts as an output that is pulled low when VDD<VIT+ (rising edge) or VDD<VIT- (falling edge) as shown in Figure 14.

The LVD filters spikes on VDD larger than tg(VDD) to avoid parasitic resets.

6.3.5 Internal Watchdog RESET

The RESET sequence generated by a internal Watchdog counter overflow is shown in Figure 14.

Starting from the Watchdog counter underflow, the device RESET pin acts as an output that is pulled low during at least tw(RSTL)out.

Figure 14. RESET Sequences

VDD

VIT+(LVD)

VIT-(LVD)

LVD

RESET

RUN	RUN
	ACTIVE PHASE

EXTERNAL	WATCHDOG
RESET	RESET
RUN	RUN
ACTIVE	ACTIVE
PHASE	PHASE

th(RSTL)in							tw(RSTL)out

EXTERNAL

RESET

SOURCE

RESET PIN

WATCHDOG

RESET

WATCHDOG UNDERFLOW

INTERNAL RESET (256 or 4096 TCPU)

VECTOR FETCH

26/164

1

ST72324Jx ST72324Kx

6.4 SYSTEM INTEGRITY MANAGEMENT (SI)

The System Integrity Management block contains the Low Voltage Detector (LVD) and Auxiliary Voltage Detector (AVD) functions. It is managed by the SICSR register.

6.4.1 Low Voltage Detector (LVD)

The Low Voltage Detector function (LVD) generates a static reset when the VDD supply voltage is below a VIT- reference value. This means that it secures the power-up as well as the power-down keeping the ST7 in reset.

The VIT- reference value for a voltage drop is lower than the VIT+ reference value for power-on in order to avoid a parasitic reset when the MCU starts running and sinks current on the supply (hysteresis).

The LVD Reset circuitry generates a reset when VDD is below:

–VIT+ when VDD is rising

–VIT- when VDD is falling

The LVD function is illustrated in Figure 15.

The voltage threshold can be configured by option byte to be low, medium or high.

Provided the minimum VDD value (guaranteed for the oscillator frequency) is above VIT-, the MCU can only be in two modes:

Figure 15. Low Voltage Detector vs Reset

–under full software control

–in static safe reset

In these conditions, secure operation is always ensured for the application without the need for external reset hardware.

During a Low Voltage Detector Reset, the RESET pin is held low, thus permitting the MCU to reset other devices.

Notes:

The LVD allows the device to be used without any external RESET circuitry.

If the medium or low thresholds are selected, the detection may occur outside the specified operating voltage range. Below 3.8V, device operation is not guaranteed.

The LVD is an optional function which can be selected by option byte.

It is recommended to make sure that the VDD supply voltage rises monotonously when the device is exiting from Reset, to ensure the application functions properly.

VDD

Vhys

VIT+

VIT-

RESET

27/164

1

ST72324Jx ST72324Kx

SYSTEM INTEGRITY MANAGEMENT (Cont’d)

6.4.2 Auxiliary Voltage Detector (AVD)

The Voltage Detector function (AVD) is based on an analog comparison between a VIT-(AVD) and

VIT+(AVD) reference value and the VDD main supply. The VIT- reference value for falling voltage is

lower than the VIT+ reference value for rising voltage in order to avoid parasitic detection (hysteresis).

The output of the AVD comparator is directly readable by the application software through a real time status bit (AVDF) in the SICSR register. This bit is read only.

Caution: The AVD function is active only if the LVD is enabled through the option byte (see Section 14.1 on page 150).

6.4.2.1 Monitoring the VDD Main Supply

The AVD voltage threshold value is relative to the selected LVD threshold configured by option byte (see

If the AVD interrupt is enabled, an interrupt is gen-

erated when the voltage crosses the VIT+(AVD) or VIT-(AVD) threshold (AVDF bit toggles).

Figure 16. Using the AVD to Monitor VDD

In the case of a drop in voltage, the AVD interrupt acts as an early warning, allowing software to shut down safely before the LVD resets the microcontroller. See Figure 16.

The interrupt on the rising edge is used to inform the application that the VDD warning state is over.

If the voltage rise time trv is less than 256 or 4096 CPU cycles (depending on the reset delay selected by option byte), no AVD interrupt will be generated when VIT+(AVD) is reached.

If trv is greater than 256 or 4096 cycles then:

– If the AVD interrupt is enabled before the

VIT+(AVD) threshold is reached, then 2 AVD interrupts will be received: the first when the AVDIE

bit is set, and the second when the threshold is reached.

–If the AVD interrupt is enabled after the VIT+(AVD) threshold is reached then only one AVD interrupt will occur.

VDD			Early Warning Interrupt
			(Power has dropped, MCU not
			not yet in reset)
VIT+(AVD)			Vhyst
VIT-(AVD)
VIT+(LVD)
VIT-(LVD)				trv VOLTAGE RISE TIME
AVDF bit	0	1	RESET VALUE	1	0
AVD INTERRUPT
REQUEST
IF AVDIE bit = 1
			INTERRUPT PROCESS		INTERRUPT PROCESS
LVD RESET
28/164
1

ST72324Jx ST72324Kx

SYSTEM INTEGRITY MANAGEMENT (Cont’d)

6.4.3 Low Power Modes

	Mode	Description
	WAIT	No effect on SI. AVD interrupt causes the
		device to exit from Wait mode.
	HALT	The CRSR register is frozen.

6.4.3.1 Interrupts

The AVD interrupt event generates an interrupt if the AVDIE bit is set and the interrupt mask in the CC register is reset (RIM instruction).

Interrupt Event	Event	Enable	Exit	Exit
	Flag	Control	from	from
		Bit	Wait	Halt
AVD event	AVDF	AVDIE	Yes	No

29/164

1

ST72324Jx ST72324Kx

SYSTEM INTEGRITY MANAGEMENT (Cont’d)

6.4.4 Register Description

SYSTEM INTEGRITY (SI) CONTROL/STATUS REGISTER (SICSR)

Read/Write

Reset Value: 000x 000x (00h)

	7							0
	0	AVD	AVD	LVD	0	0	0	WDG
		IE	F	RF				RF

Bit 7 = Reserved, must be kept cleared.

Bit 6 = AVDIE Voltage Detector interrupt enable

This bit is set and cleared by software. It enables an interrupt to be generated when the AVDF flag changes (toggles). The pending interrupt information is automatically cleared when software enters the AVD interrupt routine.

0:AVD interrupt disabled

1:AVD interrupt enabled

Bits 3:1 = Reserved, must be kept cleared.

Bit 0 = WDGRF Watchdog reset flag

This bit indicates that the last Reset was generated by the Watchdog peripheral. It is set by hardware (watchdog reset) and cleared by software (writing zero) or an LVD Reset (to ensure a stable cleared state of the WDGRF flag when CPU starts).

Combined with the LVDRF flag information, the flag description is given by the following table.

RESET Sources			LVDRF	WDGRF
External	RESET	pin	0	0
Watchdog			0	1
LVD			1	X

Application notes

Bit 5 = AVDF Voltage Detector flag

This read-only bit is set and cleared by hardware. If the AVDIE bit is set, an interrupt request is generated when the AVDF bit changes value. Refer to Figure 16 and to Section 6.4.2.1 for additional details.

0:VDD over VIT+(AVD) threshold

1:VDD under VIT-(AVD) threshold

Bit 4 = LVDRF LVD reset flag

This bit indicates that the last Reset was generated by the LVD block. It is set by hardware (LVD reset) and cleared by software (writing zero). See WDGRF flag description for more details. When the LVD is disabled by OPTION BYTE, the LVDRF bit value is undefined.

The LVDRF flag is not cleared when another RESET type occurs (external or watchdog), the LVDRF flag remains set to keep trace of the original failure.

In this case, a watchdog reset can be detected by software while an external reset can not.

CAUTION: When the LVD is not activated with the associated option byte, the WDGRF flag can not be used in the application.

30/164

1
