Reference Guide
A0DX-9562-11A 1800851-001B
Copyright Notice
The digitally encoded software and publication included with your printer are Copyrighted © 2007 by KONICA MINOLTA BUSINESS TECHNOLOGIES, INC., Marunouchi Center Building, 1-6-1 Marunouchi, Chiyoda-ku, Tokyo, 100-0005, Japan. All Rights Reserved.
This software may not be reproduced, modified, displayed, transferred, or copied in any form or in any manner or on any media, in whole or in part, without the express written permission of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of KONICA MINOLTA. The information contained in this guide is intended for use with the KONICA MINOLTA pagepro 4650EN/5650EN printers only.
About the GPL (General Public License)
This driver is written for Linux, which is written and distributed under the GNU GPL. The printing system CUPS adopted to run on the Linux is published by ESP (Easy Software Products) under the GPL. All source codes that we write must be available to the general public.
Trademarks
KONICA MINOLTA and the KONICA MINOLTA logo are trademarks or registered trademarks of KONICA MINOLTA HOLDINGS, INC.
pagepro and PageScope are trademarks or registered trademarks of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.
All other trademarks and registered trademarks are the property of their respective owners.
Notice
KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. reserves the right to make changes to this guide and to the equipment described herein without notice. Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions. However, KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. makes no warranty of any kind including, but not limited to, any implied warranties of merchantability and fitness for a particular purpose with regard to this manual.
KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. assumes no responsibility for, or liability for, errors contained in this manual or for incidental, special, or consequential damages arising out of the furnishing of this manual, or the use of this manual in operating the equipment, or in connection with the performance of the equipment when so operated.
SOFTWARE LICENSE AGREEMENT
This package contains the following materials provided by Konica Minolta Business Technologies, Inc. (KMBT): software included as part of the printing system, the digitally-encoded machine-readable outline data encoded in the special format and in the encrypted form (“Font Programs”), other software which runs on a computer system for use in conjunction with the Printing Software (“Host Software”), and related explanatory written materials (“Documentation”). The term “Software” shall be used to describe Printing Software, Font Programs and/or Host Software and also include any upgrades, modified versions, additions, and copies of the Software.
The Software is being licensed to you under the terms of this Agreement.
KMBT grants to you a non-exclusive sublicense to use the Software and Documentation, provided that you agree to the following:
1.You may use the Printing Software and accompanying Font Programs for imaging to the licensed output device(s), solely for your own internal business purposes.
2.In addition to the license for Font Programs set forth in Section 1 (“Printing Software”) above, you may use Roman Font Programs to reproduce weights, styles, and versions of letters, numerals, characters and symbols (“Typefaces”) on the display or monitor for your own internal business purposes.
3.You may make one backup copy of the Host Software, provided your backup copy is not installed or used on any computer. Notwithstanding the above restrictions, you may install the Host Software on any number of computers solely for use with one or more printing systems running the Printing Software.
4.You may assign its rights under this Agreement to an assignee of all of Licensee’s right and interest to such Software and Documentation (“Assignee”) provided you transfer to Assignee all copies of such Software and Documentation Assignee agrees to be bound by all of the terms and conditions of this Agreement.
5.You agree not to modify, adapt or translate the Software and Documentation.
6.You agree that you will not attempt to alter, disassemble, decrypt, reverse engineer or decompile the Software.
7.Title to and ownership of the Software and Documentation and any reproductions thereof shall remain with KMBT.
8.Trademarks shall be used in accordance with accepted trademark practice, including identification of the trademark owner’s name. Trademarks can only be used to identify printed output produced by the Software. Such use of any trademark does not give you any rights of ownership in that trademark.
9.You may not rent, lease, sublicense, lend or transfer versions or copies of the Software that the Licensee does not use, or Software contained on any unused media, except as part of the permanent transfer of all Software and Documentation as described above.
10.In no event will KMBT or its licensor be liable to you for any consequential, incidental INDIRECT, PUNITIVE or special damages, including any lost profits or lost saving, even if KMBT has been advised of the possibility of such damages, or for any claim by any third party. KMBT or its licensor disclaims all warranties with regard to the software, express or implied, including, without limitation implied warranties of merchantability, fitness for a particular purpose, title and non-infringement of third party rights. Some states or jurisdictions do not allow the exclusion or limitation of incidental, consequential or special damages, so the above limitations may not apply to you.
11.Notice to Government End Users: The Software is a “commercial item,” as that term is defined at 48 C.F.R.2.101, consisting of “commercial computer software” and “commercial computer software documentation,” as such terms are used in 48 C.F.R. 12.212. Consistent with 48 C.F.R. 12.212 and 48 C.F.R. 227.7202-1 through 227.7202-4, all U.S. Government End Users acquire the Software with only those rights set forth herein.
12.You agree that you will not export the Software in any form in violation of any applicable laws and regulations regarding export control of any countries.
OpenSSL Statement
OpenSSL License
Copyright (c) 1998-2003 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
1.Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
2.Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
3.All advertising materials mentioning features or use of this software must display the following acknowledgment:
“This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)”
4.The names “OpenSSL Toolkit” and “OpenSSL Project” must not be used to endorse or promote products derived from this software without prior written permission. For written permission, please contact openssl-core@openssl.org.
5.Products derived from this software may not be called “OpenSSL” nor may “OpenSSL” appear in their names without prior written permission of the OpenSSL Project.
6.Redistributions of any form whatsoever must retain the following acknowledgment:
“This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/)”
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com).
Original SSLeay License
Copyright (c) 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved.
This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL.
This library is free for commercial and non-commercial use as long as the following conditions are aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code.
The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com).
Copyright remains Eric Young’s, and as such any Copyright notices in the code are not to be removed. If this package is used in a product, Eric Young should be given attribution as the author of the parts of the library used. This can be in the form of a textual message at program startup or in documentation (online or textual) provided with the package.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
1.Redistributions of source code must retain the copyright notice, this list of conditions and the following disclaimer.
2.Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
3.All advertising materials mentioning features or use of this software must display the following acknowledgement:
“This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)”
The word ‘cryptographic’ can be left out if the rouines from the library being used are not cryptographic related.
4.If you include any Windows specific code (or a derivative thereof) from the apps directory (application code) you must include an acknowledgement:
“This product includes software written by Tim Hudson (tjh@cryptsoft.com)”
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
The licence and distribution terms for any publically available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and put under another distribution licence [including the GNU Public Licence.]
NetSNMP License
Part 1: CMU/UCD copyright notice: (BSD like)
Copyright 1989, 1991, 1992 by Carnegie Mellon University Derivative Work - 1996, 1998-2000 Copyright 1996, 1998-2000 The Regents of the University of California All Rights Reserved Permission to use, copy, modify and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appears in all copies and that both that copyright notice and this permission notice appear in supporting documentation, and that the name of CMU and The Regents of the University of California not be used in advertising or publicity pertaining to distribution of the software without specific written permission.
CMU AND THE REGENTS OF THE UNIVERSITY OF CALIFORNIA DISCLAIM ALL WARRANTIES WITH REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS. IN NO EVENT SHALL CMU OR THE REGENTS OF THE UNIVERSITY OF CALIFORNIA BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM THE LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
Part 2: Networks Associates Technology, Inc copyright notice (BSD)
Copyright (c) 2001-2003, Networks Associates Technology, Inc All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of the Networks Associates Technology, Inc nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;
OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Part 3: Cambridge Broadband Ltd. copyright notice (BSD)
Portions of this code are copyright (c) 2001-2003, Cambridge Broadband Ltd. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
The name of Cambridge Broadband Ltd. may not be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDER “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Part 4: Sun Microsystems, Inc. copyright notice (BSD)
Copyright (c) 2003 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara, California 95054, U.S.A. All rights reserved.
Use is subject to license terms below.
This distribution may include materials developed by third parties.
Sun, Sun Microsystems, the Sun logo and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of the Sun Microsystems, Inc. nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;
OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Part 5: Sparta, Inc copyright notice (BSD)
Copyright (c) 2003-2004, Sparta, Inc All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of Sparta, Inc nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;
OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Part 6: Cisco/BUPTNIC copyright notice (BSD)
Copyright (c) 2004, Cisco, Inc and Information Network Center of Beijing University of Posts and Telecommunications. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of Cisco, Inc, Beijing University of Posts and Telecommunications, nor the names of their contributors may be used to endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;
OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
1 Operation on Mac OS X .................................................................................... |
|
|
|
1 |
System Requirements for the Printer Driver |
2 |
|||
Installing the Printer Driver |
3 |
|
|
|
Installing the Printer Driver |
3 |
|
|
|
Uninstalling the printer driver 9 |
|
|
|
|
For Mac OS X 10.2 9 |
|
|
|
|
For Mac OS X 10.3/10.4 |
9 |
|
|
|
For Mac OS X 10.5/10.6 |
10 |
|
|
|
Print Center Settings (Mac OS X 10.2.8) 11 |
|
|||
When Using a USB Connection |
11 |
|
|
|
When Using a Network Connection |
13 |
|
||
AppleTalk Setting 13 |
|
|
|
|
Rendezvous Setting 15 |
|
|
|
|
IP Printing Setting 18 |
|
|
|
|
IPP Setting 20 |
|
|
|
|
Specifying Port 9100 23 |
|
|
|
|
Printer Setup Utility Settings (Mac OS X 10.3) |
27 |
|||
When Using a USB Connection |
27 |
|
|
|
When Using a Network Connection |
29 |
|
||
AppleTalk Setting 29 |
|
|
|
|
Contents |
i |
Rendezvous Setting 31 |
|
|
|
|||||
IP Printing Setting 32 |
|
|
|
|
||||
Printer Setup Utility Settings (Mac OS X 10.4) |
36 |
|||||||
When Using a USB Connection |
36 |
|
|
|||||
When Using a Network Connection |
38 |
|
||||||
Bonjour Setting 38 |
|
|
|
|
||||
AppleTalk Setting 41 |
|
|
|
|
||||
IP Printing Setting 43 |
|
|
|
|
||||
Printer Settings (Mac OS X 10.5/10.6) |
47 |
|
||||||
When Using a USB Connection |
47 |
|
|
|||||
When Using a Network Connection |
51 |
|
||||||
Bonjour Setting 51 |
|
|
|
|
||||
AppleTalk Setting 55 |
|
|
|
|
||||
IP Printing Setting 58 |
|
|
|
|
||||
Selecting Print Options 62 |
|
|
|
|
||||
For Mac OS X 10.2/10.3/10.4 |
62 |
|
|
|||||
For Mac OS X 10.5/10.6 |
64 |
|
|
|
||||
Specifying Page Setup Settings |
66 |
|
|
|||||
Page Attributes Options |
67 |
|
|
|
||||
Custom Paper Size Options 68 |
|
|
||||||
Specifying Print Settings (Mac OS X 10.4) 69 |
|
|||||||
Print Dialog Box |
|
70 |
|
|
|
|
||
Common buttons |
71 |
|
|
|
|
|||
Copies & Pages |
|
72 |
|
|
|
|
||
Layout |
73 |
|
|
|
|
|
|
|
Scheduler |
74 |
|
|
|
|
|
|
|
Paper Handling |
|
75 |
|
|
|
|
||
ColorSync |
76 |
|
|
|
|
|
|
|
Cover Page |
76 |
|
|
|
|
|
||
Error Handling |
77 |
|
|
|
|
|||
Paper Feed |
78 |
|
|
|
|
|
||
Color Options |
79 |
|
|
|
|
|||
Printer Features |
|
80 |
|
|
|
|
||
Supply Levels |
81 |
|
|
|
|
|||
Summary |
82 |
|
|
|
|
|
|
|
Specifying Print Settings (Mac OS X 10.5/10.6) |
83 |
|||||||
Print Dialog Box |
|
83 |
|
|
|
|
||
Common buttons |
84 |
|
|
|
|
|||
Layout |
85 |
|
|
|
|
|
|
|
Color Matching |
|
87 |
|
|
|
|
||
Paper Handling |
|
88 |
|
|
|
|
||
Paper Feed |
89 |
|
|
|
|
|
||
Cover Page |
90 |
|
|
|
|
|
||
Scheduler |
91 |
|
|
|
|
|
|
|
Color Options |
92 |
|
|
|
|
|||
Printer Features |
|
93 |
|
|
|
|
ii |
Contents |
Supply Levels |
94 |
|
|
|
|
Summary 95 |
|
|
|
|
|
Troubleshooting |
96 |
|
|
|
|
2 Operation on the XPS Driver for Windows ................................................... |
99 |
||||
Installing the Printer Driver 100 |
|
|
|||
Selecting Print Options/Defaults |
107 |
|
|||
Uninstalling the Printer Driver |
110 |
|
|||
Specifying Print Driver Settings |
111 |
|
|||
Common buttons |
111 |
|
|
|
|
Layout 111 |
|
|
|
|
|
Advanced Options |
112 |
|
|
|
|
Paper/Quality |
113 |
|
|
|
|
3 Operation on Linux ....................................................................................... |
|
|
|
115 |
|
System Requirements for the Printer Driver |
116 |
||||
Installing PPD File From the Command Line |
117 |
||||
Adding the Printer |
118 |
|
|
|
|
Specifying Printer Driver Settings 121 |
|
||||
Displaying the Settings Page |
|
121 |
|
||
Printer Driver Settings 122 |
|
|
|
||
Extra 122 |
|
|
|
|
|
General 122 |
|
|
|
|
|
Graphics Options 123 |
|
|
|
||
Image Options 123 |
|
|
|
||
Options Installed 124 |
|
|
|
||
Text Options 124 |
|
|
|
||
Banners 124 |
|
|
|
|
|
Printing a Document |
126 |
|
|
|
|
Example Using LPR Command |
126 |
|
|||
Example Using OpenOffice |
127 |
|
|||
Checking Print Jobs |
131 |
|
|
|
|
Troubleshooting |
132 |
|
|
|
4 Operation on NetWare .................................................................................. |
|
133 |
Printing With NetWare 134 |
|
|
Network Printing in a NetWare Environment |
134 |
|
For Remote Printer Mode With NetWare 4.x Bindery Emulation 134 |
||
For Print Server Mode With NetWare 4.x Bindery Emulation |
136 |
|
For NetWare 4.x Remote Printer Mode (NDS) |
137 |
|
For NetWare 4.x/5.x/6 Print Server Mode (NDS) 139 |
|
|
For NetWare 5.x/6 Novell Distributed Print Service (NDPS) |
140 |
Setting Up a Client (Windows) Settings When Using the NetWare Server 141
Contents |
iii |
5 |
Printer Utilities ............................................................................................... |
143 |
|
Installing Printer Utilities on Windows 144 |
|
6 Understanding the Ethernet Configuration Menus .................................... |
145 |
|
|
Ethernet Menu 146 |
|
|
Location within the Configuration Menu 146 |
|
|
Accessing the Ethernet Menu 149 |
|
|
Using the Network Menu Options 151 |
|
|
TCP/IP 151 |
|
|
HTTP 153 |
|
|
FTP 153 |
|
|
BONJOUR 154 |
|
|
DYNAMIC DNS 154 |
|
|
IPP 154 |
|
|
RAW PORT 155 |
|
|
SLP 155 |
|
|
SMTP 156 |
|
|
SNMP 156 |
|
|
WSD PRINT 156 |
|
|
IPSEC 157 |
|
|
IP ADDRESS FILTER 157 |
|
|
IPv6 158 |
|
|
NETWARE 159 |
|
|
APPLETALK 159 |
|
|
SPEED/DUPLEX 159 |
|
|
IEEE802.1X 160 |
|
7 |
Network Printing ............................................................................................ |
161 |
|
Network Connection 162 |
|
|
Theory 162 |
|
|
Making the Connection 163 |
|
|
Ethernet Interface 163 |
|
|
Using DHCP 163 |
|
|
Setting the IP Address Manually 165 |
|
|
Network Printing 169 |
|
|
AppleTalk 169 |
|
|
Bonjour 169 |
|
|
BOOTP 169 |
|
|
DDNS (Dynamic DNS) 170 |
|
|
DHCP 170 |
|
|
FTP 170 |
|
|
HTTP 170 |
|
|
IEEE802.1x 170 |
|
|
IPP 171 |
|
|
IPsec 171 |
|
|
IPv6 171 |
|
iv |
Contents |
IPX/SPX 171
LPD/LPR 171 SLP 172 SMTP 172 SNMP 172 Port 9100 173 WSD print 173
Printing via IPP (Internet Printing Protocol) 174 With Windows Server 2008/Server 2008 R2 174
Adding an IPP Port using the Printer Driver CD-ROM 174 Adding an IPP Port using Add Printer Wizard -
Windows Server 2003/XP/2000 177
Adding an IPP Port using Add Printer Wizard - Windows Vista/7/Server 2008/Server 2008 R2 178
Printing via Web Service Print Function 181
With Windows Server 2008/Server 2008 R2 181
Making the printer driver known from the Network window 181 Adding a printer from the Network window 183
Adding a printer using Add Printer Wizard 186 Updating the driver after connecting this machine 191
If the bit number differs between the server operating system and client
operating system |
193 |
|
|
||
Installing the Additional Driver |
193 |
||||
Troubleshooting |
197 |
|
|
||
8 Using PageScope Web Connection |
............................................................ 199 |
||||
About PageScope Web Connection |
200 |
||||
Display Language |
200 |
|
|
||
Requirements |
200 |
|
|
||
When connecting with Windows Server 2008/Server 2008 R2 201 |
|||||
Setting Up the Printer Web Page |
202 |
||||
Determining the Printer Name |
202 |
||||
Setting Up Your Browser Software |
202 |
||||
Internet Explorer (version 6.0 for Windows) 203 |
|||||
Netscape Navigator (version 7.1) 204 |
|||||
Understanding the PageScope Web Connection Window 205 |
|||||
Navigation |
205 |
|
|
|
|
Current Status |
206 |
|
|
||
Logging on to PageScope Web Connection 207 |
|||||
Login Page |
207 |
|
|
|
|
Language Setting |
208 |
|
|
||
Public User Mode |
208 |
|
|
||
Registered User Mode 208 |
|
|
|||
User Authentication Mode 208 |
|
||||
Account Track Mode 209 |
|
|
|||
Administrator Mode |
209 |
|
|
Contents |
v |
Viewing Printer Status 211
System Page 211
Device Information 212
Counter 221
Online Assistance 222
User Authentication 223
Job Page 225
Active Job List (shown above) 225
Done Job List 226
Done Job List (Detail) 227
Print Page 228
Default Settings 228
Tray Mapping Settings 232
Font/Form 238
Report Types 241
Direct Print 242
Configuring the Printer 243
System Page 243
Device Information 244
Counter 253
Online Assistance 254
Import/Export 256
Authentication 258
Date/Time 265
Admin Password 269
Machine Settings 271
ROM Version 274
Maintenance 275
Status Notification Settings 278
Job Page 281
Active Job List (shown above) 281
Done Job List 282
Done Job List (Detail) 283
Print Page 284
Local Interface 284
Default Settings 285
Download Font/Form 305
Network Page 308
TCP/IP 308
IPsec (General Settings) 322
IPsec (IKE Settings) 324
IPsec (IPsec SA Settings) 325
IPsec (IPsec Peer Settings) 327
Bonjour 328
WSD 330
NetWare 332
vi |
Contents |
FTP 340
SNMP 341 AppleTalk 345 Email 346 SSL/TLS 348
SSL/TLS Information 348
SSL/TLS Setting (When a certificate is not installed) 349 SSL/TLS Setting (When a certificate is installed) 350 Self-signed Certificate Setting 351
Request a certificate 353 Certificate Request 355 Install a Certificate 356
Encryption Strength Setting 357 Remove a Certificate 358 Mode Using SSL/TLS 359 Authentication 360
CA Certificate 366 Remove a Certificate 370
Contents |
vii |
viii |
Contents |
Operation on Mac OS X
Before installing the printer driver, make sure that your system meets the following system requirements.
Computer |
Apple Macintosh computer installed with the |
|
following processor: |
|
– PowerPC G3 or later processor (Pow- |
|
erPC G4 or later is recommended) |
|
– Intel Core Duo or later processor |
|
|
Connecting the computer |
USB connection (USB 2.0 (High-Speed)), |
and printer |
network connection (10Base-T/100Base-TX/ |
|
1000Base-T) |
|
|
Operating system |
Mac OS X and X Server 10.2.8/10.3/10.4/ |
|
10.5/10.6 (We recommend installing the new- |
|
est patch.) |
|
|
RAM |
More than OS recommendation (128 MB or |
|
more is recommended) |
|
|
Available disk space |
256 MB or more (for storing images) |
|
|
" pagepro 4650EN does not support Mac OS X 10.6.
2 |
System Requirements for the Printer Driver |
" This manual provides descriptions using dialog boxes for pagepro 5650EN. Since the dialog boxes appear the same for pagepro 4650EN, the dialog boxes for pagepro 5650EN are used in the following descriptions.
" You must have administrator privileges in order to install the printer driver.
" Before proceeding with the installation, be sure to exit all running applications.
" The procedure for installing the printer driver on Mac OS X 10.4 is described below. The following procedure or some steps may be different depending on the version of the operating system being used. Complete the installation according to the instructions in the dialog boxes that appear.
1 Insert the Printer Driver CD-ROM in the CD/DVD-ROM drive of your Macintosh.
" For pagepro 5650EN, the printer driver for Mac OS X 10.6 is included in the Printer Driver CD-ROM (For Windows 7/Windows Server 2008 R2/Mac OS X 10.6).
" The printer driver for Mac OS X 10.5 can be downloaded from the KONICA MINOLTA web site.
2 Double-click the CD icon on the desktop, and then double-click the pp4650 OSX Installer_103104.pkg.
The installer for the printer driver starts up.
" For OS X 10.5/10.6, the driver folder varies depending on the paper size. Select the appropriate driver folder for your environment.
–To use inch-based paper size (8 1/2 x 11 in letter size): Select english folder.
–To use metric-based paper size (A4 and the like): Select a file in other folder.
" When using Mac OS X 10.2, double-click the pp4650 OSX Installer_102.pkg.
Installing the Printer Driver |
3 |
"
"
When using Mac OS X 10.3, double-click the pp4650 OSX Installer_103104.pkg.
When using Mac OS X 10.5, double-click the pp4650 OSX Installer_105.pkg.
" When using Mac OS X 10.6, double-click the pp4650 OSX Installer_106.pkg.
3 Click Continue.
4 Click Continue.
4 |
Installing the Printer Driver |
5
6
Click Continue.
Check the details of the license agreement, and then click Continue.
Installing the Printer Driver |
5 |
7 Click Agree in the confirmation dialog box if you agree to the terms of the license.
8 In the Select a Destination page, select the disk in which you wish to install the software, and then click Continue.
6 |
Installing the Printer Driver |
9 Click Install in the Easy Install page.
Installation starts.
10 Enter the administrator user name and password in the Authenticate dialog box, and then click OK.
Installing the Printer Driver |
7 |
11 After the installation has been completed, click Close.
This completes the installation of the printer driver.
8 |
Installing the Printer Driver |
If it becomes necessary to delete the printer driver, for example, when you want to reinstall it, delete the driver according to the following procedure.
For Mac OS X 10.2
1 Open Print Center, which is located in Applications - Utilities on the hard disk.
2 Select the name of the printer to be deleted, and then click Delete. The selected printer is deleted.
3 Close the Printer List.
4 Drag the following file, which is located in Library - Printers - PPDs -
Contents - Resources - en.lproj on the hard disk, to the Trash icon.
– KONICA MINOLTA pagepro5650(4650).gz
5 Delete the unnecessary files from Library - Printers.
–Drag the KONICA MINOLTA pp4650 Color.plugin file, which is located in Library - Printers - PPD Plugins, to the Trash icon.
6 Drag the pp4650 OSX Installer_102.pkg file, which is located in the
Library - Receipts, to the Trash icon.
7 Restart the computer.
This completes uninstallation of the printer driver.
For Mac OS X 10.3/10.4
1 Open Printer Setup Utility, which is located in Applications - Utilities on the hard disk.
2 Select the name of the printer to be deleted, and then click Delete. The selected printer is deleted.
3 Close the Printer List.
4 Drag the following file, which is located in Library - Printers - PPDs -
Contents - Resources - en.lproj on the hard disk, to the Trash icon.
– KONICA MINOLTA pagepro5650(4650).gz
5 Delete the unnecessary files from Library - Printers.
–Drag the KONICA MINOLTA pp4650 Color.plugin file, which is located in Library - Printers - KONICAMINOLTA - PDEs, to the Trash icon.
–Drag the KONICA MINOLTA pp4650.icns file, which is located in
Library - Printers - KONICAMINOLTA - Icons, to the Trash icon.
Uninstalling the printer driver |
9 |
6 Drag the pp4650 OSX Installer_103104.pkg file, which is located in the
Library - Receipts, to the Trash icon.
7 Restart the computer.
This completes uninstallation of the printer driver.
For Mac OS X 10.5/10.6
1 On the Apple menu, select System Preferences.
2 Click Print & Fax.
3 Select the name of the printer to be deleted, and then click the delete button (-) on the left below the list.
4 When the confirmation message appears, click OK. The selected printer is deleted.
5 Click the close button (x) in the upper-left corner of Print & Fax.
–The following procedure is not necessary; it is only for users who would like to delete unnecessary files.
6 Drag the KONICA MINOLTA pagepro5650(4650).gz file, which is located in Library - Printers - PPDs - Contents - Resources on the hard disk, to the Trash icon.
7 Drag the pp4650 folder, which is located in Library - Printers - KONICAMINOLTA, to the Trash icon.
8 Drag the following files, which is located in the Library - Receipts, to the
Trash icon.
–pp4650 OSX Installer_105.pkg (for Mac OS X 10.5)
–pp4650 OSX Installer_106.pkg (for Mac OS X 10.6)
9 Restart the computer.
This completes uninstallation of the printer driver.
10 |
Uninstalling the printer driver |
1 Use a USB cable to connect the printer to your computer.
2 Check that the printer is turned on, and then restart the computer.
3 Open Print Center, which can be accessed by clicking Startup Disk, then
Applications, then Utilities. 4 In the Printer List, click Add.
5 Select USB from the pop-up menu.
Print Center Settings (Mac OS X 10.2.8) |
11 |
6 Select pagepro 5650(4650) in the Product list.
" If pagepro 5650(4650) does not appear, check that the printer is turned on and the USB cable is connected, and then restart the computer.
7 Select KONICA MINOLTA from the Printer Model pop-up menu.
8 Select KONICA MINOLTA pp5650(4650) PPD in the Model Name list.
12 |
Print Center Settings (Mac OS X 10.2.8) |
