ASUS P5M2P-E4L, P5M2-E4L, P5M2-E User Manual

Teaming Function for Marvell

User’s Guide

Contents

Chapter 1 Marvell Network Control			..........................................................................1
1.1	Overview ......................................................................................................		1
1.2	Installation ....................................................................................................		1
1.3	Tabs Introduction..........................................................................................		2
	1.3.1	Adapter...............................................................................................	2
	1.3.2	Virtual LAN .......................................................................................	2
	1.3.3	Team...................................................................................................	2
	1.3.4	RLMT ................................................................................................	3
	1.3.5	Protocol..............................................................................................	3
	1.3.6	Power Management ...........................................................................	3
	1.3.7	Statistics .............................................................................................	4
	1.3.8	Specifications.....................................................................................	5
	1.3.9	Support...............................................................................................	6
Chapter 2	Teaming Configuration .............................................................................		7
2.1	Add Team .....................................................................................................		7
2.2	Remove Team...............................................................................................		9
Reference .....................................................................................................................			10
Trademark Acknowledgement .....................................................................................			10

Chapter 1 Marvell Network Control

1.1 Overview

Marvell Network Control enables you to configure all Yukon® Ethernet Controllers in your system. The various tabs contain trees showing the installed controllers and their configuration.

1.2 Installation

Install Marvell CPA:

Then Marvell Network Control will be displayed in Control Panel:

1

1.3 Tabs Introduction

1.3.1 Adapter

The tab Adapter displays the network controllers available in your system with their corresponding ports. It shows the ports which have been configured as VLANs, for RLMT (Redundant Link Management Technology), and the ones which have been aggregated into a team.

1.3.2 Virtual LAN

The tab Virtual LAN displays all configured Virtual LANs and the corresponding ports.

1.3.3 Team

The Team tab displays all links or ports which are available to be aggregated into a so-called team or have been already aggregated to form a team.

2
