Garmin GMR 18 User Manual

GMR 18

marine radar installation instructions

© 2007 Garmin Ltd. or its subsidiaries
Garmin International, Inc.			Garmin (Europe) Ltd.	Garmin Corporation
1200 East 151st Street,			Liberty House	No. 68, Jangshu 2nd Road,
Olathe, Kansas 66062, USA			Hounsdown Business Park,	Shijr, Taipei County, Taiwan
Tel.	(913)	397.8200 or [phone]	Southampton, Hampshire, SO40 9RB UK	Tel. [phone]
Fax	(913)	397.8282	Tel. [phone] (outside the UK)	Fax [phone]
			0808 2380000 (within the UK)
			Fax [phone]

All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded or stored in any storage medium, for any purpose without the express prior written consent of Garmin. Garmin hereby grants permission to download a single copy of this manual onto a hard drive or other electronic storage medium to be viewed and to print one copy of this manual or of any revision hereto, provided that such electronic or printed copy of this manual must contain the complete text of this copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.

Information in this document is subject to change without notice. Garmin reserves the right to change or improve its products and to make changes in the content without obligation to notify any person or organization of such changes or improvements. Visit the Garmin Web site (www.garmin.com) for current updates and supplemental information concerning the use and operation of this and other Garmin products.

Garmin® is a trademark of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. This trademark may not be used without the express permission of Garmin.

March 2007

Part Number 190-00800-02 Rev. C

Printed in Taiwan

Welcome

Thank you for choosing the Garmin GMR 18. The GMR 18 utilizes the performance of Garmin radar and provides overlay and color information when combined with a Garmin marine multi-function display (MFD).

Product Registration

Help us better support you by completing our online registration today! Connect to our Web site at www.garmin.com/registration/.

Use this area to record the serial number (8-digit number located on the bottom of the GMR 18) in case your GMR 18 needs service. Keep the original sales receipt, or a photocopy, in a safe place.

Serial Number: ___  ___  ___  ___  ___  ___  ___  __

Contact Garmin

Contact Garmin if you have any questions while using your GMR 18. In the USA contact Garmin Product Support by phone:

[phone] or [phone], Monday–Friday, 8 AM–5 PM Central Time; or go to www.garmin.com/support/, and click Product Support.

In Europe, contact Garmin (Europe) Ltd. at +44 (0) 870.8501241 (outside the UK) or 0808 2380000 (within the UK).

Note: The Garmin GMR 18 has no user-serviceable parts. If you encounter a problem with your unit, please take it to an authorized Garmin NMEA dealer or contact Garmin Product Support for repairs.

Packing List

Before installing and getting started with your unit, please check to see that your package includes the following items. If any parts are missing, please contact your Garmin dealer immediately.

Standard Package:

•GMR 18 radar unit

•Power—marine network cable

•Mount kit hardware

•Grommet for marine cable

GMR 18 Marine Radar Installation Instructions

Installation

Scanner Installation

The following section covers the installation and setup of the GMR 18 marine radar. The GMR 18 only operates with components of the Garmin Marine Network, and Garmin MFDs (multi-function displays). See your Garmin dealer or the Garmin Web site for more details. To complete the installation, you need the appropriate fasteners, tools, and mounts. These items should be available at most marine dealers. Always wear safety goggles, ear protection, and a dust mask when drilling, cutting, or sanding. When drilling or cutting, always check first to see what is on the other side of the surface. If you experience difficulty with the installation, contact Garmin Product Support or seek the assistance of a professional installer.

Installation Guidelines

To maximize the performance of the radar, observe the following installation guidelines:

•An ideal scanner mounting location is high above the ship’s keel line with a minimal part of the vessel’s structure or rigging blocking the radar beam. Obstructions in the path of the radar beam may cause blind and shadow sectors, or generate false echoes. The higher the installation position, the further the scanner can detect targets.

•Avoid mounting the scanner on the same level as smoke stacks, horizontal spreaders, or crosstrees on a mast. Do not install the scanner near heat sources where it may be subjected to smoke or hot air from smoke stacks or heat from lights.

•The mounting surface or platform should be sturdy enough to support the weight of the scanner (15.8 lbs/7.17 kg), flat as possible, and parallel with the vessel’s water line.

•It is recommended that the radar scanner be mounted out of range of personnel (horizontal beam width above head height). When the scanner is transmitting, do not look directly at the antenna at close range, eyes are the most sensitive part of the body to electromagnetic energy. When properly installed and operated, the use of this radar conforms to the requirements of ANSI/IEEE C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields.

•A “Compass Safe Distance” must be maintained between the compass and the scanner. The Compass Safe Distance is measured from the center point of the compass to the nearest point on the scanner.

Standard compass = 1 m (39.37")

Standby Steering and Emergency compasses = 0.5 m (19.7")

12.5°

12.5°

12.5°

12.5°

•Mount other electronics and cables more than 2 m (7 ft) from the path of a radar beam. A radar beam can normally be assumed to spread 25° vertically above and below the scanner’s radiating element. For vessels with higher bow angles at cruise speed, it may be helpful to lower the angle so the beam points slightly downward to the waterline while at rest. Shims may be used as necessary.

•Install the scanner away from antennas for other electronics. GPS antennas should be either above or below the radar beam path of the scanner. Mount at least 1 m (3 ft) from any equipment transmitting or cables carrying radio signals, such as VHF radios, cables and antennas. In the case of SSB radios, the distance should be increased to 2 m (7 ft). IEC 60936-1 clause 3-27.1 states maximum distances from the antenna at which RF (radio frequency) levels can be expected.

(100W/m squared = 48" [121.92 cm]) (10W/m squared = 108" [274.32 cm])

•The radar scanner transmits electromagnetic energy. It is important that the radar is turned off or the DC power input is disconnected when personnel are required to come close to the scanner to perform work on the scanner assembly or associated equipment.

GMR 18 Radar Installation Manual
