GC9600 series
3
1
DE
CALC
IMPORTANT: Perform descaling regularly for great steam and prolonged life.
МАҢЫЗДЫ: Күшті булау және қызмет мерзімін ұзарту үшін қақтан тазалау әрекетін мерзімді түрде орындаңыз.
ВАЖНАЯ ИНФОРМАЦИЯ. Для продления срока службы и сохранения мощности подачи пара регулярно очищайте устройство от накипи.
ÖNEMLİ: Mükemmel buhar ve uzun süreli kullanım ömrü için kireç temizleme işlemini düzenli olarak gerçekleştirin.
ENGLISH 6
ҚАЗАҚША 10
РУССКИЙ 14
TÜRKÇE 19
GC9600 series
Introduction
This iron has been approved by The Woolmark Company Pty Ltd for the ironing of wool only products provided that the garments are ironed according to the instructions on the garment label and those issued by the manufacturer of this iron. R1501. In United Kingdom, Eire, HongKong and
India, theWoolmark trademark is a Certification trademark.
Product overview (Fig. 3)
1Steam supply hose
2Iron platform
3First supply hose storage compartment
4Mains cord with plug
5ECO button with light
6 On/off button with safety auto off light and TURBO setting
7’Water tank empty’ light
8EASY DE-CALC light
9EASY DE-CALC knob
10Cord storage compartment
11Second supply hose storage compartment
12Detachable water tank
13Carry lock
14Carry lock release button
15Soleplate
16Steam trigger
17‘Iron ready’ light
18Filling hole
Important
Read the separate important information leaflet and the user manual carefully before you use the appliance. Save both documents for future reference.
OptimalTempTechnology
The Optimal Temp Technology enables you to iron all types of ironable fabrics, in any order, without adjusting the iron temperature setting.
Fabrics with these symbols are ironable, for example linen, cotton, polyester, silk, wool, viscose and rayon (Fig. 4).
Fabrics with this symbol are not ironable.These fabrics include synthetic fabrics such as Spandex or elastane, Spandex-mixed fabrics and polyolefins (e.g. polypropylene), but also prints on garments
(Fig. 5).
Using your appliance
Ironing
Please read the quick start guide in the packaging carefully to start using your appliance.
Steam boost function
The steam boost function is designed to help tackle difficult creases.
-- Double press the steam trigger for a continuous shot of steam. It is not necessary to press and hold the steam trigger continuously when the steam boost function is activated.To stop the steam boost function, press the steam trigger once. (Fig. 6)
ENGLISH 7
Vertical ironing
Hot steam is emitted from the iron. Never attempt to remove creases from a garment that someone is wearing. Do not apply steam near your or someone else’s hand.
You can use the iron in vertical position to remove wrinkles from hanging fabrics.
1Hold the iron in vertical position, press the steam trigger and touch the garment slightly with the soleplate (Fig. 7).
Energy saving
ECO mode
-- By using the ECO mode (reduced amount of steam), you can save energy without compromising on the ironing result.The green light is on (Fig. 8).
-- You can deactivate the ECO mode by pressing the ECO button.The green light goes off.
Safety auto-off mode
-- To save energy, the appliance switches off automatically when it has not been used for
10 minutes.The auto-off light in the on/off button starts to flash (Fig. 9).
-- To activate the appliance again, press the on/off button.The appliance then starts to heat up again.
Note:The appliance is not switched off completely when it is in safety auto-off mode.To switch off the appliance, press the on/off button.
Turbo steam
For faster ironing and a higher amount of steam, you can use Turbo steam.
1 Press and hold the on/off button for 2 seconds until the light turns white. (Fig. 10)
2To deactivate Turbo steam, press and hold the on/off button again for 2 seconds until the white light turns blue
Ironing tips
Minimising wrinkles while drying
Start wrinkle removal early in the drying process by spreading out your laundry properly after washing and by putting garments on hangers to make them dry naturally with fewer wrinkles.
Best practice shirt ironing
Start with the time-consuming parts like collar, cuff links and sleeves. Next, iron the bigger parts like front and back to prevent wrinkling the bigger parts when you are busy ironing the time-consuming parts. Collar:When you iron a collar, start on its underside and work from the outside (the pointy end) inwards.Turn over and repeat. Fold down the collar and press the edge for a more crisp finish.
Buttons:Iron on the reverse side of the buttons for more effective and faster ironing.
IMPORTANT - DESCALING
It is very important to perform the descaling procedure as soon as the EASY DE-CALC light starts to flash and the appliance beeps continuously.
The EASY DE-CALC light flashes and the appliance beeps continuously after about a month or
10 ironing sessions to indicate that the appliance needs to be descaled. Perform the following descaling procedure before you continue ironing.
To avoid the risk of burns,unplug the appliance and let it cool down for at least two hours before you perform the descaling procedure.
8 ENGLISH
1Remove the plug from the wall socket (Fig. 11).
2Place the appliance on the edge of the tabletop.
3Hold a cup (with a capacity of at least 350ml) under the EASY DE-CALC knob and turn the knob anticlockwise (Fig. 12).
4Remove the EASY DE-CALC knob and let the water with scale particles flow into the cup
(Fig. 2).
5When no more water comes out of the appliance, reinsert the EASY DE-CALC knob and turn it clockwise to fasten it. (Fig. 13)
Troubleshooting
This chapter summarises the most common problems you could encounter with the appliance.
If you are unable to solve the problem with the information below, visit www.philips.com/support for a list of frequently asked questions or contact the Consumer Care Centre in your country.
Problem |
Possible cause |
Solution |
The ironing board |
Steam has condensed on the |
Replace the ironing board cover if the foam |
cover becomes |
ironing board cover after a long |
material has worn out.You can also add an |
wet or there are |
ironing session. |
extra layer of felt material under the ironing |
water droplets on |
|
board cover to prevent condensation on |
the garment |
|
the ironing board.You can buy felt in a |
during ironing. |
|
fabric shop. |
|
You have an ironing board |
Put an extra layer of felt material under the |
|
cover that is not designed to |
ironing board cover to prevent |
|
cope with the high steam rate |
condensation on the ironing board.You can |
|
of the appliance. |
buy felt in a fabric shop. |
Water droplets |
The steam that was still present |
Steam away from the garment for a few |
come out of the |
in the hose has cooled down |
seconds. |
soleplate. |
and condensed into water.This |
|
|
causes water droplets to come |
|
|
out of the soleplate. |
|
Steam and/or |
The EASY DE-CALC knob is |
water come out |
not tightened properly. |
from under the |
|
EASY DE-CALC |
|
knob. |
|
Switch off the appliance and let the appliance cool down for 2 hours. Unscrew the EASY DE-CALC knob and screw it back onto the appliance properly. Note: Some water may escape when you remove the knob.
|
The rubber sealing ring of the |
|
EASY DE-CALC knob is worn. |
Dirty water and |
Impurities or chemicals present |
impurities come |
in the water have deposited in |
out of the |
the steam vents and/or on the |
soleplate or the |
soleplate. |
soleplate is dirty. |
|
|
Too much scale and minerals |
|
have accumulated inside the |
|
appliance. |
Contact an authorised Philips service centre for a new EASY DE-CALC knob.
Clean the soleplate with a damp cloth.
Descale the appliance regularly
(see chapter ‘Important - DESCALING’).
|
|
ENGLISH |
9 |
Problem |
Possible cause |
Solution |
|
The iron leaves a The surface to be ironed was |
PerfectCare is safe on all garments.The |
|
|
shine or an |
uneven, for instance because |
shine or imprint is not permanent and will |
|
imprint on the |
you were ironing over a seam |
come off if you wash the garment. Avoid |
|
garment. |
or a fold in the garment. |
ironing over seams or folds or you can |
|
|
|
place a cotton cloth over the area to be |
|
|
|
ironed to avoid imprints at seams and folds. |
The appliance |
There is not enough water in |
does not produce |
the water tank (the ‘water tank |
any steam. |
empty’ light flashes). |
|
The appliance is not hot |
|
enough to produce steam. |
|
You did not press the steam |
|
trigger. |
|
The water tank is not placed in |
|
the appliance properly. |
|
The appliance is not switched |
|
on. |
The appliance has |
The auto-off function is |
switched off.The |
activated automatically when |
light in the on/off |
the appliance has not been |
button flashes. |
used for more than 10 minutes. |
The appliance |
Water is pumped into the |
produces a |
boiler inside the appliance.This |
pumping sound. |
is normal. |
Fill the water tank (see chapter ‘Using your appliance’, section ‘Filling the water tank’).
Wait until the ‘iron ready’ light on the iron lights up continuously.
Press the steam trigger and keep it pressed while you iron.
Slide the water tank back into the appliance firmly (‘click’).
Insert the plug in the wall socket and press the on/off button to switch on the appliance.
Press the power on/off button to switch on the appliance again.
If the pumping sound continues nonstop, switch off the appliance and remove the plug from the wall socket. Contact an authorised Philips service centre.
