© 2016 Koninklijke Philips N.V. All rights reserved.
4239 001 04682
1
d
GC4500 series
c
a
bc b
e
a
f g
h
User manual |
|
Посібник користувача |
Руководство пользователя |
|
Пайдаланушы нұсқаулығы |
Kullanım kılavuzu |
|
|
|
|
|
Quick Start Guide – Start here |
Quick Start Guide – Calc clean |
2 |
3 |
4 |
6 |
7 |
11 |
12 |
13 |
14 |
15 |
16 |
17 |
18 |
19 |
8 |
9 |
10 |
Quick Start Guide – Storage
|
|
|
|
|
20 |
21 |
22 |
|
|
|
|
||||
|
|
|
|
|
|
|
|
ENGLISH 6
РУССКИЙ 9
TÜRKÇE 13
УКРАЇНСЬКА 16 ҚАЗАҚША 19
GC4500 series
6 ENGLISH
Important
Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.
Read the separate important information leaflet and this user manual carefully before you use the appliance. Keep both documents for future reference.
Product overview (Fig. 1)
1Spray button
2Steam slider
a.Dry setting
b.ECO setting
c.Auto steam setting
3Steam boost trigger
4 Safety auto-off light (specifc types only)
5Temperature indicator light
6Temperature dial with Auto steam control
7Calc clean button
8Built-in calc container
Type of water to use
Your appliance has been designed to be used with tap water. If you live in an area with hard water, fast scale build-up may occur. Therefore, it is recommended to use distilled or demineralized water to prolong the lifetime of your appliance.
Do not put perfume, vinegar, starch, descaling agents, ironing aids or other chemicals in the water tank.
Ironing
Please read the quick start guide in this user manual carefully to start using your appliance. (Fig. 2-10)
Temperature setting
Select the temperature to the appropriate setting for your garment according to table 1 below:
Table 1: |
|
|
|
|
Fabric type |
|
Temperature setting |
Auto steam control |
Steam boost |
Linen |
|
MAX |
|
Yes |
Cotton |
|
●●● |
Automatically adjusted to |
Yes |
|
|
|
|
|
Wool |
|
●● |
the optimal amount |
No |
|
|
|||
Silk |
|
●● |
|
No |
|
|
|||
Synthetic fabric (e.g. acrylic, nylon, |
|
● |
Automatically adjusted to |
No |
polyamide, polyester) |
|
|
no steam |
|
ENGLISH 7
Steam setting
-- Auto steam: The iron automatically adjusts the steam output according to the selected temperature to provide the best ironing result.
-- ECO: This steam setting enables you to reduce the steam output to save energy and still have suffcient steam to iron your garments.
-- Dry: This steam setting enables you to iron without steam or to stop steam when the iron is not in use.
-- Iron with extra steam: Press and hold the steam boost trigger to get more steam to remove stubborn creases.
Delicate fabric protector (specific types only)
The delicate fabric protector protects delicate fabrics from heat damage and shiny patches.
With the delicate fabric protector you can iron delicate fabrics (silk, wool and nylon) at temperature settings ●●● to MAX in combination with all steam functions available on the iron.
The delicate fabric protector reduces the soleplate temperature instantly, thus allowing you to iron delicate fabrics safely.
If you do not know what kind or kinds of fabric an article is made of, determine the right ironing temperature by ironing a part that is not visible when you wear or use the article.
1 Put the iron on the delicate fabric protector (‘click’) (Fig. 10).
Steam boost function and vertical steaming
-- Press and release the steam boost trigger for a powerful boost steam. This can be used to remove targeted stubborn creases or creases from a hanged garment.
Note: The steam boost function should only be used at temperature setting between ●●● to MAX. Leaking may appear if you use steam boost at too low a temperature.
Hot steam comes out of the iron. Do not remove wrinkles from a garment while some one is wearing it. To prevent burns, do not direct the steam at people.
Safety auto-off (specific types only)
The safety auto-off function automatically switches off the iron if it has not been used for 30 seconds resting on its soleplate or 8 minutes resting on its backplate. The auto-off light will light up.
-- To let the iron heat up again, pick up the iron or move it slightly. The auto-off light goes out.
Cleaning and maintenance
Cleaning
1Unplug the iron and let it cool down.
2Pour any remaining water out of the water tank from the water filling door.
3Wipe flakes and any other deposit off the soleplate with a damp cloth and a non-abrasive (liquid) cleaning agent.
To keep the soleplate smooth, avoid hard contact with metal objects. Never use a scouring pad, vinegar or other chemicals to clean the soleplate.
8 ENGLISH
Calc clean function
IMPORTANT: This iron comes with a Built-in calc container, which collects loose scale particles during ironing. The calc container is not meant for removal by the user. The scale particles are flushed out of the iron during calc clean process. Perform calc clean once every 1 month to maintain good steam performance and prolong the life of your iron. If water in your area is hard, or you see scales coming out from the soleplate during ironing, use calc clean more frequently.
1Make sure the iron is unplugged and the steam slider is set to dry setting. (Fig. 11)
2Fill the water tank to the MAX indication. (Fig. 12)
Do not pour vinegar or other descaling agents into the water tank.
3 Plug in the iron and set the temperature dial to MAX. (Fig. 13-14) 4 Unplug the iron when the temperature light goes out. (Fig. 15-17)
5Hold the iron over the sink. Keep pushing the calc clean button and gently shake the iron forth and back until all water in the water tank has been used up. (Fig. 18)
Scales is flushed out, steam and boiling water also come out of the soleplate.
Note: Repeat steps 2 to 5 if the water that comes out of the iron still contains scale particles.
6Plug in the iron and let the iron heat up to dry the soleplate. (Fig. 19)
7Unplug the iron when the temperature indicator light goes out.
8Move the iron gently over a piece of cloth to remove any water stains on the soleplate.
Troubleshooting
This chapter summarises the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, visit www.philips.com/support for a list of frequently asked questions or contact the Consumer Care Centre in your country (see the worldwide guarantee leaflet for contact details).
Problem |
Possible cause |
Solution |
|
|
|
Water leaks from the water flling |
You have overflled the water tank. |
Do not fll the water tank beyond the |
door. |
|
MAX indication. Pour excess water out |
|
|
of the water tank. |
Water drips from the soleplate after |
The steam slider is set to MAX |
Set the steam slider to dry setting. |
the iron has been unplugged or has |
or ECO. |
|
been stored. |
|
|
|
You have put the iron in horizontal |
Empty the water tank. |
|
position with water still left in the |
|
|
water tank. |
|
The steam boost function does not |
You have used the steam boost |
Wait for a few seconds before you use |
work properly (water leaks out of |
function too often within a very |
the steam boost function again. |
the soleplate). |
short period. |
|
Flakes and impurities come out of the soleplate during ironing.
You have used the steam boost |
Set an ironing temperature at which |
function at too low a temperature. |
the steam boost function can be used |
|
(●●● to MAX). |
Calc are formed inside the |
Use the calc clean function (see chapter |
soleplate. |
‘Cleaning and maintenance’, section ‘calc |
|
clean function’). |
РУССКИЙ 9
Важно
Поздравляем с покупкой и приветствуем в клубе Philips! Чтобы воспользоваться всеми преимуществами поддержки Philips,зарегистрируйте продукт на веб-сайтеwww.philips.com/welcome.
Перед использованием прибора внимательно ознакомьтесь с буклетом с важной информацией и данным руководством пользователя.Сохраните эти документы для дальнейшего использования в качестве справочного материала.
Описание изделия (рис. 1)
1Кнопка разбрызгивателя
2Переключатель режимов подачи пара
a.Глажение без пара
b.Экорежим
c.Функция автоматической подачи пара
3Кнопка парового удара
4 Индикатор автоотключения (только для некоторых моделей)
5Индикатор нагрева
6 Дисковый регулятор нагрева с автоматической регулировкой подачи пара
7Кнопка очистки от накипи
8Встроенный контейнер для накипи
Тип используемой воды
Прибор предназначен для использования с водопроводной водой.Если вода в вашем регионе очень жесткая,в приборе может быстро образовываться накипь.Поэтому для продления срока службы прибора рекомендуется использовать дистиллированную или деминерализованную воду.
Не добавляйте в резервуар для воды духи,уксус,крахмал,химические средства для удаления накипи,добавки для глажения или другие химические средства.
Глажение
Перед использованием прибора внимательно знакомьтесь с информацией в прилагаемом кратком руководстве пользователя (рис.2-10).
Настройка температуры
Чтобы выбрать настройку температуры,подходящую для конкретного типа ткани,ознакомьтесь с таблицей 1 ниже.
Таблица 1. |
|
|
|
|
Тип ткани |
|
Настройка |
Автоматическая |
"Паровой |
|
|
температуры |
регулировка подачи пара |
удар" |
Лен |
|
MAX |
|
Да |
Хлопок |
|
●●● |
Автоматическая |
Да |
Шерсть |
|
●● |
настройка оптимального |
нет |
|
||||
|
уровня |
|||
Silk |
|
●● |
|
нет |
|
|
|||
Синтетические ткани (например, |
|
|
Автоматическая |
|
акрил,нейлон,полиамид, |
|
● |
настройка:подача пара |
нет |
полиэстер) |
|
|
отключена |
|
