Page 1
Camera
Operations Guide
Read this first
Video Camera Recorder/Digital Video Camera Recorder
3-087-919-14(1)
© 2004 Sony Corporation
CCD-TRV228E/TRV428E
DCR-TRV255E/TRV265E
Page 2
Read this first
restart the application or disconne c t a nd co nne ct the
USB cable again.
Before operating the unit, please read this
manual thoroughl y, and retain it for future
reference.
WARNING
To prevent fire or shock hazard, do no t
expose t h e u nit to rain o r moisture.
To avoid electrical sho ck, do not open
the cabinet. Refer servicing to qualified
personnel only.
FOR CUSTOMERS IN THE UNITED
KINGDOM
NOTICE ON THE SUPPLIED AC
ADAPTOR
A moulded plug complying with BS1363 is fitted to
this equipment for your safe ty an d convenience.
Should the fuse in the plug supplied need to be
replaced, a fuse of the same rating as the supplied one
and approved by ASTA or BSI to BS1362
(i.e., marked with or mark) must be used.
If the plug supplied with this equipment has a
detachable fuse cover , be sure to at ta ch the fus e cov er
after you change the fuse. Never use the plug without
the fuse cover. If you should lose the fuse cover, please
contact your nearest Sony service station.
FOR CUSTOMERS IN EUROPE
ATTENTION for DCR-TRV255E/TRV265E
The electromagnetic fields at the specific frequencies
may influence the picture and sound of this camcorder.
Notes on use
Note on a cassette tape
You can use standard 8 mm and Hi8 ,
Digital8 video cassettes on your camcord er. See
page 81 for details.
Notes on recording
• Before starting to record, t est the recor ding function
to make sure the picture and sound are reco rd ed
without any problems.
• Compensation for the contents of recordings cannot
be provided, even if recording or playbac k is not
possible due to a malfunction of the camcorder, etc.
• TV color systems differ depending on the cou ntry /
regions. To view your recordings on a TV, you need
a PAL system-based TV.
• Television programs, films, video tapes, and other
materials may be copyright ed . Unau thorized
recording of such materials may be contrary to the
copyright laws.
Notes on the LCD panel, viewfinder, and
lens
• The LCD screen and the viewfinder are
manufactured using extremely high-precision
technology, so over 99.99% of the pixels a re
operational for effective u se .
However, there may be some tiny blac k point s an d/
or bright points (white, red, blue, or gre en in colo r)
that appear constantly on the LCD screen and the
viewfinder.
These points are normal results of the manufacturing
process and do not affect the recording in any wa y.
• Exposing the LCD screen, the viewfinder, or the lens
to direct sunlight for long periods of time may cause
malfunctions. Be careful when placing the camera
near a window or outdoors.
• Do not aim at the sun. Doing so might cause your
camcorder to malfunction. Take pictures of the sun
only in low light conditions, such a s at dusk.
This product has been tested and found compliant with
the limits set out in the EMC Directive for using
connection cables shorter than 3 meters (9.8 feet).
Notice for DCR-TRV255E/TRV265E
b
If static electricity or electromagnetic interference
causes data transfer to disc ontinue midway (fail),
2
Page 3
Note on connecting other device
Before connecting your camcord er to ot he r devi ce
such as a VCR or a computer with an US B o r i.LINK
cable, be sure to insert the connector plug in the proper
direction. If you insert the connecto r plu g fo rcibly in
the wrong direction, the terminal may be damaged.
This may cause a malfunction of your camcorder.
• Do not hold the camcorder by the foll owing parts.
Notes on using this manual
• The images of the LCD screen and the viewfinder
used on this manual are captured using a digital still
camera, and thus may appear different from what
you see.
• In this instruction manual, each model is indicated as
follows.
CCD-TRV228E: TRV228E
CCD-TRV428E: TRV428E
DCR-TRV255E: TRV255E
DCR-TRV265E: TRV265E
Instructions with no sp ecific model nam es are for all
models.
Instructions with specific model names are for the
indicated models only.
Before you start reading this manual, check the
model name of your camcorder.
• The illustrations used on this manual are based on
the model DCR-TRV265E.
Notes on using the camcorder
• Hold your camcorder corr ectl y.
• To ensure a good grip, fasten the grip belt as shown
in the following illustr at ion.
Viewfinder
Battery pack
• Turn the SEL/PUSH EXEC dial to se le ct des ir ed
item, then press the dial to decide.
LCD panel
• You can change the language to be used for screen
display on your camcorder (p. 19).
3
Page 4
Table of Contents
CCD-TRV228E: TRV228E DCR-TRV2 55E: TRV255E
CCD-TRV428E: TRV428E DCR-TRV2 65E: TRV265E
Read this first............................................................................................. 2
Quick Start Guide
Recording movies ...................................................................................... 8
Recording/Playing back with ease ............... ....... ...... ....... ...... ....... ...... ..... 10
Getting started
Step 1: Checking supplied items.............................................................. 11
Step 2: Charging the battery pack............................................................ 12
Using an outside power source .................................................................................15
Step 3: Turning the power on................................................................... 15
Step 4: Adjusting the LCD panel and viewfinder...................................... 16
Adjusting the LCD panel ............................................................... .... .. .... .. .... ....... .. ....16
Adjusting the viewfinder .............................................................................................16
Step 5: Setting the date and time............................................................. 17
Step 6: Inserting a cassette tape.............................................................. 18
Step 7: Setting the screen language........................................................ 19
Recording
Recording movies .................................................................................... 21
Recording for a longer time .......................................................................................22
Using zoom ................................................................................................................23
Using the built-in light ................................................................................................23
Recording in mirror mode .......................................................................................... 24
Superimposing the date and time on pictures ( TRV228E/428E) ......................25
Recording still images – Tape photo recording
( TRV255E/265E)............................................................................. 25
Recording with ease – Easy Handycam .................................................. 26
Adjusting the exposure............................................................................. 27
Adjusting the exposure for b ack lit subjects ..................... ............... .............. .............27
Adjusting the exposure manually ...............................................................................28
Recording in dark places – NightShot plus.............................................. 28
Adjusting the focus manually ................................................................... 29
4
Page 5
Recording a picture using various effects ................................................ 30
Fading in and out of a scene – FADER .................................................................... 30
Superimposing a title................................................................................ 31
Searching for the last scene of the most recent recording
– END SEARCH ................................................................................. 33
Playback
Viewing pictures recorded on a tape........................................................ 34
Playing back in various modes ................................................................................. 35
Playing back with ease – Easy Handycam .............................................. 36
Various playback functions ...................................................................... 37
Displaying the screen indi cators ............................................................................... 37
Displaying the date/time and camera settings data – Data code
( TRV255E/265E) .............................................................................................37
Playing the picture on a TV............................................................. ...... ... 39
Locating a scene on a tape for playback ( TRV265E)........................... 40
Searching quickly for a desired scene – Zero set memory ....................................... 40
Searching for a scene by date of recording – Date search ....................................... 41
Searching for a still image – Photo search ...............................................................41
Playing back still images in sequence – Photo scan ................................................ 42
,continued
5
Page 6
Advanced operations
Troubleshooting
Customizing Your
Camcorder
Changing the menu settings ..............43
Using the (MANUAL SET) menu
– PROGRAM AE/P EFFECT,
etc. ...............................................44
Using the (CAMERA SET) menu
– 16:9 WIDE/STEADYSHOT,
etc. ...............................................47
Using the (PLAYER SET)/ (VCR
SET) menu
etc. ...............................................51
Using the (LCD SET) menu
– LCD B.L./LCD COLOR, etc. ......53
Using the (TAPE SET) menu
– FRAME REC/INT.REC, etc. ......54
Using the (SETUP MENU)
– CLOCK SET/USB STREAM/
LANGUAGE, etc. ....................57
Using the (OTHERS) menu
– WORLD TIME/VIDEO EDIT,
etc. ...............................................59
– HiFi SOUND/EDIT,
Troubleshooting .................................73
Warning indicators and messages .....78
Additional Information
Using your camcorder abroad ...........80
Usable cassette tapes .......................81
About the “InfoLITHIUM” battery
pack ..............................................82
About i.LINK .......................................83
Maintenance and precautions ............84
Specification ......................................87
Quick Reference
Identifying parts and controls .............90
Index ..................................................97
Dubbing/Editing
Connecting to a VCR .........................61
Dubbing to another tape ....................63
Dubbing a tape easily – Easy Dubbing
( TRV228E/428E) ................. 64
Recording pictures from a VCR
( TRV265E) ............................... 68
Dubbing selected scene s from a tape
– Digital program editi ng
( TRV255E/265E) ......................68
6
For TRV255E/265E:
Refer also to other operat in g inst ruc ti ons
supplied with your camco rde r:
• Editing images with your computer
cComputer Applications Guide
Page 7
7
Page 8
Quick Start Guide
Recording movies
1 Attach the charged battery pack to the camcorder.
To charge the battery, see page 12.
a Lift up the viewfinder. b Slide the battery pack in the direction
of the arrow until it clicks.
2 Insert a cassette into the camcorder.
a Slide the OPEN/
EJECT lever in the
direction of the arrow
and open the lid until
it clicks.
The cassette compartment
comes out automatically.
OPEN/EJECT lever
Quick Start Guide
8
b Insert the cassette with
its window-side facing
up, then push the center
of the back of the
cassette.
Window-side
c Press .
Close the cassette lid after
the cassette compartment
slides back in by itself.
Page 9
3 Start recording while checking the subject on the LCD screen.
The date and time is not set up in the default setting. To set the date and time, see page 17.
a Remove the lens cap.
Lens cap is not attached
when you purcha se your
camcorder (p.90) .
b Press OPEN and
open the LCD panel.
c While pressing the
green button, slide
the POWER switch
down to light up the
CAMERA lamp.
The power turns on.
d Press REC START/
STOP.
Recording starts. To
change to standb y m ode,
press REC START/STOP
again.
4 View the recorded picture on the LCD screen.
Quick Start Guide
a Slide the POWER
switch rep eatedly
until the PLAY/EDIT
lamp lights up.
b Press (rewind).
c Press (play) to
start the playback.
To stop, press .
To turn off the power, slide the
POWER switch up to (CHG)
OFF.
Quick Start Guide
9
Page 10
Recording/Playing back with ease
By switching to Easy Handycam operation, recording/playback operation
becomes even easier.
Easy Handycam operation allows easy recording/playback for even first
time users by providing only the basic functions for recording/playback.
Press EASY when recording/
playing back.
EASY lights up in blue (1) and
screen font siz e increases (2) during
Easy Handycam operation.
Easy Handycam
operation
ON
For details, se e i nstructions for each operation.
See page 26 for recording, page 36 for playback.
Quick Start Guide
10
Page 11
Getting started
Step 1: Checking supplied items
RMT-830: ( TRV265E)
Make sure you have following ite ms supplied
with your camcorder.
The number in parentheses indicates the number
of that item supplied.
AC Adaptor (1)
Mains lead (1)
Lens cap (1)
See page 90 on how to attach the lens cap.
Shoulder strap (1)
See page 93 on ho w to at ta ch the s hou lder strap .
A/V connecting cable (1)
Monaural: ( TRV228E/428E)
Getting started
Stereo: ( TRV255E/2 65E)
USB cable (1)
( TRV255E/265E)
Rechargeable battery pack NP-FM30 (1)
CD-ROM “SPVD-012 USB Driver” (1)
( TRV255E/265E)
21-pin adaptor (1)
For the models with the mark printed on
their bottom surfaces only.
Camera Operations Guide (This manual)
(1)
Wireless Remote Commander (1)
A button-type lithium battery is already
installed.
RMT-833: ( TRV228E/428E)
Computer Applications Guide (1)
( TRV255E/265E)
,continued
Getting started
11
Page 12
Step 2: Charging the battery pack
You can charge the battery by attaching the
“InfoLITHIUM” battery pack (M series)
to your camcorder .
b Notes
• You cannot use batteries oth er tha n the
“InfoLITHIUM” battery pack (M series) (p. 82).
• Do not short-circuit the DC plug of the AC Adaptor
or battery terminals with any metallic objects. This
may cause a malfunction.
• Use a nearby wall socket when using the AC
Adaptor. Disconnect the AC Adaptor from the wall
socket immediately if any mal f unc tion occurs.
Battery pack
2 Attach the battery pack by slid ing it in
the direction of the arrow until it
clicks.
3 With the v mark on the DC plug
facing up, connect the AC Adaptor to
the DC IN jack on your camcorder.
DC IN jack
Mains lead
To the wall socket
1 Lift up the viewfinder.
Getting started
12
DC plug
AC Adaptor
v mark
4 Connect the mains lead to the AC
Adaptor.
5 Connect the mains lead to the wall
socket.
6 Slide the POWER switch up to (CHG)
OFF.
The CHG (charge) la m p l i ght s up and
charging starts.
Page 13
After charging the battery
The CHG (charge) lamp turns off when the
battery is fully c har ged. Disconnect the AC
Adaptor fro m the DC IN jack.
To remove the battery pack
BATT (battery)
release button
1
Lift up the viewf i nder.
POWER switch
2 Set the POWER switch to (CHG) OFF.
3 Slide the battery pack out in the di rection
of the arrow whi l e pressing the BATT
(battery) release button down.
b Note
• If you do not use the battery pack for a long time, use
up the battery pack completely before storing it. See
page 82 about storage of the battery pack.
To check the remaining battery – Battery
Info
DSPL/BATT INFO
You can check the battery’s current charge level
and its current remaining recording time both
during charging or when the power is turned off.
1 Set the POWER switch to (CHG) OFF.
2 Pr ess OPEN and open the LCD pa nel .
3 Pr es s DSP L/BATT I NFO.
The battery informa tion appears for about 7
seconds.
Keep the button pressed to view it for about
20 seconds.
BATTERY INFO
BATTERY CHARGE LEVEL
0% 50% 100%
REC TIME AVAILABLE
A Battery charge level: Displays
approximate remai ning amount of
power left in the ba ttery pack.
B Approximate possibl e recording time
using the LCD panel.
C Approximate possibl e recording time
using the viewfinder.
Charging time
Approximate number of minutes req uired when
you fully charge a fully discharged battery pack
at 25°C (77°F). (10 – 30°C (50 – 86°F)
recommended.)
Battery pack
NP-FM30 (supplied) 145
NP-FM50 150
NP-QM71/QM71D 260
NP-QM91/QM91D 360
LCD SCREEN: 81 min
VIEWFINDER: 112 min
Getting started
OPEN
POWER switch
Recording time when recordi ng with the
LCD screen on
Approximate number of minutes available
when you use a fully charged battery pack at
25°C (77°F).
,continued
Getting started
13
Page 14
For TRV228E/428E:
Battery pack Continuous
recording
time
NP-FM30
(supplied)
NP-FM50 185 90
NP-QM71/
QM71D
NP-QM91/
QM91D
115 55
445 220
670 335
Typical*
recording
time
For TRV255E/265E:
Battery pack Continuous
recording
time
NP-FM30
(supplied)
NP-FM50 200 105
NP-QM71/
QM71D
NP-QM91/
QM91D
125 65
485 255
725 385
Typical*
recording
time
For TRV255E/265E:
Battery pack Continuous
recording
time
NP-FM30
(supplied)
NP-FM50 145 80
NP-QM71/
QM71D
NP-QM91/
QM91D
90 50
355 220
535 300
Typical*
recording
time
Recording time when recordi ng with the
viewfinder
Approximate nu m ber of minutes available
when you use a fully charged battery pack at
25°C (77°F).
For TRV228E/428E:
Battery pack Continuous
recording
time
NP-FM30
(supplied)
NP-FM50 280 135
NP-QM71/
QM71D
NP-QM91/
QM91D
175 85
675 330
1010 495
Typical*
recording
time
* Approximate number of minutes when recording
while you repeatedly record, start/stop, slide the
POWER switch to change the power mode, and
zoom. The actual battery life may be shorter.
Playing time
Approximate number of minutes available
when you use a fully charged battery pack at
25°C (77°F).
For TRV228E/428E:
Battery pack LCD panel
opened
NP-FM30
(supplied)
NP-FM50 185 295
NP-QM71/
QM71D
NP-QM91/
QM91D
115 185
445 715
670 1070
LCD panel
closed
For TRV255E/265E:
Battery pack LCD panel
opened
NP-FM30
(supplied)
NP-FM50 160 240
NP-QM71/
QM71D
NP-QM91/
QM91D
100 150
390 580
585 865
LCD panel
closed
Getting started
14
Page 15
b Notes
• The power will not be supplied from the battery pack
when the AC Adaptor is connected to the DC IN jack
of your camcorder, even if its mains lead is
disconnec ted from the wall socket.
• The recording and pla yback time will be shorter
when you use your camcorder in low temperature.
• The CHG (charge) lamp flashes during charging, or
the battery information will not be corre ctly
displayed in following conditions.
– The battery pack is not attac he d co rrectly.
– The batt e r y pack is dama ged.
– The battery pack is fully discharged. (For Battery
information only.)
Using an outside power source
You can use the AC Adaptor as the power
source when you do not want the battery to
run out. While you are using the AC Adaptor,
the battery pack will not lose its c harg e ev en
when it is attached to your camc order.
PRECAUTION
Even if your camcorder is turned off, AC power
(mains) is still supp lied to it while connec ted t o
the wall socket via the AC Adaptor.
Connect your camcorder as shown in
“Charging the battery pack” (p. 12).
Step 3: Turning the power on
You need to slide the POWER switch
repeatedly to select the desired power mode
to record or play.
When using this camcorder for the first time,
the [CLOCK SET] screen appears (p. 17).
Getting started
While pressing the green button, slide the
POWER switch down.
The power turns on.
To enter the recording or playing mode, sl id e
the switch repeatedly until the respective lamp
for the desire d power mode lights up.
• CAMERA mode: To record on a tape.
• PLAY/EDIT mode: To play or edit pi ctures on
a tape.
To turn off the power
Slide the POWER switch up to (CHG) OFF.
Getting started
15
Page 16
Step 4: Adjusting the LCD panel and viewfinder
Adjusting the LCD panel
You can adjust the angle and brightness of
the LCD panel to meet various recording
situations.
Even when there are obstructions between you
and the subject, you can check the subject on the
LCD screen during recording by adjusting the
angle of the LCD panel.
3 Turn the SEL/PUSH EXEC dial to select
[LCD BRIGHT], then press the dial
(p. 53).
4 Adjust the brightness of the LCD screen
with the SEL/PUSH EXEC dial, then
press the dial.
5 Pr ess MENU.
z Tips
• If you rotate the LCD panel 180 degrees to the lens
side, you can close the LCD panel with the LCD
screen facing out.
• If you are using the battery pack for power source,
you can adjust the brightness by sele c ting [LCD
B.L.] in the (L CD S ET) menu (p . 53).
• The recorded picture will not be aff e ct ed by this
setting.
• You can turn off the operation confirmation beep by
setting [BEEP] in the (OTHERS) menu to
[OFF] (p. 59).
MENU
Maximum
180 degrees
Maximum
90 degrees
Press OPEN and
open the LCD panel.
Open the LCD panel 90 degrees to the
camcorder, then rotate it to the desired
position.
SEL/PUSH EXEC dial
To adjust the brightness of the LCD
screen
1
Press MENU.
2 Turn the SEL/PUSH EXEC di al to sel ect
(LCD SET), then press the dial.
Adjusting the viewfinder
You can view images using the viewfinder
when you close the LCD panel. Use the
viewfinder when the battery is running out, or
when the screen is hard to see.
Viewfinder lens adjustme nt lever
1 Lift up the viewfinder.
2 Adjust the viewfinder lens adjustment
lever until the picture is clear.
Getting started
16
Page 17
Step 5: Setting the date and time
Set the date and time when using this
camcorder for the first time. If you do not set
the date and time, the [CLOCK SET] screen
appears every time you turn on your
camcorder.
b Note
• If you do not use your camcorder for about 3
months, the built-in rechargeable button-type
battery gets discharged an d the dat e and ti me
settings may be cleared from the memory. In that
case, charge the rechargeab le butt on- type battery
(p. 86) and then set the date and time again.
MENU
3 Press MENU.
MANUAL SET
PROGRAM AE
P EFFECT
AUTO SHTR
[
MENU] : END
STBY
4 Turn the SEL/PUSH EXEC dial to
select (SETUP MENU), then press
the dial.
SETUP MENU
CLOCK SET
USB STREAM
LTR SIZE
LANGUAGE
DEMO MODE
RETURN
[
MENU] : END
––:––:––
STBY
5 Turn the SEL/PUSH EXEC dial to
select [CLOCK SET], then press the
dial.
Getting started
OPEN
SEL/PUSH
EXEC dial
POWER
switch
1 Turn on your camcorder (p. 15).
2 Press OPEN and open the LCD panel.
Proceed to step 6 when you set the clock for
the first time.
CLOCK SET
Y
2004 1 1 0:00
[MENU] : CANCEL
STBY
M D H M
6 Turn the SEL/PUSH EXEC dial to set
[Y] (year), then press the dial.
CLOCK SET
Y
2004 1 1 0:00
[MENU] : CANCEL
STBY
M D H M
You can set any year up to the year 2079.
7 Set [M] (month), [D] (day), [H] (hour)
and [M] (minute) in the same way as
was done in step 6, then press the dial.
,continued
Getting started
17
Page 18
To check the preset date and time
For TRV228E/428E:
Press DATE to display the date indicator.
Press TIME to display the time indicator.
Press DATE (or TIME) and then press TIME
(or DATE) to simultaneously display the date
and time indicator.
To hide the date and/or time indicator, press
DATE and/or TIME again.
Step 6: Inserting a cassette tape
You can use standard 8 mm and Hi8 ,
Digital8 video cassettes on your camcorder.
For details on these cassettes (such as writeprotection), See page 81.
b Notes
• Do not force the cassette into the compartment. This
may cause a malfunction of your camcorder.
• For TRV255E/265E:
The recording time when you use your camcorder is
2/3 of the indicated time on Hi8 tape. If you
select the [LP] mode in the menu settings, the
recording time is the indicated time on
Hi8 tape.
1 Slide the OPEN/EJECT lever in
the direction of the arrow and open the
lid until it clicks.
OPEN/EJECT lever
Lid
Getting started
18
The cassette compartment automatically
comes out and opens up.
Page 19
2 Insert a cassette with its window-side
facing up.
Window-side
Push the center of the
back of the cassette
lightly.
3 Press .
The cassette compartment automatically
slides back in.
Step 7: Setting the screen language
You can select the language to be used on the
LCD screen.
MENU
OPEN
SEL/PUSH
EXEC dial
1 Turn on your camcorder.
2 Press OPEN to open the LCD panel.
POWER
switch
Getting started
4 Close the lid.
To eject the cassette
Slide the OPEN/EJECT lever in the
1
direction of the arrow and open the lid.
The cassette compartment automatically
comes out.
2 Take out the casset te, then press .
The cassette compartment automatically
slides back in.
3 Close the lid.
3 Press MENU.
MANUAL SET
PROGRAM AE
P EFFECT
AUTO SHTR
[
MENU] : END
STBY
4 Turn the SEL/PUSH EXEC dial to
select (SETUP MENU), then press
the dial.
SETUP MENU
CLOCK SET
USB STREAM
LTR SIZE
LANGUAGE
DEMO MODE
RETURN
[
MENU] : END
––:––:––
STBY
,continued
Getting started
19
Page 20
5 Turn the SEL/PUSH EXEC dial to
select [ LANGUAGE], then press
the dial.
SETUP MENU
CLOCK SET
USB STREAM
LTR SIZE
LANGUAGE
DEMO MODE
[
MENU] : END
DEUTSCH
ENGLI SH
ENG[SIMP
ESPAÑOL
FRANÇAI S
ITALIANO
STBY
]
6 Turn the SEL/PUSH EXEC dial to
select the desired language, then press
the dial.
7 Press MENU.
z Tip
• Your camcorder offers [ENG [SIMP]] (simplified
English) for when you cannot find your nativ e
tongue among the options.
Getting started
20
Page 21
Recording
2 Press OPEN and open the LCD panel.
Recording movies
Before recording, follow steps 1 to 7 in
“Getting started” (p. 11 - p. 19).
For TRV228E/428E:
Movies will be recorded along with monaural
sound.
For TRV255E/265E:
Movies will be recorded along with stereo
sound.
Camera recording la mp
OPEN
b Note
• For TRV228E/428E:
The date is automatica ll y recorded for 10 seconds
after you start recording ( Auto date function). This
function works only once a day. See page 57 for
details.
z Tip
• Performing Eas y Hand yc am ope ration, even first
time users can record easily. For details, see page 26.
REC START/STOP
1 Remove the lens cap. Pull the lens cap
string down and attach it to the grip
belt.
POWER switch
3 Slide the POWER switch until the
CAMERA lamp lights up.
Your camcorder is set to the standby mode.
Slide the POWER
switch while
pressing the green
button.
4 Press REC START/STOP.
Recording star ts. [REC] appears on the
LCD screen and the Camera recording l amp
lights up.
Press REC START/STOP aga in to st op
recording.
To turn the power off
Slide the POWER switch up to (CHG) OFF.
z Tip
• If you do not use your camcorder for a long tim e,
remove the ca ssette and stor e it.
Indicators displayed during recording
The indicators will not be recorded on the tape.
For TRV228E/428E:
123
6
60
min
SP
REC
4
0:00:00
5
Recording
,continued
Recording
21
Page 22
For TRV255E/265E:
Date/time and camera settings data (p. 37) will
not be displaye d du ri ng recording.
1237
60
min
SP
REC
0:00:00
5
A Remaining battery time
The indicated time may not be correct
depending on the environment of use.
When you opene d or closed t he LCD panel,
it takes about 1 minute to display th e correct
remaining battery time.
B Recording mode (SP or LP)
C Recording status ([STBY] (standby) or
[REC] (recor d i n g))
D Tape counter (hour: minute : se cond)
To set the counter to 0:00:00, press
COUNTER RESET (p. 92).
E Recording capacity
For TRV228E/428E:
This appears after you insert a cassette and
record for a while.
For TRV255E/265E:
This appear s af t er a whil e w hen you se t t he
POWER switch to CAMERA and insert a
cassette.
F Hi8 format
This appears while recording Hi8 format
tapes.
G Time code/Tape counter (hour: minute:
second)/Tape pho to recording
b Notes
• Before changing the bat tery pack , slide the POWER
switch up to (CHG) OFF.
• In the default setting, if you do not ope rate the
camcorder for more than ab out 5 minutes , the p ower
will automatically turn off to preserve battery power
([A.SHUT OFF], p. 59). To restart recording, slide
the POWER switch down to select CAMERA, and
then press REC STA RT/STOP.
z Tips
• To ensure smooth trans ition on a tape from the last
recorded scene to the next, note the following.
– Do not remove the cassette. (The picture will be
recorded continuously without a break even when
you turn the power off.)
– Do not record pictures in SP mode and LP mode on
the same tape.
– Avoid stopping then recording a movie in the LP
mode.
• For TRV255E/265E:
The recording time, date, and the camera settings
data are recorded automatic a lly on the tape without
being displayed on the screen. You can view this
information during playback by selecting [DATA
CODE] on the screen (p. 59).
Recording for a longer time
To record for a longer time
In the (TAPE SET) menu, select [REC
MODE], then [LP] (p. 54).
In the LP mode, you can r ecord longer than
when recording in the SP mo de (2 times longer
for TRV228E/428E, 1.5 times longer for
TRV255E/265E).
A tape recorded in the LP mode should be
played back only on t hi s c am corder.
22
Recording
Page 23
Using zoom
Using the built-in light
When the CAMERA mode is selected, you
can choose zoom to magnification levels
greater than 20 times, and from that point
activate the digi tal zoom ([D ZO OM] , p.47).
Occasional use of the zoom is effective, but
use it sparingly for best results.
1 cm (approx.
1/2 inch)*
* The minimum distance required between your
camcorder and the subject to get a sharp focus in
that position of the lever.
80 cm (approx.
2 5/8 feet)*
You can use the built-in light to suit your
shooting situation. The recommended
distance between the subject and camcorder
is about 1.5 m (5 feet).
Built-in light
Recording
LIGHT
Press LIGHT repeatedly to select a setting.
The settings are displayed cyclically in the
following orde r.
No indicator displayed: Always re cor ds
without using the buil t- i n light.
m
: Automatically turns on and off
according to the am bient brightness.
m
: Always turns on.
Move the power zoom lever slightly for a
slower zoom. Move it further for a faster
zoom.
To record wider ran g e of vi ew
Move the power zoom lever towards W.
The subject appears farther away (Wide
angle).
To record closer vie w
Move the power zoom lever towards T.
The subject appears closer (Telephot o ) .
To turn off the built-in light
Press LIGHT repeatedly until no indicator
appears on the sc reen.
b Notes
• The built-in video light emit s very br ight light,
which is perfectly safe in normal use. However,
avoid directly aiming the light at a subject’s eyes
from very close range.
• The battery pack discharges quickly while the builtin light is turned on.
• When you do not use your camcorder, turn the builtin light off and remove the battery pack to avoid
turning on the built-in light acc ide ntally.
• When flickering occurs whil e sho oting in the
mode, press LIGHT un til
appears.
,continued
Recording
23
Page 24
• The built-in light may turn on/o ff whe n you use the
[PROGRAM AE] or back light function while
shooting in the mode.
• For TRV255E/265E:
The built-in light is turned off during the interval
time of Interval recording.
• When you use the conversion lens (opt ional), light
from the built-in light is blocked and ma y not
illuminate the subject proper ly .
Recording in mirror mode
You can turn the LCD panel towards the
subject so that you and your subject can share
the image being recorded. You can also
utilize this function when recording yourself,
to keep the attention of small children
attracted to the camcorder while you record
them.
Open the LCD panel 90 degrees to the
camcorder, then rotate it 180 degrees
towards the subject.
A mirror-image of the subject appears on the
LCD screen, but the picture will be normal
when recorded.
24
b Notes
For TRV228E/428E:
• appears in the viewfinder and on the LCD
screen. Xz appears in the standby mode, and z
appears in the recording mode. Som e of oth er
indicators appear mirror-reversed and others are not
displayed.
• During recording in the mirror mo de , DATE and
TIME on your camcorder do not work.
Recording
Page 25
Superimposing the date and time
on pictures (
You can record the date and/or time
displayed on the s cre en s upe rim posed on the
picture.
TRV228E/428E)
Recording still
images
– Tape photo recording
(
TRV255E/265E)
You can record still images. Before
recording, follow steps 1 to 7 in “Getting
started” (p. 11 - p. 19).
PHOTOOPEN
Recording
DATE
CCD-TRV428E
Press DATE to record the date.
Press TIME to record the time.
Press DATE (or TIME), then press TIME
(or DATE) to record the date and time.
To hide the date and time, press DATE and/or
TIME again.
When you purchase your camcorder , the clock
is not set up yet. Set the date and time to your
local time before using (p. 17).
b Note
• The date and time indic a tor s r e corded manually
cannot be deleted.
z Tip
• If you do not record the date and time in the picture,
record the date and time in the black screen as the
background for about 10 seconds, then erase the date
and time indicators before starting actual recording.
TIME
POWER switch
1 Remove the lens cap. Pull the lens cap
string down and attach it to the grip
belt.
2 Press OPEN and open the LCD panel.
,continued
Recording
25
Page 26
3 Slide the POWER switch to select the
CAMERA mode.
Recording with ease
– Easy Handycam
Slide the POWER
switch while pressing
the green button.
4 Press and hold PHOTO lightly.
You will hear a sm al l b eep sound, and the
picture will become a still image.
Recordi n g does not s tart at this p oint.
60
min
CAPTURE
The indicator
appears.
5 Press PHOTO fully.
A shutter sound is heard, and the image is
recorded with sound for 7 seconds.
The still image is displayed on the screen
until recording is completed.
To turn the power off
Slide the POWER switch up to (CHG) OFF.
b Note
• appears when the tape photo recording does
not work.
z Tip
• You can record about 510 images in the SP mode
and about 765 images in the LP mode on a tape
which can record for 60 minutes in the SP mode.
With this Easy Handycam operation, most of
the camera settings are set to automatic
mode, only basic functio ns become available,
and screen font size increases for easy
viewing. Even first time users can enjoy easy
recording. Before recording, follow steps 1 to
7 in “Getting start ed” (p. 11 - p. 19).
Camera recording lamp
OPEN
z Tip
• Buttons that do not work during Easy Handycam
operation have a dot beside them on your camcorder.
Also, only menu items that are available during Easy
Handycam operation are displayed when MENU is
pressed.
EASY POWER switch
REC START/STOP
1 Remove the lens cap. Pull the lens cap
string down and attach it to the grip
belt.
2 Press OPEN and open the LCD panel.
3 Slide the POWER switch to select the
CAMERA mode.
You can record movies only.
26
4 Press EASY.
EASY lights up in blue.
Recording
Page 27
Easy Handycam
operation
ON
5 Press REC START/STOP.
Recording start s . [ REC] appears on the
LCD screen and the Camera recording lamp
lights up. Press REC START/STOP again
to stop recording.
Adjusting the exposure
The exposure is adjusted automatically in the
default setting.
Adjusting the exposur e for backlit subjects
To turn the power off
Slide the POWER switch up to (CHG) OFF.
To cancel Easy Handycam operation
Press EASY agai n.
b Notes
• You cannot switch from /to Easy Handycam
operation during recording.
• For TRV255E/265E:
During Easy Handycam operation, you cannot
connect the USB cable to your camcorder.
• For TRV255E/265E:
You cannot use Easy Handycam ope r ation together
with USB Streaming.
• All the settings return to their defaults dur ing Easy
Handycam operation. Previously made settings are
restored when you cancel Easy Handycam
operation.
When your subje ct has its back to the sun or
other light, you can adjust the exposure to
prevent the subject from becoming
shadowed.
BACK LIGHT
Press BACK LIGHT in CAMERA mode.
. appears.
To cancel the back light fun ct i on, press BACK
LIGHT again.
b Note
• The back light function is canceled when you press
EXPOSURE (p. 28).
Recording
,continued
Recording
27
Page 28
Adjusting the exposure manually
Recording in dark
You can fix the brightness of a picture at the
best exposure. When recording indoors on a
clear day, for instance, you can avoid
backlight shadow s on people next to the
window by manually fixing the exposure to
that of the wall side of the room.
EXPOSURE SEL/PUSH EXEC dial
1 Press EXPOSURE in CAMERA mode.
The exposure indicator appears on the
screen.
2 Turn the SEL/PUSH EXEC dial to
adjust the brightness.
places
– NightShot plus
You can record subjects in dark places (such
as when capturing the face of your baby
sleeping) with this function.
Set the NIGH TS HO T P LUS swi tch t o ON .
and [”NIGHTSHOT PLUS”] appear.
To cancel NightShot plus, set the NIGHTSHOT
PLUS switch to OFF.
While exposure is set to manual mode, is
displayed in the lef t- hand corner of the
screen.
To return the setting to automatic
exposure
Press EXPOSURE.
Recording
28
b Notes
• Do not use the NightShot plus function in bright
places. This may cause a malfunc ti o n.
• You cannot use the NightShot plus function together
with:
– [PROGRAM AE]
– Manual exposure
• Adjust the focus manually when it is hard to focus
automatically.
• Do not cover the infrared port with your f inger s or
other objects. Remove the conversion lens (optional)
if it is attached.
• Depending on the shooting conditions or
circumstances, colors may not be reproduced
properly.
Page 29
z Tip
• If you record subje c ts in c omplete darkness, set
[N.S. LIGHT] to [ O N ] in th e menu settings. The
maximum shooting distance using the NightShot
Light is about 3 meters (10 feet). If you r ecor d
subjects in dark places (such as night sc e ne or in
moonlight), set [N.S. LIGHT] to [OFF] in the menu
settings. You can make image c olor de e per ( p. 50 ).
Adjusting the focus manually
The focus is adjusted automatically in the
default setting.
You can adjust the focus manually according
to the recording conditions.
Use this function in the following cases.
– To record a subject behind a window covered
with raindrops.
– To record hor i zontal stripes.
– To record a subject with little contrast
between the subject and its backgroun d.
– When you want to focus on a subject in the
background.
– To record a stat ionary subject usi ng a tripod.
Recording
FOCUS
SEL/PUSH EXEC
dial
1 Press FOCUS in CAMERA mode.
9 appears.
2 Turn the SEL/PUSH EXEC dial to
sharpen focus.
9 changes to when the focus cannot be
adjusted any further.
when the focus cann ot be adjusted any
closer.
9 changes to
,continued
Recording
29
Page 30
Tips for focusing manually
• It is easier to focus on the subject when
you use the zoom fun ct io n. Move the
power zoom le ver towards T (telephoto)
to adjust the focus, and then, towards W
(wide angle) to ad j ust the zoom for
recording.
• When you want to record a cl ose-up
image of a subject, move the power zoom
lever towards W (wide angle) to fully
magnify the image, then adjust the focus.
To adjust the focus automatically
Press FOCUS again.
Recording a picture using various effects
FADER
SEL/PUSH EXEC dial
POWER switch
Fading in and out of a scene – FADER
You can add the following effects to
currently recording pictures.
[BLACK FADER]
[WHITE FADER]
[MOSAIC FADER]
30
Recording
Page 31
[STRIPE FADER]
This feature is for TRV228E/4 28E only.
[MONOTONE FADER]
When fading in, the pi ct ure gradually change s
from black-and-white to color.
When fading out, the picture gradually changes
from color to black-and-white.
Superimposing a title
You can insert a title when recording.
You can select one of the 8 preset titles and
the 2 custom titles.
TITLE
1 Slide the POWER switch to select the
CAMERA mode.
2 Press FADER until the desired fader
indicator flashes in the standby mode
(to fade in) or during recording (to
fade out).
BLACK
FADER
3 Press REC START/STOP.
The fader indicator stops flashing and
disappears when the fade is complete.
To cancel the operation
In step 2, press FAD ER repeatedly unti l the
indicator disa ppears.
b Notes
• For TRV255E/265E:
You cannot use the FADER functio n togethe r with:
– Tape photo recording
– [FRAME REC] (Frame recording)
– [INT.REC] (Interval recording)
• Titles do not fade in or fade out. The dat e a nd ti me
indicator for TRV228E/428E also does not
fade in or fade out.
Erase them before operating the FADER function if
they are not needed.
SEL/PUSH
EXEC dial
REC START/
STOP
1 Slide the POWER switch to select the
CAMERA mode, then press TITLE.
Select a desired tit l e from the displayed
titles (2 original titles th at you have create d
before and the pr eset titles that have been
stored in your camcorder). You can create
original titles (up to 2 types of ti tle of within
20 characters each) in the following
procedure.
1 Turn the SEL/PUSH EXEC dial to select
[CUSTOM1 ””] or [CUSTOM2””], then
press the dial.
TITLE
CUSTOM1""
[
TITLE] : END
2 Turn the SEL/PUSH EXEC dial to select
[CREATE/EDIT], then p ress the dial.
3 Turn the SEL/PUSH EXEC dial to select
the column of the desired character, then
press the dial.
STBY
OK
CREATE/ EDIT
Recording
,continued
Recording
31
Page 32
4 Turn the SEL/PUSH EXEC dial to select
the desired ch ar acter, then press t he dial.
STBY
12345
67890
АИМТЩ
БЙНУЪ
ВКФ
ГХСзЯ
ДПЦЬЕ
ƌ
P1
$ ¥
DM
£
¿
i ø ” :
[ C ]
[ cP2 ]
[ O K ]
TITLE SET
S_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
ABCDE
FGHIJ
KLMNO
PQRST
UVWXY
Z& ? !
’ . , / –
[
TITLE] : END
To erase a chara ct er : Se l ect [C].
To enter a space: Select [Z& ? !], then
select the blank part between & and ?.
To select alphabet and Russian
characters: Select [ ].
5 Turn the SEL/PUSH EXEC dial to select
the next characte r, and enter the chara cter
in the same manner.
6 When you have fin ished entering
characters, turn the SEL/PUSH EXEC
dial to select [O K ], then press the dial.
The title is stored in memory.
2 Turn the SEL/PUSH EXEC dial to
select the title you want to insert, then
press the dial.
To insert an original title, turn the SEL/
PUSH EXEC dial to select [CUSTOM1””]
or [CUSTOM2””], and press the dial, then
select [OK] and press the dial.
3 Change [COLOR], [SIZE], or
[POSITION] as necessary.
1 Turn the SEL/PUSH EXEC dial to select
[COLOR], [SIZE], or [POSITION], then
press the dial. The select ed item appears
on the screen.
2 Turn the SEL/PUSH EXEC dial to select
the desired ite m , the n pr ess the dial.
3 Repeat steps 1 and 2 until the title is laid
out as desired.
[COLOR] (color)
[WHITE] y [YELLOW] y
[VIOLET] y [RED] y [CYAN] y
[GREEN] y [BLUE]
[SIZE] (size)
[SMALL] y [LARGE]
(You can only select [SMALL] when
you are enterin g mo re than 13
characters.)
[POSITION] (position)
You can select fr om 8 t o 9 choices.
4 Turn the SEL/PUSH EXEC dial to
select [OK], then press the dial.
The title appears.
5 Press REC START/STOP.
6 Press TITLE at the scene you want to
erase the title off.
To superimpose the title while you are
recording
Press TITLE and carry out steps 2 to 4. Whe n
you press the SEL/PUSH EXEC dial at step 4,
the title is recorded.
b Notes
• If you display the menu while superimposing a title,
the title is not recorded while the menu is displayed.
• When you are selecting and setting the title, the title
displayed o n th e screen is not re corded.
• When you superimpose a tit le w hile you are
recording, the beep does not sound .
• When you are using your camcorde r on the battery
pack and do not operate it for 5 minutes, the powe r
automatically goes off as the de fault setting. If you
may take 5 minutes or longer to enter characters, set
[A.SHUT OFF] in the (OTHERS) menu to
[NEVER] (p. 59). The power will not to be turn off.
Even though the power goes off, the characters you
have entered remain stored in memory. Tur n the
power back on, then start again from st ep 1 to
continue superimposing the title.
• For TRV228E/428E:
The date and time, or either of them, may not be
displayed depending on the size or position of the
title.
z Tip
• To change a create d title, select the title in ste p 1.
Turn the SEL/PUSH EXEC dial to select [CREATE/
EDIT] and press the dial, then resel ect cha r act ers.
32
Recording
Page 33
Searching for the last
scene of the most
recent recording
– END SEARCH
This function is handy when you have played
back the tape, for example, but want t o st art
recording right after the most recently
recorded s cene. Th e END SEA RCH func tion
will not work once you eject th e cassette after
you have recorded on the tape.
Recording
END SEARCH
POWER
switch
1 Slide the POWER switch to select the
CAMERA mode.
2 Press END SEARCH.
The last scene of the most recent recording
is played back for about 5 seconds, and the
camcorder ente rs the standby mode at t he
point where the last recording has finished.
To cancel the operation
Press END SEARCH again.
b Note
• The END SEARCH function will not work correctly
when there is a blank section between recorded
sections on the tape.
z Tip
• When PLAY/ED IT mode is sel ected, you can do this
operation by pressing END SEARCH.
Recording
33
Page 34
Playback
Viewing pictures
3 Press (rewind) to go to the point
you want to view.
recorded on a tape
Make sure you have a reco r ded cassette
inserted into your camcorder.
When you want to play back th e recorded
picture on your TV, see page 39.
For TRV228E/428E/ TRV265E:
You can control playback using the Remote
Commander.
OPEN
z Tip
• Performing Easy Handycam operation, even firs t
time users can play back easily. For details, see
page 36.
POWER
switch
4 Press (play) to start playback.
To adjust the volume
Press either of the two buttons on VOLUME.
When you close the LCD panel, sound is turned
off.
: To turn the volume down
: To turn the volume up
To stop playback
Press (stop).
To pause
Press (pause) during playback. Press
(pause) or (play) to restart the
playback.
Playback stops automatically when pause mode
continues for a few minutes.
To fast forward or rewind
Press (fast forw ard) or (rewind) in
stop mode.
To review movies on the viewfinder
Close the LCD panel.
Indicators displayed during playing
back
For TRV228E/428E:
1 Press OPEN and open the LCD panel.
2 Slide the POWER switch repeatedly to
select the PLAY/EDIT mode.
Slide the POWER
switch while
pressing the green
button.
Playback
34
0:00:0060min
Page 35
For TRV255E/265E:
0:00:00:0060min
A Remaining battery time
B Recording mode (SP or LP)
C Tape transport indicator
D Tape counter (hour: minute: second)
E Hi8 format
This appears while playing back Hi8 format
tapes.
F Time code (h our: minute: se cond: frame)
or tape counter (hour: minute: second)
b Note
• For TRV255E/265E:
If you use a standard 8 mm tape, be sure to play
back the tape on your camcorder. Mosaic noise may
appear when you play back the standard 8 mm
tape on other camcorders (including an othe r DCRTRV255E/TRV265E).
To view pictures at slow speed (slow
playback)*
For TRV228E/428E/ TRV265E:
Press SLOW y on the Rem ote Com m ander
during play back. To resume norm al playback,
press PLAY.
* For TRV265E:
Pictures output from the DV Interface cannot be
played back smoothly in the slow mode.
b Notes
• For TRV228E/428E:
If slow playback lasts for about 1 minute, the
camcorder automatically returns to normal spee d
playback.
• For TRV228E/428E:
When you play back a tape recorded in the LP mode,
noise may appear on the LCD screen in the
following cases:
– Slow playback
– Playback pause
– Picture search
Playback
Playing back in various modes
To fast forward or rewind during
playback – Picture search
Keep on pressing (fast forward) or
(rewind) during playback.
To resume normal playback, release the button.
To view the picture while fast
forwarding or rewinding – Skip scan
Keep on pressing (fast forward) or
(rewind) while fast forwarding or rewinding the
tape.
To resume fast forwar ding or rewinding, r elease
the button.
Playback
35
Page 36
Playing back with
ease
– Easy Handycam
Easy Handycam operation allows easy
playback for even first time us ers by
providing only the basic functions for
playback. Also screen font size increases for
easy viewing. Make sure you have a recorded
cassette inserted into your camcorder.
EASY
4 Play back a tape.
The following buttons can be operated.
(play)/ (stop)/ (pause)/
(fast forward)/ (rewind)
For TRV228E/428E/ TRV265E:
You can operate those operations and
SLOW y on the Remote Commander.
To cancel Easy Handycam operation
Press EASY again.
b Notes
For TRV255E/265E:
• During Easy Handycam operation, you cannot
connect the USB cable to your camcord er.
• You cannot use Easy Handycam operation together
with USB Streaming.
OPEN
z Tip
• Buttons that do not work during Easy Handycam
operation have a dot beside them on your camcorder.
Also, only menu items that are available during Easy
Handycam operation are displayed when MENU is
pressed.
POWER switch
1 Press OPEN and open the LCD panel.
2 Slide the POWER switch repeatedly to
select the PLAY/EDIT mode.
3 Press EASY.
EASY lights up in blue.
Easy Handycam
operation
ON
Playback
36
Page 37
Various playback functions
Displaying the date/time and
camera settings data – Data code
(
TRV255E/265E)
You can display the recorded date on the
screen.
DSPL/BATT INFO
MENU SEL/PUSH
POWER switch
EXEC dial
Displaying the screen indicators
You can choose to display the time code, tape
counter, and other information on the screen.
Press DSPL/BATT INFO.
The indicators appear/disappear as you press the
button.
z Tips
• For TRV228E/428E/ TRV265E:
You can display the screen ind ic ato rs by pr es sing
DISPLAY on the Remote Commander.
• You can display the sc r een indicators during
playback on a TV. Select the (OTHERS) menu,
[DISPLAY], then [V-OUT/LCD] (p. 60).
During playback, you ca n view the date /time
data ([DATE/TIME]) and the camera settings
data ([CAM DATA]) that are automatically
recorded while recording pictures on a tape.
1 Slide the POWER switch repeatedly to
select the PLAY/EDIT mode.
2 Press MENU during playback or
playback pause.
3 Turn the SEL/PUSH EXEC dial to
select (OTHERS), then press the
dial.
4 Turn the SEL/PUSH EXEC dial to
select [DATA CODE], then press the
dial.
OTHERS
DATA CODE
WORLD TIME
BEEP
A. SHUT OFF
COMMANDER
DISPLAY
VIDEO EDIT
RETURN
[MENU] : END
OFF
DATE/TIME
CAM DATA
5 Turn the SEL/PUSH EXEC dial to
select the [DATE/TIME] or [CAM
DATA], then press the dial.
6 Press MENU.
60
0:00:00:00
min
Playback
1 1 2004
12:17:50
,continued
Playback
37
Page 38
To hide the date/time or the camera
settings data
Follow steps 2 to 4, and select [OFF] in step 5.
Camera settings data display
In the date/time data display, the date and time
is displayed in the same area.
If you record the picture without setting the
clock, [-- -- ----] and [--:--:--] will appear.
60
min
A SteadyShot off
B Exposure
C White ba l ance
D Gain
E Shutter speed
F Aperture value
0:00:00:00
AUTO
100 AWB
F1.6
9
1
2
3
dB
4
5
6
38
Playback
Page 39
Playing the picture on a TV
For TRV228E/428E:
A/V OUT jack
Connect your camcorder to a TV using the
supplied A/V connecting cable as shown in
the following illustration.
Connect the supplied AC Adaptor to the wall
socket for the power supply (p. 12).
Refer also to the instruction manuals supplied
with the devices to be connected.
To copy to another tape, see page 63.
Yellow
Playback
Black
Signal flow
For TRV255E/265E:
A/V OUT jack
Signal flow
A/V connecting cable (supplied)
A/V connecting cable (supplied)
Yellow
White
Red
VCRs or TVs
VCRs or TVs
,continued
Playback
39
Page 40
* Pictures can be reproduced more faithfully by using
an S video cable (optional ). When there is an S vi deo
jack on the device to be connected, connecting the S
video cable (optional) to the S vide o ja c ks on both
your camcorder and the device instea d of using the
yellow plug is recommended.
The audio will not be output when you connect with
the S video plug alone.
Locating a scene on a
tape for playback
( TRV265E)
When your TV is connected to a VCR
Connect your camcorder to the LINE IN input
on the VCR using the A/V connecting cable. Set
the input selecto r o n the VCR to LINE.
To connect to a TV without audio/video
input jacks
For TRV228E/428E:
Use a PAL system RFU adaptor (optional).
Refer to the operating instruction s of your TV
and the RFU adapto r.
When your TV is stereo
For TRV228E/428E:
Connect the audio plug of the A/V connecting
cable to the left (white) input jack of your TV.
When your TV is monaural (When your
TV has only one audio input jack)
For TRV255E/265E:
Connect the y el lo w plu g of th e A/ V co nn e cti ng
cable to the video in put jack and connect the
white or the red pl ug to the audio input jack of
your TV or VCR.
When you want to pla y the sound in monaural
mode, use a connecting cable ( optional) f or that
purpose.
If your TV/VCR has a 21-pin connector
(EUROCONNECTOR)
Use the 21-pin adaptor supplied with your
camcorder (For models with the mark
printed on their bo ttom surfaces only). This
adaptor is designed for output use only.
For TRV228E/428E:
TV/VCR
For TRV255E/265E:
TV/VCR
Searching quickly for a desired scene – Zero set memory
m REW
PLAY
STOP
DISPLAY
ZERO SET MEMORY
1 During playback, press ZERO SET
MEMORY on the Remote
Commander at the point you want to
locate later on.
The tape counter is reset to “0:00:00” and
appears on the sc reen.
If the tape counter is not displayed, press
DISPLAY on the Remote Commander.
2 Press STOP when you want to stop
playback.
3 Press m REW.
The tape stops automatically wh en the t ape
counter reaches “0:00:00.”
4 Press PLAY.
The playback star ts fr om the point
designated “0:0 0: 00” on the tape counter .
To cancel the operation
Press ZERO SET MEMORY on the Remote
Commander agai n.
40
Playback
Page 41
b Notes
• There may be a discrepa nc y of sever a l seconds
between the time code and the tape counter.
• Zero set memory will not function correctly if there
is a blank section between recorded sect ions on the
tape.
Searching for a scene by date of recording – Date search
You can locate the point where the recording
date changes.
SEARCH M.
. / >
STOP
1 Slide the POWER sw itch re peate dly to
select the PLAY/EDIT mode.
2 Press SEARCH M. on the Remote
Commander repeatedly to select
[DATE SEARCH].
3 Press . (previous)/> (next) on
the Remote Commander to select a
recording date.
Playback starts automatically from the
point where the date changes.
Each time you press the bu tton, the previous
or the next date will be searched for and
displayed.
To cancel the operation
Press STOP on the Remote Commander.
b Notes
• If one day’s recording is less than 2 minutes, your
camcorder may not accurately find the poi n t whe re
the recording date changes.
• The Date search will not function correctly when
there is a blank section between recorded sections on
the tape.
Searching for a still image – Photo search
You can locate the still image you have
recorded on a tape.
SEARCH M.
. / >
STOP
1 Slide the POWER switch repeatedly to
select the PLAY/EDIT mode.
2 Press SEARCH M. on the Remote
Commander repeatedly to select
[PHOTO SEARCH].
3 Press . (previous)/> (next) on
the Remote Commander to select the
photo for playback.
Playback of the photo starts automatically.
Each time you press the button, the previous
or the next photo will be searched for and
displayed.
To cancel the operation
Press STOP on the Remote Commander.
b Note
• If a tape has a blank section between recorded
sections, the Photo search func tion may not work
correctly.
Playback
,continued
Playback
41
Page 42
Playing back still images in sequence – Photo scan
You can also locate still images one after
another and display each image for 5 seconds
automatically.
SEARCH M.
. / >
STOP
1 Slide the POWER switch repeatedly to
select the PLAY/EDIT mode.
2 Press SEARCH M. on the Remote
Commander repeatedly to select
[PHOTO SCAN].
3 Press . (previous)/> (next) on
the Remote Commander.
Each photo will be played back for about 5
seconds.
To cancel the operation
Press STOP on the Remote Commander.
b Note
• If a tape has a blank section between recorded
sections, the Photo scan function ma y not work
correctly.
Playback
42
Page 43
B
Advanced operations
Customizing Your Camcorder
Changing the menu settings
OTHERS (p. 59)
TAPE SET
REC MODE
AUDIO MODE
REMAIN
FRAME REC
IN T. REC
RETURN
[
SP
MENU] : END
STBY
You can change various settings or make
detailed adjustments using the menu items
displayed on the screen.
MENU
POWER switchSEL/PUSH EXEC dial
1 Turn on the power (p. 15).
2 Press MENU.
The menu scree n appears.
MANUAL SET
PROGRAM AE
P EFFECT
AUTO SHTR
[
MENU] : END
STBY
3 Turn the SEL/PUSH EXEC dial to
select desired menu, then press the
dial.
MANUAL SET (p. 44)
CAMERA SET (p. 47)
PLAYER SET (p. 51) (
TRV228E/428E/ TRV255E)
VCR SET (p. 51) ( TRV265E)
LCD SET (p. 53)
TAPE SET (p. 54)
SETUP MENU (p. 57)
4 Turn the SEL/PUSH EXEC dial to
select the desired item, then press the
dial.
The available menu i t em s var y de pending
on the position of the POWER switch.
Unavailable items will be grayed out.
TAPE SET
REC MODE
AUDIO MODE
REMAIN
FRAME REC
IN T. REC
RETURN
[
MENU] : END
AUTO
ON
STBY
5 Turn the SEL/PUSH EXEC dial to
select the desired mode, then press the
dial.
TAPE SET
REC MODE
AUDIO MODE
REMAIN
FRAME REC
IN T. REC
RETURN
[
MENU] : END
STBY
ON
6 Press MENU to hide the menu screen.
If you want to change other items, select
[ RETURN] an d press the dial, then
repeat steps from 3 to 5.
Customizing Your Camcorder
Customizing Your Camcorder
43
Page 44
Using the
(MANUAL SET) menu
– PROGRAM AE/P EFFECT, etc.
You can select items listed below in the
MANUAL SET menu. To select these items,
see “Changing the menu settings” (p. 43).
PROGRAM AE
You can record pic tures easily in a situat ion that requires vari ous techniques by
selecting the following settings.
G AUTO Select this when not using PROGRAM AE.
SPOTLIGHT*
(spotlight) ( )
Select to prevent people’s f ace s from appearing
excessively white when subje cts are lit by s trong
light, such as in a theater or at a wedding.
The default settings are marked with G. The
settings you can adjust vary depending on the
power mode of your camcorder. The screen
shows the items you can operate at the moment .
Unavailable item s w ill be grayed out.
MANUAL SET
PROGRAM AE
P EFFECT
AUTO SHTR
[
MENU] : END
PORTRAIT (soft
portrait) ( )
SPORTS* (sports
lesson) ( )
BEACH&SKI*
(beach & ski) ( )
SUNSETMOON
** (sunset &
moon) ( )
LANDSCAPE**
(landscape) ( )
* Your camcorder is adjusted to focus only on subjects in the middle to far distance.
Select to bring out the subject suc h a s pe ople or
flowers while creating a soft background.
Select to minimize shake when shooting fastmoving subjects such as in tennis or golf.
Select to prevent people’s f ace s from appearing
dark in strong light or reflected light, such as at a
beach in midsummer or on a ski slope .
Select to maintain the a tmosphere of situations
such as sunsets, general night vi ews , fir e works,
and neon signs.
Select when shooting distant subjects such as
mountains. This set ting also prevents your
camcorder from focusing on glass or metal m esh
in windows that comes i n between the camco rder
and the subject.
Customizing Your Camcorder
44
Page 45
P EFFECT
**Your camcorder is adjuste d to fo cu s o nly on di stan t subjects.
Note
b
• When you set the NIGHTSHOT PLUS switch to ON, [PROGRAM AE] does not work.
(The indicator flashes.)
For TRV228E/428E:
You can add special effects (such as fi lm s) to a picture before recording.
appears when each effect is selected.
For TRV255E/265E:
You can add spec i a l effects (such as fi lms) to a picture before or after recording.
appears when each effect is selected.
GOFF Select when not using the Picture effect setting.
NEG.ART Select to record/play the picture with the color
SEPIA Select to record/play the pi cture appearing in sepia.
B&W Select to record/play th e picture appearing in monochrom e (b lack-
SOLARIZE Select to record/play the picture looking like an
and brightness of the picture reverse d.
and-white).
illustration with strong contrast.
Customizing Your Camcorder
SLIM Select to reco rd th e picture appearing vertically
expanded. (This effect is not availab le dur ing
playback.)
STRETCH Select to record the picture appe aring
horizontally expanded. (Thi s effe ct is not
available during playback.)
PASTEL Select to record the picture lo o ki n g like a pa le
pastel drawing. (This effect is not available
during playback.)
MOSAIC Select to record the picture appearing mosaic-
patterned. (This effect is not available during
playback.)
b Note
• For TRV255E/265E:
You cannot add effects to externally input pictures. Also, you cannot output pictures edited
with Picture effects via the DV Interface.
,continued
Customizing Your Camcorder
45
Page 46
AUTO SHTR
z Tip
• For TRV255E/265E:
You can copy pictures edited using pict ur e ef fec ts to anot he r tape ( p. 63).
GON Select to automatically activate the elect ronic shutter to adjust th e
OFF Select when recor ding without using the electr onic shutter.
shutter speed when recordin g in bright conditions.
Customizing Your Camcorder
46
Page 47
Using the
(CAMERA SET) menu
– 16:9 WIDE/STEADYSHOT, etc.
You can select items listed below in the
CAMERA SET menu. To select these items, see
“Changing the menu settings” (p. 43).
D ZOOM
You can select the maximum zoom level in case you want to zoom to a level
greater than 20 times while recording on a tape. Note that the image quality
decreases when you are using the digita l zoom. This function is use ful when
recording enla rged pictures of a distant subject, such as a bird.
The right side of the bar shows the digital
zooming zone.
The zooming zone appears when you select
the zooming level.
The default settings are marked with G. The
settings you can ad just vary depending on the
power mode of your camcorder. The screen
shows the items you can operate at the moment.
Unavailable items will be grayed out.
CAMERA SET
D ZOOM
1 6 : 9WI DE
STEADYSHOT
N. S. LIGHT
[
MENU] : END
Customizing Your Camcorder
GOFF Select to deactivate the digital zoom. U p to 20 times zoom is
performed optically.
40 × Select to activate the digital zoom. 20 times through 40 times zoom is
performed digitally.
990 × Select to activate the digital zoom. 20 times through 990 times zoom
is performed digitally.
,continued
Customizing Your Camcorder
47
Page 48
16:9 WIDE
For TRV228E/428E:
You can record a ci nema-like picture ([CI N EMA] mode) or a 16:9 w i de picture
([16:9 FULL] mode) to watch on the 16:9 wide-screen TV.
Refer also to the manuals supplied with y our TV.
In [CINEM A ] m ode
When viewed on the LCD screen/viewfinder
When viewed on a 16:9 wide screen TV*
When viewed on a standard TV**
In [16:9 FULL] mode
When viewed on the LCD screen/viewfinder
Customizing Your Camcorder
48
When view ed on a 16:9 wide screen TV*
When viewed on a standard TV**
* Picture appears in full screen when the wi de-screen TV switches to full mode.
**Played in 4:3 mode. When you play a picture in the wide mode, it appears as you have seen
on the LCD screen or in the viewfinder.
GOFF Standard setting (to reco rd pictur e s to play ba ck on a 4:3 TV). The
recorded picture will not be wide.
CINEMA ( ) Select to record a picture to be played back in CINEMA mode.
16:9 FULL ( ) Select to record a picture to be played back on a 16:9 wide TV.
Page 49
z Tips
• When you record in the [16:9 FULL], the da te or time indi ca tor will be widened on widescreen TVs.
•For TRV428E:
The SteadyShot does not work. If you set [16:9 FUL L ] in the me nu se ttings when the
SteadyShot is working, flashes and the SteadyShot does not function.
For TRV255E/265E:
You can record a 16:9 wide picture on the tape to watch on a 16:9 wide-screen TV
([16:9 WIDE] mode).
With this function [ON], your camcorde r offers even wider ang le s w hen you
move the power zoom lever to the “W” side than recording in [OFF].
Refer also to the manuals supplied with your TV.
When viewed on the LCD screen
When viewed on a 16:9 wide screen TV*
When viewed on a standard TV**
Customizing Your Camcorder
* Picture appears in full screen when the wide-screen TV switches to full mode.
**In 4:3 mode. When you play a picture in the wide mode, it appears as you have seen on the
LCD screen.
GOFF Standard setting (to record pictur es to pla y back on a 4:3 TV). The
ON ( ) Select to record a picture to be played back on a 16:9 wide TV.
Tip
z
• The SteadyShot does not work. If you set [16:9 WIDE] to [ON] in the menu settings when
the SteadyShot is working flashes and the SteadyShot does not function.
recorded picture will not be wide.
,continued
Customizing Your Camcorder
49
Page 50
STEADYSHOT
N.S. LIGHT
For TRV428E/ TRV255E/265E:
You can se lect this fun ction to com pensate for camera-shake.
GON Standard setting (enable the SteadyShot function). If you select a
function that STEADYSHOT cannot work with, appears.
OFF ( ) Select to deactivate the SteadyShot function.
Select to shoot a stationary subje ct with a tripod, or when using a
conversion lens (optional). Natur a l pictur e s are pr oduc e d.
b Note
• For TRV255E/265E:
Camera-shake cannot be completely compe nsated for in the following ca se s:
– When rec ording in a dark place
– When recording a subject with little co ntr ast to the background
– When recording horizontal stripes
– When using the zoom
– When recording a fast moving subject
– When the zoom position is set to the W-end side
When using the NightShot plus function to record, you can record clearer pictures
by using the NightS hot Light to emit infrared rays (invisible).
GON Select to use the NightShot Light. (p. 28)
OFF Select to disable the NightShot Light . (p. 28 )
Customizing Your Camcorder
50
Page 51
Using the (PLAYER
SET)/
menu
(VCR SET)
– HiFi SOUND/EDIT, etc.
items, see “Changing the menu setting s”
(p. 43).
The default settings are marked with
G. The
settings you ca n adjust vary dependi ng on the
power mode of your camcor der.
shows the items you can operate at the moment.
Unavailable items will be grayed out.
The screen
You can select the items listed below in the
menu (the PLAYER SET menu for
TRV228E/428E/ TRV255E, the VCR
SET menu for TRV265E.) To select these
HiFi SOUND
For TRV255E/265E:
You can select how to play back audio recorded on a tape in stereo mode.
GSTEREO Select to play back a stereo tape or dual sound track tape with main
and sub sound.
1 Select to play back a stereo tape with the left channel sound or a dual
sound track tape with main sound.
2 Select to play back a stereo tape with the right channel sound or a dual
sound track tape with sub sound.
b Notes
• You can playback a dual sound track ca sse tte on this camcorder. However, you cannot
record a dual sound track on this camcorder.
• The setting returns to [STEREO ] when you disconne c t the powe r sour c e from your
camcorder for more than 5 minutes.
EDIT
For TRV228E/428E:
Picture degradation is minimized whe n you dub or edit a tape using the camcorder
as the playback devi ce.
GOFF Select this for no compensation.
ON Select to minimize picture degradation.
VCR SET
HiFi SOUND
AUDIO MIX
[
MENU] : END
Customizing Your Camcorder
b Note
• The setting returns to [OFF] when you disconnect the power source from your camcorder
for more than 5 minutes.
,continued
Customizing Your Camcorder
51
Page 52
TBC
DNR
AUDIO MIX
For TRV228E/428E:
GON Select to correct jitter (horizontal picture shake during playback).
OFF Select to not compensate picture distortion when playing back a tape
on which you have dubbed repeatedly or reco rd ed TV game signals.
For TRV228E/428E:
GON Select to eliminate color noise in the picture.
OFF Select to minimize picture art i facts in a picture containing lots of
movement.
For TRV255E/265E:
You can adjust the audio balance between ST1 (the originally recorded sound)
and ST2.
b Notes
• You cannot adjust sound recorded in 16 bit audio mode.
• Only the originally record ed sound wil l be hear d when you disc onnect the power source
from your camcorder for more than 5 minutes.
Customizing Your Camcorder
52
Page 53
Using the (LCD
SET) menu
COLOR, etc.
You can select the items listed below in the
LCD SET menu. To select these items, see
“Changing the menu settings” (p. 43).
LCD BRIGHT
– LCD B.L./LCD
See page 16 for details.
The default settings are marked with G. The
settings you ca n adjust vary dependi ng on the
power mode of your camcor der.
The screen
shows the items you can operate at the moment.
Unavailable items will be grayed out.
LCD SET
LCD BRIGHT
LCD B. L.
LCD COLOR
[
MENU] : END
LCD B.L.
LCD COLOR
You can adjust the brightness of the LCD screen’s backlight. The recorded picture
will not be affected by this setting.
GBRT NORMAL Standard brightness.
BRIGHT Select to brighten the LCD screen.
b Notes
• When you connect your camcorder to outside power sources, [BRIGHT] is automatically
selected for the setting.
• When you select [BRIGHT], battery life is reduced by about 10 percent during recording.
Turn the SEL/PUSH EXEC dial to adjust the color on the LCD screen. The
recorded pict ure will not be affected by this setting.
Low intensity
High intensity
Customizing Your Camcorder
Customizing Your Camcorder
53
Page 54
Using the (TAPE
SET) menu
INT.REC, etc.
You can select items listed below in the TAPE
SET menu. To select items, see “Changing the
menu settings” (p. 43).
The default settings are marked with G. The
settings you can adj ust vary depending on the
REC MODE
– FRAME REC/
GSP ( SP ) Select to record in the SP (Standard Play) mode on a cassette.
LP ( LP ) Select to increase the recording time from that of the SP mode (2 times
longer for TRV228E/428E, 1.5 times longer for TRV255E/
265E) (Long Play). The use of Sony cassettes is recommended to get
the most out of your camcorder.
b Notes
• If you record in the LP mode, a mosaic-like noise may appear or sound may be interrupted
when you play back the tape on other camcorders or VCRs.
• For TRV228E/428E:
When you record a tape in the LP mode on your camcorder, recording is carried out in the
standard 8 mm system.
• For TRV255E/265E:
When you mix recordings in the SP mode and in the LP mode on one tape, the playback
picture may be distorted or the time code may not be written properly between the scenes.
power mode of your camcorder. The screen
shows the items you can operate at the moment .
Unavailable item s w ill be grayed out.
TAPE SET
REC MODE
AUDIO MODE
REMAIN
FRAME REC
INT. REC
[
MENU] : END
AUDIO MODE
ORC TO SET
Customizing Your Camcorder
54
For TRV255E/265E:
G12BIT Select to record in the 12-bit mode (2 stereo sounds).
16BIT ( ) Select to record in the 16-bit mode (1 stereo sound with high quality).
For TRV228E/428E:
You can automatically adjust the recording condition to get the best possible
recording.
When you select [ORC TO SET] in the menu settings, [START/STOP KEY]
appears. Press REC START/STOP. [ORC] appears on the screen and adjustment
starts. Your camcorder returns to the stand by mode when adjustment is complete.
It takes about 10 seconds for adjustment.
b Notes
• Each time you eject a cassette, this setting will be canceled.
Page 55
REMAIN
• When you set [ORC TO SET], a non-recorded section of about 0.1 second appears on the
tape. However, note that this non-re corde d se c tion disappears from the tape when you
continue recording from this secti on.
• To check if you have already set th is se tt ing, select [ORC TO SET] in the menu settings .
[ORC ON] is displayed if it is already set .
FRAME REC
GAUTO Select to display the remaining tape bar:
• For about 8 seconds after you turn on your camcorder with the
cassette inserted, and your cam c or de r cal cu la te s the rem ai ning
amount of tape.
• For about 8 seconds afte r (play) is pre sse d.
• For about 8 seconds after DSPL/BATT INFO is pressed to display
the screen indicators.
• For the period of tape rewinding, forwa r ding or picture search.
ON Select to always display the remaining tape indicator.
Customizing Your Camcorder
For TRV255E/265E:
You can record pict ur es with a stop-motion animated effect by alter nately frame
recording and then moving the subject a little.
For TRV265E:
Operate your camcorder using the Remot e Commander to prev ent camera shake.
GOFF Select to record in the standard recording mode.
ON Select to record pictures using the fra m e rec or di ng f unc tion.
1 Tu rn the SEL/PUS H EXEC d ial to select [ON], then
press the dial.
2 P ress MENU to hide the menu settings.
lights up.
3 Press REC START/STOP.
A picture (approximately 5 frames) is recorded, and your
camcorder enters the standby mode.
4 Move the subject and repeat step 3.
b Notes
• When you use frame recording continuously, the remaining tape time will not be indicated
correctly.
• The last scene will be longer than other scenes.
,continued
Customizing Your Camcorder
55
Page 56
INT.REC
For TRV255E/265E:
You can achieve excellent recording s of fl ow ers blooming, etc., wit h t hi s
function. Connect your camcorder to the wall socket using the supplied AC
Adaptor during the operation.
[a] [a] [a]
[b]
a. [REC TIME]
b. [INTERVAL]
[b]
1 Tu rn the SEL/PUSH EXEC dia l to select [SET], then press the dial.
2 Tu rn the S EL/PUS H EXEC dia l to select [INTERVAL], then press the
dial.
3 Turn the SEL/PUSH EXEC dial to select the desired interval time
(30 seconds, 1, 5, 10 minutes), then pre ss the dial.
4 Tu rn the SEL/PUSH EXEC dia l to select [REC TIME], then press the
dial.
5 Turn the SEL/PUSH EXEC dial to select the desired recordin g time
(0.5, 1, 1.5, 2 seconds), then press the dial.
6 Turn the SEL/PUSH EXEC dial to select [ RETURN], then press the
dial.
7 Tu rn the SEL/PUSH EXEC dia l to select [ON], then press the dial.
8 Press MENU to hide the menu settings.
flashes.
9 Pr ess REC START /STOP.
The interval recording starts.
lights up during int er v al recording.
To cancel recording, set to [OFF] in the menu settings.
b Note
• There may be a discrepancy in recording time of up to ± 5 frames from th e selected time.
Tips
z
• If you adjust the focus manually, you may be able to record clear pictures even if the light
changes (p. 29).
• You can silence the beeps during r e cordi ng ( p. 59 ).
Customizing Your Camcorder
56
Page 57
Using the (SETUP
MENU)
LANGUAGE, etc.
You can selec t items l isted below in the SETU P
MENU. To select items, see “Changing the
menu settings” (p. 43).
CLOCK SET
– CLOCK SET/USB STREAM/
You can set the date and time (p. 17).
The default settings are marked with G. The
settings you ca n adjust vary dependi ng on the
power mode of your camcor der.
The screen
shows the items you can operate at the moment.
Unavailable items will be grayed out.
SETUP MENU
CLOCK SET
USB STREAM
LTR SIZE
LANGUAGE
DEMO MODE
[
MENU] : END
AUTO DATE
USB STREAM
LTR SIZE
Customizing Your Camcorder
For TRV228E/428E:
You can automatically record th e date once a day for 10 se conds after you start
recording.
GON Select to record the date for 10 seconds after recording ha s sta r te d.
OFF Select to cancel the aut o da te function.
z Tip
• The auto date function automatically displays the date once a day. However, the date may
automaticall y appear more than once a day if:
– you set the date and time.
– you eject an d in sert the tape again.
– you stop recording within 10 seconds.
– you set [AUTO DATE] to [OF F ] onc e and set it back to [ON] in the menu sett ings.
For TRV255E/265E:
You can conn ec t a USB cabl e (su ppl ied ) to you r c amcor de r, an d vi ew t he pi ct ure
displayed on the screen of your camcorder on your comput er (USB Streaming ).
For details, refer to the “Computer Applications Guide.”
GOFF Select to deactivate the USB Streaming function.
ON Select to activate the USB Streaming function.
GNORMAL Select to display se lected menu items in norma l size.
2× Select to display select ed menu items at twice the normal hei ght.
,continued
Customizing Your Camcorder
57
Page 58
LANGUAGE
DEMO MOD E
You can select or change the language used for the on-screen display (p. 19). You
can select from English, Simplified English, Traditional-Chinese, SimplifiedChinese, French, Spanish, Portuguese, G erman, Dutch, Italian, Greek, Russian,
Arabic, or Persian.
When you remove a cassette from your camcorder, and select the CAMERA
mode, you can view the demonstration in about 10 minutes.
GON Select to see an over view of the fu ncti ons a vailabl e such as when y ou
OFF Select when you do not intend to use the [DEMO MODE].
b Note
• You can view the demonstration only when the NIGHTSHOT PLUS switch is set to OFF.
z
Tips
• The demonstration will be suspe nde d in si tua ti ons such as those described below.
– When a cassette is inse r ted.
– When a mode other than CAMERA is selected.
• If [A.SHUT OFF] is se t to [ 5 min] when the camcorder is us ed on the battery pack, the
power will be turned off after approxima te ly 5 mi nutes (p. 59).
are using this camcorder for the first time.
Customizing Your Camcorder
58
Page 59
Using the
(OTHERS) menu
TIME/VIDEO EDIT, etc.
You can select items listed below in the
OTHERS menu. T o select items, see “Chan ging
the menu settings ” ( p . 43).
The default settings are marked with G. The
settings you ca n adjust vary depend i ng on the
DATA CODE
For TRV255E/265E:
GOFF Select not to display da te, time and the camera settings data during
DATE/TIME Select to displa y the dat e and time during playback. (p. 37)
CAM DATA Select to display the camera setting data during playback. (p. 37)
WORLD TIME
You can adjust the t i m e difference when using your camcorde r ab road. Set the
time difference by turning the SEL/PUSH EXEC dial, the clock will be adjusted
in accordance with the time difference. If you set the time difference to 0, the
clock returns to the originally set time.
– WORLD
playback.
power mode of your camcorder. The screen
shows the items you can operate at the moment.
Unavailable items will be grayed out.
OTHERS
WORLD TIME
BEEP
A. SHUT OFF
COMMANDER
DISPLAY
REC LAMP
[
MENU] : END
Customizing Your Camcorder
BEEP
A.SHUT OFF
GMELODY Select to play a mel ody whe n you st art/stop recording, operate your
camcorder with the SEL/PUSH EXEC dial , or when an unus ua l
condition occurs on your camcorder.
NORMAL Select to sound a beep instead of the melody.
OFF Select to cancel the melody, beep sound, shutter sound and operation
confirmation beep.
G5 min Select to activate the Auto shut off. When approximately 5 minutes
have elapsed while you do not operate your camcorder, the camcorder
is automatically turned off to preve nt th e battery from becoming
consumed.
NEVER Select to deactivate the Au to sh u t of f.
,continued
Customizing Your Camcorder
59
Page 60
COMMANDER
DISPLAY
b Note
• When you connect y our cam corder to t he wa ll s ocket , [ A.SHUT OF F] is auto mati cally se t
to [NEVER].
For TRV228E/428E/ TRV265E:
GON Select when using the Remote Commander supplied with your
camcorder.
OFF Select to deactivate the Re mote Commander to prevent your
camcorder from responding to a com ma nd se nt by another VCR
remote control unit.
b Note
• The setting returns to [ON] when you have the power source disconnected from your
camcorder for more than 5 minutes.
REC LAMP
VIDEO EDIT
GLCD Select to show the displays such as the time code on the LCD screen
and in the viewfinder.
V-OUT/LCD Sele ct to show the displays such as the time code on the TV scr een ,
LCD screen, and in the viewfinder.
GON Select to turn on the camera recording lamp on the front of your
camcorder during recording.
OFF Select this setting in the following recording situa tions. The camera
recording lamp will not light up dur i ng rec o rd ing.
• When you do not want the subject to be nervou s abo ut be ing
recorded.
• When you are recording close to the su b j ect.
• When the subject reflects th e re cord i ng la mp.
For TRV255E/265E:
You can select up to 20 scenes (programs) and record them in the desired order to
another recording device such as VCR (p. 68).
Customizing Your Camcorder
60
Page 61
Dubbing/Editing
Connecting to a VCR
For TRV228E/428E:
A/V OUT jack
You can create a copy of the picture recorded
on your camcorder on other recording
devices (p. 63).
For TRV265E, you can also record the
picture from a VCR to a tape on your
camcorder (p. 68).
Connect your camcorder to a VCR as shown
in the following illustration.
Dubbing/Editing
Yellow
A/V connecting cable (supplied)
Signal flow
Black
VCRs
,continued
Dubbing/Editing
61
Page 62
For TRV255E/265E:
A/V OUT jack
Connecting with an i.LINK cable
i.LINK cable (optional)
i.LINK jack
DV Interface
Yellow
A/V connecting cable (supplied)
Signal flow
* Pictures can be reproduced more faithfully by using
an S video cable (optional ). When there is an S vi deo
jack on the device to be connected, connecting the S
video cable (optional) to the S vide o ja c ks on both
your camcorder and the device instea d of using the
yellow plug is recommended.
The audio will not be output when you connect with
the S video plug alone.
**For TRV255E:
Your camcorder does not accept input data from the
connected device. It can only output data from the
DV Interface.
b Notes
• Use the A/V connecting cable to con n ect your
camcorder to other devices. Bef or e conne c ting,
make sure the [DISPLAY ] setting in the
(OTHERS) menu is set to [LCD] (the default
setting) (p. 60).
• For TRV228E/428E:
When you are connecting your camco rd er to st ereo
device, connect the audio plug of the A/V
connecting cable to the l eft (white) j ack on the VCR .
White
VCRs
Red
• For TRV255E/265E:
When you are connecting your camcorder to
monaural device, connect the yellow plug of the
A/V connecting cable to the video jack, and the red
(right channel) or the white (left channel) plug to the
audio jack on the VCR.
To use an i.LINK cable for connection
For TRV265E:
Use an i.LINK cable (optional) to connect your
camcorder to ot her devi ce via the DV Int erface .
The video and sound signals are transmitted
digitally, producing high quality pictures. Note
that you cannot record the picture and sound
separately. For det ails, see page 83.
Dubbing/Editing
62
Page 63
Dubbing to another tape
You can copy and edit the pic ture played
back on your camcord e r to other recording
devices (such as VCRs).
1 Connect your VCR to your camcorder
as a recording device (p. 61, 62).
2 Prepare your VCR for recording.
• Insert a cassette fo r recording.
• If your VCR has an input selector, set it to
the input mode.
3 Prepare your camcorder for playback.
• Insert the record ed cassette.
• Slide the POWER switch to select the
PLAY/EDIT mode.
4 Start the playback on your camcorder,
and record it on the VCR.
Refer to the operating instruc tions supp lied
with your VCR for details.
• For TRV255E/265E:
When your camcorder is connected to the VCR via
the DV Interface, you cannot rec or d the title or
indicators.
• For TRV255E/265E:
Pictures edited with Picture effect ([P EFFECT]
p. 45) cannot be output via the DV Interface.
• For TRV255E/265E:
When connected using the i.LI NK cable, the
recorded picture becomes rough when a picture is
paused on your camcorder while recording to a
VCR.
z Tip
• For TRV228E/428E:
To prevent deterioration of pictur es , set [ EDI T] to
[ON] in the (PLAYER SET) menu before
dubbing (p. 51).
Dubbing/Editing
5 When the dubbing is finished, stop
your camcorder and the VCR.
b Notes
• When dubbing using the A/V c onnecting cable,
press DSPL/BATT INFO to hide indicators such as
time code (p. 37). Otherwise, they will be rec or de d
on the tape.
• For TRV255E/265E:
When connected using the A/V connecting cable, to
record the date/time and camera settings data, have
it displayed on screen (p. 37).
Dubbing/Editing
63
Page 64
Dubbing a tape easily
– Easy Dubbing ( TRV228E/428E)
You can control VCR for dubbing with your
camcorder easily with the VCR connected to
the camcorder.
5 Turn the SEL/PUSH EXEC dial to
select [SETUP], then press the dial.
EASY DUBBING
SETUP
I R SETUP
PAUSE MODE
I R TEST
RETURN
[
:
E A SY ]
E N D
B UD
0 0 : 0 0 : 0
3
NORMAL
Step 1: Preparing your camcor der and VCR for operation
Follow the steps below when yo u are
performing the Easy Dubbing for the first
time. You can skip this setting if you have set
up the VCR by the following procedure
before.
b Note
• You cannot perform the Easy Dubbing on a VCR
that does not support [IR SETUP] codes.
1 Connect your VCR to your camcorder
as a recording device ( p. 61).
2 Prepare your VCR for recording.
• Insert a cassette for recording.
• Set the input selector to input mode, if
your VCR has one.
3 Prepare your camcorder for playback.
• Insert a cassette for editing.
• Slide the POWER switch repeatedly to
select the PLAY/ED IT mode.
4 Press EASY DUB.
EASY DUBBING
START
T I T LE SEL
MODE SEL
SETUP
0 0 : 0 0 : 0
6 Turn the SEL/PUSH EXEC dial to
select [IR SETUP], then press the dial.
When you conne ct wit h an A/V connec ting
cable, you need to chec k t he [IR SETUP]
code signal t o see if your VCR can be
operated by your camcorder (infra red ray
emitter).
7 Turn the SEL/PUSH EXEC dial to
select the [IR SETUP] code of your
VCR, then press the dial.
For the [IR SETUP] code of your VCR,
refer to “[IR SETUP] code list” (p.6 5).
When there is more t han one cod e listed for
the manufactur er of your VCR, try each
code and find the m os t appropriate one.
8 Turn the SEL/PUSH EXEC dial to
select [PAUSE MODE], then press the
dial.
EASY DUBBING
SETUP
I R SETUP
PAUSE MODE
I R TEST
RETURN
[
:
E A SY ]
E N D
B UD
PAUSE
REC
PB
0 0 : 0 0 : 0
NORMAL
9 Turn the SEL/PUSH EXEC dial to
select the mode to cancel recordin g
pause on the VCR, then press the dial.
Refer to the operating instructions su pplied
with your VCR for details on operation.
[
E A SY ]
Dubbing/Editing
64
NORMAL
:
E N D
B UD
Page 65
10Point the infrared ray emitter of yo ur
camcorder towards the remote sensor
on your VCR, from about 30 cm (12
in.) away, with no obstructions.
Infrared ray
emitter
Remote sensor
VCR
11Set the VCR to recording pause.
12Turn the SEL/PUSH EXEC dial to
select [IR TEST], then press the dial.
13Turn the SEL/PUSH EXEC dial to
select [EXECUTE], then press the dial.
Recording starts on your VCR when the
setting is correct. [COMPLETE] appears
when the [IR SETU P] code test is finished.
Go on to the next step.
When recordin g fails t o start, select anothe r
[IR SETUP] code an d try again.
14Turn the SEL/PUSH EXEC dial to
select [ RETURN], then press the
dial.
[IR SETUP] code list
The following [IR SETUP] codes are reco rded
on your camcorder by default. (It is set at “3” as
the default setting.)
Manufacturing
company
Sony 1, 2, 3, 4, 5, 6
Aiwa 47, 53, 54
Akai 50, 62, 74
Alba 73
Amstrad 73
Baird 30, 36
Blaupunkt 11, 83
Bush 74
CGM 36, 47, 83
Clatronic 73
Daewoo 26
Ferguson 76, 83
Fisher 73
Funai 80
Goldstar 47
Goodmans 26, 84
Grundig 9, 83
Hitachi 42, 56
ITT/Nokia Instant 36
JVC 11, 12, 15, 21
Kendo 47
Loewe 16, 47, 84
Luxor 89
Mark 26*
Matsui 47, 58*, 60
Mitsubishi 28, 29
Nokia 36, 89
Nokia Oceanic 89
Nordmende 76
Okano 60, 62, 63
Orion 58*, 70
Panasonic 16, 78
Philips 83, 84, 86
Phonola 83 , 84
[IR SETUP] code
,continued
Dubbing/Editing
Dubbing/Editing
65
Page 66
Manufacturing
[IR SETUP] code
company
Roadstar 47
SABA 21, 76, 91
Salora 89
Samsung 22, 32, 52, 93, 94
Sanyo 36
Schneider 10, 83, 84
SEG 73
Seleco 47, 74
Sharp 89
Siemens 10, 36
Tandberg 26
Telefunken 91, 92
Thomson 76, 100
Thorn 36, 47
Toshiba 40, 93
Universum 47, 70, 84, 92
W.W. House 47
Watoson 58, 83
2 Turn the SEL/PUSH EXEC dial to
select the desired title, then press the
dial.
The title flashes.
BB I NGU D Y S A E
OK
COLOR
SIZE
BACK COL
[
EASY DUB]:END
HELLO!
0 0 : 0 0 : 0
3 Change [COLOR] (color), [SIZE]
(size), or [BACK COL.] (back ground
color) as necessary.
If you do not need to ch ange them, go to
Step 3 (p. 67) .
1 Turn the SEL/PUSH EXEC dial to select
[COLOR], [SIZE], or [BACK COL.],
then press the dial. The selected item
appears on the sc reen.
2 Turn the SEL/PUSH EXEC dial to select
the desired item, then press the dial.
3 Repeat steps 1 and 2 until the title is laid
out as desired.
* TV/VCR component
Step 2: Selecting the title
You can insert a title.
You can select one of the 8 preset titles and
the 2 custom titles. See steps 1 to 4 on
page 31 to create original titles.
1 Turn the SEL/PUSH EXEC dial to
select [TITLE SEL], then press the
dial.
EASY DUBBING
T I T LE SEL
[
EASY DUB]:END
Dubbing/Editing
66
OFF
H E L L O
!
H A P P Y B I R T H D A Y
H A P P Y H O L I D A Y S
C O N G R A T U L A T I O N S
O U R S W E E T B A B Y
0 0 : 0 0 : 0
!
4 Turn the SEL/PUSH EXEC dial to
select [OK], then press the dial.
The title lights up.
EASY DUBBING
START
T I T LE SEL
MODE SEL
SETUP
HELLO!
[
:
E A SY ]
E N D
B UD
b Notes
• You can put a title on ly into the tape of the VCR.
• If you set the background color to [F ADE] , the
picture may not appear properly, depending on the
connected VCR.
z Tips
• The title color changes as follows:
[WHITE] y [YELLOW] y [VIOLET] y
[RED] y [CYAN] y [GREEN] y [BLUE]
• The title size changes as follows:
[SMALL] y [LARGE]
0 0 : 0 0 : 0
ON
NORMAL
Page 67
• The background color changes as follows:
[FADE] y [WHITE] y [YELLOW] y
[VIOLET] y [RED] y [CYAN] y [GREEN]
y [BLUE] y [BLACK]
Step 4: Performing Easy Dubbing
Step 3: Selecting the dubbing mode
You can choose either normal recording
([NORMAL]) or interval recording
([PREVIEW]).
1 Turn the SEL/PUSH EXEC dial to
select [MODE SEL], then press the
dial.
EASY DUBBING
START
TITLE SEL
MODE SEL
SETUP
NORMAL
PREVIEW
0 0 : 0 0 : 0
HELLO!
[
EASY DUB]:END
NORMAL
2 Turn the SEL/PUSH EXEC dial to
select [NORMAL] or [PREVIEW],
then press the dial.
When you select [NORMAL]
You can record into the VCR n o rmally.
When you select [PREVIEW]
You can make a time-lapse dubbing by
setting the VCR to automatically repeat 5
seconds’ recording and 25 secon d s ’
standby.
[a]
[b]
[c]
5 s
25 s
30 s 30 s
5 s
25 s
Make su re th at y ou r c am co rd er and V CR ar e
connected, and that the VCR is set to
recording pause .
1 Turn the SEL/PUSH EXEC dial to
select [START], then press the dial.
EASY DUBBING
START
TITLE SEL
MODE SEL
SETUP
Engage rec pause.
[
EASY DUB]:END
RETURN
EXECUTE
NORMAL
0 0 : 0 0 : 0
2 Turn the SEL/PUSH EXEC dial to
select [EXECUTE], then press the dial.
When dubbing end s, your camcorder and
VCR stop automatically.
Then the display returns to the Easy
Dubbing initial screen.
To stop dubbing during editing
Press (stop) on your camcorder.
To quit Easy Dubbing
Press EASY DUB.
b Note
• [NOT READY] appears on the screen when
[START] is not carried out.
Dubbing/Editing
a. Recording time (VCR)
b. Waiting time (VCR)
c. Playback tim e (camcorder)
Dubbing/Editing
67
Page 68
Recording pictures
Dubbing selected
from a VCR
You can record and edit pictures from a VCR
on a tape inserted in your camcorder.
Insert a cassette for recording in your
camcorder.
( TRV265E)
1 Connect your VCR to your camcorder
(p. 62).
Use an i.LINK cable (optional) fo r
connection.
2 Slide the POWER switch repeatedly to
select the PLAY/EDIT mode.
3 Press (rec) and the button on its
right simultaneou s ly on your
camcorder, then immediately press
(pause) on your camcorder.
4 Start playing the cassette on your
VCR.
The pictur e pl ayed o n th e conn ecte d de vice
appears on the L C D screen of your
camcorder.
5 Press (pause) at the point you
want to start recording.
6 Press (stop) to stop recording.
z Tip
• appears when you connect your camcorder
and other devices via an i.LINK cable. (This
indicator may also appear on your TV.)
scenes from a tape
– Digital program editing
(
TRV255E/265E)
You can select up to 20 scenes (programs)
and record them in the desired order to other
recording device such as VCR.
Delete unwanted scene
Change the order
Results of editing
Step 1: Preparing your camc order
and VCR for operation
Follow the steps below when you are
performing digital program editing for the
first time to a tape in a VCR. You can skip
this setting if you have set up the VCR by the
following procedure before.
b Notes
• You cannot perform the Digital program editing on
a VCR that does not support [IR SETUP] codes.
• When your camcorder is connecte d to the VCR via
the DV Interface, you cannot record the title or
indicators.
1 Connect your VCR to the camcorder
as a recording device (p. 62).
You can use either t he A / V connecting
cable or the i.LINK cable to make the
connection. The d ubbing procedure is
easier with the i.L I N K connection.
Dubbing/Editing
68
Page 69
2 Prepare your VCR.
• Insert a cassette fo r recording.
• Set the input selector to input mode, if
your VCR has one.
3 Prepare you r camcorder (playing
device).
• Insert a cassette for editing.
• Slide the POWER switch repeatedly to
select the P L AY/EDIT mode.
4 Press MENU.
9 Turn the SEL/PUSH EXEC dial to
select [i.LINK] or [IR], then press the
dial.
When connecting with an i.LINK
cable
After selecting [i.LINK], go on to “Step 2:
Adjusting the synchronization of the VCR”
(p. 70).
When connecting with an A/V
connecting cable
After selec ti ng [IR], follow the procedure
described in “To set the [IR SETUP] code”
(p. 69).
5 Turn the SEL/PUSH EXEC dial to
select (OTHERS) , then pre ss the
dial.
6 Turn the SEL/PUSH EXEC dial to
select [VIDEO EDIT], then press the
dial.
VIDEO EDIT
MARK
UNDO
ERASE ALL
START
EDIT SET
TOTAL 0:00:00:00
SCENE 0
[MENU] : END
1 IN
0:08:55:06
7 Turn the SEL/PUSH EXEC dial to
select [EDIT SET], then press the dial.
VIDEO EDIT
EDIT SET
CONTROL
ADJ TEST
”CUT–IN”
”CUT–OUT”
IR SETUP
PAUSEMODE
IR TEST
RETURN
[MENU] : END
0:08:55:06
IR
8 Turn the SEL/PUSH EXEC dial to
select [CONTROL], then press the
dial.
VIDEO EDIT
EDIT SET
CONTROL
[MENU] : END
IR
i. LINK
0:08:55:06
To set the [IR SETUP] code
When you connect with an A/V connecting
cable, you need to check the [IR SETUP] code
signal to see if your VCR can be operated by
your camcorder (infrared ray emitter).
Infrared ray
emitter
Remote sensor
VCR
1 Turn the SEL/PUSH EXEC dial to select
[IR SETUP], then press th e di al .
2 Turn the SEL/PUSH EXEC dial to select
the [IR SETUP] code of your VCR, then
press the dial.
For the [IR SETUP] code of y our V CR,
refer to “[IR SETUP] code list” (p. 65).
When there is more than one code listed for
the manufacturer of your VCR, try each
code and find the most appropriate one.
3 Turn the SEL/PUSH EXEC dial to select
[PAUSEMODE], then press the dial.
4 Turn the SEL/PUSH EXEC dial to select
the mode to cancel recording pause on
the VCR, then press the dial.
Refer to the operating instructions supplied
with your VCR for details on operation.
Dubbing/Editing
,continued
Dubbing/Editing
69
Page 70
5 Poi nt the infrared ray em it ter of your
camcorder towards the remote sensor on
your VCR, from about 30 cm (12 in.)
away, with no obstructions.
6 Insert a cassette into your VCR, and set
the VCR to recording pause.
7 Turn the SEL/PUSH EXEC di al to sel ect
[IR TEST], then press the dia l .
8 Turn the SEL/PUSH EXEC di al to sel ect
[EXECUTE ], then press the d ial.
The recording starts on your VCR when the
setting is correct. [COMPLETE] appears
when the [IR SETUP ] co de test is finished.
Go on to “Step 2: Adjusting the
synchronization of th e VCR” (p. 70).
When recording fails to start, select another
IR code and try again.
3 Turn the SEL/PUSH EXEC dial to
select [ADJ TEST], then press the dial.
VIDEO EDIT
EDIT SET
CONTROL
ADJ TEST
”CUT–IN”
”CUT–OUT”
IR SETUP
PAUSEMODE
IR TEST
RETURN
[MENU] : END
0:08:55:06
RETURN
EXECUTE
ENGAGE
REC PAUSE
4 Turn the SEL/PUSH EXEC dial to
select [EXECUTE], then press the dial.
[EXECUTING] flas hes and a pictur e (about
50 seconds long) with 5 [IN] and [OU T ]
indicators each for adjusting
synchronization is recorded. [COMPLETE]
appears when the recording is finish ed.
Step 2: Adjusting the
synchronization of the VCR
Follow the steps below when yo u are
performing digital program editing for the
first time to a tape in a VCR. You can skip
this setting if you have set up your VCR
before using the following procedure.
You can adjust the synchronization of your
camcorder and the VCR to avoid not
recording the starting scene.
1 Remove the cassette from your
camcorder. Prepare a pen and paper
to take notes.
2 Set the VCR to recording pause mode.
Skip this step if you h ave selec ted [i.LINK]
in step 9 on p. 69.
b Note
• Run the tape for about 10 seconds before
pausing. The starting scenes may not get
recorded when you start recording from
the beginning of the t ape.
VIDEO EDIT
EDIT SET
CONTROL
ADJ TEST
”CUT–IN”
”CUT–OUT”
IR SETUP
PAUSEMODE
IR TEST
RETURN
[MENU] : END
0:08:55:06
COMPLETE
5 Rewind the tape on your VCR, then
play back in slow mode.
5 opening numbers for each [IN] a nd
closing numbe rs for each [OUT] appear .
6 Take a note of the opening numerical
value of each [IN] and the closing
number value of each [OUT], then
calculate the average numerical value
for each [IN] and [OUT].
7 Turn the SEL/PUSH EXEC dial to
select [”CUT-IN”], then press the dial.
VIDEO EDIT
EDIT SET
CONTROL
ADJ TEST
”CUT–IN”
”CUT–OUT”
IR SETUP
PAUSEMODE
IR TEST
RETURN
[MENU] : END
0:08:55:06
0
Dubbing/Editing
70
Page 71
8 Turn the SEL/PUSH EXEC dial to
select the average numerical value of
[IN], then press the dial.
The calculated start position for recording
is set.
9 Turn the SEL/PUSH EXEC dial to
select [”CUT-OUT”], then press the
dial.
VIDEO EDIT
EDIT SET
CONTROL
ADJ TEST
”CUT–IN”
”CUT–OUT”
IR SETUP
PAUSEMODE
IR TEST
RETURN
[MENU] : END
0:08:55:06
0
10Turn the SEL/PUSH EXEC dial to
select the average numerical value of
[OUT], then press the dial.
The calculated stop position for recording is
set.
11Turn the SEL/PUSH EXEC dial to
select [ RETURN], then press the
dial.
Recording the selected scenes as
programs
3 Turn the SEL/PUSH EXEC dial to
select (OTHERS), then press the
dial.
4 Turn the SEL/PUSH EXEC dial to
select [VIDEO EDIT], then press the
dial.
VIDEO EDIT
MARK
UNDO
ERASE ALL
START
EDIT SET
TOTAL 0:00:00:00
SCENE 0
[MENU] : END
1 IN
0:08:55:06
5 Search for the beginning of the first
scene that you want to record on your
camcorder, then pause playback.
6 Turn the SEL/PUSH EXEC dial to
select [MARK], then press the dial.
The starting point of the first p rogram is set,
and the upper par t of the program mark
changes to light blue.
VIDEO EDIT
MARK
UNDO
ERASE ALL
START
EDIT SET
TOTAL 0:00:00:00
SCENE 0
[MENU] : END
1 OUT
0:08:55:06
Dubbing/Editing
When you are perfor ming digital program
editing for the first time to a tape in a VCR,
go through the procedures described in Steps
1 and 2 (p. 68 to p. 70) beforehand.
1 Prepare a cassette.
Insert a tape to be pl ayed back into the
camcorder.
Insert a cassette for recording into your
VCR.
2 Press MENU.
7 Search for the end of the first scene
that you want to record on your
camcorder, then pause playback.
,continued
Dubbing/Editing
71
Page 72
8 Press the SEL/PUSH EXEC dial.
The ending point of the first program is set,
and the lower part of the program mark
changes to light blue.
VIDEO EDIT
MARK
UNDO
ERASE ALL
START
EDIT SET
TOTAL 0:00:12:00
SCENE 1
[MENU] : END
2 IN
0:09:07:06
9 Repeat steps 5 to 8 and create
programs.
10Set your VCR to the recording pause.
Skip this step if your camcorder is
connected via an i.LINK cable.
11Turn the SEL/PUSH EXEC dial to
select [START], then press the dial.
VIDEO EDIT
MARK
UNDO
ERASE ALL
START
EDIT SET
TOTAL 0:00:12:00
SCENE 1
[MENU] : END
0:09:07:06
ENGAGE
REC PAUSE
RETURN
EXECUTE
12Turn the SEL/PUSH EXEC dial to
select [EXECUTE], then press the dial.
A search for the beg i nning of the first
program starts, the n t he recording starts.
[SEARCH] appear s during search and
[EDITING] appears during editing.
VI DEO ED I T
EDITING
0:00:06:00
To end Digital program editing
Press MENU.
To save a program without using it to
record
Press MENU in step 11.
The program is stored in memory until the
cassette is eject ed.
To erase programs
1
Follow steps 1 to 4 in “Re cording the
selected scenes as programs” (p. 71).
2 Turn the SEL/PUSH EXEC dial to select
[UNDO] or [ERASE ALL], then press
the dial.
When you select [UND O ]
You can erase the las t set program.
When you select [ERASE ALL ]
You can erase all the programs.
3 Turn the SEL/PUSH EXEC dial to select
[EXECUTE], then press the dial.
The programs are deleted. To cancel this
operation, select [RETURN], and then
press the dial.
b Notes
• You cannot set starting point or ending point on a
blank section of the tape. If there is a blank section,
the total time may not appear correctly.
• When you cannot operate the device correctly using
an i.LINK cable connection, select [IR] in step 9 on
p. 69, and set the [IR SETUP] code.
SCENE 1 / 1
[ ] :
CANCEL [MENU] : END
When a program is recorded, the program
mark stops flashing and remains lit. When
all programs have been recorded, t he
program editing op er ation stops
automatically.
To cancel recording, press (stop).
Dubbing/Editing
72
Page 73
Troubleshooting
persists, remove the power source and
contact your Sony deale r.
Troubleshooting
If you run into any problem using your
camcorder, use the following table to
If “C:ss:ss” is displayed on th e LC D
screen or the viewfinder, the self-diagnosis
display functio n is acti vated. See pag e 78 for
details.
troubleshoot th e problem. If the problem
Overall operations
Symptom Cause and/or Corrective Actions
The power does not turn on. • The battery pack is discharged, running low, or not attached to the
The camcorder does not operat e even
when the power is set to on.
For TRV228E/428E/
TRV265E:
The supplied Remote Commander
does not function.
camcorder.
cAttach a charged battery pack to the camcorder. (p.12)
cUs e the AC Adaptor t o connect to the w all socket. (p. 1 5 )
cDisconnect the AC Adaptor from the wall socket or remove the battery
pack, then reconnect it after a bout 1 minute. If the functions still do not
work, press the RESET button using a sharp-pointed object. (If you press
the RESET button, all settings including the c loc k se tting are reset.)
cSet [COMMANDER] in the (OTHERS) menu to [ON]. (p. 60)
cInser t a batt er y into the battery holder with the + – polarities correctly
matching the + – marks. If this still does not solve the problem , insert a
new battery since the battery is dead. (p. 94)
cRemove any obstructions between the Remote Commander and the
remote sensor.
Troubleshooting
Batteries/Power sources
Symptom Cause and/or Corrective Actions
The CHG (charge) lamp does not
light while the battery pack is being
charged.
The CHG (charge) lamp flashes while
the battery pack is being charged.
The battery pack is quickly
discharged.
cAttach the battery pack to the camcorder corre ctly . If the lam p stil l does
not light up, then it indicates that no power is supplied from the wall
socket.
• The battery charge is completed. (p. 12)
cAttach the battery pack to the camcorder correctly. If the problem
persists, disconnec t the AC Adaptor from the wall socket and contact
your Sony dealer. The battery pack may be dama ge d. (p. 12)
• The temperature of the environment is too low, or the battery pack has
not been charged enough. This is not a malfunction.
cFully charge the battery again. If the problem persists, replace the
battery pack with a new one. It may be damaged. (p. 12, 82)
,continued
Troubleshooting
73
Page 74
Symptom Cause and/or Corrective Actions
The remaining batt er y time indicator
does not indicate the correct time.
The power turns off frequently
although the remaining bat tery
indicator indica te s tha t the battery
pack has enough power to operate.
The power abruptly turns off. • [A.SHUT OFF] in the (OTHERS) menu is set to [5 min]. (p. 59)
A problem occurs when the
camcorder is connected to the AC
Adaptor.
• The temperature of the environment is too high or too low, or the battery
pack has not been charged enough. This is not a malf unc tion.
cFully charge the battery again. If the problem persists, replace the
battery pack with a new one. It may be damaged. (p. 12, 82)
• A problem has occurred in the rem ai ning battery time indicator, or the
battery pack has not been charged enough.
cFully charge the battery again to correct the indication. (p. 12)
cWhen approximately 5 minutes have elapsed while you do not operate
your camcorder, the camcord er is au to matically turned off. Slid e the
POWER switch down to turn the po wer on again. (p.15) Or use the AC
adaptor.
cTurn off the power, and disconnect the AC Adaptor from the wall socket.
Then, conn ect it again.
Cassette tapes
Symptom Cause and/or Corrective Actions
Cassette cannot be ejected from the
compartment.
Cassette is not ejected even when the
cassette lid is open.
The remaining tape indicator is not
displayed.
cMake sure the power source (battery pack or AC Adaptor) is connected
correctly. (p. 12)
cRemove the battery pack from the camcorder, then attac h it again. (p.12)
cAttach a charged battery pack to the camcorder. (p. 12)
cMois tur e cond ensation is starting in your camcor der. (p. 85)
cSet [ REMAIN] to [ON] in the (TAPE SET) menu to always
display the remaining tape indicator. (p. 55)
LCD screen/viewfinder
Symptom Cause and/or Corrective Actions
An unknown language appears on the
screen.
An unknown picture appears on the
screen.
An unknown indicator appears on the
screen.
Troubleshooting
74
cSee page 19.
cThe camcorder is in [DEMO MODE]. (The [DEMO MODE] is
automatically displa ye d whe n you leave the camcorder for 10 minutes
after selecting CAM E RA without inserting a casse tte.) Insert a cassette
to cancel [DEMO MODE]. You can also set [DEMO MODE] to [OFF]
in the menu. (p.58)
cRefer to the indicator list. (p.96)
Page 75
Symptom Cause and/or Corrective Actions
The picture in the viewfinder is not
clear.
The picture in the viewfinder has
disappeared.
cUse the vie w f inder lens adjustment lever to adjust the lens. (p. 16)
cClose the LCD panel. The picture is not displayed in the viewfinder
when the LCD panel is op en. (p. 16)
Recording
Symptom Cause and/or Corrective Actions
The tape does not start when you
press REC START/STOP.
The power abruptly turns off. • [A.SHUT OFF] in the (OTHERS) menu is set to [5 min]. (p. 59)
For TRV428E/ TRV255E/
265E:
The SteadyShot does not function.
The auto focus does not function. cPress FOCUS to enable auto focus. (p.29)
A vertical band appears when
recording candlelight or electric light
in the dark.
A vertical band appears when
recording a bright subject.
The color of the picture is not
correctly displayed.
Picture appears too bright on the
screen, and the subject does not
appear on the screen.
The shutter sound is not heard. cSet [BEEP] to [MELODY] or [NORMAL] in the (OTHERS) menu.
For TRV428E/ TRV255E/
265E:
Black bands appear when you record
a TV screen or computer screen.
cSlid e the POWER switch to turn on the CAMERA lamp. ( p. 15)
cThe tape has reache d the en d. Rew ind it, or insert a new cassette.
cSet the write-protect ta b to RE C or insert a new cassette. (p. 81)
cThe tape is stuck to the drum due to moisture condensation. Remove the
cassette and leave your camcorder for at least 1 hour, then re-insert the
cassette. (p. 85)
cWhen approximately 5 minutes have elapsed while you do not operate
your camcorder, the camcorder is automatically turned off.
Slide the POWER switch down to turn the power on again (p. 15). Or
use the AC Ad aptor.
• The battery pack is discharg e d. (p. 1 2)
cSet [STEADYSHOT] to [ON] in the (CAMERA SET) menu.
(p. 50)
cSet [16:9 WIDE] to [OFF] in the (CAMERA SET) menu. (p. 48)
cThe recording conditions are not suitab le for auto focus. Ad just the fo cus
manually. (p. 29)
• This occurs when the contrast between the subject and the background is
too high. This is not a malfunction.
• This phenomenon is called the sme a r eff ect. This is not a malfunction.
cDeactivate the N ight Sh ot plus function. (p. 28)
cDeactivate the NightShot plus function in bright places. (p. 28)
cCancel th e bac k light fun ct ion. (p. 27)
(p. 59)
cSet [STEADYSHOT] to [OFF] in the (CAMERA SET) menu.
(p. 50)
Troubleshooting
,continued
Troubleshooting
75
Page 76
Symptom Cause and/or Corrective Actions
Flickering or changes in color occurs. cThis occurs when recording pictures under a fluorescent lamp, sodium
END SEARCH does not work. • The cassette was ejected after recording.
END SEARCH does not work
correctly.
The built-in light does not function. cPress LIGHT repeatedly to select .
lamp, or mercury lamp in the soft portrait or sports lesson mode. Cancel
[PROGRAM AE] in this case. (p.44)
• The cassette is new and has nothi ng recor de d.
• There is a blank section in the begin ning or middle of the tape. This is
not a malfunction .
cIf the problem persists, contact your Sony de aler or local authorized
Sony service facility .
Playback
Symptom Cause and/or Corrective Actions
Cannot play back. cIf the tape has reached the end, rewind the tape. (p. 34)
Horizontal lines appear on the
picture. The displayed pictures are
not clear or do not appear.
No sound or only a low sound is
heard.
The sound breaks off. cClean the head using the cleaning cassette (o ptional). (p. 85)
For TRV265E:
Cannot perform the Date search with
the recording date displaye d on the
screen.
For TRV255E/265E:
“---” is displayed on the screen.
END SEARCH does not work. • The cassette was ejected after recording.
END SEARCH does not work
correctly.
cClean the h ead using the cleaning cassette (optional) . (p. 8 5)
• For TRV228E/428E:
The television’s video chan ne l is not adjusted correctly.
cAdjust it. (p. 39)
cFor TRV228E/428E:
Set [EDIT] to [OFF] in the (PLA Y E R S E T) menu. (p. 51)
cFor TRV255E/265E:
Set [HiFi SOUND] to [STEREO] in the (PLAYER SET) menu for
TRV255E, or in the (VCR SET) menu for TRV265E. (p. 51)
cTurn up the volume. (p. 34)
cFor TRV255E/265E:
In the (PLAYER SET) menu for TRV255E, or in the (VCR
SET) menu for TRV265E, adjust [AUDIO MIX] from the [ST2] side
until the sound is heard appropriately. (p. 52)
cWhen you are using a n S VIDEO plug, make sure the black plug for
TRV228E/428E, or the red and white plugs for TRV255E/265E
of the A/V connecting cable are connected as well. (p. 39)
• There is a blank section in the begin ning or middle of the tape. This is
not a malfunction .
• The tape you are playing was recorded without setting the date and time.
• A blank section on the tape is being playe d.
• The data code on a tape with a scratch or noi se cannot be read.
• The cassette is new and has nothi ng recor de d.
• There is a blank section in the begin ning or middle of the tape. This is
not a malfunction .
Troubleshooting
76
Page 77
Symptom Cause and/or Corrective Actions
For TRV255E/265E:
The picture does not appear on the
screen when playing back a tape.
• The tape is recorded in the H i8 /standard 8 mm system .
Dubbing/Editing
Symptom Cause and/or Corrective Actions
Cannot dub correctly using the A/V
connecting cable.
For TRV265E:
Pictures from connected devices are
not displayed correctly.
For TRV255E/265E:
Digital program editing does not
function.
For TRV255E/265E:
The VCR is not responding properly
during Digital program edit ing when
it is connected via an i.LINK cable.
For TRV228E/428E:
Easy Dubbing does not function.
cSet [DISPLAY] to [LCD] in the (OTHERS) menu. (p. 60)
• The input signal is not PAL. (p. 68)
cSet the input selector on the VCR correctly, then check the connection
between your camcorder and the VCR. (p. 61)
cWhen your camcorder is connected to a DV device that is not a Sony
product via an i.LINK cable, select [IR] in step 9 of “Step 1: Preparing
your camcorder and VCR for operation.” (p. 68)
cAdjust the synchronization of the VCR. (p.70)
cEnter a correct [IR SETUP] code. (p.65)
cSelect the mode used to cancel recording pause again. (p. 69)
cSet your camcorder and the VCR more than 30 cm (12 in.) apart. (p. 69)
• The program may not be set to a blank sect ion on the tape.
cWhile connecting via an i.LINK cable, select [IR] in step 9 of “Step 1:
Preparing your camcorder and VCR for operation.” (p. 68)
• Your VCR and/or video camera recorder is not set correctly.
cMak e sure the input selector of the VC R is se t to LINE. Also, make
sure the power switch of the video cam e ra rec or de r is set to VCR .
(p. 64)
• The [IR SETUP] code or [PAUSE MODE] is n ot set correctly.
c Select the correct [IR SETUP] code and [PAUSE MODE], according
to your VCR. Then confirm VCR operation with the [IR TEST]
function. (p. 64)
Troubleshooting
Troubleshooting
77
Page 78
Warning indicators and messages
Self-diagnosis display/Warning indicators
If indicators appear on the screen, check the following. See the page in parentheses for details.
Indication Cause and/or Corrective Actions
C:ss : ss/E:ss : ss (Selfdiagnosis display)
E (Battery level warning) • The battery pack is nearly used up.
% (Moisture condensation warning)* cEject the cassette, set the POWER switch to (CHG) OFF, and leav e it for
Q (Warning indicator pertaining to
the tape)
Some symptoms can be fixed by yourself. If the problem persists even after
you tried a couple of times, contact your Sony deal er or loc a l author iz e d
Sony service facility.
C:04:ss
cA battery pack that is not an “InfoLITHIUM” battery pack is being used.
Use an “InfoLITHIUM” battery pack. (p. 82)
C:21:ss
cMoisture condensation has occurred. Remove the cassette and leave your
camcorder for at least 1 hour, then re-insert the cassette. (p. 85)
C:22:ss
cClean the head using a cleaning cassette (optional). (p. 85)
C:31ss / C:32ss
cSymptoms that are not described above have occurred. Remove and
insert the cassette, then operate your camcorder again. Do not perform
this procedure if moisture sta rts to co nde nse . (p. 85)
cRemov e the powe r sour c e. Rec onne c t it a ga in a nd ope rat e yo ur
camcorder again.
cChange the tape.
cPress the RESET button and operate your camcorder again.
E:61:ss / E:62:ss
cContact your Sony dealer or local authorized Sony se r vic e fac ility.
Inform them of the 5-digit code, which starts from “E.”
• Depending on the operating , envir onmental, or battery conditions, the
E indicator may flash, even i f there are approximately 5 to 1 0 m inu tes
remaining.
about 1 hour with the cas sette lid open. (p. 85)
Slow flashing:
• There is less than 5 minutes remaining on the tape.
• No cassette is inse rted.*
• The write-protect tab on the cassette is set to lock. (p. 81)*
Fast flashing:
• The tape has run out.*
Troubleshooting
78
Page 79
Indication Cause and/or Corrective Actions
Z (Eject cassette warning)* Slow flashing:
* You hear a melody or beep sound when the warni ng indicators appear on the screen.
• The write-protec t ta b on the cassette is set to lock. (p . 81)
Fast flashing:
• Moisture condensation has occ ur red. (p . 85)
• The self-diagnosis display code is displayed. (p. 78)
Warning messages
The following messages will appear to prompt you to correct the situation.
Subjects Indications Corrective Actions/References
Battery Use the “InfoLITHIUM” battery pack. cSee page 82.
Battery level is low. cCharge the ba tte r y. (p. 1 2)
Old battery. Use a new one. cSee page 82.
Z
Re-attach the power source. –
Moisture
condensation
Cassette/tape Q Insert a cassette. cSee page 18.
Others Cannot record due to copyright protection. –
% Z Moisture cond ensation. Eject th e c assette cSee page 85.
% Moisture condensation. Turn off for 1H. cSee page 85.
Z
Reinsert the casse tte . cThe cassette might be damaged, etc.
Q Z The tape is locked - check the tab. cSee page 81.
Q The tape has reached the end. –
Dirty video head. Use a cleaning cassette. cS ee pag e 85.
Cannot start Easy Handycam cSee page 26 and 36.
Cannot cancel Easy Handycam cSee pag e 26 and 36.
Cannot start Easy Handycam with USB connected –
Invalid button with Easy Handycam operation cSee page 26 and 36.
USB invalid during Easy Handycam cPress SEL/PUSH EXEC dial.
Troubleshooting
Troubleshooting
79
Page 80
Additional Information
Using your camcorder abroad
Power supply
You can use your camcorder in any country/
regions using the AC Adaptor supplied with
your camcorder w ith in AC 100 V to 240 V,
50/60 Hz.
On TV color systems
Your camcorder is a PAL system-based
camcorder. If you want to view the playback
picture on a TV, it must be a PAL system-based
TV (see following list) with the AUDIO/
VIDEO input jack.
System Used in
PAL Australia, Austria, Belgium,
China, Czech Republic, Denmark,
Finland, Germany, Holland, Hong
Kong, Hungary, Italy, Kuwait,
Malaysia, New Zealand, Norway,
Poland, Portugal, Singapore ,
Slovak Republic, Spain, Sweden,
Switzerland, Thailand, United
Kingdom, etc.
PAL - M Brazil
PAL - N Argentina , Paragua y, Urug ua y
SECAM Bulgaria, France, Guiana, Iran,
Iraq, Monaco, Russi a, Ukra ine, e tc.
NTSC Bahama Islands, Boliv ia, Canada,
Central Americ a, Chile, Colo mbia,
Ecuador, Guyana, Jamaica, Japan,
Korea, Mexico, Peru, Surinam,
Taiwan, the Philippines, the
U.S.A., Venezuela, etc.
Simple setting of clock by time
difference
You can easily set the clock to the local time by
setting a time difference when using your
camcorder abro ad. Select [WORLD TIME] in
the (OTHERS) menu, then set the time
difference (p. 59).
Additional Information
80
Page 81
Usable cassette tapes
You can use stand ar d 8 m m and Hi8 ,
Digital8 video cassettes on your camcorder.
Hi8 system
This Hi8 system is an extension of the
standard 8 mm system , and wa s develo ped to
produce higher quality pictures.
You cannot play b ack a tape recorded in the
Hi8 system correctly on video recorders/
players other than a Hi8 video recorder/player.
Digital8 system
This video sy stem has been develope d to enable
digital recording to Hi8 /Digital8 video
cassette.
The recording time when you use your
Digital8 system camcorder on Hi8 /
standard 8 mm tape is 2/3 the recording time
when using the conventional Hi8 /standard
8 mm system camc or der. (90 minutes of
recording time becomes 60 minutes in the SP
mode.)
To prevent a blank section from being
made on the t ape
Press END SEARCH to go to the end of the
recorded section before you begin the ne xt
recording in the following cases:
– You have eje ct ed the cassette duri ng
recording.
– You have played back the tape.
If there is a blank section or discontinu ous
signals on your tape , re-record from the
beginning to the end of the tape as described
above.
Copyright signal
When you play back
If the cassette you play back on your camcorder
contains copyright signals, you cannot copy it to
a tape in another vi deo camera connec t ed t o
your camcorder.
For TRV265E:
When you record
You cannot record software on your
camcorder that contains copyright
control signals for copyright protection
of software.
[Cannot record due to copyright protection.]
appears on th e LCD scre en, or on the TV scre en
if you try to record such software.
Your camcorder does not record copyright
control signals on the tape when it records.
Notes on use
To prevent accidental erasure
Slide the write-protect tab on the cassette to set
to SAVE.
REC: The cassette can be recorded.
SAVE: The cassett e cannot be recorded (writeprotected).
When labeling the cassette
Be sure to place the label only on the locations
as shown in the following illustration so as not
to cause malfunction of your camcorder.
Do not put a label
along the border.
Labeling position
After using the cassette
Rewind the tape to the beginning to avoid
distortion of the picture or the sound. The
cassette should then be put i n its case, and stored
in an upright position.
Additional Information
, , , and are
trademarks.
Additional Information
81
Page 82
About the “InfoLITHIUM” battery pack
This unit is compatible with the
“InfoLITHIUM” battery pack (M series). Your
camcorder operates only with the
“InfoLITHIUM” battery pack.
“InfoLITHIUM” M series battery packs have
the mark.
What is the “InfoLITHIUM” battery
pack?
The “InfoLITHIUM” battery pack is a lithiumion battery pack th at has functions for
communicating information relate d to operating
conditions betw een your camcorder and an
optional AC Adaptor/charger.
The “InfoLITHI U M” battery pack calculates
the power consu mption according to t he
operating conditions of your camcorder, and
displays the remaining battery time in minute s.
With an AC Adaptor/charger (optional), the
remaining battery time and charging time
appear.
To charge the battery pa ck
• Be sure to charge the battery pack before you
start using your c amcorder.
• We recommend chargi ng the battery pack in
an ambient temper at ure of between 10°C to
30°C (50°F to 86°F) until the CHG (charge)
lamp turns off. If you charge the battery pack
outside of this temperature range, you may not
be able to charge it efficiently.
• After charging is complete, either disconnect
the cable from the D C IN jack on your
camcorder or remove the battery pack.
To use the battery pack effectively
• Battery pack performance decreases when the
surrounding tem perature is 10°C (50°F) or
below, and the length of time you can use the
battery pack becomes shorter. In that case, do
one of the following to use the battery pack for
a longer time.
– Put the battery pack in a pocket to warm it
up, and insert it in your camcorder rig ht
before you start tak ing shots.
– Use a large capacity battery pack: NP-
QM71/QM71 D /QM91/QM91D (opt ional).
• Frequent use of the LC D screen or a frequent
playback, fast forward or rewind operation
wears out the battery pack faster. We
recommend using a large capacity battery
pack: NP-QM71/QM71D/QM91/QM91D
(optional).
• Be sure to set the POWER switch to (CHG)
OFF when not recordi ng or playing back on
your camcorder. The battery pack is also
consumed when your camcorder is in
recording standby or playback pause.
• Have spare battery packs ready for two or
three times the expected recording time, and
make trial recordings before making the actual
recording.
• Do not expose the battery pack to water. The
battery pack is not water resistant.
About remaining battery time indicator
• When the power goes of f even though the
remaining battery time indicato r indicates that
the battery pack has enough power to operate,
charge the battery pack fully again. The
indication on the remaining battery time will
be indicated correctly. Note, however, that the
battery indication will not be restored if it is
used in high temperatures for a long time, or if
left in a fully char ged state, or when the
battery pack is frequently used.
Use the remaining battery time in dication as a
guide to the approximate shooting time.
•The E mark that indicates low batte ry flashes
even if there are still 5 to 10 minutes of batte ry
time remaining, depending on the operating
conditions or amb ie nt te m p e rature and
environment.
About storage of the battery pack
• If the battery pack is not used for a long time,
fully charge the batter y pack and use i t on your
camcorder on ce a year to maint ai n the proper
function.
To store the ba ttery pa ck, rem ove it fr om your
camcorder and put it in a dry, cool place.
• To completely use up the battery pack on your
camcorder, set [A.SHUT OFF] to [NEVER]
Additional Information
82
Page 83
in the (OTHERS) menu (p. 59) and leave
your camcorder in tape recording standby
until the power goes off.
About i.LINK
About battery life
• The battery life is limited. Battery capacity
drops little by little as you use it more and
more, and as time passes. When the available
battery time is shortened considerably, a
probable cause is that the battery pack has
reached the end of its life. Please buy a new
battery pack.
• The battery life varies depending on how it is
stored and the ope rating conditions and
environment for each battery pack.
“InfoLITHIU M ” is a t rademark of Sony
Corporation.
The DV Interface on this unit is an i.LINKcompliant DV Interface. This section describes
the i.LINK stand ard and its features.
What is i.LINK?
i.LINK is a digital serial interface for
transferring digit al video, digital audio, an d
other data to other i.LI N K - compatible device.
You can also control other device using the
i.LINK.
i.LINK-compatible device can be connected
using an i.LI NK cable. Pos sible appl ications ar e
operations and data transactions with various
digital AV devices.
When two or more i.LINK-compatible device
are connected to th is uni t in a dai sy chain,
operation s and data transact i ons are possible
with not only the device that this unit is
connected to but also with other devices via the
directly connect ed device.
Note, however, that the method of operation
sometimes varies according to the
characteristics and specifications of the device
to be connected. Also, operations and data
transactions may not be possible on some
connected device.
b Note
• Normally, only one device can be conn ected to this
unit with the i.LINK cable. When connecting this
unit to i.LINK-compatible device hav ing two or
more DV Interfaces, refer to the operating
instructions of the device to be connected.
z Tips
• i.LINK is a more familiar term for the IEEE 1394
data transport bus proposed by Sony, an d is a
trademark approved by many corpor a tions.
• IEEE 1394 is an international standard standardized
by the Institute of Electrica l an d Ele ct r onic s
Engineers.
Additional Information
About i.LINK Baud rate
i.LINK’s maximum baud rate varies according
to the device. There ar e t hr ee types.
S100 (approx. 100M bps*)
S200 (approx. 200M bps)
S400 (approx. 400M bps)
The baud rate is listed under “Specifications” in
the operating inst ructions of each piec e of
,continued
Additional Information
83
Page 84
device. It is also indicated near the i.LIN K
interface on some device.
The maximum baud rate for device that does not
have any indicat io n (s uch as this unit) is
“S100.”
The baud rate may differ from the indicated
value when the unit is connected t o devi ce with
a different maximum baud rate.
* What is Mbps?
Mbps stands for “megabits per sec ond,” or the
amount of data that can be sent or received in one
second. For example, a baud rate of 100 Mbps means
that 100 megabits of data can be sent in one se con d.
To use i.LINK functions on this unit
For details on how to dub when this unit is
connected to other video device having a DV
Interface, see page 62, 63.
This unit can also be connected to other i.LINK
(DV Interface) compatible device made by
Sony (e.g. a VAIO series personal computer) as
well as to video devi ce.
Before connecting this unit to your computer,
make sure that application software supported
by this unit is already installed on your
computer.
Some i.LINK compatible video device such as
Digital Televisions, DVD recorders/players,
and MICROMV recorders/players are not
compatible with DV device. Before connecting
to other device, be sure to confirm whet her the
device is compatible with DV device or not.
For details on precautions and compatible
application softwa re , refe r also to the oper at ing
instructions for the device to be connected.
About the required i.LINK cable
Use the Sony i.LINK 4-pin-to-4-pin cable
(during DV dubbi ng).
i.LINK and are tradema rks of Sony
Corporation.
Maintenance and precautions
On use and care
• Do not use or store the camcorder and
accessories in the following locations.
– Anywhere extremely hot or cold . Never
leave them exposed to temperatures above
60°C (140°F), such as under direct sunlight,
near heaters or in a car parked in the sun .
They may malfunct i on or become
deformed.
– Near strong m agnetic fields or me chanical
vibration. The camcorder may malfunction.
– Near strong radio waves or radiation. The
camcorder may not be able to record
properly.
– Near AM recei vers and video equipme nt .
Noise may occur.
– Sandy beach or anywhere dusty. If sand or
dust gets in your camcorder, it may
malfunction. Sometimes this malfunction
cannot be repaired.
– Near windows or outdoors, where the LCD
screen, the viewf i nder, or the lens may be
exposed to direct sunlight. This damages
the inside of the viewfinder or the LCD
screen.
– Anywher e very humid.
• Operate your camcorder on DC 7.2 V (battery
pack) or DC 8.4 V (AC Adaptor).
• For DC or AC operation, use the accessories
recommended in these operating instructions.
• Do not let your camcorder get wet, fo r
example, from rain or sea water. If your
camcorder gets w et, it may malfunction.
Sometimes this malfunction cannot be
repaired.
• If any solid object or liquid get inside the
casing, unplug your camcorder and have it
checked by a Sony dealer before opera ti ng it
any further.
• Avoid rough handling, disas sembling,
modifying, or m echanical shock. Be
particularly careful of the lens.
• Keep the POWER switch setting to (CHG)
OFF when you are not using your camcorder.
Additional Information
84
Page 85
• Do not wrap your camcorder with a towel, for
example, and operate it. Doing so might cause
heat to build up inside.
• When disconnecting the mains lead, pull by
the plug and not th e l ead.
• Do not damage the ma ins lead such as by
placing anything heavy on it.
• Keep metal contacts cl ean.
• Keep the Remote Comman der and buttontype battery out of children’s reach. If the
battery is accidentally swallowed, consult a
doctor immediately.
• If the battery electrolytic liquid has leaked,
– consult your local authorized Sony service
facility.
– wash off any liquid that may have contacted
your skin.
– if any liquid ge t s i n your eyes, wash with
plenty of water and consult a doctor.
When not using your camcorder for a
long time
Occasionally turn it on and let it run such as by
playing back ta pes for about 3 minutes.
Otherwise, unpl ug it from the wall socke t .
This is not a malfunction. Do not close the
cassette lid until the cassette is ejected.
Notes on moisture condensation
Moisture may condense when you bring your
camcorder from a cold place into a warm place
(or vice versa) or w hen y ou us e yo ur c amcor der
in a humid place as shown below.
• When you bring your camcorder from a ski
slope into a place warmed up by a heating
device.
• When you bring your camcor der from an airconditioned car or room into a hot place
outside.
• When you use your camcorder after a squall or
a shower.
• When you use your camcorder in a hot and
humid place.
How to prevent moistur e condensation
When you bring yo ur cam corder from a cold
place into a warm place, put your camcorder in
a plastic bag and seal it tightly. Remove the bag
when the air temperature inside the plastic bag
has reached the surrounding temperat ure (after
about one hour).
Moisture condensation
If your camcorder is brought directly from a
cold place to a wa rm place, moisture m ay
condense insi de yo ur camc orde r, on t he surf ace
of the tape, or on the lens. In this state, the tape
may stick to the head drum and be damaged o r
your camcorder m ay not operate corr ectly. If
there is moisture inside your camcorder,
%Z Moisture condensat ion. Eject the cassette]
[
or [
% Moisture c ondens ati on. Turn of f fo r 1H.]
appears. The indicator will not appear when the
moisture condenses on the lens.
If moisture condensation has occurred
None of the functions except cassette ejection
will work. Eject the cassette, turn off your
camcorder, and leave it for about one hour with
the cassette lid op en. Your camcorder ca n be
used again if the
the power is turned on again.
If moisture starts to condense, your cam corder
sometimes cannot detect condensation. If this
happens, the cassette is sometimes not ejected
for 10 seconds aft er the cassette lid is op ened.
% or Z does not appear w hen
Video head
• When the video head becom es dirty, you
cannot record pictures normally, or distorted
picture or sound is played back.
• The video head suffers fr om wear after long
use. If you cannot o bt ain a clear image even
after using a cleaning cassette, it might be
because the video head is worn. Please contact
your Sony dealer or loc al authorized Sony
service facility to have the video head
replaced.
• For TRV228E/428E:
If the following problem occurs, clean the
video heads for 10 seconds with the Sony
V8-25CLD cleaning cassette (optional).
– Playback pictures contains noise or the
screen is displayed in blue.
– Playback pictures are hardly visible.
– Playback pictures do not appear.
,continued
Additional Information
Additional Information
85
Page 86
– [ Dirty video head. Use a cleaning
cassette.] appears on the screen during
recording.
• For TRV255E/265E:
If the following problem occurs, c lean the
video heads for 10 seconds with the Sony
V8-25CLD cleaning cassette (optional).
– Mosaic-pattern noise appears on the
playback picture or the screen is displayed
in blue.
– Playback pictures do not move.
– Playback pic tu re s do not appear or the
sound breaks off .
– [ Dirty video head. Use a cleaning
cassette.] appears on the screen during
recording.
LCD screen
• Do not add excessive pressure on the LCD
screen, as it may cause damage.
• If your camcorder is used in a c ol d pl ace, a
residual image may appear on the LCD screen.
This is not a malfunction.
• While using your camcor der, the back of the
LCD screen may heat up. This is not a
malfunction.
To clean the LCD scree n
• If fingerprints or dust make th e LCD s creen
dirty, it is recommended you using the LCD
Cleaning Kit (optional) to clean it. When you
use the LCD Cleaning Kit (optional), do not
apply the cleaning liquid directly to the LCD
screen. Use cleaning paper moistened with the
liquid.
On handli ng the casing
• If the casing is soiled, cle an the camcorder
body with a soft clot h l i ght ly moistened with
water, and then wipe th e casing with a d ry soft
cloth.
• Avoid the following to av oi d damage to the
finish.
– Using chemica ls such as thinner, benzine,
alcohol, chemical cloths, re pellent and
insecticide.
– Handling wit h above substances on yo ur
hands.
– Leaving the casing in contact with rubber or
vinyl objects fo r a long period of time.
About care and storage of the lens
• Wipe the surface of th e le ns clean with a soft
cloth in the following instances:
– When there are fi ngerprints on the lens
surface.
– In hot or humid lo cat ions
– When the lens is exposed t o salty air su ch as
at the seaside.
• Store in a well-ventilat ed location subject to
little dirt or dust.
• To prevent molds periodically clean the lens
as described ab ove.
It is recommended you operate your camcorder
about once a month to keep it in an optimum
state for a long time.
To charge the pre-installed button-type
battery
Your camcorder has a pre-installed button-type
battery to retain the date, time, and other
settings ev en w hen th e PO WER sw it ch is set t o
(CHG) OFF. The pr e- installed button-type
battery is always ch arged while you are usin g
your camcorder but it will get discharged
gradually if you do not use your camcorder. The
button-type battery will be fully discharged in
about 3 months if you do not use your
camcorder at al l. However, even if the preinstalled button-type battery is not charged, the
camcorder oper ation will not be affect ed as long
as you are not recording the date.
Procedures
Connect your camcorder to a wall socket using
the supplied AC A daptor, and leave it w i th the
POWER switch set to (CHG) OFF for more
than 24 hours.
Additional Information
86
Page 87
Specification
Video camera recorder
System
Video recording system
For TRV228E/428E:
2 rotary heads, Helical scanning FM system
For TRV255E/265E:
2 rotary heads, Helical scanning system
Audio recording system
For TRV228E/428E:
Rotary heads, FM system
For TRV255E/265E:
Rotary heads, PCM system
Quantization: 12 bits (Fs 32 kHz, stereo 1,
stereo 2), 16 bits (Fs 48 kHz, stereo )
Video sign al
PAL color, CCIR standards
Usable cassette
8 mm video form at cassette
Tape speed
For TRV228E/428E:
SP: Approx. 20.05 mm/s
LP: Approx. 10.06 mm/s
For TRV255E/265E:
SP: Approx. 28.70 mm/s
LP: Approx. 19.13 mm/s
Recording/playback time (using 90 min. Hi8/
Digital8 video cassette)
For TRV228E/428E:
SP: 1 h 30 min
LP: 3 h
For TRV255E/265E:
SP: 1 h
LP: 1 h 30 min
Fast forward/rewind time (using 90 min. Hi8/
Digital8 video cassette)
Approx. 5 min
Viewfinder
Electric view f inder (monochrome)
Image device
For TRV228E/428E:
3.0 mm (1/6 type) CCD (Charge Coupled
Device)
Gross: Approx. 380 000 pixels
Effective: Approx. 230 000 pi xe ls
For TRV255E/265E:
3.0 mm (1/6 type) CCD (Charge Coupled
Device)
Gross: Approx. 540 000 pixels
Effective: Approx. 350 000 pixels
Lens
Combined power zoom lens
Filter diameter: 37 mm (1 1/2 in.)
20 × (Optical), 990 × (Digi ta l)
F=1.6 - 2.4
Focal length
2.5 - 50 mm (1/8 - 2 in.)
When converted to a 35 mm still camera
42 - 840 mm (1 11/16 - 33 1/8 in.)
Color temperature
Auto
Minimum ill u mination
For TRV228E/428E:
1 lx (lux) (F 1.6)
For TRV255E/265E:
4 lx (lux) (F 1.6)
0 lx (lux) (in the NightShot plus mode)*
* Objects unable to be seen due to the dark can be
shot with infrared lightin g.
Input/Output connectors
S video output
4-pin mini DIN
Luminance signal: 1 Vp-p, 75 Ω (ohms),
unbalanced
Chrominance signal: 0. 3 V p-p, 75 Ω (ohms),
unbalanced
Audio/Video output
AV MINIJACK
Video signal: 1 Vp-p, 75 Ω (ohms),
unbalanced, sync negative
Audio signal: 327 mV (at output impedance
more than 47 kΩ (kilohms)), Output
impedance with less than 2.2 kΩ (kilohms)
For TRV228E/428E:
Monaural minijack ( ø 3. 5 mm )
For TRV255E/265E:
Stereo minijack (ø 3.5 mm)
RFU DC OUT
For TRV228E/428E:
Mini-minijack (ø 2.5 mm), DC5V
DV input
For TRV265E:
4-pin connector
DV output
For TRV255E/265E:
4-pin connector
Additional Information
,continued
Additional Information
87
Page 88
USB jack
For TRV255E/265E:
mini-B
LCD screen
6.2 cm (2.5 type)
Total dot number
123 200 (560 × 220)
General
Power requireme nts
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power consumption (when using the
battery pack)
For TRV228E/428E:
During camera recording using the viewfinder
1.8 W
During camera recording usi ng the LCD
2.7 W
For TRV255E/265E:
During camera recording usi ng viewfinder
2.5 W
During camera recording usi ng LCD
3.4 W
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
-20°C to + 60°C (-4°F to + 140°F)
Dimensions (approx.)
85 × 98 × 151 mm (3 3/8 × 3 7/8 × 6 in.) (w/h/
d)
Mass (Approx.)
780 g (1 lb 11 oz) main unit only
890 g (1 lb 15 oz) including the
NP-FM30 rechargeable battery pack, Hi8/
Digital8 cassette, lens cap, and shoulder strap
Supplied accessories
See page 11.
AC Adaptor AC-L15A/L15B
Power requirements
AC 100 - 240 V, 50/60 Hz
Current consumption
0.35 - 0.18 A
Power consumption
18 W
Output voltage
DC 8.4 V, 1.5 A
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
-20°C to + 60°C (-4°F to + 140°F)
Dimensions (approx.)
56 × 31 × 100 mm (2 1/4 × 1 1/4 × 4 in.) (w/h/
d) excluding the project in g pa rts
Mass (approx.)
190 g (6.7 oz) excluding the m a ins lea d
Rechargeable battery pack (NP-FM30)
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
5.0 Wh (700 mAh)
Dimensions (approx.)
38.2 × 20.5 × 55.6 mm
(1 9/16 × 13/16 × 2 1/4 in.) (w/h/d)
Mass (approx.)
65 g (2.3 oz)
Operating temperature
0°C to 40°C (32°F to 104°F)
Type
Lithium ion
Design and specificat io n s are subject to change
without notice.
Additional Information
88
Page 89
Types of differences
Model
TRV228E TRV428E TRV255E TRV265E
Recording system Hi8 Hi8 Digital8 Digital8
Playback system Hi8/8 Hi8/8 Digital8 Digital8
Audio recording Monaural Monaural Stereo Stereo
AUDIO/VIDEO jack OUT OUT OUT OUT
S VIDEO jack OUT OUT OU T OUT
DV Interface — — OUT IN/OUT
USB jack — —
SteadyShot —
Remote sensor
RFU jack
Provided
z
— Not provided
CCD- DCR-
zz z
zz
zz
zz
—
——
z
Additional Information
Additional Information
89
Page 90
Quick Reference
Identifying parts and controls
Camcorder
A Lens cap (p. 21, 25)
B LCD screen (p. 2, 16)
C OPEN button (p. 16)
D VOLUME –/+* button (p. 34)
E END SEARCH button (p.33)
F Speaker
G Viewfinder (p.2, 16)
If you attach the large capacity battery pack
NP-QM71/QM71D/QM91/QM91D
(optional) to the camcorder, extend and lift
up the viewfinder and adjust its angle.
H Batter y pack
I LIGHT button (p. 23)
J FADER butt on (p. 30)
K BACK LIGHT button (p. 27)
L FOCUS button (p. 29)
Quick Reference
90
M SEL/PUSH EXEC dial (p. 43)
* This button has a tactile dot.
To attach the lens cap
Page 91
A Built-in light (p.23)
B Lens
C Infrared ray emitter (p.64, 69)/
For TRV228E/428E/ TRV265E:
Remote sensor
D Camera recording la mp (p. 21, 26)
E Microphone
F NIGHTSHOT PLUS switch (p. 28)
G EASY button (p. 26, 36)
H DSPL/BATT INFO button (p. 13, 37)
Quick Reference
A Jack cover
B For TRV255E/265E:
A/V OUT jack (p. 39, 62)
C For TRV265E:
DV Interface (p.62)
For TRV255E:
DV OUT Interface (p. 62)
D For TRV255E/265E:
(USB) jack
E S VIDEO OUT jack (p. 39, 61)
F For TRV228E/428E:
A/V OUT jack (p. 39, 61)
G For TRV228E/428E:
RFU DC OUT jack (p. 40)
Quick Reference
,continued
91
Page 92
A RESET button (p. 73)
B For TRV255E/265E:
BURN DVD/VCD
You can easily take a picture reco rded on
the tape and burn it onto a DVD or CD-R.
See the sup plied “Computer Applications
Guide” for details.
For TRV228E/428E:
EASY DUB (Easy Dubbi ng) button
(p. 64)
C TITLE button (p. 31)
D EXPOSURE button (p. 28)
E MENU button* (p. 43)
F Video control button s ( p .34)
STOP (stop)
REW (rewind)
PLAY (playback)*
FF (fast-forward)
PAUSE (pause)
G CHG (charge) lamp (p. 12)
H CAMERA mode lamps (p. 15)
I PLAY/EDIT mode lamp (p.15)
J For TRV265E:
Rec buttons (p. 68)
REC (rec)
K For TRV228E/428E:
COUNTER RESET button (p. 21)
L For TRV228E/428E:
TIME button (p. 18, 25)
M For TRV228E/428E:
DATE button (p. 1 8, 25)
* This button has a tactile dot.
Quick Reference
92
Page 93
A Viewfinder lens adjustment lever (p. 16)
B Eyecup
C Cassette lid
D OPEN/EJECT lever (p. 18)
E Tripod receptacle
Make sure that the length of the tr ipod
screw is le ss than 5.5 m m (7 /32 inch).
Otherwise, you cannot attach the tripod
securely, and the screw may damage your
camcorder.
Quick Reference
A Power zoom lever (p. 23)
B BATT (battery) release butto n (p. 12)
C Hooks for shoulder st rap
D For TRV255E/265E:
PHOTO button (p. 25)
E POWER switch (p. 15)
F Grip belt (p.3)
G REC START/STOP button (p. 21)
H DC IN jack (p. 12)
To attaching the shoulder strap
Attach the shoulder strap supplied with your
camcorder to the hooks for the shoulder strap.
,continued
Quick Reference
93
Page 94
Remote Commander
Remove th e insulation sheet before using th e
Remote Commander.
For TRV228E/428E:
To remove the insulation sheet
Insulation sheet
To change the button-type battery
1
While pressing on the tab, inset your
fingernail into the slit to pull out the
battery case.
For TRV265E:
A Transmitter
After turning on your camcorder, point
towards the rem ot e sensor to control your
camcorder.
B REC START/STOP button (p. 21)
C Power zoom button (p. 23)
D Video control buttons (Rewind, Playback,
Fast-forward, Pause, Stop, Slow) (p. 34)
E DISPLAY button (p.37, 40)
F PHOTO button (p. 25)
G SEARCH M. button (p. 41, 42)
H ./> buttons (p. 41, 42)
I ZERO SET MEMORY button (p. 40)
Tab
2 R emove the button -type lithium battery.
3 Pl ace a new button-type lithium battery
with the + side facing up.
4 I n sert the battery ca se back into the
Remote Commander until it clicks.
Quick Reference
94
Page 95
CAUTION
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Discard used batteries according to the
manufacturer ' s i nstructions.
b Notes on the Remote Commander
• A button-type lithium battery (CR2025) is use d in
the Remote Commander. Do not use batteries other
than CR2025.
• Point the remote sensor away from strong light
sources such as direct sunlight or overhead lighting.
Otherwise, the Remote Commander may not
function properly.
• When you are operating with the Remo te
Commander supplied with your cam co rd er, your
VCR may also operate. In that case, select a
commander mode other than VTR 2 for your VCR,
or cover the sensor of your VCR with black paper.
,continued
Quick Reference
Quick Reference
95
Page 96
Indicators for the LCD screen and viewfinder
Following indicators will appear on the LCD
screen and view fi nder to indicate the st at e of
your camcorder.
Indicators and their on-screen/viewfinder
positions vary depending on your cam corder
model.
Example: Indicators in the CAMERA mode
Time code (p. 21)/Tape counter (p. 21)/Selfdiagnosis (p. 78)/Tape pho to reco rd i ng (p. 25)
0:00:00STBY60min
Indicators Meanings
y60min Remaining battery time
SP LP Recording mode (p. 21)
STBY REC Recording standby/
Tape photo recording
Built-light (p. 23)
(p. 21)
recording mode
Mirror mode (p. 24)
(p. 25)
Format indicator
Audio mode (p. 54)
Remaining tape (p. 21)
Interval recording (p.56)
Frame recording (p. 55)
DV input (p. 68)
Zero set memory (p. 40)
NightShot plus (p. 28)
Indicators Meanings
Q E Z Warning (p. 78)
Manual exposure (p. 28)
9 Manual focus (p. 29)
. Back light (p. 27)
PROGRAM AE (p.44)
Picture effect (p.45)
16:9 WIDE/CINEMA/16:9
FULL (p. 48)
( ) SteadyShot off (p. 50)
Quick Reference
96
Page 97
Index
Numerics
16:9 WIDE mode.........48, 49
21-pin adaptor....................40
A
A/V connecting cable
.........................39, 61, 62
AC Adaptor........................15
Adjusting the viewfinder ...16
AUDIO MIX......................52
AUDIO MODE..................54
AUTO DATE.....................57
AUTO SHTR.....................46
Auto shut off fu nction
(A.SHUT OFF) ...........59
B
BACK LIGHT ...................27
Battery
Battery Info .................13
Battery pack ................12
Remaining battery time
........................21, 82
BEEP..................................59
BLACK FADER................30
Built-in light.......................23
BURN DVD/VCD .............92
Button-type battery
Commander.................86
Remote Commander....94
C
Camera settings data display
.....................................37
Cassette........................18, 81
Charging the battery
Battery Pack................12
Pre-installed button-type
battery...................86
Cleaning cassette................86
Clock set (CLOCK SET)
...............................17, 57
COMMANDER.................60
D
Data code (DATA CODE)
..............................37, 59
Date search........................41
Date/time...........................37
DEMO MODE ..................58
Digital program editing
(VIDEO EDIT)...........68
Digital zoom (D ZOOM)...47
Digital8 system.................. 81
Display
DISPLAY ...................60
Display indicator.........96
DNR...................................52
Dual sound track tape........51
Dubbing.............................61
E
Easy Dubbing....................64
Easy Handycam........... 26, 36
EDIT..................................51
END SEARCH..................33
Exposure............................27
F
FADER..............................30
Focus .................................29
Frame record i ng
(FRAME REC)...........55
Full charge .........................12
G
Grip belt...............................3
H
Hi8/standard 8 mm system
....................................81
HiFi SOUND.....................51
I
i.LINK ...............................83
i.LINK cable ................62, 68
“InfoLITHIUM” battery pack
....................................82
Infrared ray emitter......64, 69
Interval recording (INT . REC )
....................................56
L
Language ( LANGUAGE)
.............................. 19, 58
LCD back light (LCD B.L.)
.................................... 53
LCD brightness (LCD
BRIGHT).................... 16
LCD COLOR.................... 53
LCD screen ......................... 2
LP (Long Play)
See Recordin g mode (REC
MODE)
LTR SIZE.......................... 57
M
Main sound
See HiFi SOUND
Menu................................. 43
CAMERA SET........... 47
LCD SET.................... 53
MANUAL SET.......... 44
OTHERS .................... 59
PLAYER SET............ 51
SETUP MENU........... 57
TAPE SET.................. 54
VCR SET.................... 51
Mirror mode......................24
Moisture condensation...... 85
Monaural..................... 21, 40
MONOTONE FADER...... 31
MOSAIC FADER............. 30
N
NightShot Light
(N.S. LIGHT)....... 29, 50
NightShot plus ..................28
NTSC ................................ 80
O
Operation confirmation beep
See BEEP
ORC .................................. 54
P
PAL................................... 80
Photo scan......................... 42
Photo search......................41
Picture effect
(P EFFECT)................45
Quick Reference
,continued
Quick Reference
97
Page 98
Picture search....................35
Playing time ......................14
Power mode.......................15
PROGRAM AE.................44
V
Video head.........................85
Viewfinder.........................16
Volume ..............................34
R
Recording capacity
Display........................22
REMAIN .................... 55
Recording lamp
(REC LAMP)..............60
Recording mode
(REC MODE).......22, 54
Recording time..................13
Remote Commander..........94
Remote sensor...................91
RESET...............................92
S
S video.........................40, 62
Self-diagnosis display .......78
Setting the date and time... 17
Skip scan ...........................35
SP (Standard Play)
See Recordin g mode (REC
MODE)
STEADYSHOT.................50
Stereo...........................21, 40
STRIPE FADER ...............31
Sub sound
See HiFi SOUND
T
Tape counter......................21
Tape photo recording ........ 25
TBC...................................52
Telephoto
See Zoom
Time code..........................21
Title...................................31
TV color systems...............80
W
Warning indicators.............78
Warning messages.............79
WHITE FADER ................30
Wide angle
See Zoom
WORLD TIME..................59
Write-protect tab................81
Z
Zero set memory................40
Zoom..................................23
U
USB jack ...........................91
USB Streaming
(USB STREAM) ........57
Using abroad ............ .........80
Quick Reference
98
Page 99
Page 100
Printed in Japan
Loading...
