Operating Instructions

Link-to-Cell Bluetooth Convergence Solution

Model No.

KX-TGE260 KX-TGE262 KX-TGE263

KX-TGE264 KX-TG454SK KX-TG484SK

KX-TGE270

KX-TGE272

KX-TGE273

KX-TGE274

KX-TGE275 KX-TG465SK

Model shown is KX-TGE260.

Before initial use, see “Getting Started” on page 11.

Thank you for purchasing a Panasonic product.

Please read these operating instructions before using the unit and save them for future reference.

Consulte “Guía Rápida Española”, página 79.

For assistance, visit our Web site: http://www.panasonic.com/help for customers in the U.S.A. or Puerto Rico.

Please register your product: http://www.panasonic.com/prodreg

TGE26x_27x(en)_0123_ver110.pdf 1 2015/01/23 9:57:38

Introduction

Model composition .......................................3

Accessory information ..................................3

Important Information

For your safety .............................................7

Important safety instructions ........................8

For best performance ...................................8

Other information .........................................9

Specifications .............................................10

Getting Started

Setting up ...................................................11

Controls ......................................................13

Display icons/Indicators .............................14

Language settings ......................................16

Date and time .............................................16

Recording your greeting message .............16

Other settings .............................................16

Link to Cell

Link to cell feature ......................................18 Pairing a cellular phone

..............................18

Link to cell settings .....................................19

Making/Answering Calls Using the Handset

Making cellular calls ...................................22

Making landline calls ..................................22

Answering calls ..........................................23

Useful features during a call .......................23

Power back-up operation for landline .........26

Making/Answering Calls Using the Base Unit

Making cellular calls ...................................28

Making landline calls ..................................28

Answering calls ..........................................28

Useful features during a call .......................29

Locator/Intercom

Handset locator ..........................................31

Cell locator .................................................31

Intercom .....................................................31

Phonebook

Phonebook .................................................33

Speed dial ..................................................36

Programming

Menu list .....................................................37

Alarm ..........................................................44

Silent mode ................................................45

Call block ....................................................46

Other programming ....................................47

Registering a unit .......................................48

Caller ID Service

Using Caller ID service ...............................49

Caller list ....................................................49

Using Bluetooth Devices

Copying phonebook from a cellular phone

(phonebook transfer) ..................................52

Text message (SMS) alert .........................53 Using a Bluetooth wireless headset (optional)

for landline calls .........................................54

Answering System for Landline

Answering system for landline ...................56

Turning the answering system on/off .........56

Greeting message ......................................56

Listening to messages ...............................57 Advanced new message alerting

features ......................................................58

Remote operation .......................................60

Answering system settings .........................61

Useful Information

Voice mail service for landline ....................63

Wall mounting ............................................64

Error messages ..........................................67

Troubleshooting .........................................68

FCC and other information .........................76

Guía Rápida Española

Guía Rápida Española ...............................79

Appendix

Customer services .....................................89 Warranty (For United States and Puerto

Rico) ...........................................................90

Index

Index...........................................................92

TGE26x_27x(en)_0123_ver110.pdf 2 2015/01/23 9:57:40

Model composition

n KX-TGE260 series n KX-TGE270 series

R Model shown is KX-TGE262. R Model shown is KX-TGE272.

Series Model No.

Base unit Handset

Part No. Part No. Quantity

KX-TGE260 series

KX-TGE260 KX-TGE260 KX-TGEA20 1

KX-TGE262 KX-TGE260 KX-TGEA20 2

KX-TGE263 KX-TGE260 KX-TGEA20 3

KX-TGE264 KX-TGE260 KX-TGEA20 4

KX-TG454SK KX-TGE260 KX-TGEA20 4

KX-TG484SK KX-TGE260 KX-TGEA20 4

KX-TGE270 s

eries

KX-TGE270 KX-TGE270 KX-TGEA20 1

KX-TGE272 KX-TGE270 KX-TGEA20 2

KX-TGE273 KX-TGE270 KX-TGEA20 3

KX-TGE274 KX-TGE270 KX-TGEA20 4

KX-TGE275 KX-TGE270 KX-TGEA20 5

KX-TG465SK KX-TGE270 KX-TGEA20 5

Accessory information

Supplied accessories

No.

Supplied handset qty.

1 unit*12 units*23 units*34 units*45 units

Accessory item/ O

rder number

Accessory quantity

A AC adaptor/PNLV226Z 1 1 1 1 1

For assistance, please visit http://www.panasonic.com/help

Introduction

TGE26x_27x(en)_0123_ver110.pdf 3 2015/01/23 9:57:40

No.

Supplied handset qty.

1 unit*12 units*23 units*34 units*45 units

Accessory item/ Order number

Accessory quantity

B Telephone line cord/

PQJA10075Z

1 1 1 1 1

Wall mounting adaptor

1 1 1 1 1

D Rechargeable batteries/

HR-4DPA

2 4 6 8 10

Handset cover

*7,

1 2 3 4 5

Belt clip

1 2 3 4 5

Charger

*10

– 1 2 3 4

*1 KX-TGE260/KX-TGE270 *2 KX-TGE262/KX-TGE272 *3 KX-TGE263/KX-TGE273 *4 KX-TGE264/KX-TGE274/KX-TG454SK/KX-TG484SK *5 KX-TGE275/KX-TG465SK *6 PNKL1044Z1: White, PNKL1044Z2: Black *7 The handset cover comes attached to the handset. *8 PNYNTGEA20BR: Black, PNYNTGEA20SR: White *9 PNKE1312Z1: White, PNKE1312Z2: Black *10 PNLC1050ZB: Black, PNLC1050ZT: Titanium Black, PNLC1050ZS: Silver

B C D E

F G

Additional/replacement accessories

Please contact your nearest Panasonic dealer for sales information (page 89).

Accessory item Order number

Rechargeable b

atteries

HHR-4DPA

R To order, please visit

http://www.panasonic.com/batterystore

Battery type: – Nickel metal hydride (Ni-MH) – 2 x AAA (R03) size for each handset

Headset KX-TCA60, KX-TCA93, KX-TCA400, KX-TCA430

For assistance, please visit http://www.panasonic.com/help

Introduction

TGE26x_27x(en)_0123_ver110.pdf 4 2015/01/23 9:57:40

Accessory item Order number

T-adaptor KX-J66

Range extender

KX-TGA405

Key detector

KX-TGA20

*1 Replacement batteries may have a different capacity from that of the supplied batteries. *2 By installing this unit, you can extend the range of your phone system to include areas

where reception was previously not available. This product can be purchased online. Please visit our Web site: http://www.panasonic.com/RangeExtender

*3 By registering the key detector (4 max.) to a Panasonic Digital Cordless Phone and

attaching it to an easy-to-lose item in advance, you can locate and find the mislaid item to which the key detector is attached. Please visit our Web site: http://panasonic.net/pcc/products/telephone/p/tga20/

Other information

R Design and specifications are subject to change without notice. R The illustrations in these instructions may vary slightly from the actual product.

Expanding your phone system

Handset (optional): KX-TGEA20

You can expand your phone system by registering optional handsets (6 max.) to a single base unit. R Optional handsets may be a different color

from that of the supplied handsets.

Bluetooth® devices

You can expand your phone system by pairing the following units to a single base unit.

Your Bluetooth cellular phone

: 2 max.

(for cellular calls: page 18)

Your Bluetooth headset

: 1 max.

(for a wireless hands-free conversation: page 54)

*1 Your cellular phone and headset must be Bluetooth wireless technology compatible. For

more details and the list of compatible cellular phones, please visit our Web site: http://www.panasonic.com/link2cell

For assistance, please visit http://www.panasonic.com/help

Introduction

TGE26x_27x(en)_0123_ver110.pdf 5 2015/01/23 9:57:40

Trademarks

R The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,

and any use of such marks by Panasonic Corporation is under license.

R All other trademarks identified herein are the property of their respective owners.

For assistance, please visit http://www.panasonic.com/help

Introduction

TGE26x_27x(en)_0123_ver110.pdf 6 2015/01/23 9:57:40

For your safety

To prevent severe injury and loss of life/ property, read this section carefully before using the product to ensure proper and safe operation of your product.

WARNING

Power connection

R Use only the power source marked on the

product.

R Do not overload power outlets and

extension cords. This can result in the risk of fire or electric shock.

R Completely insert the AC adaptor/power

plug into the power outlet. Failure to do so may cause electric shock and/or excessive heat resulting in a fire.

R Regularly remove any dust, etc. from the

AC adaptor/power plug by pulling it from the power outlet, then wiping with a dry cloth. Accumulated dust may cause an insulation defect from moisture, etc. resulting in a fire.

R Unplug the product from power outlets if it

emits smoke, an abnormal smell, or makes an unusual noise. These conditions can cause fire or electric shock. Confirm that smoke has stopped emitting and contact us at http://www.panasonic.com/contactinfo

R Unplug from power outlets and never touch

the inside of the product if its casing has been broken open.

R Never touch the plug with wet hands.

Danger of electric shock exists.

Installation

R To prevent the risk of fire or electrical

shock, do not expose the product to rain or any type of moisture.

R Do not place or use this product near

automatically controlled devices such as automatic doors and fire alarms. Radio waves emitted from this product may cause such devices to malfunction resulting in an accident.

R Do not allow the AC adaptor or telephone

line cord to be excessively pulled, bent or placed under heavy objects.

Operating safeguards

R Unplug the product from power outlets

before cleaning. Do not use liquid or aerosol cleaners.

R Do not disassemble the product. R Do not spill liquids (detergents, cleansers,

etc.) onto the telephone line cord plug, or allow it to become wet at all. This may cause a fire. If the telephone line cord plug becomes wet, immediately pull it from the telephone wall jack, and do not use.

Medical

R Consult the manufacturer of any personal

medical devices, such as pacemakers or hearing aids, to determine if they are adequately shielded from external RF (radio frequency) energy. (The product operates in the frequency range of

1.92 GHz to 1.93 GHz, and the RF transmission power is 115 mW (max.).)

R Do not use the product in health care

facilities if any regulations posted in the area instruct you not to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

CAUTION

Installation and location

R Never install telephone wiring during an

electrical storm.

R Never install telephone line jacks in wet

locations unless the jack is specifically designed for wet locations.

R Never touch uninsulated telephone wires or

terminals unless the telephone line has been disconnected at the network interface.

R Use caution when installing or modifying

telephone lines.

R The AC adaptor is used as the main

disconnect device. Ensure that the AC outlet is installed near the product and is easily accessible.

For assistance, please visit http://www.panasonic.com/help

Important Information

TGE26x_27x(en)_0123_ver110.pdf 7 2015/01/23 9:57:40

R This product is unable to make calls when:

– the handset batteries need recharging or

have failed.

– there is a power failure.

Battery

R We recommend using the batteries noted

on page 4. USE ONLY rechargeable

Ni-MH batteries AAA (R03) size.

R Do not mix old and new batteries. R Do not open or mutilate the batteries.

Released electrolyte from the batteries is corrosive and may cause burns or injury to the eyes or skin. The electrolyte is toxic and may be harmful if swallowed.

R Exercise care when handling the batteries.

Do not allow conductive materials such as rings, bracelets, or keys to touch the batteries, otherwise a short circuit may cause the batteries and/or the conductive material to overheat and cause burns.

R Charge the batteries provided with or

identified for use with this product only, in accordance with the instructions and limitations specified in this manual.

R Only use a compatible base unit (or

charger) to charge the batteries. Do not tamper with the base unit (or charger). Failure to follow these instructions may cause the batteries to swell or explode.

Attention:

A nickel metal hydride battery that is recyclable powers the product you have purchased. Please call 1-800-8-BATTERY (1-800-822-8837) for information on how to recycle this battery.

Important safety instructions

When using your product, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:

1. Do not use this product near water for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions.

SAVE THESE INSTRUCTIONS

For best performance

Base unit location/avoiding noise

The base unit and other compatible Panasonic units use radio waves to communicate with each other. R For maximum coverage and noise-free

communications, place your base unit: – at a convenient, high, and central

location with no obstructions between the handset and base unit in an indoor environment.

– away from electronic appliances such as

TVs, radios, personal computers, wireless devices, or other phones.

– facing away from radio frequency

transmitters, such as external antennas of mobile phone cell stations. (Avoid putting the base unit on a bay window or near a window.)

R Coverage and voice quality depends on the

local environmental conditions.

For assistance, please visit http://www.panasonic.com/help

Important Information

TGE26x_27x(en)_0123_ver110.pdf 8 2015/01/23 9:57:40

R If the reception for a base unit location is

not satisfactory, move the base unit to another location for better reception.

Environment

R Keep the product away from electrical noise

generating devices, such as fluorescent lamps and motors.

R The product should be kept free from

excessive smoke, dust, high temperature, and vibration.

R The product should not be exposed to

direct sunlight.

R Do not place heavy objects on top of the

product.

R When you leave the product unused for a

long period of time, unplug the product from the power outlet.

R The product should be kept away from heat

sources such as heaters, kitchen stoves, etc. It should not be placed in rooms where the temperature is less than 0 °C (32 °F) or greater than 40 °C (104 °F). Damp basements should also be avoided.

R The maximum calling distance may be

shortened when the product is used in the following places: Near obstacles such as hills, tunnels, underground, near metal objects such as wire fences, etc.

R Operating the product near electrical

appliances may cause interference. Move away from the electrical appliances.

Routine care

R Wipe the outer surface of the product

with a soft moist cloth.

R Do not use benzine, thinner, or any

abrasive powder.

Other information

CAUTION: Risk of explosion if battery is

replaced by an incorrect type. Dispose of used batteries according to the instructions.

Notice for product disposal, transfer, or return

R This product can store your private/

confidential information. To protect your privacy/confidentiality, we recommend that you erase information such as phonebook or caller list entries from the memory before you dispose of, transfer, or return the product.

Notice

ENERGY STAR

As an ENERGY STAR® Partner, Panasonic has determined that this product meets the ENERGY STAR guidelines for energy efficiency. ENERGY STAR is a U.S. registered mark.

For assistance, please visit http://www.panasonic.com/help

Important Information

TGE26x_27x(en)_0123_ver110.pdf 9 2015/01/23 9:57:40

Specifications

R Standard:

DECT 6.0 (Digital Enhanced Cordless Telecommunications 6.0) Bluetooth wireless technology 2.1

R Frequency range:

1.92 GHz to 1.93 GHz (DECT)

2.402 GHz to 2.48 GHz (Bluetooth)

R RF transmission power:

115 mW (max.)

R Power source:

120 V AC, 60 Hz

R Power consumption:

Base unit:

Standby: Approx. 1.2 W Maximum: Approx. 4.5 W

Charger:

Standby: Approx. 0.1 W Maximum: Approx. 1.8 W

R Operating conditions:

0 °C – 40 °C (32 °F – 104 °F), 20 % – 80 % relative air humidity (dry)

For assistance, please visit http://www.panasonic.com/help

Important Information

TGE26x_27x(en)_0123_ver110.pdf 10 2015/01/23 9:57:40

Setting up

Connections

R If you do not connect the telephone line

cord and use only cellular lines, set the cellular line only mode to use this unit more conveniently (page 20).

n Base unit

Connect the AC adaptor to the unit by pressing the plug firmly. Fasten the cord by hooking it. Connect the AC adaptor to the power outlet. Connect the telephone line cord to the unit, then to the single-line telephone jack (RJ11C) until you hear a click. A DSL/ADSL filter (not supplied) is required if you have a DSL/ADSL service.

Note:

R Use only the supplied Panasonic AC

adaptor PNLV226.

n Charger

Connect the AC adaptor to the power outlet.

Battery installation

R USE ONLY rechargeable Ni-MH batteries

AAA (R03) size (

R Do NOT use Alkaline/Manganese/Ni-Cd

batteries.

R Confirm correct polarities (

, ).

R Follow the directions on the display to set

up the unit.

For assistance, please visit http://www.panasonic.com/help

Getting Started

TGE26x_27x(en)_0123_ver110.pdf 11 2015/01/23 9:57:40

Battery charging

Charge for about 7 hours. R Confirm “Charging” is displayed (

R When the batteries are fully charged,

“Fully charged” is displayed.

Note when setting up

Note for connections

R The AC adaptor must remain connected at

all times. (It is normal for the adaptor to feel warm during use.)

R The AC adaptor should be connected to a

vertically oriented or floor-mounted AC outlet. Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become disconnected.

Note for battery installation

R Use the supplied rechargeable batteries.

For replacement, we recommend using the Panasonic rechargeable batteries noted on page 4, 8.

Note for battery charging

R It is normal for the handset to feel warm

during charging.

R Clean the charge contacts of the handset,

base unit, and charger with a soft and dry cloth once a month. Before cleaning the unit, disconnect from power outlets and any telephone line cords. Clean more often if the unit is exposed to grease, dust, or high humidity.

Battery level

Icon Battery level

High

Medium

Low

Needs charging.

Empty

Panasonic Ni-MH battery performance (supplied batteries)

Operation Operating time

In continuous use

10 hours max.

Not in use (standby)

8 days max.

*1 If eco mode is on.

Note:

R Actual battery performance depends on

usage and ambient environment.

Intelligent eco mode

This feature automatically reduces handset power consumption by suppressing handset transmission power when the handset is close to the base unit.

R When this feature is activated,

displayed. However, during a cellular call,

is not displayed even though this

feature is activated.

R Eco mode is turned off when the clarity

booster is activated (page 24).

For assistance, please visit http://www.panasonic.com/help

Getting Started

TGE26x_27x(en)_0123_ver110.pdf 12 2015/01/23 9:57:41

Controls

Handset

H I

Ringer indicator Belt clip holes Speaker

MjN/MkN (VOL.: Volume up/down) M N (TALK)

Dial keypad (*: TONE) Headset jack

MZN (SP-PHONE: Speakerphone) MFLASHNMCALL WAITN

Microphone Receiver Display

MOFFN M N (NOISE REDUCTION/Smart

function key)

indicator

Charge contacts

n Control type

Soft keys

By pressing a soft key, you can select the feature shown directly above it on the display. After a cellular phone is paired, MCELLN is displayed.

Navigator key

– M

DN, MCN, MFN, or MEN: Scroll through

various lists and items.

– (Volume: MDN or MCN): Adjust the

receiver or speaker volume while talking.

– MFN W: View the phonebook entry. – MEN REDIAL: View the redial list. – MCN CID (Caller ID): View the caller list.

Base unit

n KX-TGE260 series: page 3

M L K

B J

Charge contacts Speaker HEADSET indicator MANSWER ON/OFFN CELL 1 indicator CELL 2 indicator

For assistance, please visit http://www.panasonic.com/help

Getting Started

TGE26x_27x(en)_0123_ver110.pdf 13 2015/01/23 9:57:41

Message counter M N

(PLAY/STOP)

Message indicator

MLOCATES CELLN MHANDSET LOCATORN MjN/MkN (VOL.: Volume up/down) MERASEN M N (Skip) M N (Repeat)

n KX-TGE270 series: page 3

P O

BA N

J K

Charge contacts Speaker

MHOLDN MCONFN MREDIALN MPAUSEN MFLASHN MCALL WAITN MZN (SP-PHONE: Speakerphone)

SP-PHONE indicator HEADSET indicator CELL 1 indicator CELL 2 indicator Message counter M N (PLAY/STOP) Message indicator

MANSWER ON/OFFN MLOCATES CELLN MLOCATORN MINTERCOMN MjN/M

kN (VOL.: Volume up/down) MERASEN MMUTEN MCELL 1

N M

N (Skip)

MCELL 2

N M

N (Repeat)

Microphone Dial keypad (*:

TONE)

Display icons/Indicators

Handset display items

Item Meaning

Within base unit range

Out of base unit range

The landline is in use. R When flashing:

The call is put on hold.

R When flashing rapidly: An

incoming call is now being received.

A cellular line is in use.

R When flashing:

The cellular call is put on hold.

R When flashing rapidly:

A cellular call is being received.

A cellular phone is connected.

Ready to make/

receive cellular calls. R When turned off:

A cellular phone is not connected to the base unit. (page 20)

– A cellular call is being

done on that line.

– The cellular line is

selected for the setting.

Eco mode is on.

(page 12)

Noise reduction is set. (page 24)

Equalizer is set. (page 24)

Z Speakerphone is on.

(

page 22)

Ringer volume is off.

(page 39, 41)

Silent mode is on. (page 45)

For assistance, please visit http://www.panasonic.com/help

Getting Started

TGE26x_27x(en)_0123_ver110.pdf 14 2015/01/23 9:57:41

Item Meaning

Call sharing mode is off. (page 43)

Alarm is on. (page 44)

Handset number

Battery level

Blocked call (page 46)

Clarity booster is on.

(page 24)

In use

Answering system is being used by another handset or the base unit.

Cell1 in use

Someone is using the corresponding line.

Cell2 in use

C1&C2 in use

Line in use

*1 Corresponding cellular line(s) is(are)

indicated next to the item.

*2 During a cellular call, the item is not

displayed even though the feature is activated.

*3 Corresponding lines (1, 2: cellular line, L:

landline) are indicated next to the item. If all lines are turned off, no line is indicated.

Base unit display item

Item Meaning

“Greeting only” is

selected. Caller messages are not recorded. (page 62)

CELL indicators on the base unit

The CELL indicators show each cellular line status.

Status Meaning

On A cellular phone is connected.

Ready to make/receive cellular calls.

Status Meaning

Flashing – The cellular line is in use.

– Phonebook entries are

being copied from a cellular phone (page 52).

– The base unit is searching

for the paired cellular phone.

– The base unit is pairing a

cellular phone.

– A cellular call is put on hold.

Flashing rapidly

A cellular call is being received.

Light off – A cellular phone is not

paired to the base unit.

– A cellular phone is not

connected to the base unit (page 20).

Bluetooth HEADSET indicator on the base unit

The HEADSET indicator shows the Bluetooth headset status.

Status Meaning

On A Bluetooth headset is

connected to the base unit. Ready to use it.

Flashing – A Bluetooth headset is in

use.

– The base unit is searching

for the paired Bluetooth headset.

– The base unit is pairing a

headset.

– Mute is turned on.

Flashing rapidly

A landline call is being received.

Light off – The Bluetooth headset is

not connected to the base unit.

– A Bluetooth headset is not

paired to the base unit.

For assistance, please visit http://www.panasonic.com/help

Getting Started

TGE26x_27x(en)_0123_ver110.pdf 15 2015/01/23 9:57:41

Language settings

Display language

You can select either “English” or “Español” as the display language. The default setting is “English”.

1 MMENUN#110 2 M

bN: Select the desired setting. a

MSAVEN

3 MOFFN

Voice guidance language

You can select either “English” or “Español” as the voice guidance language

of the answering system. The default setting is

“English”.

1 MMENUN#112 2 M

bN: Select the desired setting.

3 MSAVEN a MOFFN

Date and time

1 MMENUN#101 2 Enter the current month, date, and year

by selecting 2 digits for each. Example: July 15, 2014 07 15 14

3 MOKN 4 Enter the current hour and minute

(12-hour clock format) by selecting 2 digits for each. Example: 9:30 09 30

5 *: Select “AM” or “PM”. 6 MSAVEN a MOFFN

Note:

R When English is selected as the display

language, 12-hour clock format is used. When Spanish is selected, 24-hour clock format is used.

Recording your greeting message

You can record your own greeting message instead of using a pre-recorded greeting message. See page 56 for details.

1 MMENUN#302 2 MbN: “Yes” a MSELECTN 3 Record a greeting message. a MSTOPN

a MOFFN

Other settings

Smart function key ( key)

The Smart function key (

key) is located

on the bottom of the handset and informs you with its flashing to allow you to activate the following features by simply pressing this key.

n When the indicator flashes rapidly,

you can:

– Answer the call (outside call, intercom).

(page 23, 32) – Stop paging. (page 31) – Stop the alarm sound. (page 45)

n When the indicator flashes slowly in

standby mode, you can:

– Listen to new messages. (page 57) – Listen to new voice mail messages.

(page 64) – View the caller list when there are

missed calls. (page 50) To activate these features, their Smart function key must be “On”. (page 17)

Using the Smart function key ( key)

When the

indicator flashes rapidly/slowly,

ress M

R The above features can be activated

depending the situation.

R If you answer a call using the Smart

function key, the speakerphone is activated.

R Even if the handset is placed on the base

unit or charger, the feature can be

For assistance, please visit http://www.panasonic.com/help

Getting Started

TGE26x_27x(en)_0123_ver110.pdf 16 2015/01/23 9:57:41

activated. You can talk or listen to new messages without lifting up the handset. If you want to perform further operations, lift up the handset.

R When the unit has new messages, new

voice mail messages, and missed calls, the unit can be operated to play the new messages first, play the new voice mail messages next, and then show the missed calls.

Setting the Smart function key

The Smart function key for the following features must be “On”. – “New message” (Default: On) – “New VM” (Default: On) – “Missed Call” (Default: Off) The settings can be set for each handset.

1 MMENUN#278 2 M

bN: Select the desired setting and press MSELECTN. R “

” is displayed next to the selected

features.

R To cancel a selected feature, press

MSELECTN again. “

” disappears.

3 MSAVEN a MOFFN

Note:

R If the

indicator flashes when the

handset is not placed on the base unit or charger, battery consumption is faster than usual.

Dialing mode

If you cannot make calls, change this setting according to your telephone line service. The default setting is “Tone”.

“Tone”: For tone dial service. “Pulse”: For rotary/pulse dial service.

1 MMENUN#120 2 M

bN: Select the desired setting.

3 MSAVEN a MOFFN

For assistance, please visit http://www.panasonic.com/help

Getting Started

TGE26x_27x(en)_0123_ver110.pdf 17 2015/01/23 9:57:41

Link to cell feature

You can connect your base unit and cellular phone using Bluetooth wireless technology, so that you can make or answer cellular calls using your phone system. This allows you to: – use the unit to talk on cellular calls even if

some areas of your home have poor cellular reception, simply by placing your cellular phone in an area with good reception.

– talk on cellular calls even if your cellular

phone is in your pocket or bag.

– enjoy cordless cellular calls even if your

cellular phone plugged in and charging.

Important:

R Your cellular phone must support the

Hands Free Profile (HFP) specification.

R You may pair 2 cellular phones and 1

headset.

R The unit can be used to talk on 2 lines at

the same time (for example, 2 cellular lines, or the landline and 1 cellular line).

R Only 2 Bluetooth devices can be used with

the unit at the same time (for example, 2 cellular lines, or the headset and 1 cellular line).

R Locate your cellular phone near the base

unit. If the cellular phone is too close to the base unit during a cellular call, you may hear noise. For best performance, we recommend placing the cellular phone between 0.6 m to 3 m (2 feet to 10 feet) away from the base unit.

Pairing a cellular phone

Important:

R For more details and the list of compatible

cellular phones, please visit our Web site: http://www.panasonic.com/link2cell

R Before pairing a Bluetooth enabled cellular

phone to the base unit, make sure that no other Bluetooth device such as a Bluetooth headset is connected to your cellular phone.

1 Handset:

For CELL 1: MMENUN#6241 For CELL 2: MMENUN#6242

R After the corresponding CELL indicator

on the base unit starts flashing, the rest of the procedure must be completed within 5 minutes.

2 Your cellular phone:

While the corresponding CELL indicator is flashing, follow the instructions of your cellular phone to enter the pairing mode. R Depending on your cellular phone, it

may ask you to enter the Bluetooth PIN (default: “0000”). If your cellular phone shows PassKey confirmation on its display, follow the directions to proceed.

3 Handset:

Wait until a long beep sounds. R It may take more than 10 seconds to

complete pairing.

R When the corresponding CELL

indicator lights up, the cellular phone is connected to the base unit. You are ready to make cellular calls.

4 MOFFN

Note:

R Make sure that your cellular phone is set to

connect to this product automatically. Refer to your cellular phone’s operating instructions.

R Make sure you cancel your cellular phone’s

current pairing if you want to pair it to the other line (page 18).

R The default setting for the text message

alert feature is “On(no announce)”, so when you pair your cellular phone to the base unit, this feature may be activated (page 53). (This depends on the version and type of cellular phone you are using.)

Unpairing a cellular phone

You can cancel the pairing of a cellular phone that is stored in the base unit.

1 For CELL 1: MMENUN#6111

For CELL 2: MMENUN#6112

2 MbN: “Yes” a MSELECTN

R When the cellular phone is unpaired,

the CELL indicator is turned off.

3 MOFFN

For assistance, please visit http://www.panasonic.com/help

Link to Cell

TGE26x_27x(en)_0123_ver110.pdf 18 2015/01/23 9:57:41

Link to cell settings

Selecting which unit receives cellular calls

You can select which unit rings and receives calls for a cellular line. When “All” is selected, all handsets and the base unit ring.

1 For CELL 1: MMENUN#6271

For CELL 2: MMENUN#6272

2 M

bN: Select the desired handset or “All”. a MSAVEN

3 MOFFN

Note:

R When you select a specific handset to

receive calls for a cellular line: – other handsets cannot answer the calls. – the base unit can answer the calls even

though it does not ring. However, you

can make the base unit ring by adjusting

the base unit ringer volume (page 39).

(KX-TGE270 series: page 3)

R When you change the setting to “All”, the

base unit ringer volume also returns to the lowest level even if the ringer volume has been changed.

R The units selected with this setting have the

text message alert feature (page 53) applied to them.

Ring as cell mode

Once this feature is turned on, the handset and base unit ring using the same ringer tone as your cellular phone. The following settings are available: – “Off”: Turn this feature off to use the

ringer tones of the handset and base unit. Caller information is announced depending on the Talking Caller ID setting (page 41).

– “On (with Talking CID)” (default):

The handset and base unit use your cellular phone’s ringer tone. Caller information is announced even if the Talking Caller ID is turned off.

– “On (without Talking CID)”: The

handset and base unit use your cellular phone’s ringer tone. Caller information is

not announced even if the Talking Caller ID is turned on.

Important:

R To use this feature, your cellular phone

must support Bluetooth in-band ringtone. Refer to your cellular phone’s operating instructions.

1 For CELL 1: MMENUN#6141

For CELL 2: MMENUN#6142

2 M

bN: Select the desired setting.

3 MSAVEN a MOFFN

Note:

R The units use the preset ringer tones

(page 41) instead of your cellular phone’s ringer tone when a cellular call is being received if: – your cellular phone is in silent mode

(depending on your cellular phone). – the base unit is in use. – 2 handsets are sharing a landline call.

R If your cellular phone is in silent mode with

“On (with Talking CID)” set, the unit announces caller information even when Talking Caller ID is turned off (page 41).

To use the handset ringer tone instead of your cellular phone’s ringer tone

Select “Off” in step 2, “Ring as cell mode”, page 19. To change the handset ringer tone for a cellular line, see page 39.

Auto connection to the Bluetooth devices (cellular phones or headset)

After pairing, your Bluetooth devices are connected to the base unit. If you move the Bluetooth devices out of base unit range, the Bluetooth devices are disconnected from the base unit. This feature allows the base unit to try to reconnect the Bluetooth devices at regular intervals when it returns within base unit range. You can set the interval. The default setting is “1 min”.

For assistance, please visit http://www.panasonic.com/help

Link to Cell

TGE26x_27x(en)_0123_ver110.pdf 19 2015/01/23 9:57:41

Important:

R When 3 Bluetooth devices (2 cellular

phones and 1 headset) are paired to the base unit, only 2 Bluetooth devices can be used with the unit at the same time, and the base unit loses its connection from other Bluetooth devices. To automatically resume the connection to Bluetooth devices, leave the auto connection on.

R Some cellular phones lose connection after

usage, please check the specifications of your cellular phone for more details.

1 MMENUN#632 2 M

bN: Select the desired setting.

3 MSAVEN a MOFFN

Note:

R Some cellular phones may ask you if you

accept the connection requirement from the base unit. In that case, select “Off” in step

2. Check the specifications of your cellular phone.

Connecting/disconnecting the cellular phone manually

If you will not be using the paired cellular phone’s link to cell feature temporarily (for example, you do not want the unit to ring when your cellular line receives a call), you can disconnect your cellular phone from the base unit. If you want to use it again, reconnect the cellular phone to the base unit.

Note:

R Even if a paired cellular phone was

disconnected from the base unit, if it is brought within the base unit’s range during the auto connection interval, it may automatically connect to the base unit (page 19).

R A disconnected cellular phone is not

unpaired from the base unit, so pairing it to the base unit again is unnecessary.

1 To connect/disconnect:

For CELL 1: MMENUN#6251 For CELL 2: MMENUN#6252 R A long beep sounds.

2 MOFFN

Cellular line only mode (If you do not use the landline)

If you do not use the landline, we recommend setting the unit to the cellular line only mode.

Important:

R If you turn on the “Cell line only

mode”, disconnect the telephone line cord from the base unit. Otherwise the “Cell line only mode” cannot be activated.

1 MMENUN#157 2 To turn on:

bN: “On” a MSELECTN a

bN: “Yes” a MSELECTN

To turn off:

bN: “Off” a MSELECTN

Note:

R Once you set this mode, you can use the

following buttons to make cellular calls: – for the handset, press M

N or MZN

instead of MCELLN (page 22). – for the base unit, press M

ZN instead of

the line button (MCELL 1N or MCELL 2N)

set for the cellular line selection

(page 21, 28). (KX-TGE270 series:

page 3)

R Once you set this mode, the following

features cannot be used: – Landline features (page 44) – Answering system (page 56)

Messages cannot be received. – Voice mail features (page 63)

R After this mode is turned on or off, the base

unit reboots. – Bluetooth connections from cellular

phones or headset are disconnected. If

the auto connection is turned on

(page 19), the cellular phones are

reconnected. –

will be displayed on the handset momentarily. The handset can be used once

is displayed.

When you use the landline again

Before connecting the telephone line to the base unit, select “Off” in step 2, “Cellular line

For assistance, please visit http://www.panasonic.com/help

Link to Cell

TGE26x_27x(en)_0123_ver110.pdf 20 2015/01/23 9:57:41

only mode (If you do not use the landline)”, page 20.

Cellular line selection

This feature determines which cellular line is selected to make cellular calls when: – you press MCELLN on the handset. – you press M

N or MZN on the handset

while the cellular line only mode is turned on.

– you press M

ZN on the base unit while the

cellular line only mode is turned on. (KX-TGE270 series: page 3)

The following settings are available: – “Manual” (handset only: default): You can

select the desired cellular line when making a call.

– “Cellphone 1”*1 (base unit default):

CELL 1 is selected.

– “Cellphone 2”*1: CELL 2 is selected.

1 For handset: MMENUN#634

For base unit*2: MMENUN#*634

2 M

bN: Select the desired setting.

3 MSAVEN a MOFFN

*1 After the Bluetooth device is paired, the

device name is displayed.

*2 KX-TGE270 series: page 3

Storing your area code (for dialing only a 7-digit phone number to make a local call)

You need to add your area code when making cellular calls to a phone number in your area. Once you store your area code, it is automatically added to the beginning of the 7-digit phone number when making cellular calls.

1 MMENUN#633 2 Enter the 3-digit area code.

R To correct a digit, press MCLEARN.

3 MSAVEN a MOFFN

Changing the Bluetooth PIN (Personal Identification Number)

The PIN is used to pair cellular phones to the base unit. The default PIN is “0000”. To prevent unauthorized access to this product, we recommend that you change the PIN, and keep it confidential.

Important:

R Please make note of your new PIN. The

unit does not reveal the PIN to you. If you forget your PIN, see page 75.

1 MMENUN#619

R If the unit prompts you to enter the old

PIN (when the default has been changed), enter the current 4-digit PIN.

2 Enter the new 4-digit PIN. a MOKN 3 Enter the new 4-digit PIN again. a

MSAVEN

4 MOFFN

For assistance, please visit http://www.panasonic.com/help

Link to Cell

TGE26x_27x(en)_0123_ver110.pdf 21 2015/01/23 9:57:41

Making cellular calls

Important:

R The unit can be used to talk on 2 lines at

the same time (for example, 2 cellular lines, or the landline and 1 cellular line).

R Only 2 Bluetooth devices can be used with

the unit at the same time (for example, 2 cellular lines, or the headset and 1 cellular line).

R Before making calls, confirm that the

corresponding CELL indicator on the base unit lights up (page 15).

1 Lift the handset and dial the phone

number.

R To correct a digit, press MCLEARN.

2 MCELLN

R The unit starts dialing when:

– only 1 cellular phone is paired. – a specific line is set to make cellular

calls (page 21).

Go to step 4.

3 M

bN: Select the desired cellular phone. a

MSELECTN

4 When you finish talking, press MOFFN or

place the handset on the base unit or charger.

Note:

R To switch to the speaker, press MZN.

To switch back to the receiver, press MZN/

Adjusting the receiver or speaker volume

Press M

jN or MkN repeatedly while talking.

Making a cellular call using the redial list

The last 5 phone numbers dialed are stored in the redial list (each 48 digits max.).

1 M

EN REDIAL

2 M

bN: Select the desired phone number.

3 MCELLN

R The unit starts dialing when:

– only 1 cellular phone is paired.

– a specific line is set to make cellular

calls (page 21).

4 M

bN: Select the desired cellular phone. a

MSELECTN

Erasing a number in the redial list

n When a cellular phone is paired:

1 M

EN REDIAL

2 M

bN: Select the desired phone number.

a MMENUN

3 M

bN: “Erase” a MSELECTN

4 M

bN: “Yes” a MSELECTN

5 MOFFN

n When a cellular phone is not paired:

1 M

EN REDIAL

2 M

bN: Select the desired phone number.

a MERASEN

3 M

bN: “Yes” a MSELECTN

4 MOFFN

Making landline calls

1 Lift the handset and dial the phone

number.

R To correct a digit, press MCLEARN.

2 M

3 When you finish talking, press MOFFN or

place the handset on the base unit or charger.

Using the speakerphone

1 Dial the phone number and press M

ZN.

2 When you finish talking, press MOFFN.

Note:

R To switch back to the receiver, press M

ZN/

Making a call using the redial list

The last 5 phone numbers dialed are stored in the redial list (each 48 digits max.).

1 M

EN REDIAL

For assistance, please visit http://www.panasonic.com/help

Making/Answering Calls Using the Handset

TGE26x_27x(en)_0123_ver110.pdf 22 2015/01/23 9:57:41

2 MbN: Select the desired phone number. 3 M

Pause (for PBX/long distance service users)

A pause is sometimes required when making calls using a PBX or long distance service. When storing a calling card access number and/or PIN in the phonebook, a pause is also needed (page 35). Example: If you need to dial the line access number “9” when making outside calls with a PBX:

1 9 a M

DN (Pause)

2 Dial the phone number. a M

Note:

R A 3.5 second pause is inserted each time

DN (Pause) is pressed.

Answering calls

When a call is being received, the ringer indicator and

indicator flash rapidly.

1 Lift the handset and press M

N or MZN

when the unit rings. R To answer a cellular call, you can also

press MCELLN.

2 When you finish talking, press MOFFN or

place the handset on the base unit or charger.

Any key answer: You can answer the call by pressing any dial key. Auto talk: You can answer calls simply by lifting the handset (page 43). Temporary handset ringer off: You can turn the ringer off temporarily by pressing M

Using the Smart function key

When the

indicator flashes rapidly, press

R You can answer the call even if the handset

is placed on the base unit or charger (page 16).

You can finish talking by pressing MOFFN without lifting up the handset.

Adjusting the handset ringer volume

Press M

jN or MkN repeatedly to select the

desired volume while ringing.

Useful features during a call

Hold

1 Press MMENUN during an outside call. 2 M

bN: “Hold” a MSELECTN

3 To release hold on the cellular line:

Press MCELLN.

R Another handset user can take the call

by pressing MCELLN.

*1 If you press MCELLN and the

selection list is displayed, select the desired cellular line and press

MSELECTN.

R The base unit user can take the call by

pressing MCELL 1N or MCELL 2N. (KX-TGE270 series: page 3)

To release hold on the landline:

Press M

R Another handset user can take the call

by pressing M

R The base unit user can take the call by

pressing M

ZN. (KX-TGE270 series:

page 3)

Note:

R After holding for 10 minutes, the call is

disconnected.

Mute

1 Press MMUTEN during a call. 2 To return to the call, press MMUTEN.

Note:

R MMUTEN is a soft key visible on the display

during a call.

For assistance, please visit http://www.panasonic.com/help

Making/Answering Calls Using the Handset

TGE26x_27x(en)_0123_ver110.pdf 23 2015/01/23 9:57:41

Flash for landline calls

MFLASHN allows you to use the special features of your host PBX such as transferring an extension call, or accessing optional telephone services.

Note:

R To change the flash time, see page 43.

For call waiting or Call Waiting C

aller ID service users

To use call waiting or Call Waiting Caller ID, you must first subscribe with your service provider/telephone company. This feature allows you to receive calls while you are already talking on the phone. If you receive a call while on the phone, you will hear a call waiting tone.

If you subscribe to both Caller ID and Call Waiting with Caller ID services, the 2nd

caller’s information is displayed after you hear the call waiting tone on the handset.

1 Press MCALL WAITN to answer the 2nd

call.

2 To switch between calls, press MCALL

WAITN.

Note:

R Please contact your service provider/

telephone company for details and availability of this service in your area.

Temporary tone dialing for landline calls (for rotary/pulse service users)

Press * (TONE) before entering access numbers which require tone dialing.

Handset clarity booster

This feature can improve sound clarity when the handset is used in an area where there may be interference. During an outside call, this feature is turned on automatically when necessary.

R When this feature is turned on,

displayed. However, during a cellular call,

is not displayed even though the

feature is activated.

Handset noise reduction

This feature allows you to hear the voice of the person you are talking to clearly, by reducing the surrounding noise coming from the other party’s telephone.

Press M

N to turn on/off while talking.

Note:

R Depending on the environment where this

handset is being used, this feature may not be effective.

R This feature is not available using the

speakerphone.

Handset equalizer

This feature clarifies the voice of the person you are talking to, producing a more natural-sounding voice that is easier to hear and understand.

1 Press MMENUN while talking. 2 MbN: “Equalizer” a MSELECTN 3 M

bN: Select the desired setting.

4 Press MOKN to exit.

Note:

R Depending on the condition and quality of

your telephone line, this feature may emphasize existing line noise. If it becomes difficult to hear, turn this feature off.

R This feature is not available while using the

speakerphone.

R When both the “Equalizer” setting and

noise reduction are activated,

shown on the display.

Call share

You can join an existing outside call.

n While another unit is on a cellular call:

1 To join the conversation, press

MCELLN. R You can join the conversation when:

– only 1 cellular phone is paired.

For assistance, please visit http://www.panasonic.com/help

Making/Answering Calls Using the Handset

TGE26x_27x(en)_0123_ver110.pdf 24 2015/01/23 9:57:42

– a specific line is set to make

cellular calls (page 21).

2 M

bN: Select the desired cellular phone.

a MSELECTN

n While another unit is on a landline call:

To join the conversation, press M

Note:

R A maximum of 3 parties (including 1 outside

party) can join a conversation using 2 extensions. (3-way conference)

R To prevent other users from joining your

conversations with outside callers, turn call sharing mode off (page 43).

Transferring calls, conference calls

Outside calls can be transferred or a conference call with an outside party can be made between 2 handsets.

1 During an outside call, press MMENUN. 2 M

bN: “Intercom” a MSELECTN

3 M

bN: Select the desired unit. a MSELECTN

4 Wait for the paged party to answer.

R If the paged party does not answer,

press M

N to return to the outside

call.

5 To complete the transfer:

Press MOFFN. To establish a conference call:

MMENUN a M

bN: “Conference” a MSELECTN R To leave the conference, press MOFFN.

The other 2 parties can continue the conversation.

R To put the outside call on hold:

MMENUN a M

bN: “Hold” a MSELECTN To resume the conference: MMENUN a M

bN: “Conference” a MSELECTN

R To cancel the conference: MMENUN a

bN: “Stop conference” a

MSELECTN

You can continue the conversation with the outside caller.

Transferring a cellular call between the handset and a cellular phone

Transferring a cellular call from the handset to a cellular phone

1 Press MMENUN during a cellular call. 2 M

bN: “Transfer to cell” a MSELECTN R The cellular call is transferred to the

cellular phone.

Note:

R Depending on your cellular phone type, you

may need to set the cellular phone to be ready to talk before transferring. For example, if your cellular phone has a top cover, open it beforehand.

Transferring a cellular call from a cellular phone to the handset

During a conversation using a cellular phone, the call cannot be transferred to the handset by the cellular phone. Perform the following with the handset.

1 During a conversation using a cellular

phone, press MCELLN. R The call is transferred to the handset

when: – only 1 cellular phone is paired. – a specific line is set to make cellular

calls (page 21).

2 M

bN: Select the desired cellular phone. a MSELECTN R The call is transferred to the handset.

Answering a 2nd call

If you receive a call while talking on the phone, the interrupt tone sounds (page 41) and the 2nd caller’s information is displayed if you subscribe to Caller ID (page 49).

Answering a 2nd call during a landline call

1 Press MMENUN during a landline call.

For assistance, please visit http://www.panasonic.com/help

Making/Answering Calls Using the Handset

TGE26x_27x(en)_0123_ver110.pdf 25 2015/01/23 9:57:42

2 MbN: “Hold” a MSELECTN 3 To answer the 2nd call:

Press MCELLN while the 2nd call is being received.

4 To hang up the 2nd call and return to the

1st call (landline call), press MOFFN, then press M

Answering a 2nd call during a cellular call

1 Press MMENUN during a cellular call. 2 M

bN: “Hold” a MSELECTN

3 To answer the 2nd call:

Press M

N or MCELLN while the 2nd call

is being received.

4 To hang up the 2nd call and return to the

1st call (cellular call), press MOFFN, then press MCELLN*1.

*1 If you press MCELLN and the selection list

is displayed, select the desired cellular line and press MSELECTN.

Power back-up operation for landline

When a power failure occurs, the charged handset temporarily supplies power to the base unit (power back-up mode). This allows you to make and receive landline calls using a handset during a power failure. The base unit will not perform any other functions. However, some functions such as Caller ID and phonebook are available only when using a handset other than the handset supplying power to the base unit. You can program

“Power failure” and the default setting is “Auto” (page 43).

Important:

R If a handset is not placed on the base unit

when a power failure occurs, “Base no power Press OFF” is displayed. After pressing MOFFN on the handset, place it on the base unit to start power back-up mode.

R Power back-up mode will not work if the

battery level of the power supplying handset is

or .

R Do not lift the power supplying handset

from the base unit during power back-up mode.

Panasonic Ni-MH battery performance (supplied batteries) during power back-up mode

When the batteries are fully charged, operating time of the handset in power back-up mode varies depending on usage. – Continuous use of the handset in power

back-up mode: 1.5 hours max.

– Continuous use of the handset other than a

handset in power back-up mode: 2 hours max.

– Not in use in power back-up mode: 2 hours

max.

Making calls during a power failure

n When only 1 handset is registered:

1 Lift the handset and dial the phone

number.

2 Within 1 minute, place the handset on

the base unit. R Wait until speakerphone is turned

on automatically and the call is made.

3 When the other party answers the call,

keep the handset on the base unit and talk using the speakerphone.

4 When you finish talking, press MOFFN.

n When 2 or more handsets are registered:

You should leave one handset on the base unit for supplying the power, and use another handset for making calls.

Note:

R The range of the base unit is limited during

a power failure. Please use the handset close to the base unit.

For assistance, please visit http://www.panasonic.com/help

Making/Answering Calls Using the Handset

TGE26x_27x(en)_0123_ver110.pdf 26 2015/01/23 9:57:42

Making a call using the redial list

n When only 1 handset is registered:

1 Lift the handset. 2 M

EN REDIAL

3 M

bN: Select the desired phone number.

4 Within 1 minute, place the handset on

the base unit. R Wait until speakerphone is turned

on automatically and the call is made.

n When 2 or more handsets are registered:

You should leave one handset on the base unit for supplying the power, and use another handset for making calls.

Making a call using the phonebook

There must be at least 2 handsets registered to the base unit in order for the phonebook feature to be used during a power failure.

You should leave one handset on the base unit for supplying the power, and use another handset for making calls.

Answering calls during a power failure

n When only 1 handset is registered:

1 When the unit rings, keep the handset

on the base unit and press M

N or

ZN.

R Speakerphone is turned on.

2 When you finish talking, press MOFFN.

n When 2 or more handsets are registered:

When the unit rings, use a handset which is not supplying power to the base unit. R Do not use or lift the handset which is

placed on the base unit during power back-up mode.

Note:

R The range of the base unit is limited during

a power failure. Please use the handset close to the base unit.

For assistance, please visit http://www.panasonic.com/help

Making/Answering Calls Using the Handset

TGE26x_27x(en)_0123_ver110.pdf 27 2015/01/23 9:57:42

Making cellular calls

Available for:

X-TGE270 series (page 3)

1 Press MCELL 1N or MCELL 2N. 2 Dial the phone number. 3 When the other party answers, speak into

the microphone.

4 When you finish talking, press M

ZN.

Note:

R For best performance, use the

speakerphone in a quiet environment.

R While on a call, you can switch from the

base unit to the handset: – With the call sharing mode on

(page 43), press MCELLN*1 on the handset. a M

bN: Select the desired cellular phone. a MSELECTN a Press MZN on the base unit.

– If the handset is on the base unit, simply

lift it.

*1 The call is taken when:

– only 1 cellular phone is paired. – a specific line is set to make cellular

calls (page 21).

Adjusting the speaker volume

Press M

jN or MkN repeatedly while talking.

Redialing the last number dialed

1 Press MCELL 1N or MCELL 2N. 2 MREDIALN

Making landline calls

1 MZN 2 Dial the phone number. 3 When the other party answers, speak into

the microphone.

4 When you finish talking, press M

ZN.

Note:

R While on a call, you can switch from the

base unit to the handset: – Press M

N on the handset, then press

ZN on the base unit with the call

sharing mode on (page 43).

– If the handset is on the base unit, simply

lift it.

Redialing the last number dialed

ZN a MREDIALN

Pause (for PBX/long distance service users)

A pause is sometimes required when making calls using a PBX or long distance service. When storing a calling card access number and/or PIN in the phonebook, a pause is also needed (page 35).

Example: If you need to dial the line access number “9” when making outside calls with a PBX:

1 M

2 9 a MPAUSEN 3 Dial the phone number.

Note:

R A 3.5 second pause is inserted each time

MPAUSEN is pressed.

Answering calls

When a landline call is being received, the SP-PHONE indicator flashes rapidly. When a cellular call is being received, the CELL indicator and SP-PHONE indicator flash rapidly.

1 Press M

ZN when the unit rings.

R You can also answer the cellular call

by pressing MCELL 1N or MCELL 2N.

2 Speak into the microphone. 3 When you finish talking, press MZN.

For assistance, please visit http://www.panasonic.com/help

Making/Answering Calls Using the Base Unit

TGE26x_27x(en)_0123_ver110.pdf 28 2015/01/23 9:57:42

Adjusting the base unit ringer volume

Press M

jN or MkN repeatedly to select the

desired volume while ringing. R To turn the ringer off, press and hold MkN

until the unit beeps.

Useful features during a call

Hold

1 Press MHOLDN during an outside call. 2 To release hold on the cellular line:

Press MCELL 1N or MCELL 2N. R A handset user can take the call:

MCELLN*1 a MSELECTN

*1 The call is taken when:

– only 1 cellular phone is paired. – a specific line is set to make

cellular calls (page 21).

To release hold on the landline:

Press M

ZN.

R A handset user can take the call by

pressing M

Note:

R While a landline call is on hold, the

SP-PHONE indicator flashes.

R After holding for 10 minutes, the call is

disconnected.

Mute

1 Press MMUTEN during a call.

R The SP-PHONE indicator flashes.

2 To return to the call, press MMUTEN.

Flash for landline calls

MFLASHN allows you to use the special features of your host PBX such as transferring an extension call, or accessing optional telephone services.

Note:

R To change the flash time, see page 43.

For call waiting service users

To use call waiting, you must first subscribe with your service provider/telephone company. This feature allows you to receive calls while you are already talking on the phone. If you receive a call while on the phone, you will hear a call waiting tone.

1 Press MCALL WAITN to answer the 2nd

call.

2 To switch between calls, press MCALL

WAITN.

Note:

R Please contact your service provider/

telephone company for details and availability of this service in your area.

Temporary tone dialing for landline calls (for rotary/pulse service users)

Press * (TONE) before entering access numbers which require tone dialing.

Call share

You can join an existing outside call. To select the line that is being used for the call: – for a cellular line press MCELL 1N or MCELL

2N.

– for the landline press MZN.

Note:

R A maximum of 3 parties (including 1 outside

party) can join a conversation using 2 extensions. (3-way conference)

R To prevent other users from joining your

conversations with outside callers, turn call sharing mode off (page 43).

Transferring calls, conference calls

Outside calls can be transferred or a conference call with an outside party can be made between a handset and the base unit.

For assistance, please visit http://www.panasonic.com/help

Making/Answering Calls Using the Base Unit

TGE26x_27x(en)_0123_ver110.pdf 29 2015/01/23 9:57:42

+ 67 hidden pages

Panasonic KX-TG454SK, KX-TG465SK, KX-TG484SK, KX-TGE260, KX-TGE262 Operating Instruction

Table of Contents

Model composition

Accessory information

Introduction

For your safety

Important Information

Important safety instructions

For best performance

Other information

Specifications

Setting up

Getting Started

Controls

Display icons/Indicators

Language settings

Date and time

Recording your greeting message

Other settings

Link to cell feature

Pairing a cellular phone

Link to Cell

Link to cell settings

Making cellular calls

Making landline calls

Making/Answering Calls Using the Handset

Answering calls

Useful features during a call

Power back-up operation for landline

Making cellular calls

Making landline calls

Answering calls

Making/Answering Calls Using the Base Unit

Useful features during a call
