00184022
00184058
00184059
“Neckband”
Bluetooth® Stereo Earphones
Operating Instructions |
GB |
Bedienungsanleitung |
D |
Instrucciones de uso |
E |
Руководство по эксплуатации |
RUS |
Gebruiksaanwijzing |
NL |
Manual de instruções |
P |
1
7
4
5
3 6
2 |
8 |
|
GOperating instruction
Controls and Displays
1.Earphones
2.Microphone
3.Status LEDs
4.Volume +, jump forward one title
5.On/off button, voice control, multifunction button (MF)
6.Volume -, jump backward one title
7.Charging socket
8.Battery
Thank you for choosing a Hama product.
Take your time and read the following instructions and information completely. Please keep these instructions in a safe place for future reference. If you sell the device, please pass these operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specific hazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
•1x Bluetooth® stereo earphones
•1x USB charging cable
•3 pairs of ear cushions (sizes S, M, L)
•2 pairs of silicone ear hooks (sizes M, L)
•These operating instructions
3. Safety Notes
•The product is intended for private, noncommercial use only.
•Use the product for its intended purpose only.
•Protect the product from dirt, moisture and overheating, and only use it in a dry environment.
•Do not use the product in the immediate vicinity of heaters or other heat sources or in direct sunlight.
•Do not drop the product and do not expose it to any major shocks.
•Do not operate the product outside the power limits given in the specifications.
•Do not open the device or continue to operate it if it becomes damaged.
•Since the battery is integrated and cannot be
removed, you will need to dispose of the product as a whole. Do this in compliance with the legal requirements.
•Dispose of packaging material immediately according to locally applicable regulations.
•Do not modify the product in any way. Doing so voids the warranty.
•Do not use the product in areas where the use of electronic devices is not permitted.
•Do not attempt to service or repair the product yourself. Leave any and all service work to qualified experts.
Warning – High volumes
•High sound pressure level!
•There is a risk of hearing damage.
•To prevent hearing loss, avoid listening at high volume levels for long periods.
•Always keep the volume at a reasonable level. Loud volumes, even over short periods, can cause hearing loss.
•Using this product limits your perception of ambient noise. For this reason, do not operate any vehicles or machines while using this product.
4.Getting Started
Warning – Battery
•Only use suitable charging devices or USB connections for charging.
•As a rule, do not charge devices or USB connections that are defective and do not try to repair them yourself.
•Do not overcharge the product or allow the battery to completely discharge.
•Avoid storing, charging or using batteries in extreme temperatures.
•When stored over a long period of time, batteries should be charged regularly (at least every three months).
•The earphones are equipped with a rechargeable battery. The battery must be fully charged before using the device for the first time.
•Ensure that the earphones are switched off before charging them.
•Begin charging by connecting the included USB charging cable to the charging socket (7) as well as to the USB connection of a PC/laptop.
•Alternatively, you can charge the earphones using a suitable USB charger. Please refer to the
2
operating instructions for the USB charger used.
•The display lights up constantly in red during the charging process.
•It takes around 2 hours until the battery is completely charged.
•Once the charging process is complete, the red light of the LED (3) turns to blue light.
•Disconnect all cable and mains connections after use.
5. Operation
Switching the earphones on/off
•Press the MF button (5) until a voice says “Power ON” and the blue LED flashes.
•To switch it off, press and hold the MF button
(5) until a voice says “Power OFF” and the red LED flashes.
Note
The functions described in this section are only available for Bluetooth®-capable terminal devices.
5.1. Bluetooth® pairing
Note – Pairing
•Make sure that your Bluetooth®-capable terminal device is on and Bluetooth® is activated.
•Make sure that your Bluetooth®-capable terminal device is visible for other Bluetooth® devices.
•For more information, please refer to the operating instructions of your terminal device.
•The earphones and the terminal device should be no further than one metre apart. The smaller the distance, the better.
•Switch on the earphones with the MF button (5).
•Press and hold the MF button (5) until the red and blue LEDs flash alternatingly. The earphones are searching for a Bluetooth® connection.
•Open the Bluetooth® settings on your terminal device and wait until Hama BTH Neckband appears in the list of Bluetooth® devices found.
•Select Hama BTH Neckband and wait until the earphones are listed as connected in the Bluetooth® settings on your terminal device.
Note – Bluetooth® password
Some terminal devices require a password in order to connect to another Bluetooth® device.
•If your terminal device requests a password for connection to the earphones, enter 0000.
Note
•Once the connection has been established, a voice says, “Connected”.
•If the connection attempt takes longer than 300 seconds to complete, it is cancelled and the LEDs go out. In this case, repeat the steps listed previously under 5.1 Bluetooth® pairing.
5.2. Automatic Bluetooth® connection (after successful pairing)
Note
•Make sure that your Bluetooth®-capable terminal device is on and Bluetooth® is activated.
•Make sure that your Bluetooth®-capable terminal device is visible for other Bluetooth® devices.
•For more information, please refer to the operating instructions of your terminal device.
•Switch on the earphones with the MF button (5). The blue LED begins to flash and the earphones automatically connect with the last terminal device used.
Note
•Once the connection has been established, a voice says, “Connected”.
•If the connection attempt takes longer than 300 seconds to complete, it is cancelled and the LEDs go out. In this case, repeat the steps listed previously under 5.2.
•It may be necessary to change the settings on your terminal device to enable it to automatically connect to the earphones.
Note – Connection impaired
After the headset and terminal device have been paired, a connection is established automatically. If the Bluetooth® connection is not established automatically, check the following:
•Check the Bluetooth® settings of your terminal device to see whether Hama BTH Neckband is connected. If not, repeat the steps listed under
5.1. Bluetooth® pairing.
•Check whether obstacles are impairing the range. If so, move the devices closer together.
•The performance can also be affected by a weak battery.
3
5.3.Bluetooth® multipoint connection
These earphones can connect to two Bluetooth®- enabled terminal devices simultaneously (multipoint).
• First connect the earphones with the first terminal device as described in 5.1.
• Then disable Bluetooth® on that terminal device.
• Next, connect the earphones with the second terminal device as described in 5.1.
• Activate Bluetooth® on the first terminal device once more. The earphones now connect to that terminal device automatically.
5.4.Audio playback
Note
•Note that the functions described under 5.3. and 5.4. are only possible with an active Bluetooth® connection.
•Your terminal device must also support the individual functions.
•For more information, please refer to the operating instructions of your terminal device.
•Functions can still be controlled directly via the terminal device.
•Set the volume on your terminal device to a low level.
•Switch on the earphones with the MF button
(5). Upon successful connection, a voice says,
“Connected”.
•Start audio playback on the connected terminal device.
•Press Volume + (4) to increase the volume. There is an announcement when the maximum volume is reached.
•Press Volume - (6) to reduce the volume.
•Press the MF button (5) to start or pause audio playback.
•Press and hold Jump forward one title (4) to skip to the next title.
•Press and hold Jump backward one title (6) to skip to the previous title.
5.5. Hands-free function
•Press the MF button (5) once to answer an incoming call.
•Press the MF button(5) twice or use your telephone to reject an incoming call.
•During a call, press the MF button (5) once to end the call.
•Press the MF button (5) twice to call the number of the last call.
Note – Call quality
To increase the call quality, make sure that you are near the earphones with your mobile phone during the call.
5.6.Disconnecting the earphones
•Switch off the earphones.
•Disconnect the earphones via the Bluetooth® settings on your terminal device.
5.7.Battery capacity
•An announcement is made and the display flashes in red when the battery is low
•Charge the earphones as described in 4. Getting started.
6. Care and Maintenance
Only clean this product with a slightly damp, lint-free cloth and do not use aggressive cleaning agents. Make sure that water does not get into the product.
7. Warranty Disclaimer
Hama GmbH & Co KG assumes no liability and provides no warranty for damage resulting from improper installation/mounting, improper use of the product or from failure to observe the operating instructions and/or safety notes.
8. Service and Support
Please contact Hama Product Consulting if you have any questions about this product.
Hotline: +49 9091 502-115 (German/English) Further support information can be found here: www.hama.com
4
9. Technical Data
|
Bluetooth® earphones |
|
Earphone/microphone |
32 Ω / 1.4 – 2.2 kΩ |
|
impedance |
||
|
||
Frequency |
20 – 20000 Hz |
|
Earphone/microphone |
96 dB / -42 dB |
|
sensitivity |
||
|
||
WBCV |
≥ 75 mV |
|
Range |
Max. 10 m |
|
Bluetooth® technology |
v4.2 |
|
Profile |
A2DP V1.3 / AVRCP V1.5 / |
|
HFP V1.6 / HSP |
||
|
||
Transmission frequency |
2.4 – 2.48 GHz |
|
Battery |
Li-Po 3.7 V |
|
Battery capacity |
120 mAh |
|
Current consumption |
Max. 80 mA |
|
Charging voltage |
Max. 5 V USB |
|
Total weight |
23 g |
|
Max. Talk Time / |
10 h / 8 h |
|
Max. Music Play Time * |
||
|
||
Standby time * |
120 h |
|
Ready for use * |
360 days |
|
Charging time |
2 h |
* after full charge
10. Recycling Information
Note on environmental protection:
After the implementation of the
European Directive 2012/19/EU and 2006/66/EU in the national legal system, the following applies: Electric and electronic devices as well as
batteries must not be disposed of with household waste. Consumers are obliged by law to return electrical and electronic devices as well as batteries at the end of their service lives to the public collecting points set up for this purpose or point of sale. Details to this are def nedi by the national law of the respective country. This symbol on the product, the instruction manual or the package indicates that a product is subject to these regulations. By recycling, reusing the materials or other forms of utilising old devices/Batteries, you are making an important contribution to protecting our environment.
11. Declaration of Conformity
Hereby, Hama GmbH & Co KG declares that the radio equipment type [00184022, 00184058, 00184059] is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address:
www.hama.com -> 00184022, 00184058, 00184059 -> Downloads.
Frequency band(s) |
2402 MHz – |
|
2480 MHz |
||
|
||
Maximum radio-frequency |
3.5 mW EIRP |
|
power transmitted |
||
|
5
DBedienungsanleitung
Bedienungselemente und Anzeigen
1.Ohrhörer
2.Mikrophon
3.Status LEDs
4.Lautstärke +, Titelsprung vorwärts
5.Taste Ein/Aus, Gesprächssteuerung, Multifunktionstaste (MF)
6.Lautstärke -, Titelsprung zurück
7.Ladebuchse
8.Akku
Vielen Dank, dass Sie sich für ein Hama Produkt entschieden haben!
Nehmen Sie sich Zeit und lesen Sie die folgenden Anweisungen und Hinweise zunächst ganz durch. Bewahren Sie diese Bedienungsanleitung anschließend an einem sicheren Ort auf, um bei Bedarf darin nachschlagen zu können. Sollten Sie das Gerät veräußern, geben Sie diese Bedienungsanleitung an den neuen Eigentümer weiter.
1. Erklärung von Warnsymbolen und Hinweisen
Warnung
Wird verwendet, um Sicherheitshinweise zu kennzeichnen oder um Aufmerksamkeit auf besondere Gefahren und Risiken zu lenken.
Hinweis
Wird verwendet, um zusätzlich Informationen oder wichtige Hinweise zu kennzeichnen.
2. Packungsinhalt
•1x Bluetooth® Stereo Ohrhörer
•1x USB-Ladekabel
•3 Paar Ohrpolster (Größe S/M/L)
•2 Paar Silikon-Earhooks (Größe M/L)
•diese Bedienungsanleitung
3. Sicherheitshinweise
•Das Produkt ist für den privaten, nicht-gewerblichen Haushaltsgebrauch vorgesehen.
•Verwenden Sie das Produkt ausschließlich für den dazu vorgesehenen Zweck.
•Schützen Sie das Produkt vor Schmutz, Feuchtigkeit und Überhitzung und verwenden Sie es nur in trockenen Räumen.
•Betreiben Sie das Produkt nicht in unmittelbarer Nähe der Heizung, anderer Hitzequellen oder in direkter Sonneneinstrahlung.
•Lassen Sie das Produkt nicht fallen und setzen Sie es keinen heftigen Erschütterungen aus.
•Betreiben Sie das Produkt nicht außerhalb seiner in den technischen Daten angegebenen Leistungsgrenzen.
•Öffnen Sie das Produkt nicht und betreiben Sie es bei Beschädigungen nicht weiter.
•Der Akku ist fest eingebaut und kann nicht entfernt werden, entsorgen Sie das Produkt als Ganzes gemäß den gesetzlichen Bestimmungen.
•Entsorgen Sie das Verpackungsmaterial sofort gemäß den örtlich gültigen Entsorgungsvorschriften.
•Nehmen Sie keine Veränderungen am Gerät vor. Dadurch verlieren sie jegliche Gewährleistungsansprüche.
•Benutzen Sie das Produkt nicht in Bereichen, in denen elektronische Produkte nicht erlaubt sind.
•Versuchen Sie nicht, das Produkt selbst zu warten oder zu reparieren. Überlassen Sie jegliche Wartungsarbeit dem zuständigen Fachpersonal.
Warnung – Hohe Lautstärke
•Hoher Schalldruck!
•Es besteht das Risiko eines Gehörschadens.
•Um einen Verlust des Hörsinns zu verhindern, vermeiden Sie das Hören bei großem Lautstärkepegel über lange Zeiträume.
•Halten Sie die Lautstärke immer auf einem vernünftigen Niveau. Hohe Lautstärken können
– selbst bei kurzer Dauer – zu Hörschäden führen.
•Die Benutzung des Produktes schränkt Sie in der Wahrnehmung von Umgebungsgeräuschen ein.
Bedienen Sie daher während der Benutzung keine Fahrzeuge oder Maschinen.
4.Inbetriebnahme
Warnung – Akku
•Verwenden Sie nur geeignete Ladegeräte oder USB-Anschlüsse zum Aufladen.
•Verwenden Sie defekte Ladegeräte oder USBAnschlüsse generell nicht mehr und versuchen Sie nicht, diese zu reparieren.
•Überladen oder tiefentladen Sie das Produkt nicht.
•Vermeiden Sie Lagerung, Laden und Benutzung bei extremen Temperaturen.
•Laden Sie bei längerer Lagerung regelmäßig (mind. vierteljährig) nach.
•Die Ohrhörer verfügen über einen wieder aufladbaren Akku. Vor der ersten Anwendung muss
6
der Akku vollständig aufgeladen werden.
•Stellen Sie sicher, dass die Ohrhörer vor dem Aufladen ausgeschaltet sind.
•Starten Sie den Ladevorgang, indem Sie das beiliegende USB-Ladekabel an die Ladebuchse (7) und an den USB-Anschluss eines PCs/Notebooks anschließen.
•Alternativ können Sie die Ohrhörer über ein geeignetes USB-Ladegerät laden. Beachten Sie hierzu die Bedienungsanleitung des verwendeten USB-Ladegeräts.
•Die Anzeige leuchtet während des Ladevorgangs dauerhaft rot.
•Es dauert ca. 2 Stunden, bis der Akku vollständig aufgeladen ist.
•Nach Abschluss des Ladevorgangs leuchtet die LED (3) blau.
•Trennen Sie anschließend alle Kabelund Netzverbindungen.
5. Betrieb
Ein-/ Ausschalten der Ohrhörer
•Drücken Sie die MF Taste(5), bis die Ansage (Power ON) ertönt und die blaue LED blinkt.
•Zum Ausschalten drücken Sie die MF Taste(5), bis die Ansage (Power OFF) ertönt, sowie die rote LED blinkt und erlischt.
Hinweis
Die in diesem Kapitel beschriebenen Funktionen sind nur mit Bluetooth®-fähigen Endgeräten möglich.
5.1. Bluetooth® Erstverbindung (Pairing)
Hinweis – Pairing
•Stellen Sie sicher, dass Ihr Bluetooth®-fähiges Endgerät eingeschaltet ist und dass Bluetooth® aktiviert ist.
•Stellen Sie sicher, dass Ihr Bluetooth®-fähiges Endgerät für andere Bluetooth® Geräte sichtbar ist.
•Beachten Sie hierzu die Bedienungsanleitung Ihres Endgerätes.
•Die Ohrhörer und das Endgerät sollten nicht weiter als 1 Meter voneinander entfernt sein. Je geringer der Abstand, desto besser.
•Schalten Sie das Headset mit der MF Taste (5) ein.
•Drücken und halten Sie die MF Taste (5), bis die blaue und rote LED abwechselnd blinken. Das Headset sucht nach einer Bluetooth® Verbindung.
•Öffnen Sie auf Ihrem Endgerät die Bluetooth®
Einstellungen und warten Sie bis in der Liste der gefundenen Bluetooth® Geräte Hama BTH Neckband angezeigt wird.
•Wählen Sie Hama BTH Neckband aus und warten Sie, bis die Ohrhörer als verbunden in den Bluetooth® Einstellungen Ihres Endgerätes angezeigt werden.
Hinweis – Bluetooth® Passwort
Manche Endgeräte benötigen für die Einrichtung der Verbindung mit einem anderen Bluetooth® Gerät ein Passwort.
•Geben Sie für die Verbindung mit den Ohrhörern das Passwort 0000 ein, wenn Sie zur Eingabe von Ihrem Endgerät aufgefordert werden.
Hinweis
•Wenn die Verbindung erfolgreich war, ertönt die Ansage Connected.
•Wenn der Verbindungvorgang länger als 300 Sekunden dauert, erlöschen die LEDs und der Vorgang wird abgebrochen.
•In diesem Fall wiederholen Sie die oben unter 5.1 genannten Schritte zur Bluetooth® Erstverbindung (Pairing).
5.2.Automatische Bluetooth® Verbindung (nach bereits erfolgtem Pairing)
Hinweis
•Stellen Sie sicher, dass Ihr Bluetooth®-fähiges Endgerät eingeschaltet ist und dass Bluetooth® aktiviert ist.
•Stellen Sie sicher, dass Ihr Bluetooth®-fähiges Endgerät für andere Bluetooth® Geräte sichtbar ist.
•Beachten Sie hierzu die Bedienungsanleitung Ihres Endgerätes.
•Schalten Sie das Headset mit der MF Taste (5) ein. Die blaue LED beginnt zu blinken und das
Headset verbindet sich automatisch mit dem zuletzt genutzten Endgerät.
Hinweis
•Wenn die Verbindung erfolgreich war, ertönt die Ansage Connected.
7
Hinweis
•Wenn der Verbindungvorgang länger als 300 Sekunden dauert, erlöschen die LEDs und der Vorgang wird abgebrochen. In diesem Fall wiederholen Sie die oben unter 5.2 genannten Schritte.
•Gegebenenfalls müssen Sie die Einstellung auf dem Endgerät vornehmen, um die automatische Verbindung mit den Ohrhörern zuzulassen.
Hinweis – Verbindung beeinträchtigt
Nach einer erfolgreichen Erstverbindung erfolgt die Verbindung automatisch. Sollte sich die Bluetooth® Verbindung nicht automatisch wiederherstellen, prüfen Sie die folgenden Punkte:
•Kontrollieren Sie in den Bluetooth® Einstellungen des Endgerätes, ob Hama BTH Neckband verbunden ist. Wenn nicht, wiederholen Sie die unter
5.1. Bluetooth® Erstverbindung genannten Schritte.
•Kontrollieren Sie, ob Hindernisse die Reichweite beeinträchtigen. Wenn ja, positionieren Sie die Geräte näher zueinander.
•Auch bei schwacher Batterie kann die Leistung beeinträchtigt sein.
5.3. Bluetooth® Multipoint Verbindung
Dieses Headset kann sich mit zwei Bluetooth®-fähigen Endgeräten gleichzeitig verbinden (Multipoint).
•Verbinden Sie zunächst das Headset wie unter 5.1 beschrieben mit dem ersten Endgerät.
•Deaktivieren Sie anschließend die Bluetooth® Funktion auf diesem Endgerät.
•Verbinden Sie dann das Headset wie unter 5.1 beschrieben mit dem zweiten Endgerät.
•Aktivieren Sie die Bluetooth® Funktion auf dem ersten Endgerät erneut. Das Headset verbindet sich dann auch mit diesem Endgerät mittels der automatischen Bluetooth® Verbindung.
5.4. Audio-Wiedergabe
Hinweis
•Beachten Sie, dass die unter 5.4. und 5.5. beschriebenen Funktionen nur bei einer aktiven Bluetooth® Verbindung möglich sind.
•Zudem müssen die einzelnen Funktionen von Ihrem Endgerät unterstützt werden.
Hinweis
•Beachten Sie hierzu die Bedienungsanleitung Ihres Endgerätes.
•Die Funktionen lassen sich weiterhin auch direkt über das Endgerät steuern.
•Stellen Sie die Lautstärke Ihres Endgerätes auf ein niedriges Niveau ein.
•Schalten Sie das Headset mit der MF Taste (5) ein. Eine erfolgreiche Verbindung wird durch die Ansage (Connected) angezeigt.
•Starten Sie die Audiowiedergabe auf dem verbundenen Endgerät.
•Drücken Sie Lautstärke+ (4), um die Lautstärke zu erhöhen. Bei Erreichen der maximalen Lautstärke erfolgt eine entsprechende Ansage.
•Drücken Sie Lautstärke- (6), um die Lautstärke zu reduzieren.
•Drücken Sie die MF Taste (5), um die AudioWiedergabe anzuhalten oder zu starten.
•Drücken und halten Sie Titelsprung vorwärts (4), um zum nächsten Titel zu springen.
•Drücken und halten Sie Titelsprung zurück (6), um zum vorherigen Titel zu springen
5.5. Freisprechfunktion
•Drücken Sie einmal die MF Taste (5), um einen eingehenden Anruf anzunehmen.
•Drücken Sie die MF Taste (5) zweimal oder nutzen Sie ihr Telefon, um den eingehenden Anruf abzuweisen.
•Drücken Sie während des Gesprächs einmal die MF Taste (5), um den Anruf zu beenden.
•Drücken Sie die MF Taste (5) zweimal, um die Nummer des letzten Anrufs anzurufen.
Hinweis – Gesprächsqualität
Achten Sie darauf, dass Sie sich mit Ihrem Mobiltelefon während eines Anrufs in der Nähe der Ohrhörer befinden, um die Gesprächsqualität zu erhöhen.
5.6. Trennen der Ohrhörer
•Schalten Sie die Ohrhörer aus.
•Trennen Sie die Ohrhörer über die Bluetooth® Einstellungen Ihres Endgerätes.
5.7. Akkukapazität
•Bei geringer Akkukapazität ertönt eine Ansage (Battery Low) und die Anzeige blinkt rot auf.
•Laden Sie das Headset – wie in 4. Inbetriebnahme beschrieben – auf.
8
