B57CR23.0B
[en] INSTRUCTION MANUAL
Built-in oven
B57CR23.0B
en
3
Table of contents
[en]INSTRUCTION MANUAL
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
( Important safety information . . . . . . . . . . . . . . . 4
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Halogen lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cleaning function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
] Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
7 Environmental protection . . . . . . . . . . . . . . . . . . 6
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 6
* Getting to know your appliance . . . . . . . . . . . . . 7
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Menu for the types of heating . . . . . . . . . . . . . . . . . . . 8
Cooking compartment functions . . . . . . . . . . . . . . . . . 9
_ Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Combining accessories . . . . . . . . . . . . . . . . . . . . . . . 10
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 10
K Before using for the first time. . . . . . . . . . . . . . 11
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cleaning the cooking compartment . . . . . . . . . . . . . . 11
Cleaning the accessories. . . . . . . . . . . . . . . . . . . . . . 11
1 Operating the appliance . . . . . . . . . . . . . . . . . . 12
Switching the appliance on and off . . . . . . . . . . . . . . 12
Setting and starting the appliance operation . . . . . . . 12
Changing or cancelling the appliance operation . . . . 13
Heating up the appliance quickly . . . . . . . . . . . . . . . . 13
O Time-setting options . . . . . . . . . . . . . . . . . . . . . 14
Showing and hiding the time-setting options . . . . . . . 14
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the cooking time . . . . . . . . . . . . . . . . . . . . . . 14
Start delay – "Ready at" . . . . . . . . . . . . . . . . . . . . . . . 14
Checking, changing or deleting settings . . . . . . . . . . 14
A Childproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 15
Automatic childproof lock . . . . . . . . . . . . . . . . . . . . . 15
One-time childproof lock . . . . . . . . . . . . . . . . . . . . . . 15
Q Basic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Changing the basic settings. . . . . . . . . . . . . . . . . . . . 16
List of basic settings . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
F Sabbath mode . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Starting Sabbath mode. . . . . . . . . . . . . . . . . . . . . . . .17
Cancelling Sabbath mode . . . . . . . . . . . . . . . . . . . . .17
D Cleaning agent . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . .17
Keeping the appliance clean . . . . . . . . . . . . . . . . . . .18
. Cleaning function. . . . . . . . . . . . . . . . . . . . . . . . 19
Self-cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
EasyClean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
p Rails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Detaching and refitting the rails . . . . . . . . . . . . . . . . .21
q Appliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Removing and fitting the appliance door . . . . . . . . . .22
Removing and installing the door panels . . . . . . . . . .23
3 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 25
Fault table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Maximum operating time exceeded . . . . . . . . . . . . . .25
Replacing the bulb in the top of the cooking
compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Glass cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
4 Customer service . . . . . . . . . . . . . . . . . . . . . . . . 26
E number and FD number . . . . . . . . . . . . . . . . . . . . .26
J Tested for you in our cooking studio . . . . . . . . 27
Silicone moulds . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Roasting and braising. . . . . . . . . . . . . . . . . . . . . . . . .30
Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Convenience products . . . . . . . . . . . . . . . . . . . . . . . .35
Yogurt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Eco types of heating. . . . . . . . . . . . . . . . . . . . . . . . . .36
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .37
Slow cook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Allowing the dough to prove at dough proving
setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Keeping warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.neff-international.com and in the online shop
www.neff-eshop.com
en Intended use
4
8Intended use
Intended use
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 2000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 8 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~ "Accessories" on page 9
(Important safety
information
Important safety information
General information
:Warning – Risk of fire!
■ Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■ A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
:Warning – Risk of burns!
■ The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■ Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■ Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.
:Warning – Risk of scalding!
■ The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■ When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■ Water in a hot cooking compartment may
create hot steam. Never pour water into the
hot cooking compartment.
Important safety information en
5
:Warning – Risk of injury!
■ Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■ The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
:Warning – Risk of electric shock!
■ Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the after-
sales service.
Risk of electric shock and serious injury!
■ The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■ Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■ A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
:Warning – Hazard due to magnetism!
Permanent magnets are used in the control
panel or in the control elements. They may
affect electronic implants, e.g. heart
pacemakers or insulin pumps. Wearers of
electronic implants must stay at least 10 cm
away from the control panel.
Halogen lamp
:Warning – Risk of electric shock!
When replacing the cooking compartment
bulb, the bulb socket contacts are live. Before
replacing the bulb, unplug the appliance from
the mains or switch off the circuit breaker in
the fuse box.
Cleaning function
:Warning – Risk of fire!
■ Loose food residues, grease and meat
juices may catch fire during the cleaning
function. Before starting the cleaning
function, remove coarse dirt from the
cooking compartment and from the
accessories.
Risk of fire!
■ The appliance will become very hot on the
outside during the cleaning function. Never
hang combustible objects, e.g. tea towels,
on the door handle. Do not place anything
against the front of the appliance. Keep
children away from the appliance.
:Warning – Risk of serious damage to
health!
The appliance will become very hot during the
cleaning function. The non-stick coating on
baking trays and tins is destroyed and noxious
gases are released. Never clean non-stick
baking trays and baking tins using the
cleaning function. Only clean enamelled
accessories using the cleaning function.
:Warning – Risk of burns!
■ The cooking compartment becomes
extremely hot during the cleaning function.
Never open the appliance door. Allow the
appliance to cool down. Keep children
away from the appliance.
Risk of burns!
■ ; The appliance will become very hot on
the outside during the cleaning function.
Never touch the appliance door. Allow the
appliance to cool down. Keep children
away from the appliance.
en Causes of damage
6
]Causes of damage
Causes of damage
General information
Caution!
■ Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■ Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■ Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■ Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■ Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■ Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■ Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean.
■ Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■ Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■ Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
7Environmental protection
Environmental protection
Your new appliance is particularly energy-efficient. Here
you can find tips on how to save even more energy
when using the appliance, and how to dispose of your
appliance properly.
Saving energy
■ Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■ Use dark, black lacquered or enamelled baking tins.
They absorb heat particularly well.
■ Open the appliance door as infrequently as possible
during operation.
■ It is best to bake several cakes one after the other.
The cooking compartment is still warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■ For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
Getting to know your appliance en
7
*Getting to know your
appliance
Getting to know your appliance
In this chapter, we will explain the displays and controls.
You will also find out about the various functions of your
appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
Control panel
In the control panel, set the appliance's different
functions. The current settings are shown on the
display.
Controls
Use the controls to set your appliance simply and
directly.
Touch buttons
There are sensors under the touch buttons. Touch on
the corresponding touch button to select a function.
--------
ShiftControl control
Use the ShiftControl control element to navigate
through the lines on the display and select the settings.
Settings that you can change have left and right
arrows '.
Note: You can also scroll through the settings values
quickly by pressing and holding a button. As soon as
you release the button, you stop scrolling through the
values quickly.
&LUFR7KHUPKRWDLU
µÉ£©Ý
³±´Å
&
( Display
0 Touch buttons
8 ShiftControl control
Touch button Use
# on/off Switching the appliance on or
off~ "Switching the appliance on
and off" on page 12
0 Main menu Selecting operating modes and set-
tings ~ "Setting and starting the
appliance operation" on page 12
3 Time-setting options Setting the timer, cooking time, or
"Ready at" start delay ~ "Time-
setting options" on page 14
Childproof lock Activating or deactivating the child-
proof lock ~ "Childproof lock"
on page 15
! Information Displaying further information
Displaying the current temperature
~ "Setting and starting the
appliance operation" on page 12
° Rapid heating Activating or deactivating rapid heat-
ing ~ "Heating up the appliance
quickly" on page 13
Activating or deactivating Power-
Boost ~ "Heating up the appliance
quickly" on page 13
# Start/Stop Starting or stopping the operation
~ "Setting and starting the
appliance operation" on page 12
Button Use
( Left Navigates to the left on the display
) Right Navigates to the right on the display
% Up Navigates upwards on the display
& Down Navigates downwards on the display
en Getting to know your appliance
8
Main menu
Touch the 0 touch button to access the main menu.
--------
Menu for the types of heating
Your appliance has different types of heating. After
switching on the appliance, you are taken directly to the
menu for the types of heating.
--------
Menu Use
¢
Types of heating
Selecting the required type of heating and tempera-
ture for your dish ~ "Switching the appliance on and
off" on page 12
"
Basic settings
Individually adjusting the appliance
settings~ "Basic settings" on page 16
š
EasyClean
Cleaning light soiling from the cooking compartment
~ "Cleaning function" on page 19
˜
Self-cleaning
Cleaning the cooking compartment pyrolytically
~ "Cleaning function" on page 19
Type of heating Temperature Use
‚
CircoTherm hot air 40 - 200 °C For baking and cooking on one or more levels.
The fan distributes the heat from the ring heating element in the back panel
evenly around the cooking compartment.
ƒ
Top/bottom heating 50 - 275 °C For traditional baking and roasting on one level. Especially suitable for cakes with
moist toppings.
Heat is emitted evenly from the top and bottom.
‡
Circo-roasting 50 - 250 °C For roasting poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the
hot air around the food.
„
Pizza setting 50 - 275 °C For preparing pizza and dishes which require a lot of heat from underneath.
The bottom heating element and the ring heating element in the back panel heat
up.
…
Bread-baking 180 - 240 °C For baking bread, bread rolls and baked items that require high temperatures.
ˆ
Grill, large area 50 - 290 °C For grilling flat items, such as steaks or sausages, for making toast, and for au gra-
tin dishes.
The whole area below the grill element becomes hot.
‰
Grill, small area 50 - 290 °C For grilling small amounts of steaks or sausages, for making toast, and for au gra-
tin dishes.
The centre area under the grill heating element becomes hot.
†
Bottom heating 50 - 250 °C For cooking in a bain marie and for the final baking stage.
The heat is emitted from below.
Š
Slow cooking 70 - 120 °C For gentle and slow cooking of seared, tender pieces of meat in ovenware without
a lid.
The heat is emitted evenly from the top and bottom at low temperatures.
Œ
Dough proving 35 - 55 °C For leaving yeast dough and sourdough to prove and for culturing yogurt.
Dough will prove more quickly than at room temperature. The surface of the
dough does not dry out.
‘
Top/bottom heating eco 50 - 275 °C For gentle cooking of selected dishes.
The heat is emitted from above and below.
ž
CircoTherm eco 40 - 200 °C For gentle cooking of selected dishes on one level without preheating.
The fan distributes the heat from the ring heating element in the back panel
around the cooking compartment.
Accessories en
9
Cooking compartment functions
The functions in the cooking compartment make your
appliance easier to use. This, for example, enables the
cooking compartment to be well lit and a cooling fan to
prevent the appliance from overheating.
Opening the appliance door
If you open the appliance door during an operation, the
operation is paused. The operation continues to run
when you close the door.
Note: For some types of heating, the operation
continues to run even when the appliance door is open.
Interior lighting
If you open the appliance door, the interior lighting
switches on. If the door remains open for longer than
around 15 minutes, the lighting switches off again.
For most operating modes, the interior lighting switches
on as soon as the operation is started. When the
operation has finished, the lighting switches off.
Note: You can set the interior lighting not to come on
during the operation in the basic settings. ~ "Basic
settings" on page 16
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after the operation, the cooling fan continues to
run for a certain period afterwards.
Note: You can change how long the cooling fan
continues to run for in the basic settings. ~ "Basic
settings" on page 16
_Accessories
Accessories
Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
--------
Only use genuine accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Note: The accessories may become deformed when
they become hot. This does not affect their function.
Once they cool down again, they regain their original
shape.
Inserting accessories
The cooking compartment has four shelf positions. The
shelf positions are counted from the bottom up.
In some appliances, the top shelf position in the
cooking compartment features a grill symbol.
:Warning – Risk of burns!
The telescopic shelves become hot when the appliance
is in use. Take special care not to get burnt when they
are pulled out.
The accessories can be pulled out approximately
halfway without tipping. With the pull-out rails at level 1,
you can pull the accessories out further.
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
you are grilling directly on the wire rack.
Accessory supports
You can use these if you wish to leave an
accessory (e.g. the universal pan) in the
cooking compartment for cleaning by
the self-cleaning function.
en Accessories
10
Ensure that the accessory is placed behind the lug ‚ on
the pull-out rail.
Example in the picture: Universal pan
The pull-out rails lock in place when they are fully pulled
out. This makes it easy to place the accessories in
position. To unlock, push the pull-out rails back into the
cooking compartment with a certain amount of force.
Notes
■ Ensure that you always insert the accessories into
the cooking compartment the right way round.
■ Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
Locking function
The accessories can be pulled out approximately
halfway until they lock in place. The locking function
prevents the accessories from tilting when they are
pulled out. The accessories must be inserted into the
cooking compartment correctly for the tilt protection to
work properly.
When inserting the wire rack, ensure that the lug ‚ is at
the rear and is facing downwards. The open side must
be facing the appliance door and the curvature must be
facing downwards ¾.
When inserting the baking tray or the universal pan,
ensure that the lug ƒ is at the rear and is facing
downwards. The sloping edge of the accessory „ must
be facing towards the appliance door.
Combining accessories
You can insert the wire rack and the universal pan at
the same time to catch drops of liquid.
When inserting the wire rack, ensure that both spacers
‚ are at the rear edge. When the universal pan is
inserted, the wire rack is on top of the upper guide rod
of the shelf position.
Optional accessories
You can purchase optional accessories from the after-
sales service and specialist retailers, or on the Internet.
You will find a comprehensive range of products for
your appliance in our brochures and on the Internet.
Both availability and whether it is possible to order
online differ between countries. Please see your sales
documents for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, please always quote the
exact designation (E no.) of your appliance.
~ "Customer service" on page 26
--------
D
D
D
F
E
E
Accessories
Baking and roasting shelf
Baking tray, suitable for pyrolytic cleaning
Universal pan, suitable for pyrolytic cleaning
Extra-deep pan, suitable for pyrolytic cleaning
Steaming set for ovens
Profi pan, suitable for pyrolytic cleaning
Lid for the Profi pan
Pizza tray
Grill tray, suitable for pyrolytic cleaning
Bread-baking stone, suitable for pyrolytic cleaning
Glass roasting dish, 5.1 litres
Glass pan
ComfortFlex shelf (1 level) + frame*
ComfortFlex rail (1 level)*
3 x fully extendable pull-out rack*
*Accessory does not fit in every appliance, quote the E no. when order-
ing
D
D
D
Before using for the first time en
11
KBefore using for the first
time
Before using for the first time
Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Initial use
As soon as the appliance is connected to the power
supply, the first setting "Language" appears on the
display.
Setting the language
1. Use the & button to navigate to the bottom line.
2. Use the ( or ) button to select the language.
3. Use the % button to return to "Language".
4. Use the ) button to select the next setting.
Setting the time
1. Use the & button to navigate to the next line.
2. Use the ( or ) button to select the current time.
3. Press the % button.
4. Use the ) button to select the next setting.
Setting the date
1. Use the & button to navigate to the next line.
2. Use the ( or ) button to select the current day.
3. Use the % button to return to "Day".
4. Use the ) button to select the next setting.
5. Use the & button to navigate to the next line.
6. Use the ( or ) button to select the current month.
7. Use the % button to return to "Month".
8. Use the ) button to select the next setting.
9. Use the & button to navigate to the next line.
10. Use the ( or ) button to select the current year.
11. Use the % button to return to "Year".
12. Use the ) button to apply the settings.
The initial use is complete.
Notes
■ You can change these settings at any time in the
basic settings. ~ "Basic settings" on page 16
■ After connecting the appliance to the power or
following a power cut, the settings for initial use are
shown in the display.
Cleaning the cooking compartment
To remove the new-appliance smell, heat up the
cooking compartment when it is empty and with the
oven door closed.
1. Remove the accessories from the cooking
compartment.
2. Remove leftover packaging, such as polystyrene
pellets, from the cooking compartment.
3. Before heating the appliance, wipe the smooth
surfaces in the cooking compartment with a soft, wet
cloth.
4. Use the # touch button to switch on the appliance.
5. Set the heating type and temperature, then start the
appliance operation. ~ "Setting and starting the
appliance operation" on page 12
6. Keep the kitchen ventilated while the appliance is
heating up.
7. Use the # touch button to switch off the appliance
after the indicated cooking time.
8. Wait until the cooking compartment has cooled
down.
9. Clean the smooth surfaces with soapy water and a
dish cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
Settings
Heating type Top/bottom heating ƒ
Temperature 240 °C
Cooking time 1 hour
en Operating the appliance
12
1Operating the appliance
Operating the appliance
You have already learnt about the controls and how
they work. Now we will explain how to set your
appliance. You will learn about what happens when you
switch the appliance on and off, and how to select the
operating mode.
Switching the appliance on and off
Touch the # touch button to switch the appliance on or
off.
After switching off the appliance, on the display you can
see if the residual heat in the cooking compartment is
high or low.
Notes
■ Certain displays and notes, such as the residual heat
in the cooking compartment, remain visible on the
display even when the appliance is switched off.
■ After an appliance operation, the cooling fan runs on
audibly until the cooking compartment has been
cooled as far as possible.
■ Switch off your device when you do not need to use
it. If no settings are applied for a long time, the
appliance switches itself off automatically.
Setting and starting the appliance operation
Example: CircoTherm hot air ‚ at 170 °C
1. Touch the # touch button to switch on the
appliance.
You are taken directly to the ¢ menu for the types of
heating.
2. Use the ( or ) button to select the type of heating.
3. Use the & button to navigate to the next line.
4. Use the ( or ) button to select the temperature.
Note: Depending on the operating mode, different
settings are available. For each further setting, use
the & button to navigate to the next line. Use the (
or ) button to select the setting.
5. Touch the # touch button to start the appliance
operation.
The heating bar and run time appear on the display.
Note: If you would like to go directly to the 0 main
menu after switching on the appliance, you can select
the main menu under "Operation after switching on" in
the basic settings chapter. ~ "Basic settings"
on page 16
Default values
The appliance suggests a temperature or setting for
each type of heating. You can accept this value or
change it in the appropriate area.
Heating bar
As soon as a type of heating has started, the heating
bar appears on the display.The heating bar shows the
temperature increase in the cooking compartment.
Run time
When a type of heating has been started, the run time is
displayed. The run time counts upwards during the
operation. You can therefore check how long the
operation has already been running.
Displaying the current temperature
To show the current temperature on the display, press
the ! touch button.
The current temperature is shown briefly only when
heating up.
Further information
If the ! touch button lights up, information can be
displayed. Touch the ! touch button to do this. The
information is displayed for a few seconds.
Display Meaning
-H- Residual heat high (above 120 °C)
-h- Residual heat low (between 60 °C and 120 °C)
&LUFR7KHUPKRWDLU
&
&LUFR7KHUPKRWDLU
&
Operating the appliance en
13
Changing or cancelling the appliance
operation
Changing the appliance operation
1. Use the # button to stop the operation.
2. Use the & or % button to navigate to the line for the
setting that should be changed.
3. Use the ( or ) button to change the setting.
4. Use the # touch button to start the changed
operation.
Notes
■ The cooling fan may continue to run while an
operation is interrupted.
■ After a temperature change, the paused running time
continues to count. After a change in the type of
heating, the running time starts again from zero.
Cancelling the appliance operation
Press and hold the # touch button until the appliance
operation is cancelled.
Note: Operating modes such as the cleaning function
cannot be cancelled.
Heating up the appliance quickly
You can use the "Rapid heat-up" and "PowerBoost"
functions to reduce the preheat time. Whether the
appliance is preheated with the "Rapid heat-up" function
or the "PowerBoost" function depends on the type of
heating that has been set. With the "PowerBoost"
function, unlike with the "Rapid heat-up" function, you
can place your food into the cold cooking compartment
even before preheating has begun. Only cook on one
level when using the "PowerBoost" function.
Notes
■ If the ° touch button is lit, the "Rapid heat-up" or
"PowerBoost" function can be activated.
■ To deactivate the "Rapid heat-up" or "PowerBoost"
function before it has finished, touch the ° touch
button.
Activating the "Rapid heat-up" function
1. Set top/bottom heating ƒ and the temperature.
Note: Set a temperature above 100 °C to allow the
appliance to preheat quickly.
2. Touch the # touch button to start the appliance
operation.
3. Touch the ° touch button to activate the "Rapid
heat-up" function.
The ° symbol appears on the display.
4. Once the set temperature has been reached, the
"Rapid heat-up" function switches itself off
automatically. The ° symbol disappears from the
display. Place the food in the cooking compartment
Activating the "PowerBoost" function
1. Set CircoTherm hot air ‚ or the bread baking
setting … and the temperature.
Note: Set a temperature above 100 °C to allow the
appliance to preheat quickly.
2. Place the food on a single level in the cooking
compartment.
3. Touch the # touch button to start the appliance
operation.
4. Touch the ° touch button to activate the
"PowerBoost" function.
The ° symbol appears on the display.
Once the set temperature has been reached, the
"PowerBoost" function switches itself off
automatically. The ° symbol disappears from the
display.
Function Type of heating Place the food in
the cooking
compartment
Rapid heat-up Top/bottom heating ƒ after preheating
PowerBoost* CircoTherm hot air ‚ before preheating
Bread-baking setting …
* Do not use more than one level for cooking
en Time-setting options
14
OTime-setting options
Time-setting options
Your appliance has different time-setting options.
Note: If you have set a time-setting option, the time
interval increases if you set a higher value. Example:
You can set a cooking time of up to one hour in one-
minute increments; for cooking times over one hour,
you can set a cooking time in five-minute increments.
Showing and hiding the time-setting options
To show or hide the time-setting options, touch the
0 touch button.
Note: After a particular length of time, the time-setting
options that are shown are automatically hidden. If you
have already set a cooking time, it will be applied.
Setting the timer
The timer can be set when the appliance is switched on
or off.
1. Touch the 0 touch button.
The time-setting options are shown on the display.
2. Select the cooking time using the ) button.
Note: When the appliance is switched on, use the %
button to navigate to the Timer . line and then
select the cooking time using the ) button.
3. Touch the 0 touch button to start the timer.
The . symbol appears on the display.The timer
counts down.
Note: As soon as the set time has elapsed, a signal
sounds. To cancel the signal tone, touch the 0 touch
button.
Setting the cooking time
Once the set cooking time has elapsed, the appliance
switches off automatically. The function can only be
used in combination with a type of heating.
1. Touch the # touch button.
2. Set the type of heating and temperature.
3. Touch the 0 touch button.
The time-setting options are shown in the display.
4. Use the ( or ) button to set the cooking time.
– Default value for the ( button = 10 minutes
– Default value for the ) button = 30 minutes
5. Touch the # touch button to start the set cooking
time.
As soon as the cooking time has elapsed, an audible
signal sounds and the appliance ends the operation
automatically. Touch the 0 touch button to end the
audible signal.
Start delay – "Ready at"
The appliance switches on automatically and switches
off at the preset end time.To do this, set the cooking
time and determine the end time for the operation.
The start delay can only be used in combination with a
type of heating.
Notes
■ Ensure that food is not left in the cooking
compartment for too long as it may spoil.
■ It is not possible to start every type of heating with a
start delay.
1. Slide food into the cooking compartment on a
suitable accessory and close the appliance door.
2. Touch the # touch button.
3. Set the type of heating and temperature.
4. Touch the 0 touch button.
The time-setting options are shown on the display.
5. Select the cooking time using the ) button.
6. Use the & button to navigate to the "* Ready at"
line.
7. Select the end time using the ) button.
8. Touch the # touch button.
The appliance waits until the appropriate time to start
the operation.
As soon as the end time has passed, a signal sounds
and the appliance stops the operation automatically. To
cancel the signal tone, touch the 0 touch button.
Checking, changing or deleting settings
1. Touch the 0 touch button.
The time-setting options are shown on the display.
2. Use the & or % button to navigate through the lines.
3. If necessary, change the setting using the ( or )
button. Set "00:00" to delete a time function.
The setting is applied automatically.
Time-setting option Use
. Timer The timer functions like an egg timer. The
appliance does not switch on and off auto-
matically.
+ Cooking time Once the set cooking time has elapsed,
the appliance switches off automatically.
* Ready at The appliance switches on automatically,
and once the set cooking time has
elapsed and the end time has passed, it
switches off automatically.
PLQ_V
K_PLQ
Loading...
