BUILT-IN OVEN
[en] INSTRUCTION MANUAL
B48FT68H0
Table of contents
8Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(Important safety information . . . . . . . . . . . . . . . 5
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Steam. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Meat thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
]Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Steam. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7Environmental protection . . . . . . . . . . . . . . . . . . 7
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 8
*Getting to know your appliance . . . . . . . . . . . . . 9
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Types of heating menu. . . . . . . . . . . . . . . . . . . . . . . . 10 Cooking compartment functions . . . . . . . . . . . . . . . . 11 Water tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
_Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . 12 Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 12 Combining accessories . . . . . . . . . . . . . . . . . . . . . . . 13 Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 13
KBefore using for the first time. . . . . . . . . . . . . . 14
Before using for the first time. . . . . . . . . . . . . . . . . . . 14 Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Calibrating the appliance and cleaning the cooking compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning the accessories. . . . . . . . . . . . . . . . . . . . . . 15
1Operating the appliance . . . . . . . . . . . . . . . . . . 15
Switching the appliance on and off . . . . . . . . . . . . . . 15 Setting and starting the appliance operation . . . . . . . 15 Changing or cancelling the appliance operation . . . . 16 Heating up the appliance quickly . . . . . . . . . . . . . . . . 16
`Steam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 FullSteam – Steam cooking . . . . . . . . . . . . . . . . . . . . 17 VarioSteam – Steam-assisted cooking. . . . . . . . . . . . 17 Dough proving setting . . . . . . . . . . . . . . . . . . . . . . . . 18 Sous-vide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Defrost setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Reheating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Filling the water tank . . . . . . . . . . . . . . . . . . . . . . . . . 19 After every steam operation . . . . . . . . . . . . . . . . . . . . 20
en
OTime-setting options . . . . . . . . . . . . . . . . . . . . . 21
Showing and hiding the time-setting options . . . . . . .21 Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Setting the cooking time. . . . . . . . . . . . . . . . . . . . . . .22 Start delay – "Ready at" . . . . . . . . . . . . . . . . . . . . . . .22 Checking, changing or deleting settings . . . . . . . . . .22
AChildproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 22
Automatic childproof lock. . . . . . . . . . . . . . . . . . . . . .22 One-time childproof lock. . . . . . . . . . . . . . . . . . . . . . .23
QBasic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Changing MyProfile . . . . . . . . . . . . . . . . . . . . . . . . . .23 List of basic settings. . . . . . . . . . . . . . . . . . . . . . . . . .23 Setting favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
nBaking and roasting assistant . . . . . . . . . . . . . 24
Information on the settings . . . . . . . . . . . . . . . . . . . . .24 Selecting a meal. . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Selecting and setting food . . . . . . . . . . . . . . . . . . . . .25
PProgrammes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Information on the settings . . . . . . . . . . . . . . . . . . . . .25 Selecting a dish . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Setting a programme . . . . . . . . . . . . . . . . . . . . . . . . .26
@Meat thermometer . . . . . . . . . . . . . . . . . . . . . . . 27
Suitable types of heating . . . . . . . . . . . . . . . . . . . . . .27 Inserting the meat probe into the food . . . . . . . . . . . .27 Core temperatures of different foods . . . . . . . . . . . . .27 Setting and starting the appliance operation . . . . . . .28 Changing or cancelling the appliance operation . . . .28
FSabbath mode . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Starting the Sabbath mode. . . . . . . . . . . . . . . . . . . . .29 Cancelling Sabbath mode . . . . . . . . . . . . . . . . . . . . .29
oHome Connect . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Setting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Remote Start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Home Connect settings . . . . . . . . . . . . . . . . . . . . . . .30 Remote diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . .30 About data protection . . . . . . . . . . . . . . . . . . . . . . . . .30 Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . .30
DCleaning agent . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . .31 Surfaces in the cooking compartment . . . . . . . . . . . .32 After cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 Keeping the appliance clean . . . . . . . . . . . . . . . . . . .32
3
en Intended use
.Cleaning function. . . . . . . . . . . . . . . . . . . . . . . . 33
EasyClean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Descaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
pRails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Changing the shelf position for the telescopic rail . . . 35 Detaching and refitting the rails . . . . . . . . . . . . . . . . .35
qAppliance door. . . . . . . . . . . . . . . . . . . . . . . . . . 36
Removing and fitting the appliance door . . . . . . . . . . 36 Removing and installing the door panels . . . . . . . . . . 37
3Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 40
Fault table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 Maximum operating time exceeded . . . . . . . . . . . . . .41 Cooking compartment bulbs . . . . . . . . . . . . . . . . . . .41
4Customer service. . . . . . . . . . . . . . . . . . . . . . . . 42
E number and FD number . . . . . . . . . . . . . . . . . . . . .42
JTested for you in our cooking studio. . . . . . . . |
42 |
Silicone moulds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
42 |
Cakes and small baked items . . . . . . . . . . . . . . . . . . |
42 |
Bread and rolls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
46 |
Pizza, quiche and savoury cakes . . . . . . . . . . . . . . . . |
49 |
Bakes and soufflés. . . . . . . . . . . . . . . . . . . . . . . . . . . |
50 |
Poultry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
51 |
Meat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
53 |
Fish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
57 |
Vegetables, side dishes and eggs . . . . . . . . . . . . . . . |
59 |
Dessert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
61 |
Menu cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
62 |
Eco heating functions. . . . . . . . . . . . . . . . . . . . . . . . . |
62 |
Acrylamide in foodstuffs. . . . . . . . . . . . . . . . . . . . . . . |
64 |
Slow cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
64 |
Drying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
65 |
Preserving and juicing . . . . . . . . . . . . . . . . . . . . . . . . |
66 |
Sterilising bottles and hygiene . . . . . . . . . . . . . . . . . . |
67 |
Allowing the dough to prove at dough proving |
|
setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
67 |
Sous-vide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
68 |
Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
71 |
Reheating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
72 |
Keeping warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
73 |
Test dishes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
74 |
Additional information on products, accessories, replacement parts and services can be found at
www.neff-international.com and in the online shop www.neff-eshop.com
8Intended use
Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.
This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.
Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
This appliance is intended for use up to a maximum height of 2000 metres above sea level.
This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsible for their safety how to use the appliance safely and have understood the associated hazards.
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 15 years old and are being supervised.
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
Always slide accessories into the cooking compartment the right way round.
~ "Accessories" on page 12
4
(Important safety information
General information :Warning – Risk of fire!
■Combustible items stored in the cooking compartment may catch fire. Never store combustible items in the cooking compartment. Never open the appliance door if there is smoke inside. Switch off the appliance and unplug it from the mains or switch off the circuit breaker in the fuse box.
■Loose food remnants, fat and meat juices may catch fire. Before using the appliance, remove the worst of the food remnants from the cooking compartment, heating elements and accessories.
■A draught is created when the appliance door is opened. Greaseproof paper may come into contact with the heating element and catch fire. Do not place greaseproof paper loosely over accessories during preheating. Always weight down the greaseproof paper with a dish or a baking tin. Only cover the surface required with greaseproof paper. Greaseproof paper must not protrude over the accessories.
:Warning – Risk of burns!
■The appliance becomes very hot. Never touch the interior surfaces of the cooking compartment or the heating elements. Always allow the appliance to cool down. Keep children at a safe distance.
■Accessories and ovenware become very hot. Always use oven gloves to remove accessories or ovenware from the cooking compartment.
■Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food containing large quantities of drinks with a high alcohol content. Only use small quantities of drinks with a high alcohol content. Open the appliance door with care.
Important safety information |
en |
:Warning – Risk of scalding!
■The accessible parts become hot during operation. Never touch the hot parts. Keep children at a safe distance.
■When you open the appliance door, hot steam can escape. Steam may not be visible, depending on its temperature. When opening, do not stand too close to the appliance. Open the appliance door carefully. Keep children away.
■Water in a hot cooking compartment may create hot steam. Never pour water into the cooking compartment when the cooking compartment is hot.
:Warning – Risk of injury!
■Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents.
■The hinges on the appliance door move when opening and closing the door, and you may be trapped. Keep your hands away from the hinges.
:Warning – Risk of electric shock!
■Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the aftersales service.
■The cable insulation on electrical appliances may melt when touching hot parts of the appliance. Never bring electrical appliance cables into contact with hot parts of the appliance.
■Do not use any high-pressure cleaners or steam cleaners, which can result in an electric shock.
■A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
:Warning – Hazard due to magnetism!
Permanent magnets are used in the control panel or in the control elements. They may affect electronic implants, e.g. heart pacemakers or insulin pumps. Wearers of electronic implants must stay at least 10 cm away from the control panel.
5
en Causes of damage
Steam
:Warning – Risk of scalding!
■The water in the water tank may become very hot if you continue to operate the appliance. Empty the water tank after every operation with steam.
■Hot steam is generated in the cooking compartment. Do not reach into the cooking compartment during any operation with steam.
■Hot liquid may spill over the sides of the accessory when it is removed from the cooking compartment. Remove hot accessories with care and always wear oven gloves.
:Warning – Risk of injury and risk of fire!
Flammable liquids can catch fire in the cooking compartment when it is hot (explosion). Do not fill the water tank with any flammable fluids (e.g. alcoholic drinks). Only fill the water tank with water or with the descaling solution that is recommended by us.
Meat thermometer
:Warning – Risk of electric shock!
The insulation of an incompatible meat thermometer may be damaged. Only use the meat thermometer which is recommended for this appliance.
]Causes of damage
General information
Caution!
■Accessories, foil, greaseproof paper or ovenware on the cooking compartment floor: do not place accessories on the cooking compartment floor. Do not cover the cooking compartment floor with any sort of foil or greaseproof paper. Do not place ovenware on the cooking compartment floor if a temperature of over 50 ºC has been set. This will cause heat to accumulate. The baking and roasting times will no longer be correct and the enamel will be damaged.
■Aluminium foil: Aluminium foil in the cooking compartment must not come into contact with the door glass. This could cause permanent discolouration of the door glass.
■Water in a hot cooking compartment: do not pour water into the cooking compartment when it is hot. This will cause steam. The temperature change can cause damage to the enamel.
■Moisture in the cooking compartment: Over an extended period of time, moisture in the cooking compartment may lead to corrosion. Allow the cooking compartment to dry after use. Do not keep moist food in the closed cooking compartment for extended periods of time. Do not store food in the cooking compartment.
■Cooling with the appliance door open: Following operation at high temperatures, only allow the cooking compartment to cool down with the door closed. Do not trap anything in the appliance door. Even if the door is only left open a crack, the front of nearby furniture may become damaged over time. Only leave the cooking compartment to dry with the door open if a lot of moisture was produced whilst the oven was operating.
■Fruit juice: when baking particularly juicy fruit pies, do not pack the baking tray too generously. Fruit juice dripping from the baking tray leaves stains that cannot be removed. If possible, use the deeper universal pan.
■Extremely dirty seal: If the seal is very dirty, the appliance door will no longer close properly during operation. The fronts of adjacent units could be damaged. Always keep the seal clean. Never operate the appliance if the seal is damaged or missing.
■Appliance door as a seat, shelf or worktop: Do not sit on the appliance door, or place or hang anything on it. Do not place any cookware or accessories on the appliance door.
■Inserting accessories: depending on the appliance model, accessories can scratch the door panel when closing the appliance door. Always insert the accessories into the cooking compartment as far as they will go.
■Carrying the appliance: do not carry or hold the appliance by the door handle. The door handle cannot support the weight of the appliance and could break.
6
Steam
Caution!
■Baking tins: Ovenware must be heat and steam resistant. Silicone baking tins are not suitable for combined operation with steam.
■Ovenware with areas of rust: Do not use any ovenware which displays areas of rust. Even the smallest spots of rust can lead to corrosion in the cooking compartment.
■Dripping liquids: When steaming with a perforated cooking container, always insert the baking tray, the universal pan or the solid cooking container underneath. Dripping liquid is caught.
■Hot water in the water tank: Hot water can damage the pump. Only fill the water tank with cold water.
■Enamel damage: Do not start any operations when there is water on the cooking compartment floor. Before operation, wipe away the water from the cooking compartment floor.
■Descaling solution: Do not allow any descaling solution to come into contact with the control panel or other surfaces on the appliance. This damages the surfaces. If this does happen, remove the descaling solution immediately with water.
■Cleaning the water tank: Do not clean the water tank in the dishwasher. Otherwise, the water tank will be damaged. Clean the water tank with a soft cloth and standard washing-up liquid.
Environmental protection |
en |
7Environmental protection
Your new appliance is particularly energy-efficient. Here you can find tips on how to save even more energy when using the appliance, and how to dispose of your appliance properly.
Saving energy
■Only preheat the appliance if this is specified in the recipe or in the tables in the operating instructions.
■Leave frozen food to defrost before placing it in the cooking compartment.
■Use baking tins that are dark-coloured, painted black or have an enamel coating. These absorb the heat particularly well.
■Remove any unnecessary accessories from the cooking compartment.
7
en Environmental protection
■Open the appliance door as infrequently as possible when the appliance is in use.
■It is best to bake several cakes one after the other. The cooking compartment stays warm. This reduces the baking time for the second cake. You can place two cake tins next to each other in the cooking compartment.
■For longer cooking times, you can switch the appliance off 10 minutes before the end of the cooking time and use the residual heat to finish cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (waste electrical and electronic equipment - WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU.
8
Getting to know your appliance |
en |
*Getting to know your appliance
In this section, we will explain the indicators and controls. You will also find out about the various functions of your appliance.
Note: Depending on the appliance model, individual details and colours may differ.
Control panel
In the control panel, set your appliance's different functions using the FullTouch TFT display. The current settings are shown on the FullTouch TFT display.
&LUFR7KHUP
&
( FullTouch TFT display 0 Touch buttons
Controls
Use the controls to set your appliance simply and directly.
Touch buttons
There are sensors under the touch buttons. Touch the corresponding touch button to select a function.
Touch button |
Use |
|
# |
On/off |
Switches the appliance on or |
|
|
off~ "Switching the appliance on |
|
|
and off" on page 15 |
ŽSteam-assisted cookSwitching on steam-assisted cooking
|
ing |
~ "VarioSteam – Steam-assisted |
|
|
cooking" on page 17 |
|
Time-setting options |
|
3 |
Sets the timer, cooking time or "Fin- |
|
|
|
ished at" start delay ~ "Time-setting |
|
|
options" on page 21 |
|
Childproof lock |
Activating and deactivating the child- |
|
|
proof lock ~ "Childproof lock" |
|
|
on page 22 |
0 |
Main menu |
Selects operating modes and settings |
|
|
~ "Setting and starting the |
|
|
appliance operation" on page 15 |
|
|
|
° |
Rapid heating |
Activating or deactivating rapid heat- |
|
|
ing ~ "Heating up the appliance |
|
|
quickly" on page 16 |
|
|
Activating or deactivating Power- |
|
|
Boost ~ "Heating up the appliance |
|
|
quickly" on page 16 |
! |
Information |
Displays additional information |
|
|
Displays the current temperature |
|
|
~ "Setting and starting the |
|
|
appliance operation" on page 15 |
” |
Open cover |
Filling or emptying the water tank |
|
|
~ "Filling the water tank" |
|
|
on page 19 |
# |
Start/stop |
Start or pause the appliance |
|
|
~ "Setting and starting the |
|
|
appliance operation" on page 15 |
FullTouch TFT display
With the FullTouch TFT display, you can navigate through the lines and select settings.
To adjust a setting, touch the appropriate point on the display using your finger. The area is displayed more brightly. With your finger touching this area of the display, swipe to the left or right until the required setting is displayed larger.
9
en Getting to know your appliance
Direction |
Use |
Navigate to the left |
On the display, use your finger to swipe |
|
to the right |
Navigate to the right |
On the display, use your finger to swipe |
|
to the left |
Navigate upwards |
Touch the top line of the display |
Navigate downwards |
Touch the bottom line of the display |
|
|
Main menu
Touch the 0 touch button to access the main menu.
Menu Use
¢Types of heating
Select the desired heating type and temperature for your food ~ "Switching the appliance on and off" on page 15
‹Steam cooking
Cooking with steam ~ "FullSteam – Steam cooking" on page 17
Types of heating menu
Your appliance comes with various types of heating. After switching on the appliance, you are taken directly to the menu for the types of heating.
£Baking and roasting assistant
Recommended settings for baking and roasting
~ "Baking and roasting assistant" on page 24
²Steam programmes
Preparing dishes with steam ~ "Programmes" on page 25
4MyProfile
Individually adjusting the appliance settings
~ "Basic settings" on page 23
EHome Connect Assistant
Connecting your appliance to your mobile device
~ "Basic settings" on page 23
,Descale
ªDrying
Drying the cooking compartment after a steam operation ~ "After every steam operation" on page 20
šEasyClean
Cleaning light soiling from the cooking compartment
~ "Cleaning function" on page 33
Type of heating |
Temperature |
Use |
|
|
|
|
|
‚ |
CircoTherm * |
40 - 200 °C |
For baking and cooking on one or more levels. |
|
|
|
The fan distributes the heat from the ring heating element in the back panel |
|
|
|
evenly around the cooking compartment. |
ƒ |
Top/bottom heating * |
50 - 250 °C |
For traditional baking and roasting on one level. Especially suitable for cakes with |
|
|
|
moist toppings. |
|
|
|
Heat is emitted evenly from the top and bottom. |
‡ |
Circo-roasting * |
50 - 250 °C |
For roasting poultry, whole fish and larger pieces of meat. |
|
|
|
The grill element and the fan switch on and off alternately. The fan circulates the |
|
|
|
hot air around the food. |
„ |
Circotherm intensive |
50 - 250 °C |
For preparing pizza and dishes which require a lot of heat from underneath. |
|
|
|
The bottom heating element and the ring heating element in the back panel heat |
|
|
|
up. |
… |
Bread-baking * |
180 - 240 °C |
For baking bread, bread rolls and baked items that require high temperatures. |
ˆ |
Full-surface grill |
50 - 275 °C |
For grilling flat items, such as steaks or sausages, for making toast, and for au gra- |
|
|
|
tin dishes. |
|
|
|
The whole area below the grill element becomes hot. |
‰ |
Centre-area grill |
50 - 275 °C |
For grilling small amounts of steaks or sausages, for making toast, and for au gra- |
|
|
|
tin dishes. |
|
|
|
The centre area under the grill heating element becomes hot. |
† |
Bottom heat |
30 - 250 °C |
For cooking in a bain marie and for the final baking stage. |
|
|
|
The heat is emitted from below. |
Š |
Slow cooking |
70–120 °C |
For gentle and slow cooking of seared, tender pieces of meat in ovenware without |
|
|
|
a lid. |
|
|
|
Heat is emitted evenly from above and below at low temperatures. |
Œ |
Dough proving ** |
2 levels |
For leaving yeast dough and sourdough to prove and for culturing yogurt. |
|
|
|
Dough will prove more quickly than at room temperature. The surface of the |
dough does not dry out.
10
|
|
|
Getting to know your appliance |
en |
|
|
|
|
|
¸ |
Sous-vide ** |
50-95 °C |
Cooking "under a vacuum" at low temperatures between 50 and 95 °C and 100% |
|
|
|
|
steam: Suitable for meat, fish, vegetables and desserts. |
|
|
|
|
A chamber vacuum-packing machine is used to heat-seal the food in special air- |
|
|
|
|
tight, heat-resistant cooking bags. The protective envelope retains the nutrients |
|
|
|
|
and flavours. |
|
“ |
Defrost setting ** |
30 - 60 °C |
For gently defrosting frozen food. |
|
|
|
|
|
|
¯ |
Plate warming |
30-70 °C |
For preheating ovenware. |
|
|
|
|
|
|
« |
Keep warm * |
60 - 100 °C |
For keeping cooked food warm. |
|
‘ |
Top/bottom heating eco |
50-250 °C |
For gently cooking selected types of food. |
|
|
|
|
Heat is emitted from above and below. |
|
|
|
|
This heating function is most effective between 150 and 250 °C. |
|
|
|
|
This heating function is used to measure the energy consumption in the conven- |
|
|
|
|
tional mode. |
|
ž |
CircoTherm eco |
40–200 °C |
For gently cooking selected types of food on one level without preheating. |
|
|
|
|
The fan distributes the heat from the ring-shaped heating element in the back |
|
|
|
|
panel around the cooking compartment. |
|
|
|
|
This heating function is most effective between 125 and 200 °C. |
|
|
|
|
This type of heating is used to measure both the energy consumption in air recir- |
|
|
|
|
culation mode and the energy-efficiency class. |
|
¨ |
Reheat ** |
80 - 180 °C |
For gently reheating food or for crisping up pastries. |
|
*Possible to use steam for this type of heating (operation only possible when the water tank is full)
**Type of steam heating (operation only possible when the water tank is full)
Cooking compartment functions
The features of the cooking compartment make your appliance easier to use. This, for example, enables the cooking compartment to be well lit and a cooling fan to prevent the appliance from overheating.
Opening the appliance door
If you open the appliance door while the appliance is in operation, this pauses the programme. The operation continues to run when you close the door.
Note: For some types of heating, the operation continues to run even when the appliance door is open.
Interior lighting
When you open the appliance door, the interior lighting switches on. If the door remains open for longer than around 15 minutes, the lighting switches off again.
In most operating modes, the interior lighting will switch on as soon as the appliance is started. Once the program is complete, the lighting switches off.
Note: You can set the interior lighting to not come on during the operation in the basic settings. ~ "Basic settings" on page 23
Cooling fan
The cooling fan switches on and off as required. The hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the appliance may overheat.
To cool the cooking compartment more quickly after operation, the cooling fan continues to run for a certain period afterwards.
Note: You can change how long the cooling fan continues to run in the basic settings. ~ "Basic settings" on page 23
Water tank
The appliance is fitted with a water tank. The water tank is behind the panel. For operations with steam, fill the water tank with water. ~ "Steam" on page 17
( Tank cover 0 Filling opening
8 Handle for removing and inserting the water tank
11
en Accessories
_Accessories
Your appliance is accompanied by a range of accessories. Here, you can find an overview of the accessories included and information on how to use them correctly.
Accessories included
Your appliance is equipped with the following accessories:
Wire rack
For ovenware, cake tins and ovenproof dishes.
For roasts, grilled items and frozen meals.
Baking tray
For tray bakes and small baked products.
Universal pan
For moist cakes, other baked items, frozen meals and large roasts.
It can be used to catch dripping fat when you are grilling directly on the wire rack. During operation with steam, it can also be used to catch drops of water.
Steam container, perforated, size S
For steaming vegetables, juicing berries and defrosting.
Steam container, unperforated, size
S
For cooking rice, pulses and cereals.
Steam container, perforated, size XL
For steaming large quantities.
Meat thermometer
Enables precision roasting to your exact requirements.
Its use is described in the relevant section. ~ "Meat thermometer"
on page 27
Only use genuine accessories. They are specially adapted for your appliance.
You can buy accessories from the after-sales service, from specialist retailers or online.
Note: The accessories may become deformed when they become hot. This does not affect their function. Once they cool down again, they regain their original shape.
Note: You can use the steam container with all heating modes involving steam without any restrictions. If you set other heating modes at high temperatures, take the steam container out of the cooking compartment. High temperatures can cause permanent deformations and discolouration of the steam container.
Inserting accessories
The cooking compartment has four shelf positions. The shelf positions are counted from the bottom up.
In some appliances, the top shelf position in the cooking compartment features a grill symbol.
:Warning – Risk of burns!
The telescopic shelves become hot when the appliance is in use. Take special care not to get burnt when they are pulled out.
Ensure that the accessory is placed under the lug ‚ on the pull-out rail.
Example in the picture: Universal pan
D |
Accessories on the telescopic shelf can be pulled out as far as the notch ƒ (fig. !). Hold the accessory on both sides in the area marked „ and remove it (fig. ").
12
Notes
■Ensure that you always insert the accessories into the cooking compartment the right way round.
■Always insert the accessories fully into the cooking compartment so that they do not touch the appliance door.
12
Locking function
The accessories can be pulled out approximately halfway until they lock in place. The locking function prevents the accessories from tilting when they are pulled out. The accessories must be inserted into the cooking compartment correctly for the tilt protection to work properly.
When inserting the wire rack, ensure that the lug ‚ is facing downwards.
D
D
When inserting baking trays, ensure that the lug ƒ is at the rear and is facing downwards. The sloping edge of the accessory „ must be facing towards the appliance door.
E |
E |
F |
Combining accessories
You can insert the wire rack and the universal pan at the same time to catch drops of liquid.
When inserting the wire rack, ensure that both spacers ‚ are at the rear edge. When the universal pan is inserted, the wire rack is on top of the upper guide rod of the shelf position.
D
D
D
Small steam containers may only be placed in the cooking compartment with the wire rack.
Accessories en
Optional accessories
You can purchase optional accessories from the aftersales service and specialist retailers, or on the Internet. You will find a comprehensive range of products for your appliance in our brochures and on the Internet.
Both availability and whether it is possible to order online differ between countries. Please see your sales documents for more details.
Note: Not all optional accessories are suitable for every appliance. When purchasing, please always quote the exact designation (E no.) of your appliance.
~ "Customer service" on page 42
Optional accessories
Baking and roasting shelf, suitable for steaming Baking tray
Universal pan Baking tray, non-stick
Universal pan, non-stick Extra-deep pan
Steam container, perforated, size XL Steam container, perforated, size S Steam container, unperforated, size S
Porcelain cooking container, unperforated, size S Porcelain cooking container, unperforated, size L Profi pan
Lid for the Profi pan Pizza tray
Grill tray Ceramic brick
Glass roasting dish, 5.1 litres Glass pan
ComfortFlex rail (1 level), suitable for steaming*
3 x fully extendable pull-out rack, suitable for steaming*
*Accessory does not fit in every appliance, quote the E no. when ordering
13
en Before using for the first time
KBefore using for the first time
Before you can use your new appliance, you must make some settings. You must also clean the cooking compartment and accessories.
Before using for the first time
Before using the appliance for the first time, ask your water supplier about the hardness of your tap water.
To ensure that the appliance can reliably remind you to descale it when required, you must set your water hardness range correctly.
Caution!
■The appliance may become damaged due to the use of unsuitable liquids.
Do not use distilled water, highly chlorinated tap water (>40 mg/l) or other liquids.
Only use cold, fresh tap water, softened water or non-carbonated mineral water.
■Malfunctions may occur when using filtered or demineralised water.
The appliance may request that you top up the water tank even though it may be full, or operation with steam is cancelled after approx. two minutes.
If required, mix filtered or demineralised water with the bottled non-carbonated mineral water with a ratio of one to one.
Notes
■If your water is very hard, we recommend that you use softened water.
■If you only use softened water, you can set the water hardness range to "softened".
■If you use mineral water, set the water hardness range to "4 very hard".
■If you use mineral water, you must only use noncarbonated mineral water.
Water hardness range |
Setting |
|
0 |
|
0 softened |
1 |
(up to 1.3 mmol/l) |
1 soft |
2 |
(1.3 - 2.5 mmol/l) |
2 medium |
3 |
(2.5 - 3.8 mmol/l) |
3 hard |
4 |
(above 3.8 mmol/l) |
4 very hard |
|
|
|
Initial use
As soon as the appliance is connected to the power supply, the first setting "Language" appears on the display.
Setting the language
1.Touch the bottom line.
2.Swipe to the left or right to select the required language.
3.Touch the top line.
Set up Home Connect
1.Touch "Home Connect".
2.Touch "Next".
Note: Further instructions can be found in section
~ "Home Connect" on page 29
Setting the time
1.Touch "Clock".
2.Touch the bottom line.
3.Swipe to the left or right to select the current hour.
4.Touch "Minutes".
5.Swipe to the left or right to select the current minute.
6.Touch the 8 symbol to apply the setting.
Setting the date
1.Touch "Date".
2.Touch the bottom line.
3.Swipe to the left or right to select the current day.
4.Touch "Month".
5.Swipe to the left or right to select the current month.
6.Touch "Year".
7.Swipe to the left or right to select the current year.
8.Touch the 8 symbol to apply the setting.
Setting the water hardness
1.Touch "Water hardness".
2.Touch the bottom line.
3.Swipe to the left or right to select the appropriate water hardness.
4.Touch the 8 symbol to complete the initial use. The initial use is complete.
Notes
■You can change these settings at any time in the basic settings. ~ "Basic settings" on page 23
■After connecting the appliance to the power or following a power cut, the settings for initial use are shown in the display.
Calibrating the appliance and cleaning the cooking compartment
The boiling point of water depends on the air pressure. During calibration, the appliance self-adjusts to the pressure ratio at the installation location. This will happen automatically the first time steam-assisted cooking is used. This produces a lot of steam.
Preparing the appliance for calibration
1.Remove the accessories from the cooking compartment.
2.Remove any leftover packaging, such as polystyrene pellets, from the cooking compartment.
3.Before calibrating the appliance, wipe the smooth surfaces in the cooking compartment with a soft, damp cloth.
14
Calibrating the appliance and cleaning the cooking compartment
Notes
■Calibration cannot be started until the cooking compartment is cold (room temperature).
■Do not open the appliance door while calibration is in progress, as this will abort the calibration process.
1. Use the # touch button to switch on the appliance.
2. Fill the water tank. ~ "Filling the water tank" on page 19
3. Set the specified type of heating, temperature and duration for the calibration, then start the appliance.
~ "FullSteam – Steam cooking" on page 17
Calibration |
|
Type of heating |
Steam ‹ |
Temperature |
100 °C |
Cooking time |
30 minutes |
|
|
4. Heat up the appliance following calibration.
Caution!
Enamel damage
Do not use the appliance if there is water on the cooking compartment floor. Before using the appliance, wipe away the water from the cooking compartment floor.
5. Dry the cooking compartment floor.
6. Set the specified type of heating and temperature for heating, then start the appliance. ~ "Setting and starting the appliance operation" on page 15
Heating up |
|
Type of heating |
CircoTherm ‚ |
Temperature |
Maximum |
Cooking time |
30 minutes |
|
|
7. Keep the kitchen ventilated while the appliance is heating.
8. Stop the appliance once the specified time has elapsed. Use the # touch button to switch off the appliance.
9. Wait for the cooking compartment to cool down. 10. Clean the smooth surfaces with soapy water and a
dish cloth.
11. Empty the water tank and dry the cooking compartment. ~ "After every steam operation" on page 20
Notes
■When relocating the appliance, restore its factory settings once it is installed so that it can adapt to its new location. Repeat the procedures for initial startup and calibration.
■The appliance retains the calibration settings, even in the event of a power cut or disconnection from the mains. Calibration does not need to be repeated.
Cleaning the accessories
Clean the accessories thoroughly using soapy water and a dish cloth or soft brush.
Operating the appliance |
en |
1Operating the appliance
You have already learnt about the controls and how they work. Now we will explain how to set your appliance. You will learn about what happens when you switch the appliance on and off, and how to select the operating mode.
Switching the appliance on and off
To switch the appliance on or off, touch the # touch button.
After the appliance has switched off, the display shows whether the residual heat in the cooking compartment is high or low.
Display |
Temperature |
Residual heat high |
above 120 °C |
Residual heat low |
between 60 °C und 120 °C |
Notes
■Certain indicators and instructions (e.g. about residual heat in the cooking compartment) remain visible on the display even when the appliance is switched off.
■After the appliance has completed an operation, you will hear the cooling fan continuing to run until the cooking compartment is cooled as much as possible.
■Switch off your appliance when you do not need to use it. If no settings are made for a long time, the appliance switches off automatically.
Setting and starting the appliance operation
Example: ‚ CircoTherm hot air at 170 °C
1.Touch the # touch button to switch on the appliance.
You go directly to the ¢ Types of heating menu.
&LUFR7KHUP
&
2.Swipe to the left or right to select the type of heating.
3.Touch the bottom line.
4.Swipe to the left or right to select the temperature.
&LUFR7KHUP
& & & & &
15
en Operating the appliance
5.Touch the # touch button to start the appliance operation.
The heat-up indicator bar and the run time appear in the display.
Note: If you want to go directly to the 0 main menu when you switch on the appliance, you can find instructions on how to do this in the Basic settings chapter under "Operation after switching on".
Default values
The appliance suggests a temperature or setting for each type of heating. You can accept this value or change it in the appropriate area.
Heating bar
As soon as a type of heating has started, the heating bar appears on the display.The heating bar shows the temperature increase in the cooking compartment.
Run time
When a type of heating has been started, the run time is displayed. The run time counts upwards during the operation. You can therefore check how long the operation has already been running.
Displaying the current temperature
To show the current temperature on the display, press the ! touch button.
The current temperature is shown briefly only when heating up.
Further information
If the ! touch button lights up, information can be displayed. Touch the ! touch button to do this. The information is displayed for a few seconds.
Changing or cancelling the appliance operation
Changing the appliance operation
1.Use the # button to stop the operation.
2.Tap the line for the setting that should be changed.
3.Swipe to the left or right to change the setting.
4.Use the # touch button to start the changed operation.
Notes
■The cooling fan may continue to run while an operation is interrupted.
■After a temperature change, the paused running time continues to count. After a change in the type of heating, the running time starts again from zero.
Cancelling the appliance operation
Press and hold the # touch button until the appliance operation is cancelled.
Note: Operating modes such as the cleaning function cannot be cancelled.
Heating up the appliance quickly
You can use the "Rapid heat-up" and "PowerBoost" functions to reduce the preheat time. Whether the appliance is preheated with the "Rapid heat-up" function or the "PowerBoost" function depends on the type of heating that has been set. With the "PowerBoost" function, unlike with the "Rapid heat-up" function, you can place your food into the cold cooking compartment even before preheating has begun. Only cook on one level when using the "PowerBoost" function.
Function |
Type of heating |
Place the food in |
|
|
the cooking |
|
|
compartment |
Rapid heat-up |
Top/bottom heating ƒ |
after preheating |
PowerBoost* |
CircoTherm hot air ‚ |
before preheating |
|
Bread-baking setting … |
|
* Do not use more than one level for cooking
Notes
■If the ° touch button is lit, the "Rapid heat-up" or "PowerBoost" function can be activated.
■To deactivate the "Rapid heat-up" or "PowerBoost" function before it has finished, touch the ° touch button.
Activating the "Rapid heat-up" function
1.Set top/bottom heating ƒ and the temperature.
Note: Set a temperature above 100 °C to allow the appliance to preheat quickly.
2.Touch the # touch button to start the appliance operation.
3.Touch the ° touch button to activate the "Rapid heat-up" function.
The ° symbol appears on the display.
4.Once the set temperature has been reached, the "Rapid heat-up" function switches itself off automatically. The ° symbol disappears from the display. Place the food in the cooking compartment
Activating the "PowerBoost" function
1.Set CircoTherm hot air ‚ or the bread baking setting … and the temperature.
Note: Set a temperature above 100 °C to allow the appliance to preheat quickly.
2.Place the food on a single level in the cooking compartment.
3.Touch the # touch button to start the appliance operation.
4.Touch the ° touch button to activate the "PowerBoost" function.
The ° symbol appears on the display.
Once the set temperature has been reached, the "PowerBoost" function switches itself off automatically. The ° symbol disappears from the display.
16
`Steam
Food can be cooked particularly gently using steam. With some heating modes, you can prepare food with steam assistance. In addition, the Dough proving, Defrost and Reheat heating modes are available.
:Warning – Risk of scalding!
When you open the appliance door, hot steam can escape. Steam may not be visible, depending on its temperature. When opening, do not stand too close to the appliance. Open the appliance door carefully. Keep children away.
Noise
Pump
You will hear a humming noise while the pump is in operation and after switching it off. This noise is caused by the pump function test. It is a normal operating noise.
Control panel
You will hear a humming or clicking noise when opening the control panel. These noises are caused by the control panel being pushed out. They are normal operating noises.
FullSteam – Steam cooking
During steaming, hot steam surrounds the food and therefore prevents loss of nutrients from the food. The shape, colour and typical aroma of the dishes are retained as a result of this preparation method.
Note: If the water tank runs dry during steaming, operation is interrupted. Fill the water tank.
Starting
1.Touch the # touch button.
2.Fill the water tank.
Note: Only switch on steaming once the cooking compartment has cooled down completely (to room temperature).
3.Touch the 0 touch button.
4.Swipe to the left or right to select "Steam ‹".
5.Touch the bottom line.
6.Swipe to the left or the right to select the required temperature.
7.Touch the bottom line.
8.Swipe to the left or the right to select the required duration.
9.Touch the # touch button.
The appliance starts the operation.
As soon as the cooking time has elapsed, an audible signal sounds and the appliance ends the operation automatically. Touch the 0 touch button to end the audible signal.
Cancelling
Press and hold the # touch button until the appliance operation is cancelled.
Steam en
Finishing
Touch the # touch button to switch the appliance off.
Menu cooking
With steam, you can cook a whole menu at once, without the different flavours mixing. ~ "Tested for you in our cooking studio" on page 42
VarioSteam – Steam-assisted cooking
When you cook with steam assistance, steam is introduced into the cooking compartment at various intervals and with varying degrees of intensity. This gives you a better cooking result.
Your food
■Becomes crispy on the outside
■Develops a shiny surface
■Is succulent and tender on the inside
■Only undergoes a minimum reduction in volume
You set the combination of heating mode and steam intensity that you want. Use the information in the tables to select a suitable heating mode and steam intensity. Alternatively, select a program from the steam programs. ~ "Tested for you in our cooking studio" on page 42~ "Programmes" on page 25
Steam intensity
Different intensity levels are available when adding steam:
■Low
■Medium
■High
Suitable heating modes
You can switch on steam assistance for these heating modes:
■CircoTherm hot air ‚
■Top/bottom heating ƒ
■Circo-roasting ‡
■Bread-baking …
■Keeping warm «
Starting
1.Touch the # touch button.
2.Fill the water tank.
3.Set the type of heating and temperature.
4.Touch the Ž touch button to switch on steam assistance.
5.On the display, swipe to the left or right to select the steam intensity.
6.Touch the 8 symbol to apply the setting.
7.Touch the # touch button.
The appliance starts the operation.
Note: If the water tank runs dry during an operation with steam assistance, a message appears on the display prompting you to fill up the water tank.
Cancelling steam addition
1.Touch the Ž touch button to cancel the addition of steam early.
2.Touch the set added steam in the bottom line.
17
en Steam
3.On the display, swipe to the left or right to select "Off".
4.Touch the 8 symbol to apply the setting.
Note: The operation continues without adding steam.
Cancelling appliance operation
Press and hold the # touch button until the appliance operation is cancelled.
Finishing
Touch the # touch button to switch the appliance off.
Dough proving setting
Dough will prove considerably more quickly using the "Dough proving Œ" heating mode than at room temperature and does not dry out.
There are two levels available for the Dough proving setting. Use the information in the tables to select the appropriate level. ~ "Tested for you in our cooking studio" on page 42
Note: If the water tank runs dry during operation with the Dough proving setting, operation is interrupted. Fill the water tank.
Starting
1.Touch the # touch button.
2.Fill the water tank.
Note: Only switch on the Dough proving setting once the cooking compartment has completely cooled down (to room temperature).
3.Swipe to the left or right to select "Dough proving".
4.Touch "1" in the bottom line.
5.Swipe to the left or right to select the required level.
6.Touch the 8 symbol to apply the setting.
7.Touch "+" in the bottom line.
8.Swipe to the left or right to select the required duration.
9.Touch the 8 symbol to apply the setting.
10.Touch the # touch button.
The appliance starts the operation.
As soon as the cooking time has elapsed, an audible signal sounds and the appliance ends the operation automatically. Touch the 0 touch button to end the audible signal.
Cancelling
Press and hold the # touch button until the appliance operation is cancelled.
Finishing
Touch the # touch button to switch the appliance off.
Sous-vide
Sous-vide is a type of low-temperature cooking during which vacuum-sealed food is cooked at low temperatures between 50-95 °C and 100% steam. Sous-vide is suitable for meat, fish, vegetables and desserts.
A chamber vacuum-packing machine is used to heatseal the food in special air-tight, heat-resistant cooking bags. The protective envelope retains the nutrients and flavours.
Notes
■If the water tank runs dry while sous-vide cooking, the operation is interrupted.
■During sous-vide cooking, more condensate forms on the cooking compartment floor than for other cooking methods.
Starting
Caution!
Risk of damage to kitchen units
Only fill the water tank once for sous-vide cooking. Do not fill the water tank a second time. Otherwise, large volumes of water will accumulate on the cooking compartment floor. The water may leak out of the cooking compartment.
1.Touch the # touch button.
2.Fill the water tank.
Note: Only activate the sous-vide function once the cooking compartment has cooled down completely (to room temperature).
3.Swipe to the left or right to select "Sous-vide ¸".
4.Touch the temperature in the bottom line.
5.Swipe to the left or the right to select the required temperature.
6.Touch "+" in the bottom line.
7.Swipe to the left or the right to select the required duration.
8.Touch the # touch button.
The appliance will start running in this operating mode.
:Warning – Risk of scalding!
Hot water collects on the vacuum-sealing bag during cooking. Use an oven cloth to carefully lift the vacuumsealing bag, so that the hot water runs off into the universal pan or the cooking container. Then use the oven cloth to carefully remove the vacuum-sealing bag.
Once the cooking time has elapsed, an audible signal will sound and the appliance will bring the operating mode to an end automatically. Touch the 0 touch button to stop the signal tone.
Cancelling
Press and hold the # touch button until the appliance operation is cancelled.
Finishing
Touch the # touch button to switch the appliance off.
Defrost setting
Us the "Defrost “" heating mode to defrost frozen products.
Note: If the water tank runs dry during operation with the Defrost setting, operation is interrupted. Fill the water tank.
18
Starting
1.Touch the # touch button.
2.Fill the water tank.
3.Swipe to the left or right to select "Defrost setting “".
4.Touch the temperature in the bottom line.
5.Swipe to the left or right to select the required temperature.
6.Touch the 8 symbol to apply the setting.
7.Touch "+" in the bottom line.
8.Swipe to the left or right to select the required duration.
9.Touch the 8 symbol to apply the setting.
10.Touch the # touch button.
The appliance starts the operation.
As soon as the cooking time has elapsed, an audible signal sounds and the appliance ends the operation automatically. Touch the 0 touch button to end the audible signal.
Cancelling
Press and hold the # touch button until the appliance operation is cancelled.
Finishing
Touch the # touch button to switch the appliance off.
Reheating
With the "Reheat ¨" heating mode, you can gently reheat food that has already been cooked or crisp up day-old baked goods. Steam is switched on automatically.
Note: If the water tank runs dry during operation with the Reheat setting, operation is interrupted. Fill the water tank.
Starting
1.Touch the # touch button.
2.Fill the water tank.
3.Swipe to the left or right to select "Reheat ¨".
4.Touch the temperature in the bottom line.
5.Swipe to the left or right to select the required temperature.
6.Touch the 8 symbol to apply the setting.
7.Touch "+" in the bottom line.
8.Swipe to the left or right to select the required duration.
9.Touch the 8 symbol to apply the setting.
10.Touch the # touch button.
The appliance starts the operation.
As soon as the cooking time has elapsed, an audible signal sounds and the appliance ends the operation automatically. Touch the 0 touch button to end the audible signal.
Cancelling
Press and hold the # touch button until the appliance operation is cancelled.
Finishing
Touch the # touch button to switch the appliance off.
Steam en
Filling the water tank
The water tank is located behind the control panel. Before starting an operation with steam, open the control panel and fill the water tank with water.
Make sure that you have set the water hardness range correctly. ~ "Basic settings" on page 23
:Warning – Risk of injury and risk of fire!
Only fill the water tank with water or with the descaling solution that is recommended by us. Do not pour any flammable liquids (e.g. alcoholic drinks) into the water tank. Due to hot surfaces, vapours from flammable liquids may catch fire in the cooking compartment (explosion). The appliance door may spring open. Hot steam and jets of flame may escape.
:Warning – Risk of burns!
The water tank may heat up while the appliance is in operation. Wait until the water tank has cooled down after the previous appliance operation. Remove the water tank from the water tank recess.
Caution!
The appliance may become damaged due to the use of unsuitable liquids.
Do not use distilled water, highly chlorinated tap water (> 40 mg/l) or other liquids.
Only use cold, fresh tap water, softened water or uncarbonated mineral water.
Caution!
Malfunctions may occur when using filtered or demineralised water.
The appliance may request that you top up the water tank even though it may be full, or operation with steam is cancelled after approx. two minutes.
If required, mix filtered or demineralised water with the bottled non-carbonated mineral water with a ratio of one to one.
Notes
■If your water is very hard, we recommend that you use softened water.
■If you use only softened water, you can set your appliance to the "softened" water hardness range.
■If you use mineral water, set the water hardness range to "4 very hard".
■If you use mineral water, you must only use noncarbonated mineral water.
1.Touch the ” touch button.
The control panel is pushed forwards automatically.
19
en Steam
2.Pull the control panel forwards with both hands and then push it upwards until it locks into place (Fig. !).
3.Lift the water tank and remove it from the water tank recess (Fig. ").
1 |
2I |
4.Press down on the cover along the seal to prevent water from leaking out of the water tank.
5.Take out the cover ‚ (Fig. #).
Note: Whether or not there is a cover ‚ depends on the appliance type.
6.Fill the water tank with cold water up to the "max." mark (Fig. $).
7.Put the cover ‚ back into the opening on the water tank.
8.Insert the filled water tank (Fig. %). Ensure that the water tank locks into place behind both holders ƒ (Fig. &).
I |
|
E |
E |
9.Slowly slide the control panel downwards and then push it towards the rear until it is closed completely. The water tank has been filled. You can start using operating modes with steam.
Refilling the water tank
Notes
■Steam-assisted operations continue without adding steam.
■If the water tank runs dry during operation with the Steaming, Dough proving, Defrost or Reheat settings, operation is interrupted. Fill the water tank.
1.Open the control panel.
2.Remove and refill the water tank.
3.Insert the filled water tank and close the control panel.
After every steam operation
:Warning – Risk of scalding!
When you open the appliance door, hot steam can escape. Steam may not be visible, depending on its temperature. When opening, do not stand too close to the appliance. Open the appliance door carefully. Keep children away.
:Warning – Risk of burns!
The appliance becomes hot during operation. Allow the appliance to cool down before cleaning.
Caution!
Enamel damage: Do not start any operations when there is water on the cooking compartment floor. Before operation, wipe away the water from the cooking compartment floor.
The remaining water is pumped back into the water tank after every operation with steam. Then empty and dry the water tank. Moisture remains in the cooking compartment. To dry the cooking compartment, you can either use the "Drying ª" operating mode or dry the cooking compartment by hand.
Notes
■Once the appliance has been switched off, the ” touch button remains lit for a little longer to remind you to empty the water tank.
■Remove limescale marks with a cloth soaked in vinegar, then wipe with clean water and dry with a soft cloth.
Emptying the water tank
Caution!
■Do not dry the water tank in the hot cooking compartment. This will damage the water tank.
■Do not clean the water tank in the dishwasher. This will damage the water tank.
1.Open the control panel.
2.Remove water tank.
3.Carefully remove the lid of the water tank.
4.Empty the water tank, clean it with detergent and then rinse it thoroughly with clean water.
5.Dry all parts with a soft cloth.
6.Rub the seal on the lid until dry.
7.Leave to dry with the lid open.
8.Place the lid on the water tank and push it down.
9.Insert the water tank and close the control panel.
Starting drying
To dry the cooking compartment, it is heated up so that the moisture in the cooking compartment evaporates. You will then need to open the appliance door to allow the steam to escape from the cooking compartment.
20
Caution!
Enamel damage: Do not start any operations when there is water on the cooking compartment floor. Before operation, wipe away the water from the cooking compartment floor.
1.Allow the appliance to cool down.
2.Remove the worst of the food remnants from the cooking compartment immediately and use a sponge to wipe away moisture from the cooking compartment floor.
3.If necessary, touch the # touch button to switch the appliance on.
4.Touch the 0 field to display the operating modes.
5.On the touch display, swipe to the left or right to select "Dry ª".
6.Touch the line at the bottom.
The duration will be displayed. It cannot be changed.
7.Touch the line at the bottom.
8.Touch the # field.
This starts the drying function; it will end automatically after 10 minutes.
9.Open the appliance door and leave it open for 1 to 2 minutes so that the moisture in the cooking compartment can escape.
Drying the cooking compartment by hand
1.Allow the appliance to cool down.
2.Remove any food remnants from the walls of the cooking compartment.
3.Dry the cooking compartment with a sponge.
4.Leave the appliance door open for 1 hour so that the cooking compartment dries completely.
Time-setting options |
en |
OTime-setting options
Your appliance has different time-setting options.
Time-setting option |
Use |
|
. |
Timer |
The timer functions like an egg timer. The |
|
|
appliance does not switch on and off auto- |
|
|
matically. |
+ |
Cooking time |
Once the set cooking time has elapsed, |
|
|
the appliance switches off automatically. |
* |
Ready at |
The appliance switches on automatically, |
|
|
and once the set cooking time has |
|
|
elapsed and the end time has passed, it |
|
|
switches off automatically. |
|
|
|
Note: If you have set a time-setting option, the time interval increases if you set a higher value. Example: You can set a cooking time of up to one hour in oneminute increments; for cooking times over one hour, you can set a cooking time in five-minute increments.
Showing and hiding the time-setting options
To show or hide the time-setting options, touch the 0 touch button.
Note: After a particular length of time, the time-setting options that are shown are automatically hidden. If you have already set a cooking time, it will be applied.
|
7LPHU |
|
|
|
|
PLQ _ V |
PLQ _ V |
|
|
|
|
Setting the timer
The timer can be set when the appliance is switched on or off.
1.Touch the 0 touch button.
The time-setting options are shown on the display.
2.Swipe to the left or right to select the duration.
Note: With the appliance switched on, first touch ". Timer" and then swipe to the left or right to select the duration.
3.Touch the 0 touch button.
The . symbol appears on the display.
Note: As soon as the set time has elapsed, a signal sounds. Touch the 0 touch button to end the audible signal.
21
en Childproof lock
Setting the cooking time
Once the set cooking time has elapsed, the appliance switches off automatically. The function can only be used in combination with a type of heating.
1.Touch the # touch button.
2.Set the type of heating and temperature.
3.Touch the 0 touch button.
The time-setting options are shown on the display.
4.Swipe to the left or right to select the cooking time.
5.Touch the # touch button to start the set cooking time.
As soon as the cooking time has elapsed, an audible signal sounds and the appliance ends the operation automatically. Touch the 0 touch button to end the audible signal.
Start delay – "Ready at"
The appliance switches on automatically and switches off at the preset end time.To do this, set the cooking time and determine the end time for the operation.
The start delay can only be used in combination with a type of heating.
Notes
■Ensure that food is not left in the cooking compartment for too long as it may spoil.
■The option to delay the start of operation is not available for every type of heating.
1.Place the food onto the appropriate accessory in the cooking compartment and close the appliance door.
2.Touch the # touch button.
3.Set the type of heating and temperature.
4.Touch the 0 touch button.
The time-setting options are shown in the display.
5.Swipe to the left or right to select the cooking time.
6.Touch "* Ready at".
7.Swipe to the left to select the end time.
8.Touch the # touch button.
The appliance waits until the appropriate time to start the operation.
As soon as the end time has been reached, an audible signal sounds and the appliance ends the operation automatically. Touch the 0 touch button to end the audible signal.
Checking, changing or deleting settings
1.Touch the 0 field.
The time-setting options are shown on the display.
2.Touch the time-setting option.
3.If required, swipe to the left or right in the touch display to change the settings. To delete a timesetting option, set "- - : - -".
The setting is applied automatically.
AChildproof lock
Your appliance is equipped with a childproof lock so that children cannot switch it on accidentally or change any settings.
Your appliance has two different locks.
Lock |
Activate/deactivate |
Automatic childproof lock |
Via the MyProfile menu ~ "Basic |
|
settings" on page 23 |
One-time childproof lock |
Via the 0 touch button |
|
|
Note: As soon as you activate the childproof lock, the control panel is locked. The 0 and # touch buttons are not included.You can deactivate the childproof lock at any time.
Automatic childproof lock
The control panel is locked so that the appliance cannot be switched on. To switch it on, the automatic childproof lock must be interrupted. After the appliance operation, the control panel is locked automatically.
Activation
1.Touch the ± touch button.
2.Touch the 0 touch button.
3.Swipe to the left or right to select "MyProfile".
4.Touch the bottom line.
5.Swipe to the left or right to select the "Automatic childproof lock".
6.Touch the bottom line.
7.Swipe to the left or right to select "Activated".
8.Touch the 0 touch button.
9.Touch "Save".
The settings are saved.The automatic childproof lock is active. After the appliance is switched off, the 1 symbol appears in the display.
Cancelling
1.Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
2.Touch the ± touch button.
3.Switch on the required appliance operation.
Deactivation
1.Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
2.Touch the ± touch button.
3.Touch the 0 touch button.
4.Swipe to the left or right to select "MyProfile".
5.Touch the bottom line.
6.Touch the top line.
7.Swipe to the left or right to select the "Automatic childproof lock".
8.Touch the bottom line.
9.Swipe to the left or right to select "Deactivated".
10.Touch the 0 touch button.
11.Touch "Save".
The "Automatic childproof lock" is deactivated.
12.Touch the ± touch button.
22
One-time childproof lock
The control panel is locked so that the appliance cannot be switched on. To switch it on, the one-time childproof lock must be deactivated. After the appliance is switched off, the control panel is no longer locked.
Activating and deactivating
1.Press and hold the 0 touch button until "Childproof lock activated" appears on the display.
The childproof lock is activated.
2.Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
The childproof lock is deactivated.
Basic settings |
en |
QBasic settings
There are various settings available to you in order to help use your appliance effectively and simply. If necessary, you can change these settings in MyProfile 4.
Changing MyProfile
1.Touch the # touch button.
2.Touch the 0 touch button.
3.Swipe to the left or right to select "MyProfile 4".
4.Touch the bottom line.
5.Swipe to the left or right to select the required setting.
6.Touch the bottom line.
7.Swipe to the left or right to select the required setting.
8.Touch the 0 touch button.
9.Touch "Save".
List of basic settings
Setting |
Selection |
Language |
Select language |
Time of day |
Sets the current time |
Date |
Sets the current date |
Water hardness |
0 (softened) |
|
1 (soft) |
|
2 (medium) |
|
3 (hard) |
|
4 (very hard) |
Favourites |
Set the heating types that should be |
|
shown in the heating types menu |
Audible signal |
Short duration |
|
Medium duration |
|
Long duration |
Volume |
Can be adjusted to one of five different |
|
levels |
Button tone |
Switched off (Exception: The button tone |
|
for the #touch button remains switched |
|
on) |
|
Switched on |
Display brightness |
Adjustable across 5 levels |
Clock display |
Off |
|
Digital |
|
Analogue |
Lighting |
On during operation |
|
Off during operation |
Childproof lock* |
Only key lock |
|
Door lock and key lock |
Automatic childproof lock |
Deactivated |
|
Activated |
|
|
23
