Pilot’s Guide for Spider II 15, 30 & HD75
40-00-0053 |
Electrophonic Limited Edition available @ www.line6.com |
Rev D |
All product names referred to in this manual are trademarks of their respective owners, which are in no way associated or affiliated with Line 6. These trademarks of other manufacturers are used solely to identify the products of those manufacturers whose tones and sounds were studied during Line 6’s sound model development.
Line 6, Spider II, FBV, FBV Shortboard, FBV4, FBV2, Floor Board, FB4 and Vetta are trademarks of Line 6, Inc. All other product names, trademarks, and artists’ names are the property of their respective owners, which are in no way associated or affiliated with Line 6. Product names, images, song names and artists’ names are used solely to identify the products whose tones and sounds were studied during Line 6’s sound model development for this product. The use of these products, trademarks, images, and artists’ names does not imply any cooperation or endorsement.
CAUTION: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION: To reduce the risk of fire or electric shock, do not remove screws. No user-serviceable parts inside. Refer servicing to qualified service personnel.
The exclamation point within a triangle means, “Caution!” Please read the information next to all caution signs.
The lightning symbol within a triangle means, “Electrical caution!” It indicates the presence of information about operating voltage and potential risks of electrical shock.
This symbol within a triangle means, “Caution! Hot surface!” It is shown in areas that may become too hot to touch when the device is in operation.
Spider II Pilot’s Guide © 2005, Line 6, Inc.
You should read these Important Safety Instructions.
Keep these instructions in a safe place.
Before using your Spider II, carefully read the applicable items of these operating instructions and the safety suggestions.
1.Obey all warnings on the amp and in the Spider II Manual.
2.Connect only to AC power outlets rated 100-120V or 200-240V 47-63Hz (depending on voltage range of the unit; refer to back panel).
3.Do not perform service operations beyond those described in the Spider II Manual. Service is required when the apparatus has been damaged in any way, such as:
•power-supply cord or plug is damaged
•liquid has been spilled or objects have fallen into the apparatus
•the unit has been exposed to rain or moisture
•the unit does not operate normally or changes in performance in a significant way
•the unit is dropped or the enclosure is damaged.
4.The bottom of the metal chassis can get hot during operation. Do not touch during operation or shortly after.
5.Do not place near heat sources, such as radiators, heat registers, or appliances which produce heat. Keep the rear of the unit at least three inches from walls or other items that might block heat radiation.
6.Do not block any of the ventilation openings or use in an enclosed space.
7.Guard against objects or liquids entering the enclosure. Do not use or place unit near water.
8.Do not step on power cords. Do not place items on top of power cords so that they are pinched or leaned on. Pay particular attention to the cord at the plug end and the point where it connects to the amp.
9.Unplug the amp when not in use for extended periods of time. Unplug the amp during lightning storms.
10.Clean only with a damp cloth.
11.Do not defeat the safety purpose of the grounding type plug. A grounding type plug has two blades and a third grounding prong. The third prong is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
12.Only use attachments/accessories specified by the manufacturer.
13.Prolonged listening at high volume levels may cause irreparable hearing loss and/or damage. Always be sure to practice “safe listening.”
1 |
Plug In Here |
2 |
Channel Memories / Amp Models |
|
||
|
The four channels each use a different Amp Model, and all come |
|||||
|
|
|
pre-loaded with a factory preset dialed in to nail a great tone. Press |
|||
|
|
|
one of these buttons to hear the presets. To replace any preset with |
|||
|
|
|
your own “snapshot” of all tone and effect knob positions (except |
|||
|
|
|
Master Volume), press and hold one of these four buttons for two |
|||
|
|
|
seconds. The light flashes when the save is complete. |
|||
|
|
CHANNELS: CLEAN |
CRUNCH |
METAL |
INSANE |
|
|
|
GUITAR |
|
|
|
|
DRIVE |
BASS |
MID |
TREBLE CHAN VOL |
Tone Controls
3 Drive is like the volume or gain knob on other amps; controls how much “dirt” you get in your sound. Bass, Mid, and Treble controls are customized for each Channel to give you optimal tonal control.
Channel Volume
4 This control helps you balance the volumes of the amp-and-effect setups that you store in your Spider II’s channels. See (2) above for the lowdown on channels.
