EBC54524
EN |
Automatic coffee maker |
User manual |
2 www.electrolux.com
CONTENTS
1. |
INTRODUCTION............................................................................................................. |
3 |
2. |
SAFETY INSTRUCTIONS.............................................................................................. |
3 |
3. |
PRODUCT DESCRIPTION............................................................................................. |
5 |
4. |
PRELIMINARY CHECKS................................................................................................ |
6 |
5. |
USING THE APPLIANCE FOR THE FIRST TIME.......................................................... |
7 |
6. |
TURNING ON AND HEATING UP.................................................................................. |
8 |
7. |
MAKING COFFEE USING COFFEE BEANS ................................................................ |
8 |
8. |
CHANGING THE QUANTITY OF COFFEE IN THE CUP ............................................. |
9 |
9. |
ADJUSTING THE COFFEE MILL ................................................................................ |
10 |
10. |
MAKING ESPRESSO COFFEE WITH PRE-GROUND COFFEE (INSTEAD OF BEANS) .10 |
|
11. |
DELIVERING HOT WATER........................................................................................... |
11 |
12. |
CHANGING THE QUANTITY OF HOT WATER ........................................................... |
11 |
13. |
MAKING CAPPUCCINO................................................................................................ |
11 |
14. |
CHANGING THE QUANTITY OF MILK AND COFFEE FOR CAPPUCCINO.............. |
12 |
15. |
MAKING A NUMBER OF CUPS OF COFFEE WITH THE JUG FUNCTION ............... |
13 |
16. |
CHANGING JUG FUNCTION PARAMETERS ............................................................ |
14 |
17. |
CLEANING ................................................................................................................... |
14 |
18. |
CHANGING AND SETTING MENU PARAMETERS .................................................... |
17 |
19. |
TURNING THE APPLIANCE OFF ............................................................................... |
21 |
20. |
TECHNICAL SPECIFICATION...................................................................................... |
21 |
21. |
DISPLAYED MESSAGES ............................................................................................ |
22 |
22. |
TROUBLESHOOTING.................................................................................................. |
23 |
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information: www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance: www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information Subject to change without notice.
ENGLISH 3
1. INTRODUCTION
1.1 Symbols used in these instructions
Important warnings are identified by these symbols.
It is vital to respect these warnings. Failure to observe the instructions could result in electric shock, serious injury, burns, fire or damage to the appliance.
DANGER!
Failure to observe the warning could result in possibly life threatening injury from electric shock.
IMPORTANT!
Failure to observe the warning could result in injury or damage to the appliance.
DANGER OF BURNS!
Failure to observe the warning could result in scalds or burns.
2.
SAFETY INSTRUCTIONS
2.1Safety information
This symbol identifies important advice or information for the user.
1.2 Letters in brackets
The letters in brackets refer to the legend in the Description of the Appliance on page 3.
1.3 Troubleshooting and repairs
In the event of problems, follow the information given in the sections “Displayed messages” and “Troubleshooting”.
If this does not resolve the problem, you should consult Customer Services.
For repairs, contact Customer Services only.
The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Never immerse the appliance in water.
This is an household appliance only. It is not intended to be used in: staff kitchen areas in shops, offices and other working environments; farm houses; by clients in hotels, motels and other residential type environments; bed and breakfast type environments.
4 www.electrolux.com
If the plug or power cable is damaged, it must be replaced by customer services only to avoid all risk. For european markets only:
This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazard involved. Clean-
ing and user maintenance shall not be made by children unless they are older than 8 and supervised. Keep the appliance and its cord out of the reach of children aged less than 8 years.
Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
When not in use and before cleaning, always unplug the appliance.
Surfaces marked with this symbol become hot during use (the symbol is present in certain models only).
2.2 Safety instructions
DANGER!
This is an electrical appliance, it is therefore important to respect the following safety warnings:
•Never touch the appliance with damp hands.
•Never touch the plug with damp hands.
•Make sure the socket used is freely accessible at all times, enabling the appliance to be unplugged when necessary.
•Unplug directly from the plug only.
•Never pull the power cable as you could damage it.
•To disconnect the appliance completely, place the main switch (A23) on the
side of the appliance in the 0 position.
•If the appliance is faulty, do not attempt to repair.
•Turn it off using the main switch (A23), unplug from the mains socket and contact Customer Services.
IMPORTANT!
Keep all packaging (plastic bags, polystyrene foam) away from children.
DANGER OF BURNS!
This appliance produces hot water and steam may form while it is in operation.
Avoid contact with splashes of water or hot steam. Use knobs and handles.
IMPORTANT!
Do not grasp the coffee maker when it is out of the cabinet.
Do not rest recipients containing liquids or inflammable or corrosive materials on top of the appliance. Place the accessories required to make the coffee (the measure for example) in the special holder. Do not rest large objects which could obstruct movement or unstable objects on the appliance.
IMPORTANT!
Do not use the appliance when extracted. Make sure the appliance is inactive before extracting it.
The only exception is adjusting the coffee mill which must be done with the machine out (see the section “Adjusting the coffee mill”).
Use original or manufacturer recommended accessories and spare parts only.
2.3 Designated use
This appliance is designed and made to prepare coffee and heat drinks.
All other use is considered improper.
3. PRODUCT DESCRIPTION
3.1 Description of the appliance
(page 3 - A)
A1. |
Cup tray |
A2. |
Service door |
A3. |
Coffee guide |
A4. |
Waste coffee container |
A5. |
Brewing unit |
A6. |
Cup tray lights |
A7. |
ON/stand-by button |
A8. |
Control panel |
A9. |
Tray |
A10. |
Hot water and steam nozzle |
A11. |
IEC connector |
A12. |
Water tank |
A13. |
Coffee spout (adjustable height) |
A14. |
Drip tray |
ENGLISH 5
This appliance is not suitable for commercial use.
The manufacturer is not liable for damage deriving from improper use of the appliance.
This appliance can be installed over a built-in oven if the latter is fitted with a cooling fan at the rear (maximum microwave power: 3 kW).
2.4 Instructions
Read these instructions carefully before using the appliance.
•Keep these instructions
•Failure to respect these instructions may result in burns or damage to the appliance.
•The manufacturer is not liable for damage deriving from failure to respect these instructions.
The appliance has a cooling fan. This comes on whenever coffee, steam or hot water is delivered. After several minutes, the fan goes off automatically.
A15. Bean container lid
A16. Bean container
A17. Grinding adjustment knob
A18. Pre-ground coffee funnel door
A19. Measure
A20. Compartment for measure
A21. Pre-ground coffee funnel
A22. Power cable
A23. Main switch
6www.electrolux.com
3.2Description of the control panel
(page 3 - B)
A light touch is enough to activate the icon.
B1. Display: guides the user in using the appliance.
B2.
icon to activate or deactivate menu parameter setting mode
B3.
icon to turn lights A6 on and off B4.
icon to select the coffee taste
B5.
icon to select the type of coffee (espresso, small cup, medium cup, large cup, mug)
B6.
icon to exit the selected mode
B7-B8.
icons to scroll forwards or backwards through the menu and display the various modes
B9. OK icon to confirm the selected function
B10.
icon to deliver a cup of coffee
B11.
icon to deliver two cups of coffee
B12.
icon to deliver cappuccino
B13.
icon to deliver hot water
B14.
“jug” icon to make a certain number of cups of coffee directly in the jug in one shot
3.3 Description of milk container and accessories
(page 3 - C)
C1. Frothed milk regulator
C2. Milk container handle
C3. CLEAN button
C4. Milk intake tube
C5. Frothed milk spout
C6. Milk frother
C7. Hot water spout
4. PRELIMINARY CHECKS
4.1 Controls after transport
After removing the packaging, make sure the product is complete and undamaged and that all accessories are present.Do not use the appliance if it is visibly damaged. Contact Customer Services.
4.2 Installing the appliance
IMPORTANT!
•Installation must be performed by a qualified professional in compliance with legislation in force in the country of installation (see Built-in installation).
•The packing elements (plastic bags, polystyrene foam, etc.) should be kept out of reach of children.
•Do not install the appliance in rooms where the temperature may drop to 0°C or lower.
•Customise the water hardness as soon as possible following the instructions in the “Setting water hardness” section.
4.3 Connecting the appliance
DANGER!
Check that the mains power supply voltage corresponds to the value indicated on the rating plate on the bottom of the appliance. Connect the appliance to an efficiently earthed and correctly installed socket with a minimum current rating of 10A only.
If the power socket does not match the plug on the appliance, have the socket replaced with a suitable type by a qualified profes-
ENGLISH 7
sional.
To comply with safety directives, an omnipolar switch with a minimum contact distance of 3 mm must be installed.
Do not use multiple sockets or extensions.
IMPORTANT!
Safety cutout devices must be included in the mains power supply in compliance with the installation regulations in the country concerned.
5. USING THE APPLIANCE FOR THE FIRST TIME
Coffee has been used to factory test the appliance and it is therefore completely normal for there to be traces of coffee in the mill.
Customise water hardness as soon as possible following the instructions in the “17.7 Setting water hardness” section.
1.Connect the appliance to the mains supply. Press the ON/stand-by button (A7) (fig. 7).
Set the required language.
2.To set the language, use the
icons (B7 and B8) to choose the required language (fig. 2). When the message “PRESS OK TO CHOOSE ENGLISH” is displayed, press the OK icon (B9) (fig. 3) for 3 seconds until “ENGLISH INSTALLED” is displayed. If you set the wrong language, follow the instructions in the “Setting the language” section. If your language is not available, select one from those displayed. The instructions refer to the English version. Then follow the instructions displayed:
3.After 5 seconds, the appliance displays “FILL TANK”. Extract the water tank (fig. 4), rinse and fill with fresh water.
Replace and push as far as it will go.
4.Place a cup under the hot water spout (fig. 5). (If the hot water spout is not inserted, the appliance displays
“INSERT WATER SPOUT”. Attach it as shown in figure 6.
The appliance displays: “HOT WATER PRESS OK”.
Press the OK icon (B9) (fig. 6) and after a few seconds a little water comes out of the spout.
5.The machine now displays “TURNING OFF... PLEASE WAIT” and goes off.
6.Extract the appliance by pulling it out using the handles (fig. 9). Open the lid and fill the container with coffee beans, then close the lid and push the appliance in.
The coffee maker is now ready for normal use.
IMPORTANT!
Never introduce pre-ground coffee, freeze dried coffee, caramelised beans or anything else which could damage the appliance.
When using the appliance for the first time, you need to make 4-5 cups of coffee and 4-5 cappuccinos before the appliance gives satisfactory results.
Each time you turn the coffee maker on by the ON/OFF main switch (A23), it performs a SELFDIAGNOSIS cycle and then goes off. To turn it on again, press the ON/stand-by button (A7) (fig. 7).
8 www.electrolux.com
6. TURNING ON AND HEATING UP
Each time the appliance is turned on, it performs an automatic preheat and rinse cycle which cannot be interrupted.
The appliance is ready for use only after completion of this cycle.
DANGER OF BURNS!
During rinsing, a little hot water flows from the coffee spouts.
To turn the appliance on, press the ON/ stand-by button (A7) (fig. 7). The message “HEATING UP... PLEASE WAIT” is displayed.
When heating is complete, the message changes to “RINSING”;
The appliance is at temperature when the message “MEDIUM CUP NORMAL TASTE” is displayed.
If no icon is pressed within about 2 minutes, the time (if set, see the “Setting the clock” section) is displayed.
If the time has not been set, the appliance displays the last functions set. When any icon is pressed, “MEDIUM CUP NORMAL TASTE” is displayed again. The appliance is ready to make coffee again.
7. MAKING COFFEE USING COFFEE BEANS
1.The appliance is preset to make coffee with a normal taste. You can also choose coffee with an extra-mild, mild, strong or extra-strong taste. There is also a pre-ground coffee option. To choose the required taste, press the
icon (B4) (fig. 10) a number of times. The required coffee taste is displayed.
2.Place 1 cup under the spouts to make 1 coffee or 2 cups for 2 coffees. Lower the spouts as near as possible to the cup for a creamier coffee (fig. 10).
3.Press the
icon (B5) (fig. 11) to select the type of coffee: espresso, small cup, medium cup, large cup, mug. Now press the
icon (B10) if you want to make a coffee and the
icon (B11) (fig. 13) if you want to make 2 coffees.
The appliance now grinds the beans and starts delivering the coffee into the cup. Once the set amount of coffee has been delivered, the machine stops delivery automatically and expels the exhausted waste coffee into the waste coffee container.
4.After a few seconds, the appliance is ready for use again.
5.To turn the appliance off, press the ON/stand-by button (A7) (fig. 7). (Before going off, the appliance per-
forms an automatic rinse cycle. Take care to avoid scalds).
NOTE 1: If the coffee is delivered a drop at a time or not at all, see the “Adjusting the coffee mill” section.
NOTE 2: If the coffee is delivered too fast and the cream is not satisfactory, see the “Adjusting the coffee mill” section.
NOTE 3: Tips for a hotter coffee:
•Proceed as described in the section
“Changing and setting menu parameters”, “Rinse” function.
•Unless preheated, do not use excessively thick cups as they will absorb too much heat.
•Preheat the cups by rinsing them with
hot water.
NOTE 4: Coffee delivery can be interrupted at any moment by re-pressing the previously selected icon which remains lit during the operation.
NOTE 5: As soon as delivery is finished, to increase the quantity of coffee in the cup, just keep pressing the previously selected icon within 3 seconds after delivery has finished.
NOTE 6: When the appliance displays “FILL TANK”, fill the tank with water or the appliance will not deliver coffee.
(It is normal for there to be a little water left in the tank).
NOTE 7: Never extract the water tank while the machine is delivering coffee.
If it is removed, it will not be possible to make the coffee and the appliance will display “GROUND TOO FINE ADJUST MILL AND PRESS OK” and then “FILL TANK”.
After about 14 single (or 7 double) coffees, the appliance displays “EMPTY WASTE COFFEE CONTAINER”.
The appliance provides a frequent empty waste coffee container message.
Even if not full, the empty waste coffee container message is displayed 72 hours after the first coffee has been delivered. For the 72 hours to be calculated correctly, the machine must never be turned off with the main switch in the 0 position. To clean, open the service door on the front of the appliance by pulling the spout, extract the drip tray and clean. When cleaning, always extract the drip tray completely.
ENGLISH 9
IMPORTANT!
When extracting the drip tray, the waste coffee container MUST always be emptied. If this is
not done, the machine may be clogged.
NOTE 8: Never extract the water tank while the machine is delivering coffee. If it is removed, it will not be possible to make the coffee and the appliance will display “GROUND TOO FINE ADJUST MILL AND PRESS OK” and then “FILL TANK”.
Check the level of water in the tank and replace in the appliance.
To turn the appliance back on, press the OK icon (B9). “HOT WATER PRESS OK” is displayed.
Press the OK icon (B9) within a few seconds and deliver water from the cappuccino maker for about 30 seconds. When delivery stops, the basic modes are displayed again.
The coffee maker may request the operation to be repeated a number of times until the air is completely eliminated from the hydraulic circuit.
If this operation is not performed correctly or if the machine is turned off, the basic modes may be displayed, although the problem is in fact still present.
8. CHANGING THE QUANTITY OF COFFEE IN THE CUP
The appliance is set by default to automatically make the following types of coffee:
•espresso
•small cup
•medium cup
•large cup
•mug
To change the quantity, proceed as follows:
•Press the
icon (B2) to enter the menu. Press the
icons (B7) and (B8) (fig. 2) until “PROGRAM COFFEE” is displayed.
•Press the OK icon (B9).
•Select the type of coffee you want to change by pressing the
icons (B7) and (B8).
•Press the OK icon (B9) to confirm the type of coffee you want to make.
•Use the
icons (B7) and (B8) to
Loading...
