Semiconductor
This version: Jun. 2000
MSM5117400D
4,194,304-Word × 4-Bit DYNAMIC RAM : FAST PAGE MODE TYPE
DESCRIPTION
The MSM5117400D is a 4,194,304-word × 4-bit dynamic RAM fabricated in Oki’s silicon-gate CMOS technology. The MSM5117400D achieves high integration, high-speed operation, and low-power consumption because Oki manufactures the device in a quadruple-layer polysilicon/double-layer metal CMOS process. The MSM5117400D is available in a 26/24-pin plastic SOJ, 26/24-pin plastic TSOP.
FEATURES
• 4,194,304-word × 4-bit configuration
•Single 5V power supply, ± 10% tolerance
• |
Input |
: TTL compatible, low input capacitance |
• |
Output |
: TTL compatible, 3-state |
• |
Refresh |
: 2048 cycles/32 ms |
•Fast page mode, read modify write capability
•CAS before RAS refresh, hidden refresh, RAS-only refresh capability
•Multi-bit test mode capability
•Package options:
26/24-pin 300mil plastic SOJ |
(SOJ26/24-P-300-1.27) |
(Product : MSM5117400D-xxSJ) |
26/24-pin 300mil plastic TSOP |
(TSOPII26/24-P-300-1.27-K) (Product : MSM5117400D-xxTS-K) |
|
|
|
xx : indicates speed rank. |
PRODUCT FAMILY
Family |
|
Access Time (Max.) |
|
Cycle Time |
Power Dissipation |
||||
|
|
|
|
|
|
|
|
|
|
tRAC |
|
tAA |
tCAC |
|
tOEA |
(Min.) |
Operating (Max.) |
Standby (Max.) |
|
|
|
|
|||||||
MSM5117400D-50 |
50ns |
|
25ns |
13ns |
|
13ns |
90ns |
550mW |
|
|
|
|
|
|
|
|
|
|
|
MSM5117400D-60 |
60ns |
|
30ns |
15ns |
|
15ns |
110ns |
495mW |
5.5mW |
|
|
|
|
|
|
|
|
|
|
MSM5117400D-70 |
70ns |
|
35ns |
20ns |
|
20ns |
130ns |
440mW |
|
|
|
|
|
|
|
|
|
|
|
1/14
MSM5117400D
PIN CONFIGRATION (TOP VIEW)
|
|
|
|
|
|
|
|
|
|
|
VCC |
|
|
|
|
|
|
|
VCC |
1 |
|
26 |
|
VSS |
|
1 |
|
26 |
|
VSS |
|||||
DQ1 2 |
|
|
|
|
|
|
DQ1 2 |
|
|
|
|
|
|||||
|
25 |
|
DQ4 |
|
25 |
|
DQ4 |
||||||||||
DQ2 3 |
|
|
|
|
|
|
DQ2 3 |
|
|
|
|
|
|||||
|
24 |
|
DQ3 |
|
24 |
|
DQ3 |
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
WE 4 |
|
23 |
|
CAS |
|
WE 4 |
|
23 |
CAS |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RAS 5 |
|
22 |
|
OE |
RAS 5 |
|
22 |
|
OE |
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NC 6 |
|
21 |
|
A9 |
|
NC 6 |
|
21 |
|
A9 |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
A10 |
8 |
|
19 |
|
A8 |
A10 |
8 |
|
19 |
|
A8 |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
A0 |
9 |
|
18 |
|
A7 |
|
A0 |
9 |
|
18 |
|
A7 |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
A1 |
10 |
|
17 |
|
A6 |
|
A1 |
10 |
|
17 |
|
A6 |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
A2 |
11 |
|
16 |
|
A5 |
|
A2 |
11 |
|
16 |
|
A5 |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
A3 |
12 |
|
15 |
|
A4 |
|
A3 |
12 |
|
15 |
|
A4 |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VCC 13 |
|
14 |
|
VSS |
|
VCC 13 |
|
14 |
|
VSS |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
26/24-Pin Plastic SOJ |
|
|
|
|
|
|
26/24-Pin Plastic TSOP |
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
(K Type) |
|
|
Pin Name |
Function |
||||||
|
|
|
|
|
|
|
|
A0–A10 |
Address Input |
||||||
|
|
|
|
|
|
|
|
|
|
|
Row Address Strobe |
||||
|
RAS |
|
|||||
|
|
|
|
|
|
|
|
|
|
Column Address Strobe |
|||||
|
CAS |
|
|||||
|
|
|
|
|
|
|
|
DQ1–DQ4 |
Data Input/Data Output |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Output Enable |
|
|
|
OE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Write Enable |
|||
|
WE |
|
|
|
|||
|
|
|
|
|
|
|
|
|
VCC |
Power Supply (5V) |
|||||
|
VSS |
Ground (0V) |
|||||
|
|
NC |
No Connection |
||||
|
|
|
|
|
|
|
|
2/14
MSM5117400D
BLOCK DIAGRAM
RAS |
Timing |
|
|
|
|
|
|
|
|
|
|
Generator |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
Timing |
|
|
|
|
CAS |
|
|
|
|
|
|
Generator |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Write |
|
WE |
|
|
|
Column |
|
|
|
|
|
Clock |
|
|
OE |
|
11 |
|
|
|
|
|
Generator |
|
|
|
||
Address |
|
|
11 |
Column Decoders |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
||||
|
Buffers |
|
|
|
|
|
|
4 |
Output |
4 |
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
Buffers |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Internal |
|
Refresh |
|
Sense Amplifiers |
4 |
I/O |
4 |
|
4 |
DQ1 - DQ4 |
A0 – A10 |
|
|
Selector |
|
|||||||
Address |
|
Control Clock |
|
|
|
|
|
|
|||
|
|
|
|
|
Input |
|
|
||||
|
Counter |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
4 |
4 |
|
||
|
|
|
|
|
|
|
|
Buffers |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
11 |
Row |
11 |
Row |
|
|
|
|
|
|
|
|
Address |
Word |
Memory |
|
|
|
|
|
|
|||
|
Buffers |
|
Deco- |
|
|
|
|
|
|
||
|
|
ders |
Drivers |
Cells |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VCC
On Chip
VBB Generator
VSS
3/14
|
|
|
|
MSM5117400D |
|
|
|
|
|
||
ELECTRICAL CHARACTERISTICS |
|
||||
|
|
|
|||
Absolute Maximum Ratings |
|
|
|
|
|
|
|
|
|
|
|
|
Parameter |
Symbol |
Rating |
|
Unit |
|
|
|
|
|
|
|
Voltage on Any Pin Relative to VSS |
VIN, VOUT |
− 0.5 to VCC + 0.5 |
|
V |
|
Voltage VCC supply Relative to VSS |
VCC |
0.5 to 7.0 |
|
V |
|
Short Circuit Output Current |
IOS |
50 |
|
mA |
|
Power Dissipation |
PD* |
1 |
|
W |
|
Operating Temperature |
Topr |
0 to 70 |
|
°C |
|
Storage Temperature |
Tstg |
− 55 to 150 |
|
°C |
|
|
*: Ta = 25°C |
|
|
|
Recommended Operating Conditions
(Ta = 0°C to 70°C)
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Unit |
|
|
|
|
|
|
|
|
Power Supply Voltage |
VCC |
4.5 |
5.0 |
5.5 |
V |
|
VSS |
0 |
0 |
0 |
V |
||
|
||||||
Input High Voltage |
VIH |
2.4 |
|
VCC + 0.5*1 |
V |
|
Input Low Voltage |
VIL |
− 0.5*2 |
|
0.8 |
V |
Notes: *1. The input voltage is VCC + 2.0V when the pulse width is less than 20ns (the pulse width is with respect to the point at which VCC is applied).
*2. The input voltage is VSS − 2.0V when the pulse width is less than 20ns (the pulse width respect to the point at which VSS is applied).
Capacitance
(VCC = 5V ± 10%, Ta = 25°C, f=1MHz)
|
|
|
|
|
Parameter |
Symbol |
Typ. |
Max. |
Unit |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input Capacitance (A0 – A10) |
CIN1 |
|
5 |
pF |
|||||||||
Input Capacitance |
CIN2 |
|
7 |
pF |
|||||||||
|
|
|
|
|
|
|
|
|
|||||
(RAS, CAS, WE, OE) |
|||||||||||||
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Output Capacitance (DQ1 – DQ4) |
CI/O |
|
7 |
pF |
4/14
MSM5117400D
DC Characteristics
(VCC = 5V ± 10%, Ta = 0°C to 70°C)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MSM5117400 |
MSM5117400 |
MSM5117400 |
|
|
|||
|
Parameter |
Symbol |
|
|
|
Condition |
D-50 |
D-60 |
D-70 |
Unit |
Note |
||||||||||||
|
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Min. |
Max |
Min. |
Max |
Min. |
Max |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Output High Voltage |
VOH |
|
IOH = − 5.0mA |
2.4 |
VCC |
2.4 |
VCC |
2.4 |
VCC |
V |
|
||||||||||||
Output Low Voltage |
VOL |
|
IOL = 4.2mA |
0 |
0.4 |
0 |
0.4 |
0 |
0.4 |
V |
|
||||||||||||
Input Leakage |
|
|
0V ≤ VI ≤ 6.5V ; |
|
|
|
|
|
|
|
|
||||||||||||
ILI |
|
All other pins not |
− 10 |
10 |
− 10 |
10 |
− 10 |
10 |
A |
|
|||||||||||||
Current |
|
|
|||||||||||||||||||||
|
|
|
|
|
|
|
under test = 0V |
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Output Leakage |
ILO |
|
DQ disable |
− 10 |
10 |
− 10 |
10 |
− 10 |
10 |
A |
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||
Current |
|
0V ≤ VO ≤ VCC |
|
||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
||||||||||||||
Average Power |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
RAS, CAS cycling, |
|
|
|
|
|
|
|
|
|||||||||||||
Supply Current |
ICC1 |
|
|
100 |
|
90 |
|
80 |
mA |
1,2 |
|||||||||||||
|
t |
= Min. |
|||||||||||||||||||||
(Operating) |
|
|
|
RC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
Power Supply |
|
|
|
RAS, |
|
CAS |
= VIH |
2 |
2 |
2 |
|
|
|||||||||||
Current |
ICC2 |
|
|
|
|
|
≥ |
|
|
|
|
|
|
mA |
1 |
||||||||
|
RAS, |
CAS |
|
1 |
|
1 |
|
1 |
|||||||||||||||
(Standby) |
|
|
VCC – 0.2V |
|
|
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
Average Power |
|
|
|
RAS |
cycling, |
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
Supply Current |
ICC3 |
|
CAS |
= VIH, |
|
100 |
|
90 |
|
80 |
mA |
1,2 |
|||||||||||
|
(RAS |
-only Refresh) |
|
|
tRC = Min. |
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
Power Supply |
|
|
|
RAS |
= VIH, |
|
|
|
|
|
|
|
|
||||||||||
Current |
ICC5 |
|
|
|
|
|
5 |
|
5 |
|
5 |
mA |
1 |
||||||||||
|
CAS |
= VIL, |
|||||||||||||||||||||
(Standby) |
|
|
DQ = enable |
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Average Power |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
Supply Current |
ICC6 |
|
|
RAS |
= cycling, |
|
100 |
|
90 |
|
80 |
mA |
1,2 |
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
(CAS before RAS |
|
CAS before RAS |
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
||||||||||||||
Refresh) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
Average Power |
|
|
|
RAS |
= VIL, |
|
|
|
|
|
|
|
|
||||||||||
Supply Current |
ICC7 |
|
|
|
|
|
|
|
|
80 |
|
70 |
|
60 |
mA |
1,3 |
|||||||
|
CAS |
cycling, |
|||||||||||||||||||||
(Fast Page Mode) |
|
|
tPC = Min. |
|
|
|
|
|
|
|
|
Notes: 1. ICC Max. is specified as ICC for output open condition.
2.The address can be changed once or less while RAS = VIL.
3.The address can be changed once or less while CAS = VIH.
5/14
