Operating instructions
Washer-dryer
WT 2780 WPM
To avoid the risk of accidents |
en - GB |
or damage to the machine |
|
it is essential to read |
|
these instructions before it is |
|
installed and used for the first time. |
M.-Nr. 09 442 060 |
Caring for the environment
Disposal of the packing material
The transport and protective packing has been selected from materials which are environmentally friendly for disposal and can normally be recycled.
Ensure that any plastic wrappings, bags etc. are disposed safely and kept out of the reach of babies and young children. Danger of suffocation!
Rather than just throwing these materials away, please ensure they are offered for recycling.
Disposal of your old machine
Electrical and electronic machines often contain materials which, if handled or disposed of incorrectly, could be potentially hazardous to human health and to the environment. They are, however, essential for the correct functioning of your machine. Please do not therefore dispose of it with your household waste.
Please dispose of it at your local community waste collection / recycling centre or contact your Dealer for advice. Ensure that it presents no danger to children while being stored for disposal.
It should be unplugged or disconnected from the mains electricity supply by a competent person.
2
Contents
Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Guide to the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Calibrating the load size sensor to zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Washing and drying environmentally and economically . . . . . . . . . . . . . . . . . 18
WASHING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Short instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Separate washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Extra options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Short . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Water plus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Stains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Further extras. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Extra quiet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Extra rinse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Pre-wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Soak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Rinse hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Adding or removing laundry after a programme has started . . . . . . . . . . . . . . . . 25 Final spin speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Rinse and interim spin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 To omit the final spin (Rinse hold) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 To omit the spin between rinses and the final spin . . . . . . . . . . . . . . . . . . . . . 26 Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Water softeners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Washing with several components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Fabric conditioner and liquid starch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Colour run and dye removers/dyes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
DRYING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Separate drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3
Contents
Extra options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Low temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Thermospin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Extra quiet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Adding or removing laundry after a programme has started . . . . . . . . . . . . . . . . 40 Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
WASHING AND DRYING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Washing and drying in a continuous sequence . . . . . . . . . . . . . . . . . . . . . . . . . . 47 After each washing or drying programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Rinse out fluff programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Changing the programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 To cancel a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Interrupting a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Changing a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Safety lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Delay start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Cleaning the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Cleaning the filter in the water inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Problem solving guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 The programme does not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 A fault message appears in the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Problems with the load size indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 General problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 An unsatisfactory wash result . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 An unsatisfactory drying result . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 The drum door cannot be opened by pressing the Door button. . . . . . . . . . . . . . 62 Opening the drum door in the event of a blocked drain outlet and/or
power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Future updates (PC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Installation and connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Front view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
4
Contents
Installation surface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Installing the washer-dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Removing the transit bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Levelling the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 Screwing out and adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Building under a continous worktop / in a kitchen run . . . . . . . . . . . . . . . . . . . 71 The Miele water protection system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 Connection to the water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73 Connection to the drainage system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Electrical connection U.K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 Notes for test institutes: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Settings menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78 Language J . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78 Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78 Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79 Temperature unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79 Brightness / Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79 Standby display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79 Keypad tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79 Lock code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80 Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80 Longer pre-wash Cottons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81 Gentle action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81 Suds cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81 Distribution controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81 Drying levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 Extended cool down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 Anti-crease. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Optional accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83 CareCollection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
5
Warning and Safety instructions
~ It is essential to read the operating instructions.
This washer-dryer conforms to current safety requirements. Inappropriate use can, however, lead to personal injury and damage to property.
To avoid the risk of accidents and damage to the washer-dryer, please read these instructions carefully before using it for the first time. They contain important information on its installation, safety, use and maintenance.
Keep these instructions in a safe place and ensure that new users are familiar with the content. Pass them on to any future owner.
Correct application
~This washer-dryer is not designed for commercial use. It is intended for use in domestic households and in similar working and residential environments.
~It must only be used as a domestic appliance to
–wash items which are specified by the manufacturer as being washable on the care label.
–dry items which have been washed in a water solution and which are marked on the manufacturer's care label as being suitable for tumble drying. If using dry cleaning kits, do so at your own risk, and follow the instructions provided on the packaging.
Any other usage is not supported by the manufacturer and could be dangerous. Miele cannot be held liable for damage resulting from incorrect or improper use or operation.
6
Warning and Safety instructions
~The washer-dryer is not intended for outdoor use.
~The washer-dryer can only be used by people with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they are supervised whilst using it, or have been shown how to use it in a safe way and understand the hazards involved.
Safety with children
~Children under 8 years of age must be kept away from the washer-dryer unless they are constantly supervised.
~Children 8 years and older may only use the washer-dryer without supervision if they have been shown how to do so in a safe way and understand the hazards involved.
~Children must not be allowed to clean or maintain the
washer-dryer unsupervised.
~ The washer-dryer is not a toy! To prevent the risk of injury, do not allow children to play on or near it or to play with the controls.
7
Warning and Safety instructions
Technical safety
~Before setting up the washer-dryer, check it for any externally visible damage.
Do not install or use a damaged machine.
~Before connecting the washer-dryer, ensure that the connection data on the data plate (voltage and connected load) match the mains electricity supply. If in any doubt, consult a qualified electrician.
~The electrical safety of this washer-dryer can only be guaranteed when correctly earthed. It is most important that this basic safety requirement is observed and regularly tested, and where there is any doubt the household wiring system should be inspected by a qualified electrician. The manufacturer cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).
~Do not connect the washer-dryer to the mains electricity supply by an extension lead. Extension leads do not guarantee the required safety of the machine (e.g. danger of overheating).
~Unauthorised repairs could result in unforeseen dangers for the user, for which the manufacturer cannot accept liability. Repairs should only be undertaken by a Miele approved service technician, otherwise any subsequent damage will not be covered by the guarantee.
8
Warning and Safety instructions
~The washer-dryer must be isolated from the electricity supply in the event of a fault and during installation, maintenance and repair work.
~The Miele "Water protection system" protects from water damage provided the following conditions have been met:
–the washer-dryer is correctly plumbed in and connected to the electricity supply.
–if a fault has been identified, the washer-dryer must be examined by a competent person before further use, and repaired if necessary.
~Faulty components must only be replaced by genuine Miele original spare parts. Only when these parts are fitted can the safety standards of the machine be guaranteed.
~If the electrical connection cable is faulty it must only be replaced by a Miele approved service technician to protect the user from danger.
~The washer-dryer must not be used in a non-stationary location (e.g. on a ship).
~Do not make any alterations to the washer-dryer, unless authorised to do so by Miele.
~In areas which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the washer-dryer and its surroundings in a clean condition at all times. Any damage which may be caused by cockroaches or other vermin will not be covered by the guarantee.
9
Warning and Safety instructions
Correct use
~Do not install your washer-dryer in rooms where temperatures below freezing may occur. Frozen hoses may burst or split. The reliability of the electronic control unit may be impaired at temperatures below freezing point.
~Before using the washer-dryer for the first time, check that the transit bars at the rear of the machine have been removed (see "Installation and connection - Removing the transit bars"). During spinning, a transit fitting which is still in place may result in damage to both the washer-dryer and adjacent furniture or appliances.
~Turn off the stopcock if the washer-dryer is to be left for any length of time (e.g. holiday), especially if there is no floor drain (gully) in the immediate vicinity.
~Flooding danger. If hooking the drain hose into a wash basin, check that the water can drain off quickly enough to prevent the sink from overflowing. Make sure that the drain hose is secure, so that the force of the water flowing out of the hose does not dislodge it.
~Take care to ensure that foreign objects (e.g. nails, pins, coins, paper clips) do not find their way into the washer-dryer with the laundry. These may damage components of the machine (e.g. suds container, drum), which in turn can result in damage to the laundry.
~If the correct amount of detergent is dispensed, the washer-dryer should not need to be descaled. If, however, you do wish to descale the machine only use proprietary non-corrosive descaling agents and strictly observe the instructions on the packaging. A special descaling agent is available to order from Miele. Follow the instructions for use on the packaging carefully.
10
Warning and Safety instructions
~ To prevent the risk of fire, the following must not be dried in this washer-dryer:
–items which have not been washed.
–items, such as workwear, which have not been thoroughly cleaned and which are still soiled with grease, oil or other deposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned there is a danger that these might self-ignite when heated, even after they have been removed from the washer-dryer at the end of the programme.
–items (e.g. mops and floor cloths) which have been treated with inflammable cleaning agents or which contain residues of acetone, alcohol, benzine, petrol, stain remover, turpentine, wax and wax remover or other chemicals.
–items which have been splashed with hair lacquer, hair spray, nail varnish remover or similar substances.
When washing such heavily soiled items, ensure that you use sufficient detergent and select a high temperature. If in doubt, wash the items several times.
~ To prevent the risk of fire, the following must not be tumble dried:
–items which have been cleaned using chemicals (e.g. professional dry-cleaning agents).
–fabrics which contain a large proportion of rubber, foam rubber or rubber-like materials. For example, products made from latex foam rubber, shower caps, waterproof textiles, rubberised articles and items of clothing and pillows with foam rubber filling.
–damaged items which contain padding or fillings (e.g. pillows, jackets). When damaged, the filling can get out with the risk of igniting in the washer-dryer.
11
Warning and Safety instructions
~In many programmes, the heating phase is followed by a cooling down phase to ensure that the items are not too hot to handle when you remove them (this also avoids the danger of the laundry self-igniting). The programme is not finished until the cooling down phase has been completed.
As soon as the programme has finished, remove all laundry from the drum.
~Warning: Do not switch the washer-dryer off before the drying programme has finished. If this is done, the laundry must be hung up or spread out to cool it down.
~Fabric conditioner and similar products must be used according to the instructions on the manufacturer's packaging.
~Only use dyes specified by the manufacturer as being suitable for use in a domestic washer-dryer. Always observe the manufacturer's instructions carefully.
~Colour run and dye removers contain sulphur compounds which can cause damage such as corrosion. Do not use these products in this washer-dryer.
~Make sure that any dispensing balls etc. are removed from laundry before the drying programme. These dispensers can melt during the drying programme and cause damage to the washer-dryer and the laundry. Do not use liquid dispenser balls or similar if you are planning to wash and then dry in one continuous sequence.
~Textiles which have been pre-treated in solvent based cleaning agents must be thoroughly rinsed in clean water before being washed in the washer-dryer.
12
Warning and Safety instructions
~Do not use solvent based cleaning agents, e.g. those containing benzine, in this washer-dryer, as this may result in damage to component parts and create toxic fumes. Such agents also pose a fire and explosion hazard.
~Caution, the metal cap is hot after drying. Open the door wide after the drying cycle. Do not touch the metal cap located on the inside of the door glass. It will still be hot and could cause a burn.
Accessories
~ Accessory parts may only be fitted when expressly approved by Miele. Using spare parts or accessories from other manufacturers will invalidate the guarantee, and Miele cannot accept liability.
Miele cannot be held liable for damage caused by non-compliance with these Warning and Safety instructions.
13
Guide to the machine
Control panel
Start/Stop button
For starting the programme selected and cancelling a programme once it has started.
Display with , OK and buttons
See the following page for more information.
button
For selecting delay start.
PC / Optical interface
This is used by Miele service technicians during servicing work for testing purposes.
Load % / Detergent % button
For displaying the load size or the recommended amount of detergent, and for calibrating the load size sensor to zero.
Extra option buttons
Programme selector
For selecting washing and drying programmes.
Washing/Drying button for selecting:
–Washing
–Drying
–Washing and Drying.
button
For switching the washer-dryer on and off.
To save energy, the machine will switch itself off automatically 15 minutes after the end of the programme/anti-crease phase or after being switched on if no other selection is made.
Door button
Opens the machine door.
14
Guide to the machine
Display
The display is operated using the , OK and buttons. The value or option currently selected will appear highlighted.
Press button
to decrease a value in the display or to scroll down to the next option.
Press button
to increase a value in the display or to scroll up to the next option.
Press the OK button
to confirm the value or option highlighted in the display.
With the programme selector at the
Further programmes / Settings position, you can change display settings (see "Settings menu") and select the additional programmes (see "Programme chart").
The display is also used for selecting the wash temperature, spin speed, soak duration, delay start, safety lock and to cancel a programme.
Use
This washer-dryer can be used:
–to wash separately
Maximum load (depending on programme) 5.5 kg;
–to dry separately
Maximum load (depending on programme) 3.0 kg;
or
–to wash and dry in a continuous sequence
Maximum load (depending on programme) 3.0 kg;
15
Before using for the first time
Before using the machine for the first time ensure that it is correctly installed and connected. Also check that the drain filter is securely tightened to prevent the risk of water leakage during use. See "Installation and connection".
This washer-dryer has undergone a complete functional test at the factory and there will be some residual water in the drum from this process.
The washer-dryer has a sensor which measures the amount of laundry in the drum. This determines the amount of detergent required. To allow the load size indicator to function correctly, you must first run a wash programme without any laundry and without detergent.
^Open the stopcock.
^Press the button.
If the machine is being switched on for the first time, the Miele Willkommen welcome screen will appear.
The welcome screen will not appear again once a programme lasting longer than 1 hour has been completed.
After a few seconds the display will change to show the screen for selecting your language.
Setting the language
Language
|
|
deutsch |
|
english |
|
^Use the and buttons to select the language you want and confirm your selection by pressing the OK button.
Setting the time of day
The display for setting the time will then appear.
Time
12:00
^Set the hour with the and buttons and confirm your setting by pressing the OK button. Then do the same to set the minutes.
After you have confirmed the minute setting, the display will change to show the reminder to remove the transport bars.
Reminder to remove transport bars
,To avoid the risk of damage, the transport bars must be removed before the washer-dryer is used for the first time. See "Installation and connection" for instructions on how to do this.
^After removing the transport bars (if this has not already been done by your fitter) press the OK button.
16
Before using for the first time
Running your first programme
Your washer-dryer is now ready for the first programme to be run.
^Turn the programme selector to
Cottons.
^Press the Start/Stop button.
^At the end of the programme switch the machine off.
After running the first programme, the load sensor has to be calibrated to zero (as you would with bathroom scales).
Calibrating the load size sensor to zero
^Switch the machine on.
^Open the drum door.
^Turn the programme selector to
Cottons.
^Press and hold the Load % / Detergent % button in until the following message appears in the display:
Zero setting OK
^ Switch the machine off.
The machine is now ready for use.
17
Washing and drying environmentally and economically
Energy and water consumption
–Water consumption and energy usage are determined by the size of the load.
To make the most out of your machine, load the maximum amount for the programme you are using.
–Use the Automatic plus and Express 20 programmes for small loads.
–When smaller amounts of laundry are washed using the Cottons programmes, the automatic load recognition system will reduce the amount of water, time and energy used. This may mean that the time left shown in the display is adjusted during the course of the wash programme.
–Using the Cottons 60°C programme instead of the Cottons 95°C programme will give energy savings of between 35% and 45%. This is sufficient for most levels of soiling. For stubborn or old soiling use the Soak extra option.
Detergent
–Do not exceed the amounts of detergent recommended by the manufacturer on the packaging.
–Reduce the amount of detergent for smaller loads. Use the Load % / Detergent % button.
Choosing the correct extra option (Pre-wash, Soak, Short)
Select:
–A wash programme together with the Short extra option for light to normal soiling where there are no obvious marks.
–A wash programme without any extra options for normal to heavy soiling.
–A wash programme together with the Soak extra option for very heavily soiled laundry.
–The Pre-wash extra option for laundry with large amounts of dirt (e.g. dust, sand).
When drying straight after washing
Select a high spin speed for the wash programme, as well as for the Thermospin to save time and energy.
18
WASHING
Short instructions
The headings numbered , , , . . .
show the operating sequence and can be used as brief instructions.
Separate washing
Sort the laundry
^ Empty all pockets.
,Foreign objects (e.g. nails, coins, paper clips, etc.) can cause damage to textiles and to components in the machine.
^Badly soiled areas, stains etc. should be cleaned as soon as possible, preferably whilst still fresh. Spillages should be carefully dabbed off using a soft, colourfast cloth. Do not rub!
Badly soiled areas can be pre-treated with liquid detergent, stain removers etc. first, following the manufacturer's instructions. You can also use the "Stains" extra option. With particularly stubborn stains ask your dry cleaner for advice.
,Do not use solvent-based cleaning agents in this machine.
^Sort the laundry by colour and by care label. Most garments have a textile care label in the collar or side seam.
Curtains: Remove lead weights first or place in a laundry bag.
–Underwiring and collar stiffeners: Any loose wiring in bras, shirt collar stiffeners, etc. should be removed or sewn in.
–Close any zips, fasten hooks and eyes etc before washing.
–Wash light and dark coloured items separately.
–Fasten duvet covers, pillow cases etc. to prevent small items from being rolled up inside them.
Do not wash items in this machine which are specified by the manufacturer as not washable on the care label.
19
WASHING
Switch the machine on
The interior drum lighting will come on.
The drum lighting will go out automatically after five minutes. Press the Door button to switch the drum lighting back on again.
Select a programme
^ Select the programme you want.
The programme selected will appear in the display.
Cottons
60°C |
|
1600 rpm |
|
|
h |
Duration: |
||
Further programmes:
Turn the programme selector to Further programmes/Settings to display a list of other programmes that the machine has to offer.
Further programmes
|
|
Settings |
|
Dark garments |
|
^Use the or button to highlight the programme you wish to select and
confirm your selection by pressing the OK button.
^Press the Washing/Drying button repeatedly until only the Washing indicator light is lit up.
The Drying indicator light must not be lit up as well as this would mean that the washing programme would be followed immediately by the relevant drying programme.
Cottons
60°C |
|
1600 rpm |
|
|
h |
Duration: |
||
^ Use the or button to alter the temperature. Press the OK button to confirm the temperature selected and move on to the spin speed option.
Cottons
40°C |
1600 rpm |
Duration: |
h |
^ Use the or button to alter the spin speed or to select No spin (No ).
20
WASHING
Select Extra option(s)
^Press the appropriate button to select
Short or Water plus. The relevant indicator light will come on.
^Then select any Further extras or the Stains option:
Example:
Further extras
|
|
Extra quiet |
|
Extra rinse |
|
^Use the or button to highlight the Extra you wish to select and confirm your selection by pressing the OK button.
A tick will appear to show which Extra has been selected. If you wish to deselect the Extra with a tick against it press the OK button again.
Press the Further extras button again to come out of the Extras menu.
You can only select extra options which are compatible with the programme being used. If the Extras or Stains option cannot be selected it is not compatible with the programme you are trying to use it with.
The Low temperature option is only available for a drying programme.
Load the drum
^Press the Door button to open the drum door.
The load size indicator display will appear.
Load
< 25%
The display shows the amount of laundry loaded in the drum as a % (in 25% steps) of the maximum load permissible for the programme selected.
^Unfold the laundry and load loosely into the drum. Mixing both large and small items gives better wash results and also helps distribute the load evenly during spinning.
The most efficient use of energy and water is achieved when a full load is washed. However, do not overload as this causes creases and reduces cleaning efficiency.
Make sure that no items are caught between the drum door and seal.
^ Shut the door with a gentle swing.
21
WASHING
Add detergent
The detergent dispenser display will now appear.
Detergent
100%
The percentage shown relates to the amount of detergent recommended by the manufacturer on the packaging.
40% |
Add slightly less than half the |
|
recommended amount . . . |
|
|
50% |
Add half the recommended |
|
amount . . . |
|
|
60% |
Add slightly more than half the |
|
recommended amount . . . |
|
|
75% |
Add three quarters of the |
|
recommended amount . . . |
|
|
100% |
Add the recommended amount |
|
|
You also need take the level of soiling and water hardness into account.
Too little detergent results in:
–Laundry not getting properly clean and with time it may become grey and hard to the touch.
–Greasy particles clinging to laundry.
–Limescale deposits on the heater elements.
Too much detergent results in:
–Excessive foam which causes a low level of agitation and poor wash, rinse and spin results.
–High water consumption (an additional rinse cycle will automatically switch in).
– A burden to the environment. |
^Pull out the detergent drawer and add detergent to the compartments as follows:
i= Detergent for the pre-wash (1/3 of the total amount recommended).
j= Detergent for the main wash including Soak, if selected
§= Fabric conditioner or liquid starch
^ Close the detergent drawer.
See "Detergent" for further information.
22
WASHING
Select Delay start
If required please refer to "Delay start" for more information.
Start the programme
^ Press the flashing Start/Stop button.
The estimated programme duration will start counting down in one minute steps. During the first few minutes the machine measures how much water is being absorbed by the laundry. The programme duration may be longer or shorter depending on this absorbency rate.
The programme sequence is also shown in the display. The washer-dryer shows you when each section of the programme is reached.
The drum lighting switches off once the programme has started.
Remove the laundry when the programme has finished
The anti-crease phase starts as soon as the programme finishes.
The machine will switch off automatically 15 minutes after the end of the anti-crease phase. You will need to press the button to switch it back on again.
^Turn the programme selector to the Stop position.
^Open the drum door and remove the laundry.
Check that all items have been removed from the drum. Items left in the drum could discolour other items in the next wash or become discoloured themselves.
Important: Always remove the laundry before switching the machine off. This is important to ensure that the load size indicator works correctly.
^Switch the machine off using thebutton.
See "After each washing or drying programme" in "WASHING AND DRYING" for further information.
After washing a full load
If you have washed a full load of laundry and you wish to dry the laundry in the washer-dryer afterwards you will have to remove half the load. Carry out the drying procedure in two batches.
23
WASHING
Extra options
You can use the Extra option buttons to augment the basic wash programmes.
Short
For light to nomal soiling with no visible staining.
The duration of the main wash is reduced.
Water plus
The water level in the main wash and the rinses will be increased.
Stains
^ Press the Stains button.
There is a choice of various types of stains for achieving the optimum wash results. With some stains, a tip about pre-treating the stain will appear in the display. You can select a maximum of three stains for a wash programme.
If the Short extra option has been selected, it will be deselected automatically.
Press the Stains button again to come out of the Stains sub-menu.
Further extras
^ Press the Further extras button.
Select the Further extras you want.
Press the Further extras button again to come out of the Extras menu.
Extra quiet
If you want to use your machine to wash laundry during quiet periods, you can reduce the noise level. The buzzer will not sound.
If the Extra quiet extra option is selected, the machine will activate the Rinse hold extra option and not spin. The programme duration is longer.
To deactivate Rinse hold
^Press the Further extras button and use the or button to select Rinse hold. To deactivate Rinse hold press the OK button.
The following will appear in the display.
Delay start can be used to delay the spin
Use Delay start to begin the final spin at a convenient time.
24
WASHING
Extra rinse
This extra option introduces an extra rinse.
Pre-wash
For laundry with large amounts of dirt (e.g. dust, sand).
Soak
For heavily soiled items with protein stains.
A length of time of between 30 minutes and 6 hours can be chosen, in 30 minute periods, for the "Soak" process.
Soak duration
0:30 h:min
(0:00 - 6:00 h)
^Use the or button to highlight the Soak duration you wish to use and confirm your selection by pressing the OK button.
To delete the soak duration
^Press the Further extras button and use the or button to select Soak. To deactivate Soak press the OK button.
Rinse hold
The laundry will not be spun and will remain suspended in the final rinse water. This reduces creasing if the laundry is not going to be removed from the drum immediately after the end of the programme.
Adding or removing laundry after a programme has started
^Press the Door button to open the drum door.
^Add or remove items.
^Close the drum door.
The programme will continue automatically.
Please note:
Once a programme has started the machine cannot recognise any adjustment to the load.
For this reason, if laundry is added or removed after the start of a programme, the machine will always complete the programme cycle assuming a full load.
This can alter the programme running time shown in the display.
The door cannot be opened, if:
–the suds temperature is above 55°C.
–the water is above a certain level.
–the programme has reached the
Final spin stage.
–the safety lock has been activated.
25
WASHING
Final spin speed
Programme |
rpm |
|
|
Cottons |
1600 |
Minimum iron |
1200 |
|
|
Denim |
900 |
Woollens |
1200 |
|
|
Express 20 |
1600 |
Shirts |
600 |
|
|
Automatic plus |
1200 |
Dark garments |
1200 |
|
|
Delicates |
600 |
Sportswear |
1200 |
|
|
Trainers |
1000 |
Outerwear |
800 |
|
|
Proofing |
1000 |
Soft toys |
900 |
|
|
Hygiene |
1600 |
First wash |
1200 |
|
|
Silks |
600 |
Pillows |
1200 |
|
|
Curtains |
600 |
Separate rinse |
1600 |
|
|
Starch |
1600 |
Drain / Spin |
1600 |
|
|
You can reduce the final spin speed. However, you cannot select a final spin speed higher than that shown in the chart above.
Rinse and interim spin
There is a spin after the main wash and between the rinses. A reduction in the final spin speed will also reduce the interim spin speed. In some programmes, an additional rinse is introduced if a spin speed of less than 700 rpm is selected.
To omit the final spin (Rinse hold)
^ Select the Rinse hold Extra.
–To start the final spin:
The machine will display the previously set spin speed. You can change this to a different spin speed if you wish. Start the final spin by pressing the Start/Stop button.
–To end the programme:
Press the Door button. The water will drain away. Press the Door button again to open the door.
To omit the spin between rinses and the final spin
^ Select the No u option.
The laundry is not spun after the final rinse. The water will drain away and the machine will go straight into the anti-crease stage.
With some programmes an additional rinse is introduced if this setting is selected.
26
|
|
|
WASHING |
|
|
|
|
Programme chart |
|
|
|
|
|
|
|
Cottons 9ö8E76* |
cold to 95°C |
Max. load 5.5 kg |
|
Suitable for |
Cotton, linen or cotton mix fabrics, e.g. T-shirts, underwear, table |
||
|
linen. |
|
|
|
|
||
Extra options |
Short, Water plus, Stains, Extra quiet, Extra rinse, Pre-wash, Soak, |
||
|
Rinse hold |
|
|
|
|
||
Note for test institutes: Short programme: 3 kg load and Short extra option |
|||
|
|
|
|
Minimum iron 43218E76* |
cold to 60°C |
Max. load 3.0 kg |
|
Suitable for |
Synthetics and mixed fibre garments as well as easy care cottons. |
||
|
|
||
Extra options |
Short, Water plus, Stains, Extra quiet, Extra rinse, Pre-wash, Soak, |
||
|
Rinse hold |
|
|
|
|
|
|
Denim |
|
cold to 60°C |
Max. load 3.0 kg |
|
|
|
|
Note |
– Wash denim inside out. |
|
|
|
– Denim often contains excess dye and may run during the first |
||
|
few washes. Wash light and dark coloured items separately. |
||
|
|
||
Extra options |
Short, Stains, Extra quiet, Pre-wash, Soak, Rinse hold |
||
|
|
|
|
Woollens / ac* |
cold to 40°C |
Max. load 2.0 kg |
|
Suitable for |
Machine and hand-washable wool or wool blend garments. If the |
||
|
care label does not specify a temperature, wash using the cold |
||
|
setting. |
|
|
|
|
|
|
Extra options |
Rinse hold |
|
|
|
|
|
|
Express 20 76* |
cold to 40°C |
Max. load 3.0 kg |
|
Suitable for |
Small loads of lightly soiled cotton garments |
|
|
|
|
||
Extras |
Water plus, Extra quiet, Extra rinse, Rinse hold; the Short option is |
||
|
activated automatically. |
|
|
|
|
|
|
Shirts |
|
cold to 60°C |
Max. load 1.5 kg |
|
|
|
|
Note |
– Pre-treat collars and cuffs if necessary. |
|
|
|
– Wash silk blouses and shirts in the Silks programme. |
||
|
|
||
Extra options |
Short, Water plus, Stains, Extra quiet, Extra rinse, Pre-wash, Soak, |
||
|
Rinse hold |
|
|
|
|
|
|
* Please note that the "buckets" represent garment care label symbols. See "Garment care label symbols".
27
Loading...
