IMPORTANT

SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons including the following:

1.Read all instructions prior to first use.

2.Do not touch hot surfaces. Always use handles or knobs.

3.To protect against fire, electric shock and injury to persons, do not immerse cord, plugs or machine in water or other liquid.

4.Not intented for use by children.

5.Close supervision is necessary when any machine is used near children. Keep machine out of reach of children.

6.This appliance is not designed to be used by children or people without knowledge or experience with the machine.

7.Children must be supervised to ensure that they do not play with the appliance.

8.Burns can occur from touching the hot plate, hot water or steam. Exercise caution.

9.Exercise caution when using the steam nozzle as steam can cause scalding.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

10.Unplug machine from outlet when not in use and when cleaning. Allow to cool before putting on or taking off parts, before cleaning the machine, and before storing.

11.All machines are subject to stringent quality control. Practical tests using machines taken at random are conducted and this may explain any slight marks or coffee residue prior to use.

12.Do not operate any machine with a damaged cord or plug or after the machine malfunctions, or has been damaged in any manner. Return machine to the nearest Krups Service Center for examination, repair or adjustment or your respective countries Consumer Service Department.

13.To reduce the risk of injury do not drape cord over the counter top or table top where it can be pulled on by children or tripped over accidentally.

14.Do not let cord hang over edge of table or counter, or touch hot surfaces.

15.The use of accessory attachments not recommended by Krups may result in fire, electric shock or injury to persons.

16.Do not use outdoors.

17.Do not place on or near a hot gas or electric burner, or in a heated oven.

18.To disconnect the machine, turn the control to “off” then remove plug from wall outlet. Do not yank cord, instead grasp plug and pull to disconnect.

ENGLISH

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

19.Do not use the machine for anything other than its intended use.

20.Do not pour liquids other than water and descaling solutions specified in this manual into the water tank.

21.Protect the machine against humidity and freezing.

22.Scalding may occur if the lid is removed during the brewing cycles.

23.This machine is for household use only.

SAVE THESE

INSTRUCTIONS

CAUTION

This machine is intended for household use only. Any servicing other than cleaning and user maintenance should be performed by the nearest authorized Krups Service Center.

Visit our website at www.krupsusa.com in the USA or www.krups.ca in Canada or contact your respective country's Consumer Service department for the service center nearest to you.

To reduce the risk of fire or electric shock, do not attempt to disassemble the machine. Repair should be done by an authorized Krups Service Center only.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

SHORT CORD INSTRUCTIONS

A short power-supply cord is to be provided to reduce risks resulting from becoming entangled in or tripping over a longer cord.

A.We do not recommend using an extension cord with this device.

B.If an extension cord is absolutely necessary,

1)the marked electrical rating of the extension cord should be at least as great as the electrical rating of the machine,

2)the longer cord should be arranged so that it will not drape over the counter top or table top where it can be pulled on by children or tripped over.

C.This machine has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

In the interest of improving products, Krups reserves the right to change specifications without prior notice.

ENGLISH

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P
	h
	i
	g
	b
	a
	c
	f
	e
	d
b	c
b3	c1
	c1
	c2
b1
b2
6

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

ENGLISH


	5				6
	5				6

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

DESCRIPTION

a	ON/OFF Pilot light		d	Measuring spoon
b	Selector knob		e	Carafe
	b1	Off position	f	Removable drip tray grid
	b2	Espresso-coffee making	g	Cappuccino accessory
	b3	position	h	Steam nozzle
	b3	Hot steam position	i	Boiler cap for water tank

cFilter-holder

c1 Removable filter for 1 to 4 cups

c2 Filter locker

ENGLISH

AUTHENTIC ESPRESSO

Espresso is a richer and more aromatic brew than regular coffee. It is typically enjoyed in smaller quantities because of its richness, and for that reason, espresso is usually served in small (1.5 - 2 oz) cups.

Your appliance when properly used will produce espresso that is deep in flavor and dark in color. Just follow the instructions and use fresh roasted coffee that has been pre-ground to an espresso grind.

Preparing an espresso or cappuccino is different from brewing regular drip coffee. One main difference is that the water will come to a boil and will then be forced through the ground coffee. This means that an espresso machine works under pressure and needs special attention.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

CAUTION – PRESSURE

Never open boiler cap (i) or remove filter holder (c) while your appliance is turned “on” or while there is still pressure in the boiler container.

To check for pressure:

Turn the selector knob (b) to the “Off” position. Fig. 1.

Turn the selector knob to the steam position (b3) Fig. 10. If steam comes out of the nozzle, then the boiler chamber is still under pressure. Close steam knob and proceed with instructions listed below.

Take a pitcher filled with cold water and hold it underneath the steam nozzle with nozzle inserted into the pitcher. Then turn the selector knob to the steam position (b3). Leave steam release knob open until no more steam comes out of nozzle. When finished turn the selector knob (b) to the “Off” position.

Now you can remove the boiler cap and the filter holder.

CAUTION – HOT

Do not touch boiler cap (i) during operation. Before removing boiler cap turn off machine, let it cool down for at least 2 or 3 minutes. Relieve pressure. (See CAUTION-PRESSURE).

BEFORE FIRST USE

Important! Before using your machine for the first time, or after not having used it for a considerable amont of time, rinse the appliance as indicated below. Check that the appliance is unplugged.

Check that the appliance is unplugged.

Unscrew the boiler cap. Fig. 2.

Pour 8 oz (240 ml) of cold water into the water tank. Do not pour warm or hot water into the water tank. Fig. 3.

Screw the boiler cap on tightly. Fig. 4.

Fit the filter (without any coffee) into the filter-holder and rotate filter inside filter-holder to secure it. Fig. 5.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

Insert the filter holder in the appliance. Turn it firmly from left to right to put it into the “locked” position. Fig. 6.

Place the carafe or a cup under the filter holder. Plug in the appliance. Fig. 7.

Turn the selector knob to the “Espresso” position (b2). Fig. 8. The ON/OFF pilot light will light up.

After a few minutes, the water will boil and hot water will start to drip. When the container/cup is full, turn the selector knob to the “Off” position (b1).

Place a cup under the steam nozzle and turn the selector knob to the steam setting (b3). When there is no more steam, turn to the “Off” position (b1).

Never remove filter holder or open boiler cap without having released remaining pressure in appliance. (See CAUTION-

PRESSURE).

ENGLISH

MAKING ESPRESSO

Important! Check that the appliance is unplugged and that there is no pressure. (See CAUTION-PRESSURE).

Unscrew the boiler cap Fig. 2. Measure out the right amount of water for your needs and pour it into the water tank. For instance: an espresso-sized cup (small cup for strong espresso) = 1 to 2 oz (25 to 50 ml). A standard-sized cup (for milder espresso) = 3 to 4 oz (75 to 100 ml). Up to 4 espressos or 2 standard cups can be made at one time, without adding additional water to the tank.

Pour the water into the tank. Fig. 3.

Screw the boiler cap on tightly. Fig. 4. Plug in the appliance.

Fit the filter into the filter-holder and rotate filter inside filter-holder to secure it. Fig. 5.

Put the ground coffee into the filter holder using the measuring spoon. 1 full measuring spoon is the amount needed for 1

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

espresso. Using a tamper or the back of the measuring spoon tamp down the coffee.

Remove any excess coffee on the edge of the filter-holder.

ATTENTION! Do not over fill or pack coffee too tightly.

Fit the filter-holder into the appliance turning it from left to right and locking it firmly into place. Fig. 6.

Place a cup or the carafe under the filter-holder. Fig. 7. Turn the selector knob to “espresso” (b2). Fig. 8.

The ON/OFF pilot light will light up. After 3 to 4 minutes, the espresso will start to drip. Wait until the espresso has stopped dripping before removing the cup or carafe and then turn the selector knob to the “Off” position (b1). Fig. 9.

ATTENTION! We advise you to not switch off the appliance before the cycle is completely finished. At the end of the cycle, steam will dry out the coffee grounds thus producing a puck that is drier and easier to remove. Never remove filter holder or open the water tank without having released remaining pressure in appliance. (See CAUTION-PRESSURE). Once you have removed the pressure from the machine the filter holder can be removed. To throw away the coffee grounds, turn over the filter holder and shake it to make the coffee grounds fall out.

MAKING CAPPUCCINOS

Follow the instructions for “Making Espresso” but add 2 oz (50 ml) of water to the volumes indicated.

An authentic cappuccino is made using 1/3 espresso, 1/3 hot steamed milk and 1/3 frothed milk. We recommend frothing the

milk before making the coffee.

Pour 4 to 6 oz (100 to 150 ml) of fresh, cold milk into a small pitcher. Do not use a pitcher cleaned with hot water or one that is still warm.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

The milk will froth better in a cold pitcher. The pitcher should fit underneath the cappuccino nozzle. We recommend using 1 or 2% milk for a stiff, dense froth. Use whole milk if you prefer a creamy froth.

Turn the knob to the “Steam” position (b3). Fig. 10.

When the steam starts coming out of the nozzle, immerse the nozzle in the pitcher of milk and make circular movements going up and down to froth the milk. It is important not to have the nozzle touch the bottom of your pitcher. Fig. 11.

Once the milk is frothed, put a cup underneath the filter holder. Turn the knob to the “Espresso” position (b2). Fig. 8.

Once the espresso has finished dripping, spoon the frothy milk over the espresso to finish the cappuccino. Never remove filter holder or open boiler cap without having released remaining pressure. (See CAUTION-PRESSURE).

ATTENTION! Clogged Steam nozzle:

Milk residue will build up in the tip of the steam nozzle after frothing milk. To avoid clogging, remove the plastic housing of the cappuccino nozzle once the appliance has cooled, for easy cleaning. Then follow “cleaning the steam nozzle” as described in the section “Cleaning the Cappuccino Nozzle”.

Don’t forget to replace the tip of the nozzle and screw it on tightly.

ENGLISH

MAKING CAFFE LATTES

Follow the instructions for “Making Cappuccinos” with the following proportions: 2/3 frothy milk, 1/3 espresso, and if desired you may spoon some milk foam on top.

STEAMING WITHOUT MAKING ESPRESSO

Steam is used to froth milk and also to reheat water (tea, hot drinks).

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

Check that the appliance is unplugged and that there is no contained pressure. (See CAUTION-PRESSURE).

Measure out a small amount of water and pour into tank. For example: 2 oz (50 ml) of water to heat 4 oz (100 ml) of liquid.

Important: for maximum efficiency, avoid putting more than 4 oz (100 ml) of water into the tank.

Tightly screw on the boiler cap. Fig. 4. Plug in the appliance.

Immerse the steam nozzle in the liquid to be heated. Turn the knob to “steam” (b3). Fig. 10.

The ON/OFF pilot light will light up.

Steam is produced after 2 to 3 minutes of preheating.

Once the liquid is hot, turn selector knob back to “Off” (b1) and unplug the appliance.

If you do not need all the water for steaming, proceed as follows: Turn off the machine.

Release the remaining steam pressure into another container.

Before turning the knob again, turn the knob to “steam” (b3) to remove any steam, take care to put a cup underneath the steam nozzle.

CAUTION! Do not turn the selector knob back to "Off" (b1) before all steam is released! (See CAUTION - PRESSURE).

ATTENTION! The plastic housing of the cappuccino nozzle

(g) has 2 fine holes at the top which draw air into the milk.

If those holes get clogged, the milk will not be frothed properly. Therefore, do not dip the cappuccino nozzle in milk or froth up to those holes.

ATTENTION! Immediately after use, wash the steam nozzle with a damp sponge.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

CLEANING AND SERVICING

Unplug the appliance and let it cool down completely before you clean it.

Occasionally wipe the outside of the appliance with a damp cloth. Regularly wash and dry the drip tray and its grid.

Do not use alcohol-based or abrasive cleaning products or solvents.

Regularly clean the grid through which the hot water passes with a damp sponge.

Important: Never use soap or other cleaning agents as it will impact the taste of your beverages.

ENGLISH

CLEANING THE CAPPUCCINO NOZZLE

Clean the steam nozzle each time after you have immersed it in the milk, otherwise the inside of the nozzle can become clogged and the milk deposits on the outside will harden and become difficult to remove.

If clogging does occur, remove the plastic housing of the cappuccino nozzle (g) once the appliance has cooled and then unscrew the tip of the steam nozzle.

Remove all milk particles by using a clean sewing needle and rinse under the faucet. Replace nozzle tip making sure to screw it on tightly. Wipe off the outside of the nozzle with a wet cloth. The plastic housing of the cappuccino nozzle should be rinsed in warm water. If the small suction openings are clogged up, they can be opened with a small needle.

CAUTION! Do not try to open or disassemble the main body of the machine.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

DECALCIFYING THE ESPRESSO SIDE

The warranty does not cover a faulty or broken espresso machine due to not being descaled.

Due to the acidity of the cleaning solution, we recommend protecting your worktop and sink during the descaling process, especially if it is made of marble or stone. Isolate your appliance with an old towel, tablecloth or tray.

The espresso machine must be decalcified regularly. The frequency depends on the hardness of your water and how often you use the espresso machine.

Before descaling, the brewing sieve on the brewing head must first be screwed off.

1.Remove all lime and coffee residues from the brewing sieve and the brewing head.

2.Remove the plastic housing of the cappuccino nozzle (g).

As a descaling agent we recommend the use of Krups descaling solution F054 available at authorized Krups retailers and Service

Centres or by contacting your respective countries Customer

Service Department.

3.Dissolve a packet of KRUPS descaling solution in 10 oz/300 ml of lukewarm water and pour into the boiler container and screw back the cap. Put a container under the brewing head and another under the steam nozzle.

(Note: Do not secure the filter holder (c) during decalcification).

4.Open the steam valve and turn on the appliance. Allow the descaling solution to run out of the espresso outlet and the steam nozzle.

5.After each brewing cycle, switch off the appliance and allow the appliance to cool down.

6.Repeat this operation once more.

Following this, allow 2 containers of clear water to run through the system. Switch off the appliance. Allow the appliance to cool down. Insert the brewing sieve into the brewing head again and push the plastic housing of the cappuccino nozzle onto the steam nozzle.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

TROUBLESHOOTING

Problems	Probable Causes	Solutions	ENGLISH

too slowly.	too fine.	ground coffee.
Espresso
The coffee drips	The coffee is ground	Use more coarsely

	Filter blocked.	Clean it with a brush.

	Water passage grid is	Clean the appliance
	clogged.	when cold.

	Presence of scale.	De-Scale the
	Presence of scale.	De-Scale the
		appliance.

The coffee drips	Dirty filter-holder or	Clean them with hot
too slowly.	dirty filter.	water.

	The coffee is ground	Use more coarsely
	too fine.	ground coffee.

The coffee	The knob is in the	Turn the knob to the
doesn’t drip.	“Steam” position	“Espresso” position
	(b3).	(b2).

The espresso	Filter holder is	Remove any excess
leaks onto the	clogged up.	ground coffee.
filter holder sides.
filter holder sides.	The filter holder is not	Put it back into place
	properly positioned.	and lock it into
		position.

Bad taste.	Insufficient rinsing.	Follow the rinsing
		instructions.

Steam
Water runs out of	The knob is in the	Turn the knob to the
the filter holder.	“Espresso”	“Steam” position (b3).
	position (b2).

Little or no steam	The knob opened too	Close the “Steam”
in the “steam”	early.	knob for 2
position.		minutes.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

Problems	Probable Causes	Solutions

The steam nozzle	Blocked steam	Rinse out the steam
doesn’t froth the	nozzle.	nozzle.
milk.
milk.	Whole milk used.	Use 1 or 2% milk.
	Whole milk used.	Use 1 or 2% milk.

	Milk not fresh or cold	Always use very fresh,
	enough.	cold milk.

	Container doesn’t	Use a small diameter
	have the right shape.	container (small jug).

LIMITED WARRANTY

: www.krups.com

With a strong commitment to the environment, most of Krups products are repairable during and after the warranty period. Before returning any defective products to the point of purchase, please call Krups consumer service directly at the phone number below for repair options. Your help to sustain the environment is appreciated!

The Warranty

This product is guaranteed by Krups for a period of 2 years against any manufacturing defect in materials or workmanship, starting from the initial date of purchase.

The manufacturer's warranty by Krups is an extra benefit which does not affect consumer's Statutory Rights.

The Krups warranty covers all costs related to restoring the proven defective product so that it conforms to its original specifications, through the repair or replacement of any defective part and the necessary labor. At Krups’s choice, a replacement product may be provided instead of repairing a defective product. Krups’s sole obligation and your exclusive resolution under this warranty are limited to such repair or replacement.

KR_COFFEEMAKERS_ESPRESSO-XP1000_8080011304_Mise en page 1 18/06/12 09:45 P

Conditions & Exclusions

The Krups warranty only applies within USA, Canada & Mexico, and is valid only on presentation of a proof of purchase. The product can be taken directly in person to an authorized service centre or must be adequately packaged and returned, by recorded delivery (or equivalent method of postage), to a Krups authorized service centre. Full address details for each country’s authorized service centre are listed on the Krups website (www.krups.com) or by calling the appropriate telephone number listed below to request the appropriate postal address.

Krups shall not be obliged to repair or replace any product which is not accompanied by a valid proof of purchase.

This warranty will not cover any damage which could occur as a result of misuse, negligence, failure to follow Krups instructions, use on current or voltage other than as stamped on the product, or a modification or unauthorized repair of the product. It also does not cover normal tear and wear, maintenance or replacement of consumable parts, and the following:

-using the wrong type of water

-scaling (any de-scaling must be carried out according to the instructions for use);

-ingress of water, dust or insects into the product;

-mechanical damages, overloading

-damages or bad results due to wrong voltage or frequency

-accidents including fire, flood, lightning, etc

-professional or commercial use

-damage to any glass or porcelain ware in the product

This warranty does not apply to any product that has been tampered with, or to damages incurred through improper use and care, faulty packaging by the owner or mishandling by any carrier.

The Krups manufacturer's warranty applies only for products purchased and used in USA, Canada & Mexico. Where a product purchased in one country and then used in another one:

a)The Krups guarantee duration is the one in the country of usage of the product, even if the product was purchased in another listed country with different guarantee duration.

ENGLISH

+ 43 hidden pages
