QuickSpecs
HP NC523SFP 10Gb 2-port Server Adapter
Overview
HP NC523SFP 10Gb 2-port Server Adapter
The NC523SFP is an eight lane (x8) PCI Express (PCIe) 10 Gigabit network solution offering superior bandwidth in a ProLiant Ethernet adapter. This dual port PCI Express Gen 2 adapter supports SFP+ (Small Form-factor Pluggable) connectors, requiring either Direct Attach Cable (DAC) for copper environments, or fiber transceivers and fiber cables for fiber optic environments.
The NC523SFP ships with advanced server features that ProLiant customers have come to expect, such as support for TCP checksum and segmentation (LSO) offload capability, VLAN tagging, jumbo frames, IPv6, and more. Flexible to order and install, the NC523SFP can be used in either standard or low profile slots.
|
NC523SFP - Low profile bracket |
NC523SFP - Standard bracket |
|
|
|
|
|
Models |
|
|
|
HP NC523SFP 10Gb 2-port Server Adapter |
593717-B21 |
||
|
|
|
|
Kit Contents |
HP NC523SFP 10Gb 2-port Server Adapter |
|
|
Full height bracket (installed on card)
Low-profile bracket
Quick install card
User documentation and driver download information
Product warranty statement
c04111107 - DA – 13844 North America — Version 18 —August 12, 2014 |
Page 1 |
QuickSpecs
HP NC523SFP 10Gb 2-port Server Adapter
Compatibility
Compatibility
Servers |
ProLiant DL (rack-optimized): |
|
|
HP ProLiant DL160 G6 |
|
|
HP ProLiant DL160 Gen8 |
|
|
HP ProLiant DL165 G7 |
|
|
HP ProLiant DL180 G6 |
|
|
HP ProLiant DL320 G6 |
|
|
HP ProLiant DL320e Gen8 |
|
|
HP ProLiant DL320e Gen8 v2 |
|
|
HP ProLiant DL360 G6 |
|
|
HP ProLiant DL360 G7 |
|
|
HP ProLiant DL360e Gen8 |
|
|
HP ProLiant DL360p Gen8 |
|
|
HP ProLiant DL370 G6 |
|
|
HP ProLiant DL380 G7 |
|
|
HP ProLiant DL380e Gen8 |
|
|
HP ProLiant DL380p Gen8 |
|
|
HP ProLiant DL385 G7 |
|
|
HP ProLiant DL385p Gen8 |
|
|
HP ProLiant DL560 Gen8 |
|
|
HP ProLiant DL580 G7 |
|
|
HP ProLiant DL585 G6 |
|
|
HP ProLiant DL585 G7 |
|
|
HP ProLiant DL785 G6 |
|
|
HP ProLiant DL980 G7 |
|
|
ProLiant ML (expansion-optimized): |
|
|
HP ProLiant ML310e Gen8 |
|
|
HP ProLiant ML310e Gen8 v2 |
|
|
HP ProLiant ML330 G6 |
|
|
HP ProLiant ML350 G6 |
|
|
HP ProLiant ML350e Gen8 |
|
|
HP ProLiant ML350p Gen8 |
|
|
HP ProLiant ML370 G6 |
|
|
ProLiant SL (scalable line): |
|
|
HP ProLiant SL160s G6 |
|
|
HP ProLiant SL160z G6 |
|
|
HP ProLiant SL165s G7 |
|
|
HP ProLiant SL165z G7 |
|
|
HP ProLiant SL170z G6 |
|
|
HP ProLiant SL2x170z G6 |
|
|
HP ProLiant SL210t Gen8 |
|
|
HP ProLiant SL230s Gen8 |
|
|
HP ProLiant SL250s Gen8 |
|
|
HP ProLiant SL270s Gen8 |
|
|
NOTE: This is a list of supported servers. Some may be discontinued. |
|
|
|
|
|
c04111107 - DA – 13844 North America — Version 18 —August 12, 2014 |
Page 2 |
QuickSpecs
HP NC523SFP 10Gb 2-port Server Adapter
Standard Features
Performance
Dual-port 10 Gigabit |
The 20,000 Mbps full duplex Ethernet transfer rate per port (40 Gbps aggregate full duplex) delivers |
Ethernet Throughput |
outstanding network performance that improves response time and removes bottlenecks for the next |
|
generation data center. 10 Gigabit Ethernet bandwidth is ideal for high performance computing, |
|
database clusters, grid systems, virtualization, server and I/O consolidation, fabric consolidation, and |
|
more. |
|
|
PCI Express Interface |
HP was an early champion of PCI Express bus technology and has played a key role in the development |
|
and industry adoption of the PCI Express specification. The NC523SFP is designed with an eight lane |
|
(x8) PCI Express bus based on the PCIe v2.0 standard. The adapter is backward compatible with four |
|
lane (x4) PCI Express, automatically auto-sensing between x8 and x4 slots. |
|
|
Jumbo Frames |
Jumbo frames (also known as extended frames) permit a 9,000 byte transmission unit (MTU). The |
|
NC523SFP adapter supports 9KB jumbo frames as a way to achieve higher throughput and better CPU |
|
utilization. Jumbo frames are particularly useful for database transfers and tape backups. |
|
|
TCP Stateless Offloading For overall improved system response, the NC523SFP adapter supports standard TCP/IP offloading techniques including:
TCP/IP checksum offload (TCO) moves the TCP and IP checksum offloading from the CPU to the network adapter.
Large Send Offload (LSO) or TCP Segmentation Offload (TSO) allows the TCP segmentation to be handled by the adapter rather than the CPU.
Interrupt Coalescing Interrupt coalescing (interrupt moderation) groups multiple packets, thereby reducing the number of interrupts sent to the host. This process optimizes host efficiency, leaving the CPU available for other duties.
802.1p QoS Tagging IEEE quality of service (QoS) 802.1p tagging allows the adapter to mark or tag frames with a priority level across a QoS-aware network for improved traffic flow.
Network Management
Management Support Like all HP ProLiant server adapters, the NC523SFP adapter ships with agents that can be managed from HP Systems Insight Manager or other management application that support SNMP.
Server Integration |
The NC523SFP adapter is a validated, tested, and qualified solution that is optimized for HP ProLiant |
||
|
servers. This approach provides a more robust and reliable networking solution than offerings from |
||
|
other venders and provides users with a single point of contact for both their servers and their network |
||
|
adapters. |
|
|
|
|
|
|
LED Indicators |
Bracket LED indicators show link integrity and network activity for easy troubleshooting. |
|
|
|
|
|
|
PXE |
Support for pre-boot execution environment (PXE) enables automatic deployment of computing |
|
|
|
resources remotely from anywhere. It allows a new or existing server to boot over the network and |
||
|
download software, including the operating system, from a management/ deployment server at |
|
|
|
another location on the network. Additionally, PXE enables decentralized software distribution and |
||
|
remote troubleshooting and repairs. |
|
|
|
|
|
|
Warranty |
Maximum: The remaining warranty of the HP product in which it is installed (to a maximum three-year, |
||
|
limited warranty). |
|
|
|
Minimum: One year limited warranty. |
|
|
|
Additional information regarding worldwide limited warranty and technical support is available at: |
|
|
|
|
|
|
|
c04111107 - DA – 13844 North America — Version 18 —August 12, 2014 |
Page 3 |
|
QuickSpecs
HP NC523SFP 10Gb 2-port Server Adapter
Standard Features
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
