User's Guide
NPD5533-00 EN
User's Guide
Copyright
Copyright
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information herein. The information contained herein is designed only for use with this Epson product. Epson is not responsible for any use of this information as applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.
Seiko Epson Corporation and its affiliates shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that occurs from the use of any interface cables other than those designated as Epson Approved Products by Seiko Epson Corporation.
© 2016 Seiko Epson Corporation. All rights reserved.
The contents of this manual and the specifications of this product are subject to change without notice.
2
User's Guide
Trademarks
Trademarks
EPSON®is a registered trademark, and EPSON EXCEED YOUR VISION or EXCEED YOUR VISION is a trademark of Seiko Epson Corporation.
PRINT Image Matching™ and the PRINT Image Matching logo are trademarks of Seiko Epson Corporation. Copyright © 2001 Seiko Epson Corporation. All rights reserved.
Epson Scan 2 software is based in part on the work of the Independent JPEG Group.
libtiff
Copyright © 1988-1997 Sam Leffler Copyright © 1991-1997 Silicon Graphics, Inc.
Permission to use, copy, modify, distribute, and sell this software and its documentation for any purpose is hereby granted without fee, provided that (i) the above copyright notices and this permission notice appear in all copies of the software and related documentation, and (ii) the names of Sam Leffler and Silicon Graphics may not be used in any advertising or publicity relating to the software without the specific, prior written permission of Sam Leffler and Silicon Graphics.
THE SOFTWARE IS PROVIDED "AS-IS" AND WITHOUT WARRANTY OF ANY KIND, EXPRESS, IMPLIED OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SAM LEFFLER OR SILICON GRAPHICS BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER OR NOT ADVISED OF THE POSSIBILITY OF DAMAGE, AND ON ANY THEORY OF LIABILITY, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
Microsoft®, Windows®, and Windows Vista®are registered trademarks of Microsoft Corporation.
Apple, Macintosh, Mac OS, OS X are trademarks of Apple Inc., registered in the U.S. and other countries.
Adobe and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.
Intel® is a registered trademark of Intel Corporation.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks.
3
User's Guide
Contents
Contents
Copyright
Trademarks
About This Manual
Introduction to the Manuals. . . . . . . . . . . . . . . . . . .7
Marks and Symbols. . . . . . . . . . . . . . . . . . . . . . . . . 7
Descriptions Used in this Manual. . . . . . . . . . . . . . . 7
Operating System References. . . . . . . . . . . . . . . . . . 8
Important Instructions
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . 9
Printer Advisories and Warnings. . . . . . . . . . . . . . . 9
Advisories and Warnings for Setting Up/
Using the Printer. . . . . . . . . . . . . . . . . . . . . . . . . 9
Printer Basics
Part Names and Functions. . . . . . . . . . . . . . . . . . . 11
Buttons and Lights. . . . . . . . . . . . . . . . . . . . . . . . . 13
Loading Paper
Paper Handling Precautions. . . . . . . . . . . . . . . . . . 15
Available Paper and Capacities. . . . . . . . . . . . . . . . 16
List of Paper Types. . . . . . . . . . . . . . . . . . . . . . . 16
Loading Paper in the Rear Paper Feed. . . . . . . . . . . 17
Placing Originals on the Scanner Glass
Placing Multiple Photos for Scanning at the
Same Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Printing
Printing from a Computer. . . . . . . . . . . . . . . . . . . 22
Printing Basics - Windows. . . . . . . . . . . . . . . . . 22 Printing Basics - Mac OS X. . . . . . . . . . . . . . . . .23 Printing on 2-Sides (for Windows only). . . . . . . .25 Printing Several Pages on One Sheet. . . . . . . . . . 26 Printing to Fit the Paper Size. . . . . . . . . . . . . . . .27 Printing Multiple Files Together (for
Windows Only). . . . . . . . . . . . . . . . . . . . . . . . . 29 Printing One Image on Multiple Sheets to
Create a Poster (for Windows Only). . . . . . . . . . 30
Printing Using Advanced Features. . . . . . . . . . . 36 Printing Photos Using Epson Easy Photo Print. . 38
Canceling Printing. . . . . . . . . . . . . . . . . . . . . . . . . 39
Canceling Printing - Printer Button. . . . . . . . . . .39
Canceling Printing - Windows. . . . . . . . . . . . . . 39
Canceling Printing - Mac OS X. . . . . . . . . . . . . . 39
Copying
Copying Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Making Multiple Copies. . . . . . . . . . . . . . . . . . . . . 40
Scanning
Scanning from the Control Panel. . . . . . . . . . . . . . 41
Scanning from a Computer. . . . . . . . . . . . . . . . . . .41
Scanning Using Epson Scan 2. . . . . . . . . . . . . . . 41
Refilling Ink
Checking the Ink Levels. . . . . . . . . . . . . . . . . . . . . 48
Ink Bottle Codes. . . . . . . . . . . . . . . . . . . . . . . . . . 48
Ink Bottle Handling Precautions. . . . . . . . . . . . . . . 48
Ref illing the Ink Tanks. . . . . . . . . . . . . . . . . . . . . . 49
Maintaining the Printer
Checking and Cleaning the Print Head. . . . . . . . . . 53
Checking and Cleaning the Print Head -
Printer Buttons. . . . . . . . . . . . . . . . . . . . . . . . . 53
Checking and Cleaning the Print Head -
Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Checking and Cleaning the Print Head -
Mac OS X. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Replacing Ink inside the Ink Tubes. . . . . . . . . . . . . 54
Replacing Ink inside the Ink Tubes - Windows. . .55 Replacing Ink inside the Ink Tubes - Mac OS X. . 55
Aligning the Print Head. . . . . . . . . . . . . . . . . . . . . 55
Aligning the Print Head - Windows. . . . . . . . . . .55
Aligning the Print Head - Mac OS X. . . . . . . . . . 56
Cleaning the Paper Path. . . . . . . . . . . . . . . . . . . . . 56
Cleaning the Scanner Glass. . . . . . . . . . . . . . . . . . .57
Checking the Total Number of Pages Fed
T hrough the Printer. . . . . . . . . . . . . . . . . . . . . . . . 57
Checking the Total Number of Pages Fed
T hrough the Printer - Printer Buttons. . . . . . . . . 57 Checking the Total Number of Pages Fed
T hrough the Printer - Windows. . . . . . . . . . . . . 58
4
User's Guide
Contents
Checking the Total Number of Pages Fed
Through the Printer - Mac OS X. . . . . . . . . . . . . 58
Saving Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Saving Power - Windows. . . . . . . . . . . . . . . . . . 58
Saving Power - Mac OS X. . . . . . . . . . . . . . . . . . 59
Software Information
Windows Printer Driver. . . . . . . . . . . . . . . . . . . . . 60
Guide to Windows Printer Driver. . . . . . . . . . . . 61 Making Operation Settings for the Windows Printer Driver. . . . . . . . . . . . . . . . . . . . . . . . . . 63
Mac OS X Printer Driver. . . . . . . . . . . . . . . . . . . . 63
Guide to Mac OS X Printer Driver. . . . . . . . . . . 64 Making Operation Settings for the Mac OS X Printer Driver. . . . . . . . . . . . . . . . . . . . . . . . . . 65
Epson Scan 2 (Scanner Driver). . . . . . . . . . . . . . . . 66
Epson Event Manager. . . . . . . . . . . . . . . . . . . . . . .66
Epson Easy Photo Print. . . . . . . . . . . . . . . . . . . . . 67
E-Web Print (for Windows Only). . . . . . . . . . . . . . 67
EPSON Sof tware Updater. . . . . . . . . . . . . . . . . . . .68
Uninstalling Applications. . . . . . . . . . . . . . . . . . . . 68
Uninstalling Applications - Windows. . . . . . . . . 68
Installing Applications. . . . . . . . . . . . . . . . . . . . . . 69
Updating Applications and Firmware. . . . . . . . . . . 70
Solving Problems
Checking the Printer Status. . . . . . . . . . . . . . . . . . 71
Checking the Error Indicators on the Printer. . . . 71 Checking the Printer Status - Windows. . . . . . . . 72 Checking Printer Status - Mac OS X. . . . . . . . . . 72
Removing Jammed Paper. . . . . . . . . . . . . . . . . . . . 72
Removing Jammed Paper from the Rear
Paper Feed. . . . . . . . . . . . . . . . . . . . . . . . . . . . .73 Removing Jammed Paper from Inside the
Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Paper Does Not Feed Correctly. . . . . . . . . . . . . . . .75
Paper Jams. . . . . . . . . . . . . . . . . . . . . . . . . . . . .75 Paper Feeds at a Slant. . . . . . . . . . . . . . . . . . . . . 75 Several Sheets of Paper are Fed at a Time. . . . . . . 75 No Paper Feeds. . . . . . . . . . . . . . . . . . . . . . . . . 75
Power and Control Panel Problems. . . . . . . . . . . . . 76
Power Does Not Turn On. . . . . . . . . . . . . . . . . . 76 Power Does Not Turn Of f. . . . . . . . . . . . . . . . . . 76
Cannot Print from a Computer. . . . . . . . . . . . . . . .76
Printout Problems. . . . . . . . . . . . . . . . . . . . . . . . . 77
Printout is Scuf fed or Color is Missing. . . . . . . . .77 Banding or Unexpected Colors Appear. . . . . . . . 77
Colored Banding Appears at Intervals of Approximately 2.5 cm. . . . . . . . . . . . . . . . . . . . 77 Blurry Prints, Vertical Banding, or
Misalignment. . . . . . . . . . . . . . . . . . . . . . . . . . 78 Print Quality is Poor. . . . . . . . . . . . . . . . . . . . . 78 Paper Is Smeared or Scuf fed. . . . . . . . . . . . . . . . 79 Printed Photos are Sticky. . . . . . . . . . . . . . . . . . 80 Images or Photos are Printed in Unexpected
Colors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80 Colors Differ from What You See on the
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80 Cannot Print Without Margins. . . . . . . . . . . . . . 80 Edges of the Image are Cropped During
Borderless Printing. . . . . . . . . . . . . . . . . . . . . . 81 The Position, Size, or Margins of the Printout
Are Incorrect. . . . . . . . . . . . . . . . . . . . . . . . . . . 81 Printed Characters Are Incorrect or Garbled. . . . 81 The Printed Image Is Inverted. . . . . . . . . . . . . . . 82 Mosaic-Like Patterns in the Prints. . . . . . . . . . . .82 Uneven Colors, Smears, Dots, or Straight
Lines Appear in the Copied Image. . . . . . . . . . . 82 Moiré (Cross-Hatch) Patterns Appear in the Copied Image. . . . . . . . . . . . . . . . . . . . . . . . . . 82 An Image of the Reverse Side of the Original Appears in the Copied Image. . . . . . . . . . . . . . . 82 The Printout Problem Could Not be Cleared. . . . 82
Other Printing Problems. . . . . . . . . . . . . . . . . . . . 83
Printing Is Too Slow. . . . . . . . . . . . . . . . . . . . . . 83
Printing Slows Down Dramatically During
Continuous Printing. . . . . . . . . . . . . . . . . . . . . 83
Cannot Start Scanning. . . . . . . . . . . . . . . . . . . . . . 83
Cannot Start Scanning when Using the
Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . 84
Scanned Image Problems. . . . . . . . . . . . . . . . . . . . 84
Uneven Colors, Dirt, Spots, and so on Appear when Scanning from the Scanner Glass. . . . . . . . 84
T he Image Quality Is Rough. . . . . . . . . . . . . . . . 85 Of fset Appears in the Background of Images. . . . 85 Text is Blurred. . . . . . . . . . . . . . . . . . . . . . . . . . 85 Moiré Patterns (Web-Like Shadows) Appear. . . . 86 Cannot Scan the Correct Area on the
Scanner Glass. . . . . . . . . . . . . . . . . . . . . . . . . . 86 Cannot Preview in T humbnail. . . . . . . . . . . . . . 86 Text is Not Recognized Correctly when
Saving as a Searchable PDF. . . . . . . . . . . . . . . . .87 Cannot Solve Problems in the Scanned Image. . . 87
Other Scanning Problems. . . . . . . . . . . . . . . . . . . .88
Scanning Speed Is Slow. . . . . . . . . . . . . . . . . . . 88 Scanning Stops when Scanning to PDF/ Multi-TIFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Other Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5
User's Guide
Contents
Slight Electric Shock when Touching the
Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88 Operation Sounds Are Loud. . . . . . . . . . . . . . . . 88 Application Is Blocked by a Firewall (for
Windows Only). . . . . . . . . . . . . . . . . . . . . . . . . 89
Appendix
Technical Specifications. . . . . . . . . . . . . . . . . . . . . 90
Printer Specif ications. . . . . . . . . . . . . . . . . . . . . 90 Scanner Specif ications. . . . . . . . . . . . . . . . . . . . 91 Interface Specif ications. . . . . . . . . . . . . . . . . . . .91 Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 Electrical Specif ications. . . . . . . . . . . . . . . . . . . 92 Environmental Specif ications. . . . . . . . . . . . . . . 92 System Requirements. . . . . . . . . . . . . . . . . . . . . 93
Regulatory Information. . . . . . . . . . . . . . . . . . . . . 93
Standards and Approvals. . . . . . . . . . . . . . . . . . 93 Restrictions on Copying. . . . . . . . . . . . . . . . . . . 93
Transporting the Printer. . . . . . . . . . . . . . . . . . . . .94
Where to Get Help. . . . . . . . . . . . . . . . . . . . . . . . . 96
Technical Support Web Site. . . . . . . . . . . . . . . . 96
Contacting Epson Support. . . . . . . . . . . . . . . . . 97
6
User's Guide
About This Manual
About This Manual
Introduction to the Manuals
The latest versions of the following manuals are available from the Epson support website.
http://www.epson.eu/Support (Europe)
http://support.epson.net/ (outside Europe)
Start Here (paper manual)
Provides you with information on setting up the printer, installing the software, using the printer basically, solving problems, and so on.
User's Guide (PDF manual)
This manual. Provides overall information and instructions on using the printer, and on solving problems.
As well as the manuals above, see the help included in the various Epson software applications.
Marks and Symbols
!Caution:
Instructions that must be followed carefully to avoid bodily injury.
cImportant:
Instructions that must be observed to avoid damage to your equipment.
Note:
Provides complementary and reference information.
& Related Information
Links to related sections.
Descriptions Used in this Manual
Screenshots of the printer driver and the Epson Scan 2 (scanner driver) screens are from Windows 10 or Mac OS X v10.11.x. The content displayed on the screens varies depending on the model and situation.
Illustrations of the printer used in this manual are examples only. Although there may be slight differences depending on the model, the method of operation is the same.
7
User's Guide
About This Manual
Operating System References
Windows
In this manual, terms such as "Windows 10", "Windows 8.1", "Windows 8", "Windows 7", "Windows Vista", and "Windows XP" refer to the following operating systems. Additionally, "Windows" is used to refer to all versions.
Microsoft® Windows® 10 operating system
Microsoft® Windows® 8.1 operating system
Microsoft® Windows® 8 operating system
Microsoft® Windows® 7 operating system
Microsoft® Windows Vista® operating system
Microsoft® Windows® XP operating system
Microsoft® Windows® XP Professional x64 Edition operating system
Mac OS X
In this manual, "Mac OS X v10.11.x" refers to OS X El Capitan, "Mac OS X v10.10.x" refers to OS X Yosemite, "Mac OS X v10.9.x" refers to OS X Mavericks, and "Mac OS X v10.8.x" refers to OS X Mountain Lion. Additionally, "Mac OS X" is used to refer to "Mac OS X v10.11.x", "Mac OS X v10.10.x", "Mac OS X v10.9.x", "Mac OS X v10.8.x", "Mac OS X v10.7.x", and "Mac OS X v10.6.8".
8
User's Guide
Important Instructions
Important Instructions
Safety Instructions
Read and follow these instructions to ensure safe use of this printer. Make sure you keep this manual for future reference. Also, be sure to follow all warnings and instructions marked on the printer.
Some of the symbols used on your printer are to ensure safety and proper use of the printer. Visit the following Web site to learn the meaning of the symbols.
http://support.epson.net/symbols
Use only the power cord supplied with the printer and do not use the cord with any other equipment. Use of other cords with this printer or the use of the supplied power cord with other equipment may result in fire or electric shock.
Be sure your AC power cord meets the relevant local safety standard.
Never disassemble, modify, or attempt to repair the power cord, plug, printer unit, scanner unit, or options by yourself, except as specifically explained in the printer's manuals.
Unplug the printer and refer servicing to qualified service personnel under the following conditions:
The power cord or plug is damaged; liquid has entered the printer; the printer has been dropped or the casing damaged; the printer does not operate normally or exhibits a distinct change in performance. Do not adjust controls that are not covered by the operating instructions.
Place the printer near a wall outlet where the plug can be easily unplugged.
Do not place or store the printer outdoors, near excessive dirt or dust, water, heat sources, or in locations subject to shocks, vibrations, high temperature or humidity.
Take care not to spill liquid on the printer and not to handle the printer with wet hands.
Be careful not to touch any ink when you handle the ink tanks, ink tank caps, and opened ink bottles or ink bottle caps.
If ink gets on your skin, wash the area thoroughly with soap and water.
If ink gets into your eyes, flush them immediately with water. If discomfort or vision problems continue after a thorough flushing, see a doctor immediately.
If ink gets into your mouth, see a doctor right away.
Do not tilt or shake an ink bottle after removing its seal; this can cause leakage.
Keep ink bottles and the ink tank unit out of the reach of children. Do not allow children to drink from or handle the ink bottles and ink bottle cap.
Printer Advisories and Warnings
Read and follow these instructions to avoid damaging the printer or your property. Make sure you keep this manual for future reference.
Advisories and Warnings for Setting Up/Using the Printer
Do not block or cover the vents and openings in the printer.
9
User's Guide
Important Instructions
Use only the type of power source indicated on the printer's label.
Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on and off.
Avoid electrical outlets controlled by wall switches or automatic timers.
Keep the entire computer system away from potential sources of electromagnetic interference, such as loudspeakers or the base units of cordless telephones.
The power-supply cords should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place objects on top of the power-supply cords and do not allow the power-supply cords to be stepped on or run over. Be particularly careful to keep all the power-supply cords straight at the ends and the points where they enter and leave the transformer.
If you use an extension cord with the printer, make sure that the total ampere rating of the devices plugged into the extension cord does not exceed the cord's ampere rating. Also, make sure that the total ampere rating of all devices plugged into the wall outlet does not exceed the wall outlet's ampere rating.
If you plan to use the printer in Germany, the building installation must be protected by a 10 or 16 amp circuit breaker to provide adequate short-circuit protection and over-current protection for the printer.
When connecting the printer to a computer or other device with a cable, ensure the correct orientation of the connectors. Each connector has only one correct orientation. Inserting a connector in the wrong orientation may damage both devices connected by the cable.
Place the printer on a flat, stable surface that extends beyond the base of the printer in all directions. The printer will not operate properly if it is tilted at an angle.
When storing or transporting the printer, avoid tilting it, placing it vertically, or turning it upside down; otherwise ink may leak.
Allow space above the printer so that you can fully raise the document cover.
Leave enough space in front of the printer for the paper to be fully ejected.
Avoid places subject to rapid changes in temperature and humidity. Also, keep the printer away from direct sunlight, strong light, or heat sources.
Do not insert objects through the slots in the printer.
Do not put your hand inside the printer during printing.
Do not touch the white flat cable and ink tubes inside the printer.
Do not use aerosol products that contain flammable gases inside or around the printer. Doing so may cause fire.
Do not move the print head by hand; otherwise, you may damage the printer.
Be careful not to trap your fingers when closing the scanner unit.
Do not press too hard on the scanner glass when placing the originals.
If any of the ink tanks are not filled up to the lower line, refill the ink soon. Continued use of the printer when the ink level is below the lower line on the tanks could damage the printer.
Always turn the printer off using the P button. Do not unplug the printer or turn off the power at the outlet until the P light stops flashing.
Before transporting the printer, make sure that the print head is in the home (far right) position.
If you are not going to use the printer for a long period, be sure to unplug the power cord from the electrical outlet.
10
User's Guide
Printer Basics
Printer Basics
Part Names and Functions
A |
Edge guide |
Feeds the paper straight into the printer. Slide to the |
|
|
edges of the paper. |
|
|
|
B |
Rear paper feed |
Loads paper. |
|
|
|
C |
Paper support |
Supports loaded paper. |
|
|
|
D |
Feeder guard |
Prevents foreign substance from entering the printer. |
|
|
Usually keep this guard closed. |
|
|
|
E |
Output tray |
Holds the ejected paper. Before printing, raise the |
|
|
stopper to prevent the ejected paper from falling off |
|
|
the tray. |
|
|
|
F |
Control panel |
Operates the printer. |
|
|
|
11
User's Guide
Printer Basics
A |
Scanner unit |
Scans placed originals. Open when removing jammed |
|
|
paper inside the printer. |
|
|
|
B |
Ink tube |
Supplies ink to the print head. |
|
|
|
C |
Ink tank unit |
Contains the ink tanks. |
|
|
|
D |
Ink reservoir tanks (Ink tanks) |
Supplies ink to the ink tubes. |
|
|
|
E |
Print head |
Fires ink. |
|
|
|
A |
Document cover |
Blocks external light while scanning. |
|
|
|
B |
Scanner glass |
Place the originals. |
|
|
|
12
User's Guide
Printer Basics
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
A |
AC inlet |
|
Connects the power cord. |
||||
|
|
|
|
||||
B |
USB port |
|
Connects a USB cable. |
||||
|
|
|
|
|
|
|
|
Buttons and Lights
A |
|
|
|
|
Turns the printer on or off. |
|
|
|
|
|
Do not turn off while the power light is flashing (while the printer is operating or processing |
|
|
|
|
|
data). |
|
|
|
|
|
Unplug the power cord when the power light is off. |
|
|
|
|
|
|
B |
|
|
|
|
Starts monochrome copying on A4 size plain paper. To increase the number of copies (by up to |
|
|
||||
|
|||||
|
|
|
|
|
20 copies), press this button within one second intervals. |
|
|
|
|
|
|
C |
|
|
|
|
Starts color copying on A4 size plain paper. To increase the number of copies (by up to 20 |
|
|
|
|||
|
|
||||
|
|
|
|
|
copies), press this button within one second intervals. |
|
|
|
|
|
|
D |
|
|
|
|
Stops the current operation. |
|
|
|
|
|
Hold this button down for three seconds until the P button flashes to run print head cleaning. |
|
|
|
|
|
|
E |
|
|
|
|
Turns on or flashes when paper is out or a paper jam occurs. |
|
|
|
|
|
|
13
User's Guide
Printer Basics
F |
|
Indicates the status of the initial ink charging. |
|
|
|
Additional functions are available with different combinations of buttons.
|
|
+ |
|
|
|
Press the |
|
and |
|
buttons simultaneously to run software on a USB-connected |
|||
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
computer and scan as a PDF file. |
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
+ |
|
or |
|
|
Press the y and the |
|
or |
|
buttons simultaneously to copy in draft mode. |
||||
|
|
|
|
|
|||||||||
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|||||
|
|
+ |
|
|
|
Turn the printer on while holding down the y button to print the nozzle check pattern. |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Related Information
& “Checking the Error Indicators on the Printer” on page 71
14
User's Guide
Loading Paper
Loading Paper
Paper Handling Precautions
Read the instruction sheets supplied with the paper.
Fan and align the edges of the paper before loading. Do not fan or curl photo paper. Doing so may damage the printable side.
If the paper is curled, flatten it or curl it slightly in the opposite direction before loading. Printing on curled paper may cause paper jams and smears on the printout.
Do not use paper that is wavy, torn, cut, folded, damp, too thick, too thin, or paper that has stickers stuck to it. Using these types of paper causes paper jams and smears on the printout.
Fan and align the edges of the envelopes before loading. When the stacked envelopes are puffed up with air, press them down to flatten them before loading.
Do not use envelopes that are curled or folded. Using these envelopes causes paper jams and smears on the printout.
Do not use envelopes with adhesive surfaces on the flaps or window envelopes.
Avoid using envelopes that are too thin, as they may curl during printing.
Related Information
& “Printer Specifications” on page 90
15
User's Guide
Loading Paper
Available Paper and Capacities
Epson recommends using genuine Epson paper to ensure high-quality printouts.
Genuine Epson Paper
Media Name |
Size |
Loading Capacity |
Manual 2-Sided |
|
|
(Sheets) |
Printing |
|
|
|
|
Epson Bright White Ink Jet Paper |
A4 |
80*1 |
|
Epson Premium Glossy Photo Paper*2 |
A4, 13×18 cm (5×7 in.), 16:9 |
20 |
- |
|
wide size (102×181 mm), 10×15 |
|
|
|
cm (4×6 in.) |
|
|
|
|
|
|
Epson Matte Paper-Heavyweight*2 |
A4 |
20 |
- |
Epson Photo Quality Ink Jet Paper*2 |
A4 |
80 |
- |
*1 For manual 2-sided printing, you can load up to 30 sheets for paper with one side already printed.
*2 Only printing from computer is available.
Note:
The availability of paper varies by location. For the latest information on paper available in your area, contact Epson support.
Commercially Available Paper
Media Name |
Size |
Loading Capacity |
Manual 2-Sided |
|
|
(Sheets) |
Printing |
|
|
|
|
Plain paper |
Letter*1, A4, B5*1, A5*1, A6*1 |
Up to the line |
|
|
|
indicated by the |
|
|
|
triangle symbol on the |
|
|
|
edge guide.*2 |
|
|
Legal*1, User Defined*1 |
1 |
|
Envelope*1 |
Envelope #10, Envelope DL, |
10 |
- |
|
Envelope C6 |
|
|
|
|
|
|
*1 Only printing from computer is available.
*2 For manual 2-sided printing, you can load up to 30 sheets for paper with one side already printed.
Related Information
& “Technical Support Web Site” on page 96
List of Paper Types
To obtain optimum printing results, select the paper type that suits the paper.
16
User's Guide
|
Loading Paper |
|
|
|
|
Media Name |
|
Media Type |
|
|
|
Epson Bright White Ink Jet Paper* |
|
plain papers |
Epson Premium Glossy Photo Paper* |
|
Epson Premium Glossy |
Epson Matte Paper-Heavyweight* |
|
Epson Matte |
Epson Photo Quality Ink Jet Paper* |
|
Epson Matte |
Plain paper* |
|
plain papers |
Envelope |
|
Envelope |
|
|
|
*These paper types are compatible with Exif Print and PRINT Image Matching when printed by the printer driver. For more information, see the documentation that came with the Exif Print or PRINT Image Matching compatible digital camera.
Loading Paper in the Rear Paper Feed
1.Open the feeder guard, extend the paper support, and then tilt it backwards.
2.Slide the edge guide to the left.
17
User's Guide
Loading Paper
3.Load paper vertically along the right side of the rear paper feed with the printable side facing up.
cImportant:
Do not load more than the maximum number of sheets specified for the paper. For plain paper, do not load above the line indicated by the triangle symbol on the edge guide.
Envelopes
Pre-punched paper
Note:
Load a single sheet of paper without binding holes at the top or the bottom.
Adjust the print position of your file to avoid printing over the holes.
18
User's Guide
Loading Paper
4.Slide the edge guide to the edge of the paper, and then close the feeder guard.
5.Slide out the output tray.
Note:
Return the remaining paper to its package. If you leave it in the printer, the paper may curl or the print quality may decline.
Related Information
&“Paper Handling Precautions” on page 15
&“Available Paper and Capacities” on page 16
19
User's Guide
Placing Originals on the Scanner Glass
Placing Originals on the Scanner Glass
cImportant:
When placing bulky originals such as books, prevent exterior light from shining directly onto the scanner glass.
1.Open the document cover.
2.Remove any dust or stains on the scanner glass.
3.Place the original face-down and slide it to the corner mark.
Note:
A range of 1.5 mm from the edges of the scanner glass is not scanned.
4.Close the cover gently.
5.Remove the originals after scanning.
Note:
If you leave the originals on the scanner glass for a long time, they may stick to the surface of the glass.
20
User's Guide
Placing Originals on the Scanner Glass
Placing Multiple Photos for Scanning at the Same Time
You can scan multiple photos at the same time and save each image in Photo Mode in Epson Scan 2 when you select Thumbnail from the list at the top of the preview window. Place the photos 4.5 mm away from the horizontal and vertical edges of the scanner glass, and place them at least 20 mm apart from each other. The photos should be larger than 15×15 mm.
21
User's Guide
Printing
Printing
Printing from a Computer
Printing Basics - Windows
Note:
See the online help for explanations of the setting items. Right-click an item, and then click Help.
Operations differ depending on the application. See the application's help for details.
1.Load paper in the printer.
2.Open the file you want to print.
3.Select Print or Print Setup from the File menu.
4.Select your printer.
5.Select Preferences or Properties to access the printer driver window.
6.Make the following settings.
Document Size: Select the paper size you loaded in the printer.
Borderless: Select to print with no margins around the image.
In borderless printing, the print data is enlarged slightly more than the paper size so that no margins are printed around the edges of the paper. Click Settings to select the amount of enlargement.
Orientation: Select the orientation you set in the application.
Paper Type: Select the type of paper you loaded.
22
User's Guide
Printing
Quality: Select the print quality.
Selecting High provides higher quality printing, but the printing speed may be slower.
Color: Select Grayscale when you want to print in black or shades of gray.
Note:
When printing on envelopes, select Landscape as the Orientation setting.
7.Click OK to close the printer driver window.
8.Click Print.
Related Information
&“Available Paper and Capacities” on page 16
&“Loading Paper in the Rear Paper Feed” on page 17
&“Guide to Windows Printer Driver” on page 61
&“List of Paper Types” on page 16
Printing Basics - Mac OS X
Note:
Explanations in the section use TextEdit as an example. Operations and screens differ depending on the application. See the application's help for details.
1.Load paper in the printer.
2.Open the file you want to print.
3.Select Print from the File menu or another command to access the print dialog. If necessary, click Show Details or d to expand the print window.
23
User's Guide
Printing
4.Make the following settings.
Printer: Select your printer.
Presets: Select when you want to use the registered settings.
Paper Size: Select the paper size you loaded in the printer. When printing with no margins, select a "borderless" paper size.
Orientation: Select the orientation you set in the application.
Note:
If the above setting menus are not displayed, close the print window, select Page Setup from the File menu, and then make settings.
When printing on envelopes, select landscape orientation.
5.Select Print Settings from the pop-up menu.
Note:
On Mac OS X v10.8.x or later, if the Print Settings menu is not displayed, the Epson printer driver has not been installed correctly.
Select System Preferences from the
menu > Printers & Scanners (or Print & Scan, Print & Fax), remove the printer, and then add the printer again. See the following to add a printer.
http://epson.sn
6.Make the following settings.
Media Type: Select the type of paper you loaded.
24
User's Guide
Printing
Print Quality: Select the print quality.
Selecting Fine provides higher quality printing, but the printing speed may be slower.
Expansion: Available when selecting a borderless paper size.
In borderless printing, the print data is enlarged slightly more than the paper size so that no margins are printed around the edges of the paper. Select the amount of enlargement.
Grayscale: Select to print in black or shades of gray.
7.Click Print.
Related Information
&“Available Paper and Capacities” on page 16
&“Loading Paper in the Rear Paper Feed” on page 17
&“Guide to Mac OS X Printer Driver” on page 64
&“List of Paper Types” on page 16
Printing on 2-Sides (for Windows only)
The printer driver prints automatically separating even pages and odd pages. When the printer has finished printing the odd pages, flip the paper over following the instructions to print the even pages. You can also print a booklet that can be created by folding the printout.
Note:
This feature is not available for borderless printing.
If you do not use paper that is suitable for 2-sided printing, the print quality may decline and paper jams may occur.
Depending on the paper and the data, ink may bleed through to the other side of the paper.
If EPSON Status Monitor 3 is disabled, access the printer driver, click Extended Settings on the Maintenance tab, and then select Enable EPSON Status Monitor 3.
2-sided printing may not be available when the printer is accessed over a network or is used as a shared printer.
1.Load paper in the printer.
2.Open the file you want to print.
3.Access the printer driver window.
25
User's Guide
Printing
4.Select Manual (Long-edge binding) or Manual (Short-edge binding) from 2-Sided Printing on the Main tab.
5.Click Settings, make the appropriate settings, and then click OK.
Note:
To print as a booklet, select Booklet.
6.Set the other items on the Main and More Options tabs as necessary, and then click OK.
7.Click Print.
When the first side has finished printing, a pop-up window is displayed on the computer. Follow the on-screen instructions.
Related Information
&“Available Paper and Capacities” on page 16
&“Loading Paper in the Rear Paper Feed” on page 17
&“Printing Basics - Windows” on page 22
Printing Several Pages on One Sheet
You can print two or four pages of data on a single sheet of paper.
Printing Several Pages on One Sheet - Windows
Note:
This feature is not available for borderless printing.
1.Load paper in the printer.
2.Open the file you want to print.
3.Access the printer driver window.
4.Select 2-Up or 4-Up as the Multi-Page setting on the Main tab.
26
User's Guide
Printing
5.Click Page Order, make the appropriate settings, and then click OK to close the window.
6.Set the other items on the Main and More Options tabs as necessary, and then click OK.
7.Click Print.
Related Information
&“Loading Paper in the Rear Paper Feed” on page 17
&“Printing Basics - Windows” on page 22
Printing Several Pages on One Sheet - Mac OS X
1.Load paper in the printer.
2.Open the file you want to print.
3.Access the print dialog.
4.Select Layout from the pop-up menu.
5.Set the number of pages in Pages per Sheet, the Layout Direction (page order), and Border.
6.Set the other items as necessary.
7.Click Print.
Related Information
&“Loading Paper in the Rear Paper Feed” on page 17
&“Printing Basics - Mac OS X” on page 23
Printing to Fit the Paper Size
You can print to fit the paper size you loaded in the printer.
27
User's Guide
Printing
Printing to Fit the Paper Size - Windows
Note:
This feature is not available for borderless printing.
1.Load paper in the printer.
2.Open the file you want to print.
3.Access the printer driver window.
4.Make the following settings on the More Options tab.
Document Size: Select the paper size you set in the application.
Output Paper: Select the paper size you loaded in the printer.
Fit to Page is selected automatically.
Note:
If you want to print a reduced image at the center of the page, select Center.
5.Set the other items on the Main and More Options tabs as necessary, and then click OK.
6.Click Print.
Related Information
&“Loading Paper in the Rear Paper Feed” on page 17
&“Printing Basics - Windows” on page 22
Printing to Fit the Paper Size - Mac OS X
1.Load paper in the printer.
2.Open the file you want to print.
3.Access the print dialog.
4.Select the size of the paper you set in the application as the Paper Size setting.
5.Select Paper Handling from the pop-up menu.
6.Select Scale to fit paper size.
7.Select the paper size you loaded in the printer as the Destination Paper Size setting.
8.Set the other items as necessary.
9.Click Print.
Related Information
&“Loading Paper in the Rear Paper Feed” on page 17
&“Printing Basics - Mac OS X” on page 23
28
User's Guide
Printing
Printing Multiple Files Together (for Windows Only)
Job Arranger Lite allows you to combine several files created by different applications and print them as a single print job. You can specify the print settings for combined files, such as layout, print order, and orientation.
1.Load paper in the printer.
2.Open the file you want to print.
3.Access the printer driver window.
4.Select Job Arranger Lite on the Main tab.
5.Click OK to close the printer driver window.
6.Click Print.
The Job Arranger Lite window is displayed and the print job is added to the Print Project.
7.With the Job Arranger Lite window opened, open the file that you want to combine with the current file, and then repeat steps 3 to 6.
Note:
If you close the Job Arranger Lite window, the unsaved Print Project is deleted. To print later, select Save from the File menu.
To open a Print Project saved in Job Arranger Lite, click Job Arranger Lite on the printer driver's Maintenance tab. Next, select Open from the File menu to select the file. The extension of the saved files is "ecl".
8.Select the Layout and Edit menus in Job Arranger Lite to edit the Print Project as necessary. See the help of Job Arranger Lite for details.
9.Select Print from the File menu.
Related Information
&“Loading Paper in the Rear Paper Feed” on page 17
&“Printing Basics - Windows” on page 22
29
User's Guide
Printing
Printing One Image on Multiple Sheets to Create a Poster (for Windows Only)
This feature allows you to print one image on multiple sheets of paper. You can create a larger poster by taping them together.
Note:
This feature is not available for borderless printing.
1.Load paper in the printer.
2.Open the file you want to print.
3.Access the printer driver window.
4.Select 2x1 Poster, 2x2 Poster, 3x3 Poster, or 4x4 Poster from Multi-Page on the Main tab.
5.Click Settings, make the appropriate settings, and then click OK.
Note:
Print Cutting Guides allows you to print a cutting guide.
6.Set the other items on the Main and More Options tabs as necessary, and then click OK.
7.Click Print.
Related Information
&“Loading Paper in the Rear Paper Feed” on page 17
&“Printing Basics - Windows” on page 22
30
