Epson EcoTank ET-M3170 User Manual

ET-M3170 User's Guide

Contents
ET-M3170 User's Guide.............................................................................................................................	13
Product Basics ..........................................................................................................................................	14
Using the Control Panel .....................................................................................................................	14
Control Panel Buttons and Lights ..................................................................................................	15
The LCD Screen .......................................................................................................................	16
Status Icon Information .............................................................................................................	16
Entering Characters on the LCD Screen .......................................................................................	17
Viewing Animations .......................................................................................................................	19
Changing LCD Screen Language..................................................................................................	21
Selecting the Date and Time .........................................................................................................	22
Selecting Your Country or Region .................................................................................................	23
Adjusting Control Panel Sounds ....................................................................................................	24
Preventing PC Connection via USB ..............................................................................................	25
Adjusting the Screen Brightness....................................................................................................	26
Product Parts Locations .....................................................................................................................	26
Product Parts - Front .....................................................................................................................	27
Product Parts - Inside ....................................................................................................................	29
Product Parts - Back......................................................................................................................	30
Using Power Saving Settings .............................................................................................................	30
Changing the Sleep Timer Settings ...............................................................................................	31
Changing the Power Off Timer Settings ........................................................................................	32
Epson Connect Solutions for Smartphones, Tablets, and More .........................................................	32
Setting Up Epson Connect Services..............................................................................................	33
Using Epson Email Print ...............................................................................................................	34
Using the Epson iPrint Mobile App ................................................................................................	35
Using Epson Remote Print ...........................................................................................................	35
Using Epson Scan to Cloud...........................................................................................................	36
Using AirPrint ....................................................................................................................................	37
Using Google Cloud Print...................................................................................................................	37
Setting Up Google Cloud Print on a Chromebook .........................................................................	38

3

Android Printing Using the Epson Print Enabler ................................................................................	39
Using the Mopria Print Service ..........................................................................................................	40
Using Fire OS Printing .......................................................................................................................	40
Using Windows 10 Mobile Printing ....................................................................................................	41
Using Epson Print and Scan App with Windows Tablets ...................................................................	41
Voice-activated Printing .....................................................................................................................	42
Wi-Fi or Wired Networking........................................................................................................................	43
Network Security Recommendations .................................................................................................	43
Wi-Fi Infrastructure Mode Setup.........................................................................................................	44
Selecting Wireless Network Settings from the Control Panel ........................................................	45
Wi-Fi Direct Mode Setup ....................................................................................................................	48
Connecting to a Mobile Device ......................................................................................................	48
Enabling Wi-Fi Direct Mode (Simple AP) .......................................................................................	50
Modifying the Wi-Fi Direct Network Name or Password ................................................................	51
Wi-Fi Protected Setup (WPS).............................................................................................................	53
Using WPS to Connect to a Network .............................................................................................	53
Printing a Network Status Sheet.........................................................................................................	54
Printing a Network Connection Report ...............................................................................................	55
Network Connection Report Codes and Messages .......................................................................	57
Changing or Updating Network Connections .....................................................................................	62
Accessing the Web Config Utility...................................................................................................	63
Changing a USB Connection to a Wi-Fi Connection......................................................................	63
Changing a Wi-Fi Connection to a Wired Network Connection......................................................	63
Connecting to a New Wi-Fi Router ................................................................................................	64
Disabling Wi-Fi Features ...............................................................................................................	65
Loading Paper ...........................................................................................................................................	66
Loading Paper in the Cassette ...........................................................................................................	66
Loading Paper in the Rear Paper Feed Slot .......................................................................................	72
Paper Loading Capacity .....................................................................................................................	75
Double-sided Printing Capacity ..........................................................................................................	77
Compatible Epson Papers..................................................................................................................	78
Paper or Media Type Settings - Printing Software..............................................................................	79
Selecting the Paper Settings - Control Panel .....................................................................................	79

4

Paper or Media Type Settings - Control Panel...............................................................................	80
Selecting the Default Paper Source Settings......................................................................................	81
Paper Source Settings Options .....................................................................................................	81
Placing Originals on the Product .............................................................................................................	83
Placing Originals on the Scanner Glass .............................................................................................	83
Placing Originals in the Automatic Document Feeder ........................................................................	85
ADF Original Document Specifications..........................................................................................	88
Copying......................................................................................................................................................	90
Copying Documents or Photos...........................................................................................................	90
Copying Options.................................................................................................................................	91
Printing from a Computer .........................................................................................................................	93
Printing with Windows ........................................................................................................................	93
Selecting Basic Print Settings - Windows ......................................................................................	94
Paper Source Options - Windows .............................................................................................	96
Print Quality Options - Windows ...............................................................................................	96
Multi-Page Printing Options - Windows.....................................................................................	96
Selecting Double-sided Printing Settings - Windows .....................................................................	97
Double-sided Printing Options - Windows.................................................................................	99
Print Density Adjustments - Windows .....................................................................................	100
Selecting Additional Layout and Print Options - Windows ...........................................................	101
Custom Tone Correction Options - Windows ..........................................................................	103
Image Options and Additional Settings - Windows..................................................................	104
Header/Footer Settings - Windows .........................................................................................	104
Selecting a Printing Preset - Windows.........................................................................................	105
Selecting Extended Settings - Windows ......................................................................................	107
Extended Settings - Windows .................................................................................................	108
Printing Your Document - Windows.............................................................................................	109
Locking Printer Settings - Windows .............................................................................................	110
Locked Setting Options...........................................................................................................	112
Selecting Default Print Settings - Windows..................................................................................	113
Changing the Language of the Printer Software Screens .......................................................	114
Changing Automatic Update Options ..........................................................................................	115
Printing with the Built-in Epson Driver - Windows 10 S.....................................................................	116

5

Selecting Print Settings - Windows 10 S......................................................................................	116
Printing on a Mac .............................................................................................................................	120
Selecting Basic Print Settings - Mac ...........................................................................................	121
Paper Source Options - Mac...................................................................................................	124
Print Quality Options - Mac .....................................................................................................	124
Selecting Page Setup Settings - Mac ..........................................................................................	125
Selecting Print Layout Options - Mac...........................................................................................	126
Selecting Double-sided Printing Settings - Mac...........................................................................	126
Double-sided Printing Options and Adjustments - Mac...........................................................	128
Selecting Printing Preferences - Mac ..........................................................................................	128
Printing Preferences - Mac......................................................................................................	129
Printing Your Document - Mac.....................................................................................................	130
Checking Print Status - Mac....................................................................................................	131
Printing From a Chromebook ...........................................................................................................	131
Cancelling Printing Using a Product Button......................................................................................	132
Scanning ..................................................................................................................................................	133
Starting a Scan.................................................................................................................................	133
Starting a Scan Using the Product Control Panel ........................................................................	133
Scanning to a Connected Computer .......................................................................................	134
Scanning to the Cloud.............................................................................................................	136
Setting Up a WSD Port (Windows 7/Windows Vista) ..............................................................	138
Changing Default Scan Job Settings ......................................................................................	139
Starting a Scan Using the Epson Scan 2 Icon .............................................................................	139
Starting a Scan from a Scanning Program...................................................................................	142
Starting a Scan from a Smart Device...........................................................................................	144
Scanning in Epson Scan 2 ...............................................................................................................	144
Additional Scanning Settings - Main Settings Tab .......................................................................	147
Additional Scanning Settings - Advanced Settings Tab...............................................................	147
Saving Scanned Documents as a Searchable PDF Using Epson Scan 2 ...................................	148
Image Format Options.................................................................................................................	150
Scan Resolution Guidelines ........................................................................................................	151
Faxing.......................................................................................................................................................	152
Connecting a Telephone or Answering Machine..............................................................................	152

6

Setting Up Fax Features ..................................................................................................................	156
Setting Up Basic Fax Features ....................................................................................................	156
Using the Fax Setup Wizard ...................................................................................................	156
Selecting the Line Type...........................................................................................................	158
Setting the Number of Rings to Answer ..................................................................................	159
Selecting Advanced Fax Settings ................................................................................................	160
Receive Settings - Fax............................................................................................................	161
Report Settings - Fax ..............................................................................................................	163
Basic Settings - Fax ................................................................................................................	163
Security Settings - Fax............................................................................................................	165
Setting Up the Fax Utility - Windows............................................................................................	166
Setting Up Fax Features Using the Fax Utility - Mac ...................................................................	168
Setting Up Contacts and Contact Groups.........................................................................................	169
Setting Up Contacts Using the Product Control Panel.................................................................	170
Creating a Contact ..................................................................................................................	170
Editing or Deleting a Contact ..................................................................................................	172
Creating a Contact Group .......................................................................................................	173
Editing or Deleting a Contact Group........................................................................................	175
Importing Contacts Using the Fax Utility - Windows ....................................................................	176
Setting Up Speed/Group Dial Lists Using the Fax Utility - Mac....................................................	179
Sending Faxes .................................................................................................................................	181
Sending Faxes from the Product Control Panel...........................................................................	181
Sending a Fax Using the Control Panel ..................................................................................	182
Fax Sending Options ..............................................................................................................	184
Sending a Fax at a Specified Time .........................................................................................	185
Dialing Fax Numbers from a Connected Telephone ...............................................................	187
Sending Faxes Using the Fax Utility - Windows ..........................................................................	187
Sending Faxes Using the Fax Utility - Mac ..................................................................................	190
Receiving Faxes...............................................................................................................................	193
Fax Reception .............................................................................................................................	193
Receiving Faxes Automatically ...................................................................................................	194
Receiving Faxes Manually...........................................................................................................	194
Receiving a Fax by Polling ..........................................................................................................	195

7

Saving and Viewing Received Faxes ..........................................................................................	196
Selecting Received Fax Options Using the Fax Utility - Windows ...............................................	197
Checking Fax Status .......................................................................................................................	200
Printing Fax Reports.........................................................................................................................	201
Fax Report Options .....................................................................................................................	201
Refilling Ink and Replacing the Maintenance Box ................................................................................	203
Ink Safety Precautions .....................................................................................................................	203
Checking the Ink and Maintenance Box Levels................................................................................	205
Checking the Ink Level on Your Product......................................................................................	205
Checking Maintenance Box Status on the LCD Screen...............................................................	206
Checking Ink and Maintenance Box Levels - Windows ...............................................................	206
Checking Ink and Maintenance Box Levels - Mac .......................................................................	208
Disabling Special Offers with Windows .......................................................................................	210
Purchase Epson Ink and Maintenance Box......................................................................................	211
Ink Bottle and Maintenance Box Part Numbers ...........................................................................	212
Refilling the Ink Tank........................................................................................................................	212
Maintenance Box Replacement .......................................................................................................	217
Adjusting Print Quality............................................................................................................................	219
Print Head Maintenance...................................................................................................................	219
Print Head Nozzle Check.............................................................................................................	219
Checking the Nozzles Using the Product Control Panel .........................................................	220
Checking the Nozzles Using a Computer Utility......................................................................	223
Print Head Cleaning ....................................................................................................................	226
Cleaning the Print Head Using the Product Control Panel ......................................................	226
Cleaning the Print Head Using a Computer Utility...................................................................	228
Power Cleaning ...........................................................................................................................	231
Power Cleaning Using the Product Control Panel...................................................................	231
Power Cleaning Using a Computer Utility ...............................................................................	232
Print Head Alignment .......................................................................................................................	234
Aligning the Print Head Using the Product Control Panel ............................................................	234
Cleaning the Paper Guide ................................................................................................................	235
Cleaning the Print Head Path ...........................................................................................................	236
Checking the Number of Sheets.......................................................................................................	239

8

Checking the Sheet Counter - Windows ......................................................................................	240
Checking the Sheet Counter - Mac..............................................................................................	241
Cleaning and Transporting Your Product .............................................................................................	242
Cleaning Your Product .....................................................................................................................	242
Cleaning the Paper Rollers ..............................................................................................................	246
Transporting Your Product ...............................................................................................................	248
Solving Problems ....................................................................................................................................	253
Checking for Software Updates........................................................................................................	253
Product Status Messages ................................................................................................................	254
Message Appears Prompting You to Reset the Ink Level ................................................................	255
Running a Product Check ................................................................................................................	256
Resetting Control Panel Defaults .....................................................................................................	258
Solving Setup Problems ...................................................................................................................	258
Product Does Not Turn On or Off.................................................................................................	259
Noise After Filling the Ink.............................................................................................................	259
Software Installation Problems ....................................................................................................	259
Solving Network Problems ...............................................................................................................	260
Product Cannot Connect to a Wireless Router or Access Point ..................................................	260
Network Software Cannot Find Product on a Network.................................................................	262
Product Does Not Appear in Mac Printer Window .......................................................................	263
Wireless Network Connection is Unstable on a Mac ...................................................................	263
Wired Network Connection Becomes Unstable...........................................................................	264
Cannot Print Over a Network.......................................................................................................	264
Cannot Scan Over a Network ......................................................................................................	266
Solving Copying Problems ...............................................................................................................	267
Product Makes Noise, But Nothing Copies..................................................................................	267
Product Makes Noise When It Sits for a While.............................................................................	268
Solving Paper Problems...................................................................................................................	268
Paper Feeding Problems.............................................................................................................	268
Paper Jam Problems in the Front of the Product .........................................................................	269
Paper Jam Problems Inside the Product .....................................................................................	271
Paper Jam Problems in the Rear Cover ......................................................................................	272
Paper Jams in the Automatic Document Feeder .........................................................................	275

9

Paper Ejection Problems .............................................................................................................	278
Solving Problems Printing from a Computer.....................................................................................	279
Nothing Prints..............................................................................................................................	279
Product Icon Does Not Appear in Windows Taskbar ...................................................................	280
Printing is Slow ............................................................................................................................	281
Solving Page Layout and Content Problems....................................................................................	282
Inverted Image.............................................................................................................................	283
Too Many Copies Print ................................................................................................................	283
Blank Pages Print ........................................................................................................................	283
Incorrect Margins on Printout.......................................................................................................	284
Incorrect Characters Print............................................................................................................	285
Incorrect Image Size or Position..................................................................................................	285
Slanted Printout...........................................................................................................................	286
Solving Print Quality Problems.........................................................................................................	286
White or Dark Lines in Printout ....................................................................................................	287
Blurry or Smeared Printout ..........................................................................................................	288
Faint Printout or Printout Has Gaps .............................................................................................	290
Grainy Printout.............................................................................................................................	291
Solving Scanning Problems .............................................................................................................	292
Scanning Software Does Not Operate Correctly .........................................................................	292
Cannot Start Epson Scan 2 .........................................................................................................	293
Scanning is Slow .........................................................................................................................	294
Solving Scanned Image Quality Problems .......................................................................................	294
Image Consists of a Few Dots Only.............................................................................................	294
Line of Dots Appears in All Scanned Images...............................................................................	295
Straight Lines in an Image Appear Crooked ................................................................................	295
Image is Distorted or Blurry .........................................................................................................	295
Image Colors are Patchy at the Edges ........................................................................................	296
Image is Too Dark .......................................................................................................................	296
Back of Original Image Appears in Scanned Image ....................................................................	296
Ripple Patterns Appear in an Image ............................................................................................	296
Scanned Image Colors Do Not Match Original Colors.................................................................	297
Scanned Image Edges are Cropped ...........................................................................................	297

10

Characters are Not Recognized During Conversion to Editable Text (OCR)...............................	297
Solving Faxing Problems..................................................................................................................	298
Cannot Send or Receive Faxes...................................................................................................	298
Cannot Receive Faxes with a Telephone Connected to Your Product ........................................	300
Fax Memory Full Error Appears...................................................................................................	301
Fax Quality is Poor ......................................................................................................................	301
Sent Fax is Received in an Incorrect Size ...................................................................................	302
Received Fax is Not Printed ........................................................................................................	302
Uninstall Your Product Software.......................................................................................................	303
Uninstalling Product Software - Windows....................................................................................	303
Uninstalling Product Software - Mac............................................................................................	304
Where to Get Help............................................................................................................................	305
Technical Specifications ........................................................................................................................	306
Windows System Requirements ......................................................................................................	306
Mac System Requirements ..............................................................................................................	307
Paper Specifications ........................................................................................................................	308
Printable Area Specifications ...........................................................................................................	309
Scanning Specifications ...................................................................................................................	310
Fax Specifications ............................................................................................................................	311
Automatic Document Feeder (ADF) Specifications ..........................................................................	312
Ink Specifications .............................................................................................................................	313
Dimension Specifications .................................................................................................................	313
Electrical Specifications ...................................................................................................................	314
Environmental Specifications ...........................................................................................................	314
Interface Specifications ....................................................................................................................	314
Network Interface Specifications ......................................................................................................	315
Safety and Approvals Specifications ................................................................................................	316
Notices .....................................................................................................................................................	317
Important Safety Instructions............................................................................................................	317
General Product Safety Instructions ............................................................................................	317
LCD Screen Safety Instructions...................................................................................................	319
Wireless Connection Safety Instructions .....................................................................................	319
Telephone Equipment Safety Instructions ...................................................................................	320

11

FCC Compliance Statement.............................................................................................................	320
Binding Arbitration and Class Waiver ...............................................................................................	323
Trademarks......................................................................................................................................	326
Copyright Notice...............................................................................................................................	327
libTIFF Software Acknowledgment..............................................................................................	327
A Note Concerning Responsible Use of Copyrighted Materials...................................................	328
Default Delay Times for Power Management for Epson Products ...............................................	328
Copyright Attribution....................................................................................................................	328

12

ET-M3170 User's Guide

Welcome to the ET-M3170 User's Guide.

For a printable PDF copy of this guide, click here.

13

Product Basics

See these sections to learn about the basic features of your product.

Using the Control Panel

Product Parts Locations

Using Power Saving Settings

Epson Connect Solutions for Smartphones, Tablets, and More

Using AirPrint

Using Google Cloud Print

Android Printing Using the Epson Print Enabler

Using the Mopria Print Service

Using Fire OS Printing

Using Windows 10 Mobile Printing

Using Epson Print and Scan App with Windows Tablets

Voice-activated Printing

Using the Control Panel

See these sections to learn about the control panel and select control panel settings.

Control Panel Buttons and Lights

Entering Characters on the LCD Screen

Viewing Animations

Changing LCD Screen Language

Selecting the Date and Time

Selecting Your Country or Region

Adjusting Control Panel Sounds

Preventing PC Connection via USB

Adjusting the Screen Brightness

Parent topic: Product Basics

14

Control Panel Buttons and Lights

1 power button and light

2 home button

3 LCD screen

4 help button

5 received fax light

The LCD Screen

Status Icon Information

Parent topic: Using the Control Panel

15

The LCD Screen

1Displays various status information; select an icon to check its status or adjust its settings

2Menu options

3Select a tab to view different options and settings

4Setting options

5Select to perform an action

Parent topic: Control Panel Buttons and Lights

Status Icon Information

Your product displays status icons on the LCD screen for certain product status conditions.

Icons Description

Displays the Supply Status screen.

16

Icons	Description
	Displays the network connection status; select the icon to set up or change your network
	connection.
	•	The product is not connected to a wired (Ethernet) network.
	•	The product is connected to a wired (Ethernet) network.
	•	The product is not connected to a wireless network.
	•	The product is searching for an SSID or experiencing a wireless network
		connection issue.
	•	The product is connected to a wireless network; the number of bars indicates the
		connection's signal strength.
	•	Wi-Fi Direct is not enabled.
	•	Wi-Fi Direct is enabled.
	The Quiet Mode setting is enabled or disabled. Select the icon to change the setting.
	Depending on the selected paper type and print quality, when this feature is enabled noise
	is reduced during printing, but print speed may also be reduced.
	Displays the number of received faxes that are waiting to be read, printed, or saved.
	Displays the Fax Data Information screen.
	Displays additional information or instructions, such as loading paper or placing a
	document on the scanner; select the icon to display the information.
	There is a problem with the indicated setting; select the icon for information on resolving
	the problem.

Parent topic: Control Panel Buttons and Lights

Entering Characters on the LCD Screen

Follow these guidelines to enter characters for passwords and other settings.

17

On-screen keyboard

1Displays the character count

2Moves the cursor left or right

3Switches between uppercase and lowercase characters

4Switches between characters and numbers or symbols

5Changes the keyboard layout

6Displays a list of common domain names to choose from

7Enters a space

8Select when you are finished

9Deletes the previous character

18

Numeric keypad

1Cancels entry and closes the keypad

2Select when you are finished

3Clears the entered number

4Deletes the previous number

Parent topic: Using the Control Panel

Viewing Animations

You can view animations on the LCD screen to help guide you with a procedure or to troubleshoot a problem.

1. Press the help button.

19

You see a screen like this:

2.Select Troubleshooting if you are experiencing a problem or How To to view instructions on common procedures.

3.Select a topic from the list of available topics and follow the on-screen instructions. While viewing the topics, you may see screens like this:

1Displays the current step number and the total number of steps

2Select the left arrow to view the previous step

20

3Indicates your overall progress through the animation

4Select the right arrow to view the next step

Parent topic: Using the Control Panel

Changing LCD Screen Language

You can change the language used on the LCD screen. 1. Press the home button, if necessary.

2. Select Settings.

You see a screen like this:

3.Select General Settings.

4.Select Basic Settings.

5.Scroll down and select Language.

6.	Select a language.
7.	Press the	home icon to exit.

Parent topic: Using the Control Panel

21

Selecting the Date and Time

Select the current date, time, and daylight saving phase in your area, and choose your preferred date and time format.

1. Press the home button, if necessary.

2. Select Settings.

You see a screen like this:

3.Select General Settings.

4.Select Basic Settings.

5.Select Date/Time Settings.

6.Select Daylight Saving Time.

7.Select the setting that applies to your area:

•Winter: it is winter or your region does not use Daylight Saving Time (DST)

•Summer: it is spring or summer and your region uses Daylight Saving Time (DST)

Note: If your region uses Daylight Saving Time (DST), you must change this setting to match the season. When you change from Winter to Summer, your product automatically sets its clock ahead one hour. When you change from Summer to Winter, it sets its clock back one hour.

8. Select Date/Time.

22

9.Select the date format you want to use.

10.Use the numeric keypad to enter the current date, then select OK.

11.Select the time format you want to use.

12.Use the numeric keypad to enter the current time, then select OK.

13.Select Time Difference.

14.Use the + and - buttons to enter the time difference between your time zone and UTC (Coordinated Universal Time), then select OK.

Parent topic: Using the Control Panel

Selecting Your Country or Region

Before using your product, select the country or region in which you are using your product.

Note: If you change the country or region, your fax settings return to their defaults and you must select them again. This setting can be locked by an administrator. If you cannot access or change this setting, contact your administrator for assistance.

1. Press the home button, if necessary.

2. Select Settings.

You see a screen like this:

3. Select General Settings.

23

4.Select Basic Settings.

5.Select Country/Region.

6.Scroll up or down, if necessary, and select your country or region. You see a confirmation screen.

7.If the setting is correct, select Yes. (If not, select No and retry.)

Parent topic: Using the Control Panel

Adjusting Control Panel Sounds

You can adjust the sound level heard when you press buttons on the control panel.

1.	Press the	home button, if necessary.
2.	Select Settings.
	You see a screen like this:

3.Select General Settings.

4.Select Basic Settings.

5.Select Sound.

6.Do one of the following:

• To mute all control panel sounds, turn the Mute setting off.

24

• To select a specific sound level, select Normal Mode or Quiet Mode.

Note: You can also select the icon on the home screen to switch between Normal Mode and Quiet Mode.

7.Scroll down and select Button Press.

8.Select the – or + icon to decrease or increase the sound.

9.Select OK to exit.

Note: You can also adjust the level for various product functions.

Parent topic: Using the Control Panel

Preventing PC Connection via USB

You can disable access to your product from a USB-connected computer. This restricts non-network access to the product.

1.	Press the	home button, if necessary.
2.	Select Settings.
	You see a screen like this:

3.Select General Settings.

4.Select Printer Settings.

25

5.Scroll down and select PC Connection via USB.

6.Select Disable.

Parent topic: Using the Control Panel

Adjusting the Screen Brightness

You can adjust the brightness of theLCD screen. 1. Press the home button, if necessary.

2. Select Settings.

You see a screen like this:

3.Select General Settings.

4.Select Basic Settings.

5.Select LCD Brightness.

6.Select the – or + icon to decrease or increase the brightness.

7.Select OK to exit.

Parent topic: Using the Control Panel

Product Parts Locations

See these sections to identify the parts on your product.

26

Product Parts - Front

Product Parts - Inside

Product Parts - Back

Parent topic: Product Basics

Product Parts - Front

1Automatic Document Feeder (ADF)

2ADF cover

3ADF input tray

4ADF edge guide

5ADF document support

27

6 ADF output tray

1Control panel

2Ink tank cover

3Ink tank

4Paper cassette cover

5Front cover

6Output tray

Parent topic: Product Parts Locations

28

Product Parts - Inside

1Document cover

2Scanner glass

3Print head

4Edge guide

5Paper cassette

6Output selector

7Printer cover

Parent topic: Product Parts Locations

29

Product Parts - Back

1Output tray stopper

2LAN port

3USB port

4LINE port

5EXT port

6AC inlet

7Rear paper feed slot

8Rear cover

9Maintenance box cover

Parent topic: Product Parts Locations

Using Power Saving Settings

Your product enters sleep mode automatically and turns off the LCD screen if it is not used for a period of time. You can make the time period shorter and select other options to save energy and resources.

Changing the Sleep Timer Settings

30
