SAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
This unit should be used with 120 V AC only.
CAUTION:
To prevent electric shocks and fire hazards, DO NOT use any other power source.
NOTE:
The rating plate (serial number plate) is on the rear of the unit.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
CAUTION
To assure continued compliance follow the attached installation instructions and do not make any unauthorized modificaitons.
THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE B EST
CONFORME À LA NORME NMB-003 DU CANADA.
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR
ATTENTION: POUR EVITER TOUT RISQUE D’ELECTROCUTION NE PAS OUVRIR LE BOITER.
AUCUNE PIECE INTERIEURE N’EST
A REGLER PAR L’UTILISATEUR.
SE REFERER A UN AGENT QUALIFIE EN CAS DE PROBLEME.
Le symbole de l’éclair à l’intérieur d’un triangle équilatéral est destiné à alerter l’utilisateur sur la présence d’une “tension dangereuse” non isolée dans le boîtier du produit. Cette tension est suffisante pour provoquer l’électrocution de personnes.
Le point d’exclamation à l’intérieur d’un triangle équilatéral est destiné à alerter l’utilisateur sur la présence d’opérations d’entretien importantes au sujet desquelles des renseignements se trouvent dans le manuel d’instructions.
*Ces symboles ne sont utilisés qu’aux Etats-Unis.
AVERTISSEMENT:
POUR EVITER LES RISQUES D’INCENDIE OU D’ELECTROCUTION, NE PAS EXPOSER L’APPAREIL A L’HUMIDITE OU A LA PLUIE.
Ce magnétoscope ne doit être utilisé que sur du courant alternatif en 120 V.
ATTENTION:
Afin d’éviter tout resque d’incendie ou d’électrocution, ne pas utiliser d’autres sources d’alimentation électrique.
REMARQUE:
La plaque d’identification (numéro de série) se trouve sur le panneau arrière de l’appareil.
WARNING:
The battery used in the AG-TL950P must be replaced by a PANASONIC authorized service dealer only.
AVERTISSEMENT:
La pile utilisée dans l’AG-TL950P ne devra être remplacée que par un service après-vente PANASONIC agréé.
CAUTION:
Do not install or place this unit in a bookcase, built-in cabinet or in another confined space in order to keep well ventilation condition. Ensure that curtains and any other materials do not obstruct the ventilation condition to prevent risk of electric shock or fire hazard due to overheating.
ATTENTION:
Ne pas installer cet appareil dans une bibliothèque, un meuble fermé ou autres endroits renfermés. Installer l’appareil dans un endroit bien ventilé. S’assurer qu’aucun rideau ou autre matériel ne bouche la ventilation du lecteur de cassetie vidéo afin de prévenir tout risque de chocs électriques ou de dangers d’incendie dû au surchauffement.
2
OPERATION LOCK
By engaging the operation lock system [LOCK], you can prevent accidental or deliberate interference with recording operation or power supply.
When this function is activated, all operation buttons are disabled.
REC
POWER |
STOP |
|
|
|
EJECT |
|
|
|
|
|
|
POWER |
|
|
REC REVIEW REC |
|
|
|
|
HDR |
RESET/ |
|
|
|
|
|
|
|
|
||
|
|
|
|
|
CANCEL |
ON SCREEN |
|
PAUSE/ |
|
|
|
|
|
SHIFT |
|
/REW REV PLAY STILL |
PLAY FF/ |
TRACKING |
V. LOCK |
TIMER SEARCH COUNTER LOCK CNT RESET |
|
|
|
MENU |
TIME MODE |
|
|||||
|
|
|
|||||
|
|
|
|
|
|
SET |
AG- |
REV ADV |
FWD ADV |
|
|
|
|
|
|
|
|
|
|
|
|
“LOCK” indicator |
|
[LOCK] button |
[TIME MODE+/–] button |
|
|
1 Engage the mode you want to lock (such as the Rec or Play mode). |
|
|
|
||
|
|
||
|
|
2 While pressing the [LOCK] button, press the [TIME MODE+/–] button. “LOCK” is shown on the display, indicating |
|
|
|
||
|
|
||
” |
that the Operation Lock mode is engaged. |
||
3 To unlock the VCR, press the [TIME MODE+/–] button while pressing the [LOCK] button. The “LOCK” indication on |
|||
|
|
the display disappears and the unit can now be operated normally.
To prevent unauthorized use, detach this page and keep it in a safe place.
3
4
CONTENTS
1 INTRODUCTION
1-1 |
Major Features ............................................. |
6 |
1-2 |
Periodical Maintenance................................ |
7 |
1-3 |
Precautions .................................................. |
7 |
1-4 |
Daily Inspection............................................ |
8 |
1-5 Regarding S-VHS ET Rcording ................... |
8 |
2 CONTROLS AND CONNECTORS
2-1 |
Front Panel |
.................................................. 9 |
2-2 |
Display ....................................................... |
11 |
2-3 |
Rear Panel ................................................. |
12 |
3 CONNECTIONS
3-1 |
Connecting to a Camera ............................ |
14 |
3-2 |
System Using Sequential Switcher ............ |
15 |
3-3 |
Connecting the Rear Panel Input/Output |
|
|
Terminal Connections ................................ |
16 |
4 ON-SCREEN/MENU SWITCHES
4-1 |
On-Screen Display ..................................... |
17 |
4-2 |
Main Menu Display .................................... |
18 |
4-3 Date and Time Setting ............................... |
19 |
|
4-4 |
Hour Meter Display .................................... |
20 |
4-5 |
Alarm Input/Power Loss Data Display ....... |
21 |
4-6 |
Menu Switch Setting .................................. |
22 |
4-7 Contents of Menu Switches ....................... |
23 |
5 PREPARATION
5-1 |
Cassette Loading/Unloading ...................... |
27 |
5-2 |
Recording/Playback Speed Mode |
|
|
Selection .................................................... |
28 |
6 RECORDING
6-1 |
Switch Setting During Recording ............... |
29 |
|
6-2 |
Recording Basic Operation ........................ |
30 |
|
6-3 |
Timer Recording ........................................ |
31 |
|
|
• |
Timer Recording Program Setting .......... |
31 |
|
• |
Holiday Timer Recording Setting ............ |
35 |
|
• |
Canceling/Changing Timer Recording |
|
|
|
Program .................................................. |
36 |
|
• |
Notes on Timer Recording ...................... |
37 |
6-4 |
Alarm Recording ........................................ |
38 |
|
6-5 |
Sensor Recording ...................................... |
40 |
|
6-6 |
Series Recording ....................................... |
41 |
|
6-7 |
Repeat Recording ...................................... |
43 |
|
6-8 |
Recording with External VCR Activation |
|
|
|
Signal ......................................................... |
44 |
|
6-9 |
How to Restore Recording After Power |
|
|
|
Failure ........................................................ |
45 |
|
6-10 |
External Timer Recording .......................... |
45 |
|
6-11 Tape End Buzzer ....................................... |
45 |
7PLAYBACK AND SPECIAL-EFFECTS PLAYBACK
7-1 |
Preparation ................................................ |
46 |
|
7-2 |
Playback .................................................... |
46 |
|
7-3 |
Special-Effects Playback ........................... |
47 |
|
|
• |
Still/Field Advance/Reverse Playback .... |
47 |
|
• |
Shuttle Search ........................................ |
48 |
7-4 Alarm Search/Date and Time Search ........ |
49 |
||
7-5 |
Repeat Playback ........................................ |
51 |
|
7-6 |
Counter Memory Function ......................... |
51 |
|
7-7 |
Tracking/V. Lock Adjustment ..................... |
52 |
|
7-8 |
QUASI-V .................................................... |
52 |
8 TROUBLESHOOTING
8-1 |
Error Indications ......................................... |
53 |
8-2 |
No Error Indication ..................................... |
54 |
9 APPENDIXES
9-1 |
Tape Reel Counter/Tape Remaining Time |
|
|
Table .......................................................... |
55 |
9-2 |
Rear Panel’s Inputs/Outputs ...................... |
56 |
9-3 |
Specifications ............................................. |
57 |
The AG-TL950P is a video cassette recorder able to execute timelapse recording with VHS cassettes.
Use only video cassettes bearing the or mark. This unit is designed for professional use.
Panasonic is not liable for compensation for loss or damage to recordings in the event this unit fails to record or play back properly because the unit malfunctions or a defective video cassette tape is used.
Please note that it may be unlawful to use any material recorded from TV broadcast programs or pre-recorded programs without the consent of the owner of copyright, except in cases where this material is recorded exclusively for personal use.
5
5S-VHS/S-VHS ET recording
S-VHS or S-VHS ET is employed as the recording mode. Employing the S-VHS ET recording mode enables recording with a horizontal resolution of 400 lines on a VHS cassette. The VHS mode is only available for playback.
5Extended timelapse recording for up to 960 hours
Recording times are selectable from 2 hours (SP mode), 6 hours (EP mode) and L12/L18/L24/24/48/72/120/168/ 240/480/960 (Timelapse mode) (when T-120 tape is used).
5High-resolution recording
Delivers horizontal resolution of more than 400 lines even in color mode.
*When a tape recorded on this unit is played back on another VCR, noise may appear on playback picture.
5High-density recording (HDR) function
Using the EP head, the tape is advanced at a fine pitch for timelapse recording. In this way, about three times more information is recorded in the same period than in conventional timelapse modes. While this results in some degradation of picture quality, the increased coverage allows you to analyze the development of a situation in greater detail. The actual recording duration on the tape is the same as that of an ordinary timelapse recording (select with menu switch <HIGH DENSITY REC>).
5Alarm recording function
When an alarm signal is input in the Record mode, the 2/6/L12/L18/L24/24/48-hour mode is automatically engaged. Alarm recording time can be selected from 5, 10, 15, 30, 60, 120, or 180 sec., to COUNTINUE, or set manually.
An index code is automatically recorded at the start point of the alarm recording for use as an alarm cue signal. Alarm recording points can be accessed quickly with the alarm search function.
5Sensor recording
Whenever an alarm signal is input in the Stop mode (Stop, Timer Recording Standby or Operating Off mode), the Record mode is automatically engaged.
5Time/date generator
Superimposes date, month, year, hour, minute and second on the image during recording. Also allows you to display the number of alarms, alarm time, and the number of the power failures on a monitor.
5Timer-recording function
Up to 8 programs can be set for daily, weekly, or weekday timer-recording. You can also set timer recording for up to 16 days a year by specifying the date (holidays, for example).
5Tape position search function
You can automatically search the start of an alarm recording or search for a recording made at a specified date and time.
5Recording check function
Recording conditions (quality) can be checked at any time during recording by pressing the REC REVIEW button.
5Operation lock system
The secret operation lock system prevents an accidental or deliberate interference with VCR operation.
5Camera switching signal output terminal
5Warning function
Error indications are shown on the front panel display. Error warnings include condensation and problems with cassette loading, cassette unloading, or the rotating system operation mode.
5Operating mode-off video throughout function
Even when the operating mode is off, the camera’s EE input can be output from the VCR.
5Series recording function
Two or more AG-TL950P can be connected for extended, long-term series recording. As the tape in each VCR reaches the end, the next unit in the series will automatically start recording.
5Time adjust function
With the IN/OUT terminal for time adjustment, the time difference can be set to “0” with multiple AG-TL950P connected. (adjustment time: 00:00/12:00)
5Digital hour meter display
5Repeat playback/recording
5Alarm recording, tape end and warning electronic buzzer
5Recording control with external activation signal
5Counter end function
5External timer connection
5Summer time compensation function
6
1 INTRODUCTION
This VCR incorporates precision mechanical parts which will collect dirt over time and ultimately deteriorate and wear out. Over long periods of use, dirt and dust accumulates on the heads, drums and tape transport mechanisms. Dust which penetrates the VCR (especially during outdoor use) also promotes the wear and deterioration of mechanical parts by causing poor contact between tape and heads. This also prevents the VCR from maintaining video and audio quality at high levels. To prevent wear and deterioration, clean the heads regularly using a head cleaning tape. However, because a head cleaning tape alone cannot clean the entire tape transport mechanism, this should also be inspected periodically to prevent any problems that could result from a sudden failure.
As replacement and adjustment of parts require advanced skills and specialized equipment, please contact the person in charge of professional video equipment at your nearest Panasonic-authorized service agent for servicing.
Monitoring Usage Time
The total operation time reached by an ordinary home VCR in 5 or 6 years may be reached by a professional VCR in as few as 5 or 6 months. Therefore, it is important that the total hours of operation be carefully monitored. An hour meter in the on-screen display (see page 20) shows the accumulated time. In the chart below, the hours accumulated in each month are shown in relation to the number of hours used per day. Times shown in the shaded area indicate that maintenance should be performed.
Usage |
|
|
|
|
|
time per |
1 month |
2 months |
3 months |
6 months |
12 months |
day |
|
|
|
|
|
2 hours |
60 |
120 |
180 |
360 |
720 |
|
|
|
|
|
|
8 hours |
240 |
480 |
720 |
1440 |
2880 |
12 hours |
360 |
720 |
1080 |
2160 |
4320 |
24 hours |
720 |
1440 |
2160 |
4320 |
8640 |
|
|
|
|
|
|
Periodic Maintenance
Check or replace the following mechanical parts according to the running time.
Running time |
1000H |
2000H |
3000H |
4000H |
|
|
|
|
|
Drum ass’y (including heads) |
^ |
|
|
|
|
|
|
|
|
Pinch rollers |
^ |
|
|
|
|
|
|
|
|
Drive parts |
^ |
^ |
^ |
|
|
|
|
|
|
^ : Cleaning |
|
|
: Check or replace as required.
: Replace
•Maintenance requirements may vary depending on the operating environment and usage. The information above should be used as a reference guide.
Replace the built-in lithium battery approximately every two years.
Handling and storage place
5Avoid using the unit in places subject to the following conditions:
•extreme heat or cold
•strong magnetic fields (do not use a transceiver within 2 meters of this unit)
•high humidity
•dust and soil
•vibrations
•variations in temperature
5Use this unit in horizontal (flat position) only.
5To avoid overheating the unit, do not block ventilation slots or stack the units. If the internal temperature rises too high, the tape may be damaged.
5When playing back a tape recorded on another VTR, there may be some noise output even when tracking adjustments are carried out. This is not a malfunction.
5Do not leave the unit in the Still or Record Pause mode for a long time as this may damage the tape.
After about 3 minutes, this unit automatically enters the Stop mode.
5Handle the unit carefully
•Do not place anything heavy on the unit (a monitor, etc.). A malfunction may occur.
•Do not put any foreign substance into the cassette loading slot.
•Avoid violent shocks to the recording chassis during transportation. Remove the cassette tape from the unit for transportation.
5Turn off the power to save electricity when not using the unit.
5To clean the unit, just wipe it with a soft cloth.
Use of thinner or benzene may dissolve or tarnish the surface. To remove stains, wipe it using a cloth dipped in water mixed with a little amount of neutral detergent, and wipe it again with a dry cloth later on.
5 Never put your hand into the front-loading tape door.
Condensation
If you do so, you may get hurt.
5 Condensation
When cold beer is poured into a glass, water drops appear on the glass’s surface. This phenomenon is called “condensation”. When condensation occurs on the VCR’s head drum and tape guides it may damage the tape.
5 Condensation occurs in the following cases:
• When the VCR is moved from a
cold place to a warm place.
• In a room that has just been heated or in an area directly exposed to a cooler.
• When there is excessive humidity.
5When condensation is expected to occur
Turn the power of the VCR on before use.
5If condensation has occurred
The VCR automatically ejects the cassette and the error indication “E-08” blinks on the display. Operation is disabled until the “E-08” indication on the display goes out.
|
|
|
|
|
|
|
REC |
POWER |
STOP |
|
|
|
EJECT |
|
|
|
|
|
|
POWER |
|
|
REC REVIEW REC |
|
|
|
|
HDR |
RESET/ |
|
|
|
|
|
|
|
CANCEL |
ON SCREEN |
|
PAUSE/ |
|
|
|
|
|
SHIFT |
|
/REW REV PLAY STILL |
PLAY FF/ |
TRACKING |
V. LOCK |
TIMER SEARCH COUNTER LOCK CNT RESET |
MENU |
TIME MODE |
|
|
|
|
|
|
|
SET |
AG- |
REV ADV |
FWD ADV |
|
|
|
|
|
7
1 INTRODUCTION
1-3 Precautions
Video cassette
Erasure prevention tab
Timelapse recording (24H-960H mode) is performed over very long periods of time which means that a durable tape is required. When using VHS tapes, do not use tapes with recording times of more than 120 minutes (T-160/T-180 etc.).
For best results, use a T-120 tape.
•Only use video cassette bearing the or mark.
•To prevent accidental erasure of a recorded tape, break the erasure prevention tab on the cassette. To use a cassette with a broken tab, place a piece of cellophane tape over the broken tab.
•Video cassettes cannot be used upside down.
•Leaving the tape in a partially wound condition for a long time may damage the tape. Rewind the tape to the beginning before storage.
To obtain the best picture quality, use an HG (high grade) tape . Degradation of picture quality may result with some types of tape. Make a test recording before performing any important recording to check the picture quality.
Although this unit has been designed for reliable operation over a long period of time, a daily inspection is recommended to ensure optimum performance. In particular, be sure to check the repeat recording/playback function on a daily basis.
Inspection procedure
1Turn on the power for all units connected to the surveillance system.
2 Check the quality of the image shown on the monitor.
•The S-VHS ET recording feature of this unit ensures a picture quality (horizontal resolution of 400 lines) on a par with S-VHS when a VHS tape is used. This function is automatically activated when a VHS tape is inserted into the unit and recording started. This unit does not perform normal VHS recording.
•S-VHS ET recording is not performed in the linear slow (L12/L18/L24) mode.
•Playback of a tape recorded in the S-VHS ET format should be performed on this unit, or on a video deck equipped with function for S-VHS or S-VHS simple playback (SQPB). (Playback may not be possible on some video decks.)
•HG (high-grade) VHS tapes are recommended for S-VHS ET recording. Depending on the characteristics of the tape, correct recording may not always be possible. Use the tape after making a test recording to ensure that recording is conducted correctly.
3Check that the date and time shown on the monitor are correct.
4Rewind the tape recorded the previous day for several seconds.
5 Press the play button for playback.
6 Check that the playback picture is normal.
7 Check that the recorded date and time are correct.
5This unit includes a Recording Check function (using the [REC REVIEW] button). Use these features to quickly check recording quality on a daily basis.
If any problems are found after inspection, turn the power off, unplug the mains plug from the socket, and contact your Panasonic dealer.
•Accidentally inserting a tape recorded in the S-VHS ET format into a dedicated VHS deck that is not designed for playback of this type could result in damage. To avoid this kind of accident, mark cassettes labels in such a way that you can easily distinguish between S-VHS ET and VHS recordings when storing cassettes.
•As far as possible avoid operations that apply a load to the tape, such as search playback, etc. This will result in deteriorating picture quality.
•Noise may appear in the playback picture during search playback and field advance. This is not a malfunction.
8
2-1 |
Front Panel |
|
|
|
|
|
|
1 |
2 |
3 |
4 |
5 |
6 |
|
|
|
|
|
REC |
|
|
POWER |
STOP |
|
EJECT |
|
|
|
|
|
|
POWER |
|
|
REC REVIEW REC |
|
|
|
|
|
RESET/ |
|
|
|
|
|
|
HDR |
|
|
|
|
|
|
|
CANCEL |
ON SCREEN |
|
|
|
|
|
|
|
|
||
PAUSE/ |
|
|
|
|
|
SHIFT |
|
/REW REV PLAY STILL |
PLAY FF/ |
TRACKING |
V. LOCK |
TIMER SEARCH COUNTER LOCK CNT RESET |
|
|
|
MENU |
TIME MODE |
|
|||||
|
|
|
|||||
|
|
|
|
|
|
SET |
AG- |
REV ADV |
FWD ADV |
|
|
|
|
|
|
|
|
|
|
|
|
9
1[POWER] power on/off button
Press to turn the operating mode ON/OFF. When this button is POWER indicator 8 lights and the unit can be operated. When a cassette is loaded, operating mode is switched on and the POWER indicator lights automatically.
The POWER button does not completely shut off the mains power to the unit, but switches the operating current on and off.
2[STOP] button
Press this button to stop the tape.
3Cassette loading slot
Insert a cassette in this slot. Use a VHS cassette tape.
4[EJECT] button
Press to eject the cassette.
5[REC] indicator
This indicator lights during recording if menu switch <REC TALLY> on the <F. DISP> screen is set to “ON”.
6[REC] button
Press this button in the Stop mode to engage the Record mode. Press to engage the Record mode in the Rec-Pause mode.
7[REC REVIEW] button
Use this button to check recording.
When pressed in the Record mode, the VCR will rewind the tape for about 5 seconds of tape time and then play back the rewound section in the 2H/6H mode to check recording quality. Recording is resumed automatically after playback at the point where recording was interrupted.
•If picture quality is judged to be inferior during recording check, the heads are cleaned automatically and the error code “E-09” is shown on the display for about 10 seconds. Recording will continue regardless of the results of the recording check.
8[POWER] indicator
Lights when the 1 [POWER] button is turned on.
9Display section
For details, refer to page 11.
0[ON SCREEN/SHIFT 7/t] buttons
•Use these buttons on the normal screen to move the display position or recording position of on-screen information. The position can be moved down by pressing the 7 button and to the right by pressing the t button.
•Use these buttons on the menu screen to select the desired item in date/time setting, timer program setting and menu switch setting.
8 |
12 |
11 |
10 |
7 |
![TIME MODE/SET +/–] buttons
•Use to select the recording and playback speed mode. Available recording/playback speed modes vary depending on the setting of menu switch <HIGH DENSITY REC> on the <VTR MODE> screen.
Each time these buttons are pressed, the recording/ playback speed mode changes as follows. The recording/ playback speed mode is shown on the display.
S-VHS tape |
VHS tape |
|
||
HDR recording |
HDR recording |
Playback speed |
||
On |
Off |
On |
Off |
|
2H* |
2H |
2H* |
2H |
Standard |
6H |
6H* |
6H |
6H* |
3x |
— |
L12H |
— |
— |
12-hour SP linear slow |
L18H |
— |
— |
— |
18-hour EP linear slow |
— |
L24H |
— |
— |
24-hour SP linear slow |
— |
24H |
— |
24H |
24-hour SP timelapse |
24H |
— |
24H |
— |
24-hour EP timelapse |
— |
48H |
— |
48H |
48-hour SP timelapse |
48H |
— |
48H |
— |
48-hour EP timelapse |
— |
72H |
— |
72H |
72-hour SP timelapse |
72H |
— |
72H |
— |
72-hour EP timelapse |
— |
84H |
— |
84H |
84-hour SP timelapse |
84H |
— |
84H |
— |
84-hour EP timelapse |
— |
120H |
— |
120H |
120-hour SP timelapse |
120H |
— |
120H |
— |
120-hour EP timelapse |
— |
168H |
— |
168H |
168-hour SP timelapse |
168H |
— |
168H |
— |
168-hour EP timelapse |
— |
240H |
— |
240H |
240-hour SP timelapse |
240H |
— |
240H |
— |
240-hour EP timelapse |
— |
480H |
— |
480H |
480-hour SP timelapse |
480H |
— |
480H |
— |
480-hour EP timelapse |
— |
960H |
— |
960H |
960-hour SP timelapse |
960H |
— |
960H |
— |
960-hour EP timelapse |
|
|
|
|
|
•The speed selection display - when a cassette tape is not yet inserted - becomes a display when the S-VHS tape is being used. If the VHS cassette tape is inserted after setting the speed that can only be selected during the time the S-VHS tape is used, it automatically changes over to the speed that can be selected when the VHS tape is being used.
Example: If the VHS tape is inserted - when a cassette tape is not yet inserted - after selecting L18H, the recording speed comes to 24H mode.
@[MENU] button
Press to display the date/time, timer program, and various other menu setting screens, as well as the hour meter, on the monitor. Press again to cancel the menu or hour meter display.
9
2 CONTROLS AND CONNECTORS
2-1 Front Panel
REC
POWER |
STOP |
|
|
|
EJECT |
|
|
|
|
|
|
POWER |
|
|
REC REVIEW REC |
|
|
|
|
HDR |
RESET/ |
|
|
|
|
|
|
|
|
||
|
|
|
|
CANCEL |
ON SCREEN |
|
|
|
|
|
|
|
|
||
PAUSE/ |
|
|
|
|
|
SHIFT |
|
/REW REV PLAY STILL |
PLAY FF/ |
TRACKING |
V. LOCK |
TIMER SEARCH COUNTER LOCK CNT RESET |
|
|
|
MENU |
TIME MODE |
|
|||||
|
|
|
|||||
|
|
|
|
|
|
SET |
AG- |
REV ADV |
FWD ADV |
|
|
|
|
|
|
|
|
|
|
|
|
25 24 23 22 21 |
|
|
|
|
|
18 17 16 15 14 |
26 |
|
|
|
|
|
|||
20 |
19 |
13 |
#[RESET/CANCEL] button
•In the Timer Program Setting mode, press this button to cancel the program settings. For details, refer to “Timer Recording” on page 36.
•Also press this button to interrupt alarm recording or to reset the alarm input data or power loss (power failure) data. For details, refer to pages 21 and 39.
•Resets the seconds in the currently displayed time to 00 when pressed together with the $ [CNT RESET] button (except in menu setting mode).
-When the seconds value is 29 or less, the minutes value is the same but the seconds value is reset to 0. (eg. 12:34:29 [ 12:34:00)
-When the seconds value is 30 or more, the seconds value is reset to “00” and the minutes value is increased by one. (e.g. 12:34:30 [12:35:00)
$[CNT RESET] button
When the display shows the control tape counter or reel tape counter, press this button to reset to “00H00M00S” or “0000”.
%[LOCK] button
Press to activate the operation lock function.
^ [COUNTER] button
Selects which data — current time, control tape counter (00H 00M 00S — 23H 59M 59S) or reel tape counter (0 — 9999) — is displayed. Each time this button is pressed, the display switches to the next item.
&[SEARCH] button
Use to search the alarm recorded section or a section recorded at a specified date and time. In the Stop mode, select the search mode by pressing this button.
•Press once to engage the Alarm Search mode.
•Press twice to engage the Alarm Scan mode.
•Press three times to engage the Date/Time Search mode.
•Press four times to release the search mode.
After the search mode is selected with this button, press the [FF] or [REW] button to execute the search operation in the selected mode.
For details, refer to page 49.
*[TIMER] button
Normally use this button for timer recording. For details, refer to “Timer Recording” on page 31.
([V. LOCK +/–] buttons
Press to reduce vertical picture jitter in the Still, Field Advance Playback and Linear Slow Timelapse Play modes.
)[TRACKING +/–] buttons
If picture noise appears during play or field advance, press these buttons to adjust tracking so that noise is reduced. When the [+] and [–] buttons are pressed simultaneously, tracking is reset to the preset level.
*You cannot make any tracking adjustment at L12H and L24H Linear Slow Time-lapse Playback modes.
q[FF] button
•Press to fast-forward the tape.
•Starts fast-forward search when pressed in the Play mode.
•Starts forward alarm search or date/time search when the Search mode is specified with the & [SEARCH] button.
•Also controls field-by-field playback in the forward direction.
w[PLAY] button
• Press to play back the tape.
e[PAUSE/STILL] button
•Engages the Record-Pause mode when pressed in the Record mode.
•Displays a still picture when pressed in the Play mode.
•Field advance or reverse playback is executed each time the [FF] or [REW] button is pressed while pressing this button in the Still mode. (When the [FF] or [REW] button is pressed for more than 2 seconds, Continuous Field Advance Playback mode is engaged. After about 3 minutes, the Stop mode is engaged.)
r[REV PLAY] button
Starts reverse playback when pressed in any mode except Record, Record-Pause and Record Check.
t[REW] button
•Press this button to rewind the cassette.
•Starts rewind search when pressed in the Play mode.
•Starts reverse alarm search or date/time search when the Search mode is specified with the & [SEARCH] button.
•Also controls field-by-field playback in the reverse direction.
y[HDR] indicator
Lights in the HDR recording and HDR playback modes.
* HDR: High Density Recording
• For details on HDR recording, refer to page 28.
10
2 CONTROLS AND CONNECTORS
1 |
6 |
7 |
8 |
9 |
10 |
11 |
12 13 |
14 |
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
3 |
4 |
5 |
1Operation mode display
Shows the operation modes.
Playback |
Recording |
Rewind |
Fast- |
Timelapse |
||
forward |
playback |
|||||
|
|
|
|
|||
|
Still |
Record- |
Rewind |
Fast-forward |
Reverse |
|
|
pause |
search |
search |
playback |
||
|
|
|||||
Field-by-field |
Reverse step |
|
|
|
||
playback |
slow playback |
|
|
|
||
* ( |
) mark in the Rec/Pause mode is shown in red. |
2 Cassette indication
Lights when a cassette is loaded. Blinks when a cassette is being ejected.
3[SP/EP] indication
Shows the standard (SP) mode or extended (EP) mode during recording/playback. During ordinary timelapse recording/playback, the [SP] indication is shown.
The [EP] indication is shown during recording in the HDR (High-Density Record) mode or during playback of a tape section recorded in the HDR mode.
4Tape counter/clock indication
•Shows the current time (hour: minute: second), tape control counter (00H 00M 00S — 23H 59M 59S) or tape reel counter (0 — 9999) when the operating mode is on. The display can be selected with the [DISPLAY] button. Shows the current time when the operating mode is off. When a cassette is ejected, the tape control counter and tape reel counter are reset automatically.
•When the cassette is rewound to the beginning in the Repeat Recording or Auto Rewind mode using the counter end output function, the tape control counter and tape reel counter are reset.
•The control and reel counter counts slowly in the Timelapse mode.
•In the timelapse mode, the control counter shows the time equivalent to that shown when a tape is played back in the 2H or 6H mode.
(Example: The control counter advances 1 second for about 8 minutes in the 960H ordinary timelapse mode.)
•During date/time search setting and operation, “td” is shown in place of the seconds.
•Shows the setting item during menu switch setting.
5Recording/playback speed display
•Normally shows the recording/playback speed mode set with the [TIME MODE] button.
•Shows the following indications in the Alarm Search mode. During alarm search: Shows the specified alarm number (example: AL12)
During alarm scan: Shows the alarm scan mode (ALSC). During date/time search: Shows the specified date and time (example 2310).
•Shows setting details in menu switch setting.
•When an error occurs, the error indication “E-**” blinks (if the menu switch <WARNING> on the <FRONT DISPLAY> screen is set to “ON”).
For error indications, refer to page 53.
6[TIMER] indication
Lights during timer recording programming/operation.
7 [REPEAT] indication
When <REPEAT REC> in the <VTR MODE> menu is set to “ON”, this indication is shown. When <TAPE END MODE> in the <ALARM/SENSOR MODE> menu is set to “STOP” and the Repeat Record mode is engaged, the [REPEAT] indication goes out if alarm recording or sensor recording takes place.
8[OVERLAP] indication
Blinks when programs scheduled for timer recording overlap.
9Timer program number
All programmed timer recording numbers light.
During timer recording, the number of the program being recorded blinks. When the timer recording ends, this number goes out.
0[AL] (alarm) indication
Shown during alarm recording or sensor recording. Blinks when alarm recording or sensor recording ends.
![S-VHS] indication
Lights when a S-VHS cassette is loaded. In the playback mode, it lights during playback of a tape recorded in the S- VHS mode.
@[LOCK] indication
Lights when the operation lock function is activated.
#[AL REC] (alarm recording) indication
Lights when the menu switch <REC MODE> on the <ALARM/ SENSOR MODE> screen is set to “ALARM” or “AL/ SENSOR”.
$[SENSOR REC] (sensor recording) indication
Lights when the menu switch <REC MODE> on the <ALARM/ SENSOR MODE> screen is set to “SENSOR” or “AL/ SENSOR”.
11
2 CONTROLS AND CONNECTORS
4 6 8
|
|
|
|
|
|
|
|
|
|
1 |
|
|
|
|
|
R S - 2 3 2 C |
|
|
|
|
|
|
AC~IN |
|
|
|
|
|
|
|
|
|
AUDIO |
|
VIDEO |
S-VIDEO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
CAM SW ALARM ALARM COM CLOCK SERIES |
|
|
|
|
|
|
|
|
|||
|
|
IN |
|
OUT |
IN REC OUT |
RESET IN REC IN |
|
|
|
|
|
|
|
|
|
|
|
|
COM |
ALARM |
TAPE |
WARNING CLOCK SERIES |
|
|
|
|
|
|
|
|
|
SPARE |
MIC |
|
|
RESET |
ENDOUT |
OUT RESETOUT REC OUT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
OUT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CAM SW |
ALARM ALARM |
COM |
CLOCK |
SERIES |
||||
2 |
3 5 |
7 |
9 |
10 |
|
|
OUT |
IN |
REC OUT |
|
RESET IN |
REC IN |
|||
|
|
COM |
ALARM |
TAPE |
WARNING |
CLOCK |
SERIES |
||||||||
|
|
RESET |
ENDOUT |
OUT |
RESETOUT |
REC OUT |
1112 1314 15 1617 18 19 20 21 22
1[AC IN] connector
Connect to an AC 120 V, 50 Hz/60 Hz socket using the AC mains cable.
2[SPARE] spare connector
This connector is not used now and thus has on function.
3[MIC] mic input connector
Connect a microphone with 3.6-mm dia. plug. When signals are input from both the microphone connector and the audio input connector, audio signals are mixed and recorded.
4 [AUDIO IN] audio input connector (Phono)
Receives audio signals from a connected audio source.
5[AUDIO OUT] audio output connector (Phono)
Outputs audio signals. No signal is output in the Timelapse Recording/Playback mode.
6[VIDEO IN] video input connector (BNC)
Receives composite video signals from a connected camera or other video source.
•For composite video signal input, set the <INPUT> menu switch in <VIDEO MODE> to LINE.
7[VIDEO OUT] video output connector (BNC)
Outputs composite video signals. Even when the power is not supplied to this unit, input signals (composite video signals) from a camera can be output through this connector (Operating mode-Off Video Throughout function).
8[S-VIDEO IN] S-VIDEO input terminal (4 pin)
Inputs separate Y/C signals.
•For separate Y/C signal input, set the <IN> menu switch in <VIDEO MODE> to “S-VIDEO”.
9[S-VIDEO OUT] S-VIDEO output terminal (4 pin)
Outputs separate Y/C signals.
0Signal ground terminal
This ground terminal is not provided for safety purposes. It is used to ground signals. Connect this terminal to ground the signal between VCRs.
![CAM SW OUT] camera switching signal output terminal
When a sequential switcher is connected, this terminal outputs camera switching timing control signals. For details on these signals, refer to page 56.
@[COM] common ground terminal
Connect to the signal ground terminal of a connected unit.
#[ALARM IN] alarm signal input terminal
Receives signals to start alarm or sensor recording.
$[ALARM RESET] alarm signal reset input terminal
Receives signals to cancel alarm recording.
*Alarm input data is not reset.
%[ALARM REC OUT] alarm recording mode signal output terminal
Outputs +12 V signals during alarm recording.
12
2 CONTROLS AND CONNECTORS
2-3 Rear Panel
^[TAPE END OUT] tape end signal output terminal
Outputs a signal when the tape ends during recording. If the menu switch <CNT TAPE END> on the <SRI/EXT MODE> screen is set, signals are output when the specified tape reel counter value is exceeded.
•Outputs a +12 V signal during recording. When the tape ends or the specified counter value is passed, a 0 V (GND level) signal is output.
•When the tape ends during auto repeat recording or auto rewind recording, 0 V signal is output for about 2 seconds.
•Connect an external alarm or buzzer via an external interface.
•To cancel the output, press the [EJECT] button, [PLAY] button, [FF] button or [REW] button.
&[COM] common ground terminal
Connect to the signal ground terminal of a connected unit.
*[WARNING OUT] warning signal output terminal
Outputs warning signals (+12 V) when a tape running or mechanism problem occurs.
([CLOCK RESET IN] clock reset input terminal
Connect to a master clock or another AG-TL950P’s [CLOCK RESET OUT] terminal. When the clock reset signal is input, the time is automatically synchronized with the master clock or another AG-TL950P’s clock. However, the time difference between VCRs should be within ±30 seconds.
When the clock reset signal is input, the clock in this unit is reset as shown below.
•When the seconds value is 29 or less, the minutes value is the same but the seconds value is reset to 0. (eg. 12:34:29 — > 12:34:00)
•When the seconds value is 30 or more, the second value is reset to 00 and the minutes value is increased by one. (e.g. 12:34:30 — > 12:35:00)
)[CLOCK RESET OUT] clock reset output terminal
Outputs the clock reset signal.
The clock reset signal is output in the following cases.
•When the internal clock is at 0:00 or 12:00
When this unit is connected to another AG-TL950P’s [CLOCK RESET IN] terminal, the other VCR’s clock can be set to the clock in this unit. However, the time difference should be within ±30 seconds.
q[SERIES REC IN] series recording/VCR activation signal input terminal
Receives series recording signal or VCR activation signal from an external control device.
Select the input signal with the menu switches in the <SRI/EXT MODE> menu.
5 Series recording input
A series recording signal is input when [SRI/EXT REC] is set to “SERIES”.
•Connect to another VCR’s series recording signal output terminal.
•When the tape in the preceding VCR ends, a signal is delivered to this terminal and recording starts automatically.
When the menu switch <CNT TAPE END> on the <SRI/EXT MODE> screen is set, the signals are delivered when the specified tape reel counter
value is reached. Recording starts automatically.
5VCR activation signal input
When [SRI/EXT REC] is set to “EXT”, recording is started and stopped with an external signal.
•Connect to an external control device.
If a VCR activation signal (ground input) is input to this terminal, the VCR starts recording automatically and continues recording for as long as the VCR activation signal is input.
w[SERIES REC OUT] series recording signal output terminal
Outputs series recording signals.
A series recording signal is output when [SRI/EXT REC] is set to “SERIES”.
•Connect to another VCR’s series recording signal input terminal.
•Outputs a signal when the tape being recorded in this unit ends.
When the menu switch <CNT TAPE END> on the <SRI/EXT MODE> screen is set, the signals are output when the specified tape reel counter value is reached.
13
|
|
CCD |
Microphone |
Amplifier |
Video camera |
|
|
|
|
|
Phono |
|
|
BNC |
|
|
4pin |
|
Microphone |
M3.5 mini- |
|
|
|
|
|
jack |
R S - 2 3 2 C |
AC~IN |
|
AUDIO |
|
VIDEO |
S-VIDEO |
|
|
|
|
|
|
|
|
|
|
IN |
|
CAM SW |
ALARM ALARM |
COM |
CLOCK |
SERIES |
||||
|
|
|
OUT |
IN |
REC OUT |
|
RESET IN |
REC IN |
||||
|
|
|
COM |
ALARM |
TAPE |
WARNING |
CLOCK |
SERIES |
||||
SPARE |
MIC |
|
|
RESET |
ENDOUT |
OUT |
RESETOUT |
REC OUT |
||||
|
|
|
|
|
|
|
|
|
|
|
OUT
|
|
4pin |
Phono |
BNC |
COM ALARM IN |
|
|
Mains cable
AC 120 V
50 Hz/60 Hz
Monitor TV |
Alarm sensor |
|
1 Connect the monitor’s video/audio input connectors to the AG-TL950P’s video/audio output connectors.
2 Connect the video camera’s video output connector to the AG-TL950P’s video input connector.
3 Input audio signals to the audio input connectors via an amplifier.
4 When connecting an alarm sensor, connect it to the AG-TL950P’s alarm input terminal.
5 When the connection is complete, connect the power plug to an AC 120 V, 50 Hz/60 Hz socket.
14
3 CONNECTIONS
Video camera |
|
|
|
CCD |
|
|
|
|
123456 |
|
|
|
|
Alarm sensor input |
Alarm sensor |
|
|
|
|
CCD |
|
123456 |
|
|
|
|
|
|
|
Alarm signal output |
|
CCD |
Video output |
Camera switching |
Sequential switcher |
|
|||
|
|
signal input |
|
CCD
Microphone
CCD
CCD
Phono |
BNC |
Amplifier |
|
|
R S - 2 3 2 C |
AC~IN |
AUDIO |
VIDEO |
|
IN
SPARE MIC
OUT
Phono BNC
S-VIDEO
CAM SW ALARM |
ALARM |
COM |
CLOCK |
SERIES |
||||
OUT |
IN |
REC OUT |
|
RESET IN |
REC IN |
|||
COM |
ALARM |
TAPE |
WARNING |
CLOCK |
SERIES |
|||
RESET |
ENDOUT |
OUT |
RESETOUT |
REC OUT |
CAM SW ALARM IN OUT
4pin
Mains cable
AC 120 V
50 Hz/60 Hz
Monitor TV
1 Connect video cameras and alarm sensor to a sequential switcher (frame switcher).
2Connect the sequential switcher’s (frame switcher) alarm signal output, camera switching signal input and video output to the AG-TL950P.
3 Connect the monitor’s video/audio input connectors to the AG-TL950P’s video/audio output connectors. 4 When the connection is complete, connect the power plug to an AC 120 V, 50 Hz/60 Hz socket.
5 Synchro should be applied to all connected video cameras.
6If you are connecting the camera switching signal input from a sequential switcher (frame switcher) to the AG-TL950P, be sure to set the <CAMERA SW> menu switch.
15
3 CONNECTIONS
[CAM SW OUT] camera switching signal output terminal [ALARM IN] alarm signal input terminal
CAM SW |
|
|
|
|
|
ALARM |
|
|
|
|
||
|
|
|
|
|
IN |
COM |
||||||
OUT |
COM |
|
||||||||||
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Sequential switcher |
|
|
|
|
|
Sequential switcher |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
alarm output |
|
|
|
|
|
|
camera switching |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
terminal |
|
|
|
|
|
|
signal input |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
[ALARM RESET] alarm reset terminal |
|
[ALARM REC OUT] alarm recording mode signal output terminal |
||||||||||
ALARM |
|
|
|
|
ALARM |
|
ALARM |
|||||
|
|
|
|
RESET |
|
REC OUT COM |
||||||
RESET |
COM |
|
||||||||||
|
|
|
|
|
|
|
Alarm lamp
Vcc |
|
External |
|
Switch |
interface |
Switch |
|
|
Vcc: 5V–12V |
|
[TAPE END OUT] tape end output terminal |
|
[WARNING OUT] warning signal output terminal |
|
|
|
WARNING
TAPE
OUT COM
END OUT COM
Alarm lamp |
Alarm lamp |
External |
External |
interface |
interface |
[CLOCK RESET] clock reset terminal
5 When setting the clock to the first VCR’s clock
First VCR |
|
Second VCR |
|
Last VCR |
|
External interface example |
||
CLOCK |
|
CLOCK |
|
|
|
CLOCK |
|
|
|
|
|
|
|
|
|||
OUT |
COM |
IN |
COM |
|
|
IN |
COM |
|
|
|
|
|
|
|
|
|
Example: Lamp lights with HIGH signal |
|
|
|
|
|
|
|
|
(Lamp, etc.) |
|
|
|
|
|
|
|
|
Power |
|
|
|
|
|
|
|
|
supply |
5 When setting the clock to the external master clock |
|
|
Relay |
|||||
|
|
First VCR |
Second VCR |
|
Last VCR |
Control |
||
|
|
|
signal |
|||||
External |
|
|
|
|
|
|
|
|
|
CLOCK |
|
CLOCK |
|
|
CLOCK |
GND |
|
master clock |
|
|
|
|||||
IN |
COM |
IN |
COM |
|
IN |
COM |
||
|
|
|
5 Use appropriately rated devices.
16
4-1 On-Screen Display
Displays the time date (date and time), recording speed, number of alarms and number of power losses (power failures) on screen in the Stop mode, Record mode and Record-Pause mode.
During recording, the on-screen data is recorded together with video signals.
•The on-screen display position can be moved with the [ON SCREEN] buttons.
•The type of data shown and display brightness can be selected on the <ON SCREEN /FRONT DISPLAY MODE> screen.
[ON SCREEN 7] button |
|
|
|
[ON SCREEN t] button |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RESET/ |
ON SCREEN |
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
REC |
|
CANCEL |
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SHIFT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
POWER |
STOP |
|
|
|
|
|
|
|
POWER |
|
EJECT |
|
|
|
|
|
MENU |
TIME MODE |
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
REC REVIEW REC |
|
|
|
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
HDR |
|
RESET/ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CANCEL ON SCREEN |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PAUSE/ |
PLAY FF/ |
|
|
|
|
|
|
|
|
|
|
SHIFT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
/REW REV PLAY STILL |
TRACKING V. LOCK |
TIMER SEARCH COUNTER LOCK CNT RESET |
|
MENU TIME MODE |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
REV ADV |
FWD ADV |
|
|
|
|
|
|
|
|
|
|
SET |
|
AG- |
|
|
|
|
|
|
– S E T + |
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
On-screen display |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Preparation |
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
Recording speed (T-MODE) |
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
Time (hour, |
|
|
|
ALARM indication during |
|
5 Connect the video output connector of this unit to the |
|
|
||||||||||||||||||||||
|
|
minute, second) |
alarm/sensor recording |
|
monitor’s video input connector. |
|
|
|||||||||||||||||||||||||
|
|
|
|
|
|
|
|
0 0 : 0 0 : 0 1 * * * 2 |
|
|
|
|
|
|
|
|
|
1 Turn on the monitor and VCR. |
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
Date (month, |
|
|
4H * * * * * * * * * * |
|
|
|
|
|
|
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||||
|
|
|
|
|
1 2 – 2 4 – 1 9 9 9 * FR I * * * * * * * * * * |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
day, year) |
|
|
AL – 0 5 6 * BLPL – 0 4 * AUTO * * * * * |
|
|
|
|
|
2 When a video signal from a camera is input to the video |
|
|
|||||||||||||||||||
|
|
Number of |
|
|
|
* ZOOMONUM . * * * * * M. * * * * * * * |
Number of |
|
|
|
||||||||||||||||||||||
|
|
|
|
|
* MACR * * TELE |
* * * * A. * * * * * * * |
|
input connector, on-screen data is superimposed on the |
|
|
||||||||||||||||||||||
|
|
alarms |
|
|
|
* DATEEHEURE * * * * * * * * * * * * * |
power losses |
|
picture. |
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
* DURE * * BANDE * * * T 4 5 * * * * * * |
(power |
|
|
|
|
|
|
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
When there is no input signal, on-screen data is shown |
|
|
|||||||||||||||||||||
|
|
|
|
|
|
|
* * * * * * * * * * * * * * * * * * * * * * * * |
failures) |
|
|
|
|||||||||||||||||||||
|
|
|
|
|
|
|
* * * * * * * * * * * * * * * * * * * * * * * * |
|
on a black background. |
|
|
|||||||||||||||||||||
|
|
|
|
|
|
|
* * * * * * * * * * * * * * * * * * * * * * * * |
|
|
|
|
|
|
|
||||||||||||||||||
|
|
|
|
|
|
|
* * * * * * * * * * * * * * * * * * * * * * * * |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
* 4F I N |
DE * MENU * * * * * * * * * * * |
|
|
|
|
|
Changing the on-screen display position |
|
|
|||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
[ON SCREEN t] button |
|
|
|
|
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
5 Move horizontally. |
|
|
|||||||||||||||||||
|
|
|
|
|
|
|
|
0 0 : 0 0 : 0 1 * * * 2 4H * * * * * * * * * * |
|
|
|
|
|
Press the [ON SCREEN t] button. |
|
|
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
[ The display position is moved to the right |
|
|
|||||||||||||||||
|
|
|
|
|
|
|
|
1 2 – 2 4 – 1 9 9 9 * FR I * * * * * * * * * * |
|
|
|
|
|
|
|
|||||||||||||||||
|
|
|
|
|
|
|
|
AL – 0 5 6 * BLPL – 0 4 * AUTO * * * * * |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
[ON SCREEN 7] |
|
* ZOOMONUM . * * * * * M. * * * * * * * |
|
|
|
|
|
5 Move downward. |
|
|
||||||||||||||||||||||
|
* MACR * * TELE * * * * A. * * * * * * * |
|
|
|
|
|
Press the [ON SCREEN 7] button. |
|
|
|||||||||||||||||||||||
button |
|
|
|
|
* DATEEHEURE * * * * * * * * * * * * * |
|
|
|
|
|
|
|
||||||||||||||||||||
|
|
|
|
|
|
|
|
* DURE * * BANDE * * * T 4 5 * * * * * * |
|
|
|
|
|
[ The display position is moved down. |
|
|
||||||||||||||||
|
|
|
|
|
|
|
* * * * * * * * * * * * * * * * * * * * * * * * |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
* * * * * * * * * * * * * * * * * * * * * * * * |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
* * * * * * * * * * * * * * * * * * * * * * * * |
|
|
|
|
|
Selecting the data display |
|
|
|||||||||||||||||
|
|
|
|
|
|
|
* * * * * * * * * * * * * * * * * * * * * * * * |
|
|
|
|
|
|
|
||||||||||||||||||
|
|
|
|
|
|
|
|
* 4F I N |
DE * MENU * * * * * * * * * * * |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ON SCREEN MODE screen |
|||
|
|
* * * * [ ONSCREEN * MODE ] * * * * * |
||||
1 |
. TONEE * * * * * * * * * * * * * * 1 0 0 |
|||||
|
|
* MANU. * BLANC * * * * * * * * * * * * |
||||
|
|
|
|
|
||
2 |
. DATENUM. * * * * * M. * * * * * ON |
|||||
Display items |
|
3 . T I ME * TELE * * * * A. * * * * * ON |
||||
|
4 . T - MODE |
* * * * * * * * * * |
ON |
|||
|
||||||
|
|
5 |
. ALARMBCNTE * * * T 4 5 * * * |
ON |
||
|
|
6 |
. POWERMLOSS * CNT I NE * * |
ON |
||
|
|
|
|
* * * |
||
|
|
* MOD [ FRONT * D I SPLAY ] * * |
||||
1 |
. REC * TAL LY * * * * * * * * * * |
* ON |
||||
2 |
. WARN I NG * * * * * * * * * * * * |
* ON |
||||
|
|
* 4 F I N * DE * MENU * * * * * * * * |
* * * |
The data displayed on-screen can be selected on the <ON SCREEN MODE> screen.
Set the <ONSCREEN/F. DISP MODE> setting to “ON”.
5When you do not want to display or record on-screen data, set the corresponding menu item to “OFF”.
Changing the on-screen display brightness
Set the brightness with the menu switch <TONE> on the <ON SCREEN MODE> screen. Select 0, 30, 70 or 100.
• The higher the number, the brighter the characters.
* For details on menu operation, refer to page 22.
17
4 ON-SCREEN/MENU SWITCHES
You can display date and time data recorded when an alarm input or power failure occurs, as well as the hour meter (drum rotating time) by selecting the desired item in the main menu.
The date/time setting screen, menu switch setting screen for each application, and timer recording program setting screen can also be displayed by selecting the desired item in the main menu.
Date/time setting, menu switch setting and hour meter can be checked on the VCR’s display as well.
[SHIFT 7] button |
[SHIFT t] button |
|||
|
|
|
REC |
|
|
EJECT |
|
|
|
POWER |
|
REC REVIEW |
REC |
|
HDR |
RESET/ |
|||
ON SCREEN |
|
|||
|
CANCEL |
|
SHIFT
CNT RESET |
MENU |
TIME MODE |
Operation
5Connect the video output connector of this unit to the monitor’s video input connector.
1 Turn on the monitor and VCR.
2Press the [MENU] button.
[ The main menu screen is shown on the monitor screen.
SET |
AG- |
[MENU] button |
|
|
[SET +] button |
|
||
|
|
|||||
|
|
[SET –] button |
|
|||
|
|
|
|
Main menu screen |
|
|
* |
* * * * * * [ MENU ] * * * * * * * * * * * |
Cursor |
||||
* |
T I ME |
ADJUST * * * * * * * * * |
* * * |
|||
* |
ONSCREEN / F . D I SP * MODE |
* * * |
|
|||
* |
V I DEO / VTR * MODE * * * * * * * * * |
|
||||
* |
SR I / EXT * MODE * * * * * * * * * * * |
|
||||
* |
ALARM / SENSOR * MODE * * ONNN |
|
||||
* |
BUZ ZER / I N * OUT * * * * * * ONNN |
|
||||
* |
PROGRAM * T I MER * * * * * * * * * * |
|
||||
* |
HOL I DAY * SET * * * * * * * * * * * * |
|
||||
* |
HOUR |
METER * * * * * * * * * ONNN |
|
|||
* |
ALARM * RECAL L / POWER * LOSS |
|
||||
* |
|
|
|
|
|
|
3Press the [SHIFT 7] button to move the cursor to the item you want to display.
4Press the [SET +/–] button to display the selected menu screen on the monitor (see below).
5To restore the main menu screen, press the [MENU] button.
To cancel the main menu mode, press the [MENU] button again. The normal screen is restored.
Contents of the main menu items
5TIME ADJUST (VCR's displayT ADJ)
Displays the date/time setting screen.
*Set the clock before operating the VCR (refer to page 19).
5ONSCREEN/FRONT DISPLAY MODE (VCR's displayDiSP)
Let’s you choose whether or not to display onscreen display items, brightness selection, [REC] indicator and warning indicator.
5VIDEO/VTR MODE (VCR's displayViDEO)
For VCR operation settings such as V. Pulse ON/ OFF, HDR recording, counter memory function and repeat recording/playback.
5 SRI/EXT MODE (VCR's displaySRi ET)
For setting series recording or automatic recording with an external signal.
5ALARM/SENSOR MODE (VCR's displayAL 5EN)
For setting alarm recording or sensor recording operation.
5BUZZER/IN OUT (VCR's displayBU22iO)
Turn ON/OFF buzzers such as the tape end buzzer and alarm/sensor buzzer and set camera switch signal output.
5PROGRAM TIMER (VCR's displayPRG)
Shows timer recording program settings with the day of the week.
5HOLIDAY SET (VCR's displayHOLiDY)
Shows timer recording program settings at specified dates.
5HOUR METER (VCR's displayHOUR)
Shows the VCR’s operating time (drum rotation time).
5ALARM RECALL/POWER LOSS (VCR's displayAL P0)
Shows the date and time when an alarm was input or a power failure occurred.
18
