SERVICE MANUAL
CD RECEIVER
KD-AR870J,KD-G820J,KD-G821E, KD-G821EX,KD-G821EY,KD-G821EU, KD-G824UI,KD-G825U,KD-G825UN, KD-G825UH,KD-G825UT,KD-G827EE
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7 2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10 3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11 4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15 5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
COPYRIGHT © 2006 Victor Company of Japan, Limited
No.MA249
2006/2
SPECIFICATION
KD-AR870/KD-G820
|
AUDIO AMPLIFIER SECTION |
|
|
|
|||
Power Output |
|
20 W RMS × 4 Channels at 4 Ω |
and [< or =] 1% THD+N |
||||
Signal to Noise Ratio |
|
80 dBA (reference: 1 W into 4 Ω |
) |
|
|
||
Load Impedance |
|
4 Ω (4 Ω |
to 8 Ω allowance) |
|
|
|
|
Tone Control Range |
Low |
±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz) |
|
||||
|
|
|
|
||||
|
Mid |
±12 dB (500 Hz, 1 kHz, 1.5 kHz, 2.5 kHz) |
|
||||
|
|
|
|
||||
|
High |
±12 dB (10 kHz, 12.5 kHz, 15 kHz,17.5 kHz) |
|
||||
|
|
|
|
|
|
|
|
Frequency Response |
|
40 Hz to 20 000 Hz |
|
|
|
|
|
|
|
|
|
|
|
|
|
Line-In Level/Impedance |
KD-AR870 |
1.5V/20kΩ |
load |
|
|
|
|
Line-Out Level/Impedance |
KD-AR870 |
5.0 V/20 kΩ load (full scale) |
|
|
|
||
|
KD-G820 |
4.0 V/20 kΩ load (full scale) |
|
|
|
||
Output Impedance |
|
1 kΩ |
|
|
|
|
|
Subwoofer-Out Level/Impedance |
2.0 V/20 kΩ load (full scale) |
|
|
|
|||
Other Terminals |
|
CD changer, LINE IN (for KD-AR870) |
|
|
|||
|
|
|
|
|
|
|
|
|
TUNER SECTION |
|
|
|
|
||
Frequency Range |
FM |
87.5 MHz to 107.9 MHz (with channel interval set to 100 kHz or 200 kHz) |
|||||
|
|
87.5 MHz to 108.0 MHz (with channel interval set to 50 kHz) |
|||||
|
|
|
|||||
|
AM |
530 kHz to 1 710 kHz (with channel interval set to 10 kHz) |
|||||
|
|
531 kHz to 1 602 kHz (with channel interval set to 9 kHz) |
|||||
|
|
|
|
|
|
||
FM Tuner |
Usable Sensitivity |
11.3 dBf (1.0 µV/75 Ω ) |
|
|
|
||
|
50 dB Quieting Sensitivity |
16.3 dBf (1.8 µV/75 Ω ) |
|
|
|
||
|
Alternate Channel Selectivity (400 kHz) |
65 dB |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Frequency Response |
40 Hz to 15 000 Hz |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Stereo Separation |
35 dB |
|
|
|
|
|
|
|
|
|
|
|
|
|
AM Tuner |
Sensitivity |
20 µV |
|
|
|
|
|
|
Selectivity |
35 dB |
|
|
|
|
|
|
|
|
|
|
|
||
|
CD PLAYER/USB MEMORY SECTION |
|
|
|
|||
Type |
|
Compact disc player |
|
|
|
||
|
|
|
|||||
Signal Detection System |
|
Non-contact optical pickup (semiconductor laser) |
|||||
Number of Channels |
|
2 channels (stereo) |
|
|
|
|
|
|
|
|
|
|
|
|
|
Frequency Response |
|
5 Hz to 20 000 Hz |
|
|
|
|
|
|
|
|
|
|
|
|
|
Dynamic Range |
|
96 dB |
|
|
|
|
|
|
|
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
98 dB |
|
|
|
|
|
|
|
|
|
|
|
||
Wow and Flutter |
|
Less than measurable limit |
|
|
|
||
|
|
|
|
|
|
||
MP3 Decoding Format |
|
MPEG1/2 Audio Layer 3 |
|
|
|
||
|
|
Max. Bit Rate : 320 kbps |
|
|
|
||
|
|
|
|
|
|||
WMA (Windows Media® Audio) Decoding |
Max. Bit Rate : 192 kbps |
|
|
|
|||
|
|
|
|
|
|
|
|
Playable USB memory |
Format |
FAT 12/16/32 |
|
|
|
|
|
|
|
|
|
|
|||
|
Storage |
Less than 4 GB (1 partition type) |
|
|
|||
|
|
|
|
|
|
|
|
|
Playable Audio Format |
MP3/WMA |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Max. Current |
Less than 500 mA |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GENERAL |
|
|
|
|
|
Power Requirement |
Operating Voltage |
DC 14.4 V (11 V to 16 V allowance) |
|
|
|||
|
|
|
|
|
|
|
|
Grounding System |
|
Negative ground |
|
|
|
|
|
|
|
|
|
|
|||
Allowable Operating Temperature |
0°C to +40°C (32°F to 104°F) |
|
|
|
|||
Dimensions (W × H × D) |
Installation Size (approx.) |
182 mm × |
52 mm × |
152 mm (7-3/16" × |
2-1/16" × |
6") |
|
|
Panel Size (approx.) |
188 mm × |
58 mm × |
11 mm (7-7/16" × |
2-5/16" × |
7/16") |
|
Mass (approx.) |
|
1.4 kg (3.1 lbs) (excluding accessories) |
|
||||
|
|
|
|
|
|
|
|
1-2 (No.MA249)
KD-G821
|
|
AUDIO AMPLIFIER SECTION |
|
||
Maximum Power Output |
|
Front |
50 W per channel |
|
|
|
|
|
|
|
|
|
|
Rear |
50 W per channel |
|
|
|
|
|
|||
Continuous Power Output (RMS) |
Front |
19 W per channel into 4 Ω , 40 Hz to 20 000 Hz at no more than 0.8% total |
|||
|
|
|
harmonic distortion. |
|
|
|
|
|
|
||
|
|
Rear |
19 W per channel into 4 Ω , 40 Hz to 20 000 Hz at no more than 0.8% total |
||
|
|
|
harmonic distortion. |
|
|
|
|
|
|
|
|
Load Impedance |
|
4 Ω (4 Ω |
to 8 Ω allowance) |
||
Tone Control Range |
|
Low |
±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz) |
||
|
|
|
|
||
|
|
Mid |
±12 dB (500 Hz, 1 kHz, 1.5 kHz, 2.5 kHz) |
||
|
|
|
|
||
|
|
High |
±12 dB (10 kHz, 12.5 kHz, 15 kHz, 17.5 kHz) |
||
|
|
|
|
|
|
Frequency Response |
|
40 Hz to 20 000 Hz |
|
||
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
70 dB |
|
|
|
|
|
|
|||
Line-Out Level/Impedance |
|
5.0 V/20 kΩ load (full scale) |
|||
Output Impedance |
|
1 kΩ |
|
|
|
Subwoofer-Out Level/Impedance |
|
2.0 V/20 kΩ load (full scale) |
|||
Other Terminals |
|
CD changer, Steering wheel remote input |
|||
|
|
|
|
|
|
|
|
TUNER SECTION |
|
|
|
Frequency Range |
|
FM |
87.5 MHz to 108.0 MHz |
||
|
|
|
|
||
|
|
AM |
(MW) 522 kHz to 1 620 kHz |
||
|
|
|
(LW) 144 kHz to 279 kHz |
||
|
|
|
|
||
FM Tuner |
|
Usable Sensitivity |
11.3 dBf (1.0 µV/75 Ω ) |
||
|
|
50 dB Quieting Sensitivity |
16.3 dBf (1.8 µV/75 Ω ) |
||
|
|
Alternate Channel Selectivity (400 kHz) |
65 dB |
|
|
|
|
|
|
|
|
|
|
Frequency Response |
40 Hz to 15 000 Hz |
|
|
|
|
|
|
|
|
|
|
Stereo Separation |
30 dB |
|
|
|
|
|
|
|
|
MW Tuner |
|
Sensitivity |
20 µV |
|
|
|
|
Selectivity |
35 dB |
|
|
|
|
|
|
|
|
LW Tuner |
|
Sensitivity |
50 µV |
|
|
|
|
CD PLAYER/USB MEMORY SECTION |
|
||
Type |
|
Compact disc player |
|||
|
|
|
|||
Signal Detection System |
|
Non-contact optical pickup (semiconductor laser) |
|||
Number of Channels |
|
2 channels (stereo) |
|
||
|
|
|
|
||
Frequency Response |
|
5 Hz to 20 000 Hz |
|
||
|
|
|
|
|
|
Dynamic Range |
|
96 dB |
|
|
|
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
98 dB |
|
|
|
|
|
|
|||
Wow and Flutter |
|
Less than measurable limit |
|||
|
|
|
|||
MP3 Decoding Format |
|
MPEG1/2 Audio Layer 3 |
|||
|
|
|
Max. Bit Rate : 320 kbps |
||
|
|
||||
WMA (Windows Media® Audio) Decoding Format |
Max. Bit Rate : 192 kbps |
||||
|
|
|
|
||
Playable USB memory |
|
Format |
FAT 12/16/32 |
|
|
|
|
|
|
||
|
|
Storage |
Less than 4 GB (1 partition type) |
||
|
|
|
|
|
|
|
|
Playable Audio Format |
MP3/WMA |
|
|
|
|
|
|
|
|
|
|
Max. Current |
Less than 500 mA |
|
|
|
|
|
|
|
|
|
|
GENERAL |
|
|
|
Power Requirement |
|
Operating Voltage |
DC 14.4 V (11 V to 16 V allowance) |
||
|
|
|
|
|
|
Grounding System |
|
Negative ground |
|
||
|
|
|
|
||
Allowable Operating Temperature |
|
0°C to +40°C |
|
||
Dimensions (W × H × D) |
|
Installation Size (approx.) |
182 mm × |
52 mm × |
152 mm |
|
|
Panel Size (approx.) |
188 mm × |
58 mm × |
11 mm |
Mass (approx.) |
|
1.4 kg (excluding accessories) |
(No.MA249)1-3
KD-G824
|
|
AUDIO AMPLIFIER SECTION |
|
||
Maximum Power Output |
|
Front |
50 W per channel |
|
|
|
|
|
|
|
|
|
|
Rear |
50 W per channel |
|
|
|
|
|
|||
Continuous Power Output (RMS) |
Front |
19 W per channel into 4 Ω , 40 Hz to 20 000 Hz at no more than 0.8% total |
|||
|
|
|
harmonic distortion. |
|
|
|
|
|
|
||
|
|
Rear |
19 W per channel into 4 Ω , 40 Hz to 20 000 Hz at no more than 0.8% total |
||
|
|
|
harmonic distortion. |
|
|
|
|
|
|
|
|
Load Impedance |
|
4 Ω (4 Ω |
to 8 Ω allowance) |
||
Tone Control Range |
|
Low |
±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz) |
||
|
|
|
|
||
|
|
Mid |
±12 dB (500 Hz, 1 kHz, 1.5 kHz, 2.5 kHz) |
||
|
|
|
|
||
|
|
High |
±12 dB (10 kHz, 12.5 kHz, 15 kHz, 17.5 kHz) |
||
|
|
|
|
|
|
Frequency Response |
|
40 Hz to 20 000 Hz |
|
||
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
70 dB |
|
|
|
|
|
|
|||
Line-Out Level/Impedance |
|
5.0 V/20 kΩ load (full scale) |
|||
Output Impedance |
|
1 kΩ |
|
|
|
Subwoofer-Out Level/Impedance |
|
2.0 V/20 kΩ load (full scale) |
|||
Other Terminal |
|
CD changer |
|
||
|
|
|
|
|
|
|
|
TUNER SECTION |
|
|
|
Frequency Range |
|
FM |
87.5 MHz to 108.0 MHz |
||
|
|
|
|
||
|
|
AM |
531 kHz to 1 602 kHz |
||
|
|
|
|
||
FM Tuner |
|
Usable Sensitivity |
11.3 dBf (1.0 µV/75 Ω ) |
||
|
|
50 dB Quieting Sensitivity |
16.3 dBf (1.8 µV/75 Ω ) |
||
|
|
Alternate Channel Selectivity (400 kHz) |
65 dB |
|
|
|
|
|
|
|
|
|
|
Frequency Response |
40 Hz to 15 000 Hz |
|
|
|
|
|
|
|
|
|
|
Stereo Separation |
30 dB |
|
|
|
|
|
|
|
|
AM Tuner |
|
Sensitivity |
20 µV |
|
|
|
|
Selectivity |
35 dB |
|
|
|
|
|
|
|
|
|
|
CD PLAYER/USB MEMORY SECTION |
|
||
Type |
|
Compact disc player |
|||
|
|
|
|||
Signal Detection System |
|
Non-contact optical pickup (semiconductor laser) |
|||
Number of Channels |
|
2 channels (stereo) |
|
||
|
|
|
|
||
Frequency Response |
|
5 Hz to 20 000 Hz |
|
||
|
|
|
|
|
|
Dynamic Range |
|
96 dB |
|
|
|
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
98 dB |
|
|
|
|
|
|
|||
Wow and Flutter |
|
Less than measurable limit |
|||
|
|
|
|||
MP3 Decoding Format |
|
MPEG1/2 Audio Layer 3 |
|||
|
|
|
Max. Bit Rate : 320 kbps |
||
|
|
||||
WMA (Windows Media® Audio) Decoding |
Max. Bit Rate : 192 kbps |
||||
|
|
|
|
||
Playable USB memory |
|
Format |
FAT 12/16/32 |
|
|
|
|
|
|
||
|
|
Storage |
Less than 4 GB (1 partition type) |
||
|
|
|
|
|
|
|
|
Playable Audio Format |
MP3/WMA |
|
|
|
|
|
|
|
|
|
|
Max. Current |
Less than 500 mA |
|
|
|
|
|
|
|
|
|
|
GENERAL |
|
|
|
Power Requirement |
|
Operating Voltage |
DC 14.4 V (11 V to 16 V allowance) |
||
|
|
|
|
|
|
Grounding System |
|
Negative ground |
|
||
|
|
|
|
||
Allowable Operating Temperature |
|
0°C to +40°C |
|
||
Dimensions (W × H × D) |
|
Installation Size (approx.) |
182 mm × |
52 mm × |
152 mm |
|
|
Panel Size (approx.) |
188 mm × |
58 mm × |
11 mm |
Mass (approx.) |
|
1.4 kg (excluding accessories) |
1-4 (No.MA249)
KD-G825
|
|
AUDIO AMPLIFIER SECTION |
|
||
Maximum Power Output |
|
Front |
50 W per channel |
|
|
|
|
|
|
|
|
|
|
Rear |
50 W per channel |
|
|
|
|
|
|||
Continuous Power Output (RMS) |
Front |
19 W per channel into 4 Ω , 40 Hz to 20 000 Hz at no more than 0.8% total |
|||
|
|
|
harmonic distortion. |
|
|
|
|
|
|
||
|
|
Rear |
19 W per channel into 4 Ω , 40 Hz to 20 000 Hz at no more than 0.8% total |
||
|
|
|
harmonic distortion. |
|
|
|
|
|
|
|
|
Load Impedance |
|
4 Ω (4 Ω |
to 8 Ω allowance) |
||
Tone Control Range |
|
Low |
±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz) |
||
|
|
|
|
||
|
|
Mid |
±12 dB (500 Hz, 1 kHz, 1.5 kHz, 2.5 kHz) |
||
|
|
|
|
||
|
|
High |
±12 dB (10 kHz, 12.5 kHz, 15 kHz, 17.5 kHz) |
||
|
|
|
|
|
|
Frequency Response |
|
40 Hz to 20 000 Hz |
|
||
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
70 dB |
|
|
|
|
|
|
|||
Line-Out Level/Impedance |
|
5.0 V/20 kΩ load (full scale) |
|||
Output Impedance |
|
1 kΩ |
|
|
|
Subwoofer-Out Level/Impedance |
|
2.0 V/20 kΩ load (full scale) |
|||
Other Terminal |
|
CD changer |
|
||
|
|
|
|
|
|
|
|
TUNER SECTION |
|
|
|
Frequency Range |
|
FM |
87.5 MHz to 108.0 MHz |
||
|
|
|
|
||
|
|
AM |
531 kHz to 1 602 kHz |
||
|
|
|
|
||
FM Tuner |
|
Usable Sensitivity |
11.3 dBf (1.0 µV/75 Ω ) |
||
|
|
50 dB Quieting Sensitivity |
16.3 dBf (1.8 µV/75 Ω ) |
||
|
|
Alternate Channel Selectivity (400 kHz) |
65 dB |
|
|
|
|
|
|
|
|
|
|
Frequency Response |
40 Hz to 15 000 Hz |
|
|
|
|
|
|
|
|
|
|
Stereo Separation |
30 dB |
|
|
|
|
|
|
|
|
AM Tuner |
|
Sensitivity |
20 µV |
|
|
|
|
Selectivity |
35 dB |
|
|
|
|
|
|
|
|
|
|
CD PLAYER/USB MEMORY SECTION |
|
||
Type |
|
Compact disc player |
|||
|
|
|
|||
Signal Detection System |
|
Non-contact optical pickup (semiconductor laser) |
|||
Number of Channels |
|
2 channels (stereo) |
|
||
|
|
|
|
||
Frequency Response |
|
5 Hz to 20 000 Hz |
|
||
|
|
|
|
|
|
Dynamic Range |
|
96 dB |
|
|
|
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
98 dB |
|
|
|
|
|
|
|||
Wow and Flutter |
|
Less than measurable limit |
|||
|
|
|
|||
MP3 Decoding Format |
|
MPEG1/2 Audio Layer 3 |
|||
|
|
|
Max. Bit Rate : 320 kbps |
||
|
|
||||
WMA (Windows Media® Audio) Decoding |
Max. Bit Rate : 192 kbps |
||||
|
|
|
|
||
Playable USB memory |
|
Format |
FAT 12/16/32 |
|
|
|
|
|
|
||
|
|
Storage |
Less than 4 GB (1 partition type) |
||
|
|
|
|
|
|
|
|
Playable Audio Format |
MP3/WMA |
|
|
|
|
|
|
|
|
|
|
Max. Current |
Less than 500 mA |
|
|
|
|
|
|
|
|
|
|
GENERAL |
|
|
|
Power Requirement |
|
Operating Voltage |
DC 14.4 V (11 V to 16 V allowance) |
||
|
|
|
|
|
|
Grounding System |
|
Negative ground |
|
||
|
|
|
|
||
Allowable Operating Temperature |
|
0°C to +40°C |
|
||
Dimensions (W × H × D) |
|
Installation Size (approx.) |
182 mm × |
52 mm × |
152 mm |
|
|
Panel Size (approx.) |
188 mm × |
58 mm × |
11 mm |
Mass (approx.) |
|
1.4 kg (excluding accessories) |
(No.MA249)1-5
KD-G827
|
|
AUDIO AMPLIFIER SECTION |
|
||
Maximum Power Output |
|
Front |
50 W per channel |
|
|
|
|
|
|
|
|
|
|
Rear |
50 W per channel |
|
|
|
|
|
|||
Continuous Power Output (RMS) |
Front |
19 W per channel into 4 Ω , 40 Hz to 20 000 Hz at no more than 0.8% total |
|||
|
|
|
harmonic distortion. |
|
|
|
|
|
|
||
|
|
Rear |
19 W per channel into 4 Ω , 40 Hz to 20 000 Hz at no more than 0.8% total |
||
|
|
|
harmonic distortion. |
|
|
|
|
|
|
|
|
Load Impedance |
|
4 Ω (4 Ω |
to 8 Ω allowance) |
||
Tone Control Range |
|
Low |
±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz) |
||
|
|
|
|
||
|
|
Mid |
±12 dB (500 Hz, 1 kHz, 1.5 kHz, 2.5 kHz) |
||
|
|
|
|
||
|
|
High |
±12 dB (10 kHz, 12.5 kHz, 15 kHz, 17.5 kHz) |
||
|
|
|
|
|
|
Frequency Response |
|
40 Hz to 20 000 Hz |
|
||
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
70 dB |
|
|
|
|
|
|
|||
Line-Out Level/Impedance |
|
5.0 V/20 kΩ load (full scale) |
|||
Output Impedance |
|
1 kΩ |
|
|
|
Subwoofer-Out Level/Impedance |
|
2.0 V/20 kΩ load (full scale) |
|||
Other Terminal |
|
CD changer |
|
||
|
|
|
|
|
|
|
|
TUNER SECTION |
|
|
|
Frequency Range |
|
FM1/FM2 |
87.5 MHz to 108.0 MHz |
||
|
|
|
|
||
|
|
FM3 |
65.00 MHz to 74.00 MHz |
||
|
|
|
|
||
|
|
AM |
(MW) 522 kHz to 1 620 kHz |
||
|
|
|
(LW) 144 kHz to 279 kHz |
||
|
|
|
|
||
FM Tuner |
|
Usable Sensitivity |
11.3 dBf (1.0 µV/75 Ω ) |
||
|
|
50 dB Quieting Sensitivity |
16.3 dBf (1.8 µV/75 Ω ) |
||
|
|
Alternate Channel Selectivity (400 kHz) |
65 dB |
|
|
|
|
|
|
|
|
|
|
Frequency Response |
40 Hz to 15 000 Hz |
|
|
|
|
|
|
|
|
|
|
Stereo Separation |
30 dB |
|
|
|
|
|
|
|
|
MW Tuner |
|
Sensitivity |
20 µV |
|
|
|
|
Selectivity |
35 dB |
|
|
|
|
|
|
|
|
LW Tuner |
|
Sensitivity |
50 µV |
|
|
|
|
CD PLAYER/USB MEMORY SECTION |
|
||
Type |
|
Compact disc player |
|||
|
|
|
|||
Signal Detection System |
|
Non-contact optical pickup (semiconductor laser) |
|||
|
|
|
|
||
Number of Channels |
|
2 channels (stereo) |
|
||
|
|
|
|
||
Frequency Response |
|
5 Hz to 20 000 Hz |
|
||
|
|
|
|
|
|
Dynamic Range |
|
96 dB |
|
|
|
|
|
|
|
|
|
Signal-to-Noise Ratio |
|
98 dB |
|
|
|
|
|
|
|||
Wow and Flutter |
|
Less than measurable limit |
|||
|
|
|
|||
MP3 Decoding Format |
|
MPEG1/2 Audio Layer 3 |
|||
|
|
|
Max. Bit Rate : 320 kbps |
||
WMA (Windows Media® Audio) Decoding Format |
Max. Bit Rate : 192 kbps |
||||
|
|
|
|
||
Playable USB memory |
|
Format |
FAT 12/16/32 |
|
|
|
|
|
|
||
|
|
Storage |
Less than 4 GB (1 partition type) |
||
|
|
|
|
|
|
|
|
Playable Audio Format |
MP3/WMA |
|
|
|
|
|
|
|
|
|
|
Max. Current |
Less than 500 mA |
|
|
|
|
|
|
|
|
|
|
GENERAL |
|
|
|
Power Requirement |
|
Operating Voltage |
DC 14.4 V (11 V to 16 V allowance) |
||
|
|
|
|
|
|
Grounding System |
|
Negative ground |
|
||
|
|
|
|
||
Allowable Operating Temperature |
|
0°C to +40°C |
|
||
Dimensions (W × H × D) |
|
Installation Size (approx.) |
182 mm × |
52 mm × |
152 mm |
|
|
Panel Size (approx.) |
188 mm × |
58 mm × |
11 mm |
Mass (approx.) |
|
1.4 kg (excluding accessories) |
|||
|
|
|
|
|
|
•Design and specifications are subject to change without notice.
•Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/ or other countries.
•iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
1-6 (No.MA249)
SECTION 1
PRECAUTIONS
1.1Safety Precautions
! Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
! |
Please use enough caution not to see the beam directly or touch it in case of an |
|
adjustment or operation check. |
|
|
(No.MA249)1-7
1.2Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.2.1Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products. Be careful to use proper grounding in the area where repairs are being performed.
(1)Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the traverse unit (optical pickup) on it.
(2)Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(caption)
Anti-static wrist strap
1M
Conductive material (conductive sheet) or iron plate
(3)Handling the optical pickup
•In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
•Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily destroy the laser diode.
1.3Handling the traverse unit (optical pickup)
(1)Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2)Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a time when attaching it to the connector.
(3)Handle the flexible cable carefully as it may break when subjected to strong force.
(4)It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1.4Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the pickup unit.
•Apply solder to the short land before the flexible wire is disconnected from the connector on the pickup unit. (If the flexible wire is disconnected without applying solder, the pickup may be destroyed by static electricity.)
•In the assembly, be sure to remove solder from the short land after connecting the flexible wire.
Short-circuit point (Soldering)
Flexible wire
Pickup
1-8 (No.MA249)
1.5Important for laser products
1.CLASS 1 LASER PRODUCT
2.DANGER : Invisible laser radiation when open and inter lock failed or defeated. Avoid direct exposure to beam.
3.CAUTION : There are no serviceable parts inside the Laser Unit. Do not disassemble the Laser Unit. Replace the complete Laser Unit if it malfunctions.
4.CAUTION : The CD,MD and DVD player uses invisible laser radiation and is equipped with safety switches which prevent emission of radiation when the drawer is open and the safety interlocks have failed or are defeated. It is dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of procedures other than those specified here in may result in hazardous radiation exposure.
! |
|
Please use enough caution not to |
|||
|
|
see the beam directly or touch it |
|||
|
|
in case of an adjustment or operation |
|||
|
|
check. |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
REPRODUCTION AND POSITION OF LABELS
WARNING LABEL
CLASS 1
LASER PRODUCT
CAUTION : Visible and Invisible laser radiation when open and interlock failed or defeated. AVOID DIRECT EXPOSURE TO BEAM. (e)
ADVARSEL : Synlig og usynlig laserstråling når maskinen er åben eller interlocken fejeler. Undgå direkte eksponering til stråling. (d)
VARNING : Synlig och osynling laserstrålning när den öppnas och spärren är urkopplad. Betrakta ej strålen. (s)
VARO : Avattaessa ja suojalukitus ohitettuna tai viallisena olet alttiina näkyvälle ja näkymättömälle lasersäteilylle. Vältä säteen kohdistumista suoraan itseesi. (f)
(No.MA249)1-9
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 DIFFERENT POINT
|
KD-AR870 |
KD-G820 |
KD-G821 |
KD-G824 |
KD-G825 |
KD-G827 |
|
|
|
|
|
|
|
LINE IN |
YES |
NO |
NO |
NO |
NO |
NO |
|
|
|
|
|
|
|
RDS |
NO |
NO |
YES |
NO |
NO |
NO |
|
|
|
|
|
|
|
STEERING WHEEL REMOTE INPUT |
NO |
NO |
YES |
NO |
NO |
NO |
|
|
|
|
|
|
|
1-10 (No.MA249)
SECTION 3
DISASSEMBLY
3.1Main body section
3.1.1Removing the front panel assembly (See Fig.1)
(1)Push the control panel release button in the lower left part of the front panel assembly and remove the front panel assembly.
(2)Take out the front panel assembly.
3.1.2Removing the bottom cover (See Fig.2)
(1)Turn the main body up side down.
(2)Insert a screwdriver under the joints to release the joints a on the left side, joints b on the right side and joint c on the back side of the main body, then remove the bottom cover from the main body.
Caution:
When releasing the joints using a screwdriver, do not damage the main board.
Front panel assembly
Control panel release button
Fig.1
Bottom cover
b
a
b
a c
Fig.2
(No.MA249)1-11
3.1.3 Removing the front chassis assembly (See Figs.3 and 4)
•Remove the front panel assembly and bottom cover.
(1)Remove the two screws A on the front side of the main body. (See Fig.3)
(2)Remove the two screws B on the both sides of the main body. (See Fig.4)
(3)Release the joints d and joints e on the both sides of the main body, and then remove the front chassis assembly toward the front. (See Fig.4)
3.1.4Removing the side panel (See Fig.5)
Reference:
Remove the front panel assembly as required.
(1)Remove the two screws C and three screws D attaching the side panel on the left side of the main body.
(2)Take out the side panel from the main body.
Front chassis assembly
A
Fig.3
B B
d |
e |
|
Front chassis assembly
Fig.4
C D D C
Side panel D
Fig.5
1-12 (No.MA249)
3.1.5Removing the rear bracket
(See Fig.6) [For KD-AR870, KD-G820 and KD-G821]
•Remove the bottom cover.
(1)Remove the four screws E, two screws F and two screws G attaching the rear bracket on the back side of the main body.
(2)Take out the rear bracket.
3.1.6 Removing the rear bracket
(See Fig.6) [For KD-G824, KD-G825 and KD-G827]
•Remove the bottom cover.
(1)Remove the three screws E, three screws F and two screws G attaching the rear bracket on the back side of the main body.
(2)Take out the rear bracket.
3.1.7Removing the main board (See Figs.6 to 8)
•Remove the front panel assembly, bottom cover, front chassis assembly and side panel.
(1)Remove the four screws E for KD-AR870, KD-G820 and KD-G821 or three screws E for KD-G824, KD-G825 and KD-G827 attaching the rear bracket on the back side of the main body. (See Fig.6.)
(2)Remove the three screws H attaching the main board. (See Fig.7)
(3)Disconnect the connector CN501 and take out the main board. (See Fig.7)
(4)Remove the one screw J attaching the USB board. (See Fig.8)
Reference:
Remove the rear bracket as required.
for KD-AR870, KD-G820, KD-G821 |
|
F Rear bracket G |
F |
E |
E |
|
E |
||||||
for KD-G824, KD-G825,KD-G827 |
|
|
|
|
|||||
|
F Rear bracket G |
|
F |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
E E
Fig.6
Main board
H H
H
CN501 |
Rear bracket |
|
Fig.7
CD mechanism assembly
Main board
Fig.8
J
(No.MA249)1-13
3.1.8 Removing the CD mechanism assembly (See Fig.9)
•Remove the front panel assembly, bottom cover, front chassis assembly, side panel, main board and CD mechanism control board.
(1)Remove the three screws K attaching the top chassis.
(2)Take out the CD mechanism assembly.
3.1.9 Removing the switch board (See Figs.10 to 13)
•Remove the front panel assembly.
(1)Release the main volume knob from the front panel assembly. (See Fig.10)
(2)Remove the five screws L and one screw M attaching the front panel assembly. (See Fig.11)
(3)Release the nine joints f and take out the rear cover. (See Fig.12)
(4)Lift the switch board from the front panel assembly little by little and take out the switch board. (See Fig.13)
K |
CD mechanism assembly |
Top chassis |
|
|
|
Fig.9 |
Volume knob |
Front panel assembly |
Fig.10
L
M
Rear cover
Fig.11
f |
Rear cover |
f |
|
|
|
|
|
|
|
|
|
f
Fig.12
Switch board
Fig.13
3.2CD mechanism section
For the CD mechanism, please refer the mechanism manual TN2001-1118 (No.MY004).
1-14 (No.MA249)
SECTION 4 ADJUSTMENT
4.1Adjustment method
Test instruments required for adjustment
(1)Digital oscilloscope (100MHz)
(2)Electric voltmeter
(3)Digital tester
(4)Tracking offset meter
(5)Test Disc JVC :CTS-1000
(6)Extension cable for check EXTSH002-22P × 1
Standard volume position
Balance and Bass &Treble volume : lndication"0" Loudness : OFF
Standard measuring conditions |
|
|
Power supply voltage |
DC14.4V(11 to 16V) |
|
Load impedance |
20KΩ (2 Speakers connection) |
|
Output Level KD-ARXXX |
Line out 4.0V |
(Vol. MAX) |
KD-GXXX |
Line out 2.5V |
(Vol. MAX) |
Dummy load
Exclusive dummy load should be used for AM,and FM. For FM dummy load,there is a loss of 6dB between SSG output and antenna input.The loss of 6dB need not be considered since direct reading of figures are applied in this working standard.
How to connect the extension cable for adjusting
Caution:
Be sure to attach the heat sink and rear bracket onto the power amplifier IC and regulator IC respectively, before supply the power. If voltage is applied without attaching these parts, the power amplifier IC and regulator IC will be destroyed by heat.
EXTSH002-22P
Side panel
Rear bracket
CN501
(No.MA249)1-15
SECTION 5
TROUBLESHOOTING
5.1Feed section
Is 4V present at both |
YES |
||
|
|||
sides of the feed motor? |
|
||
|
|
|
|
|
NO |
|
|
|
|
YES |
|
Is the voltage output at |
|||
|
|||
pin 4 and pin 5 of IC501? |
|
||
|
|
|
|
|
NO |
|
Is the voltage input at pin YES 28 of IC501?
|
NO |
|
|
|
|
|
YES |
||
Is the voltage output at |
||||
|
|
|||
pin 12 of IC541? |
|
|
||
|
|
|
|
|
|
NO |
|
|
|
|
|
|
Is the power supply
present at pins 8,16,25, YES 28,32,53,71 and pin 90
of IC541?
NO
Check the connections of CD8V power supply.
5.2Focus section
When the lens is moving:
4V YES
Does the S-search waveform appear at IC501 pins 8 and 9?
NO
Is the voltage input at pin YES 15 of IC501?
NO
Is the voltage output at |
YES |
|
|
||
pin 9 of IC541? |
|
|
|
|
|
|
NO |
|
|
|
Is the power supply
present at pins 8,16,25, YES 28,32,53,71 and pin 90
of IC541?
NO
Check the connections of CD8V power supply.
Check the feed motor.
Check the connections between the feed motor and IC501.
Is the power supply present at pin 3, pin 12 and pin 21 of IC501?
NO
Check the connections of CD8V power supply.
Check the connections between IC501 and IC541.
Check IC541.
Check the pickup and its connections.
Is the power supply present at pin 3, pin 12 and pin 21 of IC501?
NO
Check the connections of CD8V power supply.
Check the connections between IC501 and IC541.
Check IC541.
YES
Check IC501.
YES
Check IC501.
1-16 (No.MA249)
5.3Spindle section
YES Is the disk rotated?
|
NO |
|
|
|
|
|
YES |
||
Is the voltage output at |
||||
|
|
|||
pin 6 and pin 7 of IC501? |
|
|
||
|
|
|
|
NO
Is the voltage input at pin YES 17 of IC501?
NO
Is the voltage output at |
YES |
||
|
|
||
pin 13 of IC541? |
|
|
|
|
|
|
|
|
NO |
|
|
Does the RF signal appear |
YES |
Is the RF waveform at |
|
|
|
|||||||||||
at pin 83 of IC541? |
|
|
|
|
|
pin 83 of IC541 distorted? |
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NO |
|
NO |
|
|
YES |
||
|
|
|
|
|
|
|
|
|
|
|
|
|||||
Check the spindle motor |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
Check the circuits in |
|
|
Proceed to the Tracking |
||||||||
and its wiring. |
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
the vicinity of IC541 |
|
|
section. |
||||||||
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
or the pickup. |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
Is the power supply |
YES |
|
|
|
|
|
|
|
|
|
|
|||||
|
|
Check IC501. |
|
|
|
|
|
|||||||||
present at pin 3, pin 12 |
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
||||||
and pin 21 of IC501? |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Check the connections |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
of CD8V power supply. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Check the connections |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
between IC501 and |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC541. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Is the power supply
present at pins 8,16,25, YES
Check IC541.
28,32,53,71 and pin 90 of IC541?
NO
Check the connections of CD8V power supply.
5.4Tracking section
When the disc is rotated at first:
Approx. 1.2V YES Replace IC541 or repair
the malfunction
connection point.
Is the tracking error signal output at pin 6 of IC541?
NO
Check the pickup and its connections.
(No.MA249)1-17
5.5Signal processing section
Is the sound output from |
YES |
Normal |
|
||||
both channels (L, R)? |
|
|
|
||||
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
NO |
|
|
|
|
|
|
|
|
YES |
|
|
YES |
||
No sound from either |
Is 9V present at pin 24 |
|
|||||
|
|
|
|||||
channel. |
|
|
of IC161? |
|
|||
|
|
|
|
|
|
|
NO
Compare the L-ch and R-ch to locate the defective point.
NO
Is 9V present at pin 13 |
YES |
||
|
|
||
of IC901? |
|
|
|
|
|
|
|
|
NO |
|
|
|
|
|
|
Check IC901 and its |
|
|
|
peripheral circuits. |
|
|
|
|
|
|
|
|
Is the audio signal |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
(including sampling |
YES |
|
Is the audio signal output |
|
||||||
|
output components) |
|
|
|
at pin 18 and pin 19 of |
|
|||||
|
|
|
|
|
|||||||
|
output to pins 1 and 7 of |
|
|
|
IC161 during playback? |
|
|||||
|
IC581 during playback? |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NO |
|
|
|
|
|
NO |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Check IC581 and its |
|
|
|
Check IC161 and its |
|
|
||||
|
peripheral circuits. |
|
|
|
peripheral circuits. |
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Check the connections |
|
|
|
|
|
|
|
|
|
|
|
between pin 24 of IC161 |
|
|
|
|
|
|
|
|
|
|
|
and pin 13 of IC901. |
|
|
|
|
|
YES |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
Check the power |
|
|
|
|
|
|
|
|
|
|
|
amplifier IC301. |
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
5.6Maintenance of laser pickup
(1)Cleaning the pick up lens
Before you replace the pick up, please try to clean the lens with a alcohol soaked cotton swab.
(2)Life of the laser diode
When the life of the laser diode has expired, the following symptoms will appear.
•The level of RF output (EFM output: amplitude of eye pattern) will be low.
Is RF output |
NO |
|
Replace it. |
||
1.3 0.4Vp-p? |
||
|
YES
OK
(3)Semi-fixed resistor on the APC PC board
The semi-fixed resistor on the APC printed circuit board which is attached to the pickup is used to adjust the laser power.Since this adjustment should be performed to match the characteristics of the whole optical block, do not touch the semi-fixed resistor.
If the laser power is lower than the specified value, the laser diode is almost worn out, and the laser pickup should be replaced. If the semi-fixed resistor is adjusted while the pickup is functioning normally, the laser pickup may be damaged due to excessive current.
5.7Replacement of laser pickup
Turn off the power switch and disconnect the power cord.
Replace the pickup with a normal one. (Refer
to "Removing the pickup unit" on the previous page.)
Plug the power cord in and turn the power on. At this time, check that the laser emits for about
seconds and the objective lens moves up and down. Note: Do not observe the laser beam directly.
Play a disc.
Check the eye-pattern at
RF test point or
ARF test point.
Finish.
1-18 (No.MA249)
5.816P CORD DIAGRAM (for KD-AR870)
8 |
BK |
|
YL |
16 |
|
|
|
|
7 |
RD |
|
OR/WH 15 |
|
|
|
|
|
6 |
NC |
|
NC |
14 |
BK |
Black |
GN |
Green |
5 |
BL/WH |
|
BR |
13 |
RD |
Red |
VI |
Violet |
|
|
|
|
|
BL |
Blue |
GY |
Gray |
4 |
WH |
|
WH/BK 12 |
WH |
White |
YL |
Yellow |
|
3 |
GN |
|
GN/BK 11 |
BR |
Brown |
OR |
Orange |
|
2 |
VI |
|
VI/BK 10 |
|
|
|
|
|
1 |
GY |
|
GY/BK |
9 |
|
|
|
|
|
|
16 |
YL |
|
MEMORY |
|
|
|
|
|
8 BK |
|
GND |
|
|
|
|
|
|
7 RD |
|
ACC |
|
|
GND |
|
|
|
|
|
|
|
|||
|
|
15 |
OR/WH |
|
ILL |
|
|
|
|
|
13 BR |
|
TEL |
|
|
|
|
|
|
5 BL/WH |
|
REMOTE |
|
|
|
|
|
|
|
|
|
CAUTION! |
|
|
|
|
|
|
|
|
REMOTE OUTPUTONLY |
|
|
|
|
|
3 GN |
|
RL+ |
|
|
|
|
|
|
11 GN/BK |
|
RL- |
|
|
|
|
|
|
2 |
VI |
|
RR+ |
|
|
|
|
|
10 |
VI/BK |
|
RR- |
|
|
|
|
|
4 WH |
|
FL+ |
|
|
|
|
|
|
12 |
WH/BK |
|
FL- |
|
|
|
|
|
1 |
GY |
|
FR+ |
|
|
|
|
|
9 |
GY/BK |
|
FR- |
|
|
|
RR |
Rear Right |
REMOTE |
Remote out |
|
|
|
|
FR |
Front Right |
ACC |
ACC Line |
|
|
|
|
FL |
Front Left |
MEMORY |
Memory Backup Battery + |
|
|
|
|
RL |
Rear Left |
GND |
Ground |
|
|
|
|
TEL |
Telephone muting |
ILL |
Illuminations Control |
|
|
|
|
(No.MA249)1-19
5.916 PIN CORD DIAGRAM (for KD-G820)
8 |
BK |
|
YL |
16 |
|
|
|
|
7 |
RD |
|
OR/WH 15 |
|
|
|
|
|
6 |
NC |
|
NC |
14 |
BK |
Black |
GN |
Green |
5 BL/WH |
|
NC |
13 |
RD |
Red |
VI |
Violet |
|
|
|
|
|
|
BL |
Blue |
GY |
Gray |
4 |
WH |
|
WH/BK 12 |
WH |
White |
YL |
Yellow |
|
3 |
GN |
|
GN/BK 11 |
|
|
OR |
Orange |
|
2 |
VI |
|
VI/BK 10 |
|
|
|
|
|
1 |
GY |
|
GY/BK |
9 |
|
|
|
|
|
|
16 |
YL |
|
MEMORY |
|
|
|
|
|
8 BK |
|
GND |
|
|
|
|
|
|
7 RD |
|
ACC |
|
|
GND |
|
|
|
|
|
|
|
|||
|
|
15 |
OR/WH |
|
ILL |
|
|
|
|
|
5 BL/WH |
|
REMOTE |
|
|
|
|
|
|
|
|
|
CAUTION! |
|
|
|
|
|
|
|
|
REMOTE OUTPUTONLY |
|
|
|
|
|
3 GN |
|
RL+ |
|
|
|
|
|
|
11 GN/BK |
|
RL- |
|
|
|
|
|
|
2 |
VI |
|
RR+ |
|
|
|
|
|
10 |
VI/BK |
|
RR- |
|
|
|
|
|
4 WH |
|
FL+ |
|
|
|
|
|
|
12 |
WH/BK |
|
FL- |
|
|
|
|
|
1 |
GY |
|
FR+ |
|
|
|
|
|
9 |
GY/BK |
|
FR- |
|
|
|
RR |
Rear |
Right |
REMOTE |
Remote out |
|
|
|
|
|
FR |
Front |
Right |
ACC |
ACC Line |
|
|
|
|
|
FL |
Front |
Left |
MEMORY |
Memory Backup Battery + |
|
|
|
|
|
RL |
Rear |
Left |
GND |
Ground |
|
|
|
|
|
|
|
|
ILL |
Illuminations Control |
|
|
|
|
|
1-20 (No.MA249)
5.10 16 PIN CORD DIAGRAM (for KD-G821,KD-G827)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 |
BK |
|
|
|
YL |
16 |
|
|
|
|
BK |
Black |
GN |
Green |
|
|
|
|
|
|
|
7 |
RD |
|
|
|
OR/WH |
15 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RD |
Red |
VI |
Violet |
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
6 |
NC |
|
|
|
NC |
14 |
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
BL |
Blue |
GY |
Gray |
|
|
|
|
||||
|
|
|
5 |
BL/WH |
|
|
|
BR |
13 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
WH |
White |
YL |
Yellow |
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
WH |
|
|
|
WH/BK |
12 |
|
|
|
|
BR |
Brown |
OR |
Orange |
|
|
|
|
|
|
|
3 |
GN |
|
|
|
GN/BK |
11 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
VI |
|
|
|
VI/BK |
10 |
|
|
|
|
|
|
|
1 |
NC |
BR |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
1 |
GY |
|
|
|
GY/BK |
9 |
|
|
|
|
|
|
|
3 |
NC |
YL |
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5 |
BL/WH OR/WH |
6 |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 |
RD |
BK |
8 |
|
|
|
RD |
|
7 |
RD |
ACC |
RD |
7 |
16 |
YL |
MEMORY |
YL |
4 |
15 |
OR/WH |
ILL |
|
6 |
8 |
BK |
GND |
|
8 |
6 |
BL/WH |
REMOTE |
|
5 |
13 |
BR |
TEL |
|
2 |
3 |
GN |
RL+ |
|
7 |
11 |
GN/BK |
RL- |
|
8 |
2 |
VI |
RR+ |
|
1 |
|
|
|||
10 |
VI/BK |
RR- |
|
2 |
4 |
WH |
FL+ |
|
5 |
12 |
WH/BK |
FL- |
|
6 |
1 |
GY |
FR+ |
|
3 |
9 |
GY/BK |
FR- |
|
4 |
|
|
|
|
1 |
VI |
VI/BK |
|
|
|
|
3 |
GY |
GY/BK |
RR |
Rear Right |
ANT |
Auto Antenna |
5 |
WH WH/BK |
|
|
|
|
|
|||
FR |
Front Right |
ACC |
ACC Line |
7 |
GN |
GN/BK |
FL |
Front Left |
TEL |
Telephone Muting |
|
|
|
RL |
Rear Left |
GND |
Ground |
|
|
|
REMOTE |
Remote |
MEMORY |
Memory Backup Battery+ |
|
|
|
2
4
6
8
ILL |
Illuminations Control |
(No.MA249)1-21
5.11 16 PIN CORD DIAGRAM (for KD-G824,KD-G825)
8 |
|
|
|
BK |
|
YL |
16 |
|
|
|
|
|
|
|
|
|
|
|
||||||||
7 |
|
|
RD |
|
OR/WH 15 |
|
BK |
Black |
GN |
Green |
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NC |
|
|
|
|
|
|
|
|
|
|
|
|
6 |
|
|
|
BL |
|
14 |
|
RD |
Red |
VI |
Violet |
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|||||||||||||||||||
5 |
|
|
BL/WH |
|
BR |
13 |
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
BL |
Blue |
GY |
Gray |
|
|
|||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
4 |
|
|
|
WH |
|
WH/BK |
12 |
|
WH |
White |
YL |
Yellow |
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
BR |
Brown |
OR |
Orange |
|
|
||||||||||||||||
3 |
|
|
|
GN |
|
GN/BK |
11 |
|
|
|
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
2 |
|
|
|
VI |
|
VI/BK |
10 |
|
|
|
|
|
|
|
|
|
|
|
||||||||
1 |
|
|
|
GY |
|
GY/BK |
9 |
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MEMORY |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
16 |
YL |
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
8 BK |
|
GND |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
7 RD |
|
ACC |
|
|
|
|
|
GND |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
15 |
OR/WH |
|
ILL |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
13 |
BR |
|
TEL |
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
3 GN |
|
RL+ |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
11 GN/BK |
|
RL- |
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
VI |
|
RR+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
10 |
VI/BK |
|
RR- |
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
4 WH |
|
FL+ |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
FL- |
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
12 |
WH/BK |
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
GY |
|
FR+ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
9 |
GY/BK |
|
FR- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5 BL/WH |
|
REMOTE |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CAUTION!REMOTE
6 BL |
ANT |
OUTPUT ONLY
POWER |
ANTENNA |
|
RR |
Rear |
Right |
ANT |
Auto |
Antenna |
|
|
FR |
Front |
Right |
ACC |
ACC |
Line |
|
|
FL |
Front |
Left |
ILL |
Illuminations Control |
|
|
|
|
|
|
|
|
|
|
|
RL |
Rear |
Left |
GND |
Ground |
|
|
|
REMOTE |
Remote out |
MEMORY Memory Backup Battery+ |
|
|||
|
|
||||||
|
TEL |
Telephone muting |
|
|
|
|
|
|
|
|
|
|
|
|
|
1-22 (No.MA249)
(No.MA249)1-23
Victor Company of Japan, Limited
Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,Gumma-ken, 371-8543,Japan
(No.MA249)
Printed in Japan VPT
