Daewoo DLM-26C3LPB, DLM-26C3, DLM-26C3B, DLM-26C3PBD, DLM-26C3LPBD Instruction Manual

LCD TELEVISION

INSTRUCTION MANUAL

DLM-26C3(B/BD/P/PB/PBD/R)
DLM-32C1(B/BD/P/PB/PBD/R)
DLM-32C3(B/BD/P/PB/PBD/R)
DLM-32C5(B/BD/P/PB/PBD/R)
DLM-32C7(B/BD/P/PB/PBD/R)
DLM-32U1(B/BD/P/PB/PBD/R)
DLM-32U2(B/BD/P/PB/PBD/R)
DLM-37C7(B/BD/P/PB/PBD/R)
DLM-42C1(B/BD/P/PB/PBD/R)
DLM-42C5(B/BD/P/PB/PBD/R)
DLM-42C7(B/BD/P/PB/PBD/R)

Caution

2

WARNING :

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION :

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulat­ed “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk electric shock.

The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and servic­ing instructions in the literature accompanying the appliance.

Important
Safeguards

3

Please read the following safeguards for your TV and retain for future reference.
Always follow all warnings and instructions marked on the television.

1. Read, Retain and Follow All Instructions

Read all safety and operating instructions before operating the TV. Retain them safely
for future reference. Follow all operations and instructions accordingly.

2. Heed Warnings

Adhere to all warnings on the appliance and in the operating instructions.

3. Cleaning

Unplug the TV from the wall outlet before cleaning. Do not use liquid, abrasive, or aerosol cleaners.
Cleaners can permanently damage the cabinet and screen. Use a lightly dampened cloth for
cleaning.

4. Attachments and Equipment

Never add any attachment and/or equipment without approval of the manufacturer as such additions may
result in the risk of fire, electric shock or other personal injury.

5. Water and Moisture

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.

6. Setting

Do not place this TV on an unstable cart, stand or table. Placing the TV on an unstable base can
cause the TV to fall, resulting in serious personal injuries as well as damage to the TV. Use only a
cart, stand, bracket or table recommended by the manufacturer or salesperson.

7. Ventilation

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the TV and to
protect it from overheating. Do not cover the ventilations openings in the cabinet and never place the set in a confined
space such as built-in cabinet unless proper ventilation is provided. Leave a minimum 10 cm gap all around the unit.

8. Power Source

This TV should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supplied to your home, consult your appliance dealer or local power company.

9. Grounding or Polarization

This TV is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This
plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug. A warning that an apparatus with CLASS I construction
shall be connected to a MAINS socket outlet with a protective earthing connection.

10. Power-Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs, wall outlets, and the point
where they exit from the TV.

MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.

11. Lightning

For added protection for this TV during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the TV due to lightning and power-line surges.

12. Wall or Ceiling Mounting

When mounting the product on a wall or ceiling, be sure to install the product using the designated
mounting tool according to the method recommended by the manufacturer.

Important

Safeguards

4

13. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light
or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching such power lines or circuits as contact with
them might be fatal.

14. Overloading

Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

15. Object and Liquid Entry

Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or
short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into the TV.

16. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the TV, be
sure the antenna or cable system is grounded so as to provide
some protection against voltage surges and built-up static charges.
Section 810 of the National Electric Code, ANSI /NFPA No. 70-1984,
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead in wire to an antenna
discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.

17. Servicing

Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.

18. Damage Requiring Service

Unplug the TV from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
(a) When the power-supply cord or plug is damaged.
(b) If liquid has been spilled, or objects have fallen into the TV.
(c) If the TV has been exposed to rain or water.
(d) If the TV does not operate normally by following the operating instructions. Adjust only those controls

that are covered by the operating instructions as an improper adjustment of other controls may result in

damage and will often require extensive work by a qualified technician to restore the TV to its normal operation.
(e) If the TV has been dropped or the cabinet has been damaged.
(f) When the TV exhibits a distinct change in performance - this indicates a need for service.

19. Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock or other hazards.

20. Safety Check

Upon completion of any service or repair to the TV, ask the service technician to perform safety checks to
determine that the TV is in safe operating condition.

21. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.

ANTENNA
LEAD IN WIRE

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING
CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

GROUND CLAMP

ELECTRIC
SERVICE
EQUIPMENT

NEC — NATIONAL ELECTRICAL CODE

EXAMPLE OF ANTENNA GROUNDING

Warning

5

This section must be read carefully and followed by the user prior to the operation of the product.

The manual states important instructions for the user's own safety, and the proper operation of the product.

In case of an accident, please unplug the unit from the outlet immediately.

Hold the plug when unplugging the unit
from the outlet. The cord may cause fire
or electric shock if damaged.

Do not cause the product to lean or put it in
an unstable place since it may cause a
serious injury to a person, as well as damage
to the product if it falls.

Do not put any object that contains water ­such as flowerpot - near to the unit.
The water may penetrate into the unit, and
be a cause of fire or hazardous electric
shock.

To reduce the risk of electric shock, do
not remove cover or back. No user ­serviceable parts inside. Refer to qualified
service personnel for repair.

Do not put on or use the product near water
and moisture-such as in a bathroom,
washbowl, etc. It may be a cause of fire and
electric shock hazards.

To prevent fire and damages to the product,
unplug the unit from the outlet during
lightning storm, or when it is left unattended
and unused for a long period of time.

Do not let children hang on or climb on
the product since it may be a cause of
serious injury.

Slots and openings in the case are provided
for ventilation to ensure reliable operation of
the product. Never put in any item-such as a
coin, paper, match- through these openings
since it may touch dangerous voltage points
that could result in fire or shock hazard.

Do not put volatile substance-such as
benzene, naphtha- near the product since it
may cause a change in the product's colour.

Do not view the TV too closely since it
may cause damage in your eyesight.

Do not spill water or drop the remote
controller since it may be a cause of
malfunctioning.

Refer servicing to qualified service
personnel for cleaning at least once a year
since dust inside the TV set may be a result
or fire and malfunctioning of the product.

Warning

6

The product should be situated away from
any heat source-such as radiators, heat
registers, stoves, or other products that
produce heat.

Do not put on any heavy item on the
power cord since it may result in fire or
hazardous electric shock if the cord is
damaged.

Do not cover the top of the television set.
Ventilation will be prevented, and it may
be a cause of fire if the product is
internally overheated.

Unplug the power from the outlet and all the
related connections from the unit to prevent
electric shock. At least two people must work
together to move the TV set when transporting
to prevent the TV from falling, and
consequently, any serious injury or damage.

Do not touch the power cord with
moisturized or wet hands when plugging
to or unplugging from the outlet since it
may be a cause of electric shock.

Please be advised of electric wires and cables
when installing the antenna. It may be a cause of
hazardous electric shock and fire if the antenna
touches or falls on the electric wire; thus, it must be
installed firmly, and far away from the cables.

This section must be read carefully and followed by the user prior to the operation of the product.

The manual states important instructions for the user's own safety, and the proper operation of the product.

Please keep the user's manual in a safe place for future reference.

Do not expose the product to a dusty or
moisturized place since it may be a cause
of malfunctioning.

Please place the TV set in such a way
that the main plug can be easily
disconnected.

The screen case of the product is scratched
easily.
When cleaning, use the microfiber sheet
which enclosed.
When a force to give it cleans strongly, it
will be scratched and the product's colour
will be changed. If foreign material gets in
the fiber, the product will be scratched.
Shake off the fiber cleanly and use.

Table of
Contents

7

Installation and Maintenance

Antenna Connection 9

Video Connection 12

Camcorder & Video Game Connection 13

DVD Player Connection 14

STB Connection 15

PC Connection 16

Cable TV Broadcasting Connection 18

Connect with the Dolby Digital AMP 19

Name of Each Part 20

Basic Guide

Parts of the Remote Controller 22

Method To Use Basic Menu 24

To Watch TV 25

Setting Up TV Stations 27

Selection of AV and Multimedia Input Signal 31

Application Guide

Screen Adjustment 33

PIP Mode 37

Sound Adjustment 39

Selection of Language 41

Adjustment of Time 42

Teletext 43

Troubleshooting 44

Standard of Product 46

Supplied

Accessories

8

Make sure that the following accessories are provided with the product.

AC cord

AC cord Instruction manual

M

U

T

E

M

U

L

T

I
M

E

D

I

A

T

V

/

A

V

S

L

E

E

P

P

O

W

E

R

S

.

E

F

F

E

C

T

V

O

L

V

O

L

P

R

P

R

S

E

L

E

C

T

O

K

M

E

D

I

T

P

R

E

V

P

R

N

O

R

M

A

L

I

N

D

E

X

M

G

D

I

S

-

C

O

D

E

H

O

L

D

T

.C

A

N

C

E

L

S

I

Z

E

T

E

X

T

R

E

V

E

A

L

P

.

S

/

S

T

I

L

L

P

.

I

N

P

U

T

P

.

M

O

D

E

P

.

S

W

A

P

P

.

P

R

R

E

C

A

L

L

D

Y

N

A

M

I

C

B

A

S

S
M

E

N

U

A

S

P

E

C

T

S

T

I

L

L

S

O

U

N

D

L

O

C

K

Remote controller

Batteries

Cover Bottom

-When you install wall mounting you set
up cover bottom like upper picture.

Cable holder

Microfiber sheet

(For 32C1/U1/U2, 42C1)

1

23

The method of wire arrangement

1. Assemble the cable holder enclosed on the back
of TV. (PICTURE 1)
(ASSEMBLY METHOD: After you push the
"A"(prominence part of cable holder) in the
hole, rotate the cable holder clockwise as an
angle of 90°. You can separate in reverse order
of assembly.)

2. Open the cable holder. (PICTURE 2)
( you can open the cable holder that press and
push "B" part.)

3. After arrange lines with the cable holder, lock the
"B" again. (PICTURE 3)

Antenna
Connection

9

Indoor Antenna Connection

1. Connect the feeder cable of the antenna to the combining adapter.

WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of wrong

antenna connection. Be sure to check its direction and place when
installing.

2. Connect the combining adapter to the antenna input at the left side of the TV set.

WHEN USING THE COMBINING ADAPTER : You may obtain the combining adapter at your closest

Service Center.

UP-GRADE

PORT

Antenna Input

BACK OF THE TV SET

Antenna

Connection

10

Antenna socket at the left side of the TV set

ANT/CABLE

ANT/CABLE

CTV Antenna Connection

Such community TV Antenna installation may be found in most of co-op apartments.

When a coaxial cable is used : Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to

the right.

When a feeder cable is used : Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to

the right.

Antenna socket at the left side of the TV set

Antenna
Connection

11

Outdoor Antenna Connection

Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses

Single Antenna Connection

Separate Antenna Connection.

UP-GRADE

PORT

VHF Antenna

UHF Antenna

ANT/CABLE

TV

ANT/CABLE

Video

Connection

12

AV1

MONITOR OUT

VIDEOR - AUDIO - L

MONITOR OUT

L - AUDIO - R

POWER

CH

VOL MENU

PLAY INPUT REW PLAY F.FWD

STOP/
EJECT

STAND

-BY

AV1

VIDEO

AV 2

S-VIDEOVIDEOR - AUDIO - L

AV 2

S-VIDEOVIDEOR - AUDIO - L

AV1

MONITOR OUT

VIDEOR - AUDIO - L

1. Prepare the RCA cable for picture / sound.

2. Connect the RCA to Monitor out terminal of 1’st TV set.

3. Connect the RCA to AV1 or AV2 input terminal of 2’st TV set.

4. Turn on the TV sets.

Note : If S-video and RCA jack are connected the same time, The TV set will only detect the S-Video mode.

• If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is

recommended for better picture quality.

Note :

• Monitor out works only CVBS signal. : RF, AV1, AV2(S-Video)

Connecting with an External Source

Connecting with the Monitor Out.

You may connect an S-Video input to enjoy clearer and brighter picture images. You can make the
connection with the AV1,AV2 inputs.

S-Video

TV

TV

Camcorder & Video
Game Connection

13

Note : If S-video and RCA jack are connected at the same time, the TV set only detects the S-Video mode.
* If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is

recommended for better picture quality.

Watching the Camcorder Recording on TV

1. Prepare the S-video and RCA connector.

2. These connectors connect to S-Video or AV1, AV2 as shown in the picture below.

3. Turn on the TV set and camcorder/video game.

4.

Select AV1, AV2(S-Video) mode, using the

”TV/AV”

button of the Remote controller or

“

”

button of

the TV set.

AV1

MONITOR OUT

VIDEOR - AUDIO - L

Video game

AV 2

S-VIDEOVIDEOR - AUDIO - L

TV

DVD Player

connection

14

INPUT

HDMI 1 HDMI 2

AV1

MONITOR OUT

COMPONENT INPUT

PC INPUT

OPTICAL

Pr Pb Y

VIDEOR - AUDIO - L

R - AUDIO - L

PC AUDIO

DIGITAL

AUDIO

AV 2

S-VIDEOVIDEOR - AUDIO - L

Note :

• When you connect with the component video, please check the colour of the cable between the DVD and

TV set.

Note :

If S-video and RCA jack are connected at the same time, the TV set will only detect the S-Video mode.

• If your AV device has both Video OUT terminal and S-Video OUT terminal, the S-Video connection is

recommended for better picture quality.

When connecting with a component cable

When connecting with a S-VHS cable and RCA cable

TV

TV

STB(Set Top Box)
Connection

15

INPUT

HDMI 1 HDMI 2

AV1

MONITOR OUT

COMPONENT INPUT

PC INPUT

OPTICAL

Pr Pb Y

VIDEOR - AUDIO - L

R - AUDIO - L

PC AUDIO

DIGITAL

AUDIO

Set Top Box

Set Top Box

INPUT

HDMI 1 HDMI 2

AV1

MONITOR OUT

COMPONENT INPUT

PC INPUT

OPTICAL

Pr Pb Y

VIDEOR - AUDIO - L

R - AUDIO - L

PC AUDIO

DIGITAL

AUDIO

When connecting with a HDMI cable

When connecting with a component cable

TV

TV
