S/M NO. : TSP901XEF1
Service Manual
32" PLASMA PDP TV
CHASSIS : SP-901X
Model : DPX-32F1BMB
Caution
:In this Manual, some parts can be changed for improving. their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List)in Service Information Center.
I. Parts with the exception of MODULE
1. Safety Precautions
(1)When moving or laying down a PDP Set, at least two people must work together. Avoid any impact towards the PDP Set.
(2)Do not leave a broken PDP Set on for a long time. To prevent any further damages, after checking the condition of the broken Set, make sure to turn the power(AC) off.
(3)When opening the BACK COVER, you must turn off power(AC) to prevent any electric shock. When PDP is operating, high voltage and high current inside the Set can cause electric shocks.
(4)When loosening screws, check the position and type of the screw. Sort out the screws and store them separately for reassembling.
Because screws holding PCBs are working as electric circuit GROUNDING, make sure to check if any screw is missing when assembling / reassembling. Do not leave any screws inside the set.
(5)If you open the BACK COVER,
you will see a Panel Gas Exhaust Tube (Picture. 1-1) inside the bracket.
If this part is damaged, the entire PDP PANEL must be replaced. Therefore, when working with the set, be careful not to damage this part.
(6)A PDP Set contains different kinds of connector cables.
When connecting or disconnecting cables,
check the direction and position of the cable |
Picture.1-1 Panel Gas Exhaust Tube |
beforehand. |
(7)Connect / disconnect the connectors slowly with care especially FFC(film) cables and FPC cables.
Do not connect or disconnect connectors instantaneously with force, and handle them carefully for reassembling.
(8)Connectors are designed so that if the number of pins or the direction does not match, connectors will not fit.
When having problem in plugging the connectors, check their kind, position, and direction.
-3-
2. Product Specification
2-1. Specification
ITEM |
SPECIFICATION |
REMARK |
|
|
|
1. GENERAL. |
|
|
1-1. MODL NO |
DPX-32F1BMB |
|
1-2. CHASSIS NO |
SP-901X |
|
1-3. SCREEN SIZE |
32”(16:9) |
|
1-4. COUNTRY |
Middle & South America |
|
1-5. RESOLUTION |
852(H) X 480(V) |
|
1-6. REMOCON TYPE |
R-55F06 |
|
1-7. SAFETY STANDARD |
CB |
|
1-8 .TUNING METHOD |
FS |
|
1-9. MEMORY CHANNEL |
181CH |
|
|
|
|
2. MECHANICAL |
|
|
2-1. APPEARANCE |
|
|
1) WITHOUT STAND |
W x H x D = 825 x 561 x 87.8 mm |
|
2) WITH STAND |
W x H x D = 825 x 603.2 x 233.6 mm |
|
2-2. WEIGHT |
|
|
1) WITHOUT STAND |
18.5 Kg |
|
2) WITH STAND |
19.2 Kg |
|
|
|
|
3. ELECTRICAL |
|
|
3-1. VIDEO INPUT |
COMPOSITE(NTSC, PAL, SECAM, PAL-M/N, NTSC4.43) 2 Ports & |
|
|
S-VHS(50/60Hz Y/C) 2 Ports |
|
3-2. DTV/DVD INPUT |
1080i, 720P, 480P, 480i, 576P, 576i |
|
|
(Y, Pb/Cb, Pr/Cr COMPONENT SIGNAL) 2 Ports |
|
3-3. PC INPUT |
VGA ~ WXGA(Dot clock : 110MHz), 15 PIN D-SUB 1 Port |
|
3-4. HDMI INPUT |
HDMI-H INPUT(HDMI Jack) 1 Port |
|
3-5. TV INPUT |
|
|
1) COLOR STANDARD |
NTSC-M, PAL M/N |
|
2) ANTENNA IN |
ONE INPUT 75 Unbalanced (F-Type Standard) |
|
3) RECEPTION CHANNEL |
VHF : Ch 02 ~ 13 |
|
|
UHF : Ch 14 ~ 69 |
|
|
CATV : Ch 1, 14 ~ 125 |
|
4) IF & SUBCARRIER |
PIF : 45.75MHz |
|
|
SIF : 41.25MHz |
|
3-6. SOUND INPUT |
VIDEO 2 Ports, DTV/DVD 2 Ports, PC/HDMI 1 Port |
|
3-7. SPEAKER OUTPUT |
10W(R) + 10W(L) |
|
3-8. POWER REQUIREMENT |
AC 100V~240V, 50/60Hz |
|
|
|
|
-4-
Product Specification
ITEM |
SPECIFICATION |
REMARK |
|
|
|
3-9. POWER CONSUMPTION |
200 W |
|
3-10.Phone Jack(Upgrade) |
S/W Upgrade |
|
3-11. AV OUTPUT |
CVBS, SOUND R/L 1 Port |
|
3-12. FUNCTION |
|
|
1) SCALING |
HDMI : Screen Mode(16:9, 4:3) |
|
|
PC : Screen Mode(16:9, 4:3), H/V Position, Auto) |
|
|
TV / AV : Screen Mode(16:9, 4:3, LB(16:9), LBS(16:9), 14:9, |
|
|
LB(14:9), LBS(14:9) |
|
|
COMPONENT : Screen Mode(16:9, 4:3) |
|
2) OSD Language |
4 Languages (English, Franch, Spanish, Portuguese) |
|
3) PIP/POP |
TV, Video, S-Video / HDMI |
|
4) OTHERS |
Still, Sleep Mode, Sound Mode, Timer, Screen Mode, |
|
|
Closed Caption, MGDI, Picture Mode |
|
|
|
|
4. OPTICAL |
|
|
4-1. SCREEN SIZE |
32”(81 cm) DIAGONAL |
|
4-2. ASPECT RATIO |
16 : 9 |
|
4-3. NUMBER OF PIXELS |
852(H) X 480(V) |
|
4-4. DISPLAY COLOR |
1,073,000,000 Colors (10 Bits for each RGB) |
|
4-5. CELL PITCH |
277um(H) X 830(V)um (1 Pixel = a Set of RGB Cells) |
|
4-6. PEAK LUMINANCE |
Typical 550cd/m2 (25% White Window, 60Hz) |
|
4-7. CONTRAST RATIO |
Average 60:1(In a bright room with 100Lux at center, 60Hz) |
|
4-8. VIEWING ANGLE |
FREE |
|
|
|
|
5. USERCONTROL & ACCESSORIES |
|
|
5-1 CONTROL BUTTON(SET) |
SOFT S/W : MOVE/CH(UP, DOWN), VOLUME(LEFT, RIGHT), |
|
|
MENU, INPUT SELECT, POWER |
|
5-2. REMOTE CONTROL |
Power, Display, 10KEY(0~9), 100KEY, Still, Screen Size, |
|
(R-55F06) |
Menu, TV, AV, Multimedia, PREV CH, Mute, CH(UP/DOWN), |
|
|
VOL(UP/DOWN), Caption, Picture Mode, Sound Mode, MTS, |
|
|
Sound Effect, PIP, Ch Up(Sub), Sleep Timer, Add/Erase, Position, |
|
5-3. ACCESSORIES |
REMOTE CONTROL, INSTRUCTION MANUAL, POWER CORD |
|
5-4. OPTIONAL PARTS |
STAND, WALL HANGER |
|
|
|
|
-5-
Product Specification
2-2. Available Input Signal
1) PC&HDMI
Resolution |
H.Freq.(kHz) |
V.Freq.(Hz) |
Remark |
HDMI |
PC |
|
|
|
|
|
|
|
|
|
31.469 |
59.940 |
DOS |
O |
O |
|
|
|
|
|
|
|
|
640 x 480 |
37.861 |
72.809 |
VESA |
O |
O |
|
|
|
|
|
|
|
|
|
37.500 |
75.000 |
VESA |
O |
O |
|
|
|
|
|
|
|
|
720 x 400 |
31.469 |
70.087 |
IBM |
O |
O |
|
|
|
|
|
|
|
|
800 x 600 |
35.156 |
56.250 |
VESA |
O |
O |
|
|
|
|
|
|
||
37.879 |
60.317 |
VESA |
O |
O |
||
|
||||||
|
|
|
|
|
|
|
1024 x 768 |
48.363 |
60.004 |
VESA |
O |
O |
|
|
|
|
|
|
|
|
1280 x1024 |
63.981 |
60.020 |
VESA |
O |
O |
|
|
|
|
|
|
|
2)Component
•1080i - 50 / 60Hz
•720p - 50 / 60Hz
•480p/i - 50 / 60Hz
•576p/i - 50 / 60Hz
3)Video
•PAL, PAL - M, PAL - N
•NTSC, NTSC 4.43
•SECAM
-6-
3. The Feature of Inside
3-1. Main PCB’s Connection Diagram |
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
AV3 |
|
|
|
|
|
|
|
|
|
|
|
|
(Y/C, CVBS) |
|
|
|
|
|
|
-S |
|
|
|
|
|
|
|
PC851 |
|
|
|
|
|
VIDEO1 |
OUT_ |
SPDIF |
HDMI |
|
|
P801 |
|
|
IC202 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC201 |
|
|
|
|
|
|
|
|
|
|
|
|
|
DDR SDRAM |
|
|
|
|
|
|
|
J855 |
J301 |
|
|
IC101 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PW338B |
|
DDR SDRAM |
|
|
|
OUTMONITOR |
|
|
|
|
|
|
|
|
|
|
|
|
VIDEO1 |
|
L/RAudio |
PC& DVI |
|
|
J801 |
|
IC401 |
|
PC301 |
|
|
|
|
|
|
|
|
|
|
|
|
FLASH 16M |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TO PDP MODULE |
|
|
|
|
(D |
|
|
|
|
|
PCB MAIN |
|
|
|
|
COMPONENT1 |
COMPONENT2 |
|
jack SUB)- |
Upgrade PC |
|
J851 |
J802 |
PIC16F690 |
|
P108 |
|
|
|
|
|
IC622 |
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
SP-901X |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
From PWR |
|
|
|
|
|
|
J854 |
J853 |
J151 |
|
|
|
P109 |
|
|
|
|
|
|
|
|
|
|
|
From PWR |
|
|||
|
|
|
|
|
|
|
|
|
IC751 |
|
|
|
|
|
|
|
|
|
|
|
|
|
MSP4650K |
|
|
|
|
|
|
|
|
|
|
|
TU901 |
|
|
|
PC602 |
|
|
|
|
|
|
|
|
|
|
IC701 |
|
|
|
KEY |
|
|
|
|
|
|
|
|
TUNER |
|
|
|
PA103 |
||
|
|
|
|
|
|
|
|
|
STA515W |
|
PC601 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
P701 |
P702 |
|
PA101 |
LED |
|
|
|
|
|
|
|
|
|
|
|
|
|
Fig.2 Main PCBs Block Diagram
3-2. Block Diagram
Fig.3 Signal Block Diagram : DPX-
-7-
The Feature of Inside
3-3. Power Specification
-8-
4. Default Setting in User Menu OSD
4-1. Picture
1) Mode
|
Normal |
|
Dynamic |
Cinema |
User |
Brightness |
48 |
|
46 |
55 |
Undefined |
Contrast |
70 |
|
74 |
60 |
Undefined |
Sharpness |
7 |
|
8 |
6 |
Undefined |
Colour |
55 |
|
60 |
50 |
Undefined |
Tint |
50 |
|
50 |
50 |
Undefined |
* HDMI & PC Input - Only brihgtness and contrast are available. |
|
||||
2) Default Value of Other Functions |
|
|
|
||
|
|
|
|
|
|
Function |
Default Value |
|
|
|
|
Colour Temp |
Normal |
|
|
|
|
|
|
|
|
|
|
N.R. |
On |
|
|
|
|
|
|
|
|
|
|
* N.R. means the noise reduction
* HDMI & PC don't support N.R. functions
4-2. Sound
1) Mode
|
Normal |
Movie |
Music |
News |
User |
120 Hz |
32 |
50 |
48 |
15 |
Undefined |
200 Hz |
32 |
50 |
48 |
15 |
Undefined |
500 Hz |
32 |
38 |
38 |
32 |
Undefined |
1.2 kHz |
32 |
28 |
15 |
50 |
Undefined |
3 kHz |
32 |
28 |
15 |
50 |
Undefined |
7.5 kHz |
32 |
40 |
42 |
32 |
Undefined |
12 kHz |
32 |
48 |
56 |
15 |
Undefined |
|
|
|
|
|
|
2) Default Value of Other Functions
Function |
Default Value |
Balance |
0 |
|
|
Effect |
Off |
|
|
AVC |
Off |
-9-
Default Settinf in User Menu OSD
4-3. Screen
1) Mode
|
16 : 9 |
4 : 3 |
LB (16:9) |
LBS (16:9) |
14 : 9 |
LB (14:9) |
LBS (14:9) |
Component |
O |
O |
X |
X |
X |
X |
X |
TV |
O |
O |
O |
O |
O |
O |
O |
AV |
O |
O |
O |
O |
O |
O |
O |
PC |
O |
O |
X |
X |
X |
X |
X |
HDMI |
O |
O |
X |
X |
X |
X |
X |
|
|
|
|
|
|
|
|
* H. Position, V. Position, and Auto screen size is available in only PC mode.
4-4. Feature |
|
|
|
|
|
|
|
1) Mode |
|
|
|
|
|
|
|
|
|
|
|
|
|
Function |
Background |
Language |
Child Lock |
MGDi plus |
Auto Power |
|
|
|
|
|
|
|
|
Default Value |
10 |
English |
Off |
On |
Off |
|
|
|
|
|
|
|
* HDMI & PC don’t support MGDI function.
2) |
Closed Caption |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
Function |
Caption Mode |
|
Caption Box |
|
CC on Mute |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Default Value |
Off |
|
|
|
Black |
|
|
Off |
|
|
|
|
|
|
|
|
3) |
Time Setting |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
Function |
Clock |
|
Off Timer |
Off Time |
|
Wake Timer |
Wake Time |
Wake CH. |
Wake Vol. |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
Default Value |
Undefined |
|
Off |
|
PM 12:00 |
|
Off |
PM 12:00 |
1 |
20 |
|||||
|
4) |
ISM |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
Function |
Pixel Shift |
|
Low Bright |
|
Image Invert |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Default Value |
Off |
|
|
|
On |
|
|
Off |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4-5. Install |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Function |
CH Mode |
|
Channel |
|
|
Memory |
|
Fine Tune |
|
Video |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Default Value |
Cable |
|
|
|
1 |
|
|
Erase |
|
0 |
|
Auto |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
-10-
5. Service Mode
To enter SERVICE MODE,
A.Press “ VOL” -> “MUTE ” -> “RECALL” -> “MUTE” button of remote controller (R-55F06)
or
B. Press “S9” button of SERVICE REMOTE CONTROLLER.
[Note] In the first line, there is the model name and the version of the upgraded program on the PDP set.
5-1. Default Value of Pw338B_1 and Pw338B_2
|
Sub Bias |
Sub Gain |
Bias R |
Bias G |
Bias B |
Gain R |
Gain G |
Gain B |
|
|
|
|
|
|
|
|
|
Pw338B_1 |
32 |
72 |
32 |
30 |
41 |
28 |
32 |
45 |
Pw338B_2 |
32 |
64 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1)Pw338B_1
O Sub Bias : For BRIGHTNESS adjustment (All inputs) O Sub Gain : For CONTRAST adjustment (All inputs)
O Bias R : For R BRIGHTNESS adjustment (All inputs) O Bias G : For G BRIGHTNESS adjustment (All inputs) O Bias B : For B BRIGHTNESS adjustment (All inputs) O Gain R : For R CONTRAST adjustment (All inputs)
O Gain G : For G CONTRAST adjustment (All inputs) O Gain B : For B CONTRAST adjustment (All inputs)
2)Pw338B_2
O Sub Bias : For HDMI BRIGHTNESS adjustment O Sub Gain : For HDMI CONTRAST adjustment
5-2. FrontEnd_1
Function |
R Offset |
G Offset |
B Offset |
R Gain |
G Gain |
B Gain |
|
|
|
|
|
|
|
Default Value |
512 |
512 |
512 |
512 |
512 |
512 |
Function |
Y Offset |
Pb Offset |
Pr Offset |
Y Gain |
Pb Gain |
Pr Gain |
Default Value |
512 |
512 |
512 |
512 |
512 |
512 |
|
|
|
|
|
|
|
O RGB offset values will be set by executing ‘RGB Auto Cal’ in service mode.
O YPbPr offset values will be set by executing ‘YPbPr Auto Cal’ in service mode.
-11-
Service Mode
O The automatically set offset values may different from the default value depend on B/D. However, the main B/D should be replaced or contact Kunpo R&D center in Korea if the OFFSET values differ more than ±20 from default value.
5-3. |
FrontEnd_2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AV Brt |
|
AV Cont |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
FrontEnd_2 |
|
128 |
|
134 |
|
|
|
|
|
|
5-4. |
MGDI |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Function |
|
|
VEH |
|
2D-Peaking |
BWE Enable |
BWE Gain |
BWE Mid gain |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Default Value |
|
|
1 |
|
0 |
0 |
4 |
2 |
||
|
Function |
|
BWE TCONST |
|
BWE BWCOFS |
HFILTER |
VFILTER |
|
|||
|
Default Value |
|
|
5 |
|
16 |
6 |
6 |
|
||
5-5. |
Msp46X0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
Function |
|
Sc pScale |
|
Fm pScale |
HDMI pScale |
|
|
|||
|
|
|
|
|
|
|
|
|
|
||
|
Default Value |
|
|
24 |
|
53 |
20 |
|
|
||
|
Function |
|
BBE pScale |
|
Mvoice Level |
Audio Delay |
|
|
|||
|
Default Value |
|
|
30 |
|
12 |
40 |
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
O In Msp46X0,
-Sc pScale : Prescale adjustment for external input (AV, Component, PC etc.)
-Fm pScale : FM/AM prescale adjustment
-BBE Level : BBE level control
-HDMI pScale: HDMI prescale adjustment
-Mvoice Level : Mvoice level control
-Audio Delay : Sound delay control
5-6. Misc
Function |
Tst Ptrn AT |
Tst Ptrn MA |
TV Auto Off |
Search Mode |
|
|
|
|
|
Default Value |
Undefined |
Undefined |
On |
60Hz |
|
|
|
|
|
O Tst Ptrn AT shows five cycled patterns (white, black, red, green, blue) every 1 minute automatically
O Tst Ptrn MA shows five cycled patterns manually by pressing volume up key.
-12-
Service Mode
5-7. Panel
Function |
Sync Mode |
Bright Mode |
Power Mode |
Gamma Mode |
Panel Temp |
|
|
|
|
|
|
Default Value |
AUTO |
100% |
100% |
2.2N |
**.* |
|
|
|
|
|
|
O Panel Temp indicates the current temperature of the panel.
5-8. Reset
O Level 1 - Resets all data in E2PROM other than HDCP key, EDID, RGB offset and YPbPr offset of FrontEnd_1.
O Level 2 - Resets all data in E2PROM other than the exception of Level 1 and Pw338B_1.
O Factory - Resets the data of auto search, language setting, time setting, and the user menu values that could be reset by ‘Initialize’ function in
Feature mode.
-13-
