CP 059 MT(X) UK
Cooker maxioven
Instructions for use end installation
Congratualtions on choosing an ARISTON appliance, which you will find is dependable and easy to use. We recommend that you read this manual for best performance and to extend the life of your appliance. Thank you.
SAFETY PRECAUTIONS
THESE INSTRUCTIONS ARE ONLY VALID FOR THE COUNTRIES OF DESTINATION WHOSE SYMBOLS ARE SHOWN IN THE BOOKLET AND ON THE APPLIANCE RATING PLATE.
1.This appliance has been designed for private, nonprofessional use in normal dwellings.
2.Read the recommendations in this instruction booklet carefully, as they give important advice regarding safe installation, use and maintenance. Keep this booklet in a safe place for further reference when required.
3.Oven accessories which may come into contact with food are made of materials which comply with the contents of EEC Regulation 89/109 of 21.12.88 and national regulations in force.
4.After having removed the packaging, check that the appliance is intact. If in doubt, do not use the appliance and contact professionally qualified personnel.
5.Some parts are covered with a removable scratch-proof film. Before using the appliance the film should be removed and the underlying part cleaned with a cloth and a non-abrasive household cleaning product. When switching on for the first time, it is advisable to heat the empty oven at maximum temperature for about 30 minutes to eliminate any residue from manufacture.
6.All installation and adjustment operations should be carried out by qualified technicians in accordance with current regulations. Specific indications are given in the “instructions for the installer” paragraph.
7.Before connecting the appliance, make sure that the data on the rating plate (situated on the rear part of the appliance and on the last page of the instruction booklet) correspond to those of the mains electricity and gas supplies.
8.During operation, the oven glass door and adjacent parts of the appliance become hot. Make sure, therefore, that children do not touch the appliance.
For greater safety, an additional child-safety device is available from our Head Office and our Authorised Service Centres (see enclosed list). When ordering this, please give the code: BAB - followed by the appliance model. The model is stamped on the plate which is visible on the front part of the oven upon opening the door.
9.Check that the capacity of the electrical system and the power outlets are suitable for the maximum power of the appliance, indicated on the rating plate. If in doubt, consult a professionally qualified technician.
10.Periodically check the condition of the gas connection pipe and have it replaced by a qualified technician as soon as it shows any signs of wear or anomaly.
11.Under no circumstances should the user replace the power supply cable or the gas connection pipe of this appliance. In the event of damage or the necessity for replacement, only contact an authorised service centre.
12.Do not leave the appliance plugged in if it is not in use. Switch off the main switch and gas supply when you are not using the cooker.
13.The burners and the cast-iron pan supports remain hot for a long time after use. Take care not to touch them.
14.To avoid accidental spillage do not use cookware with uneven or deformed bottoms on the burners.
15.Never use flammable liquids such as alcohol or gasoline, etc. near the appliance when it is in use.
16.If the cooker is placed on a pedestal, take the necessary precautions to prevent the same from sliding off the pedestal itself.
17.To obtain the best results with the cooktop, several fundamental rules should be followed while cooking or preparing food. Use cookware with a flat bottom to make certain that the pot sets properly on the cooking area.
1
COOKER DESCRIPTION
F |
E |
AAuxiliary gas burner
BSemi-rapid gas burner
CRapid gas burner
DTriple ring gas burner
EIgnitor for Gas Burners
FSafety Device - Activates if the flame accidentally goes out (spills, drafts, etc.), interrupting the delivery of gas to the burner.
GGrid pan
HElectric oven selector knob (cooking function selection)
MControl Knobs for Gas Burners
NElectric oven thermostat knob (temperature selection)
RSupport Grid for Cookware
SElectric oven operation indicator light
TTimer
2
INSTRUCTIONS FOR USE
HOB OPERATION
The burners are fitted with automatic ignition and a thermocouple safety device, which automatically cuts off the gas from the burner in a few seconds if the flame accidentally goes out during operation. The burners differ in size and power. Choose the most appropriate one for the diameter of the cookware being used. Each burner can be regulated with the corresonding control knob "M" by using one of the following settings:
Off |
|
High flame |
|
Low flame |
|
The symbols |
near the knobs show the position of the |
relative burner on the hob.
To ignite a burner, proceed as follows:
•turn the relative knob counter-clockwise until the pointer is on the high-flame symbol;
•press the knob down fully and activate the automatic gas ignition
;
•keep the knob pressed down for about 10 seconds with the flame lit to allow the safety thermocouple to be heated;
•release the knob, checking that the flame is stable. If it is not, repeat the operation.
For minimum power, turn the knob towards the low flame symbol. Intermediate positions are possible by simply putting the knob anywhere between the high and the low flame symbol.
To turn off the burner, turn the knob clockwise to the off position " ".
Important:
•Do not activate the automatic ignition device for more than 15 consecutive seconds.
•Difficulty in ignition is sometimes due to air inside the gas duct.
•If a burner flame accidentally goes out, the gas continues to exit for a few moments before the safety device activates. Turn the control knob to the off position and do not attempt ignition again for at least 1 minute, thereby letting the gas disperse, which could otherwise be a danger.
•When the appliance is not in operation, check that the
knobs are in the off position "
". The main gas supply cut-off cock should also be closed.
Using the burners
To obtain maximum efficiency from the burners, it is advisable to only use pans with a diameter suitable for the burner being used, so that the flame does not extend beyond the pan base (see following table).
Burner |
Diameter of the pan in cm. |
Auxiliary A |
from 6 to 14 |
|
|
Semi-rapid B |
from 15 to 20 |
|
|
Rapid C |
from 21 to 30 |
|
|
Triple ring D |
from 24 to 30 |
|
|
When a liquid starts boiling, it is advisable to turn the flame down just enough to keep the liquid simmering.
The hob is fitted with a pan reducing support (fig.1), which should only be used on the auxiliary burner "A"
fig.1
MULTI-FUNCTION OVEN
The oven offers nine combinations of heating elements; so the most suitable combination may therefore be chosen for each dish, with convincing results.
By turning the selector knob “H” marked with the symbol
, different cooking modes are obtained, as shown in the following table:
Symbol |
|
Function |
Power |
0 |
0) Off |
- |
|
|
1) |
Top + Bottom heating |
2350 W |
|
|
elements |
|
|
|
|
|
|
2) Bottom heating element |
1300 W |
|
|
3) Top heating element |
1050 W |
|
|
4) Grill heating element |
2000 W |
|
|
5) |
Maxigrill (Top + Grill eating |
3050 W |
|
elements) |
||
|
|
||
|
6) |
Maxigrill (Top + Grill heating |
3100 W |
|
elements) + fan |
||
|
|
||
|
7) Bottom heating element + Fan |
1350 W |
|
|
8) |
Rear round heating element + |
2850 W |
|
Fan |
||
|
|
||
|
9) Fast defrosting |
50 W |
|
After having selected the heat source, put the thermostat knob "N" (marked with the symbol
) onto the temperature required.
•For traditional cooking (roasts, biscuits, etc.) in
conventional mode use the
mode (hot above + below).
Only put the food to be cooked into the oven when it has reached the selected temperature and preferably use just one shelf for cooking.
To provide heat only to the bottom or the top part of the
dishes, turn the selector to the position
(hot below) or
(hot below + fan) or
(hot above);
3
