A1221
iPhone
Bluetooth
Headset
User’s Guide
Congratulations on your new iPhone
Bluetooth
®
Headset. Use the headset to
talk hands-free on your iPhone. Follow
these instructions to get started.
Pair the Headset with iPhone
1 Connect the included iPhone Dual Dock to a USB 2.0
port on your computer (not on the keyboard).
2 Connect iPhone and the headset to the dock. The
headset pairs with iPhone automatically.
The fi rst time you connect the headset, let it charge
for about an hour until the status light on the headset
turns from amber to green.
3 Remove iPhone and the headset from the dock. Then
press the button on the top of the headset so that calls
will be routed through the headset.
3
You can also pair the headset with iPhone and charge
the headset using the included iPhone Travel Cable.
Connect the cable to your computer, then connect the
headset and iPhone to the cable.
4
Make or Answer a Call
1 Place the headset in either ear with the microphone
pointed towards your mouth.
Note: Placing the included foam pad over the speaker
may provide a more comfortable fi t.
2 Make a call on iPhone, or press the button on top of the
headset to answer an incoming call.
If you answer an incoming call by tapping the iPhone
touchscreen, audio is routed through iPhone.
3 When you fi nish, press the button to end the call.
Adjust the Volume
m Use the volume buttons on the side of iPhone.
WARNING: For important safety information about
avoiding hearing loss, see page 13.
5
What Else You Can Do
To Do this
Answer incoming call Press button.
End current call Press button.
Decline incoming call Press button for about one
Switch to incoming or
on-hold call and put
current call on hold
Switch to incoming or
on-hold call and end
current call
Check whether
headset is turned on
Turn headset on Press and hold button for
Turn headset o∂ Press and hold button for
second, until you hear a
beep.
Press button.
Press button for about one
second, until you hear a
beep.
Press button.
If headset is on, status light
blinks green and headset
beeps.
about three seconds, until
you see the status light
blink green or hear four
rising tones.
about four seconds, until
you see the status light
blink amber or hear four
falling tones.
6
