Hardware Guide

V G C - V 2 S e r i e s ( P C V - E 1 1 M / P C V - F 1 1 M )

n N

Read this first

Notice

This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval.

Sony Corporation provides no warranty with regard to this manual, the software, or other information contained herein and hereby expressly disclaims any implied warranties or merchantability or fitness for any particular purpose with regard to this manual, the software or such other information. In no event shall Sony Corporation be liable for any incidental, consequential, or special damages, whether based on tort, contract, or otherwise, arising out of or in connection with this manual, the software, or other information contained herein or the use thereof.

Macrovision: This product incorporates copyright protection technology that is protected by U.S patents and other intellectual property rights. Use of this copyright protection technology must be authorised by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorised by Macrovision. Reverse engineering or disassembly is prohibited.

In the manual, the ™ or ® marks are not specified.

Sony Corporation reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein is governed by the terms of a separate user licence agreement.

Please note that the illustrations in this manual may not necessarily apply to your model. Please see the Specifications sheet for the specific configuration of your VAIO.

n N

Read this first

ENERGY STAR

As an ENERGY STAR Partner, Sony has determined that this product meets the ENERGY STAR guidelines for energy efficiency. The International ENERGY STAR Office Equipment Program is an international program that promotes energy saving through the use of computers and their office equipment. The program backs the development and dissemination of products with functions that effectively reduce energy consumption. It is an open system in which business proprietors can participate voluntarily. The targeted products are office equipment such as computers, displays, printers, facsimiles and copiers. Their standards and logos are uniform among participating nations.

ENERGY STAR is a U.S. registered mark.

Environmental information

Halogenated flame retardants are not used in cabinets.

Corrugated cardboard is used for packaging cushions.

Owner's record

The serial number, model number and product key are located on the back of your Sony desktop. Record the numbers and refer to them if you call VAIO-Link. See also the printed Specifications sheet.

n N

Read this first

Safety information

General

Opening the unit, for whatever reason, could lead to damages that are not covered by the guarantee.

To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

To prevent fire or shock hazard, do not expose your VAIO desktop to rain or moisture.

If reporting a gas leak, do not use the modem or a telephone in the vicinity of the leak.

Avoid using the modem during a severe electrical storm.

Do not move your computer while the system is in Standby mode.

The magnetic properties of some objects can have serious consequences for your hard disk drive. They can erase the data on the hard disk drive and cause the computer to malfunction. Do not place your computer near or on any objects, which emit magnetic fields, mainly:

TV sets

Speakers

Magnets and magnetic bracelets.

You can find detailed safety information in the Regulations Guide.

Audio/video

Audio and picture distortion may occur if this equipment is positioned in close proximity to any equipment emitting electromagnetic radiation.

n N

Read this first

Connectivity

Never install modem or telephone wiring during a severe lightning storm.

Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

Take care when installing or modifying telephone lines.

To disconnect your VAIO completely from the mains voltage, unplug the power cable.

Make sure that the socket outlet is easily accessible.

Optical disc drive

The use of optical instruments can cause eye hazard. As the laser beam used in this product is harmful to the eyes, do not attempt any disassembling process. For servicing, refer to qualified personnel only.

n N

Read this first

Regulatory information

Sony hereby declares that this product is in compliance with the essential requirements and other relevant provisions of European Directive 1999/5/EC s(radio equipment and telecommunications terminal equipment Directive).

Models with Wireless LAN:					Models without Wireless LAN:

Declaration of Conformity

The European Union is targeting the free movement of goods for the internal market and to prevent technical barriers to trade. This effort has resulted in several EU Directives asking that manufacturers make their products comply with essential standards. Manufacturers are required to affix the "CE" mark on the products they sell and to draw up a "Declaration of Conformity" (DoC).

Primarily, the Declarations of Conformity are intended for the market surveillance authorities as proof that products satisfy the required standards. Additionally, Sony provides these EU DoC's on the website www.compliance.sony.de as a service to our customers.

You can search for all Declarations of Conformity available for a specific product by typing in the model name in the search box. A list of matching documents will be displayed and can be downloaded. Please note that the availability of declarations depends on the scope of the EU Directives and the individual product specifications.

Before activating the built-in modem, please read the Regulations Guide.

You can find detailed safety information in the Regulations Guide.

If your model is equipped with Wireless LAN, please read the Regulations Guide before activating the Wireless LAN functionality.

Depending on the country, usage of the Wireless LAN functionality may be restricted. For country-specific details, please refer to the Regulations Guide. The Wireless LAN PC functionality which is incorporated into this unit has passed Wi-Fi certification, and complies with the interoperability specifications established by WECA (Wireless Ethernet Compatibility Alliance).

n N

Read this first

Disposing of the internal memory backup battery

Your Sony VAIO desktop is equipped with an internal back-up memory battery (motherboard battery) that should not have to be replaced during the lifetime of the product. If you want to replace the battery, please contact VAIO-Link: www.vaio-link.com

Keep away from children.

Dispose of the battery properly at its end-of-life.

In some areas the disposal of non-hazardous batteries in household or business waste may be prohibited. Please use the public waste collection system.

Disposing of the AA batteries

AA batteries are delivered with this VAIO (keyboard, mouse and remote control).

Do not handle damaged or leaking batteries.

Dispose of promptly and properly at end-of-life.

May explode or leak if recharged, disposed of in fire, mixed with other types of battery or

improperly installed.

Keep away from children.

In some areas, the disposal of batteries in household or business waste may be prohibited. Please use the public collection system.

n N

Welcome

Congratulations on purchasing a Sony VAIO computer. Sony has combined leading-edge technology in audio, video, computing and communications to provide you with state-of-the-art personal computing.

As well as exceptional performance, here are the main features you can enjoy:

Sony audio and video quality – The high-quality internal speakers and graphics enable you to take advantage of today’s advanced multimedia applications, games, and entertainment software.

Wireless setup – Thanks to the Wireless LAN (IEEE 802.11b/g) technology, you can communicate freely, without cables or wires.

VAIO Zone – Take advantage of this new software application, allowing you to enjoy music, video, and photos locally or through a home networking environment. If your computer has TV tuner functionalities, you can also watch/record TV on your VAIO.

TVTV – tvtv takes your VAIO's TV functions to a new level. Never miss your favourite TV programme again, by remote-recording it via the Internet onto your TV tuner-equipped VAIO. The tvtv Interactive Programme Guide gives you a comprehensive overview of what's on when and automatically synchronises it with your VAIO, wherever you happen to be at the time.

Multimedia features – Make the most out of your audio and video CDs and DVDs, even record them yourself.

Sony Memory Stick PRO slot – This compact digital storage medium allows you to easily transfer images, sounds, data and text between cameras, computers, and more.

Windows XP – Your system includes the latest operating system from Microsoft.

Excellent customer support – If you are experiencing any problems with your computer, please check the VAIO-Link website for a possible solution: www.vaio-link.com. Before contacting VAIO-Link, please try to solve the problem by reading this guide, your printed Guide to Troubleshooting and Recovering your VAIO System, the online help files in the Windows Help and Support Center or the manuals and help files for the peripherals or software.

n N

Welcome

Documentation pack

Your documentation pack contains printed information and user guides to read on your computer. Guides are provided in PDF format, which you can easily browse through and print out.

The My Info Centre portal is a perfect starting point to using your VAIO - a comprehensive collection of everything you need to get the most from your PC.

The user guides are collected under My Documentation, which can be shown as follows:

1Go to Start and click the My Info Centre icon .

2From My Home, select your country and language from the drop-down boxes.

3	From the pictures at the top of the window click My Documentation .
4	Select the guide you want to read.

You can manually browse to the user guides by going to My Computer > VAIO (C:) (your C drive) > My Documentation > Documentation and opening the folder for your language.

You may have a separate disc for the documentation of bundled accessories.

n N

Welcome

Printed documentation

The printed part of your documentation pack includes the following:

A Getting Started brochure, where you will find a brief description of the items in your box and how to set up your computer;

A Specifications sheet, containing a table of specifications, a list of bundled software and, on the reverse side, a guide to setting up your VAIO;

A Guide to Troubleshooting and Recovering your VAIO System, where you will find solutions to common problems, an explanation of the purpose and use of the VAIO disc delivered with your computer, and VAIO-Link information;

Booklets containing the following information: Sony Guarantee conditions, Safety Regulations, Modem Regulations and

Wireless LAN Regulations.

n N

Welcome

Non-printed documentation

My Documentation contains the following VAIO user guides:

The Hardware Guide (this guide) explains the features of your VAIO in detail, how to use these features confidently and safely, connect peripheral devices and more.

The Software Guide describes how to register your VAIO, the software features available with VAIO systems, how to change settings, how to manage drivers, and more.

The VAIO Zone guide explains the valuable features of VAIO’s multimedia portal. If your computer has TV tuner functionalities, this is where you will find information about watching/recording TV on your VAIO.

My Documentation also gives you:

Help files about reading the guides.

Important information about your computer, in the form of notices and announcements. In My Info Centre you can also find:

My Software

Feeling creative? Click this icon for an overview of your software and check out our upgrade options.

My VAIO essentials

Want to expand the capabilities of your VAIO? Click on this icon and have a look at your compatible accessories.

My Websites

Click this icon and check out our most popular websites.

My ISP

Click this icon to find out about the preferred offerings from our partners and access the world of the internet.

n N

Welcome

Further sources

Go to Start > Help and Support for VAIO support information as well as tips and tricks.

Consult the Online Help files of the software you are using for detailed information on features and troubleshooting.

Go to www.club-vaio.com to find online tutorials about your favourite VAIO software.

n N

Welcome

Ergonomic considerations

Whenever possible, try and take into account the following ergonomic considerations when using your new computer, whether at home or in the office:

Position of the keyboard and mouse – Make sure the keyboard is directly in front of you. Keep your forearms horizontal, with your wrists in a neutral, comfortable position while using the keyboard or mouse – not at an angle. Let your upper arms hang naturally at your sides. Place the mouse at the same level as the keyboard and use your whole arm to move it.

Position and viewing angle of the display – Set the display at a comfortable viewing distance. Make sure the display screen is at eye level or slightly lower. Use the display’s tilting feature to find the best position. You can reduce eye-strain and musclefatigue by adjusting the tilt of the display to the proper position. Remember to adjust the brightness setting of the display.

Furniture and posture – Sit in a chair with good back support. Adjust the level of the chair so your feet are flat on the floor. A footrest may make you more comfortable. Sit in a relaxed, upright posture and avoid slouching forward or leaning too far backwards.

Lighting – Choose a location where windows and lights do not create glare or reflection on the display. Use indirect lighting to avoid bright spots reflecting on the display. Proper lighting adds to your comfort and work effectiveness.

Ventilation – Make sure you leave at least 25 cm of space behind and on each side of the main unit.

And finally – Remember to have breaks during sessions with your computer. Excessive use of the computer may strain muscles or tendons.

n N

Using your VAIO

Once you have read and followed the information in the printed Getting Started guide and Specifications sheet, you can start using your computer safely and confidently. Read on to get the most out of using your VAIO computer.

Shutting down your computer safely (page 14)

Using the keyboard (page 15)

Using the pointing device (page 19)

Using the mouse (page 21)

Using the TV function (page 24)

Using the disc drive (page 25)

Using the modem (page 28)

Using power modes (page 29)

Using the Memory Stick (page 31)

Using PC Cards (page 34)

Using Wireless LAN (WLAN) (page 36)

n N

Using your VAIO

Shutting down your computer safely

It is important that you shut down your computer properly so you do not lose unsaved data.

To shut down your computer, proceed as follows:

1Turn off any peripherals connected to your computer.

2Click the Start button.

3Click Turn Off Computer.

The Turn off computer window appears.

4Click Turn Off.

5Respond to any prompts warning you to save documents or to consider other users and wait for your computer to turn off automatically.

The power indicator turns off.

See the printed Guide to Troubleshooting and Recovering your VAIO System if you have problems shutting down your computer.

n N

Using your VAIO

Using the keyboard

Your VAIO is delivered with a wireless keyboard. You can place the keyboard anywhere you find comfortable within a range of approx. 80 cm* from the main unit.

The keyboard has a standard key arrangement and additional keys that perform specific functions. For more information on the standard keys and shortcuts, please go to the Windows Help and Support Center (Start > Help and Support). The VAIO-Link website (www.vaio-link.com) also contains glossary information to help you use the keyboard.

* Effective usage distance depending on the environment.

n N

Using your VAIO

	KEY	FUNCTION

1	Standby	Press the button to place the computer in Standby mode. Press the power button or Standby key briefly to resume normal
		operation.

2	Numeric keypad	Use the numeric keypad to type numbers or to perform basic maths calculations. Press the Num Lock key to activate the
		numeric keypad. Press the Num Lock key again to deactivate the numeric keypad.

3	Directional arrows	The Up, Down, Left, and Right arrow keys move the pointer on the screen.

4	Applications	The Applications key displays a shortcut menu in certain software programmes. Pressing this key is equivalent to clicking
		the right mouse button.

5	Pointing device	See Using the pointing device (page 19) for more information.

6	Windows	The Microsoft Windows key displays the Start menu. Pressing this key is equivalent to clicking Start on the taskbar.

		n N
		17
		Using your VAIO


	KEY	FUNCTION

7	<Fn> key	Used in combination with other keys to execute commands.
		<Fn>+<F2>: Turns off the speaker sound.
		<Fn>+<F3>: Decreases the volume of the speakers.
		<Fn>+<F4>: Increases the volume of the speakers.
		<Fn>+<F5>: Decreases the brightness of the display screen.
		<Fn>+<F6>: Increases the brightness of the display screen.

8	Function keys	The 12 function keys along the top of the keyboard are used to perform certain tasks. The task associated with each function
		key may vary from one application to the next.

9	LED screen	Num Lock:
		Turns on when the number keys in the numeric keypad are active.
		Caps Lock:
		Turns on when the letters appear in uppercase as you type. The <Shift> key lowers the case of typed characters when
		Caps Lock is on.
		Scroll Lock:
		Turns on when the screen scrolls differently (not all applications support this function).

10	Battery compartment	Storage compartment for the AA batteries.

11	Keyboard feet	Extend to adjust the keyboard height.

12	CONNECT button	Press to enable the keyboard to communicate with the system unit.

n N

Using your VAIO

Before you use the keyboard

Before attempting to use the wireless keyboard, you must enable communication between the computer and the keyboard.

Two AA batteries, for use in the wireless keyboard, are supplied with your VAIO.

To connect the wireless keyboard, proceed as follows:

1 Insert the 4 AA batteries (1) into the wireless keyboard as shown.

2 Turn on the computer.

3 Slide the power switch on the right-hand side of the keyboard to turn on the keyboard (2).

4 Press the CONNECT button on the right panel of the computer (3).

5 Turn the wireless keyboard over and press the

CONNECT button (4). Communication between the wireless keyboard and the computer is now active.

If your wireless keyboard does not operate properly, the batteries may need to be replaced. If your wireless keyboard is not being used for extended periods of time, remove the batteries to avoid possible damage from battery leakage.

If you want to put the keyboard in a more ’ergonomical’ position, open the keyboard feet.

n N

Using your VAIO

Using the pointing device

The keyboard features a pointing device (1), which controls the cursor on the screen. You can point to, select and drag objects on the screen using the built-in pointing device.

Action	Description

Point	Slide one finger on the pointing device to place the pointer (2) on an item or object.

Click	Press the left button (3) once.

Double-click	Press the left button twice.

Right-click	Press the right button (4) once. In many applications, this action displays a shortcut menu.

Drag and select	Slide one finger while pressing the left button.
