4-647-657-03(1)
USB Floppy Disk Drive
/ Operating Instructions Mode d'emploi / Bedienungsanleitung Istruzioni per l’uso / Gebruiksaanwijzing Manual de instrucciones / =
PCGA-UFD5
Sony Corporation © 2000 Printed in Japan
VAIO
• |
1 |
|
b |
||
• |
||
• |
2 USB |
|
• |
3 VAIO |
|
|
||
|
||
|
けがなど人身事故の原因となります。
またはVAIO
入ったときは、VAIO
VCCIB
USB
VAIOVAIOVAIO
•1
1
VAIO
VAIO VAIO
にお届けします。詳しくはコンピュータ本体に付属の「VAIO
8 VAIO
•PCGA-UFD5
|
USB |
|
5 35 10 |
|
20 % 80 % |
|
35 65 % |
|
29 |
|
–20 60 10 |
|
10 % 90 % |
|
60 20 % |
|
35 |
|
111×17.5 ×150 mm |
|
285 g |
|
170 mm |
|
1 |
|
1 |
English
WARNING
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.
Owner's Record
The model number and serial number are located on the bottom of your drive. Record the serial number in the space provided here. Refer to the model and serial numbers when you call your Sony Service Center.
Model No. PCGA-UFD5
Serial No. ——————————
For customers in the U.S.A.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.
For questions regarding your product or for the Sony Service Center nearest you. Call 1-888-476-6972 in the United States or 1-800-961-7669 in Canada. The number below is for FCC related matters only.
Regulatory Information
|
Declaration of Conformity |
Trade Name: |
SONY |
Model No.: |
PCGA-UFD5 |
Responsible Party: |
Sony Electronics Inc. |
Address: |
1 Sony Drive, Park Ridge, NJ.07656 USA |
Telephone No.: |
201-930-6972 |
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
For customers in Canada
This Class B digital apparatus complies with Canadian ICES-003.
For customers in Europe
This product conforms to the following European Directives: 89/336/EEC, 92/31/EEC (EMC Directives)
93/68/EEC (CE Marking Directive)
This product complies with EN 55022 Class B and EN 50082-1 for use in the following areas: residential, commercial and light-industrial.
Before use
The Sony PCGA-UFD5 is the USB floppy disk drive designed exclusively for Sony Notebook Computers. However, this floppy disk drive may not be used with some models. Before connecting the floppy disk drive, check your computer. For more information about how to use, please read the Sony Notebook Computer User Guide.
Specifications
Interface
USB
Operating temperature
41 ˚F to 95 ˚F (5 ˚C to 35 ˚C)
(temperature gradient less than 18 ˚F (10 ˚C)/hour)
Operating humidity
20 % to 80 % (not condensed), provided that humidity is less than 65 % at 95 ˚F (35 ˚C)
(hygrometer reading of less than 84 ˚F (29 ˚C))
Storage temperature
-4 ˚F to 140 ˚F (-20 ˚C to 60 ˚C)
(temperature gradient less than 18 ˚F (10 ˚C)/hour)
Storage humidity
10 % to 90 % (not condensed), provided that humidity is less than 20 % at 140 ˚F (60 ˚C)
(hygrometer reading of less than 95 ˚F (35 ˚C))
Dimensions |
2/ × |
|
× |
|
|
Approx. 4 |
7/ |
5 |
9/ inches (w/h/d) |
||
|
5 |
10 |
× |
|
10 |
(Approx. 111 × |
17.5 |
150 mm) |
|||
Mass Approx. 10.08 oz. (285 g)
Cord length
Approx. 6 7/10 inches (170 mm)
Supplied accessories
Operating instructions (1)
Design and specifications are subject to change without notice.
Note on use
•Do not place the unit in locations that are:
–Extremely hot or cold
–Dusty or dirty
–Very humid
–Vibrating
–Exposed to corrosive gas
–Exposed to direct sunlight
On cleaning
Clean the unit with a soft dry cloth, or a soft cloth lightly moistened with a mild detergent solution. Do not use any type of solvent, such as alcohol or benzine, which may damage the finish.
