User’s Manual/ Manuel de l’utilisateur
MultiSync 70GX2
MultiSync 90GX2
Index
Warning................................................................................................................................................................ |
1 |
Contents............................................................................................................................................................. |
2 |
Display Setup..................................................................................................................................................... |
3 |
Mounting............................................................................................................................................................ |
7 |
Flexible Arm Installation................................................................................................................................ |
8 |
Controls.............................................................................................................................................................. |
9 |
Recommended Use......................................................................................................................................... |
12 |
Specifications.................................................................................................................................................. |
15 |
Features............................................................................................................................................................. |
17 |
Troubleshooting.............................................................................................................................................. |
18 |
References....................................................................................................................................................... |
19 |
Limited Warranty............................................................................................................................................ |
20 |
Manufacturer’s Recycling and Energy Information .............................................................................. |
21 |
Avertissement................................................................................................................................................. |
23 |
Contenu............................................................................................................................................................ |
24 |
Configuration de I’affichage......................................................................................................................... |
25 |
Montage............................................................................................................................................................ |
29 |
Installation du bras flexible ........................................................................................................................ |
30 |
Commandes...................................................................................................................................................... |
31 |
Usage recommandé........................................................................................................................................ |
34 |
Fiche technique.............................................................................................................................................. |
37 |
Fonctions.......................................................................................................................................................... |
39 |
Dépannage...................................................................................................................................................... |
40 |
Références....................................................................................................................................................... |
41 |
Garantie limitée.............................................................................................................................................. |
42 |
Informations du fabricant relatives |
|
au recylage et aux économies d’énergie ................................................................................................ |
43 |
Advertencia..................................................................................................................................................... |
46 |
Contenido......................................................................................................................................................... |
47 |
Supervise la disposición.............................................................................................................................. |
48 |
Motaje............................................................................................................................................................... |
52 |
Cómo instalar el brazo flexible.................................................................................................................... |
53 |
Controles.......................................................................................................................................................... |
54 |
Uso recomendado........................................................................................................................................... |
57 |
Especificaciones............................................................................................................................................. |
59 |
Características................................................................................................................................................ |
61 |
Solución de problemas.................................................................................................................................. |
62 |
Referencias...................................................................................................................................................... |
63 |
Información del fabricante sobre reciclado y energía.......................................................................... |
64 |
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems.
Canadian Department of Communications Compliance Statement
DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950-1.
FCC Information
1.Use the attached specified cables with the MultiSync® 70GX2™ (L175GG) or 90GX2™ (L195GH) color monitors so as not to interfere with radio and television reception.
(1)Please use the supplied power cord or equivalent to ensure FCC compliance.
(2)Please use the supplied shielded video signal cable. Please use the supplied USB cable with ferrite cores.
Use of other cables and adapters may cause interference with radio and television reception.
2.This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet, prepared by the Federal Communications Commission, helpful: ”How to Identify and Resolve Radio-TV Interference Problems.“ This booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, Stock No. 004-000-00345-4.
Contents
Your new NEC MultiSync® LCD
monitor box* should contain the following:
•MultiSync 70GX2 or 90GX2 monitor
•Power Cord
•User’s Manual
•USB Cable
•Video Signal Cable
(mini D-SUB 15 pin to mini D-SUB 15 pin)
•Video Signal Cable (DVI-D to DVI-D)
•Cable Cover
Cable
Cover
Power Cord
Mini D-SUB Cable
USB Cable
DVI-D Cable
User’s Manual
*Remembertosaveyouroriginalboxandpackingmaterialtotransportorshipthemonitor.
Display Setup
To attach the MultiSync® LCD monitor to your system, follow these instructions:
1.Turn off the power to your computer.
2.For the PC or MAC with DVI digital output : Connect the DVI signal cable to the connector of the display card in your system (Figure 1). Tighten all screws.
For the PC with Analog output: Connect the 15-pin mini D-SUB signal cable to the connector of the display card in your system (Figure 2). Tighten all screws.
For MAC setup: Connect the Macintosh cable adapter to the computer, then attach the 15-pin mini D-SUB signal cable to the Macintosh cable adapter (Figure 3). Tighten all screws.
NOTE: To obtain the MultiSync Macintosh cable adapter, call NEC Display Solutions of America, Inc. at (800) 632-4662.
3.Remove the connector cover (Figure 4).
4.Place hands on each side of the monitor and tilt the LCD panel 30° (Figure 5).
5.Connect all cables to the appropriate connectors through the square hole in the stand (Figure 6).
6.Place the connector cover onto the back cabinet (Figure 7).
7.Place all cables into the hooks (Figure 8).
8.Place hands on each side if the monitor to tilt the LCD panel back 5° (Figure 9).
9.Place the cable cover onto the stand (Figure 9). To remove the cable cover, push the notch at the bottom of the cover up (towards the top of the monitor) in order to unhook the cover from the stand (Figure 10).
10.Connect the power cord to the power outlet (Figure 11).
NOTE: If you use this monitor at AC125-240V, please refer to Recommended Use section of this manual for proper selection of power cord.
11.The vacation switch on the back side of the monitor must be turned on (Figure 11). Turn on the monitor with the front power button and power on the computer.
NOTE: The vacation switch is a true on/off switch. If this switch is in the OFF position, the monitor cannot be turned on using the front button. DO NOT switch on/off repeatedly.
12.Analog input only: No-Touch Auto Adjust automatically adjusts the monitor to optimal settings upon initial setup most of the time. For further adjustments, use the following OSM® controls:
• Auto Adjust Contrast |
• Auto Adjust |
Refer to the Controls section of this User ’s Manual for a full description of these OSM controls.
NOTE: For download information on the Windows® 95/98/Me/2000/XP INF file for your monitor, refer to the References section of this User’s Manual.
NOTE: If you have any problems, please refer to the Troubleshooting section of this User’s Manual.
Display Setup –continued
Figure 1 |
Figure 2 |
Figure 3 |
DVI Signal Cable |
Macintosh Cable Adapter (not included) |
|
|
|
Note: Some Macintosh systems do not require a |
|
Macintosh Cable Adapter |
Figure 4 |
Figure 5 |
|
Figure 6
Display Setup –continued
Figure 7
Figure 8 |
Figure 9 |
|
Figure 11
Figure 10
ON Position
OFF Position
Vacation
Switch
Display Setup –continued
Tilt and Swivel
Grasp both sides of the monitor screen with your hands and adjust the tilt and swivel as desired (Figure TS.1).
NOTE: Handle with care when tilting and swiveling the monitor screen.
Figure TS.1
Mounting
Remove Monitor Stand for Mounting
1.Place hands on each side of the monitor and tilt the LCD panel 5˚ degrees. Remove the cable cover (Figure M.1).
Remove the connector cover (Figure M.2).
2.Disconnect all cables.
3.Place monitor face down on a non-abrasive surface (Figure M.3).
NOTE: Handle with care when the monitor is facing down to avoid damaging the front buttons.
4.Remove the 2 screws connecting the stand to the monitor (Figure M.3).
5.Lift up the stand to unlatch the upper hooks and remove the stand (Figure M.4).
6.Remove the 2 screws on the top of the monitor (Figure M.5). The monitor is now ready for mounting in an alternate manner.
7.Connect the cables and replace the connector cover on the back of the monitor.
8.Reverse this process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method. Handle with care when removing stand.
Figure M.1 |
Figure M.2 |
|
Figure M.3
Figure M.5
Figure M.4
Flexible Arm Installation
This LCD monitor is designed for use with a flexible arm. To mount the monitor to a flexible arm:
1.Follow the instructions on how Remove Monitor Stand for Mounting to remove the stand.
2.Use the 4 screws to attach the arm to the monitor (Figure F.1).
NOTE: The LCD monitor should only be used with an approved arm (e.g. GS mark). To meet the safety requirements, the monitor must be mounted to an arm which
guaranties the necessary stability under consideration of the weight of the monitor.
12mm
M4
4 x 12mm with lock washer and flat washer
100mm
Figure F.1
4 Screws (M4)
(Max Depth: 8.5 mm)
Thickness of Bracket (Arm)
2.0~3.2mm
100mm
Weight of LCD assembly: 70GX2 - 4.0 kg (MAX) 90GX2 - 4.8 kg (MAX)
Controls
OSM® (On-Screen Manager) control buttons on the front of the monitor function as follows:
To access OSM menu, press any of the control buttons (MENU/EXIT, Left, Right, Down, Up). To change signal input, press the SELECT button.
NOTE: OSM must be closed in order to change signal input.
Button |
Menu |
MENU/EXIT |
Exits the OSM controls. |
|
Exits to the OSM main menu. |
Left/Right |
Moves the highlighted area left/right to select control menus. |
|
Moves the bar left/right to increase or decrease the adjustment. |
Down/Up |
Moves the highlighted area down/up to select one of the controls. |
SELECT |
Active Auto Adjust function. Enter the OSM sub menu. |
RESET/DV MODE |
Resets the highlighted control menu to the factory setting. |
|
Switches the DV MODE. |
|
|
NOTE: When reset is pressed in the main and sub-menu, a warning window will appear allowing you to cancel the reset function by pressing the MENU/EXIT button.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO Contrast (Analog input only)
Adjusts the image displayed to optimal settings.
DV MODE
Allows you to select the suitable setting for Movies, Photos, etc.
Auto Adjust (Analog input only)
Automatically adjusts the Image Position, H. Size and Fine settings.
Image Controls (Analog input only)
LEFT / RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN / UP
Controls Vertical Image Position within the display area of the LCD.
H.SIZE
Adjust this setting to increase or decrease the horizontal size
FINE
Adjust this setting to improve focus, clarity, and image stability.
Controls –continued
AccuColor® Control Systems
AccuColor® Control Systems: Six color presets select the desired color setting (sRGB and NATIVE color presets are standard and cannot be changed).
R,G,B: Increases or decreases Red, Green or Blue color depending upon which is selected. The change in color will appear on screen and the adjustment (increase or decrease) will be shown by the bars.
NATIVE: Original color presented by the LCD panel that is unadjustable. sRGB: sRGB mode dramatically improves the color fidelity in the desktop environment by using a single standard RGB color space. With this color sup-
ported environment, the operator could easily and confidently communicate color without further color management overhead in the most common situations.
NOTE: When MOVIE, GAMING, or PHOTO is selected as the DV MODE, NATIVE is selected automatically as the six color preset and cannot be changed.
Tools
OFF TIMER: Monitor will automatically power-down when the end user has selected a predetermined amount of time.
LED BRIGHTNESS: You can adjust the Blue LED brightness
HOT KEY: You can adjust the brightness and contrast directly. When this function is set to ON, you can adjust the brightness with left or right control and contrast with up or down control while the OSM menu is off.
FACTORY PRESET: Selecting Factory Preset allows you to reset all OSM control settings back to the factory settings. The RESET button will need to be held down for several seconds to take effect. Individual settings can be reset by highlighting the control to be reset and pressing the RESET button.
Menu Tools
LANGUAGE: OSM® control menus are available in eight languages. OSM LEFT/RIGHT: You can choose where you would like the OSM control image to appear horizontally on your screen.
OSM DOWN/UP: You can choose where you would like the OSM control image to appear vertically on your screen.
OSM Turn Off: The OSM control menu will stay on as long as it is in use. In the OSM Turn Off submenu, you can select how long the monitor waits after the last touch of a button to shut off the OSM control menu.
OSM Lock Out: This control completely locks out access to all OSM control functions except Brightness and Contrast. When attempting to activate OSM controls while in the Lock Out mode, a screen will appear indicating the OSM controls are locked out. To activate the OSM Lock Out function, press SELECT, then right control button and hold down simultaneously. To deactivate the OSM Lock Out, press SELECT, then left control button and hold down simultaneously while in the OSM menu.
10
Controls –continued
RESOLUTION NOTIFIER: If this option is ON, a message will appear on the screen after 30 seconds notifying the user that the optimal resolution is not being used. The optimal resolution is 1280 x 1024.
Information
The Information menu indicates the current input, display resolution, horizontal and vertical frequency, and polarity settings of the monitor. The model and serial numbers of your monitor are also indicated.
OSM® Warning: OSM Warning menus disappear with Exit button.
NO SIGNAL: This function gives a warning when there is no signal present. After power is turned on or when there is a change of input signal or video is inactive, the No Signal window will appear.
RESOLUTION NOTIFIER: This function gives a warning if a resolution other than the optimal resolution is used. After power is turned on or when there is a change of input signal or the video signal doesn’t have proper resolution, the Resolution Notifier window will open. This function can be disabled in the Menu Tools.
OUT OF RANGE: This function gives a recommendation of the optimized resolution and refresh rate. After the power is turned on or there is a change of input signal or the video signal doesn’t have proper timing, the Out Of Range menu will appear.
11
Recommended Use
Safety Precautions and Maintenance
FOR OPTIMUM PERFORMANCE, PLEASE NOTE
THE FOLLOWING WHEN SETTING UP AND USING
THE MULTISYNC® LCD COLOR MONITOR:
•DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel.
•Do not spill any liquids into the cabinet or use your monitor near water.
•Do not insert objects of any kind into the cabinet slots, as they may touch dangerous voltage points, which can be harmful or fatal or may cause electric shock, fire or equipment failure.
•Do not place any heavy objects on the power cord. Damage to the cord may cause shock or fire.
•Do not place this product on a sloping or unstable cart, stand or table, as the monitor may fall, causing serious damage to the monitor.
•When operating the MultiSync LCD monitor with its AC 125-240V power supply, use a power supply cord that matches the power supply voltage of the AC power outlet being used. The power supply cord you use must have been approved by and comply with the safety standards of your country. (Type H05VV-F should be used in Europe)
•In UK, use a BS-approved power cord with molded plug having a black (5A) fuse installed for use with this monitor. If a power cord is not supplied with this monitor, please contact your supplier.
•Do not place any objects onto the monitor and do not use the monitor outdoors.
•The inside of the flourescent tube located within the LCD monitor contains mercury. Please follow the bylaws or rules of your municipality to dispose of the tube properly.
•Do not bend power cord.
•Do not use monitor in high temperatured, humid, dusty, or oily areas.
•Do not cover vent on monitor.
Immediately unplug your monitor from the wall outlet and refer servicing to qualified service personnel under the following conditions:
•When the power supply cord or plug is damaged.
•If liquid has been spilled, or objects have fallen into the monitor.
•If the monitor has been exposed to rain or water.
•If the monitor has been dropped or the cabinet damaged.
•If the monitor does not operate normally by following operating instructions.
•If glass is broken, handle with care.
•If monitor or glass is broken, do not come in contact with the liquid crystal and handle with care.
•Allow adequate ventilation around the monitor so that heat can properly dissipate. Do not block ventilated openings or place the monitor near a radiator or other heat sources. Do not put anything on top of monitor.
•The power cable connector is the primary means of detaching the system from the CAUTION power supply. The monitor should be installed close to a power outlet which is easily accessible.
•Handle with care when transporting. Save packaging for transporting.
Image Persistence
Please be aware that LCD Technology may experience a phenomenon known as Image Persistence. Image Persistence occurs when a residual or “ghost” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD monitors’ image persistence is not permanent, but constant images being displayed for a long period of time should be avoided.
To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example, if an image was on the monitor for one hour and a residual image remains, the monitor should be turned off for one hour to erase the image.
As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
12
Recommended Use –continued
CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR
CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE
FOLLOWING WHEN YOU POSITION THE MONITOR:
•For optimum performance, allow 20 minutes for warm-up.
•Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.
•Position your monitor no closer than 16 inches and no further away than 28 inches from your eyes. The optimal distance is 20 inches.
•Rest your eyes periodically by focusing on an object at least 20 feet away. Blink often.
•Position the monitor at a 90° angle to windows and other light sources to minimize glare and reflections. Adjust the monitor tilt so that ceiling lights do not reflect on your screen.
•If reflected light makes it hard for you to see your screen, use an anti-glare filter.
•Adjust the monitor’s brightness and contrast controls to enhance readability.
•Use a document holder placed close to the screen.
•Position whatever you are looking at most of the time (the screen or reference material) directly in front of you to minimize turning your head while you are typing.
•Get regular eye checkups.
Ergonomics
To realize the maximum ergonomics benefits, we recommend the following:
•Use the preset Size and Position controls with standard signals
•Use the preset Color Setting
•Use non-interlaced signals with a vertical refresh rate between 60-75Hz
•Do not use primary color blue on a dark background, as it is difficult to see and may produce eye fatigue to insufficient contrast.
For more detailed information on setting up a healthy work environment, write the American National Standard for Human Factors Engineering of Visual Display Terminal Workstations – ANSI-HFS Standard No. 100-1988 – The Human Factors Society, Inc. P.O. Box 1369, Santa Monica, California 90406.
Cleaning the LCD Panel
•When the liquid crystal panel becomes dusty or dirty, wipe gently with soft cloth.
•Please do not rub the LCD panel with coarse material.
•Please do not apply pressure to the LCD surface.
•Please do not use OA cleaner. OA cleaner will cause deterioration or discolor the LCD surface.
Cleaning the Cabinet
•Unplug the power supply
•Gently wipe the cabinet with a soft cloth
•To clean the cabinet, dampen the cloth with a neutral detergent and water, wipe the cabinet and follow with a dry cloth.
NOTE: Many plastics are used on the surface of the cabinet. DO NOT clean with benzene, thinner, alkaline detergent, alcoholic system detergent, glass cleaner, wax, polish cleaner, soap powder, or insecticide. Do not touch rubber or vinyl to the cabinet for a long time. of fluids and fabrics can cause the paint to deteriorate, crack or peel.
13
Recommended Use –continued
To avoid scratches
•Do not touch LCD panel with coarse material or hard objects.
•Use only a soft cloth for cleaning the surface of the LCD panel.
To avoid stains
•Clean fingerprints, water drips, chemical spills, etc. from the LCD panel immediately or discoloration and spots will occur. If the LCD panel is rubbed with too much force, cracking may occur, which will lead to abnormalities in the display.
To avoid breakage or screen trouble
•Do not push hard on the LCD panel surface.
•Do not set heavy objects on the LCD panel surface.
•Do not leave the LCD panel under constant pressure.
14
Specifications
Monitor |
|
MultiSync® |
Notes |
|
Specifications |
|
70GX2 |
|
|
LCD Module |
Diagonal : |
17.0 inch |
|
Active matrix; thin film transistor (TFT) |
Viewable Image Size : |
17.0 inch |
|
liquid crystal display (LCD); 0.264 mm |
|
Native Resolution (Pixel Count) : |
1280 x1024 |
dot pitch; 400cd/m2 white luminence; |
||
|
|
|
|
700:1 contrast ratio, typical |
Input Signal |
Video : |
ANALOG 0.7 Vp-p/75 Ohms |
Digital Input: DVI-D |
|
|
Sync : |
Separate sync. TTL Level Positive/Negative |
||
|
|
Horizontal sync. Positive/Negative |
|
|
|
|
Vertical sync. Positive/Negative |
|
|
|
|
Composite sync. Positive/Negative*2 |
|
|
|
|
Sync on Green (Video 0.7Vp-p and Sync Negative 0.3Vp-p)*2 |
||
Display Colors |
|
16,194,277 |
Dependent on display card used. |
|
Maximum |
Left/Right : |
85°/85° |
(CR>5) |
|
Viewing Angles |
Up/Down : |
85°/70° |
(CR>5) |
|
Synchronization |
Horizontal : |
31.5 kHz to 81.1 kHz |
Automatically |
|
Range |
Vertical : |
56.0 Hz to 75.0 Hz |
Automatically |
|
Resolutions Supported |
|
720 x 400*1 VGA text |
Some systems may not support all |
|
|
|
640 x 480*1 @ 60 Hz to 75 Hz |
modes listed. |
|
|
|
800 x 600*1 @ 56 Hz to 75 Hz |
|
|
|
|
832 x 624*1 @ 75 Hz |
|
|
|
|
1024 x 768*1 @ 60 Hz to 75 Hz |
|
|
|
|
1152 x 864*1 @ 75 Hz |
|
|
|
|
1152 x 870*1 @ 75 Hz |
|
|
|
|
1280 x 1024 @ 60 Hz to 75 Hz..............NEC DISPLAY SOLUTIONS |
||
|
|
|
|
cites recommended resolution at 60 Hz |
|
|
|
|
for optimal display performance. |
Active Display Area |
Horizontal : |
337.9 mm/13.3 inches |
|
|
|
Vertical : |
270.3 mm/10.6 inches |
|
|
USB Hub |
I/P: |
USB Specification Revision 2.0 |
|
|
|
Port: |
Upstream 1 |
|
|
|
|
Downstream 4 |
|
|
|
Load Current: |
Maximum 0.5A per port |
|
|
Power Supply |
|
100 – 240 V~ 50/60 Hz |
|
|
Current Rating |
|
1.0 - 0.5 A |
|
|
Dimensions |
|
367.0 mm (W) x 390.5 mm (H) x 203.0 mm (D) |
||
|
|
14.4 inches (W) x 15.4 inches (H) x 8.0 inches (D) |
||
Weight |
|
5.7 kg |
|
|
|
|
12.6 lbs |
|
|
Environmental Considerations |
|
|
|
|
Operating Temperature : |
5°C to 35°C/41°F to 95°F |
|
||
|
Humidity : |
30% to 80% |
|
|
|
Altitude : |
0 to 12,000 Feet |
|
|
Storage Temperature : |
-10°C to 60°C/-14°F to 140°F |
|
||
|
Humidity : |
10% to 85% |
|
|
|
Altitude : |
0 to 40,000 Feet |
|
|
|
|
|
|
|
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 If your display is not showing a picture of the SOG and Composite sync. signal, please contact our hotline for assistance. NOTE: Technical specifications are subject to change without notice.
15
Specifications
Monitor |
|
MultiSync® |
Notes |
||
Specifications |
|
90GX2 |
|
||
|
LCD Module |
Diagonal : |
19.0 inch |
|
Active matrix; thin film transistor (TFT) |
|
Viewable Image Size : |
19.0 inch |
|
liquid crystal display (LCD); 0.294 mm |
|
|
Native Resolution (Pixel Count) : |
1280 x1024 |
dot pitch; 400cd/m2 white luminence; |
||
|
|
|
|
|
700:1 contrast ratio, typical |
|
Input Signal |
Video : |
ANALOG 0.7 Vp-p/75 Ohms |
Digital Input: DVI-D |
|
|
|
Sync : |
Separate sync. TTL Level Positive/Negative |
||
|
|
|
Horizontal sync. Positive/Negative |
|
|
|
|
|
Vertical sync. Positive/Negative |
|
|
|
|
|
Composite sync. Positive/Negative*2 |
|
|
|
|
|
Sync on Green (Video 0.7Vp-p and Sync. Negative 0.3Vp-p)*2 |
||
|
Display Colors |
|
16,777,216 |
Dependent on display card used. |
|
|
Maximum |
Left/Right : |
85°/85° |
(CR>5) |
|
|
Viewing Angles |
Up/Down : |
85°/70° |
(CR>5) |
|
|
Synchronization |
Horizontal : |
31.5 kHz to 81.1 kHz |
Automatically |
|
|
Range |
Vertical : |
56.0 Hz to 75.0 Hz |
Automatically |
|
|
Resolutions Supported |
|
720 x 400*1 VGA text |
Some systems may not support all |
|
|
|
|
640 x 480*1 @ 60 Hz to 75 Hz |
modes listed. |
|
|
|
|
800 x 600*1 @ 56 Hz to 75 Hz |
|
|
|
|
|
832 x 624*1 @ 75 Hz |
|
|
|
|
|
1024 x 768*1 @ 60 Hz to 75 Hz |
|
|
|
|
|
1152 x 864*1 @ 75 Hz |
|
|
|
|
|
1152 x 870*1 @ 75 Hz |
|
|
|
|
|
1280 x 1024 @ 60 Hz to 75 Hz..............NEC DISPLAY SOLUTIONS |
||
|
|
|
|
|
cites recommended resolution at 60 Hz |
|
|
|
|
|
for optimal display performance. |
|
|
|
|
|
|
Active Display Area |
Horizontal : |
376.3 mm/14.8 inches |
|
||
|
|
Vertical : |
301.1 mm/11.9 inches |
|
|
|
USB Hub |
I/P: |
USB Specification Revision 2.0 |
|
|
|
|
Port: |
Upstream 1 |
|
|
|
|
|
Downstream 4 |
|
|
|
|
Load Current: |
Maximum 0.5A per port |
|
|
|
Power Supply |
|
100 – 240 V~ 50/60 Hz |
|
|
|
|
|
|
|
|
|
Current Rating |
|
1.1-0.55A |
|
|
Dimensions |
|
412.5 mm (W) x 407.3 mm (H) x 203.0 mm (D) |
|||
|
|
|
16.2 inches (W) x 16.0 inches (H) x 8.0 inches (D) |
||
|
|
|
|
|
|
|
Weight |
|
6.5 kg |
|
|
|
|
|
14.3 lbs |
|
|
|
|
|
|
|
|
|
Environmental Considerations |
|
|
|
|
|
Operating Temperature : |
5°C to 35°C/41°F to 95°F |
|
||
|
|
Humidity : |
30% to 80% |
|
|
|
|
Altitude : |
0 to 12,000 Feet |
|
|
|
Storage Temperature : |
-10°C to 60°C/-14°F to 140°F |
|
||
|
|
Humidity : |
10% to 85% |
|
|
|
|
Altitude : |
0 to 40,000 Feet |
|
|
|
|
|
|
|
|
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 If your display is not showing a picture of the SOG and Composite sync. signal, please contact our hotline for assistance. NOTE: Technical specifications are subject to change without notice.
16
Features
Thin-frame design creates more desktop space for you to work and play, while the flat screen’s crisp, bright images and crystal-clear text deliver a comfortable viewing experience.
No Touch Auto Adjust™ automatically adjusts your optimal image settings upon initial power-on.
AccuColor® Control System allows you to change between six color settings on your display to match your personal preference.
Redesigned OSM® controls allow you to quickly and easily adjust all elements of your screen image.
NaViSet™ software offers an expanded and intuitive graphical interface, allowing you to more easily adjust OSM® display settings via mouse and keyboard.
USB 2.0 hub adds excitement to your computing by connecting you to digital cameras, scanners and more.
ErgoDesign® Features: Enhanced human ergonomics to improve the working environment, protect the health of the user and save money. Examples include OSM controls for quick and easy image adjustments, tilt base for preferred angle of vision, small footprint and compliance with MPRII and TCO guidelines for lower emissions.
Plug and Play: The Microsoft® solution with the Windows®95/98/Me/2000/XP operating system facilitates setup and installation by allowing the monitor to send its capabilities (such as screen size and resolutions supported) directly to your computer, automatically optimizing display performance.
IPM® (Intelligent Power Manager) System: Provides innovative power-saving methods that allow the monitor to shift to a lower power consumption level when on but not in use, saving two-thirds of your monitor energy costs, reducing emissions and lowering the air conditioning costs of the workplace.
Multiple Frequency Technology: Automatically adjusts monitor to the display card’s scanning frequency, thus displaying the resolution required.
FullScan® Capability: Allows you to use the entire screen area in most resolutions, significantly expanding image size.
VESA Standard Mounting Interface: Allows users to connect their MultiSync® monitor to any VESA standard third party mounting arm or bracket. Allows for the monitor to be mounted on a wall or an arm using any third party compliant device.
OptiClear® DVM: Provides rich color saturation, remarkable clarity, and true-to-life contrast to enhance the user’s overall visual perception.
17
Troubleshooting
No picture
•The signal cable should be completely connected to the display card/computer.
•The display card should be completely seated in its slot.
•Make sure the Vacation Switch is in the ON position.
•Front Power Switch and computer power switch should be in the ON position.
•Check to make sure that a supported mode has been selected on the display card or system being used. (Please consult display card or system manual to change graphics mode.)
•Check the monitor and your display card with respect to compatibility and recommended settings.
•Check the signal cable connector for bent or pushed-in pins.
•Check the signal input, “INPUT 1” or “INPUT 2”.
Power Button does not respond
•Unplug the power cord of the monitor from the AC outlet to turn off and reset the monitor.
•Check the Vacation Switch on the back side of the monitor.
Image Persistence
•Please be aware that LCD Technology may experience a phenomenon known as Image Persistence. Image Persistence occurs when a residual or “ghost” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD monitors’ image persistence is not permanent, but constant images being displayed for a long period of time should be avoided.
To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example, if an image was on the monitor for one hour and a residual image remains, the monitor should be turned off for one hour to erase the image.
As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying
moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
Image is unstable, unfocused or swimming is apparent
•Signal cable should be completely attached to the computer.
•Use the OSM Image Adjust controls to focus and adjust display by increasing or decreasing the fine total. When the display mode is changed, the OSM Image Adjust settings may need to be re-adjusted.
•Check the monitor and your display card with respect to compatibility and recommended signal timings.
•If your text is garbled, change the video mode to non-interlace and use 60Hz refresh rate. LED on monitor is not lit (no blue or amber color can be seen)
•Power Switch should be in the ON position and power cord should be connected.
•Make sure the Vacation Switch is in the ON position.
•Make sure the LED Brightness Control within the OSM is at the proper setting.
Display image is not sized properly
•Use the OSM Image Adjust controls to increase or decrease the H.SIZE.
•Check to make sure that a supported mode has been selected on the display card or system being
used. (Please consult display card or system manual to change graphics mode.)
No Video
•If no video is present on the screen, turn the Vacation Switch off and on again.
•Make certain the computer is not in a power-saving mode (touch the keyboard or mouse).
USB Hub does not operate
•Make sure the USB cable is properly connected. Refer to the User’s Manual of the USB device.
18
References
NEC Monitor Customer Service & Support
Customer Service and Technical Support: (800) 632-4662
Fax: |
(800) |
695-3044 |
Parts and Accessories/Macintosh |
|
|
Cable Adapter: |
(800) |
632-4662 |
Warranty Information: |
www.necdisplay.com |
|
Online Technical Support |
www.necdisplay.com |
|
Sales and Product Information |
|
|
Sales Information Line: |
(888) |
632-6487 |
Canadian Customers: |
(866) |
771-0266, Ext#: 4037 |
Government Sales: |
(800) |
284-6320 |
Government Sales email: |
gov@necdisplay.com |
|
Electronic Channels |
|
|
World Wide Web: |
www.necdisplay.com |
|
Product Registration: |
www.necdisplay.com |
|
European Operations: |
www.nec-display-solutions.com |
|
Drivers and Downloads |
www.necdisplay.com |
|
19
Loading...
