MultiSync LCD1970VX
MultiSync LCD1970NX
MultiSync LCD1970NXp
User’s Manual
Index
Warning, Caution ......................................................................................................................... |
English-1 |
Declaration ................................................................................................................................... |
English-1 |
Canadian Department of Communications Compliance Statement ............................................ |
English-2 |
Declaration of Conformity ............................................................................................................ |
English-2 |
Contents ....................................................................................................................................... |
English-3 |
Quick Start ................................................................................................................................... |
English-4 |
Controls ........................................................................................................................................ |
English-8 |
Recommended use .................................................................................................................... |
English-10 |
Specifications for LCD1970VX ................................................................................................... |
English-12 |
Specifications for LCD1970NX .................................................................................................. |
English-13 |
Specifications for LCD1970NXp ................................................................................................ |
English-14 |
Features ..................................................................................................................................... |
English-15 |
Troubleshooting .......................................................................................................................... |
English-16 |
TCO’03 ....................................................................................................................................... |
English-17 |
Manufacturer’s Recycling and Energy Information..................................................................... |
English-18 |
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
|
|
CAUTION |
|
CAUTION: |
TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM |
||
|
WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE |
||
|
POWER CORD FROM THE AC OUTLET.DO NOT REMOVE COVER (OR BACK). NO USER |
||
|
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. |
||
This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. Therefore, it should be read carefully in order to avoid any problems.
Caution:
When operating the MultiSync LCD1970VX/MultiSync LCD1970NX/MultiSync LCD1970NXp with a 220-240V AC power source in Europe, use the power cord provided with the monitor.
In the UK, a BS approved power cord with a moulded plug has a Black (five Amps) fuse installed for use with this equipment. If a power cord is not supplied with this equipment please contact your supplier.
When operating the MultiSync LCD1970VX/MultiSync LCD1970NX/MultiSync LCD1970NXp with a 220-240V AC power source in Australia, use the power cord provided with the monitor. If a power cord is not supplied with this equipment please contact your supplier.
For all other cases, use a power cord that matches the AC voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.
Declaration
Declaration of the Manufacturer
We hereby certify that the colour monitor MultiSync LCD1970VX (L194RK)/MultiSync LCD1970NX (L194RH)/MultiSync LCD1970NXp (L194RH) are in compliance with
Council Directive 73/23/EEC:
– EN 60950-1
Council Directive 89/336/EEC:
–EN 55022
–EN 61000-3-2
–EN 61000-3-3
–EN 55024
and marked with
NEC Display Solutions, Ltd.
4-13-23, Shibaura,
Minato-Ku
Tokyo 108-0023, Japan
English
Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation. ENERGY STAR is a U.S. registered trademark.
OmniColor is a registered trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland.
ErgoDesign is a registered trademark of NEC Display Solutions, Ltd. in Austria, Benelux, Denmark, France, Germany, Italy, Norway, Spain, Sweden and U.K.
NaViSet is a trademark of NEC Display Solutions Europe GmbH in the countries of EU and Switzerland.
MultiSync is a registered trademark of NEC Display Solutions, Ltd. in the countries of U.K., Italy, Austria, Netherlands, Switzerland, Sweden, Spain, Denmark, Germany, Norway and Finland.
All other brands and product names are trademarks or registered trademarks of their respective owners.
As an ENERGY STAR® Partner, NEC Display Solutions of America, Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. The ENERGY STAR emblem does not represent EPA endorsement of any product or service.
English-1
Canadian Department of Communications Compliance
Statement
DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 60950-1.
FCC Information
1.Use the attached specified cables with the MultiSync LCD1970VX (L194RK)/MultiSync LCD1970NX (L194RH)/ MultiSync LCD1970NXp (L194RH) colour monitor so as not to interfere with radio and television reception.
(1)The power supply cord you use must have been approved by and comply with the safety standards of U.S.A., and meet the following condition.
Power supply cord |
Non shield type, 3-conductor |
Length |
2.0 m |
Plug shape |
|
U.S.A
(2)Please use the supplied shielded video signal cable. Use of other cables and adapters may cause interference with radio and television reception.
2.This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, Stock No. 004-000-00345-4.
Declaration of Conformity
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
U.S. Responsible Party: |
NEC Display Solutions of America, Inc. |
|
Address: |
500 Park Blvd, Suite 1100 |
|
|
Itasca, Illinois 60143 |
|
Tel. No.: |
(630) 467-3000 |
|
|
|
|
Type of Product: |
Display Monitor |
|
Equipment Classification: |
Class B Peripheral |
|
Model: |
MultiSync LCD1970VX (L194RK)/MultiSync LCD1970NX (L194RH)/ |
|
|
MultiSync LCD1970NXp (L194RH) |
|
We hereby declare that the equipment specified above conforms to the technical standards as specified in the FCC Rules.
English-2
Contents
Your new NEC MultiSync LCD monitor box* should contain the following:
•MultiSync LCD monitor with tilt/swivel/height adjust stand
•Power Cord
•Cable cover
•Video Signal Cable (15-pin mini D-SUB male to 15-pin mini D-SUB male)
•User’s Manual
•CD ROM (includes complete User’s Manual in PDF format).
To see the User’s Manual, Acrobat Reader 4.0 or higher must be installed on your PC.
Power Cord
Cable cover
User’s Manual |
15-pin mini D-SUB male to |
CD-ROM |
|
15-pin mini D-SUB male |
|
NOTE: This monitor can be equipped with optional loudspeakers: “MultiSync Sound bar”. Please ask your dealer or check our website
http://www.nec-display-solutions.com
*Remember to save your original box and packing material to transport or ship the monitor.
English
English-3
Quick Start
To attach the MultiSync LCD monitor to your system, follow these instructions:
1.Turn off the power to your computer.
2.For the PC or MAC with DVI digital output: Connect the DVI signal cable (not included) to the connector of the display card in your system (Figure A.1). Tighten all screws.
For the PC with Analog output: Connect the 15-pin mini D-SUB signal cable to the connector of the display card in your system (Figure A.2). Tighten all screws.
For the MAC: Connect the Macintosh cable adapter to the computer, then attach the 15-pin mini D-SUB signal cable to the Macintosh cable adapter (Figure B.1). Tighten all screws.
DVI signal cable |
Figure A.1 |
Figure A.2 |
(not included) |
Macintosh
Cable Adapter Figure B.1
(not included)
NOTE: Some Macintosh systems do not require a Macintosh cable adapter.
3.Place hands on each side of the monitor to tilt the LCD panel 30-degree angle and lift up to the highest position (Figure C.1).
4.Connect all cables to the appropriate connectors (Figure C.1).
5.Place power cord into the specific hooks indicated in Figure C.2.
6.Place the D-Sub into the specific hooks indicated in Figure C.2.
30˚ Tilt
|
Power Cord |
Highest |
D-SUB Cable |
|
|
Stand |
|
Position |
|
DVI Cable (not included) |
Figure C.1 |
Figure C.2 |
DC-OUT (NX/NXp only)
NEC optional product attachment.
Do not use this connector unless specified.
English-4
