LP8 820 VR01/LP8 820 INOX VR01
12 place settings
Dear Customer,
Please carefully read this manual before using the dishwasher, it will help you to use and maintain the dishwasher properly.
Keep it to refer to it at a later date.
Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions, Operating Instructions, Installation Instructions and Troubleshooting Tips, etc.
To review the section on troubleshooting Tips will help you to solve some common problems by yourself .
If you can not solve the problems by yourself , please ask for the help of professional technicians.
The manufacturer, following a policy of constant development and updating of the product, may make modifications without giving prior notice.
This user manual shall also be got from the manufacturer or responsible vendor.
Control Panel................................................... |
3 |
Dishwasher Features.................................... ... |
3 |
A Water Softener........................................... |
4 |
B Loading the Salt into the Softener................. |
5 |
C Fill the Rinse Aid Dispenser......................... |
5 |
D Function of Detergent ................................. |
6 |
Attention before or after loading the Dishwasher |
|
Baskets.......................................................... |
9 |
Loading the upper Basket............................... |
10 |
Loading the Lower Basket............................... |
10 |
Wash Cycle Table........................................... |
11 |
Turning on the Appliance................................ |
11 |
Change the Programme.................................. |
12 |
At the end of the Wash Cycle........................... |
12 |
Filtering System............................................. |
13 |
Caring for the Dishwasher............................... |
14 |
Positioning the Appliance............................... |
15 |
About Power Connection................................ |
15 |
Water Connection.......................................... |
16 |
Start of Dishwasher....................................... |
17 |
Before calling for service................................. |
18 |
Error codes................................................... |
19 |
Technical information..................................... |
20 |
When using your dishwasher,
follow the precautions listed below:
This appliance is intended to be used in household and similar applications such as:
-staff kitchen areas in shops, offices and other working environments;
-farm houses;
-by clients in hotels, motels and other residential type environments;
-bed and breakfast type environments.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. For EN60335-1
This appliance is not intended for use by persons (including children )with reduced physical, sensory or mental capabilities, or lack of experience and knowledge ,unless they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. For IEC60335-1
This appliance is for indoor use only, for household
use only.
To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.
Please unplug before cleaning and maintenance the appliance .
Use a soft cloth moisten with mild soap, and then use a dry cloth to wipe it again.
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of anelectric shock by providing a path of least resistance of electric current. This appliance is equipped with a cord having an equipment-earthing conductor and a grounding plug.
The plug must be plugged into an appropriate outlet that is installed and earthed in accordance with all local codes and ordinances.
Improper connection of the equipment-earthing conductor can result in the risk of an electric shock.
Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded.
Do not modify the plug provided with the appliance; If it does not fit the outlet.
Have a proper outlet installed by a qualified electrician.
Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
Do not operate your dishwasher unless all enclosure panels are properly in place.
Open the door very carefully if the dishwasher is operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the door when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to damage the door seal;
2) Warning: Knives and other utensils with sharp points must be loaded in the basket with their points down or placed in a horizontal position.
Check that the detergent powder is empty after completion of the wash cycle.
Do not wash plastic items unless they are marked dishwasher safe or the equivalent.
For plastic items not so marked, check the manufacturer's recommendations.
Use only detergent and rinse additives designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
Children should be supervised to ensure that they do not play with the appliance.
The door should not be left open, since this could increase the risk of tripping.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
During installation, the power supply must not be excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using new hose sets and that old hose-sets should not be reused.
The maximum number of place settings to be washed is 12.
The maximum permissible inlet water pressure is 1MPa.
The minimum permissible inlet water pressure is 0.04MPa.
Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts are marked with the standard international abbreviations:
PE |
for polyethylene, e.g. sheet wrapping material |
PS |
for polystyrene, e.g. padding material |
POM |
polyoxymethylene, e.g. plastic clips |
PP |
polypropylene, e.g. Salt filler |
ABS |
Acrylonitrile Butadiene Styrene, e.g. Control |
Panel .
Packaging material could be dangerous for children!
For disposing of package and the appliance please go to a recycling centre. Therefore cut off the power supply cable and make the door closing device unusable.
Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling.
By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
For more detailed information about recycling of this product, please contact your local city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary.
For detailed operating method read the corresponding content on the instruction manual.
Switch on the appliance
Fill the detergent dispenser
Check the rinse aid level
Check the regeneration salt level
Load the baskets
Select a programme
Press the On/Off button to switch on the appliance, Open the door.
With each wash cycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
(On models with water softener system only.) Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into the softener by the number of cycles the dishwasher has run.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans, then load the baskets. Refer to the dishwasher loading instructions.
Close the door, Press the Programme button until the selected programme lights up. ( See the section entitled“Operationg instruction”)
Running the dishwasher
Changing the programme
Add forgotten dishes in the dishwasher.
If the appliance is switched off during a wash cycle.
Switch off the appliance
Turn off the water tap, unload the baskets
Turn on the water tap and press the Start/Pause button. The machine will start working after about 10 seconds.
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent may have already been released and the water already drained. If this is the case, the detergent dispenser must be refilled.
2. Press the Start/Pause button then press the program button for more than 3 seconds to cancel the running programme.
3. Select a new programme.
4. Restart the dishwasher.
1.Press the start/pause button to stop the machine. 2.Open the door.
3.Add the forgotten dishes.
4.Close the door, then press the start/pause button, the dishwasher will start running again after 10 seconds.
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher according to the original Power-on state ).
When the working cycle has finished, the buzzer of the dishwasher will sound 8 times, then stop.
Turn off the appliance using the ON/OFF button.
Open the door carefully.
Hot steam may escape
when the door is opened!
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unload the appliance, starting from the lower basket.
To get the best performance from your dishwasher, read all operating instructions before using it for the first time.
1.On/Off: To turn on/off the power supply. 2.Delay Button : To Press the button to delay.
3.Half load functions Button: To select Half load functions. (With this Half load function you can only use it when you have only about or less than6 place setting dish ware, and you will see less water and energy consumption , can only
be used with Intensive, Normal, ECO,Glass and 90 min .) 4. Delay indicators: to be on when selected the delay function.
5.Halfload indicator: To be on when selected the Halfload function.
6.Child lock indicator: press the halfload functions button and delay button simultaneously to lock the program.
7.Water tap indicator: the tap is not open or water inlet is not working.
Front view
8.Salt warning lights: To be on when the salt container need to be refilled.
9.Rinse aid warning lights: To be on when dispenser need to be refilled.
10.Display screen: to show the reminding time and the state(running state, delay time etc )
11.Program indicators: to show whichprogram you have chose.
12.Start/Pause: To start the selected washing program or pause the washing program when
the machine is working.
13.Program Button : To Press the button to select appropriate Program.
Back view
1 |
6 |
|
|
2 |
7 |
|
3 |
|
4 |
8 |
5
1 |
Upper Basket |
4 |
2 |
Inner pipe |
5 |
3 |
Lower Basket |
6 |
|
9 |
|
|
10 |
|
|
|
|
|||
|
|
|
|
Drain pipe |
|
Salt Container |
7 |
Spray arms |
10 |
||
|
|
Filter assembly |
|
|
|
Dispenser |
8 |
|
|
|
|
|
|
|
|
|
|
Cup Shelf |
9 |
Inlet pipe connector |
|
|
|
