SM-J200F SM-J200G/DD SM-J200H/DD SM-J200Y
SM-J200F/DS SM-J200GU/DS SM-J200H/DS
User Manual
English. 09/2015. Rev.1.0 |
www.samsung.com |
Table of Contents
Basics
4Read me first
5Package contents
6Device layout
8 |
Battery |
13 |
SIM or USIM card |
16 |
Memory card |
18 |
Turning the device on and off |
18 |
Touchscreen |
21 |
Home screen |
27Lock screen
28Notification panel
29Entering text
31Screen capture
31Opening apps
32Device and data management
Applications
36Installing or uninstalling apps
37Phone
41Contacts
42Messages
44Internet
45Email
46Camera
52Gallery
54Smart Manager
57 S Planner
59Video
60Voice Recorder
61My Files
61Memo
62Clock
63Calculator
64Radio
65USB Backup
66Google apps
Settings
68 |
Introduction |
68 |
Wi-Fi |
70 |
Bluetooth |
72 |
Flight mode |
72Mobile hotspot and tethering
73Data usage
74SIM card manager (dual SIM models)
74Mobile networks
75NFC and payment (NFC-enabled models)
78 More connection settings
80Sounds and notifications
80Display
81Applications
81 Wallpaper
81 Themes
2
Table of Contents
81Lock screen and security
82Privacy
82Accessibility
83Accounts
84Backup and reset
84Language and input
85Battery
85Storage
86Date and time
86User manual
86About device
Appendix
87 Troubleshooting
3
Basics
Read me first
Please read this manual before using the device to ensure safe and proper use.
•Descriptions are based on the device’s default settings.
•Some content may differ from your device depending on the region, service provider, model specifications, or device’s software.
•Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in.
•Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung.
•Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly.
•Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media.
•You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature.
•Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers.
•Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty.
4
Basics
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information
Package contents
Check the product box for the following items:
•Device
•Battery
•Quick start guide
• The items supplied with the device and any available accessories may vary depending on the region or service provider.
•The supplied items are designed only for this device and may not be compatible with other devices.
•Appearances and specifications are subject to change without prior notice.
•You can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase.
•Use only Samsung-approved accessories. Using unapproved accessories may cause the performance problems and malfunctions that are not covered by the warranty.
•Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website.
5
Basics
Device layout
Headset jack |
Proximity sensor |
Speaker |
Front camera |
|
Touchscreen
Home key
Recents key
Multipurpose jack
GPS antenna
Flash
Rear camera
Back cover
Main antenna
Power key
Back key
Microphone
Loud speaker
Volume key
NFC antenna (NFC-enabled models)
6
Basics
• Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery.
•Using a Samsung-approved screen protector is recommended. Unapproved screen protectors may cause the sensors to malfunction.
•Do not allow water to contact the touchscreen. The touchscreen may malfunction in humid conditions or when exposed to water.
Keys
Key |
Function |
||
Power |
• |
Press and hold to turn the device on or off. |
|
• |
Press to turn on or lock the screen. |
||
|
|||
|
|
|
|
Recents |
• |
Tap to open the list of recent apps. |
|
|
|
|
|
|
• |
Press to turn on the screen while the screen is locked. |
|
Home |
• |
Press to return to the Home screen. |
|
|
• |
Press and hold to launch Google. |
|
|
|
|
|
|
• |
Tap to return to the previous screen. |
|
Back |
• |
Tap and hold to access additional options for the current |
|
|
|
screen. |
|
|
|
|
|
Volume |
• |
Press to adjust the device volume. |
|
|
|
|
|
7
Basics
Battery
Installing the battery
1 Remove the back cover.
Be careful not to damage your fingernails when you remove the back cover.
Do not bend or twist the back cover excessively. Doing so may damage the cover.
2 Insert the battery with the battery’s gold-coloured contacts properly aligned with the device’s contacts.
2
1
8
Basics
3 Replace the back cover.
Removing the battery
1
2
Remove the back cover.
Pull out the battery.
9
Basics
Charging the battery
Charge the battery before using it for the first time or when it has been unused for extended periods.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.
1 Plug the small end of the charger into the multipurpose jack of the device, and plug the large end of the charger into an electric socket.
Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty.
2 After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket.
Do not remove the battery before removing the charger. This may damage the device.
To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging.
10
Basics
Viewing the remaining charging time
While charging, open the Home screen and tap Apps →Settings →Battery.
The actual charging time may vary depending on the status of your device and the charging conditions. The remaining charging time may not be displayed when you charge the device in very cold or very hot conditions.
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
•Optimise the device using the Smart manager.
•When you are not using the device, switch to sleep mode by pressing the Power key.
•Activate power saving mode.
•Close unnecessary apps.
•Deactivate the Bluetooth feature when not in use.
•Deactivate the Wi-Fi feature when not in use.
•Deactivate auto-syncing of apps.
•Decrease the backlight time.
•Decrease the screen brightness.
Battery charging tips and precautions
•When the battery power is low, the battery icon appears empty.
•If the battery is completely discharged, the device cannot be turned on immediately when the charger is connected. Allow a depleted battery to charge for a few minutes before turning on the device.
•If you use multiple apps at once, network apps, or apps that need a connection to another device, the battery will drain quickly. To avoid disconnecting from the network or losing power during a data transfer, always use these apps after fully charging the battery.
•Using a power source other than the charger, such as a computer, may result in a slower charging speed due to a lower electric current.
11
Basics
•The device can be used while it is charging, but it may take longer to fully charge the battery.
•If the device receives an unstable power supply while charging, the touchscreen may not function. If this happens, unplug the charger from the device.
•While charging, the device and the charger may heat up. This is normal and should not affect the device’s lifespan or performance. If the battery gets hotter than usual, the charger may stop charging.
•If the device is not charging properly, take the device and the charger to a Samsung Service Centre.
Ultra power saving mode
Use this mode to extend the device’s battery power. In ultra power saving mode, the device performs the following:
•Restricts the available apps to essential and selected apps only.
•Deactivates the mobile data connection when the screen turns off.
•Deactivates the Wi-Fi and Bluetooth features.
On the Home screen, tap Apps →Settings →Battery →Ultra power saving mode, and then tap the switch to activate it.
To deactivate ultra power saving mode, tap MORE →Disable Ultra power saving mode.
The usage time left shows the time remaining before the battery power runs out. Usage time left may vary depending on your device settings and operating conditions.
12
Basics
SIM or USIM card
Installing the SIM or USIM card
Insert the SIM or USIM card provided by the mobile telephone service provider.
• |
Only microSIM cards work with the device. |
• |
Some LTE services may not be available depending on the service provider. For |
|
more information about service availability, contact your service provider. |
1
2
Remove the back cover and battery.
►Single SIM models: Insert the SIM or USIM card with the gold-coloured contacts facing downwards.
13
Basics
►Dual SIM models: Insert the SIM or USIM card with the gold-coloured contacts facing downwards.
Insert the primary SIM or USIM card into SIM card slot 1 ( 1 ) and the secondary SIM or USIM card into SIM card slot 2 ( 2 ).
2
1
Use caution not to lose or let others use the SIM or USIM card. Samsung is not responsible for any damages or inconveniences caused by lost or stolen cards.
3 Replace the battery and back cover.
14
Basics
Removing the SIM or USIM card
1
2
Remove the back cover and battery.
Pull out the SIM or USIM card.
►Single SIM models:
►Dual SIM models:
15
Basics
Using dual SIM or USIM cards (dual SIM models)
If you insert two SIM or USIM cards, you can have two phone numbers or service providers for a single device.
Activating SIM or USIM cards
On the Home screen, tap Apps →Settings →SIM card manager. Select a SIM or USIM card and tap the switch to activate it.
Changing the display name and icon of SIM or USIM cards
On the Home screen, tap Apps →Settings →SIM card manager. Select a SIM or USIM card, tap Name or Icon. Set a display name and icon for each card.
Switching between cards
When two SIM or USIM cards are activated, card selection icons appear on the dashboard of the notification panel. Open the notification panel and then select a card.
Memory card
Installing a memory card
Your device accepts memory cards with maximum capacities of 128 GB. Depending on the memory card manufacturer and type, some memory cards may not be compatible with your device.
• Some memory cards may not be fully compatible with the device. Using an incompatible card may damage the device or the memory card, or corrupt the data stored in it.
•Use caution to insert the memory card right-side up.
•The device supports the FAT file system for memory cards. When inserting a card
formatted in a different file system, the device asks to reformat the memory card.
•Frequent writing and erasing of data shortens the lifespan of memory cards.
•When inserting a memory card into the device, the memory card’s file directory appears in the My Files →SD card folder.
16
Basics
1
2
3
Remove the back cover.
Insert a memory card with the gold-coloured contacts facing downwards.
Replace the back cover.
Removing the memory card
Before removing the memory card, first unmount it for safe removal.
On the Home screen, tap Apps →Settings →Storage →Unmount SD card.
1
2
3
Remove the back cover.
Pull out the memory card.
Replace the back cover.
Do not remove the memory card while the device is transferring or accessing information. Doing so can cause data to be lost or corrupted or damage to the memory card or device. Samsung is not responsible for losses that result from the misuse of damaged memory cards, including the loss of data.
17
Basics
Formatting the memory card
A memory card formatted on a computer may not be compatible with the device. Format the memory card on the device.
On the Home screen, tap Apps →Settings →Storage →Format SD card →FORMAT SD CARD →ERASE EVERYTHING.
Before formatting the memory card, remember to make backup copies of all important data stored in the memory card. The manufacturer’s warranty does not cover loss of data resulting from user actions.
Turning the device on and off
Press and hold the Power key for a few seconds to turn on the device.
When you turn on your device for the first time or after performing a data reset, follow the onscreen instructions to set up your device.
To turn off the device, press and hold the Power key, and then tap Power off.
• If your device is frozen and unresponsive, press and hold the Power key for more than 7 seconds to restart it.
•Follow all posted warnings and directions from authorised personnel in areas where the use of wireless devices is restricted, such as aeroplanes and hospitals.
Touchscreen
• Do not allow the touchscreen to come into contact with other electrical devices. Electrostatic discharges can cause the touchscreen to malfunction.
•To avoid damaging the touchscreen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips.
•The device may not recognise touch inputs close to the edges of the screen, which
are outside of the touch input area.
•Leaving the touchscreen idle for extended periods may result in afterimages (screen burn-in) or ghosting. Turn off the touchscreen when you do not use the device.
•It is recommended to use fingers when you use the touchscreen.
18
Basics
Tapping
To open an app, to select a menu item, to press an on-screen button, or to enter a character using the keyboard on the screen, tap it with your finger.
Tapping and holding
Tap and hold an item or the screen for more than 2 seconds to access available options.
Dragging
To move an item, tap and hold it and drag it to the target position.
19
Basics
Double-tapping
Double-tap on a webpage or image to zoom in. Double-tap again to return.
Swiping
Swipe to the left or right on the Home screen or the Apps screen to view other panels. Swipe upwards or downwards to scroll through a webpage or a list of items, such as contacts.
Spreading and pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
20
Basics
Home screen
Home screen
The Home screen is the starting point for accessing all of the device’s features. It displays widgets, shortcuts to apps, and more.
To view other panels, swipe to the left or right.
A widget
An app
Favourite apps
A screen indicator |
A folder |
Apps screen icon
21
Basics
Home screen options
On the Home screen, tap and hold an empty area, or pinch your fingers together to access the available options. Customise the Home screen by adding, deleting, or rearranging Home screen panels. You can also set the Home screen wallpaper, add widgets to the Home screen, and more.
•Wallpapers: Change the wallpaper settings for the Home screen and the locked screen.
•Widgets: Add widgets to the Home screen. Widgets are small apps that launch specific app functions to provide information and convenient access on your Home screen.
•Themes: Change the device’s theme. Visual elements of interface, such as colours, icons, and wallpapers, will change depending on the selected theme.
Adding items
Tap and hold an app or a folder from the Apps screen, and then drag it to the Home screen.
To add widgets, tap and hold an empty area on the Home screen, tap Widgets, tap and hold a widget, and then drag it to the Home screen.
22
Basics
Moving and removing an item
Tap and hold an item on the Home screen, and then drag it to a new location. To move the item to another panel, drag it to the side of the screen.
You can also move frequently used apps to the shortcuts area at the bottom of the Home screen.
To remove an item, tap and hold the item. Then, drag it to Remove at the top of the screen.
Creating folders
1
2
On the Home screen, tap and hold an app, and then drag it over another app.
Drop the app when a folder frame appears around the apps. A new folder containing the selected apps will be created.
3 Tap Enter folder name. and enter a folder name. To change the folder colour, tap
.
To add more apps to the folder, tap and hold another app, and then drag it to the folder.
23
Basics
Managing panels
On the Home screen, tap and hold an empty area to add, move, or remove a panel. To add a panel, swipe to the left, and then tap
.
To move a panel, tap and hold a panel preview, and then drag it to a new location.
To remove a panel, tap and hold a panel preview, and then drag it to Remove at the top of the screen.
To set a panel as the main Home screen, tap
.
Apps screen
The Apps screen displays icons for all apps, including newly installed apps.
On the Home screen, tap Apps to open the Apps screen. To view other panels, swipe to the left or right.
Moving items
This feature may not be available depending on the region or service provider.
On the Apps screen, tap EDIT. Tap and hold an item and drag it to a new location. To move the item to another panel, drag it to the side of the screen.
Creating folders
1
2
This feature may not be available depending on the region or service provider.
On the Apps screen, tap EDIT.
Tap and hold an app, and then drag it over another app.
24
Basics
3 Drop the app when a folder frame appears around the apps. A new folder containing the selected apps will be created.
4 Tap Enter folder name. and enter a folder name. To change the folder colour, tap
.
To add more apps to the folder, tap and hold another app, and then drag it to the folder.
25
Basics
Indicator icons
Indicator icons appear on the status bar at the top of the screen. The icons listed in the table below are most common.
The status bar may not appear at the top of the screen in some apps. To display the status bar, drag down from the top of the screen.
Icon |
Meaning |
|
No signal |
|
|
/ |
Signal strength |
/ |
Currently accessing SIM or USIM card (dual SIM models) |
|
|
|
Roaming (outside of normal service area) |
|
|
|
GPRS network connected |
|
|
|
EDGE network connected |
|
|
|
UMTS network connected |
|
|
|
HSDPA network connected |
|
|
|
HSPA+ network connected |
|
|
/ |
LTE network connected (LTE-enabled models) |
|
|
|
Wi-Fi connected |
|
|
|
Bluetooth feature activated |
|
|
|
GPS activated |
|
|
|
Call in progress |
|
|
|
Missed call |
|
|
|
New text or multimedia message |
|
|
|
Alarm activated |
|
|
|
Mute mode activated |
|
|
|
Vibration mode activated |
|
|
26
Basics
Icon Meaning
Flight mode activated
Error occurred or caution required
Battery power level
Lock screen
Pressing the Power key turns off the screen and locks it. Also, the screen turns off and automatically locks if the device is not used for a specified period.
To unlock the screen, press the Power key or the Home key and swipe in any direction.
You can change the way that you lock the screen to prevent others from accessing your personal information.
On the Apps screen, tap Settings →Lock screen and security →Screen lock type, and then select a screen lock method. The device requires an unlock code whenever unlocking it.
If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it.
27
Basics
Pattern
Draw a pattern by connecting four dots or more, and then draw the pattern again to verify it. Set a backup PIN to unlock the screen when you forget the pattern.
PIN
A PIN consists of numbers only. Enter at least four numbers, and then enter the password again to verify it.
Password
A password consists of characters and numbers. Enter at least four characters including numbers and symbols, and then enter the password again to verify it.
Notification panel
Using the notification panel
When you receive new notifications, such as messages or missed calls, indicator icons appear on the status bar. To see more information about the icons, open the notification panel and view the details.
To open the notification panel, drag the status bar downwards. To close the notification panel, swipe upwards on the screen.
28
Loading...
