DDX635WBT
DDX635WBTM
MONITOR WITH DVD RECEIVER
INSTRUCTION MANUAL
This instruction manual is used to describe models listed below. Model availability and features (functions) may differ depending on the country and sales area.
•Region 2 (DVD Region Code 2 area)
•Region 3 (DVD Region Code 3 area)
•Region 4 (DVD Region Code 4 area)
© 2014 JVC KENWOOD Corporation |
LVT2515-001A (MN/M2N/XN) |
CONTENTS
BEFORE USE............................................................ |
2 |
How to reset your unit.................................................... |
3 |
INITIAL SETTINGS .................................................. |
4 |
BASICS .................................................................... |
6 |
Component names and functions............................. |
6 |
Common operations....................................................... |
7 |
Common screen operations......................................... |
8 |
Selecting the playback source..................................... |
9 |
DISCS .................................................................... |
10 |
USB........................................................................ |
15 |
iPod/iPhone ......................................................... |
16 |
APPs...................................................................... |
19 |
Pandora® (Only for DDX635WBT Region 4)....... |
20 |
TUNER................................................................... |
22 |
OTHER EXTERNAL COMPONENTS ...................... |
26 |
Using external audio/video players—AV-IN ........ |
26 |
Using a rear view camera ............................................ |
26 |
Using a smartphone—HDMI/MHL........................... |
27 |
Watching a TV.................................................................. |
27 |
Using the external navigation unit.......................... |
28 |
BLUETOOTH ......................................................... |
29 |
SETTINGS.............................................................. |
37 |
Settings for using applications of the iPod/ |
|
iPhone/Android .............................................................. |
37 |
Sound adjustment ......................................................... |
38 |
Adjustment for video playback................................. |
40 |
Changing display design............................................. |
42 |
Customizing the <TOP MENU> screen .................. |
43 |
Customizing the system settings ............................. |
43 |
Setting menu items....................................................... |
45 |
REMOTE CONTROLLER ........................................ |
48 |
CONNECTION/INSTALLATION ............................ |
53 |
REFERENCES......................................................... |
58 |
Maintenance .................................................................... |
58 |
More information........................................................... |
58 |
Error message list ........................................................... |
62 |
Troubleshooting............................................................. |
63 |
Specifications................................................................... |
65 |
BEFORE
USE
V WARNINGS: (To prevent accidents and damage)
•DO NOT install any unit or wire any cable in a location where;
–it may obstruct the steering wheel and gearshift lever operations.
–it may obstruct the operation of safety devices such as air bags.
–it may obstruct visibility.
•DO NOT operate the unit while driving.
If you need to operate the unit while driving, be sure to look around carefully.
•The driver must not watch the monitor while driving.
The marking of products using lasers
The label is attached to the chassis/case and says that the component uses laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit.
How to read this manual:
•Illustrations of DDX635WBT Region 3 are mainly used for explanation. The displays and panels shown in this manual are examples used to provide clear explanations of the operations. For this reason, they may be different from the actual displays or panels.
•This manual mainly explains operations using the buttons on the monitor panel and touch panel. For operations using the remote controller (RC-DV340: supplied only for DDX635WBT Region 3/ DDX635WBTM), see page48.
•< > indicates the various screens/menus/operations/settings that appear on the touch panel.
•[ ] indicates the buttons on the touch panel.
•Indication language: English indications are used for the purpose of explanation. You can select the indication language from the <Setup> menu. (Page 47)
For Kazakhstan (DDX635WBTM)
Дата изготовления (месяц/год) находится на этикетке устройства.
2
BEFORE
USE
For DDX635WBTM
Declaration of Conformity with regard to the EMC Directive 2004/108/EC
Declaration of Conformity with regard to the R&TTE Directive 1999/5/EC
Declaration of Conformity with regard to the RoHS Directive 2011/65/EU
Manufacturer:
JVC KENWOOD Corporation
3-12 Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan
EU Representative:
JVCKENWOOD NEDERLAND B.V. Amsterdamseweg 37, 1422 AC UITHOORN, The Netherlands
English
Hereby, JVC KENWOOD declares that this unit “DDX635WBTM” is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Türkçe
Bu vesileyle JVC KENWOOD, “DDX635WBTM” ünitesinin,1999/5/EC Direktifinin başlıca gereksinimleri ve diğer ilgili
hükümleri ile uyumlu olduğunu beyan eder.
For Turkey
Bu ürün 28300 sayılı Resmi Gazete’de yayımlanan Atik Elektrikli ve Elektronik Eşyalarin Kontrolü Yönetmeliğe uygun olarak üretilmiştir.
Eski Elektrik ve Elektronik Ekipmanların İmha Edilmesi Hakkında Bilgi (ayrı atık toplama sistemlerini kullanan ülkeleri için uygulanabilir)
Sembollü (üzerinde çarpı işareti olan çöp |
kutusu) ürünler ev atıkları olarak atılamaz. |
Eski elektrik ve elektronik ekipmanlar, |
bu ürünleri ve ürün atıklarını |
geri dönüştürebilecek bir tesiste |
değerlendirilmelidir. Yaşadığınız bölgeye |
en yakın geri dönüşüm tesisinin yerini |
öğrenmek için yerel makamlara müracaat |
edin. Uygun geri dönüşüm ve atık |
imha yöntemi sağlığımız ve çevremiz |
üzerindeki zararlı etkileri önlerken |
kaynakların korunmasına da yardımcı |
olacaktır. |
V Cautions on the monitor:
•The monitor built into this unit has been produced with high precision, but it may have some ineffective dots. This is inevitable and is not considered defective.
•Do not expose the monitor to direct sunlight.
•Do not operate the touch panel using a ball-point pen or similar tool with a sharp tip.
Touch the buttons on the touch panel with your finger directly (if you are wearing a glove, take it off).
•When the temperature is very cold or very hot...
–Chemical changes occur inside, causing malfunction.
–Pictures may not appear clearly or may move slowly. Pictures may not be synchronized with the sound or picture quality may decline in such environments.
Fors afety...
•Do not raise the volume level too much, as this will make driving dangerous by blocking outside sounds, and may cause hearing loss.
•Stop the car before performing any complicated operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.
How to reset your unit
If the unit fails to operate properly, press the Reset button. The unit returns to factory settings when the Reset button is pressed (except the registered Bluetooth devices).
ENGLISH 3
INITIAL
SETTINGS
Initials etup
When you power on the unit for the first time or reset the unit, the initial setting screen appears.
•You can also change the settings on the <Setup> screen. (Page 45)
1
<Language> Select the text language used for (Page 47) on-screen information.
|
• Set <GUI Language> to |
|
display the operation buttons |
|
and menu items in the |
|
selected language ([Local]: |
|
initially selected) or English |
|
([English]). |
<Angle> |
Adjust the panel angle. |
(Page 7) |
|
<R-CAM |
Select [ON] when connecting |
Interrupt> |
the rear view camera. |
(Page 46) |
|
<Panel |
Select the color of the buttons |
Color> |
on the monitor panel. |
(Page 42) |
|
2 Finish the procedure.
The <TOP MENU> screen is displayed.
Setting the security function
You can set a security code to protect your receiver system against theft.
Registering the security code
1Display the <TOP MENU> screen.
On the source control screen:
2 Display the <System> setting screen.
3Display the <Security Code Set> screen.
•Press [K] repeatedly to change the page on the <System> menu screen.
•To clear the registered security code, perform steps 1 and 2, then press [CLR] in <Security Code>.
4Enter a four-digit number (1), then confirm the entry (2).
•Press [Clear] to delete the last entry.
•Press [Cancel] to cancel the setting.
5Repeat step 4 to confirm your security code.
Now, your security code is registered.
•When the unit is being reset or disconnected from the battery, you are required to enter the security code. Enter the correct security code, then press
[Enter].
4
INITIAL
SETTINGS
Activating the security function
You can activate the security function to protect your receiver system against theft.
1Display the <System> setting screen.
On the <TOP MENU> screen:
•Press [K] repeatedly to change the page on the <System> menu screen.
2
The security indicator on the monitor panel flashes when the vehicle ignition is off.
To deactivate the security function: Select [OFF] for <SI>.
Clock settings
1Display the <TOP MENU> screen.
On the source control screen:
2 Display the <Setup> screen.
3 Display the <Clock> screen.
4 Set the clock time.
<NAV>* Synchronizes the clock time with the connected navigation unit.
<Radio Data Synchronizes the clock time with System> FM Radio Data System.
<OFF> Sets the clock manually. (See below.)
When selecting <OFF>:
Adjust the hour (1), then adjust the minute (2).
• Press [Reset] to set the minute to “00”.
5 Finish the procedure.
* Appears only when the navigation unit is connected.
ENGLISH 5
BASICS
Component names and functions
1Power indicator/Security indicator
•Lights up while the unit is turned on.
•Flashes when the security function is activated. (Page 5)
2 Monitor panel*
3 Screen (touch panel)
4TEL/VOICE button
•Displays the phone control screen. (Press) (Page 33)
•Activates voice dialing. (Hold) (Page 34)
5
/ V.OFF button
•Displays the phone book. (Press) (Page 33)
•The function of the button when held varies depending on the <Phonebook Key Long
Press> setting. (Page 47)
6Volume +/− button
Adjusts the audio volume. (Page 7) ATT button
Attenuates the sound. (Page 7)
7M (Eject) button
•Ejects the disc. (Tilts the monitor panel fully.)
•Opens/closes the monitor panel.
8MENU/B button
•Displays the <TOP MENU> screen. (Press) (Page 8)
•Turns off the power. (Hold) (Page 7)
•Turns on the power. (Press) (Page 7)
9AV/AV OUT button
•Displays the current source screen. (Press)
•Displays the screen of the external component connected to the AV-OUT terminal. (Hold) (Page57)
pS/T button
Functions same as [S]/[T] on the touch panel during playing a source.
qAPPS button
Displays the App screen. (Page 19)
wAUDIO button
•Displays the <Equalizer> screen. (Press) (Page 38)
*You can change the color of the buttons on the monitor panel. (Page 42)
V Caution on the volume setting:
Digital devices produce very little noise compared with other sources. Lower the volume before playing these digital sources to avoid damaging the speakers by sudden increase of the output level.
6
BASICS
Common operations
Turning on the power
Turning off the power
(Hold)
Adjusting the volume
To adjust the volume (00 to 35)
Press + to increase, and press − to decrease.
•Holding the button increases/decreases the volume continuously.
Toat tenuatet hes ound
The ATT indicator lights up.
To cancel the attenuation: Press the same button again.
Adjusting the panel angle
1Display the <Angle Adjust> screen.
On the <TOP MENU> screen:
•Press [K] repeatedly to change the page on the <Display> menu screen.
2 Select an angle (0 – 6).
•To set the current position as the power off position, select [Memory].
Putting the unit in standby
1 Display all <TOP MENU> items.
On the <TOP MENU> screen:
2
ENGLISH 7
BASICS
Turning off the screen
(Hold)
•This operation works only when <Phonebook Key Long Press> is set to [V-OFF]. (Page 47)
To turn on the screen: Press MENU/B on the monitor panel, or touch the display.
Common screen operations
Common screen descriptions
You can display other screens any time to change the source, show the information, or change the settings, etc.
Source control screen
Performs source playback operations.
•The operation buttons vary depending on the selected source.
1
2
34
Common operation buttons:
1Displays other operation buttons.
•Disabled when there are no other buttons. 2 Switches between the normal source control screen and easy control screen. (See below.)
3 Displays the <TOP MENU> screen. (See the right column.)
•Pressing MENU/B on the monitor panel also displays the <TOP MENU> screen.
4Displays the screen of the connected navigation unit.* (Page 28)
Easy control screen
Pressing [
] switches between the normal source control screen and easy control screen.
The easy control screen allows you to control the source easily with simple buttons.
•The displayed buttons vary depending on the selected source.
<TOP MENU> screen
Displays the source control screen and settings screen.
1 |
2 |
3
Common operating buttons:
1Changes the playback source. (Page 9)
•Press [ALL SRC] to display all <TOP MENU> items. (Page 9)
•You can arrange the items to display on the <TOP MENU> screen. (Page 43)
2 Displays the phone control screen. (Page 33)
3 Displays the <Setup> screen. (See below.)
<Setup> screen
Changes the detailed settings. (Page 45)
1
|
|
3 |
|
2 |
4 |
Common operating buttons: |
|
|
1 |
Selects the menu category. |
|
2 |
Displays the <TOP MENU> screen. |
|
3 |
Changes the page. |
|
4 |
Returns to the previous screen. |
|
* Appears only when a navigation unit is connected.
8
BASICS
Touch screen operations
1
3 |
4 |
2
1Displays the video control menu while playing a video.
2Displays the source control screen while playing a video.
•The operation buttons disappear when the screen is touched or when no operation is done for about 5 seconds.
3 Goes to the previous chapter/track.*
4 Goes to the next chapter/track.*
* Not available for video from an external component.
Selecting the playback source
On the <TOP MENU> screen:
•You can change the items (other than [SETUP]) to display on the <TOP MENU> screen. (Page 43)
Displays the navigation screen when a navigation unit is connected. (Page 28)
Plays a disc. (Page 10)
Switches to the radio broadcast. (Page 22)
Plays an iPod/iPhone. (Page 16) Plays files on a USB device. (Page 15)
Plays a device connected to the HDMI/MHL input terminal. (Page 27)
Switches to the Pandora broadcast. (Page 20)
Plays a Bluetooth audio player. (Page 35)
Switches to the screen of App from the connected iPod touch/ iPhone. (Page 19)
Displays the phone control screen. (Page 33)
[AV-IN1][AV-IN2]
Switches to an external component connected to the AVIN1 or iPod/AV-IN2 input terminal. (Page 26)
*1 When no navigation unit is connected, “No Navigation” appears. *2 Only for DDX635WBT Region 4.
To display all sources and items on the <TOP MENU> screen
•You can change the page to display more items by pressing [J]/[K].
ENGLISH 9
DISCS
Playing a disc
•If a disc does not have a disc menu, all tracks on it will be played repeatedly until you change the source or eject the disc.
•For playable disc types/file types, see page 59.
Inserting a disc
Insert a disc with the label side facing up.
The source changes to “DISC” and playback starts.
•The IN indicator lights up while a disc is inserted.
•If “
” appears on the screen, the unit cannot accept the operation you have tried to do.
–In some cases, without showing “
,” operations will not be accepted.
•When playing back a multi-channel encoded disc, the multi-channel signals are downmixed to stereo.
Ejecting a disc
•When removing a disc, pull it horizontally.
•You can eject a disc when playing another AV source.
•If the ejected disc is not removed within
60 seconds, the disc is automatically inserted again into the loading slot to protect it from dust.
Closingt hem onitorp anel
After removing the disc, press M on the monitor panel. The monitor panel closes.
Playback operations
When the operation buttons are not displayed on the screen, touch the area shown on the illustration.
•To change settings for video playback, see page 40.
Indications and buttons on the source control screen
For DVD/DVD-VR/VCD/DivX/MPEG1/MPEG2
1 |
2 |
3 |
4 5 6
Playback information
1 Media type
2Current playback item information
•DVD Video: Title no./Chapter no.
•DVD-VR: Program no. (or Playlist no.)/Chapter no.*
•DivX/MPEG1/MPEG2: Folder no./Track no.
•VCD: Scene no. (with PBC) or Track no. (without PBC)
3 Playing time
4 Playback mode (Page 13)
5 File type (for DivX/MPEG1/MPEG2)
6 IN indicator
* To display the Original Program/Playlist screen, see page 11.
10
DISCS
Operation buttons
[ |
] |
|
|
|
Displays the easy control screen. |
|
|
|
|
|
|
|
(Page 8) |
[ |
]*1 |
|
Displays the folder/track list. |
|||
|
|
|
|
|
|
(Page 12) |
[O] [N] |
• Reverse/forward search during |
|||||
|
|
|
|
|
|
playback.*2 |
[S] [T] |
• Selects a chapter/track. (Press) |
|||||
|
|
|
|
|
|
• Reverse/forward search.*2 (Hold) |
[IW] |
|
Starts/pauses playback. |
||||
[o] |
|
Stops playback. |
||||
[ |
] |
|
|
|
Displays other operation buttons. |
|
|
|
|
|
|
|
• Disabled when there are no other |
|
|
|
|
|
|
buttons. |
[MODE] |
Changes the settings for disc |
|||||
|
|
|
|
|
|
playback on the <DISC Mode> |
|
|
|
|
|
|
screen. (Page 14) |
[ |
] [ |
]*3 |
Selects playback mode. (Page 13) |
|||
[Playlist]*4 |
Displays an Original Program/Playlist |
|||||
|
|
|
|
|
|
screen. |
[ |
|
] [ |
|
|
]*5 |
Plays in frame-by-frame. |
|
|
|||||
|
|
|||||
[ |
] [ |
|
]*1 |
Selects a folder. |
||
[PBC]*6 |
|
Activates or deactivates the VCD PBC |
||||
|
|
|
|
|
|
(Playback Control) function. |
[MENU] |
Displays the <TOP MENU> screen. |
|||||
*1 Does not appear for DVD/DVD-VR/VCD.
*2 Search speed varies depending on the type of disc or file. *3 Does not appear for DVD/DVD-VR.
*4 Appears only for DVD-VR.
*5 Appears only for DVD/DVD-VR. *6 Appears only for VCD.
ForC D/MP3/WMA/AAC
1 2 3 4 5
6 7 8
Playback information
1 Media type
2Track/file information
•Pressing [<] scrolls the text if not all of the text is shown.
3Current playback item information
•MP3/WMA/AAC: Folder no./Track no.
•CD: Track no.
4 Playback status
5 Playing time
6 Playback mode (Page 13)
7 File type
8 IN indicator
Operation buttons
[ |
] |
|
Displays the easy control screen. |
|
|
|
(Page 8) |
[ |
]*1 |
|
Displays the folder/track list. |
|
|
|
(Page 12) |
[S] [T] |
Selects a track. |
||
[O] [N] |
Reverse/forward search.*2 |
||
[IW] |
|
Starts/pauses playback. |
|
[ |
] |
|
Displays other operation buttons. |
|
|
|
• Disabled when there are no other |
|
|
|
buttons. |
[MODE] |
Changes the settings for disc |
||
|
|
|
playback on the <DISC Mode> |
|
|
|
screen. (Page 14) |
[ |
] [ |
]*1 |
Selects a folder. |
[ |
] [ |
] |
Selects playback mode. (Page 13) |
[o] |
|
Stops playback. |
|
[MENU] |
Displays the <TOP MENU> screen. |
||
*1 |
Does not appear for CDs. |
||
*2 |
Search speed varies depending on the type of disc or file. |
||
ENGLISH 11
DISCS
Selecting a folder/track on the list
1
2Select the folder (1), then the item in the selected folder (2).
•Repeat the procedure until you select the desired track.
•You can change the page to display more items by pressing [J]/[K].
•Press [
] to open the folder containing the current track.
•Press [
] to return to the root folder.
•Press [
] to return to the upper layer.
Video menu operations
You can display the video menu screen during video playback.
•Available items on the screen differ depending on the types of the loaded disc and playback files.
•The operation buttons disappear when the screen is touched or when no operation is done for about 5 seconds.
*
*
[ZOOM]* |
Displays the picture size selecting |
|
screen. (Page 41) |
[Aspect] |
Selects the aspect ratio. |
|
(Page 41) |
[PictureAdjust] |
Displays the picture adjustment |
|
screen. (Page 40) |
[Audio]* |
Selects the audio type (or channel |
|
for DVD-VR). |
[Subtitle]* |
Selects the subtitle type. |
[Angle]* |
Selects the view angle. |
[MENU]* |
Displays the disc menu. |
[T MENU]* |
Displays the disc menu (DVD). |
[CUR]* |
Displays the menu/scene |
|
selecting screen. |
|
• [J] [K] [H] [I]: Selects an item. |
|
• [Enter]: Confirms the selection. |
|
• [Return]: Returns to the |
|
previous screen. |
[Highlight]* |
Switches to the direct disc menu |
|
mode. Touch the target item to |
|
select. |
•To restore the screen, press AV on the monitor panel.
* May not appear depending on the media/file etc.
12
DISCS
For VCD
1
2
[ZOOM] |
Displays the picture size selecting |
|
screen. (Page 41) |
[Aspect] |
Selects the aspect ratio. |
|
(Page 41) |
[PictureAdjust] |
Displays the picture adjustment |
|
screen. (Page 40) |
[Audio] |
Selects the audio channel (ST: |
|
stereo, LL: left, RR: right). |
[Return] |
Displays the previous screen or |
|
menu. |
[Direct] |
Displays/hides the direct selecting |
|
buttons. (See the right column.) |
•To select a track directly, press [Direct] to display the direct selecting buttons, then...
–When you enter a wrong number, press [CLR] to delete the last entry.
Selecting playback mode
[
] Selects Repeat playback mode.
[
] Selects Random playback mode.
•For DVD/DVD-VR: Repeat play is available.
For VCD (without PBC)/CD/DivX/MPEG1/MPEG2/ MP3/WMA/AAC: Repeat and Random play are available.
–You cannot activate the repeat mode and the random mode at the same time.
•Each time you press the button, the playback mode changes. (The corresponding indicator lights up.)
–Available items differ depending on the types of loaded disc and playback file.
C-REP |
Repeats current chapter. |
T-REP |
Repeats current title/program. |
REP |
Repeats current track. |
FO-REP |
Repeats all tracks of the |
|
current folder. |
FO-RDM |
Randomly plays all tracks of |
|
the current folder, then tracks |
|
of the next folders. |
RDM |
Randomly plays all tracks. |
To cancel Repeat/Random playback: Press the button repeatedly until the indicator disappears.
ENGLISH 13
DISCS
Settings for disc playback
•The items available on the <DISC Mode> screen are different depending on the discs/files played back.
Setting items
<Menu |
Select the initial disc menu language. |
Language>* |
(Initial: English) (Page 61) |
<Audio |
Select the initial audio language. |
Language>* |
(Initial: Original) (Page 61) |
<Subtitle |
Select the initial subtitle language |
Language>* |
or turn subtitles off (Off). (Initial: |
|
English) (Page 61) |
<Dynamic |
You can change the dynamic range |
Range |
while playing Dolby Digital software. |
Control>* |
• Wide: Select this to enjoy a |
|
powerful sound at a low volume |
|
level with its full dynamic range. |
|
• Normal: Select this to reduce the |
|
dynamic range a little. |
|
• Dialog (initial): Select this to |
|
reproduce movie dialog more |
|
clearly. |
<Angle |
Select whether to display the angle |
Mark> |
mark. |
|
• ON (initial): Select this to display |
|
the angle mark. |
|
• OFF: Select this to hide the angle |
|
mark. |
<Screen Select the monitor type to watch a Ratio>* wide screen picture on the external
monitor.
|
16:9 (Initial) |
4:3 LB |
4:3 PS |
<Parental |
Set the parental level. |
|
|
Level>* |
(See below.) |
|
|
<CD Read> Select the files to play back a disc containing music files. You cannot change the setting when a disc is inserted.
•1 (initial): Automatically distinguishes between audio file discs and music CDs.
•2: Forces to play as a music CD. No sound can be heard if an audio file disc is played.
* You can change these settings only while playback is stopped.
Setting the parental lock
The parental lock cannot be set during DVD playback.
1Display the <Parental Pass> screen.
On the <DISC Mode> screen:
•Press [K] repeatedly to change the page on the <DISC Mode> screen.
2Enter the 4-digit parental pass code (1), and press [Enter] (2).
•To clear the entry, press [Clear].
•To cancel setting the code, press [Cancel].
3Adjust the parental level (OFF, Level 1 to
Level 8).
To deactivate the parental lock: Select [OFF] for <Parental Level>.
14
USB
Connecting a USB device
You can connect a USB mass storage class device such as a USB memory, Digital Audio Player etc. to the unit.
•For details about connecting USB devices, see page 56.
•You cannot connect a computer or portable HDD to the USB input terminal.
•For playable file types and notes on using USB devices, see page 60.
When a USB device is connected...
The source changes to “USB” and playback starts.
•All tracks in the USB device will be played repeatedly until you change the source.
To disconnect the USB device safely:
Press [M], then disconnect the USB device after “No Device” appears.
Playback operations
When the operation buttons are not displayed on the screen, touch the area shown on the illustration.
•To change settings for video playback, see page 40.
Indications and buttons on the source control screen
1 2 3 4
56 7
Playback information
1Track/file information (for MP3/WMA/WAV/AAC/ FLAC)
• Pressing [<] scrolls the text if not all of the text
is shown.
2Current playback item information
•MPEG1/MPEG2/H.264/WMV: Folder no., Track no., etc.
•MP3/WMA/WAV/AAC/FLAC: Folder no., Track no., etc.
•JPEG/BMP/PNG: Folder no./File no. 3 Playback status
4 Playing time
5 Jacket picture (Shown while playing if the file has tag data that includes the jacket picture)
6 Playback mode (See the right column.)
7 File type
Operation buttons
[ |
] |
Displays the easy control screen. |
|
|
(Page 8) |
[ |
] |
Displays the list selection screen. |
|
|
(Page 16) |
[S] [T] Selects a track.
[O] [N] |
Reverse/forward search.*1 |
[IW] |
Starts/pauses playback. |
[ ] |
Displays other operation buttons. |
|
• Disabled when there are no other |
|
buttons. |
[MODE] |
Changes the picture display time |
|
|
|
setting on the <USB Mode> screen. |
|
|
(Page 16) |
[ |
] [ ] |
Selects a folder. |
[ |
] |
Selects repeat playback mode.*2 *3 |
|
|
• REP: Repeats the current track/file. |
|
|
• FO-REP: Repeats all tracks/files |
|
|
in the current folder or specified |
|
|
category. |
[ |
] |
Selects random playback mode.*2 *3 |
|
|
• RDM: |
|
|
– When selecting the track/file from |
|
|
the folder, randomly plays all |
|
|
tracks/files of the current folder, |
|
|
then the tracks/files of the next |
|
|
folder. |
|
|
– When selecting the track/file from |
|
|
the category, randomly plays |
|
|
all tracks/files of the specified |
|
|
category. |
[M] |
Disconnects the USB device safely. |
|
[MENU] |
Displays the <TOP MENU> screen. |
|
*1 |
Search speed varies depending on the file type. |
|
*2 |
To cancel random or repeat mode, press the button repeatedly until |
|
*3 |
the indicator disappears. |
|
You cannot activate the repeat mode and the random mode at the |
||
|
same time. |
|
ENGLISH 15
USB
Setting <Picture Display Time>
Set the interval between slides during slide-shows of the picture files.
•On the <Category List>/<Folder List>: You
can switch the file type to list: Press [
] to list audio files, [
] to list video files, or [
] to list still picture files.
•On the <Category List>/<Link Search>: To list the items in alphabetical order, press [A-Z], then select the first character.
From <Category List>:
Select the category (1), then the item in the selected category (2).
Selecting a track in a list
1
2 Select the list.
3Select the track.
•You can change the page to display more items by pressing [J]/[K].
•Press [
] to return to the root folder.
•Press [
] to return to the upper layer.
•Press [
] to open the folder containing the current track.
•If you want to play all tracks in the folder, press [I] on the right of the desired folder.
From <Link Search>:
Select the tag type to display the list of contents containing the same tag as the track/file currently played back (1), then the item (2).
From <Folder List>:
Select the folder (1), then the item in the selected folder (2).
iPod/iPhone
Preparation
Connecting iPod/iPhone
•For details about connecting iPod/iPhone, see page 56.
•For playable iPod/iPhone types, see page 61.
Connect your iPod/iPhone according to your purpose or the type of the iPod/iPhone.
Wired connection
•To listen to music:
–For iPod/iPhone except for iPhone 5/iPod touch (5th Generation)/iPod nano (7th Generation), use USB Audio cable for iPod/iPhone— KCA-iP102 (optional accessory)
–For iPhone 5/iPod touch (5th Generation)/ iPod nano (7th Generation), use USB 2.0 cable (accessory of the iPod/iPhone)
•To watch video and listen to music:
–For iPod/iPhone except for iPhone 5/iPod touch (5th Generation)/iPod nano (7th Generation), use USB Audio and Video cable for iPod/ iPhone—KCA-iP202 (optional accessory)
–For iPhone 5/iPod touch (5th Generation)/iPod nano (7th Generation), use the HDMI cable KCA-HD100 (optional accessory) and USB 2.0 cable (accessory of the iPod/iPhone) through Lightning-Digital AV adapter (accessory of the iPod/iPhone)
16
iPod/iPhone
Bluetooth connection
Pair the iPod/iPhone through Bluetooth. (Page 29)
•For iPhone 5/iPod touch (5th Generation)/iPod nano (7th Generation): To watch the video, connect your iPod/iPhone to HDMI/MHL input terminal using KCA-HD100 (optional accessory). (Page56)
•For iPod/iPhone except for iPhone 5/iPod touch (5th Generation)/iPod nano (7th Generation): You cannot watch the video with Bluetooth connection.
Selecting the iPod/iPhone device to play and connection method
When connecting the iPod/iPhone device for first time, the setup screen (for connection, etc.)
appears. Follow the procedure on the setup screen to configure the settings.
1Display the <iPod Settings> screen.
On the <TOP MENU> screen:
•If [Enter] for <iPod Setup> cannot be selected, put the unit in standby. (Page 7)
2
•If you do not need to change the setting, press [OK] to exit from the setup screen.
3Select the connection method (1), then press [Next] (2).
<USB + |
Select this when the iPod/ |
AV-IN> |
iPhone is connected using |
|
KCA-iP202 (optional accessory). |
<USB 1 Wire> Select this when the iPod/ |
|
|
iPhone is connected using |
|
KCA-iP102 or USB 2.0 cable |
|
(accessory of the iPod/iPhone). |
<HDMI + |
Select this when the iPod/ |
Bluetooth> |
iPhone is connected using |
|
HDMI cable KCA-HD100 |
|
(optional accessory) and USB |
|
2.0 cable (accessory of the iPod/ |
|
iPhone) through Lightning- |
|
Digital AV adapter (accessory of |
|
the iPod/iPhone). |
<Bluetooth> |
Select this when the iPod/ |
|
iPhone is connected via |
|
Bluetooth. |
•When selecting <USB + AV-IN> or <USB 1 Wire>, go to step 5.
4When selecting <HDMI + Bluetooth> or
<Bluetooth> as the connection method, the device selection screen appears. Search for the available iPod/iPhone devices (1), then select the target device from the list (2).
•You can change the page to display more items by pressing [J]/[K].
•If the device is already listed, skip the step 1.
•To stop searching, press [Cancel].
5 Confirm the settings.
ENGLISH 17
iPod/iPhone
Selecting preference settings for iPod/ iPhone playback
When the source is “iPod”...
1
2
<Audiobooks> |
Select the speed of audio |
|
books. |
<Wide |
• [ON]: Select this to display |
Screen>* |
the video compatible with |
|
wide-screen display in wide- |
|
screen. |
•[OFF]: Select this to deactivate.
* You cannot change the setting when iPod/iPhone is connected.
Playback operations
When the operation buttons are not displayed on the screen, touch the area shown on the illustration.
•To change settings for video playback, see page 40.
Indications and buttons on the source control screen
1 2 3 4
5
Playback information
1Song/video information
•Pressing [<] scrolls the text if not all of the text is shown.
2 Track no./Total track number
3 Playback status
4 Playing time
5 Artwork (Shown if the song contains artwork)
Operation buttons
[ |
] |
Displays the easy control screen. |
|
|
|
(Page 8) |
|
[ |
] |
Displays the audio/video file list. |
|
|
|
(Page 19) |
|
[S] [T] Selects an audio/video file. |
|||
[O] [N] |
Reverse/forward search. |
||
[IW] |
Starts/pauses playback. |
||
[ |
] |
Displays other operation buttons. |
|
|
|
• Disabled when there are no other |
|
|
|
|
buttons. |
[MODE] |
Changes the settings for iPod/iPhone |
||
|
|
playback on the <iPod Mode> |
|
|
|
screen. (See the far left column.) |
|
[ |
] |
Selects repeat playback mode. |
|
|
|
• |
1: Functions the same as |
|
|
|
“Repeat One.” |
|
|
• |
All: Functions the same as |
|
|
|
“Repeat All.” |
[ |
] |
Selects random playback mode.* |
|
|
|
• |
: Functions the same as “Shuffle |
|
|
• |
Songs.” |
|
|
Album: Functions the same as |
|
|
|
|
“Shuffle Albums.” |
[MENU] |
Displays the <TOP MENU> screen. |
||
*To cancel random mode, press the button repeatedly until the indicator disappears.
18
iPod/iPhone
Selecting an audio/video file from the menu
1
2Select the menu (
: audio or
: video) (1), a category (2), then a desired item (3).
•Select the item in the selected layer until the desired file starts playing.
•You can change the page to display more items by pressing [J]/[K].
•Press [All E] to play all songs/videos.
•Press [
] to return to the top layer.
•Press [
] to return to the upper layer.
Audio menu:
•Press [A-Z] to sort the list in alphabetical order.
Video menu:
•Available categories differ depending on the type of your iPod/iPhone.
APPs
You can use an App of the connected iPod touch/ iPhone/Android on this unit.
Preparation
1Connect the iPod touch/iPhone/Android.
•For wired connection, see page 56 for iPod touch/iPhone or page 57 for Android.
–To view the video, connect the device by using KCA-iP202 or KCA-HD100 (optional accessory).
•For Bluetooth connection, see page 31.
2Select the iPod touch/iPhone/Android device to use and connection method on the <APP Setup> screen. (Page 37)
[S] [T] Selects an audio/video file.
[O] [N] |
Reverse/forward search. |
[IW] |
Starts/pauses playback. |
[MENU] |
Displays the <TOP MENU> screen. |
For some applications such as navigation applications, the operating buttons and information are not shown. You can perform the operations on the touch panel, such as scrolling the map.
You can also play back the audio/video using iPod/ iPhone instead of the unit.
•When you are using Garmin StreetPilot® Onboard, the screen appears. For Garmin StreetPilot® Onboard for iPhone, visit the Garmin web site: www.garmin.com
When connecting the device for first time, the setup screen (for connection, etc.) appears. Follow the procedure on the setup screen to configure the settings.
Using an App
Playback operations
1Start the App on your iPod touch/iPhone/ Android.
2 Select “APPs” as the source. (Page 9)
Operation buttons on the source control screen
Garmin App:
•The current position of your vehicle appears on the map. When the vehicle moves, the map scrolls.
•The screens of the iPhone and unit are not the same.
Switching to the App screen while listening to another source
On the monitor panel:
ENGLISH 19
Pandora® (Only for DDX635WBT Region 4)
You can stream Pandora from iPod touch/iPhone, Android or BlackBerry devices.
•Install the latest version of the Pandora application on your iPod touch/iPhone/Android/ BlackBerry.
Preparation
Connect the device, then start the Pandora application.
For Android/BlackBerry
1Pair the Android/BlackBerry device through Bluetooth. (Page 29)
2Select the device to use and connection method on the <APP Setup> screen. (Page 37)
3Select “PANDORA” as the source.
On the <TOP MENU> screen:
The Pandora application is started.
For iPod touch/iPhone
1Connect the iPod touch/iPhone. (Page 16)
2Select the iPod touch/iPhone device to use and connection method on the <APP Setup> screen. (Page 37)
3Start the Pandora application on the connected iPod touch/iPhone.
The “PANDORA” source control screen is displayed.
•You can also display the “PANDORA” source control screen by connecting the iPod touch/ iPhone using KCA-iP202 or KCA-HD100 after starting the Pandora application.
Playback operations
You can operate Pandora using the remote controller. Only playing, pausing, and skipping are available.
Indications and buttons on the source control screen
1 2 3 4
Playback information
1 Picture data
2Track information
• Pressing [<] scrolls the text if not all of the text
is shown.
3 Playback status
4 Playing time
Operation buttons
[ |
] |
Displays the easy control screen. |
|
|
(Page 8) |
[ |
] |
Displays the list selecting screen. |
|
|
(Page 21) |
[ |
] |
Thumbs down to the current track |
|
|
and skips to the next track. |
[ |
] |
Registers the current track as a |
|
|
favorite. |
[IW] |
Starts/pauses playback. |
|
[T] |
Skips the current track. |
|
|
|
• Not available when the Pandora |
|
|
skip reaches its limit. |
[ ] |
Displays other operation buttons. |
•Disabled when there are no other buttons.
[ |
] |
Bookmarks the artist. |
|
[ |
] |
Bookmarks the current track. |
|
|
|||
[ |
] |
Adds the current artist to the Station |
|
|
|
List. |
|
[ |
] |
Adds the current track to the Station |
|
List. |
|||
|
|
20
Pandora®
Adding a station from the Genre List to the Station List
The screen shows the genres sent by the connected device. Select a genre and station to add to the Station List.
1 Display the list selecting screen.
2
3Select a genre (1), then a station (2).
•You can change the page to display more items by pressing [J]/[K].
The selected station is added to the Station List.
Selecting a station from the list
1Display the list selecting screen. (See above.)
2
3 Select a station from the list.
[Shuffle] Plays all the songs in the registered stations randomly.
[By Date] Sorts the list in reverse chronological order.
[By Name] Sorts the list in alphabetical order.
•The
indicator appears on the left of the item when Shuffle is activated. (All songs on the registered stations are played randomly.)
•The
indicator appears on the right of the item when the station is shared.
Requirements for Pandora®
iPhone or iPod touch
•Install the latest version of the Pandora application on your iPhone or iPod touch. (Search for “Pandora” in the Apple iTunes App Store to find and install the most current version.)
•Connect iPod touch/iPhone to this unit with cable or via Bluetooth.
–When connecting with cable: Use KCA-iP202, KCA-HD100, KCA-iP102 (optional accessory) or USB 2.0 cable (accessory of the iPod/iPhone).
–When connecting via Bluetooth, following profiles must be supported.
–SPP (Serial Port Profile)
–A2DP (Advanced Audio Distribution Profile)
Android™
•Visit Google play and search for Pandora to install.
•Bluetooth must be built in and the following profiles must be supported.
–SPP (Serial Port Profile)
–A2DP (Advanced Audio Distribution Profile)
BlackBerry®
•Visit www.pandora.com from the built in browser to download the Pandora application.
•Bluetooth must be built in and the following profiles must be supported.
–SPP (Serial Port Profile)
–A2DP (Advanced Audio Distribution Profile)
NOTE
•Ensure you are logged in to your smartphone application. If you do not have a Pandora account, you can create one for free from your smartphone or at www.pandora.com.
•Pandora is available only in the U.S./Australia/New Zealand.
•Because Pandora is a third-party service, the specifications are subject to change without prior notice. Accordingly, compatibility may be impaired or some or all of the services may become unavailable.
•Some functions of Pandora cannot be operated from this unit.
•For issues using the application, contact Pandora at pandora-support@pandora.com
•Establish an Internet connection using LTE, 3G, EDGE, or WiFi.
ENGLISH 21
Loading...
