/ Technical Information |
|
|
|
|
|
|
|
|
|
|
|
|
|
IGBT- |
FP75R12KT4 |
|
|
|
|
|
|
|
|
|
|
|
|
IGBT-modules |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EconoPIM™3 Modul mit Trench/Feldstopp IGBT4 und Emitter Controlled 4 Diode |
|
|
|
|
|
|
|
|
||||
|
EconoPIM™3 module with trench/fieldstop IGBT4 and Emitter Controlled 4 diode |
|
|
|
|
|
|||||||
|
IGBT, / IGBT,Inverter |
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
Preliminary Data |
|
|
||||||
|
/ Maximum Rated Values |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Tvj = 25°C |
|
|
|
VCES |
|
1200 |
|
V |
|||
|
Collector-emitter voltage |
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TC = 95°C, Tvj max = 175°C |
|
|
|
IC nom |
|
75 |
|
A |
|||
|
Continuous DC collector current |
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
tP = 1 ms |
|
|
|
ICRM |
|
150 |
|
A |
|||
|
Repetitive peak collector current |
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TC = 25°C, Tvj max = 175°C |
|
|
|
Ptot |
|
385 |
|
W |
|||
|
Total power dissipation |
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VGES |
|
+/-20 |
|
V |
|||
|
Gate-emitter peak voltage |
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
/ Characteristic Values |
|
|
|
|
|
|
min. |
typ. |
max. |
|
|
|
|
|
IC = 75 A, VGE = 15 V |
|
Tvj = 25°C |
|
|
|
1,85 |
2,25 |
|
V |
||
|
Collector-emitter saturation voltage |
IC = 75 A, VGE = 15 V |
|
Tvj = 125°C |
VCE sat |
|
|
2,15 |
|
|
V |
||
|
|
IC = 75 A, VGE = 15 V |
|
Tvj = 150°C |
|
|
|
2,25 |
|
|
V |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC = 2,40 mA, VCE = VGE, Tvj = 25°C |
|
|
VGEth |
|
5,2 |
5,8 |
6,4 |
|
V |
||
|
Gate threshold voltage |
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VGE = -15 V ... +15 V |
|
|
|
QG |
|
|
0,57 |
|
|
µC |
|
|
Gate charge |
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Tvj = 25°C |
|
|
|
RGint |
|
|
10 |
|
|
Ω |
|
|
Internal gate resistor |
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
f = 1 MHz, Tvj = 25°C, VCE = 25 V, VGE = 0 V |
|
|
Cies |
|
|
4,30 |
|
|
nF |
||
|
Input capacitance |
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
f = 1 MHz, Tvj = 25°C, VCE = 25 V, VGE = 0 V |
|
|
Cres |
|
|
0,16 |
|
|
nF |
||
|
Reverse transfer capacitance |
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
VCE = 1200 V, VGE = 0 V, Tvj = 25°C |
|
|
ICES |
|
|
|
1,0 |
|
mA |
||
|
Collector-emitter cut-off current |
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
- |
VCE = 0 V, VGE = 20 V, Tvj = 25°C |
|
|
|
IGES |
|
|
|
100 |
|
nA |
|
|
Gate-emitter leakage current |
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
( ) |
IC = 75 A, VCE = 600 V |
|
Tvj = 25°C |
td on |
|
|
0,16 |
|
|
µs |
||
|
Turn-on delay time, inductive load |
VGE = ±15 V |
|
Tvj = 125°C |
|
0,17 |
|
µs |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RGon = 1,1 Ω |
|
Tvj = 150°C |
|
|
|
0,17 |
|
|
µs |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
( ) |
IC = 75 A, VCE = 600 V |
|
Tvj = 25°C |
tr |
|
|
0,03 |
|
|
µs |
||
|
Rise time, inductive load |
VGE = ±15 V |
|
Tvj = 125°C |
|
|
0,04 |
|
|
µs |
|||
|
|
|
|
|
|||||||||
|
|
RGon = 1,1 Ω |
|
Tvj = 150°C |
|
|
|
0,04 |
|
|
µs |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
( ) |
IC = 75 A, VCE = 600 V |
|
Tvj = 25°C |
td off |
|
|
0,34 |
|
|
µs |
||
|
Turn-off delay time, inductive load |
VGE = ±15 V |
|
Tvj = 125°C |
|
0,43 |
|
µs |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RGoff = 1,1 Ω |
|
Tvj = 150°C |
|
|
|
0,45 |
|
|
µs |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
( ) |
IC = 75 A, VCE = 600 V |
|
Tvj = 25°C |
tf |
|
|
0,08 |
|
|
µs |
||
|
Fall time, inductive load |
VGE = ±15 V |
|
Tvj = 125°C |
|
|
0,15 |
|
|
µs |
|||
|
|
|
|
|
|||||||||
|
|
RGoff = 1,1 Ω |
|
Tvj = 150°C |
|
|
|
0,17 |
|
|
µs |
||
|
|
|
|
|
|
|
|
|
|
|
|
||
|
( ) |
IC = 75 A, VCE = 600 V, LS = 40 nH |
Tvj = 25°C |
|
|
|
3,10 |
|
|
mJ |
|||
|
Turn-on energy loss per pulse |
VGE = ±15 V, di/dt = 2500 A/µs (Tvj = 150°C) Tvj = 125°C |
Eon |
|
6,60 |
|
mJ |
||||||
|
|
RGon = 1,1 Ω |
|
Tvj = 150°C |
|
|
|
7,65 |
|
|
mJ |
||
|
|
|
|
|
|
|
|
|
|
|
|
||
|
( |
IC = 75 A, VCE = 600 V, LS = 40 nH |
Tvj = 25°C |
|
|
|
4,20 |
|
|
mJ |
|||
|
Turn-off energy loss per pulse |
VGE = ±15 V, du/dt = 3600 V/µs (Tvj = 150°C)Tvj = 125°C |
Eoff |
|
|
6,40 |
|
|
mJ |
||||
|
|
RGoff = 1,1 Ω |
|
Tvj = 150°C |
|
|
|
7,20 |
|
|
mJ |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VGE ≤ 15 V, VCC = 800 V |
|
|
|
ISC |
|
|
|
|
|
|
|
|
SC data |
VCEmax = VCES -LsCE ·di/dt |
tP ≤ 10 µs, Tvj = 150°C |
|
270 |
|
A |
|
|||||
|
|
|
|
|
|
||||||||
|
|
IGBT / per IGBT |
|
|
|
RthJC |
|
|
|
0,39 |
|
K/W |
|
|
Thermal resistance, junction to case |
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IGBT / per IGBT |
|
|
|
RthCH |
|
|
0,13 |
|
|
K/W |
|
|
Thermal resistance, case to heatsink |
λPaste = 1 W/(m·K) / λgrease = 1 W/(m·K) |
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
Tvj op |
|
-40 |
|
150 |
|
°C |
|
|
Temperature under switching conditions |
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
prepared by: AS |
date of publication: 2013-11-04 |
|
|
|
|
|
|
|
|
|
|
|
|
approved by: RS |
revision: 2.1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1
/ Technical Information
IGBT- |
FP75R12KT4 |
IGBT-modules |
Preliminary Data
, / Diode, Inverter
/ Maximum Rated Values
|
Tvj = 25°C |
VRRM |
|
1200 |
|
V |
|
Repetitive peak reverse voltage |
|||||||
|
|
|
|
|
|
||
|
|
IF |
|
75 |
|
A |
|
Continuous DC forward current |
|||||||
|
|
|
|
|
|
||
|
tP = 1 ms |
IFRM |
|
150 |
|
A |
|
Repetitive peak forward current |
|||||||
|
|
|
|
|
|
||
I2t- |
VR = 0 V, tP = 10 ms, Tvj = 125°C |
I²t |
|
960 |
|
A²s |
|
I²t - value |
|||||||
|
|
|
|
|
|
/ Characteristic Values |
|
|
|
min. |
typ. |
max. |
|
|
IF = 75 A, VGE = 0 V |
Tvj = 25°C |
|
|
1,70 |
2,15 |
V |
Forward voltage |
IF = 75 A, VGE = 0 V |
Tvj = 125°C |
VF |
|
1,65 |
|
V |
|
IF = 75 A, VGE = 0 V |
Tvj = 150°C |
|
|
1,65 |
|
V |
|
|
|
|
|
|
|
|
|
IF = 75 A, - diF/dt = 2500 A/µs (Tvj=150°C) |
Tvj = 25°C |
|
|
88,0 |
|
A |
Peak reverse recovery current |
VR = 600 V |
Tvj = 125°C |
IRM |
|
89,0 |
|
A |
|
VGE = -15 V |
Tvj = 150°C |
|
|
90,0 |
|
A |
|
|
|
|
|
|
|
|
|
IF = 75 A, - diF/dt = 2500 A/µs (Tvj=150°C) |
Tvj = 25°C |
|
|
7,30 |
|
µC |
Recovered charge |
VR = 600 V |
Tvj = 125°C |
Qr |
|
13,0 |
|
µC |
|
VGE = -15 V |
Tvj = 150°C |
|
|
14,5 |
|
µC |
|
|
|
|
|
|
|
|
|
IF = 75 A, - diF/dt = 2500 A/µs (Tvj=150°C) |
Tvj = 25°C |
|
|
2,65 |
|
mJ |
Reverse recovery energy |
VR = 600 V |
Tvj = 125°C |
Erec |
|
4,60 |
|
mJ |
|
VGE = -15 V |
Tvj = 150°C |
|
|
5,65 |
|
mJ |
|
|
|
|
|
|
|
|
|
/ per diode |
|
RthJC |
|
|
0,62 |
K/W |
Thermal resistance, junction to case |
|
||||||
|
|
|
|
|
|
|
|
|
/ per diode |
|
RthCH |
|
0,205 |
|
K/W |
Thermal resistance, case to heatsink |
λPaste = 1 W/(m·K) / λgrease = 1 W/(m·K) |
|
|
||||
|
|
|
|
|
|
||
|
|
|
Tvj op |
-40 |
|
150 |
°C |
Temperature under switching conditions |
|
||||||
|
|
|
|
|
|
|
, / Diode, Rectifier
/ Maximum Rated Values
|
Tvj = 25°C |
VRRM |
|
1600 |
|
V |
|
Repetitive peak reverse voltage |
|||||||
|
|
|
|
|
|
||
( ) |
TC = 80°C |
IFRMSM |
80 |
|
A |
||
Maximum RMS forward current per chip |
|||||||
|
|
|
|
|
|
||
|
TC = 80°C |
IRMSM |
|
140 |
|
A |
|
Maximum RMS current at rectifier output |
|||||||
|
|
|
|
|
|
||
|
tp = 10 ms, Tvj = 25°C |
IFSM |
|
600 |
|
A |
|
Surge forward current |
tp = 10 ms, Tvj = 150°C |
470 |
A |
||||
|
|
|
|||||
I2t- |
tp = 10 ms, Tvj = 25°C |
I²t |
|
1800 |
|
A²s |
|
I²t - value |
tp = 10 ms, Tvj = 150°C |
1100 |
A²s |
/ Characteristic Values |
|
|
|
min. |
typ. |
max. |
|
|
Tvj = 150°C, IF = 75 A |
|
VF |
|
1,15 |
|
V |
Forward voltage |
|
||||||
|
|
|
|
|
|
|
|
|
Tvj = 150°C, VR = 1600 V |
|
IR |
|
1,00 |
|
mA |
Reverse current |
|
||||||
|
|
|
|
|
|
|
|
|
/ per diode |
|
RthJC |
|
|
0,65 |
K/W |
Thermal resistance, junction to case |
|
||||||
|
|
|
|
|
|
|
|
|
/ per diode |
|
RthCH |
|
0,215 |
|
K/W |
Thermal resistance, case to heatsink |
λPaste = 1 W/(m·K) / λgrease = 1 W/(m·K) |
|
|
||||
|
|
|
|
|
|
||
|
|
|
Tvj op |
-40 |
|
150 |
°C |
Temperature under switching conditions |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
prepared by: AS |
date of publication: 2013-11-04 |
|
|
|
|
|
|
approved by: RS |
revision: 2.1 |
|
|
|
|
|
|
2
/ Technical Information
IGBT- |
FP75R12KT4 |
IGBT-modules |
Preliminary Data
IGBT, - / IGBT, Brake-Chopper
/ Maximum Rated Values
|
Tvj = 25°C |
VCES |
|
1200 |
|
V |
|
Collector-emitter voltage |
|||||||
|
|
|
|
|
|
||
|
TC = 95°C, Tvj max = 175°C |
IC nom |
|
50 |
|
A |
|
Continuous DC collector current |
|||||||
|
|
|
|
|
|
||
|
tP = 1 ms |
ICRM |
|
100 |
|
A |
|
Repetitive peak collector current |
|||||||
|
|
|
|
|
|
||
|
TC = 25°C, Tvj max = 175°C |
Ptot |
|
280 |
|
W |
|
Total power dissipation |
|||||||
|
|
|
|
|
|
||
|
|
VGES |
|
+/-20 |
|
V |
|
Gate-emitter peak voltage |
|||||||
|
|
|
|
|
|
/ Characteristic Values |
|
|
|
|
min. |
typ. |
max. |
|
|
|
IC = 50 A, VGE = 15 V |
|
Tvj = 25°C |
|
|
1,85 |
2,25 |
V |
|
Collector-emitter saturation voltage |
IC = 50 A, VGE = 15 V |
|
Tvj = 125°C |
VCE sat |
|
2,15 |
|
V |
|
|
IC = 50 A, VGE = 15 V |
|
Tvj = 150°C |
|
|
2,25 |
|
V |
|
|
|
|
|
|
|
|
|
|
|
|
IC = 1,60 mA, VCE = VGE, Tvj = 25°C |
|
VGEth |
5,2 |
5,8 |
6,4 |
V |
||
Gate threshold voltage |
|
||||||||
|
|
|
|
|
|
|
|
||
|
VGE = -15 V ... +15 V |
|
|
QG |
|
0,38 |
|
µC |
|
Gate charge |
|
|
|||||||
|
|
|
|
|
|
|
|
||
|
Tvj = 25°C |
|
|
RGint |
|
4,0 |
|
Ω |
|
Internal gate resistor |
|
|
|||||||
|
|
|
|
|
|
|
|
||
|
f = 1 MHz, Tvj = 25°C, VCE = 25 V, VGE = 0 V |
|
Cies |
|
2,80 |
|
nF |
||
Input capacitance |
|
||||||||
|
|
|
|
|
|
|
|
||
|
f = 1 MHz, Tvj = 25°C, VCE = 25 V, VGE = 0 V |
|
Cres |
|
0,10 |
|
nF |
||
Reverse transfer capacitance |
|
||||||||
|
|
|
|
|
|
|
|
||
- |
VCE = 1200 V, VGE = 0 V, Tvj = 25°C |
|
ICES |
|
|
1,0 |
mA |
||
Collector-emitter cut-off current |
|
||||||||
|
|
|
|
|
|
|
|
||
- |
VCE = 0 V, VGE = 20 V, Tvj = 25°C |
|
|
IGES |
|
|
100 |
nA |
|
Gate-emitter leakage current |
|
|
|||||||
|
|
|
|
|
|
|
|
||
( ) |
IC = 50 A, VCE = 600 V |
|
Tvj = 25°C |
td on |
|
0,16 |
|
µs |
|
Turn-on delay time, inductive load |
VGE = ±15 V |
|
Tvj = 125°C |
0,17 |
µs |
||||
|
|
|
|
|
|
|
|
||
|
RGon = 15 Ω |
|
Tvj = 150°C |
|
|
0,17 |
|
µs |
|
|
|
|
|
|
|
|
|
|
|
( ) |
IC = 50 A, VCE = 600 V |
|
Tvj = 25°C |
tr |
|
0,03 |
|
µs |
|
Rise time, inductive load |
VGE = ±15 V |
|
Tvj = 125°C |
|
0,04 |
|
µs |
||
|
|
||||||||
|
RGon = 15 Ω |
|
Tvj = 150°C |
|
|
0,04 |
|
µs |
|
|
|
|
|
|
|
|
|
|
|
( ) |
IC = 50 A, VCE = 600 V |
|
Tvj = 25°C |
td off |
|
0,33 |
|
µs |
|
Turn-off delay time, inductive load |
VGE = ±15 V |
|
Tvj = 125°C |
0,43 |
µs |
||||
|
|
|
|
|
|
|
|
||
|
RGoff = 15 Ω |
|
Tvj = 150°C |
|
|
0,45 |
|
µs |
|
|
|
|
|
|
|
|
|
|
|
( ) |
IC = 50 A, VCE = 600 V |
|
Tvj = 25°C |
tf |
|
0,08 |
|
µs |
|
Fall time, inductive load |
VGE = ±15 V |
|
Tvj = 125°C |
|
0,15 |
|
µs |
||
|
|
||||||||
|
RGoff = 15 Ω |
|
Tvj = 150°C |
|
|
0,17 |
|
µs |
|
|
|
|
|
|
|
|
|
||
( ) |
IC = 50 A, VCE = 600 V, LS = 40 nH |
Tvj = 25°C |
|
|
5,70 |
|
mJ |
||
Turn-on energy loss per pulse |
VGE = ±15 V |
|
Tvj = 125°C |
Eon |
|
7,70 |
|
mJ |
|
|
RGon = 15 Ω |
|
Tvj = 150°C |
|
|
8,40 |
|
mJ |
|
|
|
|
|
|
|
|
|
||
( |
IC = 50 A, VCE = 600 V, LS = 40 nH |
Tvj = 25°C |
|
|
2,80 |
|
mJ |
||
Turn-off energy loss per pulse |
VGE = ±15 V |
|
Tvj = 125°C |
Eoff |
|
4,30 |
|
mJ |
|
|
RGoff = 15 Ω |
|
Tvj = 150°C |
|
|
4,80 |
|
mJ |
|
|
|
|
|
|
|
|
|
|
|
|
VGE ≤ 15 V, VCC = 800 V |
|
|
ISC |
|
|
|
|
|
SC data |
VCEmax = VCES -LsCE ·di/dt |
tP ≤ 10 µs, Tvj = 125°C |
180 |
A |
|||||
|
|
|
|||||||
|
IGBT / per IGBT |
|
|
RthJC |
|
|
0,54 |
K/W |
|
Thermal resistance, junction to case |
|
|
|||||||
|
|
|
|
|
|
|
|
||
|
IGBT / per IGBT |
|
|
RthCH |
|
0,245 |
|
K/W |
|
Thermal resistance, case to heatsink |
λPaste = 1 W/(m·K) / λgrease = 1 W/(m·K) |
|
|
||||||
|
|
|
|
|
|
||||
|
|
|
|
Tvj op |
-40 |
|
150 |
°C |
|
Temperature under switching conditions |
|
|
|||||||
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
prepared by: AS |
date of publication: 2013-11-04 |
|
|
|
|
|
|
|
|
approved by: RS |
revision: 2.1 |
|
|
|
|
|
|
|
3
/ Technical Information
IGBT- |
FP75R12KT4 |
IGBT-modules |
Preliminary Data
- / Diode, Brake-Chopper
/ Maximum Rated Values
|
Tvj = 25°C |
VRRM |
|
1200 |
|
V |
|
Repetitive peak reverse voltage |
|||||||
|
|
|
|
|
|
||
|
|
IF |
|
25 |
|
A |
|
Continuous DC forward current |
|||||||
|
|
|
|
|
|
||
|
tP = 1 ms |
IFRM |
|
50 |
|
A |
|
Repetitive peak forward current |
|||||||
|
|
|
|
|
|
||
I2t- |
VR = 0 V, tP = 10 ms, Tvj = 125°C |
I²t |
|
90,0 |
|
A²s |
|
I²t - value |
VR = 0 V, tP = 10 ms, Tvj = 150°C |
80,0 |
A²s |
/ Characteristic Values |
|
|
|
min. |
typ. |
max. |
|
|
IF = 25 A, VGE = 0 V |
Tvj = 25°C |
|
|
1,75 |
2,25 |
V |
Forward voltage |
IF = 25 A, VGE = 0 V |
Tvj = 125°C |
VF |
|
1,75 |
|
V |
|
IF = 25 A, VGE = 0 V |
Tvj = 150°C |
|
|
1,75 |
|
V |
|
|
|
|
|
|
|
|
|
IF = 25 A, - diF/dt = 1200 A/µs (Tvj=150°C) |
Tvj = 25°C |
|
|
39,0 |
|
A |
Peak reverse recovery current |
VR = 600 V |
Tvj = 125°C |
IRM |
|
40,0 |
|
A |
|
|
Tvj = 150°C |
|
|
41,0 |
|
A |
|
|
|
|
|
|
|
|
|
IF = 25 A, - diF/dt = 1200 A/µs (Tvj=150°C) |
Tvj = 25°C |
|
|
2,40 |
|
µC |
Recovered charge |
VR = 600 V |
Tvj = 125°C |
Qr |
|
4,10 |
|
µC |
|
|
Tvj = 150°C |
|
|
4,40 |
|
µC |
|
|
|
|
|
|
|
|
|
IF = 25 A, - diF/dt = 1200 A/µs (Tvj=150°C) |
Tvj = 25°C |
|
|
0,90 |
|
mJ |
Reverse recovery energy |
VR = 600 V |
Tvj = 125°C |
Erec |
|
1,50 |
|
mJ |
|
|
Tvj = 150°C |
|
|
1,70 |
|
mJ |
|
|
|
|
|
|
|
|
|
/ per diode |
|
RthJC |
|
|
1,35 |
K/W |
Thermal resistance, junction to case |
|
||||||
|
|
|
|
|
|
|
|
|
/ per diode |
|
RthCH |
|
0,61 |
|
K/W |
Thermal resistance, case to heatsink |
λPaste = 1 W/(m·K) / λgrease = 1 W/(m·K) |
|
|
||||
|
|
|
|
|
|
||
|
|
|
Tvj op |
-40 |
|
150 |
°C |
Temperature under switching conditions |
|
||||||
|
|
|
|
|
|
|
/ NTC-Thermistor
/ Characteristic Values |
|
|
|
min. |
typ. |
max. |
|
|
|
TC |
= 25°C |
R25 |
|
5,00 |
|
kΩ |
|
Rated resistance |
||||||||
|
|
|
|
|
|
|
||
R100 |
TC |
= 100°C, R100 = 493 Ω |
R/R |
-5 |
|
5 |
% |
|
Deviation of R100 |
||||||||
|
|
|
|
|
|
|
||
|
TC |
= 25°C |
P25 |
|
|
20,0 |
mW |
|
Power dissipation |
||||||||
|
|
|
|
|
|
|
||
B- |
R2 |
= R25 exp [B25/50(1/T2 - 1/(298,15 K))] |
B25/50 |
|
3375 |
|
K |
|
B-value |
||||||||
|
|
|
|
|
|
|
||
B- |
R2 |
= R25 exp [B25/80(1/T2 - 1/(298,15 K))] |
B25/80 |
|
3411 |
|
K |
|
B-value |
||||||||
|
|
|
|
|
|
|
||
B- |
R2 |
= R25 exp [B25/100(1/T2 - 1/(298,15 K))] |
B25/100 |
|
3433 |
|
K |
|
B-value |
||||||||
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
Specification according to the valid application note. |
|
|
|
|
|
prepared by: AS |
date of publication: 2013-11-04 |
approved by: RS |
revision: 2.1 |
4
