OBJ_BUCH-1289-003.book Page 1 Wednesday, June 22, 2016 1:17 PM
Robert Bosch Power Tools GmbH
70538 Stuttgart
Germany
GSC 10,8 V-LI Professional
www.bosch-pt.com
1 609 92A 1TF (2012.12) PS / 36
en Original instructions cn tw
ko
th id Petunjuk-Petunjuk untuk
Penggunaan Orisinal
vi Bảng hướng dẫn nguyên bản
OBJ_BUCH-1289-003.book Page 2 Wednesday, June 22, 2016 1:14 PM
2 |
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4
. . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . |
17 |
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Bahasa Indonesia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Halaman 26
Tiếng Việt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Trang 31
|
1 609 92A 1TF | (22.6.16) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 3 Wednesday, June 22, 2016 1:14 PM
| 3
A
|
Bosch Power Tools |
|
|
1 609 92A 1TF | (22.6.16) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 4 Wednesday, June 22, 2016 1:14 PM
4 | English
English
Safety Notes
General Power Tool Safety Warnings
WARNING |
Read all safety warnings and all in- |
|
structions. Failure to follow the warnings |
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mainsoperated (corded) power tool or battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges and moving parts. Damaged or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed.
Use of the power tool for operations different from those intended could result in a hazardous situation.
Battery tool use and care
Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
|
1 609 92A 1TF | (22.6.16) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 5 Wednesday, June 22, 2016 1:14 PM
Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
Service
Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
Safety Warnings for Cordless Sheet Metal Shears
Secure the workpiece. A workpiece clamped with clamping devices or in a vice is held more secure than by hand.
Always wait until the machine has come to a complete stop before placing it down. The tool insert can jam and lead to loss of control over the power tool.
Do not open the battery. Danger of short-circuiting.
Protect the battery against heat, e. g., against continuous intense sunlight, fire, water, and moisture. Danger of explosion.
In case of damage and improper use of the battery, vapours may be emitted. Ventilate the area and seek medical help in case of complaints. The vapours can irritate the respiratory system.
Use the battery only in conjunction with your Bosch power tool. This measure alone protects the battery against dangerous overload.
Use only original Bosch batteries with the voltage listed on the nameplate of your power tool. When using other batteries, e. g. imitations, reconditioned batteries or other brands, there is danger of injury as well as property damage through exploding batteries.
Product Description and Specifications
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
While reading the operating instructions, unfold the graphics page for the machine and leave it open.
Intended Use
The power tool is intended for cutting sheet metals without loss due to metal chips. It is suitable for curved and straight cuts.
English | 5
Product Features
The numbering of the product features refers to the illustration of the machine on the graphics page.
1 Battery unlocking button
2 Battery pack
3 Button for charge-control indicator
4 Battery charge-control indicator
5 On/Off switch
6 Chip deflector
7 Handle (insulated gripping surface)
8 Allen key
9 Fastening screw for upper cutter
10Upper cutter
11Bottom cutter
12Adjustment screw, bottom cutter
13Fastening screw for bottom cutter
14Setting gauge *
*Accessories shown or described are not part of the standard delivery scope of the product. A complete overview of accessories can be found in our accessories program.
Technical Data
Cordless Sheet Metal |
|
GSC 10,8 V-LI |
Shears |
|
|
Article number |
|
3 601 J26 1.. |
Rated voltage |
V= |
10.8 |
Stroke rate at no load n |
min-1 |
3 600 |
0 |
|
|
Max. steel sheet cutting |
|
|
capacity* |
mm |
1.3 |
Smallest curve radius |
mm |
15 |
Weight according to EPTA- |
|
|
Procedure 01:2014 |
kg |
1.4 - 1.6 |
* to 400 N/mm2 with reference to steel sheet
Assembly
Battery Charging
Use only the battery chargers listed on the graphics page. Only these battery chargers are matched to the lithium ion battery used in your machine.
Note: The battery is supplied partially charged. To ensure full capacity of the battery, completely charge the battery in the battery charger before using your power tool for the first time.
The Lithium-Ion battery can be charged at any time without reducing its service life. Interrupting the charging procedure does not damage the battery.
The battery is equipped with a NTC temperature control which allows charging only within a temperature range of between 0 °C and 45 °C. A long battery service life is achieved in this manner.
Battery Charge-control Indication
The three green LEDs of the battery charge-control indicator 4 indicate the charge condition of the battery 2. For safety
|
Bosch Power Tools |
|
|
1 609 92A 1TF | (22.6.16) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 6 Wednesday, June 22, 2016 1:14 PM
6 | English
reasons, it is only possible to check the status of the charge condition when the machine is at a standstill.
–To indicate the charge condition, press and hold button 3 of the switched off machine.
LED |
Capacity |
Continuous lighting 3 x green |
≥2/3 |
Continuous lighting 2 x green |
≥1/3 |
Continuous lighting 1 x green |
< 1/3 |
Flashing light 1 x green |
Reserve |
Removing the battery
–To remove the battery 2, press the unlocking buttons 1 and pull the battery out of the machine to the rear. Do not exert any force.
Operation
Starting Operation
Inserting the battery
Use only original Bosch lithium ion batteries with the voltage listed on the nameplate of your power tool. Using other batteries can lead to injuries and pose a fire hazard.
Note: Use of batteries not suitable for the machine can lead to malfunctions of or cause damage to the power tool.
–Insert the charged battery 2 into the handle until it can be felt to engage and faces flush against the handle.
Switching On and Off
–To start the machine, push the On/Off switch 5 forward so that the “I” is indicated on the switch.
–To switch off the machine, push the On/Off switch 5 toward the rear so that the “0” is indicated on the switch. To save energy, only switch the power tool on when using it.
The Lithium-Ion battery is protected against deep discharging by the “Electronic Cell Protection (ECP)”. When the battery is empty, the machine is switched off by means of a protective circuit: The inserted tool no longer rotates.
Note: If the machine should automatically switch off because of a discharged or overheated battery, make sure to set the machine’s On/Off switch 5 to off. Charge the battery and allow it to cool down before restarting the machine. Otherwise the battery can become damaged.
Working Advice
The power tool is not suitable for stationary operation.
For example, it may not be clamped in a vice or fastened on a workbench.
Only work with the chip deflector 6 mounted. Take care that the chip deflector is not damaged or bent. Danger of injury when working without the chip deflector or when it is damaged. Have a damaged chip deflector replaced immediately by an after-sales service centre for Bosch power tools.
Wear protective gloves while working. Take care that cut sheet parts do not bend toward your body. Sharp
burrs develop at the cut steel sheet and can cause injuries to the operator. If required, press bending steel sheet parts away from your body using gloves.
–Apply the power tool to the workpiece only when switched on.
–Guide the power tool at an angle of 80 to 90 ° to the surface of the sheet metal and do not tilt it to the side.
80–90˚ |
–Guide the machine evenly and with light feed in the cutting direction. Excessive feed significantly reduces the service life of the saw blade and can cause damage to the power tool.
–When cutting curves, make sure not to tilt the power tool laterally and work with low feed rate only.
Maximum Steel Sheet Cutting Capacity
The maximum steel sheet cutting capacity dmax depends on the strength properties of the material to be cut.
The machine allows for cutting of metal sheet to the following thicknesses:
Material |
Max. strength proper- |
dmax |
|
ty |
[mm] |
|
[N/mm2] |
|
Steel |
400 |
1.3 |
|
600 |
0.8 |
|
800 |
0.6 |
Aluminium |
250 |
2.0 |
Adjusting Cutter Clearance a
Before any work on the machine itself (e. g. maintenance, tool change, etc.) as well as during transport and storage, remove the battery from the power tool.
There is danger of injury when unintentionally actuating the On/Off switch.
|
The cutter clearance a (gap between the |
|
cutters) depends on the sheet thickness |
|
dmax to be cut. |
|
The cutter clearance a should be 10 % of |
|
the sheet thickness dmax (e. g. 0.1 mm cut- |
|
ter clearance for 1 mm sheet thickness). |
a |
For softer or more ductile materials, the |
clearance a must be decreased; for harder |
|
|
or more brittle materials, increased. |
–Loosen the fastening screw 13 for the bottom cutter. Adjust the required cutter clearance a with the adjustment screw 12. The upper cutter 10 and the bottom cutter 11 may not touch each other. Check the clearance with the
|
1 609 92A 1TF | (22.6.16) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 7 Wednesday, June 22, 2016 1:14 PM
setting gauge 14. Retighten the fastening screw 13 for the bottom cutter with a tightening torque of 3 – 4 Nm.
Temperature Dependent Overload Protection
When using the machine as intended for, it cannot be subject to overload. In case of excessive load or when not within the permitted battery temperature range of 0 – 70 °C, the stroke rate is reduced or the machine switches off. With reduced stroke rate, the machine will not run at full stroke rate again until after reaching the permitted battery temperature. In case of automatic shut-off, switch the machine off, allow the battery to cool down and then switch the machine on again.
Recommendations for Optimal Handling of the Battery
Protect the battery against moisture and water.
Store the battery only within a temperature range between 0 °C and 50 °C. As an example, do not leave the battery in the car in summer.
A significantly reduced working period after charging indicates that the battery is used and must be replaced.
Observe the notes for disposal.
Maintenance and Service
Maintenance and Cleaning
Before any work on the machine itself (e. g. maintenance, tool change, etc.) as well as during transport and storage, remove the battery from the power tool.
There is danger of injury when unintentionally actuating the On/Off switch.
For safe and proper working, always keep the machine and ventilation slots clean.
If the machine should fail despite the care taken in manufacturing and testing procedures, repair should be carried out by an after-sales service centre for Bosch power tools.
In all correspondence and spare parts order, please always include the 10-digit article number given on the type plate of the machine.
Replace the blade (see figure A)
The upper cutter 10 and the bottom cutter 11 are identical, have four cutting edges each, and can be exchanged with each other.
Turn or replace the cutters in good time. Only sharp application tools achieve good cutting capacity and make the machine last longer.
–To replace the upper cutter 10, loosen the fastening screw 9; to replace the bottom cutter 11, loosen the fastening screw 13.
–Turn the cutter by 90 ° or install a new cutter. When installing the bottom cutter 11, pay attention that it faces against the adjustment screw 12.
Note: Turn the cutter only in the direction indicated in the figure and insert a new cutter only in the position shown in the figure. Cutting is not possible with an incorrectly inserted cutter.
–Retighten the fastening screw 9 for the upper cutter and the fastening screw 13 for the bottom cutter with a tighten-
English | 7
ing torque of 3 – 4 Nm. Check the cutter clearance a (see “Adjusting Cutter Clearance a”, page 6).
Upper cutter 10 and bottom cutter 11 may not be reground.
After-sales Service and Application Service
Our after-sales service responds to your questions concerning maintenance and repair of your product as well as spare parts. Exploded views and information on spare parts can also be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions concerning our products and their accessories.
People’s Republic of China China Mainland
Bosch Power Tools (China) Co., Ltd. 567, Bin Kang Road
Bin Jiang District 310052 Hangzhou, P. R. China
Service Hotline: 4008268484 Fax: (0571) 87774502
E-Mail: contact.ptcn@cn.bosch.com www.bosch-pt.com.cn
HK and Macau Special Administrative Regions
Robert Bosch Hong Kong Co. Ltd. 21st Floor, 625 King’s Road North Point, Hong Kong
Customer Service Hotline: +852 2101 0235 Fax: +852 2590 9762
E-Mail: info@hk.bosch.com www.bosch-pt.com.hk
Indonesia
PT. Multi Mayaka
Kawasan Industri Pulogadung
Jalan Rawa Gelam III No. 2
Jakarta 13930
Indonesia
Tel.: (021) 46832522
Fax: (021) 46828645 /6823
E-Mail: sales@multimayaka.co.id
www.bosch-pt.co.id
Philippines
Robert Bosch, Inc.
28th Floor Fort Legend Towers, 3rd Avenue corner 31st Street, Fort Bonifacio Global City, 1634 Taguig City, Philippines Tel.: (02) 8703871
Fax: (02) 8703870 matheus.contiero@ph.bosch.com www.bosch-pt.com.ph
Bosch Service Center: 9725-27 Kamagong Street San Antonio Village
Makati City, Philippines Tel.: (02) 8999091 Fax: (02) 8976432
rosalie.dagdagan@ph.bosch.com
|
Bosch Power Tools |
|
|
1 609 92A 1TF | (22.6.16) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 8 Wednesday, June 22, 2016 1:14 PM
8 | English
Malaysia
Robert Bosch (S.E.A.) Sdn. Bhd. No. 8A, Jalan 13/6
G.P.O. Box 10818 46200 Petaling Jaya Selangor, Malaysia Tel.: (03) 79663194 Fax: (03) 79583838
cheehoe.on@my.bosch.com Toll-Free: 1800 880188 www.bosch-pt.com.my
Thailand
Robert Bosch Ltd. Liberty Square Building No. 287, 11 Floor Silom Road, Bangrak Bangkok 10500
Tel.: 02 6311879 – 18 88 (10 lines) Fax: 02 2384783
Robert Bosch Ltd., P. O. Box 2054 Bangkok 10501, Thailand
Bosch Service – Training Centre 2869-2869/1 Soi Ban Kluay
Rama IV Road (near old Paknam Railway) Prakanong District
10110 Bangkok Thailand
Tel.: 02 67178 00 – 4 Fax: 02 2494296 Fax: 02 2495299
Singapore
Robert Bosch (SEA) Pte. Ltd. 11 Bishan Street 21 Singapore 573943
Tel.: 6571 2772
Fax: 6350 5315 leongheng.leow@sg.bosch.com Toll-Free: 1800 3338333 www.bosch-pt.com.sg
Vietnam
Robert Bosch Vietnam Co. Ltd 10/F, 194 Golden Building 473 Dien Bien Phu Street Ward 25, Binh Thanh District 84 Ho Chi Minh City
Vietnam
Tel.: (08) 6258 3690 ext. 413 Fax: (08) 6258 3692 hieu.lagia@vn.bosch.com www.bosch-pt.com
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch.com.au
Transport
The contained lithium-ion batteries are subject to the Dangerous Goods Legislation requirements. The user can transport the batteries by road without further requirements.
When being transported by third parties (e.g.: air transport or forwarding agency), special requirements on packaging and labelling must be observed. For preparation of the item being shipped, consulting an expert for hazardous material is required.
Dispatch batteries only when the housing is undamaged. Tape or mask off open contacts and pack up the battery in such a manner that it cannot move around in the packaging. Please also observe possibly more detailed national regulations.
Disposal
The machine, rechargeable batteries, accessories
and packaging should be sorted for environmentalfriendly recycling.
Do not dispose of power tools and batteries/rechargeable batteries into household waste!
Batteries no longer suitable for use can be directly returned at:
Great Britain
Robert Bosch Ltd. (B.S.C.) P.O. Box 98
Broadwater Park North Orbital Road Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 7360109 Fax: (0844) 7360146
E-Mail: boschservicecentre@bosch.com
Battery packs/batteries:
Li-ion:
Please observe the instructions in section “Transport”, page 8.
Subject to change without notice.
|
1 609 92A 1TF | (22.6.16) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 9 Wednesday, June 22, 2016 1:14 PM
| 9
|
|
|||
|
|
|
||
|
|
! |
|
|
|
|
|||
|
|
|
|
|
|
|
|||
|
|
|||
" " |
|
|||
|
||||
|
||||
|
||||
|
|
|||
|
||||
|
|
|||
|
||||
|
|
|||
|
|
|||
|
||||
|
||||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|
||
中会使操作者失去对工具的控制。
|
|
如果你身体接地会增加电击危险。
电动工具将增加电击危险。
是危险的。
事故由维护不良的电动工具引发。
接软线。
使用剩余电流动作保护器RCD RCD
那些与其用途不符的操作可能会导致危险。
盒的充电器用到其他电池盒时会发生着火危险。
瞬间的疏忽会导致严重人身伤害。
诸如适当条件下使用防尘面具、防滑安全鞋、安全 帽、听力防护等装置能减少人身伤害。
/
燃烧或火灾。
生腐蚀或燃烧。
|
Bosch Power Tools |
|
|
1 609 92A 1TF | (22.6.16) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 10 Wednesday, June 22, 2016 1:14 PM
10 |
性。
比用手持握工件更牢固。
工具。
池散发的蒸汽会刺激呼吸道。
才能确保蓄电池不会过载。
有受伤的危险以及因为蓄电池爆炸而造成的财物损 失。
火灾并且/
以切剪曲线和直线。
1
2
3
4
5
6
7
8
9
10
14*
*
|
|
GSC 10,8 V-LI |
|
|
3 601 J26 1.. |
|
|
|
|
= |
10,8 |
|
|
|
n0 |
/ |
3600 |
* |
|
1,3 |
|
|
|
|
|
15 |
EPTA-Procedure |
|
1.4 - 1.6 |
01:2014 |
|
* 400 /
才能够为您的电动工具所使用的锂离子蓄电池充 电。
功率。
NTC-0 45
4 2
–3
LED |
|
|
3 |
|
≥2/3 |
|
|
|
2 |
|
≥1/3 |
|
|
|
1 |
|
<1/3 |
|
|
|
1 |
|
|
|
|
|
–2 1
|
1 609 92A 1TF | (22.6.16) |
|
|
Bosch Power Tools |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OBJ_BUCH-1289-003.book Page 11 Wednesday, June 22, 2016 1:14 PM
|
|
|
| 11 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
80–90˚ |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
– |
|||
– 2 |
||||
|
||||
|
||||
|
||||
|
||||
/ |
– |
|||
– 5 |
|
|
||
"I" |
|
|
||
– 5 |
|
|||
dmax |
||||
"0" |
||||
|
|
|
||
|
|
|
||
|
|
|
||
" |
|
|||
|
|
|
||
(ECP)" |
|
|
dmax |
|
|
|
[ / ] |
[ ] |
|
|
|
|||
|
400 |
1,3 |
||
|
||||
|
|
600 |
0,8 |
|
5 |
|
800 |
0,6 |
|
|
|
250 |
2,0 |
|
|
||||
a |
|
|||
|
|
|||
|
|
|||
6
, ,,,
– 角最好保持在80 90
|
|
|
|
a |
|
|
|
|
|
dmax |
|
|
a |
|
|
dmax 10 % |
|
|
1 |
|
a |
0,1 |
|
|
||
|
||
|
a |
|
|
|
–13 12a 10 111413 3–4
受载的状况下或蓄电池的温度在许可温度范围 （0–70 °C
|
Bosch Power Tools |
|
|
1 609 92A 1TF | (22.6.16) |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Loading...
