Plasma TV

user manual

E-MANUAL

Thank you for purchasing this Samsung product. To receive more complete service, please register your product at

www.samsung.com/register

Model______________ Serial No.______________

2013-02-07 3:23:45

Warning! Important Safety Instructions

(Please read the safety instructions below before installing and using the product.)

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPEN.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product.

This symbol indicates that important literature concerning operation and maintenance has been included with this product.

•The slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation. To ensure reliable operation of this apparatus, and to protect it from overheating, these slots and openings must never be blocked or covered.

-Do not cover the slots and openings with a cloth or other materials.

-Do not block the slots and openings by placing this apparatus on a bed, sofa, rug or other similar surface.

-Do not place this apparatus in a confined space, such as a bookcase or built-in cabinet, unless proper ventilation is provided.

•Do not place this apparatus near or over a radiator or heat register, or where it is exposed to direct sunlight.

•Do not place a vessel containing water (vases etc.) on this apparatus, as this can result in a risk of fire or electric shock.

•Do not expose this apparatus to rain or place it near water (near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool etc.). If this appratus accidentally gets wet, unplug it and contact an authorized dealer immediately.

•Make sure to pull out the power cord from the outlet before cleaning.

•This apparatus use batteries. In your community, there might be regulations that require you to dispose of these batteries properly to protect the environment. Please contact your local authorities for disposal or recycling information.

•Do not overload wall outlets, extension cords, or adaptors beyond their capacity, since this can result in fire or electric shock.

•Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords at the plug end, where connected to adaptors, and at the point where they exit from the apparatus.

•To protect this apparatus from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the set due to lightning and power line surges.

•Before connecting the AC power cord to the DC adaptor outlet, make sure the voltage designation of the DC adaptor corresponds to the local electrical supply. (depending on the model)

•Never insert anything metallic into the open parts of this apparatus. Doing so may create a danger of electric shock.

•To avoid electric shock, never touch the inside of this apparatus. Only a qualified technician should open this apparatus.

•Make sure to plug the power cord in until it is firmly inserted. Pull on the plug, not the cord, when removing the power cord from the outlet. Do not touch the power cord with wet hands.

•If this appratus does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately and contact an authorized dealer or service center.

•Be sure to pull the power plug out of the outlet if the TV is to remain unused or if you are to leave the house for an extended period of time (especially when children, elderly or disabled people will be left alone in the house).

-Accumulated dust can cause an electric shock, an electric leakage, or a fire by causing the power cord to generate sparks and heat, or cause the insulation to deteriorate.

•Be sure to contact an authorized service center, when installing your set in a location with heavy dust, high or low temperatures, high humidity, chemical substances or where it will operate for 24 hours a day such as in an airport, a train station, etc. Failure to do so may cause serious damage to your set.

•Use only a properly grounded plug and receptacle.

-An improper ground may cause electric shock or equipment damage. (Class l Equipment only.)

•To turn off the apparatus completely, you must pull the power plug out of the wall socket. Consequently, the power plug should be readily accessible at all times.

•Do not allow children to hang onto the product.

•Store the accessories (batteries, etc.) in a location safely out of the reach of children.

•Do not install the product in an unstable location such as a shaky self, a slanted floor, or a location exposed to vibration.

•Do not drop or impart a shock to the product. If the product is damaged, disconnect the power cord and contact a service center.

•To clean the product, unplug the power cord from the power outlet and wipe the product using a soft cloth dipped in a small amount of water. Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air freshener, lubricant or detergent. This may damage the appearance or erase the printing on the product.

•Do not expose the apparatus to dripping or splashing.

•Do not dispose of batteries in a fire.

•Do not short circuit, disassemble, or overheat the batteries.

•not short circuit, disassemble, or overheat the batteries.

•There is a danger of explosion if you replace the batteries with the wrong type of battery. Replace only with the same or equivalent type.

•WARNING - TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OTHER OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES.

[PF4900-XNZF]BN68-04783E.indb 2

2013-01-23 1:52:35

For more information on how to use e-Manual (P. 9)

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Product design and specifications may be changed without notice.

Digital TV notice

1. Functionalities related to Digital TV (DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC) digital terrestrial signals are broadcasted or where you are able to access to a compatible DVB-C (MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local dealer the possibility to receive DVB-T or DVB-C signal.

2. DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and DVB-C is that for the broadcast transmission of digital TV over cable. However, some differentiated features like EPG (Electric Programme Guide), VOD (Video On Demand) and so on, are not included in this specification. So, they cannot be workable at this moment.

3. Although this TV set meets the latest DVB-T and DVB-C standards, as of [August, 2008], the compatibility with future DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed.

4. Depending on the countries/areas where this TV set is used some cable-TV providers may charge an additional fee for such a service and you may be required to agree to terms and conditions of their business.

5. Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with some cable service providers. 6. For more information, please contact your local Samsung customer care centre.

The reception quality of TV may be affected due to differences in broadcasting method between the countries. Please check the TV performance in the local SAMSUNG Authorized Dealer, or the Samsung Call Centre whether it can be improved by reconfiguring TV setting or not.

User Instructions

• Screen Image retention

Do not display a still image (such as on a video game) on the plasma display panel for more than several minutes as it can cause screen image retention. This image retention is also known as “screen burn”. To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image.

• Heat on the top of the Plasma TV

The top side of the product may be hot after long periods of use as heat dissipates from the panel through the vent hole in the upper part of the product. This is normal and does not indicate any defect or operation failure of the product.

However, children should be prevented from touching the upper part of the product.

• The product is making a “cracking” noise.

A “cracking” noise may occur when the product contracts or expands due to a change in the surrounding environment such as temperature or humidity. This is normal and not a defect of the unit.

• Cell Defects

The PDP uses a panel consisting of 2,360,000(HD-level) to 6,221,000(FHD-level) pixels which require sophisticated technology to produce. However, there may be a few bright or dark pixels on the screen. These pixels will have no impact on the performance of the product.

•Avoid operating the TV at temperatures below 41°F (5°C)

•A still image displayed too long may cause permanent damage to the PDP Panel.

Watching the Plasma TV in 4:3 format for a long period of time may leave traces of borders displayed on the left, right and centre of the screen caused by the difference of light emission on the screen. Playing a DVD or a game console may cause similar effects to the screen.

Damages caused by the above effect are not covered by the Warranty.

• After-images on the Screen.

Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images. To prevent this effect, reduce the “brightness” and “contrast” when displaying still images for a long time.

• Warranty

Warranty does not cover any damage caused by image retention. Burn-in is not covered by the warranty.

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health or the environment. To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.

CIS languages (Russian, Ukrainian, Kazakhs) are not available for this product, since this is manufactured for customers in EU region.

English

English - 3

[PF4900-XNZF]BN68-04783E.indb 3

2013-01-23 1:52:36

List of Features

3D

This exciting new feature enables you to view 3D content from some broadcasting or 3D BD players.

Media Play

•Media Play connects your TV and compatible Samsung mobile phones/devices through a network.

•Allows you to play music files, pictures, and movies saved on a USB device.

e-Manual

•Allows you to read on screen full manual. (p. 9)

Accessories

Please make sure the following items are included with your TV. If any items are missing, contact your dealer.The items’ colours and shapes may vary depending on the models.

Cables not included in the package contents can be purchased separately.

• Remote Control & Batteries (AAA x 2)					•		Power Cord
•	Warranty Card / Regulatory Guide				•		Owner’s Instructions
•	3D Active Glasses				•		Cleaning Cloth

• Holder-Wire Stand	Assembling the Holder-Wire stand
			Ferrite Core for Power Cord: The ferrite cores are used
			to shield the cables from interference. When connecting a
			cable, open the ferrite core and clip it around the cable near
	A	B	the plug as shown in the figure.
			• A Maximum distance between the ferrite core and the end
Ferrite Core (2EA)			of the cord inserted in the TV: 3/4 inches
			• B Maximum distance between the ferrite core and the
			other end of the cord inserted in the AC outlet: 3/4 inches

An administration fee may be charged if either

(a)an engineer is called out at your request and there is no defect in the product (i.e. where you have failed to read this user manual)

(b)you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual)

The amount of such administration charge will be advised to you before any work or home visit is carried out.

English - 4

[PF4900-XNZF]BN68-04783E.indb 4

2013-01-23 1:52:38

Viewing the Remote Control

This is a special remote control for the visually impaired persons and has Braille points on the Power, Channel, and Volume buttons.

Turns the TV on and off.

Alternately select Teletext ON, Double, Mix or OFF.

Adjusts the volume.

Displays the main on-screen menu.

Displays Media Play.

Quickly select frequently used functions.

Selects the on-screen menu items and changes the values seen on the menu.

Returns to the previous menu.

E-MANUAL: Displays the e-Manual guide. (p. 9)

X: Sets the video, which provided with 3D signal.

AD/SUBT.: Audio Description selection. (Not available in some locations) / Displays digital subtitles.

					Displays and selects the available video sources.
					Press to directly access to channels.
					Returns to the previous channel.
					Cuts off the sound temporarily.
					Changes channels.
					Displays channel lists on the screen.
	MEDIA.P				Displays the EPG (Electronic Programme Guide).
					Displays information on the TV screen.
					Exits the menu.
	A	B	C	D	Use these buttons according to the direction on
					screen.
	E-MANUAL		AD/SUBT.
					Use these buttons in a specific feature.
					For details, refer to the e-Manual.

Installing batteries (Battery size: AAA)

English - 5

English

[PF4900-XNZF]BN68-04783E.indb 5

2013-01-23 1:52:38

Using the TV’s Controller (Panel Key)

The TV's Controller, a small joy stick like button on the rear left side of the TV, lets you control the TV without the remote control.Some functions which require a PIN code may not be available.

The product colour and shape may vary depending on the model.Exits the menu when pressing the controller more than 1 second.

When using the controller in the up/down/left/right directions, make sure you do not push the controller in first. If you push the controller in first it will not move in the up/down/left right directions.

Selecting the Media Play

TV Controller

The image is drawn by facing the front side of the TV.

Selecting the Menu Selecting a Source

Return

Power off

Function menu

Remote control sensor

Standby mode

Do not leave your TV in standby mode for long periods of time (when you are away on a holiday, for example). A small amount of electric power is still consumed even when the power button is turned off. It is best to unplug the power cord.

Initial Setup

When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWERP button. Setup is available only when the source is set to TV.

If You Want to Reset This Feature...

You should do Setup (MENU → System) again at home although you did in shop.

Select System - Setup (Initial Setup). Enter your 4 digit PIN number. The default PIN number is “0-0-0-0” (except France). If you want to change the PIN number, use the Change PIN function.

If you forget the PIN code, press the remote control buttons in the following sequence in Standby mode, which resets the PIN to “0-0-0-0” (France: “1-1-1-1”): POWER (off) → MUTE → 8 → 2 → 4 → POWER (on).

Changing the Input Source

Source

TV / Ext. / HDMI1 / HDMI2/DVI / AV / Component

Use to select TV or other external input sources such as DVD / Blu-ray players / cable box / STB satellite receiver connected to the TV.Press the SOURCE button. In the displayed Source list, connected inputs will be highlighted.

PC(D-Sub) input is not supported. If you want to connect PC to the TV, you can connect the HDMI to DVI cable with the HDMI IN 2(DVI) port on the TV.

Ext. always stays activated.Press the TOOLS button.

•Edit Name

You can set an external input source name you want.

––When connecting a PC to the HDMI IN 2(DVI) port with HDMI cable, you should set the TV to PC mode under Edit Name.

––When connecting a PC to the HDMI IN 2(DVI) port with HDMI to DVI cable, you should set the TV to DVI PC mode under

Edit Name.

––When connecting an AV devices to the HDMI IN 2(DVI) port with HDMI to DVI cable, you should set the TV to DVI Devices mode under Edit Name.

•Information

You can see detailed information about the connected external device.

English - 6

[PF4900-XNZF]BN68-04783E.indb 6

2013-01-23 1:52:40

Connections

AV connection		Component connection			HDMI connection
BD Player		BD Player			Set top Box / BD Player / PC
VIDEO OUT		OUT	T		HDMI OUT

It supports both Component and AV connection in one port.

DIGITAL)T

OPTICAL

Audio connection

W W

TV Side Panel

USB

COMMON INTERFACE

VHF/UHF Antenna

or

Cable

VCR or DVD

SCART connection

TV Rear Panel

The position of port may differ depending on the model.

The PDP device may interfere with an amateur radio or AM radio.

When using two-way radio mobile and portable units or amateur radio or AM radio near by your TV, this may cause the TV to malfunction.

NOTE

•PC(D-Sub) and PC/DVI AUDIO IN input are not supported.

•Connecting through the HDMI cable may not be supported depending on the PC.

•If a DVI to HDMI cable is connected to HDMI IN 2(DVI) port, there will be no audio.

•For set-top box connection using HDMI cable, we highly recommend you to connect the HDMI IN 1(STB) port.

English - 7

English

[PF4900-XNZF]BN68-04783E.indb 7

2013-01-23 1:52:41

Connecting to a COMMON INTERFACE slot (Your TV viewing Card Slot)

To watch paid channels, the “CI or CI+ CARD” must be inserted.
• If you do not insert the “CI or CI+ CARD”, some channels will display
the message “Scrambled Signal”.
• The pairing information containing a telephone number, the “CI or
CI+ CARD” ID the Host ID and other information will be displayed in
about 2~3 minutes. If an error message is displayed, please contact
your service provider.
• When the configuration of channel information has finished, the
message “Updating Completed” is displayed, indicating the channel	• The image may differ depending on the model.
list is updated.

NOTE

•You must obtain a “CI or CI+ CARD” from a local cable service provider.

•When removing the “CI or CI+ CARD”, carefully pull it out with your hands since dropping the “CI or CI+ CARD” may cause damage to it.

•Insert the “CI or CI+ CARD” in the direction marked on the card.

•The location of the COMMON INTERFACE slot may be different depending on the model.

•“CI or CI+ CARD” is not supported in some countries and regions; check with your authorized dealer.

•If you have any problems, please contact a service provider.

•Insert the “CI or CI+ CARD” that supports the current aerial settings. The screen will be distorted or will not be seen.

Network Connection

Network Connection - Wireless

You can connect your TV to your LAN through a standard wireless router or modem. To connect wirelessly, you must first attach a “Samsung Wireless LAN Adapter” (WIS12ABGNX, WIS09ABGNX - sold separately) to the USB port on the side of your TV. See the illustration below.

USB port on the side of the TV

	Wireless IP sharer
The LAN Port on the Wall	(wireless router having DHCP server)

Samsung Wireless LAN Adapter

LAN Cable

Samsung’s Wireless LAN adapter is sold separately and is offered by select retailers and Ecommerce sites. Samsung’s Wireless LAN adapter supports the IEEE 802.11a/b/g and n communication protocols. Samsung recommends using IEEE 802.11n. When you play video over a network connection, the video may not be played smoothly.

Most wireless network systems incorporate a security system that requires devices that access the network through an access point or wireless router (typically a wireless IP Sharer) to transmit an encrypted security code called an access key.

If HIGH PURE THROUGHPUT (Greenfield) 802.11n mode is selected and the Encryption type is set to WEP for your wireless router, Samsung TVs will not support a connection in compliance with new Wi-Fi certification specifications.

English - 8

[PF4900-XNZF]BN68-04783E.indb 8

2013-01-23 1:52:42

How to use the e-Manual

E-MANUAL

Screen Display

You can find instructions about your TV’s features in the e-Manual in your TV. To use, press the E-MANUAL button on your remote. Move the cursor using the up/down/right/left buttons to highlight a category, then a topic, and then press the ENTEREbutton. The e-Manual displays the page you want to see.

You can also access it through the menu:

OO MENUm→ Support → e-Manual → ENTERE

To return to the e-Manual main menu, press the E-MANUAL button on the remote.

Currently displayed		Basic Features
video, TV
Programme, etc.

Changing the Preset Picture Mode

Adjusting Picture Settings

Changing the Picture Options

Changing the Preset Sound Mode

Adjusting Sound Settings

}Index EEnter eExit

The category list. Press ◄ or ► button to select the category you want.

Displays the sub-menu list. Use the arrow buttons on your remote to move the cursor. Press ENTEREbutton to select the submenu you want.

Operation Buttons

}Index: Displays the index screen.

EEnter: Selects a category or sub-menu. eExit: Exit the e-Manual.

<Viewing the Contents>

aTry now: Displays the OSD menu that corresponds to the topic. To return to the e-Manual screen, press the

E-MANUAL button.

bHome: Moves to the e-Manual home screen. LPage: Moves to previous or next page.

{Zoom: Magnifies a screen.

––Press the {(Zoom) button to magnify the screen. You can scroll through the magnified screen by using the ▲ or ▼ buttons. To return to the screen to normal size, press the RETURN button.

How to toggle between an e-Manual topic and the corresponding OSD menu(s).

This function is not enabled in some menus.

You cannot use the Try now function if the menu is not activated.

	Method 1		Method 2
1.	If you want to use the menu that corresponds to an e-Manual topic,	1.	Press the ENTEREbutton when a topic is displayed. “Are you sure?”
	press the red button to select Try now.		appears. Select Yes, and then press the ENTEREbutton. The OSD
2.	To return to the e-Manual screen, press the E-MANUAL button.		window appears.
		2.	To return to the e-Manual screen, press the E-MANUAL button.

How to search for a topic on the index page

This function may not be supported depending on the language.

1.If you want to search a keyword, press the blue button to select Index.

2.Press the ◄ or ► button to select a character order you want.

3.Press the ▲ or ▼ button to select a keyword you want to see, and then press the ENTEREbutton.

4.You can view the corresponding e-Manual instruction screen.To close the Index screen, press the RETURN button.

English

English - 9

[PF4900-XNZF]BN68-04783E.indb 9

2013-01-23 1:52:43

Teletext Feature

The index page of the Teletext service gives you information on how to use the service. For Teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed.

You can change Teletext pages by pressing the numeric buttons on the remote control.

												1	0	(mode): Selects the Teletext mode (LIST/FLOF). If pressed during LIST mode,
		1											switches the mode to List save mode. In List save mode, you can save a Teletext page
													into a list using the 8(store) button.
												2	/(Teletext on/mix/off): Activates the Teletext mode for the current channel. Press
													the button twice to overlap the Teletext mode with the current broadcasting screen.
													Press it one more time to exit teletext.
												3	1	(sub-page): Displays the available sub-page.
												4	8	(store): Stores the Teletext pages.
												5	6	(index): Displays the index (contents) page at any time while you are viewing Teletext.
2												6	4	(size): Displays the teletext on the upper half of the screen in double-size. To move
				3
													the text to the lower half of the screen, press it again. For normal display, press it once

again.

8

9

4

MEDIA5

60

7!

A B C D @

E-MANUAL X AD/SUBT.

79(hold): Holds the display at the current page, in the case that there are several secondary pages that follow automatically. To undo, press it again.

82(page up): Displays the next Teletext page.

93(page down): Displays the previous Teletext page.

05(reveal): Displays the hidden text (answers to quiz games, for example). To display the normal screen, press it again.

!7(cancel): Shrinks the Teletext display to overlap with the current broadcast.

@Colour buttons (red, green, yellow, blue): If the FASTEXT system is used by the broadcasting company, the different topics on a Teletext page are colour-coded and can be selected by pressing the coloured buttons. Press the colour corresponding to the topic of your choice. A new colour coded page is displayed. Items can be selected in the same way. To display the previous or next page, press the corresponding coloured button.

The Teletext pages are organized according to six categories

Part

Contents

ASelected page number.

BBroadcasting channel identity.

CCurrent page number or search indications.

DDate and time.

EText.

FStatus information. FASTEXT information.

A	B	C	D

E

F

English - 10

PF4900-XC_ENG.indd 10

2013-02-07 4:59:50

3D Active Glasses - SSG-5100GB

Features

Samsung's SSG-5100GB 3D glasses enable you to view 3D images on your 3D TV. The Samsung 3D glasses communicate with Samsung 3D TVs via the 2.4GHz RF band.

The Samsung 3D glasses are only compatible with Samsung D, E, and F series 3D TV's that were released in 2011, 2012, and 2013. These 3D glasses cannot be connected to other Bluetooth devices.

Parts

LED Indicator & Power Button

Battery Cover

Liquid crystal shutter

For details on how to attach the glasses' temples and how to pair the glasses with the TV, refer to the separate 3D glasses manual.

Pairing 3D Active Glasses

What is Pairing? Pairing is the process of connecting 3D glasses and a 3D TV so that the two devices can exchange data.

Ensure your Samsung TV and 3D glasses are no farther than 19.5 in (50 cm) apart from each other while pairing is in progress.

Operating range

Recommended pairing distance

Turning the glasses on

Press the power button briefly. The green LED is turned on for 3 seconds. (Make sure that 3D is activated on the TV before using the 3D glasses.)

Turning the glasses off

Press the power button briefly. The red LED is turned on for 3 seconds.

Performing the pairing process

Turn the TV on and let it power up completely. Press and hold the Power button on the glasses. The green and the red LEDs blink alternately for 2 seconds.

2~6m

Recommended viewing distance

Recommended viewing	2~6m
distance	(6.5 to 19.5 ft)
Recommended pairing	50 cm or less
distance	(19.5 in)

Once the 3D glasses are paired, the remaining battery capacity is displayed on the TV screen. (This feature only applies to Samsung F series 3D TVs and 3D glasses that have been available since 2013.)

If you keep trying to pair the glasses and the TV, the battery level will decrease significantly. However, the battery level will recover to a certain degree in about a minute.

The working distance depends on the existence of obstacles (a person, metal, walls, etc.) between the glasses and the TV and the strength of the Bluetooth signal.

Turn off the 3D glasses while they are not in use. If you leave the 3D glasses on, the battery lifespan decreases.

Pairing steps

1. Turn on the TV, and then move the glasses within 19.5 inches of the TV.

2. Press the power button on the 3D glasses briefly. The 3D glasses will power on and pairing will start.

3. The message “3D glasses are connected to TV.” will be displayed on the TV screen when the pairing is successfully completed.

If pairing fails, the 3D glasses will power off.

If the first attempt to pair fails, power the TV off and on again and perform step 2.

How to pair again: Press the power button on the 3D glasses for more than 1 second.

<Pairing is needed again in the following situations:>

•If the 3D glasses do not function, even when the power button is pressed, especially on the 3D TV after a repair.

•If you want to play 3D content on another Samsung 3D TV model that belongs to the D, E, or F series released in 2011 through 2013. You must pair the glasses with the other TV.

Replacing the Battery

If the red LED blinks every two seconds continually, replace the battery with a new one.

Pull the	Open the	Remove the	Replace the	Push the	Close the
battery cover	battery cover	battery	battery	battery cover	battery cover
downward				downward

Insert the "+" side of the battery into the side marked with "+" in the battery compartment.

To check the remaining battery capacity, refer to the pairing section in this manual.

Viewing guidelines

•When viewing a 3D video under a fluorescent lamp (50 Hz – 60 Hz) or 3-wavelength lamp, you may notice a small amount of screen flickering.

•If this occurs, dim or turn off the light.

•Switching the input mode while watching a 3D movie may disable the 3D function on the TV. As a result, the 3D glasses may not function and the movie may not be displayed properly.

•If the 3D glasses are moved outside of their working distance, the signal from the TV will disconnect and the glasses' 3D function will turn off after several seconds.

•The 3D glasses will power off after the 3D function turns off. When this happens, the red LED will turn on for 3 seconds.

•Under some circumstances, the 3D glasses may malfunction due to interference from other devices.

•Ensure you are within the working distance of the glasses when you view a 3D video.

•The images may not be viewable in 3D if you move outside of the working distance for 3 seconds.

•If you lie on your side while watching TV with 3D active glasses, the picture may appear dark or may not be visible.

•The 3D glasses may not work properly due to interference from other 3D products or electronic devices that operate on the 2.4GHz frequency such as a microwave oven or Internet AP. If the 3D function malfunctions due to interference, please move all other electronic or wireless communication devices as far away from the glasses and the TV as possible.

English

English - 11

PF4900-XC_ENG.indd 11

2013-02-07 4:59:52

•The 3D effect may be experienced differently depending on the viewer. You may not notice the 3D effect at all if you wear glasses and have an unusual prescription.

•If a part of the 3D glasses or lenses is defective or damaged, it cannot be repaired and the glasses should be replaced. If the glasses stop working within the warranty period, the glasses can be repaired or replaced for free. If the glasses have been damaged due to the fault of the customer or the warranty period has expired, a new pair of glasses will have to be purchased.

CAUTION!

IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D IMAGES. READ THE FOLLOWING CAUTIONS BEFORE YOU OR YOUR CHILD USE THE 3D FUNCTION.

•Adults should frequently check on children who are using the 3D function. If there are any complaints of tired eyes, headaches, dizziness or nausea, stop the child from viewing the 3D TV and ensure that they rest.

•Do not use the 3D glasses for other purposes such as general wear, sunglasses, protective goggles, etc.

•Some viewers may experience discomfort such as dizziness, nausea and headaches while viewing 3D TV. If you experience any of these symptoms, stop viewing the 3D TV, remove the 3D glasses and rest for awhile.

•Watching 3D pictures for an extended period of time may cause eye strain. If you experience any eye strain, stop viewing the 3D TV, remove the 3D glasses and rest for awhile.

•Do not use the 3D function or 3D glasses while walking or moving around. Using the 3D function or 3D Active Glasses while moving around may result in injury from running into objects, tripping, and/or falling.

SAFETY PRECAUTIONS

The following safety instructions are to ensure your personal safety and prevent property damage. Please read them to ensure the proper use of the product.

•Do not place the product in a location exposed to direct sunlight, heat, fire, or water. Exposure may result in a product malfunction or fire.

•Do not apply force to the lenses of the 3D glasses. Do not drop or bend the product. Applying force, dropping, or bending may result in a product malfunction.

•Use only the specified standard batteries. When replacing the battery, insert the battery so that its polarity (+, –) is correct. Failing to do so may damage the battery or result in fire, personal injury or environmental damage caused by liquid leaking from the battery.

•Keep the used battery out of the reach of children so that they do not accidently swallow the battery. If your child has swallowed the battery, consult your doctor immediately.

•When cleaning the product, do not spray water or cleaner directly onto the surface of the product. Spraying water or cleaner directly onto the glasses may result in fire or electric shock, damage to the product's surface, or cause the indicator labels on the product's surface to come loose.

•Do not use chemicals containing alcohol, solvents, or surfactants, or chemicals such as wax, benzene, thinner, mosquito repellant, lubricant or cleaners. These may cause a discolouration of or cracks in the product surface and cause the indicator labels on the product's surface to come loose.

•Since the product surface and lens are easily scratched, make sure to use a clean soft cloth (a cloth consisting of superfine fibers or cotton flannel) when cleaning to avoid scratching either the surface or the lens. As the product may become scratched if there are any foreign items on the cloth, make sure to shake off any dust before using it.

•Never disassemble, repair, or modify the 3D glasses yourself. Do not use the glasses when they are out of order or broken.

•Take care that you do not injure your eyes with the edges of the frame of the 3D glasses when wearing them.

•Use your hands to put on or remove the 3D glasses.

Troubleshooting

	...If you encounter	...Try this
		• Replace the battery.
	My 3D glasses do not	• The 3D glasses should be close to the TV. Make sure
		that the distance between the TV and your 3D glasses
	work.
		is less than 19.5 feet (6m) in a straight line.
		• Check the 3D function settings of your TV.
	The LED keeps blinking	• The battery is dead. Replace the battery.

Specifications (Model Number: SSG-5100GB)

		Shutters	Liquid crystal	Transmittance	36±2%
	Optics
		Recommended	2 ~ 6m (6.5 to	Field Rate	120 fields/
		viewing distance	19.5 ft)		second
	Weight	Glasses	21.5g/.76 oz. (including the battery:
			24.0±0.5g/.85.±.018oz.)
	Power	Glasses	One 3V lithium/manganese dioxide battery
			3V(CR2025)
		Glasses	0.85mA (Average)
	Power		Type	165mAh, 3.0V (CR2025)
	Consumption	Battery
			Operating time	150 hours
			when On
		Operating	50°F ~ 104°F (10°C ~ 40°C)
	Operating	Temperature
	Conditions	Custody	-4°F ~ 113°F (-20°C ~ 45°C)
		Temperature

Product specifications may be changed without notice in order to enhance product performance.

The continuous operating time may differ depending on the wireless communication environment and usage conditions.

English - 12

PF4900-XC_ENG.indd 12

2013-02-07 4:59:54

WARRANTY

This Samsung product is warranted for the period of the listed period at the table (Refer to the warranty period table by the country) from the original date of purchase, against defective materials and workmanship. In the event that warranty service is required, you should first return the product to the retailer from whom it was purchased. However, Samsung Authorised Service Centres will comply with this warranty during the Warranty Period. To obtain details, please contact your nearest Authorised Service Centre.

PROCEDURE FOR MAKING A WARRANTY CLAIM

To make a claim under the warranty, you must contact the Samsung Centre during the Warranty Period to discuss the problems you are having with the product. If a repair or replacement is required, you will be provided with a Warranty Claim Number and address of an Authorised Service Centre.

If you are provided with a Warranty Claim Number, to obtain a repair or replacement of the product, you must send the product to the Authorised Service Centre advised together with:

•a copy of your completed warranty card or, if you have already provided this to Samsung, your name, address and contact telephone number;

•your original receipt, invoice or sales slip for the purchase of the product as new;

•your Warranty Claim Number.

Samsung will then repair or replace the product and return it to you using the contact details provided.

WARRANTY CONDITIONS

1.The warranty is only valid if the above procedure for making a warranty claim is followed.

2.Samsung’s obligations are limited to the repair or, at its discretion, replacement of the product or the defective part.

3.Warranty repairs must be carried out by Samsung Authorised Service Centres. No re-imbursement will be made for repairs carried out by service centres or dealers that are not authorised by Samsung and any such repair work and damage to the products caused by such repair work will not be covered by this warranty.

4.This product is not considered to be defective in materials nor workmanship by reason that it requires adaptation in order to conform to national or local technical or safety standards in force in any country other than the one for which the product was originally designed and manufactured. This warranty will not cover, and no reimbursement will be made for such adaptation, nor any damage which may result.

5.The warranty does not apply to any product that has been damaged or rendered defective as a result of any of the following excluded reasons, namely:

•as a result of accident, misuse, or abuse;

•through the failure to use this product for its normal purposes;

•by the use of parts not manufactured or sold by Samsung;

•by modification without the written permission of Samsung;

•by damage resulting from transit, neglect, power surge or failure;

•by damage resulting from lightning, water, fire, or acts of God;

•as a result of normal wear and tear; or

•differences in broadcasting methods or product standards between countries.

6.This warranty is valid for any person who legally acquired possession of the product during the warranty period.

7.NOTHING IN THESE WARRANTY CONDITIONS SHALL EXCLUDE OR LIMIT SAMSUNG’S LIABILITY FOR DEATH OR PERSONAL INJURY CAUSED BY THE PROVEN NEGLIGENCE OF SAMSUNG, UNLESS SUCH LIMITATION OR EXCLUSION IS PERMITTED BY APPLICABLE LAW.

8.WITH THE EXCEPTION OF SAMSUNG’S LIABILITY WHICH CANNOT BE EXCLUDED OR LIMITED BY LAW, SAMSUNG SHALL NOT BE LIABLE FOR: ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES LOSSES OR EXPENSES; OR LOST PROFITS; OR LOSS OF USE OR LOSS OF DATA; OR DAMAGE TO GOODWILL, REPUTATION OR LOST BUSINESS, ARISING DIRECTLY OR INDIRECTLY, FROM THE PURCHASE, USE OR SALE OF THE PRODUCT, WHETHER OR NOT SAMSUNG WAS ADVISED OR AWARE OF THE POSSIBILITY OF SUCH DAMAGES, LOSSES OR EXPENSES.

9.WITH THE EXCEPTION OF SAMSUNG’S LIABILITY WHICH CANNOT BE EXCLUDED OR LIMITED BY LAW, SAMSUNG’S LIABILITY UNDER OR IN CONNECTION WITH THIS WARRANTY OR THE PURCHASE, USE OR SALE OF THE PRODUCT SHALL NOT EXCEED THE PRICE PAID FOR THE PRODUCT AS NEW.

10.UNLESS PROVIDED FOR IN THIS WARRANTY, ALL CONDITIONS, WARRANTIES AND TERMS IMPLIED BY STATUTE OR OTHERWISE ARE HEREBY EXCLUDED TO THE MAXIMUM EXTENT PERMISSIBLE BY LAW.

11.The above warranty conditions do not affect your statutory rights as a consumer or otherwise.

English

English - 13

[PF4900-XNZF]BN68-04783E.indb 13

2013-01-23 1:52:49

Troubleshooting

If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, visit “www.samsung.com”, then click on Support, or call Samsung customer service centre.

	Issues	Solutions and Explanations
		First of all, please perform the Picture Test and confirm that your TV is properly displaying test image. (go to MENU -
	Picture Quality	Support - Self Diagnosis - Picture Test) If the test image is properly displayed, the poor picture may caused by the
		source or signal.
		• If you have an analogue cable/set top box, upgrade to a digital set top box. Use HDMI or Component cables to deliver
		HD (high definition) picture quality.
		• Cable/Satellite subscribers: Try HD stations from the channel line up.
	The TV image does not look as good	• Aerial connection: Try HD stations after performing Auto tuning.
	as it did in the store.	• Many HD channels are up scaled from SD (Standard Definition) contents.
		• Adjust the Cable/Set top box video output resolution to 1080i or 720p.
		• Make sure you are watching the TV at the minimum recommended distance based on the size and definition of the
		signal.
		• Compression of video contents may cause picture distortion especially in fast moving pictures such as sports and
	The picture is distorted: macroblock	action movies.
	error, small block, dots, pixelization	• Low signal level or bad quality can cause picture distortion. This is not a TV issue.
		• Mobile phones used close to the TV (cca up to 1m) may cause noise in picture on analogue and digital TV.
	Colour is wrong or missing.	• If you’re using a component connection, make sure the component cables are connected to the correct jacks. Incorrect
		or loose connections may cause colour problems or a blank screen.
		• Adjust the Picture options in the TV menu. (go to Picture Mode / Colour / Brightness / Sharpness)
	There is poor colour or brightness.	• Adjust Energy Saving option in the TV menu. (go to MENU - System - Eco Solution - Energy Saving)
		• Try resetting the picture to view the default picture settings. (go to MENU - Picture - Reset Picture)
	There is a dotted line on the edge of	• If the picture size is set to Screen Fit, change it to 16:9.
	the screen.	• Change cable/satellite box resolution.
	The picture is black and white.	• If you are using an AV composite input, connect the video cable (yellow) to the Green jack of component input 1 on the
		TV.
	When changing channels, the picture	• If connected with a cable box, please try to reset the cable box. Reconnect the AC cord and wait until the cable box
	freezes or is distorted or delayed.	reboots. It may take up to 20 minutes.
		• Set the output resolution of the cable box to 1080i or 720p.
		First of all, please perform the Sound Test to confirm that your TV audio is properly operating. (go to MENU - Support -
	Sound Quality	Self Diagnosis - Sound Test)
		If the audio is ok, the sound problem may be caused by the source or signal.
	There is no sound or the sound is too	• Please check the volume of the device (Cable/Sat Box, DVD, Blu-ray etc) connected to your TV.
	low at maximum volume.
		• Set the Speaker Select option to TV Speaker in the sound menu.
		• If you are using an external device, make sure the audio cables are connected to the correct audio input jacks on the
	The picture is good but there is no	TV.
		• If you are using an external device, check the device’s audio output option (ex. you may need to change your cable
	sound.
		box’s audio option to HDMI when you have a HDMI connected to your TV).
		• If you are using a DVI to HDMI cable, a separate audio cable is required.
		• Reboot the connected device by reconnecting the device’s power cable.
	The speakers are making an	• Check the cable connections. Make sure a video cable is not connected to an audio input.
	inappropriate noise.	• For aerial or cable connections, check the signal strength. Low signal level may cause sound distortion.

English - 14

[PF4900-XNZF]BN68-04783E.indb 14

2013-01-23 1:52:50

	Issues	Solutions and Explanations
	No Picture, No Video
		• Make sure the AC power cord is securely plugged in to the wall outlet and the TV.
	The TV will not turn on.	• Make sure the wall outlet is working.
		• Try pressing the POWER button on the TV to make sure the problem is not the remote. If the TV turns on, refer to “The
		remote control does not work” below.
		• Ensure the Sleep Timer is set to Off in the Time menu.
	The TV turns off automatically.	• If your PC is connected to the TV, check your PC power settings.
		• Make sure the AC power cord is plugged in securely to the wall outlet and the TV.
		• When watching TV from an aerial or cable connection, the TV will turn off after 10 ~ 15 minutes if there is no signal.
	You can not play 3D videos in some	• Take out the disk from player and put it again, or restart the BD player.
	of the BD players.
		• Check cable connections (remove and reconnect all cables connected to the TV and external devices).
		• Set your external device’s (Cable/Set top Box, DVD, Blu-ray etc) video outputs to match the connections to the TV
	There is no picture/video.	input. For example, if an external device’s output is HDMI, it should be connected to an HDMI input on the TV.
		• Make sure your connected devices are powered on.
		• Be sure to select the TV’s correct source by pressing the SOURCE button on the remote control.
		• Reboot the connected device by reconnecting the device’s power cable.
	Aerial (Air/Cable) Connection
		• Make sure the Aerial cable is connected securely.
	The TV is not receiving all channels.	• Please try Setup (Initial setup) to add available channels to the channel list. Go to MENU - System - Setup (Initial
		setup) and wait for all available channels to be stored.
		• Verify the Aerial is positioned correctly.
	The picture is distorted: macro block	• Compression of video contents may cause picture distortion, especially on fast moving pictures such as sports and
	error small block, dots, pixelization	action movies.
		• A low signal can cause picture distortion. This is not a TV issue.
	Others
	The picture will not display in full	• HD channels will have black bars on either side of the screen when displaying up scaled SD (4:3) contents.
		• Black bars on the top and bottom will appear during movies that have aspect ratios different from your TV.
	screen.
		• Adjust the picture size options on your external device or TV to full screen.
		• Plasma TVs typically make a soft humming sound. This is normal. It’s caused by the electrical charges that are used to
		create the images on the screen.
	Plasma TV is making humming noise.	• If the humming sound is loud, you may have set the brightness on the TV too high. Try setting the brightness lower.
		• You can also have loud humming if the back of your Plasma TV is too close to a wall or other hard surface. Also try
		rerouting your connection cables.
		• Improper installation of wall mount can create excessive noise.
		• To minimize the possibility of screen burn, this unit is equipped with Pixel Shift screen burn reduction technology. Pixel
	Image Retention (Burn In) Issue.	Shift lets you set the picture so it moves slightly up and down (Vertical Line) and side to side (Horizontal Dot). The
		regular, slight movement of the picture reduces screen burn in.
		• Replace the remote control batteries with the poles (+/–) in the right direction.
	The remote control does not work.	• Clean the sensor’s transmission window on the remote.
		• Try pointing the remote directly at the TV from 5~6 feet away.
	The cable/set top box remote control	• Programme the Cable/Set top box remote control to operate the TV. Refer to the Cable/Set top box user manual for
	doesn’t turn the TV on or off, or	the SAMSUNG TV code.
	adjust the volume.
	A “Mode Not Supported” message	• Check the supported resolution of the TV, and adjust the external device’s output resolution accordingly.
	appears.

English

English - 15

[PF4900-XNZF]BN68-04783E.indb 15

2013-01-23 1:52:51

	Issues	Solutions and Explanations
	There is a plastic smell from the TV.	• This smell is normal and will dissipate over time.
	The TV Signal Information is
	unavailable in the Self Diagnosis	• This function is only available with digital channels from an Aerial / RF / Coax connection.
	Test menu.
	TV is tilted to the right or left side.	• Remove the stand base from the TV and reassemble it.
	There are difficulties assembling the	• Make sure the TV is placed on a flat surface. If you can not remove the screws from the TV, please use a magnetized
	stand base.	screw driver.
	The Broadcasting menu is grey out	• The Broadcasting menu is only available when the TV source is selected.
	(unavailable).
	Your settings are lost after 30 minutes	• If the TV is in the Store Demo mode, it will reset audio and picture settings every 30 minutes. If you want to change the
	or every time the TV is turned off.	settings from Store Demo mode to Home Use, press the SOURCE button to select TV mode, and go to MENU →
		Support →Use Mode.
	You have intermittent loss of audio	• Check the cable connections and reconnect them.
		• Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the cables are flexible enough for
	or video.
		long term use. If mounting the TV to the wall, we recommend using cables with 90 degree connectors.
	You see small particles when you
	look closely at the edge of the frame	• This is part of the product’s design and is not a defect.
	of the TV.
	The PIP menu is not available.	• PIP functionality is only available when you are using a HDMI or components source.
	You turned the TV off 45 minutes	• It is normal. The TV operates the OTA (Over The Aerial) function itself to upgrade firmware downloaded whilst your
	ago, and it turned on again.	watching TV.
	The message “Scrambled Signal” or	• If you are using a CAM CARD (CI/CI+), check that it is installed into the common interface slot.
	“Weak or No Signal” appears.	• If there is still a problem, pull the CAM CARD out of the TV and insert it into the slot again.
	There are recurrent picture/sound	• Check and change the signal/source.
	issues.
	A reaction may occur between the
	rubber cushion pads on the base	• To prevent this, use felt pads on any surface of the TV that comes in direct contact with furniture.
	stand and the top finish of some
	furniture.
	The message “This file may not be	• This may appear because of high bit rate of content. Content generally will play but could experience some playability
	playable properly.” appears.	issue.

You can keep your TV in optimum operating condition by upgrading to the latest firmware (www.samsumg.com → support) by USB.

English - 16

[PF4900-XNZF]BN68-04783E.indb 16

2013-01-23 1:52:51

Installing the Wall Mount

The wall mount kit (sold separately) allows you to mount the TV on the wall. For detailed information on installing the wall mount, see the instructions provided with the wall mount. Contact a technician for assistance when installing the wall mount bracket. We do not advice you to do it yourself.

Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you select to install the TV on your own.

Wall Mount Kit Specifications (VESA)

Wall mount kit is not supplied but sold separately.

Install your wall mount on a solid wall perpendicular to the floor. When attaching to other building materials, please contact your nearest dealer. If installed on a ceiling or slanted wall, it may fall and result in severe personal injury.

NOTE

•Standard dimensions for wall mount kits are shown in the table below.

•When purchasing our wall mount kit, a detailed installation manual and all parts necessary for assembly are provided.

•Do not use screws that do not comply with the VESA standard screw specifications.

•Do not use screws longer than the standard dimension, as they may cause damage to the inside of the TV set.

•For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ depending on their specifications.

•Do not fasten the screws too strongly, this may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents.

•Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.

•Do not exceed 15 degrees tilt when mounting this TV.

inches	VESA Spec. (A * B)	Standard Screw			Quantity
43~51	400 X 400		M8		4
60~64	600 X 400

Do not install your Wall Mount Kit while your TV is turned on. It may result in personal injury due to electric shock.

Securing the TV to the Wall

Caution: Pulling, pushing, or climbing onto the TV may cause the TV to fall. In particular, ensure that your children do not hang over or destabilize the TV; doing so may cause the TV to tip over, resulting in serious injuries or death. Follow all safety precautions provided on the included Safety Flyer. For added stability, install the anti-fall device for safety purposes, as follows.

To avoid the TV from falling

Wall

1.Put the screws into the clamps and firmly fasten them onto the wall. Confirm that the screws have been firmly installed onto the wall.

You may need additional material such as an anchor depending on the type of wall.

Since the necessary clamps, screws, and string are not supplied, please purchase these additionally.

2.Remove the screws from the centre back of the TV, put the screws into the clamps, and then fasten the screws onto the TV again.

Screws may not be supplied with the product. In this case, please purchase the screws of the following specifications.

3.Connect the clamps fixed onto the TV and the clamps fixed onto the wall with a strong string and then tie the string tightly.

NOTE

•Install the TV near to the wall so that it does not fall backwards.

•It is safe to connect the string so that the clamps fixed on the wall are equal to or lower than the clamps fixed on the TV.

•Untie the string before moving the TV.

4.Verify all connections are properly secured. Periodically check connections for any sign of fatigue for failure. If you have

any doubt about the security of your connections, contact a professional installer.

English

English - 17

[PF4900-XNZF]BN68-04783E.indb 17

2013-01-23 1:52:52

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation.

Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product.

When using a stand or wall-mount, use parts provided by Samsung Electronics only.

• If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.

The appearance may differ depending on the product.

Be careful when you contact the TV because some parts can be somewhat hot.

Installation with a stand.

10 cm

10 cm

10 cm

Installation with a wall-mount.

	10 cm
10 cm	10 cm
	10 cm

Storage and Maintenance

If you remove the attached sticker on the TV screen, clean the residues and then watch TV.

The exterior and screen of the product can get scratched during cleaning. Be sure to wipe the exterior and screen carefully using a soft cloth to prevent scratches.

Do not spray water directly onto the product. Any liquid that goes into the product may cause a failure, fire, or electric shock.

Clean the product with a soft cloth dapped in a small amount of water. Do not use a flammable liquid (e.g. benzene, thinners) or a cleaning agent.

Anti-theft Kensington Lock

The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for additional information on proper use.

Please find a “K” icon on the rear of the TV. A kensington slot is beside the “K” icon.

The position and colour			on the model.

<Optional>

To lock the product, follow these steps:

1.Wrap the Kensington lock cable around a large, stationary object such as desk or chair.

2.Slide the end of the cable with the lock attached through the looped end of the Kensington lock cable.

3.Insert the locking device into the Kensington slot on the product.

4.Lock the lock.

These are general instructions. For exact instructions, see the User manual supplied with the locking device.

The locking device has to be purchased separately.

English - 18

[PF4900-XNZF]BN68-04783E.indb 18

2013-01-23 1:52:54

Specifications

Environmental Considerations
Operating Temperature	10°C to 40°C (50°F to 104°F)
Operating Humidity	10% to 80%, non-condensing
Storage Temperature	-20°C to 45°C (-4°F		to 113°F)
Storage Humidity	5% to 95%, non-condensing
Display Resolution	1024 X 768
Stand Swivel (Left / Right)	-20˚ ~ 20˚
Sound (Output)	10W X 2
Model Name	PS43F4900		PS51F4900
Screen Size	43 inches (109 cm)		51 inches (128 cm)
Dimensions (W x H x D)
Body	1009.7 x 617.5 x 55.7 (mm)		1185.2 x 702.1 x 55.7 (mm)
With stand	1009.7 x 692.3 x 305.0 (mm)		1185.2 x 776.5 x 305.0 (mm)
Weight
Without Stand	13.6 kg		17.7 kg
With Stand	18.0 kg		22.1 kg

Design and specifications are subject to change without prior notice.

For information about power supply, and more about power consumption, refer to the label attached to the product.Typical power consumption is measured according to IEC 62087 Ed.2

Recommendation - EU Only

•Hereby, Samsung Electronics, declares that this 3D Active Glasses is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

•Hereby, Samsung Electronics, declares that this PDP TV is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

•This equipment may be operated in all EU countries.

•The official Declaration of Conformity may be found at http://www.samsung.com, go to Support > Search Product Support and enter the model name.

English - 19

English

[PF4900-XNZF]BN68-04783E.indb 19

2013-01-23 1:52:55

Supported Video Formats

File Extention	Container	Video Codec	Resolution	Frame rate (fps)	Bit rate (Mbps)	Audio Codec
	AVI	DivX 3.11/4.x/5.x/6.x				AC3
*.avi / *.mkv	MKV		1920 x 1080		30	LPCM
		MPEG4 SP/ASP
*.asf / *.wmv	ASF					ADPCM
*.mp4 / *.3gp	MP4	H.264 BP/MP/HP				(IMA, MS)
*.vro / *.mpg	3GP					AAC
		Motion JPEG	640 x 480		8
*.mpeg / *.ts	MOV			6~30		HE-AAC
*.tp / *.trp	FLV					WMA
		Window Media Video v9
*.mov / *.flv	VRO					DD+
*.vob / *.svi	VOB	MPEG2			30	MPEG (MP3)
*.divx	PS		1920 x 1080			DTS (Core)
	TS	MPEG1				G.711(A-Law, μ-Law)
*.webm	WebM	VP8			20	Vorbis

Other Restrictions

•Video content will not play, or not play correctly, if there is an error in the content or the container.

•Sound or video may not work if the contents have a standard bit rate/frame rate above the compatible Frame/sec listed in the table.

•If the Index Table is in error, the Seek (Jump) function is not supported.

•Some USB/digital camera devices may not be compatible with the player.

•The menu can be displayed late if the video is over 10Mbps(bit rate).

Video decoder	Audio decoder
• Supports up to H.264, Level 4.1 (FMO/ASO/RS are not supported.)	• WMA 10 Pro supports up to 5.1 channel and M2 profile.
• frame rate :	• WMA lossless audio is not supported.
- Below 1280 x 720: 60 frame max	• Vorbis supports up to 2ch.
- Above 1280 x 720: 30 frame max	• DD+ supports up to 5.1 channel.
• VC1 AP L4 is not supported.
• GMC 2 or higher is not supported.

Supported Subtitle Formats

• External

Name	File extension
MPEG-4 timed text	.ttxt
SAMI	.smi
SubRip	.srt
SubViewer	.sub
Micro DVD	.sub or .txt
SubStation Alpha	.ssa
Advanced SubStation Alpha	.ass
Powerdivx	.psb

• Internal

Name	Container	Format
Xsub	AVI	Picture Format
SubStation Alpha	MKV	Text Format
Advanced SubStation Alpha	MKV	Text Format
SubRip	MKV	Text Format
MPEG-4 Timed text	MP4	Text Format

Supported Photo Formats

	File Extension	Type	Resolution
	*.jpg	JPEG	15360 X 8640
	*.bmp	BMP	4096 X 4096
	*.mpo	MPO	15360 X 8640

The MPO type file does not support Zoom, Rotate and Slide Show Effect functions.

Supported Music Formats

	File Extension	Type	Codec	Remark
	*.mp3	MPEG	MPEG1 Audio Layer 3
	*.m4a
	*.mpa	MPEG4	AAC
	*.aac
	*.flac	FLAC	FLAC	Supports up to 2ch.
	*.ogg	OGG	Vorbis	Supports up to 2ch.
				WMA 10 Pro supports up to 5.1 channel
	*.wma	WMA	WMA	and M2 profile. (WMA lossless audio is
				not supported.)
	*.wav	wav	wav
	*.mid	midi	midi	type 0 and type 1
	*.midi

English - 20

[PF4900-XNZF]BN68-04783E.indb 20

2013-01-23 1:52:57

Full available resolution: 1024 X 768 @ 60 Hz

Optimal resolution is 1024 X 768 @ 60 Hz. See specification page for full available resolution.

	Mode	Resolution	Horizontal Frequency (KHz)	Vertical Frequency (Hz)	Pixel Clock Frequency (MHz)	Sync Polarity (H / V)
	IBM	720 x 400	31.469	70.087	28.322	-/+
	MAC	640 x 480	35.000	66.667	30.240	-/-
		832 x 624	49.726	74.551	57.284	-/-
		640 x 480	31.469	59.940	25.175	-/-
		640 x 480	37.861	72.809	31.500	-/-
		640 x 480	37.500	75.000	31.500	-/-
		800 x 600	37.879	60.317	40.000	+/+
	VESA DMT	800 x 600	48.077	72.188	50.000	+/+
		800 x 600	46.875	75.000	49.500	+/+
		1024 x 768	48.363	60.004	65.000	-/-
		1024 x 768	56.476	70.069	75.000	-/-
		1024 x 768	60.023	75.029	78.750	+/+

NOTE

•The interlace mode is not supported.

•The set might operate abnormally if a non-standard video format is selected.

Licence

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under a license from U.S. Patent No’s: 5,956,674, 5,974,380, 5,978,762, 6,487,535, 6,226,616, 7,212,872, 7,003,467, 7,272,567, 7,668,723, 7,392,195, 7,930,184, 7,333,929 and 7,548,853. DTS, the Symbol, and DTS and the Symbol together are registered trademarks & DTS Premium Sound | 5.1 is a trademark of DTS, Inc. ©2012 DTS, Inc. All Rights Reserved.

Manufactured under a license from U.S. Patent No’s: 6,285,767, 8,027,477, 5,319,713, 5,333,201, 5,638,452, 5,771,295, 5,970,152, 5,912,976, 7,200,236, 7,492,907, 8,050,434, 7,720,240, 7,031,474, 7,907,736 and 7,764,802. DTS, the Symbol, and DTS and the Symbol together are registered trademarks & DTS Studio Sound is a trademark of DTS, Inc. ©2012 DTS, Inc. All Rights Reserved.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

DivX Certified® to play DivX® video up to HD 1080p, including premium content.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.com for more information and software tools to convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration. Covered by one or more of the following U.S. patents : 7,295,673; 7,460,668; 7,515,710; 7,519,274

DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license.

Open source licence notice

In the case of using open source software, Open Source Licences are available on the product menu.

Open Source Licence Notice is written only English.

English

English - 21

[PF4900-XNZF]BN68-04783E.indb 21

2013-01-23 1:52:59

Avertissement ! Consignes de sécurité importantes

(Avant toute installation de votre produit Samsung, veuillez lire les sections correspondant aux inscriptions qui figurent sur ce dernier.)

ATTENTION

RISQUE D'ELECTROCUTION - NE PAS OUVRIR

ATTENTION : POUR REDUIRE LES RISQUES D'ELECTROCUTION, NE RETIREZ PAS LE COUVERCLE (NI LE PANNEAU ARRIERE). A L'INTERIEUR DE L'APPAREIL, AUCUNE PIECE NE PEUT ETRE REPAREE PAR L'UTILISATEUR. POUR TOUT DEPANNAGE, ADRESSEZ-VOUS A UN SPECIALISTE.

Ce symbole indique qu'une tension élevée est présente à l'intérieur de l'appareil. Tout contact avec une pièce située à l'intérieur de cet appareil est dangereux.

Ce symbole vous prévient qu'une documentation importante relative au fonctionnement et à l'entretien est fournie avec le produit.

•Les fentes et les ouvertures ménagées dans le boîtier ainsi qu'à l’arrière et au-dessous de l'appareil assurent la ventilation de ce dernier. Afin de garantir le bon fonctionnement de l'appareil et éviter les risques de surchauffe, ces fentes et ouvertures ne doivent être ni obstruées ni couvertes.

-Ne couvrez pas les fentes et les ouvertures avec un morceau de tissu ou tout autre objet.

-Ne les obstruez pas non plus en plaçant l’appareil sur un lit, un canapé, un tapis ou toute autre surface semblable.

-Ne placez pas l’appareil dans un environnement clos tel qu’une bibliothèque ou une armoire encastrée, sauf si une ventilation adéquate est prévue.

•Ne placez pas l’appareil à proximité ou au-dessus d’un radiateur ou d’une résistance de chauffage, ni dans un endroit exposé à la lumière directe du soleil.

•Ne placez aucun récipient d’eau (vases, etc.) sur l’appareil car cela entraîne un risque d’incendie ou de décharge électrique.

•N’exposez pas l’appareil à la pluie et ne le placez pas à proximité d'une source d'eau, par exemple une baignoire, un lavabo, un évier, un bac de lavage, un sous-sol humide, une piscine, etc. Si l’appareil vient à être mouillé par accident, débranchez-le et contactez immédiatement un revendeur agréé. Veillez à débrancher le cordon d'alimentation de la prise avant de nettoyer l'appareil.

•Cet appareil fonctionne sur piles. Dans un souci de préservation de l’environnement, la réglementation locale prévoit peut-être des mesures spécifiques de mise au rebut des piles usagées. Veuillez donc contacter les autorités compétentes afin d’obtenir des informations sur la mise au rebut ou le recyclage des piles.

•Evitez de surcharger les prises murales, les rallonges et les adaptateurs car cela entraîne un risque d'incendie ou de décharge électrique.

•Les cordons d'alimentation doivent être déroulés de sorte qu'aucun objet placé sur ou contre eux ne les chevauche ou les pince. Accordez une attention particulière aux cordons au niveau de l'extrémité des fiches, des adaptateurs et de la sortie de l’appareil.

•En cas d'orage, ou bien lorsque vous vous absentez ou n'utilisez pas votre appareil pendant une longue période, débranchez celui-ci de la prise murale et débranchez également l’antenne ou le connecteur au réseau câblé. Ces précautions éviteront que l’appareil ne soit endommagé par la foudre ou par des surtensions.

•Avant de raccorder le cordon d’alimentation CA à la prise de l’adaptateur CC, vérifiez que la tension indiquée sur ce dernier correspond bien à la tension délivrée par le réseau électrique local.

•N'insérez jamais d'objet métallique dans les parties ouvertes de cet appareil : vous risqueriez de recevoir une décharge électrique.

•Afin d’éviter tout risque d'électrocution, ne mettez jamais les doigts à l’intérieur de l’appareil. Seul un technicien qualifié est habilité à ouvrir cet appareil.

•Veillez à enfoncer le cordon d'alimentation jusqu'à ce qu'il soit inséré correctement. Lorsque vous retirer le cordon d'alimentation, veillez à tenir la fiche d'alimentation lorsque vous retirez la fiche de la prise. Ne touchez pas le cordon d'alimentation si vous avez les mains mouillées.

•Si l’appareil ne fonctionne pas normalement, en particulier s’il émet des odeurs ou des sons anormaux, débranchez-le immédiatement et contactez un revendeur ou un centre de dépannage agréé.

•Si vous prévoyez de ne pas utiliser le téléviseur ou de vous absenter de chez vous pendant une période prolongée, veillez à retirer la fiche d'alimentation de la prise (en particulier si des enfants, des personnes âgées ou des personnes handicapées restent seuls à la maison).

-L'accumulation de poussière peut amener le cordon d'alimentation à produire des étincelles et de la chaleur ou l'isolation à se détériorer, entraînant un risque de fuite électrique, d'électrocution et d'incendie.

•Contactez un centre de service agréé si l'appareil est destiné à une installation dans des endroits exposés à la poussière, à des températures faibles ou élevées, à une forte humidité, à des substances chimiques et s'il a été prévu pour fonctionner 24/24 heures, comme dans des aéroports, des gares ferroviaires, etc.

•Le non-respect de ce qui précède peut gravement endommager le téléviseur.

•N'utilisez que des prises correctement reliées à la terre.

-Une mise à la terre incorrecte peut entraîner des électrocutions ou endommager l'appareil (appareils de classe I uniquement).

•Pour débrancher l'appareil du secteur, la fiche doit être retirée de la prise secteur, raison pour laquelle la fiche secteur doit être accessible à tout moment.

•Ne laissez pas des enfants se suspendre à l'appareil.

•Rangez les accessoires (batterie, etc.) dans un endroit hors de portée des enfants.

•N'installez pas l'appareil à un endroit instable, comme sur une étagère bancale, sur une surface inclinée ou à un endroit exposé à des vibrations.

•Evitez de laisser tomber le produit ou de lui faire subir des chocs. Si le produit est endommagé, débranchez le cordon d'alimentation et contactez un centre de service.

•Pour nettoyer le produit, retirez le cordon d'alimentation de la prise de courant et nettoyez le produit à l'aide d'un chiffon doux humidifié à l'eau. N'utilisez aucune substance chimique, telle que la cire, le benzène, l'alcool, des solvants, des insecticides, des désodorisants, des lubrifiants ou des détergents. Ces substances peuvent altérer l'aspect du produit ou effacer les imprimés se trouvant sur celui-ci.

•L'appareil ne doit pas être exposé aux gouttes ou aux éclaboussures.

•Ne vous débarrassez pas des piles en les faisant brûler.

•Les piles ne doivent pas être court-circuitées, démontées ou subir de surchauffe.

•Le remplacement incorrect de la batterie entraîne un risque d'explosion. Remplacez-la uniquement par une batterie similaire ou équivalente.

•ATTENTION : POUR EVITER TOUT RISQUE D'INCENDIE, TENEZ TOUJOURS CE PRODUIT A DISTANCE DES BOUGIES OU AUTRES FLAMMES OUVERTES.

PF4900-XNZF_FRA.indd 2

2013-01-23 10:31:32

Pour plus d'informations sur l'utilisation du manuel électronique (P. 9)

Les figures et illustrations contenues dans ce mode d’emploi sont fournies pour référence uniquement. Elles peuvent différer de l’aspect réel du produit. La conception et les spécifications du produit sont susceptibles d’être modifiées sans préavis.

Avis concernant le téléviseur numérique

1. Les fonctions relatives à la télévision numérique (DVB) ne sont disponibles que dans les pays ou régions où des signaux terrestres numériques de type DVB-T (MPEG2 et MPEG4 AVC) sont diffusés ou dans lesquels vous avez accès à un service de télévision par câble compatible DVB-C (MPEG2 et MPEG4 AAC). Consultez votre distributeur local pour connaître les possibilités en matière de réception des signaux DVB-T ou DVB-C.

2. DVB-T est la norme du consortium européen DVB pour la diffusion des signaux terrestres de télévision numérique. La norme DVB-C est, quant à elle, prévue pour la diffusion des signaux de télévision numérique par câble. Certaines fonctions particulières, telles que le guide électronique des programmes (Electric Program Guide - EPG) ou encore la vidéo à la demande (Video On Demand - VOD), ne sont toutefois pas incluses dans cette spécification. Dès lors, elles ne seront pas traitées pour l’instant.

3. Bien que ce téléviseur soit conforme aux dernières normes DVB-T et DVB-C (août 2008), il n’est pas garanti qu’il soit compatible avec les futures diffusions de signaux numériques terrestres DVB-T et par câble DVB-C.

4. En fonction du pays ou de la région où vous vous trouvez, certains opérateurs de télévision par câble peuvent facturer des frais supplémentaires pour un tel service. Il se peut également que vous deviez accepter les termes et conditions de ces sociétés.

5. Il se peut que certaines fonctions de TV numérique ne soient pas disponibles dans certains pays ou certaines régions et que la réception des signaux DVB-C ne soit pas correcte avec tous les opérateurs.

6. Pour plus d’informations, contactez votre service client Samsung.

Les différentes méthodes de diffusion adoptées en fonction des pays peuvent affecter la qualité de réception du téléviseur. Vérifiez le fonctionnement du téléviseur chez votre revendeur agréé SAMSUNG ou contactez le centre d’appel de Samsung pour savoir s’il est possible d’en améliorer les performances en reconfigurant les réglages.

Instructions d'utilisation

• Rémanence à l'écran

N’affichez pas une image figée (telle qu’elle apparaît sur un jeu vidéo) sur l’écran plasma au-delà de quelques minutes, sinon cela risquerait de provoquer une rémanence à l’écran. Cette rémanence de l'image est également appelée "brûlure de l'écran". Pour éviter la rémanence, réduisez le niveau de contraste ou de luminosité de l'écran lorsque vous affichez une image figée.

• Chaleur diffusée sur la partie supérieure du téléviseur à écran plasma

Le dessus de l'appareil peut chauffer en cas d'utilisation prolongée, car la chaleur s'échappe du panneau par le trou d'aération situé dans la partie supérieure du produit.

Ce phénomène est normal et n'indique aucunement la présence d'un défaut ou d'un dysfonctionnement. Il convient cependant d'empêcher les enfants de toucher la partie supérieure de l'écran.

• Le produit fait un bruit de "claquement".

Ce bruit de "claquement" risque d'être perceptible lorsque le produit se contracte ou s'étend suite à un changement du milieu ambiant, tel que la température ou l'humidité. Ce phénomène est normal et ne constitue pas un défaut.

• Défauts de cellule

L'écran plasma utilise un panneau constitué de 2 360 000 (niveau HD) à 6 221 000 (niveau FHD) pixels dont la fabrication fait appel à une technologie avancée. Il se peut toutefois que quelques points clairs ou sombres apparaissent à l'écran. Ces pixels n'ont aucune incidence sur la performance du produit.

•Évitez d'utiliser le téléviseur à des températures inférieures à 5 °C (41 °F).

•Une image figée affichée pendant une période prolongée peut endommager définitivement l'écran plasma.

Visionner pendant longtemps le téléviseur à écran plasma au format 4/3 risque de laisser apparaître des traces de bordures sur la gauche, sur la droite et au centre de l’écran. Ces traces sont dues à la différence de luminosité sur l’écran. Lire un DVD ou un jeu vidéo sur console risque de provoquer des effets similaires sur l'écran.

Les dommages provoqués par l'effet susmentionné ne sont pas couverts par la garantie.

• Images rémanentes à l’écran.

L'affichage d'images fixes de jeux vidéo et d'ordinateurs pendant une période excessive peut produire des rémanences. Pour empêcher ce phénomène, réduisez la luminosité et le contraste en cas d'affichage prolongé d'images figées.

• Garantie

La garantie ne couvre pas les dommages causés par la rémanence. Les brûlures ne sont pas couvertes par la garantie.

Instructions de mise au rebut de ce produit (Déchets d'équipements électriques et électroniques)

(Applicable dans les pays de l'Union Européenne et dans d'autres pays européens pratiquant la collecte sélective de déchets)

Ce symbole sur le produit, ses accessoires ou sa documentation indique que ni le produit, ni ses accessoires électroniques usagés (chargeur, casque audio, câble USB, etc.) ne peuvent être jetés avec les autres déchets ménagers. La mise au rebut incontrôlée des déchets présentant des risques pour l'environnement et la santé publique, veuillez séparer vos produits et accessoires usagés des autres déchets. Vous favoriserez ainsi le recyclage de la matière qui les compose dans le cadre d'un développement durable. Les particuliers sont invités à contacter le magasin leur ayant vendu le produit ou à se renseigner auprès des autorités locales pour connaître les procédures et les points de collecte de ces produits en vue de leur recyclage. Les utilisateurs professionnels doivent contacter leur fournisseur et consulter les conditions générales du contrat d'achat. Ce produit et ses accessoires ne peuvent être jetés avec les autres déchets professionnels et commerciaux.

Élimination des batteries de ce produit

(Applicable aux pays de l'Union européenne et aux autres pays européens dans lesquels des systèmes de collecte sélective sont mis en place.)

Le symbole sur la pile, le manuel ou l'emballage indique que les batteries de ce produit ne doivent pas être éliminées en fin de vie avec les autres déchets ménagers. L'indication éventuelle des symboles chimiques Hg, Cd ou Pb signifie que la pile ou l'accumulateur contient des quantités de mercure, de cadmium ou de plomb supérieures aux niveaux de référence stipulés dans la directive CE 2006/66. Si les piles ne sont pas correctement éliminées, ces substances peuvent porter préjudice

à la santé humaine ou à l'environnement. Afin de protéger les ressources naturelles et de favoriser la réutilisation du matériel, veillez à séparer les batteries des autres types de déchets et à les recycler via votre système local de collecte gratuite des piles et accumulateurs.

Les langues de la CEI (russe, ukrainien, kazakh) ne sont pas disponibles pour ce produit, fabriqué pour des clients de l'UE.

Français - 3

Français

PF4900-XNZF_FRA.indd 3

2013-01-23 10:31:33

Liste des fonctions

3D

Cette nouvelle fonctionnalité vous permet de regarder du contenu 3D depuis des lecteurs BD 3D.

Media Play

•Media Playconnecte votre téléviseur et vos téléphones portables/appareils Samsung compatibles via un réseau.

•Vous permet de lire des fichiers audio et des images sauvegardés sur un périphérique USB.

e-Manual

•Permet l’affichage des instructions sur les caractéristiques du téléviseur. (p. 9)

Accessoires

Vérifiez que les éléments suivants sont inclus avec votre téléviseur. S’il manque des éléments, contactez votre revendeur.La couleur et la forme des éléments peuvent varier en fonction du modèle.

Les câbles qui ne se trouvent pas dans le contenu de l'emballage peuvent être achetés séparément.

• Télécommande et piles (AAA x 2)					•		Câble d'alimentation
•	Carte de garantie / Guide réglementaire				•		Instructions d’utilisation
•	Lunettes actives 3D				•		Chiffon de nettoyage

•Support du serre-câble

Tore magnétique (2EA)

Installation du support du serre-câble

		Blindage magnétique pour cordon d'alimentation :
		Le blindage magnétique sert à protéger les câbles des
		interférences. Lors de la connexion d'un câble, ouvrez le
		blindage magnétique et rabattez-le autour du câble près de
A	B	la prise, comme illustré.
		• A Distance maximale entre le blindage magnétique et
		l'extrémité du cordon insérée dans le téléviseur : 3/4
		pouces

•B Distance maximale entre le blindage magnétique et l'autre extrémité du cordon insérée dans la prise CA : 3/4 pouces

Des frais d'administration peuvent vous être facturés si:

(a)un technicien intervient à votre demande et que le produit ne comporte aucun défaut (c.-à-d; si vous n'avez pas pris la peine de lire le présent manuel d'utilisation)

(b)vous amenez le produit dans un centre de réparation alors qu'il ne comporte aucun défaut (c.-à-d; si vous n'avez pas pris la peine de lire le présent manuel d'utilisation)

Le montant de ces frais d'administration vous sera signifié avant la réalisation de toute prestation ou visite à domicile.

Français - 4

PF4900-XNZF_FRA.indd 4

2013-02-07 9:44:38

Présentation de la télécommande

Ceci est une télécommande spéciale destinée aux malvoyants. Elle dispose de points Braille sur les boutons Power, Channel et Volume.

Permet d’allumer et éteindre la télévision.

Choisissez Teletext Activé, Double, Mix ou ARRET.

permet de régler le volume.

Permet d’afficher le menu principal à l’écran.

Affiche Media Play.

Permet de sélectionner rapidement les fonctions fréquemment utilisées.

Permettent de sélectionner des éléments de menu à l’écran et de modifier les valeurs des menus.

Permet de revenir au menu précédent.

E-MANUAL: affiche le Guide e-Manual. (p. 9) X: définit la vidéo fournissant le signal 3D.

AD/SUBT.: Sélection de la description audio. (Non disponible dans tous les pays) / permet d'afficher les sous-titres numériques.

					Permet d’afficher et de sélectionner les sources vidéo
					disponibles.
					Appuyez pour atteindre les chaînes directement.
					Permet de revenir à la chaîne précédente.
					Permet de couper temporairement le son.
					Permet de changer de chaîne.
					Affiche la liste des chaînes à l’écran.
	MEDIA.P				Permet d’afficher le Guide électronique des
					programmes (EPG).
					Permet d’afficher des informations sur l’écran du
					téléviseur.
					Permet de quitter le menu.
	A	B	C	D	Utilisez ces boutons conformément aux instructions
					affichées à l'écran.
	E-MANUAL		AD/SUBT.
					Ces boutons ont des fonctions spécifiques.
					Pour plus d’informations, reportez-vous au manuel
					électronique.

Français

Installation des piles (type de pile : AAA)

Français - 5

PF4900-XNZF_FRA.indd 5

2013-01-23 10:31:35
