Samsung ProXpress M337x, ProXpress M387x, ProXpress 407x Service Manual

Name: Samsung ProXpress M337x
Brand: Samsung
SKU: 2594190
Rating: 4.3 (3 reviews)

4.3 (3)

Mono Laser MFP

ProXpress M337x / M387x / 407x

series

(Ver1.3)

SERVICEMANUAL

Mono Laser MFP

Contents

1. Precautions

2. Product Specifications

3. Disassembly and Reassembly

4. Alignment and Troubleshooting

5. System Diagram

6. Reference Information

Refer to the service manual in the GSPN (see the rear cover) for more information.

Contents

1.	Precautions ......................................................................................................................................				1	−	1
	1.1.	Safety warning ........................................................................................................................			1	−	1
	1.2.	Caution for safety ....................................................................................................................			1	−	2
		1.2.1.	Toxic material.............................................................................................................		1	−	2
		1.2.2. Electric shock and fire safety precautions .........................................................................			1	−	2
		1.2.3.	Handling precautions ...................................................................................................		1	−	4
		1.2.4. Assembly and Disassembly precautions...........................................................................			1	−	4
		1.2.5. Disregarding this warning may cause bodily injury ............................................................			1	−	5
	1.3.	ESD precautions......................................................................................................................			1	−	6
2.	Product Specifications........................................................................................................................				2	−	1
	2.1.	Specifications..........................................................................................................................			2	−	1
		2.1.1.	Product Overview........................................................................................................		2	−	1
		2.1.2.	Specifications .............................................................................................................		2	−	2
			2.1.2.1.	General .......................................................................................................	2	−	2
			2.1.2.2.	Print ...........................................................................................................	2	−	3
			2.1.2.3.	Copier.........................................................................................................	2	−	4
			2.1.2.4.	Scanner .......................................................................................................	2	−	5
			2.1.2.5.	Fax.............................................................................................................	2	−	6
			2.1.2.6.	Controller and Software..................................................................................	2	−	7
			2.1.2.7.	Paper Handling.............................................................................................	2	−	9
			2.1.2.8.	Consumables................................................................................................	2	− 11
			2.1.2.9.	Maintenance Part ..........................................................................................	2	− 12
	2.2.	Product Description..................................................................................................................			2	− 13
		2.2.1.	Front View.................................................................................................................		2	− 13
		2.2.2.	Rear View	..................................................................................................................	2	− 15
		2.2.3.	Paper Path..................................................................................................................		2	− 16
		2.2.4.	System layout .............................................................................................................		2	− 17
			2.2.4.1.	Feeding Part.................................................................................................	2	− 18
			2.2.4.2.	Image Creation .............................................................................................	2	− 20
			2.2.4.3.	Fuser unit ....................................................................................................	2	− 22
			2.2.4.4. LSU (Laser Scanning Unit) .............................................................................		2	− 23
			2.2.4.5.	Drive Unit ...................................................................................................	2	− 24
		2.2.5.	Hardware configuration ................................................................................................		2	− 25
			2.2.5.1.	Main Controller (M337x_M387x_M407xFR_M4072FD) .....................................	2	− 28
			2.2.5.2.	Main Controller (M407xFX) ...........................................................................	2	− 31
			2.2.5.3.	OPE Controller.............................................................................................	2	− 33
			2.2.5.4.	SO-DIMM PBA............................................................................................	2	− 34
			2.2.5.5.	WLAN(M387xFW model only) .......................................................................	2	− 34

i	Copyright© 1995-2013 SAMSUNG. All rights reserved.

Contents

	2.2.5.6. ADF and RADF SUB PBA .............................................................................		2	− 35
	2.2.5.7.	SCF PBA - Optional ......................................................................................	2	− 35
	2.2.5.8.	CRUM PBA.................................................................................................	2	− 36
	2.2.5.9.	Fax Board....................................................................................................	2	− 37
	2.2.5.10.	SMPS Board ................................................................................................	2	− 38
	2.2.5.11.	HVPS board.................................................................................................	2	− 39
2.2.6.	Engine Firmware Control Algorithm ...............................................................................		2	− 40
	2.2.6.1.	Feeding .......................................................................................................	2	− 40
	2.2.6.2.	Transfer.......................................................................................................	2	− 40
	2.2.6.3.	Fusing.........................................................................................................	2	− 41
	2.2.6.4.	LSU............................................................................................................	2	− 41
2.2.7.	Software Descriptions ..................................................................................................		2	− 42
	2.2.7.1.	Software system overview ..............................................................................	2	− 42
	2.2.7.2.	Architecture .................................................................................................	2	− 42
	2.2.7.3. Data and Control Flow ...................................................................................		2	− 43
3. Disassembly and Reassembly ..............................................................................................................			3	−	1
3.1. Precautions when replacing parts ................................................................................................			3	−	1
3.1.1.	Precautions when assembling and disassembling ...............................................................		3	−	1
3.1.2.	Precautions when handling PBA.....................................................................................		3	−	1
3.1.3.	Releasing Plastic Latches..............................................................................................		3	−	2
3.2. Screws used in the printer..........................................................................................................			3	−	3
3.3. Replacing the Main SVC parts ...................................................................................................			3	−	5
3.3.1.	Left and Right Cover....................................................................................................		3	−	5
3.3.2.	Front Cover................................................................................................................		3	−	6
3.3.3.	ADF or RADF Unit .....................................................................................................		3	−	7
3.3.4.	OPE Unit...................................................................................................................		3	−	8
3.3.5.	Platen Unit.................................................................................................................		3	−	9
3.3.6.	Top-Middle Cover .......................................................................................................		3	− 10
3.3.7.	Fax Board	..................................................................................................................	3	− 11
3.3.8.	Middle and Inner Cover................................................................................................		3	− 12
3.3.9.	Main Board ................................................................................................................		3	− 13
3.3.10.	HVPS board ...............................................................................................................		3	− 13
3.3.11.	SMPS Board...............................................................................................................		3	− 14
3.3.12.	Laser Scanning Unit (LSU) ...........................................................................................		3	− 14
3.3.13.	Fuser Unit	..................................................................................................................	3	− 15
3.3.14.	Main Drive Unit..........................................................................................................		3	− 16
3.3.15.	Feed Drive Unit ..........................................................................................................		3	− 17
3.3.16.	Pick Up_Regi_MP Clutch .............................................................................................		3	− 17
3.3.17.	Pick-Up Roller............................................................................................................		3	− 18
3.3.18.	Transfer Roller............................................................................................................		3	− 19

Contents

	3.3.19.	MP Unit	....................................................................................................................	3	− 20
	3.3.20.	Bin-full sensor ............................................................................................................		3	− 20
	3.3.21.	Regi_Feed ............................................................................................._Empty Sensor		3	− 21
	3.3.22.	Reverse Roller ...........................................................................................................		3	− 22
	3.3.23.	SCF(Second .................................................................................Cassette Feeder) Unit		3	− 23
		3.3.23.1. ...........................................................................................	SCF Right Cover	3	− 23
		3.3.23.2. ...........................................................................................	SCF Main Board	3	− 23
		3.3.23.3. ...........................................................................................	SCF Main Motor	3	− 24
		3.3.23.4. ..................................................................................................	SCF Clutch	3	− 24
		3.3.23.5. .............................................................................	SCF pick up _ forward roller	3	− 25
		3.3.23.6. .......................................................................................	SCF Reverse Roller	3	− 25
		3.3.23.7. .....................................................................................	SCF Main Drive Unit	3	− 26
		3.3.23.8. ...............................................................................................	SCF Lift Assy	3	− 26
		3.3.23.9. .........................................................................................	SCF Pick - Up Unit	3	− 27
		3.3.23.10. ...................................................................SCF Pick-Up_Empty_Feed Sensor		3	− 28
4. Alignment and Troubleshooting ...........................................................................................................				4	−	1
4.1.	Alignment and Adjustments.......................................................................................................			4	−	1
	4.1.1.	Control Panel..............................................................................................................		4	−	1
	4.1.2.	Understanding ......................................................................................The Status LED		4	−	4
	4.1.3.	Clearing .............................................................................................................Jams		4	−	6
		4.1.3.1. ......................................................................	Clearing original document jams	4	−	6
		4.1.3.2. .......................................................................................	Clearing paper jams	4	− 10
	4.1.4.	Useful menu .........................................................................................item for service		4	− 18
	4.1.5.	Periodic ..............................................................................................Defective Image		4	− 20
	4.1.6.	Useful management ..............................................................................................tools		4	− 21
		4.1.6.1. ...............................................................	Using Samsung Easy Printer Manager	4	− 21
		4.1.6.2. ...................................................	Using Samsung Printer Status (Windows only)	4	− 24
		4.1.6.3. ................................................................	Using SyncThru Web Service (SWS)	4	− 25
	4.1.7.	Updating ......................................................................................................Firmware		4	− 27
		4.1.7.1. ........................................................	Update the firmware by using the USB port	4	− 27
		4.1.7.2. ..........................................................	Update the firmware by using the network	4	− 28
	4.1.8.	Tech Mode.................................................................................................................		4	− 30
		4.1.8.1. ..................................................................................	Entering the Tech Mode	4	− 30
		4.1.8.2. ..........................................................................................	Tech Mode Menu	4	− 31
		4.1.8.3. ...........................................................................	Tech Mode Menu description	4	− 32
4.2.	Troubleshooting ......................................................................................................................			4	− 37
	4.2.1.	Procedure ...............................................................................of checking the symptoms		4	− 37
		4.2.1.1. ...........................................................................................	Basic Check List	4	− 38
	4.2.2.	Error Code .....................................................................................and Troubleshooting		4	− 39
	4.2.3.	Image quality ..................................................................................................problem		4	− 70

iii	Copyright© 1995-2013 SAMSUNG. All rights reserved.

Contents

		4.2.4. Other errors................................................................................................................	4	− 76
5.	System Diagram................................................................................................................................		5	−	1
	5.1.	Block Diagram (M337xFD_M387xFD_M387xFW_M407xFR_M4072FD) ........................................	5	−	1
	5.2.	Block Diagram (M407xFX).......................................................................................................	5	−	2
	5.3.	Connection Diagram (M337xFD_M387xFD_M387xFW_M407xFR_M4072FD).................................	5	−	3
	5.4.	Connection Diagram (M407xFX)................................................................................................	5	−	4
6.	Reference Information........................................................................................................................		6	−	1
	6.1.	Tool for Troubleshooting...........................................................................................................	6	−	1
	6.2.	Glossary.................................................................................................................................	6	−	2
	6.3. The Sample Pattern for the Test ..................................................................................................		6	−	8
	6.4. Model Name and Code .............................................................................................................		6	−	9
	6.5.	Revision History......................................................................................................................	6	− 10

1. Precautions

In order to prevent accidents and damages to the equipment please read the precautions listed below carefully before servicing the product and follow them closely.

1.1. Safety warning

1)Only to be serviced by a factory trained service technician.

High voltages and lasers inside this product are dangerous. This product should only be serviced by a factory trained service technician.

2)Use only Samsung replacement parts.

There are no user serviceable parts inside the product. Do not make any unauthorized changes or additions to the product as these could cause the product to malfunctions and create an electric shocks or fire hazards.

3)Laser Safety Statement

The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1 Subchapter J for Class I(1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1. Class I laser products are not considered to be hazardous. The laser system and printer are designed so there is never any human access to laser radiation above a Class I level during normal operation, user maintenance or prescribed service condition.

•Wavelength: 800 nm

•Beam divergence

-Paraller: 11 degrees

-Perpendicular: 35 degrees

•Maximum power of energy output: 12 mW

WARNING

Never operate or service the product with the protective cover removed from Laser/Scanner assembly. The reflected beam, although invisible, can damage your eyes.

When using this product, these basic safety precautions should always be followed to reduce risk of fire, electric shock, and personal injury.

4) Lithium battery not replaceable by user

1-1	Copyright© 1995-2013 SAMSUNG. All rights reserved.

1. Precautions

1.2. Caution for safety

1.2.1. Toxic material

This product contains toxic materials that could cause illness if ingested.

1)Please keep imaging unit and toner cartridge away from children. The toner powder contained in the imaging unit and toner cartridge may be harmful, and if swallowed, you should contact a doctor.

1.2.2. Electric shock and fire safety precautions

Failure to follow the following instructions could cause electric shock or potentially cause a fire.

1)Use only the correct voltage, failure to do so could damage the product and potentially cause a fire or electric shock.

2)Use only the power cable supplied with the product. Use of an incorrectly specified cable could cause the cable to overheat and potentially cause a fire.

3)Do not overload the power socket, this could lead to overheating of the cables inside the wall and could lead to a fire.

4)Do not allow water or other liquids to spill into the product, this can cause electric shock. Do not allow paper clips, pins or other foreign objects to fall into the product, these could cause a short circuit leading to an electric shock or fire hazard.

5)Never touch the plugs on either end of the power cable with wet hands, this can cause electric shock. When servicing the product, remove the power plug from the wall socket.

6)Use caution when inserting or removing the power cord. When removing the power cord, grip it firmly and pull. The power cord must be inserted completely, otherwise a poor contact could cause overheating leading to a fire.

7)Take care of the power cable. Do not allow it to become twisted, bent sharply around corners or power cable may be damaged. Do not place objects on top of the power cable. If the power cable is damaged it could overheat and cause a fire. Exposed cables could cause an electric shock. Replace the damaged power cable immediately, do not reuse or repair the damaged cable. Some chemicals can attack the coating on the power cable, weakening the cover or exposing cables causing fire and shock risks.

1-2

1. Precautions

8)Ensure that the power sockets and plugs are not cracked or broken in any way. Any such defects should be repaired immediately. Take care not to cut or damage the power cable or plugs when moving the machine.

9)Use caution during thunder or lightning storms. Samsung recommends that this machine be disconnected from the power source when such weather conditions are expected. Do not touch the machine or the power cord if it is still connected to the wall socket in these weather conditions.

10)Avoid damp or dusty areas, install the product in a clean well ventilated location. Do not position the machine near a humidifier or in front of an air conditioner. Moisture and dust built up inside the machine can lead to overheating and cause a fire or cause parts to rust.

11)Do not position the product in direct sunlight. This will cause the temperature inside the product to rise possibly leading to the product failing to work properly and in extreme conditions could lead to a fire.

12)Do not insert any metal objects into the machine through the ventilator fan or other part of the casing, it could make contact with a high voltage conductor inside the machine and cause an electric shock.

13)	When replacing the SMPS board, please wait 5 minutes after unplugging the power cord, then replace it. You

can get a shock by the electric discharge.

1-3	Copyright© 1995-2013 SAMSUNG. All rights reserved.

1. Precautions

1.2.3. Handling precautions

The following instructions are for your own personal safety to avoid injury and so as not to damage the product.

1)Ensure the product is installed on a level surface, capable of supporting its weight. Failure to do so could cause the product to tip or fall.

2)The product contains many rollers, gears and fans. Take great care to ensure that you do not catch your fingers, hair or clothing in any of these rotating devices.

3)Do not place any small metal objects, containers of water, chemicals or other liquids close to the product which if spilled could get into the machine and cause damage or a shock or fire hazard.

4)Do not install the machine in areas with high dust or moisture levels, beside on open window or close to a humidifier or heater. Damage could be caused to the product in such areas.

5)Do not place candles, burning cigarettes, etc on the product, These could cause a fire.

6)Ensure that the machine is installed and used in proper area to meet the temperature and humidity specifications.

•If the machine is stored at below zero Celsius for a long time, do not use the machine instantly after movement. It can malfunction. Take care of the machine storage. If the machine is stored at below zero Celsius for a long time, keep the machine at room temperature and install it.

1.2.4. Assembly and Disassembly precautions

1)Replace parts carefully and always use Samsung parts. Take care to note the exact location of parts and also cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly. Please carry out the following procedures before dismantling the product or replacing any parts.

2)Ensure that power is disconnected before servicing or replacing any electrical parts.

3)Disconnect interface cables and power cables.

4)Only use approved spare parts. Ensure that part number, product name, any voltage, current or temperature rating are correct.

5)When removing or re-fitting any parts do not use excessive force, especially when fitting screws into plastic.

6)Take care not to drop any small parts into the machine.

7)Handling of the OPC Drum

•The OPC Drum can be irreparably damaged if it exposed to light. Take care not to expose the OPC Drum either to direct sunlight or to fluorescent or incandescent room lighting. Exposure for as little as 5 minutes can damage the surface of the photoconductive properties and will result in print quality degradation. Take extra care when servicing the product. Remove the OPC Drum and store it in a black bag or other lightproof container. Take care when working with the Covers (especially the top cover) open as light is admitted to the OPC area and can damage the OPC Drum.

•Take care not to scratch the green surface of OPC Drum Unit. If the green surface of the Drum Cartridge is scratched or touched the print quality will be compromised.

1-4

1. Precautions

1.2.5. Disregarding this warning may cause bodily injury

1)Be careful with the high temperature part.

The fuser unit works at a high temperature. Use caution when working on the printer. Wait for the fuser unit to cool down before disassembly.

2)Do not put fingers or hair into the rotating parts.

When operating a printer, do not put hand or hair into the rotating parts (Paper feeding entrance, motor, fan, etc.). If do, you can get harm.

3)When you move the printer, use safe lifting and handling techniques.

This printer is heavy. Use the lifting handles located on each side of the machine. Back injury could be caused if you do not lift carefully.

4)Ensure the printer is installed safely.

Ensure the printer is installed on a level surface, capable of supporting its weight. Failure to do so could cause the printer to tip or fall possibly causing personal injury or damaging the printer.

5)Do not install the printer on a sloping or unstable surface. After installation, double check that the printer is stable.

1-5	Copyright© 1995-2013 SAMSUNG. All rights reserved.

1. Precautions

1.3. ESD precautions

Certain semiconductor devices can be easily damaged by static electricity. Such components are commonly called “Electrostatically Sensitive (ES) Devices” or ESDs. Examples of typical ESDs are: integrated circuits, some field effect transistors, and semiconductor “chip” components. The techniques outlined below should be followed to help reduce the incidence of component damage caused by static electricity.

CAUTION

Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.

1)Immediately before handling a semiconductor component or semiconductor-equipped assembly, drain off any electrostatic charge on your body by touching a known earth ground. Alternatively, employ a commercially available wrist strap device, which should be removed for your personal safety reasons prior to applying power to the unit under test.

2)After removing an electrical assembly equipped with ESDs, place the assembly on a conductive surface, such as aluminum or copper foil, or conductive foam, to prevent electrostatic charge buildup in the vicinity of the assembly.

3)Use only a grounded tip soldering iron to solder or desolder ESDs.

4)Use only an “anti-static” solder removal device. Some solder removal devices not classified as “anti-static” can generate electrical charges sufficient to damage ESDs.

5)Do not use Freon-propelled chemicals. When sprayed, these can generate electrical charges sufficient to damage ESDs.

6)Do not remove a replacement ESD from its protective packaging until immediately before installing it. Most replacement ESDs are packaged with all leads shorted together by conductive foam, aluminum foil, or a comparable conductive material.

7)Immediately before removing the protective shorting material from the leads of a replacement ESD, touch the protective material to the chassis or circuit assembly into which the device will be installed.

8)Maintain continuous electrical contact between the ESD and the assembly into which it will be installed, until completely plugged or soldered into the circuit.

9)Minimize bodily motions when handling unpackaged replacement ESDs. Normal motions, such as the brushing together of clothing fabric and lifting one’s foot from a carpeted floor, can generate static electricity sufficient to damage an ESD.

1-6

2. Product Specifications

2.1. Specifications

2.1.1. Product Overview

1)Speed

•M337x series : Up to 33 ppm in A4 (35 ppm in Letter)

•M387x series : Up to 38 ppm in A4 (40 ppm in Letter)

•M407x series : Up to 40 ppm in A4 (42 ppm in Letter)

2)Processor

•M337x series / M387x series / M407xFR : 600 MHz

•M407xFX : 600 MHz + 1GHz

3)Printer Languages

•PostScript3, PCL6/5e, IBM ProPrinter, EPSON, SPL

4)Memory (Std / Max)

•M337xFD / M387xFD / M387xFW / 407xFR : 256 MB / 512 MB

•M407xFX : 1 GB / 1 GB

5)Interfaces

•High-Speed USB 2.0

•Ethernet

•M337xFD / M387xFD / M387xFW ; 10/100 Base TX

•M407xFR / M407xFX : 10/100/1000 Base TX

•Wireless Network

•M387xFW Only : 802.11b/g/n

•LCD

•4–line LCD : M337xFD / M387xFD / M387xFW / 407xFR

•4.3 inch Touch LCD : M407xFX

6)Consumables

•Integrated Toner System

:M3370FD / M3870FD/ M3870FW / M4070FR / M4070FX

•Separated Toner System

:M3375FD / M3875FD/ M3875FW / M4075FR / M4075FX

2-1	Copyright© 1995-2013 SAMSUNG. All rights reserved.

2. Product Specifications

2.1.2. Specifications

•Product Specifications are subject to change without notice.

2.1.2.1. General

Item		Specification
Temperature	Operating	10 to 30 °C (50 to 86°F)

	Storage	-20 to 40 °C (-4 to 104 °F)

Humidity	Operating	20 to 80% RH

	Storage	10 to 90% RH

Noise Level	Print mode	•	M337x series: Less than 54 dB (A)
		• M387x/ M407x series: Less than 56 dB (A)

	Copy/ Scan mode	•	M337x series: Less than 56 dB (A)
		• M387x/ M407x series: Less than 58 dB (A)

Power Consumption	Ready mode	•	Less than 10 Wh (Except. M407xNX)
		• Less than 15 Wh (M407xNX)

	Average operating mode	Less than 700 W

	Power save mode	•	Less than 1.1 Wh (Except. M407xNX)
			(Wi-Fi Direct on: Less than 2.8Wh / off : 1.6Wh, M387xFW
			only)
		• Less than 3.9 Wh (M407xNX)

Dimension	Width x Length x Height	•	M337xFD/ M337xHD/ M387xFD/ M387xHD series: 414.6 x
			420.6 x 449.1 mm (16.32 x 16.56 x 17.68 inches)
		•	M387xFW/M407xFR/ M407xFX /M407xHR series: 467 x
			444.3 x 482.6 mm (18.39 x 17.49 x 19 inches)
		• M4072FD : 410.6 x 483 x 449.1 mm (16.17 x 19 x 17.68
			inches)

Weight	Machine with	•	M337xFD/ M337xHD/ M387xFD/ M387xHD series: 21.44
	consumables		Kg (47.27 Ibs)
		•	M387xFW/M407xFR/ M407xFX / M407xHR series: 24.8
			Kg (54.68 Ibs)
		• M4072FD : 15.4 Kg (33.95 lbs)

Reliability & Service	Recommended Monthly	• M337xFD : 1000 ~ 2500 pages
	Printing Volume (AMPV)	• M387x series : 1500 ~ 3500 pages
		• M407x series : 2000 ~ 4000 pages

	Max. Monthly Print	•	M337xFD : 50,000 pages
	Volume	•	M387x series : 80,000 pages
		•	M407x series : 100,000 pages

2-2

2. Product Specifications

2.1.2.2. Print

Item		Specification
Engine Speed	Simplex	•	M337x series
			• Up to 33 ppm in A4 (35 ppm in Letter)
		•	M387x series
			• Up to 38 ppm in A4 (40 ppm in Letter)
		•	M407x series
			• Up to 40 ppm in A4 (42 ppm in Letter)

	Duplex	•	M337x series
			• Up to 16 ipm in A4 (17 ipm in Letter)
		•	M387x series
			• Up to 19 ipm in A4 (20 ipm in Letter)
		•	M407x series
			• Up to 20 ipm in A4 (21 ipm in Letter)

FPOT	Ready Mode	As fast as 6.5 sec

	Sleep Mode	• M337x series : Less than 15.5 sec
		• M387x/407x series : Less than 18 sec

Resolution	Optical (Standard)	600 x 600 dpi

	Enhanced	Up to 1,200 x 1,200 dpi effective output

Emulation		PostScript3, PCL6/5e, IBM ProPrinter, EPSON, SPL

2-3	Copyright© 1995-2013 SAMSUNG. All rights reserved.

2. Product Specifications

2.1.2.3. Copier

Item		Specification
Copy Speed	SDMC (SDMC: Single	[Simplex to Simplex (1-1)]
	Document Multiple Copy)	•	M337x series
			• Up to 33 cpm in A4 (35 cpm in Letter)
		•	M387x series
			• Up to 38 cpm in A4 (40 cpm in Letter)
		•	M407x series
			• Up to 40 cpm in A4 (42 cpm in Letter)

FCOT	From Ready @Platen	Less than 10 sec

Resolution (ADF)	Text mode	• Scan : 600 x 600 dpi
		• Print : 600 x 600 x 2 bit dpi

	Text & Printed Photo	• Scan : 600 x 600 dpi
	mode	• Print : 600 x 600 x 2 bit dpi

	Glossy Photo mode	• Scan : 600 x 600 dpi
		• Print : 600 x 600 x 2 bit dpi

Resolution (Platen)	Text mode	• Scan : 600 x 600 dpi
		• Print : 600 x 600 x 2 bit dpi

	Text & Printed Photo	• Scan : 600 x 600 dpi
	mode	• Print : 600 x 600 x 2 bit dpi

	Glossy Photo mode	• Scan : 1200 x 1200 dpi
		• Print : 1200 x 1200 x 1bit - Addressable

Copier Features	Duplex Copy	• M337xFD / M387xFD / M4072FD : 1–to–2
		• M387xFW / M407xFR / M407xFX : 2-to-1, 2-to-2, 1-to-2

	Reduce/Enlarge	25 to 400% by 1%unit

	ID Card Copy	Yes

	N-up	2,4

	Darkness Adjustment	11 levels

	Multicopy Quanity	Max 99 copies

2-4

2. Product Specifications

2.1.2.4. Scanner

Item		Specification
Scan Method		3 CH CIS

Compatibility		TWAIN Standard, WIA Standard

Scan Speed	B/W	24 ipm @300 dpi

	Gray	24 ipm @300 dpi

	Color	8 ipm @300 dpi

Resolution	Platen (Optical)	600 x 600 dpi

	(D)ADF (Optical)	600 x 600 dpi

	Max Resolution@Scan to	4800 x 4800 dpi
	Local Host

Scanning Size ((D)ADF)	Max. Document Width	216 mm [8 1/2"]

	Effective Scan Width	208 mm [8.19"]

	Max. Document Length	356 mm [14']

	Effective Scan Length	348 mm [13.7"]

Scanning Size (Platen)	Max. Document Width	216 mm [8 1/2"]

	Effective Scan Width	208 mm [8.19"]

	Max. Document Length	297 mm [11.7"]

	Effective Scan Length	289 mm [11.37"]

Scan to		PC, Email, USB Memory, FTP, SMB

Scan File Format		PDF, JPEG, XPS, TIFF

2-5	Copyright© 1995-2013 SAMSUNG. All rights reserved.

2. Product Specifications

2.1.2.5. Fax

Item		Specification
Compatibility		ITU-T G3, ECM

Compression Method		MH/MR/MMR,JBIG,JPEG

Modem Speed		33.6 Kbps

Transmission Speed		3sec @336 Kbps

Gray Scale / Halftones		256 levels

Resolution	Standard	203 x 98 dpi

	Fine/Photo	203 x 196 dpi

	Super Fine	300 x 300 dpi

Fax Memory		6 MB

Max Document Width		216 mm [8 1/2"]

Max Document Length		356 mm [14']

2-6

2. Product Specifications

2.1.2.6. Controller and Software

Item		Specification
Processor		• M337x series / M387x series / M407xFR / M4072FD : 600
			MHz
		• M407xFX : 600 MHz + 1GHz

Memory	Standard	• M337xFD/ M387xFD/ M387xFW/ M407xFR/ M4072FD
			: 256 MB
		•	M407xFX : 1 GB

	Max	• M337xFD/ M387xFD/ M387xFW/ M407xFR / M4072FD
			: 512 MB
		•	M407xFX : 1 GB

Driver	Supporting OS	[Window]
		• XP (32 / 64 bit) / 2003 Server (32/64 bit) / Vista (32/64 bit)
			/ 2008 server (32/64 bit) / 7 (32/64 bit) / 2008 Server R2 / 8
			(32/64bit)

		[Mac]
		• X 10.5 ~ 10.8

		[Linux]
		• RedHat Enterprise WS 4, 5, 6 (32/64 bit)
		• Fedora 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 (32/64 bit)
		• OpenSuSE 10.2, 10.3, 11.0, 11.1, 11.2, 11.3, 11.4 (32/64 bit)
		• SuSE Linux Enterprise Desktop 10, 11 (32/64 bit)
		• Debian 4.0, 5.0, 6.0 (32/64 bit)
		• Mandriva 2007, 2008, 2009, 2009.1, 2010 (32/64 bit)
		• Ubuntu 6.06, 6.10, 7.04, 7.10, 8.04, 8.10, 9.04, 9.10, 10.04,
			10.10, 11.04 (32/64 bit)

		[Unix]
		• HP-UX 11.0, 11i v1, 11i v2, 11i v3 (PA-RISC, Itanium)
		• Sun Solaris 9, 10, 11 (x86, SPARC)

Network Protocols		[TCP/IP]
		• TCP/IPv4/IPv6, HTTP, SNMPv1/v2c/v3, SMTP, IPSec,
			DNS/WINS, DDNS, DHCP, SSL/TLS, BOOTP, AutoIP,
			Standard TCP/IP printing, LPR, IPP,UPnP(SSDP), Bonjour,
			Telnet, WSD, SLP, SetIP
		[Others]
		• HTTPs,IPPs, 802.1x(EAP-MD5, EAP-MSCHAPv2, PEAP,
			TLS), IPSec

2-7	Copyright© 1995-2013 SAMSUNG. All rights reserved.

2. Product Specifications

Item	Specification
Interface	•	High-Speed USB 2.0
	•	Ethernet
		• M337xFD / M387xFD / M387xFW ; 10/100 Base TX
		• M407xFR / M407xFX : 10/100/1000 Base TX
	•	Wireless Network
		• ProXpress M382xDW Only : 802.11b/g/n
	•	LCD
		• 4–line LCD : M337xFD / M387xFD / M387xFW /
		407xFR /4072FD
		• 4.3 inch Touch LCD : M407xFX

Software and Application	•	Admin Deployment Application
	•	Easy Printer Manager

2-8

2. Product Specifications

2.1.2.7. Paper Handling

Item			Specification
			•	M337x series
				• 250-sheet Cassette Tray @80g/m²
Standard Capacity				• 1–sheet Manual Feeder
Standard Capacity			•	M387x/ M407x series
			•	M387x/ M407x series
				• 250-sheet Cassette Tray @80g/m²
				• 50–sheet Multi Purpose Tray @80g/m²

			•	M337x series
Max. Capacity				• 771 sheet (@80g/m² ) with option cassette
Max. Capacity			•	M387x/ M407x series
			•	M387x/ M407x series
				• 820 sheet (@80g/m² ) with option cassette

Printing			•	Max. Size : 216 x 356 mm (8.5" x 14")
Printing			•	Min. Size : 76 x 127 mm (3.0" x 5.0")
			•	Min. Size : 76 x 127 mm (3.0" x 5.0")

		Capacity	• Plain Paper : 50 sheets @ 80g/m²
		Capacity	•	Envelop : 5 sheets
Multi-purpose tray			•	Envelop : 5 sheets

		Media sizes	A4, A5, A6, Letter, Legal, Folio, Oficio, Executive, ISO B5, JIS B5,

			3"x5", Envelope (Monarch, No.10, DL, C5, C6), Custom
	NOTE


		Media type	Plain, Thin, Thick, Thicker, Cotton, Colored, Envelope, Transparency,

	M387x/ M407x series		Pre-Printed, Recycled, Labels, Bond, Card stock, Archive
	M387x/ M407x series		Pre-Printed, Recycled, Labels, Bond, Card stock, Archive
		Media weight	16~58 lb (60 to 220 g/m²)

		Sensing	Paper Empty

		Capacity	250 sheets @ 80 g/m²

		Media sizes	A4, A5, A6, Letter, Legal, Folio, Oficio, Executive, ISO B5, JIS B5,
		Media sizes	Custom
Standard Cassette Tray			Custom

		Media types	Plain Paper, Thin, Thick, Recycled, Bond, Cardstock, Archive
		Media types

		Media weight	16~43 lb (60 to 163 g/m²)

		Sensing	Paper Empty

		Capacity	520 sheets @ 80 g/m²

		Media sizes	A4, A5, A6, Letter, Legal, Folio, Oficio, Executive, ISO B5, JIS B5

Optional Cassette Tray		Media types	Plain Paper, Thin, Thick, Recycled, Bond, Cardstock, Archive

		Media weight	16~43 lb (60 to 163 g/m²)

		Sensing	CST Open, Paper Empty

		Capacity	• Face-Down : 150 sheets @ 80 g/m²
Output Stacking		Capacity	•	Face-Up : 1 sheet
Output Stacking			•	Face-Up : 1 sheet
		Output Full sensing	Yes

		Supporting	Built-in

Duplex		Media sizes	A4, Letter, Oficio, Folio, Legal

		Media types	Plain Paper, Thin, Thick, Recycled, Bond
		Media types	Plain Paper, Thin, Thick, Recycled, Bond

		Media weight	16~32 lb (60 to 120 g/m²)

2-9	Copyright© 1995-2013 SAMSUNG. All rights reserved.

2. Product Specifications

Item		Specification
	Capacity	50 sheet @80g/m²

ADF	Document Weight	12.5~28lb

	Document Size	• Width: 142 ~ 216 mm (5.6" ~ 8.5")
	Document Size	• Width: 142 ~ 216 mm (5.6" ~ 8.5")
		• Length : 148 ~ 356 mm (5.8" ~ 14.0")

		• Envelop : 10 mm (0.4") from edge (Top, Bottom, Left, Right)
Printable Area	Non-Printable Area	• Other Media : 4 mm (0.16") from edge (Top, Bottom, Left,
		Right)

2-10

2. Product Specifications

2.1.2.8. Consumables

NOTE

M337x/ M387x/ M407x series have 2 types of consumable depending on model.

•Integrated Toner System : M3370FD / M3870FD/ M3870FW / M4070FW / M4070FX / M4072FD

•Separated Toner System : M3375FD / M3875FD/ M3875FW / M4075FW / M4075FX

Integrated Toner System

				M3870FD	M4070FR
Item	Model Name	Average yield	M3370FD	M3870FD	M4070FX
Item	Model Name	Average yield	M3370FD	M3870FW	M4070FX
				M3870FW	M4072FD
					M4072FD
Laser Toner	MLT-D203S	Approx. 3,000 pages	O	O	O
Cartridge
Cartridge	MLT-D203L	Approx. 5,000 pages	O	O	O
	MLT-D203L	Approx. 5,000 pages	O	O	O

	MLT-D203E	Approx. 10,000 pages	X	O	O

	MLT-D203U	Approx. 15,000 pages	X	X	O

NOTE

•The yield of initial toner cartridge is approx. 3,000 pages.

•Declared cartridge yield in accordance with ISO/IEC 19752.

Separated Toner System

Item	Model Name	Average yield	M3375FD	M3875FD	M4075FR
Item	Model Name	Average yield	M3375FD	M3875FW	M4075FX
				M3875FW	M4075FX
Toner Cartridge	MLT-D204S	Approx. 3,000 pages	O	O	O

	MLT-D204L	Approx. 5,000 pages	O	O	O

	MLT-D204E	Approx. 10,000 pages	X	O	O

	MLT-D204U	Approx. 15,000 pages	X	X	O

Imaging Unit	MLT-R204	Approx. 30,000 pages	O	O	O

NOTE

•The yield of initial toner cartridge is approx. 3,000 pages.

•Declared cartridge yield in accordance with ISO/IEC 19752.

CAUTION

When purchasing new toner cartridges or other supplies, these must be purchased in the same country as the machine you are using. Otherwise, new toner cartridges or other supplies will be incompatible with your machine due to different configurations of toner cartridges and other supplies according to the specific country conditions.

2-11	Copyright© 1995-2013 SAMSUNG. All rights reserved.

2. Product Specifications

2.1.2.9. Maintenance Part

Item	Part Code		Life
Pick up roller (Tray1)	JC73-00340A		Approx. 90,000 pages

Pick up / Forward roller (Tray2)	JC97-02259A		Approx. 200,000 pages

Reverse roller (Tray1)	JC90-01032A		Approx. 60,000 pages

Reverse roller (Tray2)	JC97-02259A		Approx. 100,000 pages

Transfer roller	JC66-02842A		Approx. 100,000 pages

Fuser Unit	•	JC91-01023A (110V)	Approx. 90,000 pages
	•	JC91-01024A (220V)

2-12

Samsung ProXpress M337x, ProXpress M387x, ProXpress 407x Service Manual

2. Product Specifications

2.2. Product Description

This chapter describes the functions and operating principal of the main component.

2.2.1. Front View

NOTE

•This illustration may differ from your machine depending on your model. There are various types of machine.

•Some features and optional goods may not be available depending on model or country

1	Document feeder cover
2	Document feeder width guide
3	Document feeder input tray
4	Document feeder support tray
5	Document feeder output tray
6	Control panel
7	Control board cover
8	Front cover
9	Paper level indicator
10	Tray 2
11	Tray 1
12	Multi-purpose (or manual feeder) tray
13	USB memory port

14	Output support tray
15	Output tray
16	Scanner glass
17	Scanner lid
18	Front cover handle
19	Paper width guides on a multipurpose (or manual
	feeder) tray
20	Multi-purpose support tray
21	Toner cartridge
	NOTE
	M3370 M3870 M4070 M4072FD series

2-13	Copyright© 1995-2013 SAMSUNG. All rights reserved.

			2. Product Specifications

22	Toner cartridge	23	Imaging unit

	NOTE		NOTE
	M3375 M3875 M4075 series		M3375 M3875 M4075 series


		24	Handset

			NOTE
			Handset model only

2-14

2. Product Specifications

2.2.2. Rear View

NOTE

•This illustration may differ from your machine depending on your model. There are various types of machine.

•Some features and optional goods may not be available depending on model or country

1	Rear cover
2	Network port
3	USB port
4	5V output port for IEEE 1284B parallel connector

		NOTE
		This optional IEEE 1284B parallel connector can be used by plugging in both the USB port and the
		5V output port.


5	Power-switch
6	Power receptacle
7	Telephone line socket (LINE)
8	Extension telephone socket (EXT.)

9	Rear cover handle

2-15	Copyright© 1995-2013 SAMSUNG. All rights reserved.

2. Product Specifications

2.2.3. Paper Path

The following diagram displays the path the paper follows during the printing process.

2-16

2. Product Specifications

2.2.4. System layout

This model consists of the Scanner part, Engine part, Hardware and Firmware. The scanner part consists of the platen unit, ADF/DADF unit, OPE unit. The engine part consists of the mechanical parts comprising Frame, Duplex, Toner cartridge, Drive unit, Transfer roller, Fuser, Cassette. The Hardware part consists of the main control board, power board, operation panel, PC Interface.

1	LSU	9	Fuser
2	Cartridge	10	Exit roller1
3	Regi roller	11	Exit roller2
4	MP	12	Scanner (Platen)
5	Feed roller	13	DADF/ADF
6	Pick up roller	14	OPE

7Cassette

8Duplex

2-17	Copyright© 1995-2013 SAMSUNG. All rights reserved.

2. Product Specifications

2.2.4.1. Feeding Part

It consists of a cassette, an MP tray for supplying different types of media (envelope, label, special paper) and parts related to paper feed initialization.

1) Cassette

The paper trays consist of the Main trays, Optional trays (SCF), and one Multi-Purpose (MP) tray. The basic cassette is located on front side of the machine and allows feeding of common paper. Paper size is set using the Size Guides in each tray. Adjust the Paper length/width guides to match the paper size.

2) Pick up / Reverse(Retard) roller

When pickup takes place, the pickup roller rotates to separate and transport the paper. The pickup roller rotates when the pickup clutch is activated. The retard roller serve to make sure that a single sheet of paper is moved to the paper path, and the paper is moved as far as the registration roller by the work of the feed roller. The following is a diagram of the pickup section :

3) Registration roller

It is used as an anti skew device, and to setup proper registration timing with that of the toned image on the drum. It also is used for jam detection to ensure paper has left the paper tray.

2-18

2. Product Specifications

4) MP Tray

The multi-purpose tray can hold special sizes and types of print material, such as postcards, note cards, and envelopes. It is useful for single page printing on letterhead or colored paper. It uses 3 rollers feeding method to feed 50 sheets of general papers.

5) Duplex Unit

It has paper transferring function, paper guide function, jam removing function. It is designed for basic attachment, and the duplex feeding takes a side feeding method. Usable papers are A4, letter, and legal size paper. For removing a jam occurred in a front part, it is designed to open a cassette and a guide. It is designed to open a rear cover to remove a jam in a rear part. If a face up tray is open, the duplex option cannot be used.

6) SCF (Second Cassette Feeder)

It is the same method with the main cassette, and the capacity is 520 sheets. It has a separate driving mechanism. It is designed for a common use with a main cassette.

2-19	Copyright© 1995-2013 SAMSUNG. All rights reserved.
