20-566.fm Page 1 Thursday, August 5, 1999 8:04 AM
OWNER’S MANUAL
50-Channel Portable Scanner
Cat. No. 20-566
PRO-72
Please read before using this equipment.
20-566.fm Page 2 Thursday, August 5, 1999 8:04 AM
FEATURES
Your new RadioShack PRO-72 50-Channel Portable
Scanner gives you direct access to over 32,000 exciting
frequencies, including police and fire depa rtments, ambulance services, and amateur radio services. You can select up to 50 channels to scan, and you can change your
selection at any time.
The secret to your scanner’s ability to scan so many frequencies is it s custom-d esi gned micro pro cessor — a tiny,
built-in computer.
Your scanner has these spec ial features:
Ten Preprogrammed Search Bands
— let you search
for transmissions within preset frequency ranges, so you
can find intere sting frequencies more quickly.
Ten Preprogrammed Weather Frequencies
— keep
you informed about cur rent weather conditions.
HyperScan
and HyperSearch
™
™
—
so you can scan up
to 25 channels per second and search up to 50 steps per
second.
Fifty Channels
— let you store up to 50 of your favorite
frequencies for easy recall and scanning.
Duplicate Frequenc y Check
— automatically warns you
if you try to store a frequency you’ve already stored, to
help you use the scanner’ s mem ory more efficiently.
Monitor Memory
— lets you temporarily save a frequency located during a direct search, so you can move it to
channel storage later.
©
1997 Tandy Corporation.
RadioShack, HyperScan, and HyperSearch are trademarks
All Rights Reserved.
used by Tandy Corporation.
2
20-566.fm Page 3 Thursday, August 5, 1999 8:04 AM
Channel Lockout — k eeps channels you select from being scanned.
Memory Backup — keeps the channel frequencies
stored in memory for about 1 hour during a power loss.
Two-Second Scan Delay — delays scanning for 2 seconds before moving to another channel, so you can hear
more replies.
Key Lock — lets you lock the keys to help prevent accidentally changing the scanner’s program ming.
Flexible Antenna with BNC Connector — provides excellent rece ption. The BNC conne cto r makes it easy to attach and remove the antenna or a variety of optional
antennas.
Liquid Crystal Display — clearly displays how the scanner is set and makes it easy to change those settings.
Display Backlight — makes the scanner’s display easy
to read in low-light situations.
Three Power Options — you can power the scanner
from int ernal b atter ies (n ot suppl ied – including n onrechargeable batteries, rechargeable batteries, or a rechargeable scanner battery pack) or external AC or DC
power (using optional adapters).
We recommend you record your scanner’s serial number
here. This number is on the scanner’s back panel.
Serial Number:
3
20-566.fm Page 4 Thursday, August 5, 1999 8:04 AM
Your PRO-72 scanner can receive all of these frequencies:
• 29–54 MHz (10-Meter Amateur Radio, VHF Lo, 6-
Meter Amateur Radio)
• 137–174 MHz (Aircraft/Air Shows, Government, 2-
Meter Amateur Radio, VHF Hi)
• 380–512 MHz (Military Aircraft, UHF Lo, 70-Centime-
ter Amateur Radio, UHF “T” Band, Government)
• 806–824 MHz (UHF Public Service, Trunked Ser-
vices)
• 849–869 MHz (UHF Hi, Trunked Services)
• 894–960 MHz (UHF Hi, 33-Centimeter Amateur
Radio, Trunked Services)
For a list of the frequency ranges in the ten preprogrammed search ba nds, see “Sea rch Bands” on Pa ge 24.
In addition, your scanner is preprogrammed with the following weather service frequencies:
• 161.6500 MHz
• 161.7750 MHz
• 162.4000 MHz
• 162.4250 MHz
• 162.4500 MHz
• 162.4750 MHz
• 162.5000 MHz
• 162.5250 MHz
• 162.5500 MHz
• 163.2750 MHz
4
20-566.fm Page 5 Thursday, August 5, 1999 8:04 AM
FCC NOTICE
Your scanner might cause TV or radio interference even
when it is operating properly. To determine whether your
scanner is causin g the inte rfere nce, turn off your scanne r.
If the interference goes away, your scanner is causing
the interference. Try to eliminate the interference by:
• Moving your scanner away from the TV or radio
• Connecting your scanner to an outlet that is on a different electrical circuit from the TV or radio
• Contacting your local RadioShack store for hel p
This device complies with Part 15 of the
eration is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired oper ation.
FCC Rules
. Op-
5
20-566.fm Page 6 Thursday, August 5, 1999 8:04 AM
SCANNING LEGALLY
Your scanner covers frequencies used by many different
groups including police and fire departments, ambulance
services, gover nment agencies, private companies, amateur radio services, military operations, pager services,
and wireline (telephone and telegraph) service providers.
It is legal to listen to almost ever y trans missio n your scanner can receive. However, there are some transmissions
you should never intentionally lis ten to. These include:
• Telephone conversations (either cellular, cordless, or
other private mean s of t elephone signal transm ission)
• Pager transmissions
• Any scrambled or encrypted transmissions
According to the Electronic Communications Privacy Act
(ECPA), you are subject to fines and possible imprisonment for intentionally listening to, using, or divulging the
contents of such a transmission unless you have t he consent of a party to the communication (unless such activi ty
is otherwise illegal). We encourage responsible, legal
scanner use.
6
20-566.fm Page 7 Thursday, August 5, 1999 8:04 AM
CONTENTS
Preparation ....................... ... .. ....... ... .. ........ .. ... ............. 9
Power S ou r ce s .... .. ........ .. ... ....... .. ... ....... ... .. ....... ... . 9
Using Batteries ............................................... 9
Using Standard AC Power .......... .................. 12
Using Vehicle Battery Power ........................ 13
Charging a Rechargeabl e Battery Pack ....... 14
Connecting the Antenna ...................................... 15
Connecting an Optio nal Antenna .................. 16
Connecting an Earphone/Headphones ................ 16
Listening Safely ............................................ 17
Traffic Safety ................................................. 17
Connecting an Extension Speaker ...................... 18
Using the Belt Clip ............................................... 18
Your Scanner ............................................................. 19
A Look at the Keypad ........ .. ...................... .......... 20
A Look at the Display ........... .. ...................... ........ 22
Understanding Bands/Monitor Memory ............... 24
Search Bands ........................ ....................... 24
Monitor Memory ............................................ 25
Operation ............................... ... .. ....... ... .. ........ .. .. ....... 26
Turning On the Scanner/
Setting Volume and Squelch ......... ...................... . 26
Storing Active Frequencies .................................. 27
Manually Storing Frequencies .............. .. ...... 27
Band Search ............... .. ...................... .......... 29
Direct Search ................................................ 31
Moving a Frequency from the Monitor Memory
to a Channel ........................................................ 32
Monitoring a Stored Channel .............. ................. 32
Scanning the Channels ........................................ 33
Listening to the Monitor Memory ......................... 34
Clearing a Channel ......... .. ....................................34
Listening to a Weat her Band ............. ............ ...... 35
7
20-566.fm Page 8 Thursday, August 5, 1999 8:04 AM
Spec ia l F e at u re s .................. ... .. ....... ... .. ........ .. ... ....... 36
Delay ...... .. ... ....... ... .. ............... .. .. ........ .. ... ....... .. ... 36
Locking Out a Channel . ....................................... 36
Using the Display Backlight ................................. 37
Turning the Key Tone On and Off ........................ 38
Using the Keylock ................................................ 38
A General Guide to Scanning ................................... 39
Guide to Frequencies .......................................... 39
US Weather Frequencies ............................. 39
Other Weather Frequencies ......................... 39
Ham Radio Frequencies ............................... 39
Birdie Frequencies ............. ...................... .... 40
Guide to the Action Bands ................................... 41
United States Broadcast Bands ............. ...... 41
Typical Band Usage ......... ............ ............ .....41
Primary Usage .............................................. 42
Spec ifi ed In te r va ls ... ...................... .. ... ....... ... .. ..... 43
Band Allocation .................................................... 43
Frequency Conversion ........................................ 47
Troubleshooting ........................................................ 48
Resetting/Initializing the Scanner ........................ 50
Resetting the Scanner .................................. 50
Initializing the Scanner ................................. 51
Care and Maintenance .............................................. 52
Spec if ic a ti on s ........ .. ............... .. ... ....... .. ... ....... ... .. ..... 54
8
20-566.fm Page 9 Thursday, August 5, 1999 8:04 AM
PREPARATION
POWER SOURCES
You can power your scanner from any of four sources:
• Internal batteries (not supplied) with the provided
battery holder
• A rechargeable scanner battery pack (not suppl ied)
• Standard AC power (using an optional AC adapter)
• Vehicle battery power (using an optional DC cigarette-
lighter adapter)
Notes:
• Connecting an AC or DC adapter to the scanner dis-
connects any internal batteries, but it does not disconnect a rechargeable battery pack. If you install a
rechargeable battery pack, you can operate the
scanner and recharge the battery pack at the same
time. See “Using Batteries” below and “Charging a
Rechargeable Battery Pack” on Page 14.
• If the scanner stops working properly after you con-
nect it to p ower, try resetting it. See “Resetting/Initializing the Scanner” on Page50.
Using Batteries
You can power your s canner fro m six AA batte ries. For the
longest operation and best performance, we recommend
alkaline batteries, such as RadioShack Cat. No. 23-552.
You can also power the scanner using a rechargeable
scanner battery pack, such as Cat. No. 23-288, and recharge it as you use the scanner.
9
20-566 .fm Page 10 Thurs day, August 5, 1999 8:04 AM
You can also use six rechar geable nick el-cadmium bat teries (such as Cat. No. 23-125) to power the scanner. To
charge or recharge nickel-cadmium batteries, however,
you must remove them from the scanner and use an external charger (such as Cat. No. 23-134).
Note: If you are using a rechargeable scanner battery
pack, you must char ge it bef ore you ca n use y our scan ner
(see “Charging a Rechargeable Battery Pack” on
Page 14).
Caution: Do not mi x old and new batt erie s, differ ent types
of batteries (standard, alkaline, or rechargeable), or rechargeable batt eri es of different capacit ies.
Follow these steps to install batteries or a battery pack.
1. Press down on the battery com partment cover on the
bottom of the scanner and slide the cover in the
direction of the arr ow to r em ove it.
2. Slide the battery holder out of the battery compartment.
10
20-566 .fm Page 11 Thurs day, August 5, 1999 8:04 AM
3. If you are installing individual batteries, insert six AA
batteries in the battery holder as indicated by the
polarity symbols (+ and –) marked on the battery
holder.
4. Slide the battery holder or battery pack into the compartment as shown.
Caution: The battery holder or battery pack fits only
one way inside the battery compartment. Do not
force it.
5. Replace the cover.
When battery power is l ow,
flashes and t he scanner
BATT
beeps about every 3 seconds. Immediat ely replace all six
non-rechargeable batteries, remove and recharge all six
rechargeable bat teries, or recharge the battery pack.
Caution: Always dispose of old batteries promptly and
properly. Do not bury or burn them.
11
20-566 .fm Page 12 Thurs day, August 5, 1999 8:04 AM
Using Standard AC Power
To power the scanner from AC power, you need an AC
adapter (Cat. No. 273-1665).
Cautions:
• You must use an AC adapter tha t supplies 9 volts and
delivers at least 200 milliamps. Its center tip must be
set to negative, and its barrel plug must correctly fit
the scanner’s
adapter meets these specifications. Using an adapter
that does not meet these speci fications cou ld damage
the scanner or the adapter.
• When you finish using the AC adapter, disconnect it
from the AC outlet first. Then disconnect it from the
scanner.
Plug the adapter ’s 1.3 mm in ner diameter /3.4 mm o uter diameter barrel plug into the scanner’s
Then plug the adapt er’s p ower mod ule into a s tand ard AC
outlet.
PWR/DC 9V
jack. The recommended
PWR/DC 9V
jack.
PWR/DC 9V
Warning:
Do not use an AC adapter’s po lar ized plug with
an extension cord, receptacle, or other outlet unless the
blades can be fully inserted to prevent blade exposure.
12
20-566 .fm Page 13 Thurs day, August 5, 1999 8:04 AM
Using Vehicle B attery Power
To power the scanner from your vehicle’s cigarette-li ghter
socket, you need a DC adapter (Cat. No. 270-1560).
Cautions:
• You must use a DC adapter that supplies 9 volts and
delivers at least 200 milliamps. Its center tip must be
set to negative, and its plug must correctly fit the
scanner’s
adapter meets these specifications. Using an
adapter that does not meet these specifications
could damage the scanner or the adapter .
• To protect your vehicle’s electrical system, always
plug the adapter into the scanner before you plug it
into your vehicle’s cigarette-lighter socket. Always
unplug the adapter from the vehicle’s cigarettelighter socket before you unplug it from the sca nner.
PWR/DC 9V
jack. The recommended
4
3
2
1
1. Connect the DC adapter’s supplied 1.3 mm inner
diameter/3.4 mm outer diameter barrel plug to the
cable, with the tip set to – (negative).
2. Set the adapter’s volta ge switch to
3. Insert the barrel plug into the scanner’s
9V
.
PWR/DC 9V
jack.
4. Plug the other end of the adapter into your vehicle’s
cigarette-lighter socket.
13
20-566 .fm Page 14 Thurs day, August 5, 1999 8:04 AM
Notes:
• Mobile use of this scanner is unlawful or requires a
permit in some areas. Check the laws in your area.
• If the scanner does not operate properly when you
connect a DC adapter, unplug the adapter from the
cigarette-lighter socket and clean the socket to
remove ashes and other debris.
Charg ing a R echarge ab l e B attery Pac k
Your scanner has a built-in charging circuit that lets you
charge a rechargeable battery pack (Cat. No. 23-288)
while it is in the scanner . To charge the battery pack, simply connect an AC or DC adapt er to the sc anner’s
jack.
9V
It takes about 14–1 6 hour s to re char ge a batt ery pac k t hat
is fully discharged. You can oper ate the scanner whil e recharging the batt ery pack, but charging t akes longer.
PWR/DC
Notes:
• If you want to take the battery pack out of the scanner to charge it, follow the instructions in “Using Batteries” on Page 9 to remove it, then follow the
instructions provided with the battery pack to charge
it.
• A rechargeable battery pack lasts longer if you let it
fully discharge once a month. To do this, simply use
the scanner until
flashes and the scanner
BATT
beeps about every 3 seconds. Then fully charge the
battery pack.
14
20-566 .fm Page 15 Thurs day, August 5, 1999 8:04 AM
Important! At the end of a rechargeabl e battery pack’s
useful life, it must be recycled or dis posed of properly.
Contact your local, county, or state hazardous waste
management authori ties for information on recycl ing or
disposal programs in your area. Some options that might
be available are: mun icipa l cu rb-side colle ction, dro p- off
boxes at retailers such as your local RadioSha ck store,
recycling col lection centers, and m a il back programs.
CONNECTING THE ANTENNA
Follow these steps to attach the supplied flexible antenna
to your scanner.
1. Align the slots around the antenna’s connector with
the tabs on the
2. Press the antenna down over the jack and turn the
antenna’s base clockwise until it lock s into place.
ANT
jack.
15
20-566 .fm Page 16 Thurs day, August 5, 1999 8:04 AM
Connecting an Optional Antenna
ANT
The
use the scanner wit h a variety of antennas. Instead of the
supplied antenn a, you can attach a different one, such as
an external mobile antenna or outdoor base station ant enna. Your local RadioShack store sells a variety of antennas.
Always use 50-ohm coaxial cable, such as RG-58 or RG8, to connect an outdoor antenna. For lengths over 50
feet, use RG- 8 low- loss d ielec tric co axial cable. If you r antenna’s cable does not have a BNC connector, you will
also need a BNC adapter (also ava il able at your local RadioShack store).
Follow the ins tallation ins tructio ns supplied wi th the ant enna, route the antenna cable to the scanner, then connect
it to the
jack on the top of the scanner makes it easy to
ANT
jack.
Warning:
ing an outdoor base station antenna. If the antenna starts
to fall, let it go ! It could contact over head power lines. If the
antenna touches a power line, contact with the antenna,
mast, cable or guy wires can cause electrocution and
death! Call the p ower company to remove th e antenna . Do
not attempt to do so yourself.
Use extreme caution when installing or remov-
CONNECTING AN EARPHONE/
HEADPHONES
For private listening, you can plug an earphone or mono
headphones (available at your local RadioShack store)
1
with a
ner. This disconnects the internal speaker.
16
/8-inch plug into the jack on top of your scan-
20-566 .fm Page 17 Thurs day, August 5, 1999 8:04 AM
Listening Safely
To protect your hearin g, foll ow these gui deli nes when you
use an earphone or headphones:
• Do not listen at extremely high volume levels.
Extended high-volume listening can lead to permanent hearing loss.
• Set the volume to the lowest setting before you begin
listening. After you begin listening, adjust the volume
to a comfortable level.
• Once you set the volume, do not increase it. Over
time, your ears adapt to the volume level, so a volume level that does not cause discomfort might still
damage your hearing.
Traffic Safety
Do not use an earphone or headph ones with your sca nner
when operating a motor vehicle or riding a bicycle in or
near traffic. Doing s o can c reate a traff ic haz ard and could
be illegal in some areas.
If you use an earphone or headp hones with your scanner
while riding a bicycle, be very careful. Do not listen to a
continuous broadcast. Even though some earphones/
headphones let you hear some outside sounds when listening at normal volume levels, they still can present a
traffic hazard.
17
20-566 .fm Page 18 Thurs day, August 5, 1999 8:04 AM
CONNECTING AN EXTENSION
SPEAKER
In a noisy area, an extension speak er (Cat. No. 21-549) or
an amplified speaker (Cat. No. 21-541) might provide
more comfortable l istening.
Plug the speaker cable’s
jack.
1
/8-inch plug into your scanner’s
USING THE BELT CLIP
You can use the belt clip for hands-fr ee carrying when you
are on the go. Simply slide the belt clip over your belt or
waistband.
18
Belt Clip
20-566 .fm Page 19 Thurs day, August 5, 1999 8:04 AM
YOUR SCANNER
Once you understand a few simple terms we use in this
manual and familiarize yourself with your scanner’s features, you ca n put th e sca nner to work for you . You si mply
determine the communications you want to receive, then
set the scanner to scan those frequencies.
frequency
A
in kHz or MHz). To find active frequencies, you can use
search
the
ranges of frequenc ies.
When you find a frequency, you can store it into a permanent memory location called a
scan
the channels to see i f there is act ivity on the f requencies stored there. Each time the scanner finds an active
frequency, it stays on that channel until the transmission
ends.
Another option is to store the frequency into a temporary
memory location called a
cide to move it to a channel.
is the tuning location of a station (expressed
function to search
bands
, which are preset
channel
moni tor m em ory
. You can then
until you de-
Just keep in mind — you
channels.
search
frequencies and
scan
19
20-566 .fm Page 20 Thurs day, August 5, 1999 8:04 AM
A LOOK AT THE KEYPAD
Your scanner’ s keys mi ght s eem c onf using at fi rst, but this
information should help you understand each key’s function.
WX
— scans through the preprogrammed weather chan-
nels.
BAND
— selects a preprogrammed search band.
SCAN
— scans through the programmed channels.
MANUAL
— stops scanning to let you directly enter a
channel number.
/ — searches down or up from the currently displayed frequency, or selects the direction when you scan
channels.
CLEAR
— clears an incorrect entry.
PGM
— lets you program frequencies into channels.
20
20-566 .fm Page 21 Thurs day, August 5, 1999 8:04 AM
— locks/unlock s the ke ypad to preve nt accident al en-
tries.
LIGHT
— turns on/off the dis play’s backlight .
Number Keys
— use these keys to enter the numbers for
a channel or frequency.
0
MON/
— enters a zero or accesses the monitor memory.
DLY/
(delay/dec imal p oint) — p rog rams a 2-s econd de lay
•
for the sel ected cha nnel, or ent er s a dec imal po in t (nec essary when programming fr equencies).
L-OUT/E
(lockout/enter) — locks out channels so they will
not be scanned, or enters fr equencies into channel s.
21
20-566 .fm Page 22 Thurs day, August 5, 1999 8:04 AM
A LOOK AT THE DISPLAY
The display has indicat ors that show t he scanner’s cur rent
operation .
— appears when you manually select a channel.
MAN
— appears when you scan channels.
SCAN
— appears when you scan or m anually search t he pre-
WX
programmed weather channels.
— appears when you listen to the monitor memory.
MON
— appears when battery power is low.
BATT
— appears when you manually select a channel you
L/O
locked out.
— appears during a band or direct frequency
SRCH
search.
or — indicates the search or scan direction.
DELAY
for a channel.
PGM
scanner’s channels.
22
— appears when you program a 2-second delay
— appears while you program frequencies into the
20-566 .fm Page 23 Thurs day, August 5, 1999 8:04 AM
— appears when you lock the keypad.
— appears after the digits (1–50) that show which
ch
channel the scanner is tuned to.
— appears during a direct frequency search.
–d
000.0000
which frequency t he scanner is tuned to.
Error
dUPL
quency that is already stored in another channel.
— the digits on the right of the display show
— appears when you make an entry error.
(duplicate) — appears when you try to store a fre-
23
20-566 .fm Page 24 Thurs day, August 5, 1999 8:04 AM
UNDERSTANDING BANDS/MONITOR
MEMORY
Search Bands
Your scanner can tune over 32,000 different frequencies.
Many of these frequenci es are grouped within permanent
memory locations called search bands.
Displayed
Band
Search
Range
(MHz)
Description
0
1
2
3
4
5
6
7
8
9
Note:
849
tune any frequencies between 824
894 MHz, to help prevent reception of transmissions you
should not listen to. For more information, see “Scanning
Legally” on Page 6.
24
29–50
50–54
137–144
144–148
148–174
380–420
420–450
450–470
470–512
806–960
The actual searc h range of Band 9 is 806
–
869 MHz, and 894–960 MHz. The scanner does not
10-Meter Amateur Radio, VHF Lo
6-Meter Amateur Radio
Aircraft/Air Shows, Government
2-Meter Amateur Radio
VHF Hi
Government
70-Centimeter Amateur Radio
UHF Lo
UHF “T” Band
UHF Hi
–
824 MHz,
–
849 MHz and 869
–
20-566 .fm Page 25 Thurs day, August 5, 1999 8:04 AM
You can s ea rch t he se ban ds to qui ckly f ind act ive f reque ncies you might want to store into the scanner’s channels.
For exam ple, if you wa nt ed to s ea rch f or tran smi ss ions b etween amat eur radio oper ators, you could search onl y the
search bands where you are most likely to hear the transmissions (Bands 0, 1, 3, and 6). See “Band Search” on
Page 29 .
Note: The frequencies in the scanner’s search bands are
preset. You cannot change them.
Monitor Memory
The scanner also has a moni tor memory that you can use
to temporarily st or e a frequ ency whil e you d ecide whet her
to save it into a channel. This is handy for quickly storing
an active frequency when you are searching through an
entire band using direct search. See “Direct Search” on
Page 31.
25
OFF
MAX
MIN
MAX
VOLUME
SQUELCH
OFF
MAX
MIN
MAX
VOLUME
SQUELCH
20-566 .fm Page 26 Thurs day, August 5, 1999 8:04 AM
OPERATION
TURNING ON THE SCANNER/
SETTING VOLUME AND SQUELCH
Note:
Make sure the scanner’s antenna is connected be-
fore you turn it on.
1. Turn
2. Turn
SQUELCH
VOLUME
fully counterclockwise.
clockwise until it clicks and you hear a
hissing sound.
3. Turn
SQUELCH
clockwise until the hissing sound
stops.
Notes:
• If the scanner picks up unwanted, partial, or very
weak transmissions, turn
SQUELCH
clockwise to
decrease the scanner’ s sensitivity to these signals. If
you want to listen to a weak or distant station, turn
SQUELCH
SQUELCH
•If
counterclockwise.
is adjusted so you always hear a hissing
sound, the scanner does not scan properly.
26
20-566 .fm Page 27 Thurs day, August 5, 1999 8:04 AM
• If you have not stored frequencies into any channels
(see “Storing Active Frequencies” on Page 27), the
scanner does not scan.
STORING ACTIVE FREQUENCIES
You can manually store fr equencies yo u already k now into
the scanner’s channels. You can also store frequencies
you found using band search directly into channels. You
can also store a frequency into a monitor memory then
store it into a channel.
Good references for active frequencies are the RadioShack
Police Call Radio Guide Including Fire and Emergency
Services
Frequency Directory
year, so be sure to get a current copy.
If you do not have a refere nce to fr eque ncies i n your ar ea,
follow the steps in “Band Search” on Page 29 or “Direct
Search” on Page 31 to search for transmissions. See al so
“Guide to the Action Bands” on Page 41.
,
Aeronautical Frequency Direct ory
. We updat e these directorie s every
, and
Maritime
Manually Storing Frequencies
If you know a frequency you want to store, you can store
it manually.
1. Press
PGM
.
PGM
appears.
27
20-566 .fm Page 28 Thurs day, August 5, 1999 8:04 AM
2. Use the number keys to enter the channel number
where you want to store the frequency, then press
PGM
again. Or, repeatedly press
PGM
until the
desired channel number appears.
DLY/
3. Use the number keys and
to enter the fre-
•
quency (including the decimal point) you want to
store into that channel.
4. Press
E
to store the frequency.
Notes:
• If you entered an invalid frequency in Step 3,
Error
appears, the channel number flashes,
and the scanner beeps three times after you
E
press
. Simply repeat Steps 3 and 4.
• Your scanner automatically rounds the entered
frequency down to the nearest valid frequency.
For example, if you enter a frequency of
151.4730, your scanner accepts it as 151.4700.
• If you entered a frequency that is already stored
in another channel,
(duplicate) and the
dUPL
lowest-numbered channel containing the duplicate frequency flash for about 3 seco nds. To store
the frequency anyway, press
E
again.
5. Repeat Steps 2–4 to store more frequencies into
channels.
28
20-566 .fm Page 29 Thurs day, August 5, 1999 8:04 AM
Band Search
If you do not know of a f requency to st ore, yo u can sea rch
your scanner’s preprogrammed search bands (see
“Search Bands” on Page24) for active frequencies, then
store any that you find i nto your scanner’s channe ls.
Follow these steps to search for and store active frequencies using band searc h.
1. Press
BAND
. The last selected band number (b followed by the band number) and the frequency
search range appear for about 2 seconds.
2. To select a different band, within 2 seconds, enter
the band’s number (0–9) or repeatedly press
BAND
until the desired band number appears.
After about 2 seconds,
appears, the next
SRCH
available channel flashes, and the scanner begins
searching rapid ly upward in that band (fro m lowest to
highest frequency) for an active frequency.
29
20-566 .fm Page 30 Thurs day, August 5, 1999 8:04 AM
Notes:
• To reverse the search direction at any time, hold
down for about 1 second.
• To search the band upward or downward in small
increments (in steps of 5 or 12.5 kHz, depending
on the band), repeatedly press and release or
.
• To select a different band after the scanner begins
searching the cur rent band, simply repeat Step 2.
The scanner stops when it finds an act ive freq uency.
3. To store the displayed frequency in the channel currently flashing on the display, press
. The scanner
E
stores the frequency , then the next available channel
flashes.
Notes:
• You cannot store a frequency in the monitor mem-
ory during band search.
• After you store a frequency into the last available
channel,
number. If you try to store a channel while
appears, Ch
appears instead of a channel
--ch
appears briefly. In order to
FULL
--ch
store more frequencies, you must clear some
channels. See “Clea ring a Channel” on Page 34.
4. To search for another active frequency in the
selected band, hold down or for about 1 second.
30
20-566 .fm Page 31 Thurs day, August 5, 1999 8:04 AM
Direct Search
You can search up or down from the currently displayed
frequency and store the frequency into the monitor memory.
1. Press
and
MANUAL
DLY/
to enter the frequency where you want to
•
or
PGM
, then use the number keys
start the search.
Note:
T o st art fro m a frequency al read y stored in one
of your scanner’s channels, press
MANUAL
enter the desired channel number, then press
UAL
PGM
or
again.
or
PGM
MAN-
2. Hold down or for about 1 second to search up
or down from the selected frequency.
When the scanner finds an active frequency, it stops
searching.
3. To store the frequency in the monitor memory, simply
MON/0
press
.
appears on the display.
MON
,
4. To continue the search, hold down or for
about 1 second.
31
20-566 .fm Page 32 Thurs day, August 5, 1999 8:04 AM
MOVING A FREQUENCY FROM THE
MONITOR MEMORY TO A CHANNEL
1. Press
2. Press
3. Press
MANUAL
you want to store the frequency, then press
, the frequency num ber or
PGM
selected channel numb er appear.
MON
channel number flashes.
E
.
flashing, and the scanner stores the frequency in the
selected channel.
, enter the channel number where
000.0000,
.
and the frequency appear and the
MON
disappears, the channel number stops
MON
PGM
and the
MONITORING A STORED CHANNEL
You can continuously monitor a specific channel without
scanning. This is useful if you hear an emergency broadcast on a channel and do not want to miss any details —
even though there might be periods of sile nce — or if you
simply want to monitor that channel.
Follow these steps to manually select a channel.
1. Press
MANUAL
.
.
2. Enter the channel number.
3. Press
32
MANUAL
again.
20-566 .fm Page 33 Thurs day, August 5, 1999 8:04 AM
SCANNING THE CHANNELS
To begin scanning channels or to start scanning again after monitoring a specific channel, press
and appear, and the scanner begins to rapidly
SCAN
scan upward until it finds an active frequency.
If the scanner finds an active frequency, it stops and dis-
plays that c hannel and f requency number , then i t automa tically begins scanning again when the transmission ends
on that frequency .
Notes:
• You must store frequencies into channels before the
scanner can scan them (see “Storing Active Frequencies” on Page 27).
• To change the scanning direction, pre ss or .
• The scanner does not scan empty channels.
SCAN
.
33
20-566 .fm Page 34 Thurs day, August 5, 1999 8:04 AM
LISTENING TO THE MONITOR
MEMORY
To listen to the frequency stored in the monitor memory,
MANUAL
press
stored in the monitor memory appear.
then
MON
.
MAN, MON
, and the frequency
CLEARING A CHANNEL
1. Press
2. Use the number keys to enter the channel number
3. Press
4. Press
5. To delete more frequencies, repeat Step s 2–4.
34
MANUAL
containing the frequency you want to delete, then
PGM
press
desired channel number appears.
CLEAR
L-OUT
Channel” on Page36) appears, the channel number
flashes, and the frequency number changes to
000.0000
.
. Or, repeatedly press
PGM
. The frequency number flashes.
.
(lockout — see “Locking Out a
L/O
to indicate the frequency is cleared.
until the
PGM
appears.
20-566 .fm Page 35 Thurs day, August 5, 1999 8:04 AM
LISTENING TO A WEATHER BAND
The FCC (Federal Communications Commission) has allocated channels for use by the National Oceanic and Atmospheric Administration (NOAA). Regulatory agencies
in other countries have a ls o allocated channels for use by
their weather reporting authorities.
Your local weather reporting authority broadcast your local forecast and regional weather information on one or
more of these channels .
To hear your local forecast and regional weather information, simply press
weather band, and and
should stop within a few seconds on your local weather
broadcast.
WX
. Your scanner scans through the
appear. Your scanner
WX
If the broadcast is weak, press or to resume scanning.
To reverse the scanni ng direction, press or .
To manually select a specific preprogrammed weather
channel, repeatedly press
• Repeatedly press or to move forward or backward through the channels.
• Press the 1-digit number (0–9) of the channel you
want to listen to.
WX
until
appears, then:
MAN
35
20-566 .fm Page 36 Thurs day, August 5, 1999 8:04 AM
SPECIAL FEATURES
DELAY
Many agencies use a two-way radio system that might
have a pause of several seconds between a query and
a reply. To avoid missing a reply, you can program a
2-second delay into any of your scanner’s channels.
Then, when the scann er stops on the channel,
appears and the scan ner continu es to monitor the channel
for 2 seconds after the transmission stops before it resumes scanning.
You can program a 2-second delay in any of these ways:
• If the scanner is scanning and stops on an active
channel, quickly press
again.
• If the desired channel is not selected, manually select
the channel then press
• If the scanner is searching, press
search.
DELAY
second delay to every transmission it stops on.
appears and the scanner automatically adds a 2-
DLY
before it starts to scan
DLY
.
DLY
DELAY
during the
To turn off the d elay, pres s
DLY
when
DELAY
is display ed.
LOCKING OUT A CHANNEL
You can scan existing channels faster by locking out a
channel that has a continuous transmission, such as a
weather channel.
To lock out a c han nel, sel ect the cha nnel t hen p ress
L-OUT
.
appears.
L/O
36
20-566 .fm Page 37 Thurs day, August 5, 1999 8:04 AM
To remove the loc kout from a channel, m anually s elect the
channel then press
Notes:
• You can still manua ll y select locked-out channels.
• Your scanner automatically locks out empty channels.
L-OUT
until
disappears.
L/O
USING THE DISPLAY BACKLIGHT
You can turn on the display’s backlight for easy viewing in
again.
LIGHT
to turn on the display l ight for
dimly-lit areas. Press
5 seconds. To tu rn off the light befor e it automat icall y turns
off, press
LIGHT
37
20-566 .fm Page 38 Thurs day, August 5, 1999 8:04 AM
TURNING THE KEY TONE ON AND
OFF
Each time you press any of the scanner’s keys (except
LIGHT
and
Follow these steps to turn the scanner’s key tone off or
back on.
1. If the scanner is on, turn
until it clicks to turn it off.
2. While you hold down the
scanner.
3. After 1 second, release
), the scanner sounds a tone.
VOLUME
2
and E keys, turn on the
2
and E.
counterclockwise
USING THE KEYLOCK
Once you program your scanner, you can protect it from
accidental program changes by turning on the keylock
feature. When the keypad is locked, the only contr ols that
operate are
scanner continues to scan channels).
LIGHT, VOLUME
, and
SQUELCH
(and the
To turn on the keylock, hold down for about 3 seconds until appears. The scan ner beeps t hree t ime s (i f
the key tone i s tur ned on). To turn it off, hold down for
about 3 seconds until disappears.
38
20-566 .fm Page 39 Thurs day, August 5, 1999 8:04 AM
A GENERAL GUIDE TO SCANNING
Reception of the frequencies covered by your scanner is
mainly “line-of -sight.” Tha t means you usually cannot hear
stations that are beyond the horizon.
GUIDE TO FREQUENCIES
US Weather Frequencies
162.400 162.425 162.450 162.475
162.500 162.525 162.550
Other Weather Frequencies
161.650 161.775 162.440 163.275
Ham Radio Frequencies
Ham radio operators often transmit emergency information when other means of communication break down.
The following cha rt shows th e frequ encies t he scann er receives that Ham radi o operators
normally use:
Wavelength (meters) Frequencies (MHz)
10-Meter 29.000–29.700
6-Meter 50.000
2-Meter 144.000
70-cm 420.000
33-cm 902.000
54.000
–
148.000
–
450.000
–
928.000
–
39
20-566 .fm Page 40 Thurs day, August 5, 1999 8:04 AM
Birdie Frequencies
Every scanner has birdi e freq uencies. Birdies are signals created inside the scanner’s receiver. These ope rat ing frequencies might interfere with broadcasts on the
same frequencies. If you program one of these frequencies, you hear only nois e on that frequ ency. If the i nterference is not severe, you might be able to turn
clockwise to cut out the birdie.
The birdie frequencies on this unit to watch for are:
30.735 37.800 38.400
40.000 40.980 41.900
51.200 140.800 149.400
153.000-153.300 153.500-153.800 157.300-157.800
158.085 159.300-159.700 161.400-161.900
163.920 166.400 384.000
396.800 409.600 422.400
435.200 448.000 460.800
473.600 486.400 499.200
512.000
SQUELCH
To find t he birdies i n your s canner, be gin b y d isconne cting
the antenna and moving it away from the scanner. Make
sure that no other nearby radio or TV sets are turned on
near the scanner. Use the s earc h funct ion and sc an eve ry
frequency range from its lowest frequency to the highest.
Occasionally, the searching will stop as if it had found a
signal, often without any sound. That is a birdie. Make a
list of all the birdi es in your scanner for future reference.
40
20-566 .fm Page 41 Thurs day, August 5, 1999 8:04 AM
GUIDE TO THE ACTION BANDS
United States Broadcast Bands
In the Un ited States, t here are seve ral broadcast b ands.
The standard AM and FM bands are probably the most well
known. There are also four television audio broadcast
bands — the lower three transmit on the VHF band and
the fourth transmits on the UHF band.
Typical Band Usage
VHF Band
Low Range 29.00–50.00 MHz
6-Meter Amateur 50.00–54.00 MHz
U.S. Gov ernmen t 137.00 –144.0 0 MH z
2-Meter Amateur 144.00–148.00 MHz
High Range 148.0 0–174.00 MHz
UHF Band
Military Aircraft 380.00–384.00 MHz
U.S. Gov ernmen t 406.00 –420.0 0 MH z
70-c m Amateur 420.0 0–450.00 MHz
Low Range 450.00–470.00 MHz
FM-TV Audio Broadcast, Wide
Band
800 Band Law Enforcement 806.0 0–824.00 MHz
Conventional Systems 851.0 0–856.00 MHz
Conventional/Trunked Systems 856.00–866.00 MHz
Public Safety 866.00–869.00 MHz
Trunked Private/General 894.00–960.00 MHz
470.00 –512.0 0 MH z
41
20-566 .fm Page 42 Thurs day, August 5, 1999 8:04 AM
Primary Usage
As a general rul e, most of t he radio ac tivity i s concentra ted
on the following frequencies:
VHF Band
Activities Frequencies
Government, Police, and Fire 153.785–155.980 MHz
Emergency Services 158.73 0–159.46 0 MHz
Railroad 160.000–161.900 MHz
UHF Band
Activities Frequencies
Land-M obile “Paired”
Frequencies
Base Stations 451.025–454.950 MHz
Mobile Units 456.025–459.950 MHz
Repeater Units 460.025–464.975 MHz
Control Statio ns 465.025–469.975 MHz
450.000–470.000 MHz
Note:
Remote control stations and mo bile units ope rate
at 5 MHz higher than their associated bas e st ations and
relay repeater units.
42
20-566 .fm Page 43 Thurs day, August 5, 1999 8:04 AM
SPECIFIED INTERVALS
Frequencies in diff eren t bands ar e acce ssibl e only at specific intervals. For example:
Frequency Range(s) Specified Interval
29–54 and 137–174 MH z 5.0 kHz steps
380–512 and 806–960 MHz 12.5 k Hz steps
BAND ALLOCATION
To help decide which frequency ranges to scan, use the
following listing of the typical services that use the frequencies your scanner receives. These frequencies are
subject to change, and might vary from area to area. For
a more complete listing, refer to the
Guide including Fire and Emergency Services
at your local RadioShack store.
Abbreviations Services
AIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Aircraft
BIFC . . . . . . . . . . . . . . . . . . . .Boise (ID) Interagency Fire Cache
BUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Business
CAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Civil Air Patrol
CB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Citizens Band
CCA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Common Carrier
CSB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Conventional Systems
CTSB . . . . . . . . . . . . . . . . . . . . .Conventional/Trunked Systems
FIRE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Fire Department
HAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Amateur (Ham) Radio
GOVT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Federal Government
GMR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . General Mobile Radio
GTR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . General Trunked
IND. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Industrial Services
(Manuf acturing, Const ruction, Farming, Forest Products)
MAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Military Amateur Radio
MARI . . . . . . . . . . . . . . . . . . . . . . . . . . . Maritime Limited Coast
MARS. . . . . . . . . . . . . . . . . . . . . . Military Affiliate Radio System
MED . . . . . . . . . . . . . . . . . . . . . . . .Emergency/Medical Services
MIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . U.S. Military
MOV . . . . . . . . . . . . . . . . . . . . . . . Motion Picture/Video Industry
NEW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . New Mobile Narrow
NEWS. . . . . . . . . . . . . . . . . Relay Press (Newspaper Reporters)
(Coast Guard, Marine Telephone,
Shipboard Radio, Private Stations)
Police Call Radio
, available
43
20-566 .fm Page 44 Thurs day, August 5, 1999 8:04 AM
OIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Oil/Petroleum Industry
POL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Police Department
PUB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Public Services
(Public Safety, Local Government, Forestry Conservation)
PSB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Public Safety
PTR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Private Trunked
ROAD . . . . . . . . . . . . . . . . . . . . . Road & Highway Maintenance
RTV. . . . . . . . . . . . . . . . . . .Radio/TV Remote Broadcast Pickup
TAXI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Taxi Services
TELB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mobile Telephone
TELC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cordless Phones
TELM . . . . . . . . . . . . . . . . . . . . . . . . . . Telephone Maintenance
TOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Tow Trucks
TRAN . . . . . . . . . . . . . . . . . . . . . . . . . . .Transportation Services
TSB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Trunked Systems
TVn. . . . . . . . . . . . . . . . . . . . . . . . . . . . FM-TV Audio Broadcast
USXX . . . . . . . . . . . . . . . . . . . . . . . . . . . Government Classified
UTIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power & Water Utilities
WTHR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Weather
(Aircraft, Radio Common Carrier, Landline Companies)
(Trucks, T ow Trucks, Buses, Railroad, Other)
VERY HIGH FREQUENCY (VHF)
VHF Low Band—(in 5 kHz steps)
29.900–30.550 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, MIL
30.580–31.980 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IND, PUB
32.000–32.990 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, MIL
33.020–33.980 . . . . . . . . . . . . . . . . . . . . . . . . . . BUS, IND, PUB
34.010–34.990 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, MIL
35.020–35.980 . . . . . . . . . . . . . . . . . . . . BUS, PUB, IND, TELM
36.000–36.230 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, MIL
36.250. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Oil Spill Cleanup
36.270–36.990 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, MIL
37.020–37.980 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .PUB, IND
38.000–39.000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, MIL
39.020–39.980 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PUB
40.000–42.000 . . . . . . . . . . . . . . . . . . . . . . . . GOVT, MIL, MARI
42.020–42.940 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . POL
42.960–43.180 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IND
43.220–43.680 . . . . . . . . . . . . . . . . . . . . . . . . . TELM, IND, PUB
43.700–44.600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TRAN
44.620–46.580 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . POL, PUB
46.600–46.990 . . . . . . . . . . . . . . . . . . . . . . . . . . . . GOVT, TELC
47.020–47.400 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PUB
47.420. . . . . . . . . . . . . . . . . . . . . . . . . . . . . American Red Cross
47.440–49.580 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IND, PUB
49.610–49.990 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MIL, TELC
6-Meter Amateur Band
50.00–54.00 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .HAM
44
20-566 .fm Page 45 Thurs day, August 5, 1999 8:04 AM
U.S. Government Band
137.000–144.000 . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, MIL
2-Meter Amateur Band
144.000–148.000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .HAM
VHF High Band
148.050–150.345 . . . . . . . . . . . . . . . . . . . . . . . . CAP, MAR, MIL
150.775–150.790 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MED
150.815–150.980 . . . . . . . . . . . . . . . . . . TOW, Oil Spill Cleanup
150.995–151.475 . . . . . . . . . . . . . . . . . . . . . . . . . . . ROAD, POL
151.490–151.955 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IND, BUS
151.985 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TELM
152.0075 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MED
152.030–152.240 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TELB
152.270–152.480 . . . . . . . . . . . . . . . . . . . . . . . . IND, TAXI, BUS
152.510–152.840 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TELB
152.870–153.020 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IND, MOV
153.035–153.725 . . . . . . . . . . . . . . . . . . . . . . . . . IND, OIL, UTIL
153.740–154.445 . . . . . . . . . . . . . . . . . . . . . . . . . . . . PUB, FIRE
154.490–154.570 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IND, BUS
154.585 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Oil Spill Cleanup
154.600–154.625 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BUS
154.655–156.240 . . . . . . . . . . . . . . . . . MED, ROAD, POL, PUB
156.255–157.425 . . . . . . . . . . . . . . . . . . . . . . . . . . . . OIL, MARI
157.450 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MED
157.470–157.515 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TOW
157.530–157.725 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IND, TAXI
157.740 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BUS
157.770–158.100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TELB
158.130–158.460 . . . . . . . . . . . . . . BUS, IND, OIL, TELM, UTIL
158.490–158.700 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TELB
158.730–159.465 . . . . . . . . . . . . . . . . . . . . . . POL, PUB, ROAD
159.480 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .OIL
159.495–161.565 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TRAN
161.580–162.000 . . . . . . . . . . . . . . . . . . . . . . . .OIL, MARI, RTV
162.0125–162.35 . . . . . . . . . . . . . . . . . . . . . . GOVT, MIL, USXX
162.400–162.550 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . WTHR
162.5625–162.6375 . . . . . . . . . . . . . . . . . . . . GOVT, MIL, USXX
162.6625 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MED
162.6875–163.225 . . . . . . . . . . . . . . . . . . . . . GOVT, MIL, USXX
163.250 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MED
163.275–166.225 . . . . . . . . . . . . . . . . . . . . . . GOVT, MIL, USXX
166.250 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GOVT, RTV, FIRE
166.275–169.400 . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, BIFC
169.445–169.505 . . . . . . . . . . . . . . . . . . .Wireless Mikes, GOVT
169.55–169.9875 . . . . . . . . . . . . . . . . . . . . . . GOVT, MIL, USXX
170.000–170.150 . . . . . . . . . . . . . . . . . BIFC, GOVT, RTV, FIRE
170.175–170.225 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT
170.245–170.305 . . . . . . . . . . . . . . . . . . . . . . . . .Wireless Mikes
170.350–170.400 . . . . . . . . . . . . . . . . . . . . . . . . . . . .GOVT, MIL
45
20-566 .fm Page 46 Thurs day, August 5, 1999 8:04 AM
170.425–170.450 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BIFC
170.475. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PUB
170.4875–173.175 . . . . . . . . . . . . . GOVT, PUB, Wireless Mikes
173.225–173.5375 . . . . . . . . . . . . . . . . MOV, NEWS, UTIL, MIL
173.5625–173.5875 . . . . . . . . . . . . . .MI L Medical/Crash Crews
173.60–173.9875 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GOVT
ULTRA HIGH FREQUENCY (UHF)
U. S. Government Band
406.125–419.975 . . . . . . . . . . . . . . . . . . . . . . . . . . GOVT, USXX
70-cm Amateur Ban d
420.000–450.000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .HAM
Low Band
450.050–450.925 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RTV
451.025–452.025 . . . . . . . . . . . . . . . . . . . IND, OIL, TELM, UTIL
452.0375–453.00 . . . . . . . . . . . .IND, TAXI, TRAN TOW, NEWS
453.0125–454.000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . PUB, OIL
454.025–454.975 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TELB
455.050–455.925 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RTV
457.525–457.600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BUS
458.025–458.175 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MED
460.0125–460.6375 . . . . . . . . . . . . . . . . . . . . . FIRE, POL, PUB
460.650–462.175 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BUS
462.1875–462.450 . . . . . . . . . . . . . . . . . . . . . . . . . . . .BUS, IND
462.4625–462.525 . . . . . . . . . . . . . . . . . . IND, OIL, TELM, UTIL
462.550–462.925 . . . . . . . . . . . . . . . . . . . . . . . . . . . .GMR, BUS
462.9375–463.1875 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MED
463.200–467.925 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BUS
FM-TV Audio Broadcast, UHF Wide Band
(Channels 14 through 69 in 6 MHz steps)
475.750. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Channel 14
481.750. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Channel 15
487.750. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Channel 16
..
511.750. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Channel 20
Some cities use the 470–512 MHz band for land/mobile
Note:
service.
Conventional Systems Band — Locally Assigned
851.0125–855.9875 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CSB
Convent iona l/ Trun ke d Sys tem s Band — Locally Ass ign ed
856.0125–860.9875 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CTSB
Trunked Systems Band — Locally Assigned
861.0125–865.9875 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TSB
46
20-566 .fm Page 47 Thurs day, August 5, 1999 8:04 AM
Public Safety Band — Locally Assigned
866.0125–868.9875 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PSB
33-Centimeter Amateur Band
902.0000–928.0000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .HAM
Private Trunked
935.0125–939.9875 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PTR
General Trunked
940.0125–940.9875 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GTR
FREQUENCY CONVERSION
The tuning location of a station can be expressed in frequency (kHz or MHz) or in wavelength (meters). The following information can help you make the necessary
conversions.
1 MHz (million) = 1,000 kHz (thousand)
To convert MHz to kHz, mul tipl y the number of megaher tz
by 1,000:
30.6 2 (MHz)
x
1000 = 30,620 kHz
To convert from kHz to MHz, divide the number of kilohertz by 1,000:
127,8 00 (k H z ) ÷ 1000 = 127.8 MHz
To convert MHz to meters, divide 300 by the number of
megahertz:
300 ÷ 50 MHz = 6 meters
47
20-566 .fm Page 48 Thurs day, August 5, 1999 8:04 AM
TROUBLESHOOTING
If your scanner is not working as it should, these suggestions might help you eliminate the problem. If the scanner
still does not operate properly, take it to your local RadioShack store for assistance.
Problem Possible Causes Remedies
The scanner
does not
work at all.
Poor or no
reception.
The AC or DC
adapter is not
properly connected.
The internal batteries/batter y pack
needs to be recharged, or the
non-rechargeable
batteries are dead.
Improperly connected antenna.
Programmed frequencies are the
same as birdie frequencies.
Be sure the adapter is plugged into
a working AC outlet or cigarettelighter socket , an d
is fully inserted
into the scanner’ s
PWR/DC 9V
Charge the rechargeable batte ries or battery
pack, or replace
non-rechargeabl e
batte ries with
fresh batteries.
Be sure the antenna is properly connected.
Avoid programming frequencies
listed under “Birdie Frequencies” on
Page 40.
jack.
48
20-566 .fm Page 49 Thurs day, August 5, 1999 8:04 AM
Problem
Scanner is on
but does not
scan.
In the scan
mode, the
scanner locks
on frequencies that hav e
an unclear
transmission.
Possible
Causes
SQUELCH
is not
correctly adjusted.
Programmed frequencies are the
same as bird i e
frequencies.
Remedies
Adjust
SQUELCH
clockwise (see
“Turning On the
Scanner/Setting
Volume and
Squelch” on
Page 26).
Avoid programming frequencies
listed under “Birdie Frequenci es” on
Page 40 or only
listen to them
manually.
49
20-566 .fm Page 50 Thurs day, August 5, 1999 8:04 AM
RESETTING/INITIALIZING THE
SCANNER
If the scanner ’s di splay l ock s up or doe s not work pro per ly
after you c onnect a po wer sour ce, y ou mi ght n eed to res et
or initialize it.
Important:
scanner. If that does not work, you can initialize the scanner; however, initializing clears all frequencies you stored
in the scanner’s memory and initializes the scanner to its
default sett ings.
If you have problems, first try to reset the
Resetting the Scanner
1. Turn off the scanner, then turn it on again.
2. Insert a pointed object, such as a straightened paper
clip, into the reset hole on the side of the scanner.
Then gently press and release the reset button
inside the opening. The display goes blank, then
information reappears.
50
20-566 .fm Page 51 Thurs day, August 5, 1999 8:04 AM
Initializing the Scanner
Important:
This procedure clears all frequencies you
stored in the scann er’s memory and initiali zes the scanner
to its def ault settings. I nitialize the scanner only when you
are sure the scanner is not working properly.
1. Turn off the scanner, then turn it on again.
2. While holding down
CLEAR
, insert a pointed object,
such as a straightened paper clip, into the reset hole
on the side of the scanner. Then gently press and
release the reset button inside the opening. The display goes blank, then inf ormation reappears.
Note:
You must release the reset button before you
release
CLEAR
. Otherwise, the memory might not
clear.
3. When the display reappears, release
CLEAR
.
51
20-566 .fm Page 52 Thurs day, August 5, 1999 8:04 AM
CARE AND MAINTENANCE
Your RadioShack PRO-72 50-Channel Portable Scanner
is an example of superior design and craftsmanship. The
following suggestions will help you care for your scanner
so you can enjoy it for years.
Keep the scanner dry. If it gets wet, wipe
it dry immediately. Liquids might contain
minerals that can corrode the electronic
circuits.
Use and store the scanner only in normal
temperature environments. Temperature
extremes can shorten the life of electronic devices, damage batteries, and distort
or melt plastic p arts.
Keep the scanner away from dust and
dirt, which can cause premature wear of
parts.
52
Handle the scanner gently and carefully.
Dropping it can damage circuit boards
and cases and can cause the scanner to
work improperly.
Use only fresh batteries of the required
size and type. Batteries can leak chemicals that damage your scanner’s electronic parts .
Wipe the scanner with a dam p cloth occ asionally to keep it looki ng new. Do not use
harsh chemicals, cleaning solvents, or
strong detergents to clean the scanner.
20-566 .fm Page 53 Thurs day, August 5, 1999 8:04 AM
Modifying or tamper ing with the sca nner ’s i nternal components can cause a malfunction and might invalidate your
scanner’s war ranty and vo id your FCC aut horizat ion to operate it. If you r scanner is not perf orming as it sh oul d, take
it to your local RadioShack store for assistance.
53
20-566 .fm Page 54 Thurs day, August 5, 1999 8:04 AM
SPECIFICATIONS
Frequency Coverage:
Ham .............................. 29–30 MHz (5.0 kHz steps)
VHF Lo ......................... 30–50 MHz (5.0 kHz steps)
Ham .............................. 50–54 MHz (5.0 kHz steps)
Government .............. 137–144 MHz (5.0 kHz steps)
Ham .......................... 144–148 MHz (5.0 kHz steps)
VHF Hi ...................... 148–174 MHz (5.0 kHz steps)
Ham/Government ... 380–450 MHz (12.5 kHz steps)
UHF Lo ................... 450–470 MHz (12.5 kHz steps)
UHF Hi (T) .............. 470–512 MHz (12.5 kHz steps)
UHF Hi ................ 806–824 MHz (in 12.5 kHz steps)
849–860 MHz (in 12. 5 kHz steps)
894–960 MHz (in 12. 5 kHz steps)
Channels of Operation: ............................... 50 Channels
and 1 Monitor Memory
Sensitivity (20 dB S/N):
29–54 MHz .................................................... 1.0 µV
137–174 MHz ............. ...................... ............. 1.0 µV
380–512 MHz ............. ...................... ............. 1.0 µV
806–960 MHz ............. ...................... ............. 2.0 µV
Selectivity:
±10 kHz .... ... ....... ... .. ....... ... .. ....... ... .. ........ .. ... .. –6 d B
±18 kHz .... ... ....... ... .. ....... ... .. ....... ... .. ........ .. ... – 50 d B
Spurious Rejection:
29–54 MHz ................................... 50 dB at 40 MHz
137–174 MHz ............................. 50 dB at 154 MHz
Scanning Rate ........................Up to 25 channels/second
Search Rate ................................. Up to 50 steps/second
Delay Time .................................................... .. 2 seconds
Intermediate Frequencies (IF):
1st ............................................................. 10.7 MHz
2nd ..................... ............ ...................... ....... 455 kHz
IF Rejection: 10.7 MHz ...................... 70 dB at 154 MHz
54
20-566 .fm Page 55 Thurs day, August 5, 1999 8:04 AM
Squelch Sensitivity:
Threshold .............. .. ...................... Less than 1.0 µV
Tight ................................................. (S+N)/N 25 dB
Antenna Impedance ........................ ................. 50 Ohms
Audio Output Power (10% THD) ......... 200 mW Nominal
Built-in Speaker ................................... 1
Power Requirements .................. 9 V DC, 6 AA batteries
AC Adapter (Cat. No. 273-1665)
DC Adapter (Cat. No. 270-1560)
Rechargeable Batt ery Pack (Cat. No. 23-288)
Current Drain (Squelched) ................... ..................50 mA
Dimensions (HWD) .................. 6
Weight ................................................................... 8.5 oz
Supplied Accessory ......................... ............ ...... Antenna
3
/8 Inch (36 mm)
8 ohm, Dynamic T ype
3
/4 × 25/16 × 19/16 Inches
(171 × 59 × 40 mm)
(240 g)
Specifications are typical; individual units might vary.
Specifications are subject to change and improvement
without notice.
US PATENT NUMBERS
3,794,925
3,801,914
3,961,261
3,962,644
4,027,251
4,092,594
4,123,715
4,245,348
55
y
y
g
y
y
y
g
g
y
y
y
g
g
y
y
g
g
g
y
g
g
j
g
y
y
g
20-566 .fm Page 56 Thurs day, August 5, 1999 8:04 AM
Limited One-Year Warranty
This product is warrant ed by RadioShack against manufa cturing defects in
material and workmanship under normal use for one (1)
purchase from RadioShack compan
dioShack franchisees and dealers. In the event of a product defect durin
warrant
period, take the prod uct a nd the Ra dio Shack sal es rec eipt as pro of
of purchase date to an
less otherwis e prov ided b
out char
e for parts and labor; (b) replace the product with one of the same or
similar desi
ucts, and products on whi ch a r efund is made, become the p ropert
dioShack. New or reconditioned parts and products ma
performance of wa rrant
are warranted for the remainder of the or i
char
the warrant
This warrant
to acts of God, abuse, accident, misuse, imprope r or abnormal usa
to follow instructions, impr oper installation or maintenance, alteration, li
nin
than those provid ed b
sumables such as fuses or batteries; (d) cosmetic dama
shippin
up service ad
EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS
WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED
WARRANTIES CONTAINED HEREIN. EXCEPT AS PROVIDED HEREIN,
RadioShack SHALL HAVE NO LIABILITY OR RES PONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY
LIABILITY, LOSS OR DAMAGE CAUSED DIRE CTLY OR INDIRECTLY BY
USE OR PERFORMANCE OF THE P RODUCT OR ARISING OUT OF A NY
BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY
DAMAGES RESULTING FROM INCONVENIENCE, LO SS O F TIME , D ATA,
PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow the limitatio ns on how lon
lasts or the ex clusion of in cidental or consequen tial damages, so the abov e
limitations or exclusi ons ma
cific le
state.
RadioShack Customer Relations, Dept. W, 100 Throckmorton St., Suite 600,
n; or (c) refund the purchase price. All replaced par ts and prod-
ed for repair or replac ement of the pr odu ct made after the expir atio n of
period.
does not cover: (a) damage or failure caused by or attributable
or other incidence of excess voltage or current; (b) any repairs other
or insuranc e cos ts; or (f) cos ts of pr odu ct remov al, insta llatio n, s et-
al rights, and you may also have other rights which vary from state to
RadioShack store. RadioShack will, at its option, un-
law: (a) correct the defect by product repair with-
service. Repai red or replaced part s and products
a RadioShack Authorized Service Facil ity; (c) con-
ustment or reinstallation.
not apply to you. This warranty gives you spe-
Fort Worth, TX 76102
-owned stores and authorized Ra-
inal warranty period. You will be
We Service What We Sell
ear from the date of
of Ra-
be used in the
e, failure
e; (e) transportation,
an implied warrant
the
ht-
1/97
RadioShack
A Division of Tandy Corporation
Fort Worth, Texas 76102
GE-97-D-2429
4A7 Printed in Hong Kong
Loading...
