Operating Instructions

Network Camera

Model No. WV-S2500 Series

WV-S2200 Series

WV-S2100 Series

WV-S1500 Series

WV-S1100 Series

-S2531LN

WV-S1131

WV-S2131L

-S2131L

-S1131

WV-S1531LN

WV-S2531LN

WV-S1531LN

This manual covers the models: WV-S2500Series (WV-S2531LN and WV-S2511LN), WV-S2200 Series

(WV-S2231L and WV-S2211L), WV-S2100 Series (WV-S2131, WV-S2131L, WV-S2111L, WV-S2110, and

WV-S2130), WV-S1500 Series (WV-S1531LN and WV-S1511LN), and WV-S1100 Series (WV-S1132,

WV-S1112, WV-S1131, and WV-S1111).

Before attempting to connect or operate this product, please read these instructions

carefully and save this manual for future use.

The model number is abbreviated in some descriptions in this manual.

Preface

About the user manuals

There are 3 sets of operating instructions as follows.

• Operating Instructions (this document): Explains how to perform the settings and how to operate this

camera.

• Important Information: Provides information about the cautions required for safely using and installing this

camera.

• Installation Guide: Explains how to install and connect devices.

The screens used in these operating instructions show the case of WV-S1131. Depending on the model used,

the screens shown in the explanations may differ to the actual camera screens.

About notations

The following notations are used when describing the functions limited for specified models.

The functions without the notations are supported by all models.

S11x2

: The functions with this notation are available when using the model WV-S1132 and WV-S1112.

S11x1

: The functions with this notation are available when using the model WV-S1131 and WV-S1111.

S15x1

: The functions with this notation are available when using the model WV-S1531LN and WV-S1511LN.

S25x1

: The functions with this notation are available when using the model WV-S2531LN and WV-S2511LN.

S22x1

:The functions with this notation are available when using the model WV-S2231L and WV-S2211L.

S21x1

: The functions with this notation are available when using the model WV-S2131, WV-S2131L, and

WV-S2111L.

S21x0

: The functions with this notation are available when using the model WV-S2110 and WV-S2130.

S113x

: The functions with this notation are available when using the model WV-S1132 and WV-S1131.

S111x

: The functions with this notation are available when using the model WV-S1112 and WV-S1111.

S153x

: The functions with this notation are available when using the model WV-S1531LN.

S151x

: The functions with this notation are available when using the model WV-S1511LN.

S253x

: The functions with this notation are available when using the model WV-S2531LN.

S251x

: The functions with this notation are available when using the model WV-S2511LN.

S223x

: The functions with this notation are available when using the model WV-S2231L.

S221x

: The functions with this notation are available when using the model WV-S2211L.

S213x

: The functions with this notation are available when using the model WV-S2131L, WV-S2131, and

WV-S2130.

S211x

: The functions with this notation are available when using the model WV-S2110 and WV-S2111L.

Abbreviations

The following abbreviations are used in these operating instructions.

Microsoft

Windows

10 is described as Windows 10.

Microsoft

Windows

8.1 is described as Windows 8.1.

Microsoft

Windows

8 is described as Windows 8.

Microsoft

Windows

7 is described as Windows 7.

2 Operating Instructions

Preface

Windows

Internet Explorer

11, Windows

Internet Explorer

10, Windows

Internet Explorer

9 and

Windows

Internet Explorer

8 are described as Internet Explorer.

SDXC/SDHC/SD memory card is described as SD card or SD memory card.

Universal Plug and Play is described as UPnP™ or UPnP.

For administrator registration

At the time of first access to the camera (or at the time of initialization), the registration screen will be displayed.

[User name (1 to 32 characters)]

Enter the user name of the administrator.

Available number of characters: 1 - 32 characters

Unavailable characters: 2-byte characters, and 1-byte symbols " & : ; \

[Password (8 to 32 characters)]/[Retype password]

Enter the administrator password.

Available number of characters: 8 - 32 characters

Unavailable characters: 2-byte characters, and 1-byte symbols " &

Note

• Distinguish between upper- and lower cases.

• For the password, use two or more types of characters from alphabetic characters, numbers, and

symbols.

IMPORTANT

• If you forgot or do not know the password or user name, the camera must be initialized. Because all

settings other than preset position settings are deleted when the camera is initialized, make sure to

keep the information secure from third parties. Refer to “Parts and functions” section in the Important

Information in the supplied CD-ROM for more information about initializing the camera.

• It is recommended to change the password periodically.

Operating Instructions 3

Preface

The registration completion screen will be displayed after registering a user name and password of the

administrator. After 10 seconds, the camera will be reconnected automatically. Please click “here” if it is not

displayed automatically.

When the camera is reconnected to, an authentication window is displayed. Enter the registered user name

and password to start operation.

Viewer software

In order to display H.265 (or H.264) images, send/receive audio to/from the camera, and play images saved

on the SD memory card, the “Network Camera View 4S” (ActiveX

) viewer software must be installed. This

software can be installed directly from the camera or by selecting the [Install] button next to [Viewer

Software] on the menu of the CD-ROM provided, and then following the on-screen instructions.

IMPORTANT

• The default setting of “Automatic installation” is “On”. Follow the instructions on page 235 when the

message is displayed on the information bar of the browser.

• Depending on the software environment of your PC, it may take time for the message to be displayed

on the information bar of the browser.

• If you display the “Live” page on a PC and click the [Viewer Software] button, the installation screen

for ActiveX, which is required for viewing camera images, is displayed. Follow the on-screen

4 Operating Instructions

Preface

instructions and install the software. When displayed JPEG images (still images), there is no need to

install ActiveX.

• When the install wizard is displayed again even after completing the installation of the ActiveX, restart

the PC.

• The viewer software used on each PC should be licensed individually. The number of installations of

the viewer software from the camera can be checked on the [Upgrade] tab of the “Maintenance” page

(®page 209). Refer to your dealer for the software licensing.

Operating Instructions 5

Preface
