Multi Purpose Camera
AK-HC1500G
ULTI FORMAT
DIGITAL CAMERA SYSTEM
AK-HC1500G
РУССКИЙ ESPAÑOL ITALIANO FRANÇAIS DEUTSCH ENGLISH
Before attempting to connect, operate or adjust this product, please read these instructions completely.
ENGLISH VERSION
CAUTION |
RISK OF ELECTRIC SHOCK |
DO NOT OPEN |
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, |
DO NOT REMOVE COVER (OR BACK). |
NO USER SERVICEABLE PARTS INSIDE. |
REFER TO SERVICING TO QUALIFIED SERVICE PERSONNEL. |
The lightning flash with arrowhead symbol, within an equilateral triangle, intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (service) instructions in the literature accompanying the appliance.
For CANADA
This class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
FCC Note:
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Warning:
To assure continued FCC emission limit compliance, the user must use only shielded interface cables when connecting to external units. Also, any unauthorized changes or modifications to this equipment could void the user’s authority to operate it.
indicates safety information.
- 1 (E) -
ENGLISH
WARNING:
•TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
•THE APPARATUS SHALL NOT BE EXPOSEDTO DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
CAUTION:
TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD AND ANNOYING INTERFERENCE, USE THE RECOMMENDED ACCESSORIES ONLY.
Note:
The rating plate is on the bottom of the unit.
indicates safety information.
- 2 (E) -
IMPORTANT SAFETY
INSTRUCTIONS
Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference.
1)Read these instructions.
2)Keep these instructions.
3)Heed all warnings.
4)Follow all instructions.
5)Do not use this apparatus near water.
6)Clean only with dry cloth.
7)Do not block any ventilation openings.Install in accordance with the manufacturer’s instructions.
8)Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9)Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10)Protect the power cord form being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11)Only use attachments/accessories specified by the manufacturer.
12)Use only with the cart,
stand, tripod, bracket, or table specified by the manufacturer, or
sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13)Unplug this apparatus during lightning storms or when unused for long periods of time.
14)Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
indicates safety information.
- 3 (E) -
Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households)
This symbol on the products and/or accompanying documents means that used
electrical and electronic products should not be mixed with general household waste.
For proper treatment, recovery and recycling, please take these products to designated collection points, where they will be accepted on a free of charge basis. Alternatively, in some countries you may be able to return your products to
your local retailer upon the purchase of an equivalent new product.
Disposing of this product correctly will help to save valuable resources and prevent any potential negative effects on human health and the environment which could otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point. Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.
ENGLISH
- 4 (E) -
Contents
Accessories .......................................... |
5 |
Introduction ........................................... |
6 |
Characteristics ...................................... |
6 |
Precautions for use .............................. |
7 |
Major operating controls and |
|
their functions .................................. |
8 |
How to install ...................................... |
12 |
How to set the lens ........................ |
12 |
How to install on the camera housing, |
|
pan/tilt head, tripod, etc. ............ |
12 |
How to set up the system .................. |
13 |
Configuration example 1: Connection |
|
of camera controller .................. |
13 |
Configuration example 2: |
|
High-speed P/T system ............. |
14 |
Operation procedure .......................... |
15 |
How to adjust ...................................... |
16 |
Flange back adjustment |
|
(for zoom lens) ............................ |
16 |
Lens iris gain volume adjustment .. |
16 |
White balance adjustment ............. |
17 |
Color temperature and white balance |
|
adjustment (reference) .............. |
17 |
Black balance adjustment............... |
18 |
Gen-lock adjustment ...................... |
18 |
Setting of menu items ........................ |
19 |
How to display the menus .............. |
19 |
TOP menu ...................................... |
19 |
MAINTENANCE menu ................. |
20 |
SETTING menu ............................ |
36 |
CAMERA ID menu ....................... |
43 |
FILE OPERATION menu .............. |
44 |
TIME CODE menu ....................... |
45 |
Menu list ......................................... |
46 |
Appearance ......................................... |
49 |
Specifications ..................................... |
50 |
Appendix ............................................. |
51 |
Control cable for |
|
information camera ....................... |
51 |
Accessories |
|
Lens cap ................................................. |
1 |
Filter ........................................................ |
2 |
- 5 (E) -
Introduction
This camera employs new 2/3˝ 1 million-pixel IT CCD, realizing a compact light-weight system including the optical system.
The newly developed CCD image sensor, 14-bit A/D converter and brand-new DSP make for a wide dynamic range.
The self-contained format conversion circuit ensures support for a multiple number of HD formats including 1080/59.94i, 50i, 720/60p, 59.94p and 50p.
Making the best use of the features of a small-sized self-contain camera, it is accommodated in the camera housing and able to provide high-quality HD pictures as an multi purpose digital camera.
ENGLISH
Characteristics
New 2/3˝ 1 million-pixel CCD is employed. [1280(H) 720(V)]
1 million-pixel CCD is 2/3˝ in size, being compact and light-weight.
Multiple HD formats supported
Signal output of many different formats enabled by incorporating a format conversion circuit in Panasonic’s original LSI chip.
Fabrication of a circuit for 24 Hz-based formats also supported.
14-bit A/D conversion and brand-new DSP featured
Wide dynamic range achieved
Crystal-clear shooting even of images with different brightness levels
Boosting of gain to a maximum 72 dB enabled
Electronic extender function provided
Cine gamma supported
Multiple functions
Multi-function DTL such as high-luminance DTL and skin DTL.
Right and left, top and bottom picture reversing function.
- 6 (E) -
Precautions for use
DON’TS
Do not attempt to disassemble the camera or other units. In order to prevent electric shock, do not remove screws or covers. There are no user-serviceable parts inside.
Do not abuse the camera. Avoid striking, shaking, etc. The camera contains sensitive components which could
be damaged by improper handling or storage.
Do not let the lens remain uncapped when the camera is not use. If the lens is not installed, do not leave the lens mount hole uncovered.
Do not touch the surface of the lens or prism.
Do not use strong of abrasive detergents when cleaning the camera body.
Do not aim the camera toward the sun, no matter whether it is turned on or not.
Do not expose the camera to rain or moisture, and do not try to operate the equipment in wet conditions. Do not operate the camera if it becomes wet.
Do not operate the camera outdoors during a lightning storm.
Do not use the camera in an extreme environment where high temperatures or high humidity exist.
Do not leave the camera turned on when not in use. Do not unnecessarily turn the camera power on and off repeatedly. Do not block the ventilation slots.
Do not cover the port otherwise block ventilation during operation. Internal heat buildup can cause a fire.
DO’S
Refer any servicing to qualified service personnel.
Handle the camera with care.
Protect the precision made lens by placing the lens cap over when the camera is not in use. If the lens is not installed, protect the surface of the prism by placing the body cap into the lens mount hole.
Use a mild blower or lens cleaning tissue designed for coated lenses, to clean the surface of the lens or prism in the event that it should become dirty.
Use a dry cloth to clean the camera if it is dirty. In case the dirt is hard to remove, use mild detergent and wipe gently.
Use caution when operating the camera in the vicinity of spot lights or bright lights, as well as light reflecting objects and surfaces.
Take immediate action if ever the camera should become wet. Turn the power off and have the unit checked by an authorized service facility.
Follow normal safety precaution to avoid personal injury.
Use the camera in an environment where the temperature is within 32°F
– +104°F (0°C – +40°C), and the relative humidity is within 30% – 90% (no condensation).
Always turn the power off when the camera is not going to be used. Operate the camera only when there is adequate ventilation.
Cooling fan
There is internally provided a cooling fan. Since the cooling fan is a consumable part, replace it after about 30,000 hours of operation.
(Be sure to ask the dealer for the replacement.)
- 7 (E) -
Major operating controls and their functions
Front view |
Top view |
|
|
|
|
|
|
ENGLISH
Bottom view |
Rear view |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
||
|
|
||
|
|
||
|
|
||
|
|||
|
|
||
|
|
|
- 8 (E) -
Major operating controls and their functions
Lens mount
2/3” standard bayonet type (B4 mount) lens is installed.
Lens fixing ring knob
Lens is fixed by turning the knob clockwise.
Camera mounting hole (1/4-20UNC)
Camera mounting hole (3/8-16UNC)
The screw holes can be used to secure the camera for installing it on camera housing, and when using a pan/tilt head or a tripod.
MENU switch [MENU]
A menu will appear on the monitor screen when MENU switch is pressed for at least 3 seconds. The menu screen is cleared when the switch is pressed for at least 3 seconds while the menu is displayed.
ENTER/AWB switch [ENTER/AWB]
The item just below can be selected by pressing this switch while the menu is on the screen.
When the menu is not displayed or the camera is in shooting mode, the automatic white balance control (AWB) can be set with this switch.
UP/ABB switch [UP/ABB]
The item just above can be selected by pressing this switch while the main menu is displayed.
While the Sub menu is displayed, any setting can be brought up to a higher value with this switch.
When the menu is not displayed or the camera is in shooting mode, the automatic black balance control (ABB) can be set with this switch.
DOWN/BAR switch [DOWN/BAR]
The item just below can be selected by pressing this switch while the Sub menu is on the screen.
While the Sub menu is displayed, any setting can be brought down to a lower value with this switch.
When the menu is not displayed, the color bar and the shooting conditions are alternately indicated by pressing the switch for about 5 seconds.
Each time the MENU switch is pressed while the UP/ABB switch and DOWN/BAR switch is held down and while the menu is not displayed, the video output format is changed in the following sequence.
720/60p 720/59.94p 720/50p 1080/60i 1080/59.94i 1080/50i 1080/30p 1080/29.97p 1080/25p 1080/24p 1080/23.98p
When the video format is changed, the operate indicator flashes twice with the 720/60p format and once with any other format.
- 9 (E) -
Major operating controls and their functions
HD SDI output connector [HD SDI OUT]
SDI signal output is given by this line.
G/L input connector [G/L IN]
For gen-lock with the camera, the external sync signal (black burst) or tri-level sync signal is supplied to this input connector.
Cable clamp
Clamp the DC power supply cable connected to the DC 12 V input connector to prevent it from slipping out.
Optional card slot
Slot for inserting an optional card. For details, refer to the manual for optional cards.
Cooling fan
•Do not block or obstruct the ventilation during operation. It may otherwise cause internal heating or fire.
•The life of this fan is approximately 50,000 hours (at room temp. 77°F (25°C)). Replace the fan as needed.
(When the room temperature is higher than 95°F (35°C), replace the fan 30% earlier.) Be sure to ask the dealer for the replacement.
Interface connector [I/F]
5 |
10 |
15 |
Pin No. |
Signal |
|
|
1 |
Gen-lock signal GND |
|
|
|
|
||
|
|
|
2 |
Time code signal input |
1 |
|
11 |
3 |
Not used |
6 |
4 |
TX_N (EIA422)/TXD (EIA232) output |
||
|
|
|
||
|
|
|
5 |
RX_N (EIA422)/RXD (EIA232) output |
|
|
|
6 |
Camera power supply input (DC +12 V) |
|
|
|
7 |
Gen-lock signal input |
|
|
|
8 |
GND |
|
|
|
9 |
TX_P (EIA422) output |
|
|
|
10 |
RX_P (EIA422) input |
|
|
|
11 |
GND |
|
|
|
12 |
Time code signal GND |
|
|
|
13 |
GND |
|
|
|
14 |
GND |
|
|
|
15 |
GND |
ENGLISH
- 10 (E) -
Major operating controls and their functions
Tally output connector [TALLY OUT]
The R tally and G tally signals are output from this connector.
These signals take effect when the optional card for studio applications has been inserted.
Pin No. |
Signal |
1 |
GND |
2 |
R_TALLY_OUT |
3 |
G_TALLY_OUT |
4 |
+12 V (500 mA Max) |
IRIS connector [IRIS]
Used to connect the IRIS control cables of the lens.
Pin No. |
Signal |
Pin No. |
Signal |
1 |
Return control |
7 |
Iris follow |
2 |
VTR-S/S |
8 |
Iris auto selection |
3 |
UNREG GND |
9 |
— |
4 |
Iris manual selection |
10 |
Zoom position information |
5 |
Iris control |
11 |
Focus position information |
6 |
UNREG 12 V |
12 |
NC |
Zoom/Focus connector [ZOOM/FOCUS]
Used to connect the zoom/focus control cables of lens.
Pin No. |
Signal |
Pin No. |
Signal |
1 |
Focus control selection |
7 |
COM |
2 |
Zoom control selection |
8 |
Focus control |
3 |
GND |
9 |
Zoom control |
4 |
Forcible iris closing |
10 |
Iris control selection |
5 |
Iris control |
11 |
COM +Voltage |
6 |
+Voltage |
12 |
COM –Voltage |
Operate indicator
Green LED lamp lights to indicate that the specified DC power is supplied to the DC 12 V input connector .
When the video format is changed, the operate LED flashes twice when the format is 720/60p and once with any other format.
DC 12 V input connector [DC12V IN]
12 V DC is supplied through the optional DC power supply cable (AW-CA4T1).
-11 (E) -
How to install Be sure to ask the dealer for the installation, adjustment and connection of this equipment.
How to set the lens
Standard 2/3” bayonet type (B4 mount) lens of any makers can be used*.
Turn the lens fixing ring knob counterclockwise to remove the lens mount cap.
Set the lens in place, and turn the lens fixing ring knob clockwise to precisely fix the lens.
Connect the iris control cable to the IRIS connector.
Connect the zoom/focus control cable to the ZOOM/FOCUS connector.
* Note that there are some lenses uncontrollable with respect to zoom, focus function.
Iris control cable (to IRIS connector)
Zoom/focus control cable (to ZOOM/FOCUS connector) (When a pan/tilt head is used, connect the cable
to the pan/tilt head.)
Lens fixing ring knob
Attach the provided filter to the iris control cable and zoom/focus control cable.
Filter
ENGLISH
How to install on the camera housing, pan/tilt head, tripod, etc.
Precisely set the camera on the camera housing, pan/tilt head, tripod, etc. by using the camera set-screw hole (1/4-20UNC, 3/8-16UNC).
When mounting the camera on a pan/tilt head, be sure to use proper tools and make sure that there is no fear of falling off.
-12 (E) -
How to set up the system
Configuration example 1: Connection of camera controller
Use multi cable supplied with AK-HRP150G for the connection of camera controller AK-HRP150G and this unit.
Multi purpose camera
AK-HC1500G
Lens
ULTI FORMAT
HD SDI OUT
AK-HC1500G
IRIS
Multi cable (POWER + CONTROL)
AC adapter |
Monitor |
AW-PS505A |
Camera controller
AK-HRP150G
Before connecting the cables, be sure to set the power switch of AC adapter to OFF.
Connect the multi cable to the interface connector of the camera, and the opposite side to camera controller.
Set the AC adapter power switch to ON, then the camera can be controlled.After shooting, set the AC adapter power switch to OFF.
- 13 (E) -
How to set up the system
Configuration example 2: High-Speed P/T system
ENGLISH
|
IRIS |
Lens |
Cable kit |
AW-CAK4HIG |
|
|
HD SDI |
ZOOM/FOCUS |
|
|
Multi purpose camera |
|
AK-HC1500G |
|
HD SDI |
|
Indoor pan/tilt head |
|
AW-PH400 |
10BASE-T straight cable |
|
(Pan/tilt control) |
|
|
Cable kit |
|
AW-CAK4HIG |
|
(Camera control) |
|
Monitor |
AC adapter |
AC adapter |
AW-PS505A |
AW-PS505A |
Pan/tilt control panel |
Camera |
AW-RP400 |
controller |
|
AK-HRP150G |
- 14 (E) -
Operation procedure
1Turn on the power of each equipment.
2Properly adjust the light for the object.
3Adjust the flange back of the lens, the iris and the focus.
Flange back must be adjusted when the camera is used for the first time or after replacement of the lens.
4Adjust the white balance.
This adjustment is needed when the camera is used for the first time or after leaving unused for a long time.
The adjustment is necessary when the lighting condition or brightness is changed.
After adjusting the white balance once, re-adjustment is not needed under the same condition.
5Adjust the black balance.
This adjustment is needed when the camera is used for the first time or after leaving unused for a long time.
The adjustment is necessary when the ambient temperature is greatly changed or at the change of season.
After adjusting the black balance once, re-adjustment is not needed under the same condition.
6Start shooting.
(After shooting, be sure to turn off the power of each equipment connected.)
- 15 (E) -
Loading...
