Page 1
© KROHNE 09/2004
Supplementary
Installation and
Operating Instructions
HART Communicator 275
Asset Management Solutions (AMS)
Process Device Manager (PDM)
UFC 030
Ultrasonic Flow Converter
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 1/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 2
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
1 General Information 3
2 IDs and Revision numbers 5
3 HART Communicator 275 (HC275), Field Communicator 375 (FC375) 6
3.1 Installation 6
3.2 Operating 6
4 Asset Management Solutions (AMS) 6
4.1 Installation 6
4.2 Operating 6
5 Process Device Manager (PDM) 7
5.1 Installation 7
5.2 Operating 7
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 2/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 3
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
1 General Information
The UFC 030 is a “four-wire” transmitter with 4...20mA current output and HART capability. Dependent on device implementation it is available with active/passive current output (standard) or passive current output (MODIS).
General Characteristics of the UFC 030 HART interface:
• Multidrop Mode is supported
• Burst Mode is not supported
Electrical connection: Refer to section “Electrical connection of the signal inputs and outputs” of the following manual:
• “Installation and Operating Instructions Universal 3-Beam ultrasonic flowmeter UFM 3030 Compact ultrasonic flowmeter UFC 030 Ultrasonic flow converter UFS 3000 Ultrasonic flow sensor” (KROHNE)
There are two ways of using the HART communication:
a) As a point-to-point connection between the UFC 030 and the HART master equipment. The instrument's current output may be active or passive.
Point-to-Point Analog/Digital Mode
Primary Master
Power Supply
For slaves with passive current output (2 wire)
HART
Modem
HART
≥ 250 Ω
Secondary Master
Analog
mA
4
20
Terminal I/C
Terminal ⊥
4...20 mA
UFC 030
Addr. 0
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 3/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 4
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
b) As a multipoint connection (multidrop) with up to 15 devices (UFC 030 or other HART equipment) in parallel. The instrument's current outputs must be passive.
Multidrop Mode
Primary Master
HART
Modem
HART
Power Supply
≥ 250 Ω
4 mA 4 mA
Terminal I/C
Terminal ⊥
. . .
Secondary Master Up to 15
Slaves
. . .
UFC 030
Addr. > 0
(passive Current Output)
UFC 030
Addr. > 0
(passive Current Output)
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 4/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 5
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
In case the UFC 030's current output shall work continuously active a 'third wire' is needed to properly connect it together with two-wire loop powered devices in the same network.
Multidrop Mode (‘three-wire’)
(Connecting two-wire and four-wire devices in the same network)
Secondary Master
Primary Master
HART
Modem
Power Supply
HART
HART
≥ 250 Ω
4 mA
two-wire loop powered devices
4 mA
. . .
Addr. > 0 Addr. > 0
Terminal V+
4 mA
UFC 030 Addr. > 0
4 mA
four-wire active source devices
. . .
Terminal I/C
UFC 030 Addr. > 0
2 IDs and Revision numbers
The HART Device Descriptions described in this document have the following IDs and revision numbers: Manufacturer ID: 69 (0x45) Device Type: 231 (0xE7) Device Revision: 2 DD Revision: 1 HART Universal Revision: 5 HC 275 OS Revision: ≥ 4.9 FC 375 System SW Rev.: ≥ 1.6 AMS Version: ≥ 6.0 PDM Version: ≥ 5.2 FDT Version: ≥ 1.2
For information about Transmitter Revisions and related Device Descriptions refer to the KROHNE HART Device List.
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 5/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 6
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
3 HART Communicator 275 (HC275), Field Communicator 375 (FC375)
3.1 Installation
The UFC 030 HART Device Description has to be installed on the HC275 and FC375 respectively. Otherwise the user will work with the instrument as a generic one thus loosing opportunity for entire instrument control. For installing DDs on the HC275 a ‘HART Communicator Module Programmer’ is needed (see details in the ‘Module Programmer User’s Guide’). For installing DDs on the FC375 the ‘Easy Upgrade Programming Utility’ is needed and the FC375 must have a System Card with ‘Easy Upgrade’ option (see details in the ‘375 Field Communicator User’s Manual’).
3.2 Operating
Refer to the UFC 030 Menu Tree HC275 / FC375 (Attachment A). The UFC 030 operation via HC275 / FC375 is made quite close to the manual instrument control via keypad. Due to limitations of the HC275 / FC375 there are some peculiarities:
• The online help of each parameter is only a short form help. However it contains the function number as a reference to the device’s local display and the “Installation and Operating Instructions” for a comprehensive description.
• Some selection lists (e.g. for output functions) may contain items which are actually not valid for the device concerned. However invalid settings are rejected when trying to send them to the device.
Parameter protection via passwords (Entry Code, Service Code) is the same as on local display. Please refer to the online help for valid symbols according to device’s keypad. The set of parameters of the HC275 “standard configuration” is only a partial set which doesn’t contain service parameters. However the HC275 “full configuration” contains a complete set of parameters. Prior to sending a “full configuration” to a device the Service Code protection must be disabled in case. Both types of configurations can be transferred to AMS. The FC375 always creates a “full” configuration for interaction with AMS. Still the FC375 considers only a partial parameter set (like the HC275 “standard configuration”) when sending it to a device.
4 Asset Management Solutions (AMS)
4.1 Installation
If the UFC 030 Device Description is not already installed on the AMS System a so called Installation Kit UFC 030 HART AMS is needed (available as download from KROHNE ‘Download Centre’ on the internet or on floppy disk /
CD-ROM from KROHNE). For installing the DD with the Installation Kit refer to the “AMS Intelligent Device Manager Books Online" section
"Basic AMS Functionality /Device Configurations / Installing Device Types / Procedures /Install device types from media”. Please read also the “readme.txt”, which is also contained in the Installation Kit.
4.2 Operating
Refer to the UFC 030 Menu Tree AMS (Attachment B). Due to AMS requirements and conventions the UFC 030 operation differs to some extent from operation with HC275 / FC375 and via local keypad. Due to limitations of the HC275 / FC375 which affect also AMS there are some peculiarities:
• The online help of each parameter is only a short form help. However it contains the function number as a reference to the device’s local display and the “Installation and Operating Instructions” for a comprehensive description.
• Some selection lists (e.g. for output functions) may contain items which are actually not valid for the device concerned. However invalid settings are rejected when trying to send them to the device.
Parameter protection via passwords (Entry Code, Service Code) is the same as on local display. Please refer to the online help for valid symbols according to device’s keypad.
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 6/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 7
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
5 Process Device Manager (PDM)
5.1 Installation
If the UFC 030 Device Description is not already installed on the PDM System a so called Device Install is needed (available as download from KROHNE ‘Download Centre’ on the internet or on floppy disk / CD-ROM from KROHNE). For installing the DD with the Device Install refer to the “PDM Manual” section 11.2:”Device Install / Integrating Devices in SIMATIC PDM with 'Device Install'". Please read also the “readme.txt”, which is also contained in the Device Install.
5.2 Operating
Refer to the UFC 030 Menu Tree PDM (Attachment C). Due to PDM requirements and conventions the UFC 030 operation differs to some extent from operation with HC275 / FC375 and via local keypad. Due to limitations of the HC275 / FC375 which affect also PDM there are some peculiarities:
• The online help of each parameter is only a short form help. However it contains the function number as a reference to the device’s local display and the “Installation and Operating Instructions” for a comprehensive description.
• Some selection lists (e.g. for output functions) may contain items which are actually not valid for the device concerned. However invalid settings are rejected when trying to send them to the device.
Parameter protection via passwords (Entry Code, Service Code) is the same as on local display. Please refer to the online help for valid symbols according to device’s keypad.
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 7/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 8
Attachment A
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree HC275 / FC375
1 Dynamic
Variables
2 Configuration /
Test
1 View Process
Vars
2 View In/Outputs
1 Test / Info
1 Actual Flow 2 Corrected Flow 3 VOS 4 Analog In put 1 5 Analog In put 2 6 F/R Indication 7 Gain 8 Digital Output 9 Totalizer 1
Opt
10 Totalizer 2 11 Totalizer Sum
1 Function I 2 Value I 3 %Range I 4 Function P 5 Value P 6 %Range P
Opt
Opt
Opt
7 Analog Input 1 8 Analog Input 2
1 Test Outputs
2 Test Inputs
3 Device Info
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
1 Test Current O. 2 Test Pulse O.
1 Analog In put 1 2 Analog In put 2
1 Manufacturer 2 Model Number 3 Serial Number 4 µP2 HW No. 5 µP2 SW No. 6 FE HW No. 7 DSP HW No. 8 DSP SW No.
Opt
Opt
Opt
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
3 Quit/Reset 4 HART Variables
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local HC275/FC375,
affects only HC275/FC375 views
4 Sensor Limits
1 Volume Flow 2 Heat Flow 3 VOS
1 Upper Snsr Limit 2 LowerSnsrLimit 3 Minimum Span
Rd
Rd
Rd
1 Simulation Mode
5 Simulation
2 Uncorr ected Flow 3 VOS
2 Installation
3 Service Menu
2, 3
5
4 Gain 5 Analog In put 1 6 Analog In put 2 7 Digital Input
Opt
Opt
Opt
4
KROHNE UFC030 HA 45e70201 (1/5) 05/04
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 8/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 9
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree HC275 / FC375
1 Dynamic
Variables
2 Configuration /
Test
1
1 Test / Info
2 Installation
1
1 Flow
2 Version
1 Flow Units 2 Full Scale 3 Zero Value 4 Zero Calibration
Opt
5 Master TC
6 L.F.Cutoff
7 Meter Size Units
Opt
8 Meter Size 9 GK Value 10 Flow Direction 11 VOS Min/Max
Units 12 Min VOS 13 Max VOS
1 Converter Function 2 Temperature
Opt
Units 3 Input 1 4mA 4 Input 1 20mA 5 Pressure Units 6 Input 2 4mA 7 Input 2 20mA
Opt
8 K0
Opt
9 K1 10 K2 11 Density 15 12 Heat Flow Units 13 Full Scale
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
1 L.F.Cutoff 2 Cutoff on 3 Cutoff off
Opt
Opt
3 Quit/Reset 4 HART Variables
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local HC275/FC375,
affects only HC275/FC375 views
3 Service Menu
4
3 Display
4 Current Output I 5 Pulse Output P 6 Digital Input C
5
7 User Data 8 Logging
1 Display Flow 2 Function Totalizer 3 Display Totalizer 4 Volume Units 5 Energy Units 6 VOS Units 7 Cyclic Display 8 Error Messages 9 Date 10 Analog Input 11 Signal Gain
12 Display Formats
3
Opt
Opt
1 Format Flow 2 Format
Opt
Heat Flow 3 Format Volume 4 Format
Energy
KROHNE UFC030 HA 45e70201 (2/5) 05/04
Loc
Loc, Opt
Loc
Loc, Opt
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 9/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 10
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree HC275 / FC375
1 Dynamic
Variables
2 Configuration /
Test
1
1 Test / Info
2 Installation
1 Flow
1
2 Version 3 Display
4 Current Output I
5 Pulse Output P
6 User Data
1 Function I
1
2 Direction I 3 Range I 4 I 0% 5 I 100% 6 Limit
1 Function P 2 Direction P 3 Digital Output 4 Trip.Point 1 5 Trip.Point 2 6 Time Constant 7 Output 8 Pulserate Units 9 Pulsrate 10 Units
Pulse/Unit 11 Pu lse/Un it 12 Pulswidth
1 Language 2 Entry Code 1 3 tag 4 Text Volume 5 Text Time 6 Unit V olu me 7 Unit Time 8 Enable Reset 9 Error Limit 10 Counter
Decrement 11 Counter Limit
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
3 Quit/Reset 4 HART Variables
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local HC275/FC375,
affects only HC275/FC375 views
3 Service Menu
5
4
KROHNE UFC030 HA 45e70201 (3/5) 05/04
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 10/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 11
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree HC275 / FC375
1 Dynamic
Variables
2 Configuration /
Test
3 Quit/Reset
4 HART Variables
1
1 Test / Info
2 Installation
3 Service Menu
1 Quit Errors 2 Reset Totalizers 3 Master R eset 4 Reset Conf. Flag
1 Communication
2 Device inform.
3 Dyn. Vars Settings
1
2, 3
5
Opt
1 Poll addr 2 Num req preams
Rd
3 Num resp preams
1 Manufacturer 2 Model 3 Dev id
Rd
Rd
Rd
4 Tag 5 Date 6 Dev des 7 Message 8 Write protect
Rd
9 Final asmbly num 10 Snsr s/n
11 Revision #'s
Rd
1 PV is
1 Universal rev 2 Fld dev rev 3 Software rev 4 Hardware rev
Rd
Rd
Rd
Rd
2 SV is 3 TV is 4 4V is
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local HC275/FC375,
affects only HC275/FC375 views
KROHNE UFC030 HA 45e70201 (4/5) 05/04
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 11/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 12
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree HC275 / FC375
1 Dynamic
Variables
2 Configuration /
Test
1
1 Test / Info
2 Installation
3 Service Menu
1
2, 3
1 Service Code
2 System
3 Current Output I
Opt
4 Sensor
5 Measuring Path
1 Reset Menu Par. 2 Reset Service Par. 3 Reset Calib. Par. 4 Reset All Par. 5 Reset Factory Par. 6 Meter Size Table
Opt
7 Version
1 Calibration 4 mA 2 Calibration 20 mA 3 Calibrate Current
Output I
1 Dead Time 2 Trigger Select
Opt
3 Trigger Level 1 4 Trigger Margin 5 Sensor Frequency 6 Zero Value Path 1
....
Opt
1 Select Path
2 Weight 1
1 Path 1 active
... ... 5 Calibrate Path 6 Length 1 ... 9 T. Win dow Start 10 T. Window End
3 Quit/Reset 4 HART Variables
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local HC275/FC375,
affects only HC275/FC375 views
1 Calibrate Analog
6 An. Inp. Calib.
Opt
Input 1
2 Calibrate Analog
Input 2 3 Input 1 0mA 4 Input 1 20mA 5 Input 2 0mA 6 Input 2 20mA
1 SI units 2 Pulse Output
1 Manufacturer
7 Device
Infor mation
Opt
2 Model No. 3 Serial Number
Rd
4 µP2 HW No. 5 Front end HW No. 6 DSP HW No.
7 Available I/O
4
8 Raw Values
Opt
1 Rel. Flow Speed 1 ... 4 SOS 1
3 Current Output 4 Digital Input 5 Analog IO module 6 HART Interface 7 FF Interface 8 PA Interface
Rd
Rd
9 MODIS Version
Rd
Rd
... 7 Gain 1 ...
KROHNE UFC030 HA 45e70201 (5/5) 05/04
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 12/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 13
Attachment B
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree AMS
Configure
Compare
Clear Offline
-----------------------------------
Status/Conditions
Process Variables
Scan Device
-----------------------------------
Calibration Management
Diagnostics and Test
Calibrate
Reset
Paramter Protection
-----------------------------------
Rename
Unassign
Assign / Replace
-----------------------------------
Audit Trail
Record Manual Event
Drawings / Notes ...
Help ...
Basic Setup
Sensor
•Zero Value
• Flow Direction
Process Input
•Flow Units
• Full Scale
•Master TC
•L.F. Cutoff
• Cutoff on
• Cutoff off
Correction
• Converter Function
Sensor Meter
• Meter Size Table
•Meter Size Units
3
•Meter Size
•GK Value
Volume Flow Limits
• Upper Sensor Limit
• Minim um Span
Heat Flow Limits
2
• Upper Sensor Limit
• Minim um Span
Process Input
•Flow Units
• Full Scale
•Master TC
L.F. Cutoff
•L.F. Cutoff
• Cutoff on
• Cutoff off
• VOS Min/Max Units
•Min VOS
•Max VOS
Correction
Current / Pulse Output
• Function I
•Range I
• Function P
•Output
Opt
Opt
Display
• Function Totalizer
Opt
Opt
• Display Totalizer
Version
• Converter Function
•Temperature Units
• Input 1 4mA
• Input 1 20mA
• Pressure Un its
• Input 2 4mA
• Input 2 20mA
Opt
•K0
Opt
•K1
Opt
•K2
• Density 15
• Heat Flow Units
• Full Scale
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Analog Input Calibration
Opt
• Input 1 0mA
Opt
Opt
•Zero Value
•Flow Direction
Opt
Sensor
• Input 1 20mA
• Input 2 0mA
• Input 2 20mA
• Dead Time
•Trigger Select
Rd
Rd
Opt
Rd
Opt
Opt
•Trigger Level 1
• Trigger Margin
• Sensor Frequency
Rd
Current Output
Current Output
• Function I
•Direction I
•Range I
•I 0%
• I 100%
•Limit
•Calibration 4mA
• Calibration 20mA
Pulse Output
• Function P
•Direction P
•Digital Output
•Trip. Point 1
•Trip. Point 2
• Time Constant
Opt
Opt
•Output
•PulserateUnits
•Pulserate
• Units Pulse/Un it
• Pulse/Unit
•Pulsewidth
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local AMS, affects on ly AMS views
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 13/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Display
•Display Flow
• Function Totalizer
•Display Totalizer
• Volume Units
•Energy Units
• VOS Units
•Analog Input
Opt
Opt
Opt
•Signal Gain
Local Display
•Language
• Cyclic Display
• Error Messages
•Date
•Text Volume
•Text Time
•Unit Volume
•Unit Time
Display Formats
•Format Flow
•Format Heat Flow
•Format Volume
• Format Energy
KROHNE UFC 030 HA 45e70201 (1/3) 09/04
Loc
Opt, Loc
Loc
Opt, Loc
Page 14
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree AMS
Configure
Compare
Clear Offline
-----------------------------------
Status/Conditions
Process Variables
Scan Device
-----------------------------------
Calibration Management
Diagnostics and Test
Calibrate
Reset
Paramter Protection
-----------------------------------
Rename
Unassign
Assign / Replace
-----------------------------------
Audit Trail
Record Manual Event
Drawings / Notes ...
Help ...
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local AMS, affects on ly AMS views
Measuring Path
• Path 1 active ...
•Weight 1 ...
• Length 1 ...
•Zero Value Path 1
• Time Window Start
• Time Window End
Device
Device Info
• Manufacturer
•Model Number
• Serial Number
•µP1 HW No.
•µP2 SW No.
• FE HW No.
3
• DSP HW No.
• DSP SW No.
HART
Revision Numbers
• Universal rev
• Fld dev rev
•Software rev
• Hardware rev
Preambles
•Num reqpreams
• Num resp preams
Test Current Output I Test Pulse Output P Test Analog Inputs
Quit Errors Reset Totalizers Master Reset Reset Conf. Changed Flag Reset Menu Parameters Reset Service Param. Reset Calibration Par. Reset All Parameters Reset Factory Par.
Entry Code 1 Service Code
Simulation
Plausibility Filter
• Error Limit
• Counter Decrement
• Counter Limit
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
•Version
• Enable Reset
Identification
• Manufacturer
Rd
•Model
•Dev ID
Rd
•Poll Addr
Rd
•Tag
Rd
Rd
Opt
Opt
•Date
•Dev des
•Message
•Write Protect
Zero Calibration
Rd
Calibrate Current O. I Calibrate Analog Inp. 1
Opt
Opt
Opt
Opt
Opt
Opt
Calibrate Analog Inp. 2 Calibrate P ath
Opt
• S imu lat ion Mode
• Uncorrected Flow
• VOS
•Gain
• Analog Input 1
• Analog Input 2
Available I/O
•SI Units
• Pulse Output
• Current Output
• Digital Input
Opt
Opt
Opt
Opt
• Analog IO module
•HART Interface
• FF Interface
• PA Interface
Opt, Rd
Opt, Rd
• MODIS Version
Final asmbly num Snsr s/n
Dynamic Variables Settings
Rd
•PV is
•SV is
•TV is
•4V is
Opt
Opt
Opt
Opt
KROHNE UFC 030 HA 45e70201 (2/3) 09/04
Opt
Opt
Opt
Opt
Opt, Rd
Opt, Rd
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 14/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 15
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree AMS
1
Configure
Compare
Clear Offline
-----------------------------------
Status/Conditions
Process Variables
Scan Device
-----------------------------------
Calibration Management
Diagnostics and Test
Calibrate
2
Reset
Paramter Protection
-----------------------------------
Rename
Unassign
Assign / Replace
-----------------------------------
Audit Trail
Record Manual Event
Drawings / Notes ...
Help ...
Overview
• Primary variable out of limits
• Non-primary variable out of limits
• Primary variable analog output saturated
• Primary variable analog output f ixed
•Cold start
• Configuration changed
• Field device malfunction
IO / Totalizers
• Underrun analog input 1
• Overrun analog input 1
• Underrun analog input 2
• Overrun analog input 2
• 2 0mA An a log In pu t H W Error
•Calibration Data Lost
• Current Output Overrange
• Current Output in fixed mode
• Pulse Output Overrange
• Pulse Output in fixed mode
Process Values
• Actual Flow
• Corrected Flow
Opt
• VOS
Correction
• Analog Input 1
• Analog Input 2
Opt
Opt
Additional Values
• F/R Indication
•Gain
Sensor / Device
• Path 1 Signal Failure
•…
• Path 3 Signal Failure
• Sensor open
•Sensor short circuit
•Unreliable
•Empty Pipe Error
• Totalizer Overrun Error
• Totalizer Storage Error
• PRimary flow Overrun Error
• SECondary flow Overrun Error
Totalizers
• Totalizer 1
• Totalizer 2
• Totalizer Sum
Opt
Opt
Opt
• Signal Proc. Contr. Error
• Peripheral Contr. Error
•HW error frontend
• Communication error
• EEPROM R/W Error
• Checks. err. service par.
• Checks. err. menu par.
• S imu lat ion mode active
•Restart
Raw Values
• Relative Flow Speed 1 ... 3
• SOS 1 ... 3
• Gain 1 ... 3
Opt
Opt
Opt
Current Output
•Value
• Percent of Range
Pulse Output P
Opt
•Value
• Percent of Range
Opt
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local AMS, affects on ly AMS views
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 15/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Device
•Tag
•Descriptor
HART
Opt
• Polling Address
• Device ID
KROHNE UFC 030 HA 45e70201 (3/3) 09/04
Page 16
Attachment C
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree PDM
Menu Bar
File Device View Options Help
Communication Path
----------------------------------­Load To Device Load To P G/PC
----------------------------------­Set Address
-----------------------------------
Simulation
Test
-----------------------------------
Reset
-----------------------------------
Calibration
2,3
Simulation
• Simulation Mode
• Uncorrected Flow
• VOS
•Gain
• Analog Input 1
• Analog Input 2
Test
Opt
Inputs
Opt
Opt
• Analog Input 1
• Analog Input 2
Reset
•Reset
•<Quit Errors>
•<Reset Totalizers>
Opt
•<Master Reset>
• <Reset Conf. Changed Fl.>
Calibration Zero Calibration
• Zero Value 1 ... 3
• <Zero Calibration>
Current Output Calibr.
•Calibration4 mA
• Calibration 20 mA
• <Calibrate Current O.>
Opt, Rd
Opt
Opt
Opt
Opt
Opt
Outputs
• Test Current Output I
• Test Pulse Output P
Opt
Reset Device Parameters
•<Reset Menu Par.>
• <Reset Service Par.>
• <Reset Calibration Par.>
• <Reset All Par.>
•<Reset Factory Par.>
Analog Input Ca libr.
• Input 1 0mA
• Input 1 20mA
• Input 2 0mA
• Input 2 20mA
• <Calibr. An. Inp. 1>
• <Calibr. An. Inp. 2>
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Measuring Path Calibr.
• <Calibrate Path>
Opt
Opt
-----------------------------------
Parameter Protection
-----------------------------------
HART Communication
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local PDM, affects only PDM views
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 16/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Parameter Protection
•Entry Code Lock
• <Activcte/D eactivate Entry Code Lock>
• Service Code Lock
Rd
Rd
• <Deactivate Service Code Lock>
HART Communication Preambles
• Request Preambles
• Response Preambles
Dynamic Variables Settings
•PV is
Rd
Rd
•SV is
•TV is
•4V is
KROHNE UFC030 HA 45e80101 (1/5)
09.04
Page 17
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree PDM
Menu Bar
1
File Device View Options Help
Display
Yt Diagram
Outputs/Inputs
Measured Values
•Actual Flow
• Corrected Flow
•VOS
•F/R Indication
•Gain
•Digital Output
• Device Status
Y t Diagram
•Actual Flow
• Corrected Flow
• VOS
Current Outputs
• Function I
• Digital Value I
•Analog Value I
• Percent of Range
•Full Scale
Rd
Opt
Totalizer
Opt
• Totalizer 1
• Totalizer 2
• Totalizer Sum
Analog Inputs
Opt
Opt
• Analog Input 1
• Analog Input 2
Pulse Output
• Function P
• Digital Value P
•Analog Value P
• Percent of Range
•Full Scale
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Rd
Raw Values
•Relative Flow Speed 1 ... 3
•SOS 1 ... 3
• Gain 1 ... 3
Analog Inputs
• Analog Input 1
• Analog Input 2
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Device Status
----------------------------------­Toolbar Status Bar
----------------------------------­Update
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local PDM, affects only PDM views
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 17/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
3
KROHNE UFC030 HA 45e80101 (2/5)
09.04
Page 18
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree PDM
Menu Bar
1
File Device View Options Help
Display
Yt Diagram
Outputs/Inputs
Device Status
----------------------------------­Toolbar Status B ar
----------------------------------­Update
Device Device Info
• Manufacturer
2
Rd
• Model Number
•Serial Number
• µP1 HW No.
• µP2 SW No.
• FE HW No.
• DSP HW No.
• DSP SW No.
Rd
Rd
Rd
Rd
Rd
Status
Overview
• Primary variable out of limits
• Non-primary variable out of limits
• Analog Output outside the operating range limits
• Analog Output in fixed mode
• Cold start
• Con figuration changed
• Field device malfunction
I/O
• Calibration Data Lost
• 20mA Analog Input HW Error
• Underrun analog input 1
• Overrun analog input 1
• Underrun analog input 2
• Overrun analog input 2
• Current Output Overrange
• Pulse Output Overrange
• Current Output in fixed mode
• Pulse Output in fixed mode
HART IDs
Rd
Rd
•Tag
• Manufacturer
•Device Type
Rd
Rd
•HART Device ID
• Universal Revision
•Device Revision
Rd
• Software Revision
• Hardware Revision
Rd
•Date
• Final Assem bly No.
• Sensor Serial No.
Sensor
• Sensor open
• Sensor short circuit
• Path 1 Signal Failure
•…
• Path 3 Signal Failure
Rd
Rd
Rd
Rd
Rd
Rd
Device Status
• Unreliable
•Empty Pipe Error
• Signal Proc. Contr. Error
• Peripheral Contr. Error
• HW erro r frontend
• Communication error
• EEPROM R/W Error
• Checks. err. service par.
• Checks. err. menu par.
• Simulation mode active
•Restart
Totalizers
• Totalizer Overrun Error
• Totalizer Storage Error
• PRimary flow Overrun Error
• SECondary flow Overrun Error
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local PDM, affects only PDM views
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 18/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
KROHNE UFC030 HA 45e80101 (3/5)
09.04
Page 19
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree PDM
Parameter Table
Identification
Operation Unit
Device
-----------------------------------
Input
Measuring Limits
Operation Parameter
Sensor
Version
Analog Input
Measuring Path
Plausibility Filter
-----------------------------------
Output
Current Output I
Pulse Output P
-----------------------------------
Human Interface
Local Display
Display Formats
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local PDM, affects only PDM views
Identification
Operation Unit
•Tag
•Descriptor
• Message
Device
• Manufacturer
•Model Number
•Serial Number
• µP1 HW No.
• µP2 SW No.
Opt
Opt
• FE HW No.
•DSP HW No.
•DSP SW No.
•Version
• Meter Size Table
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Opt
•Enable reset
Available I/O
Opt
5
•SI Units
• Pulse Output
• Current Output
Opt
• Digital Input
• Analog IO modu le
•HART Interface
5
• FF Interface
•PA Interface
•MODIS Version
• Time/log Module
HART
• Manufacturer
• Device T ype
•HART Device ID
• Universal Revision
•Field Device Revision
• Software Revision
• Hardware Revision
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Rd
•Date
• Final Assembly No.
•Sensor Serial No.
Input
• Flow Units
• Full Scale
•Zero Value
•Master TC
•GK Value
•Flow Direction
• VOS Min/Max Units
•Min VOS
•Max VOS
• L.F. Cutoff
•Cutoff on
•Cutoff off
Opt
Opt
Input ...
Process Connection
•Meter Size Table
•Meter Size Units
•Meter Size
Measuring Limits
Volume Flow
• Upper Sensor Limit
•Minimum Span Heat Flow
• Upper Sensor Limit
•Minimum Span VOS
• Upper Sensor Limit
•Lower Sensor Limit
•Minimum Span
Operation Parameter
Opt
Sensor
•Dead Time
•Trigger Select
•Trigger Level 1
•Trigger Margin
• Sensor Frequency
Opt
Version
• Converter Function
• Temperature Units
• Input 1 4mA
Opt
• Input 1 20mA
•Pressure Units
• Input 2 4mA
• Input 2 20mA
Opt
•K0
Opt
•K1
Opt
•K2
• Density 15
• Heat Flow Units
•Full Scale
Opt
Opt
Opt
Analog Input Calibration
• Input 1 0mA
• Input 1 20mA
• Input 2 0mA
Opt
• Input 2 20mA
Measuring Path
• Path 1 active ...
•Weight 1 ...
• Length 1 ...
• Zero Value 1 ...
•Time Window Start
•Time Window End
Plausibility Filter
•Error Limit
• Counter Decrement
• Counter Limit
Opt
Opt
Rd
Rd
Rd
Rd
Rd
Rd
Rd
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
KROHNE UFC030 HA 45e80101 (4/5)
09.04
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 19/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Page 20
Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
UFC 030 HART Menu Tree PDM
Parameter Table
Identification
Operation Unit
Device
-----------------------------------
Input
Measuring Limits
Operation Parameter
Sensor
Version
Analog Input
Measuring Path
Opt
Opt
Plausibility Filter
-----------------------------------
Output
Current Output I
Pulse Output P
Opt
-----------------------------------
Human Interface
Local Display
Display Formats
Output
•IO Fitted
4
Current Output I
• Function I
Rd
•Direction I
•Range I
•I 0%
• I 100%
•Limit
•Calibration 4mA
• Calibration 20mA
Pulse Output P
4
• Function P
•Direction P
• Digital Output
•Trip. Point 1
•Trip. Point 2
•Time Constant
Opt
•Output
•PulsrateUnits
•Pulserate
• U nit s Pulse/Un it
•Pulse/Unit
•Pulsewidth
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Opt
Human Interface
• Display Flow
• Function Totalizer
• Display Totalizer
• Volume Units
•Energy Units
• VOS Units
• Analog Input
Opt
Opt
Opt
Opt
• Signal Gain
Local Display
• Language
• Cyclic Display
• Error Messages
Opt
•Date
•Text Volume
•Text Time
•Unit Volume
•Unit Time
Display Formats
•Format Flow
•Format Heat Flow
•Format Volume
• Format Energy
Loc
Opt, Loc
Loc
Opt, Loc
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local PDM, affects only PDM views
KROHNE UFC030 HA 45e80101 (5/5)
09.04
KROHNE Messtechnik GmbH & Co. KG · Ludwig-Krohne-Str. 5 D-47058 Duisburg 20/20 Tel.: 0203-301 0 Fax: 0203-301 389 · e-mail: [email protected]
Loading...
