EDE1074PDW |
EN TUMBLE DRYER |
USER MANUAL |
2 |
|
NL WASDROGER |
GEBRUIKSAANWIJZING |
19 |
|
FR SÈCHE-LINGE |
NOTICE D'UTILISATION |
36 |
|
DE WÄSCHETROCKNER |
BENUTZERINFORMATION |
54 |
2 electrolux
Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
CONTENTS
Important safety information |
2 |
Cleaning and maintenance |
11 |
Product description |
4 |
What to do if ... |
12 |
Control Panel |
5 |
Machine settings |
14 |
Before first use |
5 |
Technical data |
14 |
Sorting and preparing laundry |
5 |
Installation |
15 |
Programme chart |
6 |
Environment |
18 |
Daily use |
9 |
Service |
18 |
Subject to change without notice.
IMPORTANT SAFETY INFORMATION
Important! In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. Save these instructions and make sure that they remain with the appliance if it is moved or sold, so that everyone using it through its life will be properly informed on appliance use and safety.
GENERAL SAFETY
•It is dangerous to alter the specifications or attempt to modify this product in any way.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
•Make sure that small pets do not climb into the drum. To avoid this, please check into the drum before using.
•Any objects such as coins, safety pins, nails, screws, stones or any other hard, sharp material can cause extensive damage and must not be placed into the machine.
•In order to avoid danger of fires caused by excessive drying, do not use appliance to dry the following items: Cush-
ions, quilts and the like (these items accumulate heat).
•Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.
•Always unplug the appliance after use, clean and maintenance.
•Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Centre. Always insist on genuine spare parts.
•Items that have been soiled with substances such as cooking oil acetone, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer.
•Danger of explosion: Never tumble dry items that have been in contact with inflammable solvents (petrol, methylated spirits, dry cleaning fluid and the like). As these substance are volatile, they could cause an explosion. Only tumble dry items washed with water.
•Risk of fire: items that have been spotted or soaked with vegetable or cooking oil constitute a fire hazard and should not be placed in the tumble dryer.
•If you have washed your laundry with stain remover you must execute an extra rinse cycle before loading your tumble dryer.
•Please make sure that no gas lighters or matches have accidentally been left in pockets of garments to be loaded into appliance
Warning! Never stop a tumble dry before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated. Risk of fire!
•Risk of electric shock! Do not spray down the appliance with jets of water.
•The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature that ensures that items will not be damaged.
•Ensure you have adequate ventilation in the installation room to avoid the back flow of gases into the room from appliances burning other fuels, including open fires.
INSTALLATION
•This appliance is heavy. Care should be taken when moving it.
•When unpacking the appliance, check that it is not damaged. If in doubt, do not use it and contact the Service Centre.
•All packing and transit bolts must be removed before use. Serious damage can occur to the product and to property if this is not adhered to. See relevant section in the user manual.
•Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
•Care must be taken to ensure that the appliance does not stand on the electrical supply cable.
•If the machine is situated on a carpeted floor, please adjust the feet in order to allow air to circulate freely.
•After having installed the appliance, check that it is not pressing or standing on its electrical supply cable or/and inlet hose.
•If the tumble dryer is placed on top of a washing machine, it is compulsory to use the stacking kit (optional accessory).
electrolux 3
USE
•This appliance is designed for domestic use. It must not be used for purposes other than those for which it was designed.
•Only wash fabrics which are designed to be machine dried. Follow the instructions on each garment label.
•Do not dry unwashed items in the tumble dryer.
•Do not overload the appliance. See the relevant section in the user manual.
•Clothes which are dripping wet should not be placed in the dryer.
•Garments which have been in contact with volatile petroleum products should not be machine dried. If volatile cleaning fluids are used, care should be taken to ensure that the fluid is removed from the garment before placing in the machine.
•Never pull the power supply cable to remove the plug from the socket; always take hold of the plug itself.
•Never use the tumble dryer if the power supply cable, the control panel, the working surface or the base are damaged so that the inside of the tumble dryer is accessible.
•Fabric softeners, or similar products should be used as specified by the fabric softener instructions.
•Caution - hot surface : Do not touch the door light cover surface when the light is switched on.1)
•
Hot surface: Do not touch the back of the appliance while it is operating!
CHILD SAFETY
•This machine is not intended for use by young children or infirm persons without supervision.
•Children often do not recognise the hazards associated with electrical appliances. Children should be supervised to ensure that they do not play with the appliance.
1) Only dryers equipped with internal drum light.
4 electrolux
Warning!
•Danger of suffocation! The packaging components (e.g. plastic film, polystyrene) can be dangerous to children - Keep them out of children’s reach.
•Keep all detergents in a safe place out of children’s reach.
•Make sure that children or pets do not climb inside the drum.
PRODUCT DESCRIPTION
8
7 |
6 |
1Control panel
2Door
3Fluff filter
4Rating plate
5Adjustable feet
1
2
3
4
5
6Sideways vent outlets / back vent outlet
7Ring nut
8Lamp for inside light
electrolux 5
CONTROL PANEL
|
6 |
5 |
4 |
1 |
2 |
3 |
|
1Programme knob and "O" (OFF) switch
2Function buttons
3START/PAUZE (START PAUSE) button
4FILTER (FILTER) light
5STARTUITSTEL (DELAY START ) button
6Display
WHAT IS SHOWN IN THE DISPLAY
SYMBOL DESCRIPTION
Time to end (time of time programm, time of start delay)
Child lock
Delay start
Drying phase
Cooling phase
Anticrease guard phase
Error, wrong selection
BEFORE FIRST USE
In order to remove any residues which may have been produced during production, wipe the dryer drum with a damp cloth or
carry out a brief drying cycle (ca. 30 min.) with damp cloths in the machine.
SORTING AND PREPARING LAUNDRY
SORTING LAUNDRY
•Sort by fabric type:
–Cotton/linen for programmes in COTTONS programme group.
–Mixtures and synthetics for programmes in SYNTHETICS programme group.
•Sort by care label: The care labels mean:
Drying in the tumble dryer possible in principle
6 electrolux
Drying at normal temperature
Drying at reduced temperature (press DELICATE button!)
Drying in the tumble dryer not possible
Important! Do not place in the appliance any wet laundry which is not specified on the care label as being suitable for tumbledrying.
This appliance can be used for all wet laundry items which are labelled as suitable for tumble-drying.
•Do not dry new, coloured textiles together with light-coloured laundry items. Textile colours may bleed.
•Do not dry cotton jersey and knitwear with the EXTRA DRY programme. Items may shrink!
•Wool and wool-like textiles can be dried
using the WOOL CARE programme.
Preparing laundry
•To avoid laundry becoming tangled: close zips, button up duvet covers and tie loose ties or ribbons (e.g. of aprons).
•Empty pockets. Remove metal items (paper clips, safety pins, etc).
•Turn items with double-layered fabrics inside out (e.g. with cotton-lined anoraks, the cotton layer should be outermost). These fabrics will then dry better.
Important! Do not overload the appliance. Observe max. loading volume of 7 kg.
LAUNDRY WEIGHTS
Type of laun- |
|
Weight |
dry |
|
|
Bathrobe |
|
1200 g |
Napkin |
|
100 g |
Quilt cover |
|
700 g |
Sheet |
|
500 g |
Pillow case |
|
200 g |
Tablecloth |
|
250 g |
Towelling tow- |
|
200 g |
el |
|
|
Tea cloth |
|
100 g |
Night dress |
|
200 g |
Ladies' briefs |
|
100 g |
Man's work |
|
600 g |
shirt |
|
|
Man's work |
|
200 g |
shirt |
|
|
Man's pyja- |
|
500 g |
mas |
|
|
Blouse |
|
100 g |
Men's under- |
|
100 g |
pants |
|
|
|
|
|
PROGRAMME CHART
Programmes
KATOEN
(COTTON) EXTRA DROOG
(EXTRA
DRY)
(weightwhen dry) |
Additional functions/op- |
|
Application/properties |
|
Care mark |
||
|
|
|
|
||||
|
tions |
|
|
|
|
||
|
|
|
|
|
|
||
max. load |
|
|
|
|
|
|
|
|
LAGE TEMP. |
(DELICATE) , |
|
|
|
|
|
7 kg |
ANT-IKREUK |
(LONG ANTI- |
|
Thorough drying of thick or multi- |
|
|
|
CREASE) , ZOEMER |
(BUZ- |
|
layered fabrics, e.g. terry towelling |
|
|
||
|
ZER) , STARTUITSTEL (DELAY |
|
items, bathrobes. |
|
|
||
|
START) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
electrolux 7 |
||
|
|
|
|
|
|
|
|
|
|
|
|
Programmes |
|
(weightwhen dry) |
Additional functions/op- |
|
Application/properties |
|
Care mark |
||||
|
|
|
tions |
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
||
|
|
|
max. load |
|
|
|
|
|
|
|
|
KATOEN |
|
|
LAGE TEMP. |
(DELICATE) , |
|
|
|
|
|||
(COTTON) |
|
|
|
|
|
|
|||||
|
|
ANT-IKREUK |
(LONG ANTI- |
|
Thorough drying of thick or multi- |
|
|
||||
STERK- |
|
7 kg |
|
|
|
||||||
|
CREASE) , ZOEMER |
(BUZ- |
|
layered fabrics, e.g. terry towelling |
|
|
|||||
DROOG |
|
|
|
|
|||||||
|
|
ZER) , |
STARTUITSTEL (DE- |
|
items, bathrobes. |
|
|
||||
(STRONG |
|
|
|
|
|
||||||
|
|
|
LAY START) |
|
|
|
|
|
|||
DRY) |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
KATOEN |
|
|
LAGE TEMP. |
(DELICATE) , |
|
|
|
|
|||
(COTTON) |
|
7 kg |
ANT-IKREUK |
(LONG ANTI- |
|
Thorough drying of fabrics of even |
|
|
|||
KASTDROOG |
|
CREASE) , ZOEMER (BUZ- |
|
thicknesses, e.g. terry towelling |
|
|
|||||
1) |
(STOR- |
|
|
ZER) , |
STARTUITSTEL (DE- |
|
items, knitwear, towels. |
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
AGE DRY) |
|
|
|
LAY START) |
|
|
|
|
|
||
KATOEN |
|
|
LAGE TEMP. |
(DELICATE) , |
|
|
|
|
|||
(COTTON) |
|
|
ANT-IKREUK |
(LONG ANTI- |
|
For thin textiles which are still to be |
|
|
|||
STRIJK- |
|
7 kg |
CREASE) , ZOEMER |
(BUZ- |
|
ironed, e.g. knitted items, cotton |
|
|
|||
DROOG+ |
|
|
ZER) , STARTUITSTEL (DE- |
|
shirts. |
|
|
||||
1) (DAMP) |
|
|
|
|
|
|
|||||
|
|
|
LAY START) |
|
|
|
|
|
|||
KATOEN |
|
|
LAGE TEMP. 3) |
(DELI- |
|
|
|
|
|||
|
|
CATE) , ANT-IKREUK |
|
|
|
|
|||||
(COTTON) |
|
|
|
For thin fabrics which are also to be |
|
|
|||||
|
7 kg |
(LONG ANTI-CREASE) , |
|
|
|
||||||
STRIJK- |
|
|
|
|
|||||||
|
ZOEMER |
(BUZZER) , |
|
ironed, e.g. knitwear, cotton shirts. |
|
|
|||||
DROOG |
|
|
|
|
|
||||||
|
|
|
|
|
|
||||||
|
|
STARTUITSTEL (DELAY |
|
|
|
|
|||||
(IRON DRY) |
|
|
|
|
|
|
|||||
|
|
|
START) |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
||
SYNTHE- |
|
|
LAGE TEMP. |
(DELICATE) , |
|
|
|
|
|||
TISCH |
|
|
|
|
|
|
|||||
|
|
ANT-IKREUK |
(LONG ANTI- |
|
Thorough drying of thick or multi- |
|
|
||||
(SYNTHET- |
|
3 kg |
|
|
2) |
||||||
|
CREASE) , ZOEMER |
(BUZ- |
|
layered fabrics, e.g. pullovers, bed- |
|
||||||
ICS) EXTRA |
|
|
|
|
|||||||
|
|
ZER) , |
STARTUITSTEL (DE- |
|
ding, table linen. |
|
|
||||
DROOG (EX- |
|
|
|
|
|
||||||
TRA DRY) |
|
|
|
LAY START) |
|
|
|
|
|
||
SYNTHE- |
|
|
LAGE TEMP. |
(DELICATE) , |
|
|
|
|
|||
TISCH |
|
|
|
For thin fabrics which are not iron- |
|
|
|||||
(SYNTHET- |
|
|
ANT-IKREUK |
(LONG ANTI- |
|
|
2) |
||||
|
|
|
ed, e.g. easy care shirts, table linen, |
|
|||||||
ICS) KAST- |
|
3 kg |
CREASE) , ZOEMER |
(BUZ- |
|
|
|
||||
|
|
baby clothes, socks, lingerie with |
|
|
|||||||
DROOG 1) |
|
|
ZER) , STARTUITSTEL (DELAY |
|
|
|
|||||
|
|
|
bones or wires. |
|
|
||||||
(STORAGE |
|
|
|
START) |
|
|
|
|
|||
|
|
|
|
|
|
|
|
||||
DRY) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 electrolux
Programmes
SYNTHE-
TISCH
(SYNTHETICS) STRIJK-
DROOG
(IRON DRY)
TIJD
(TIME)
MIX
(MIXED)
STRIJKVRIJ
(EASY IRON
JEANS (JEANS)
WOL OPFRIS-
SEN
(WOOL CARE)
max. load (weight when dry)
3 kg
7 kg
3 kg
1 kg (or 5 shirt s)
7 kg
1 kg
Additional functions/options
LAGE TEMP. 3)
(DELI-
CATE) , ANT-IKREUK
(LONG ANTI-CREASE) ,
ZOEMER
(BUZZER) , STARTUITSTEL (DELAY
START)
STARTUITSTEL
(DELAY START)
LAGE TEMP.
(DELICATE) , ANT-IKREUK
(LONG ANTI-
CREASE) , ZOEMER (BUZZER) , STARTUITSTEL (DELAY
START)
, TIJD (TIME)
LAGE TEMP. 3)
(DELI-
CATE) , ANT-IKREUK
(LONG ANTI-CREASE) ,
ZOEMER
(BUZZER) , STARTUITSTEL (DELAY
START)
LAGE TEMP. 3)
(DELI-
CATE) , ANT-IKREUK
(LONG ANTI-CREASE) ,
ZOEMER
(BUZZER) , STARTUITSTEL (DELAY
START)
LAGE TEMP.
, ANT-IK- REUK
(LONG ANTI-
CREASE) , ZOEMER (BUZZER) , STARTUITSTEL (DELAY
START)
LAGE TEMP.
(DELICATE) ,
, ZOEMER
(BUZZER) , STARTUITSTEL (DELAY
START)
Care mark
Application/properties
2)
For thin fabrics which are also to be ironed, e.g. knitwear, cotton shirts.
For further drying of individual items of laundry.
For drying cotton and synthetic fabrics, uses low temperature.
Special programme with anti-crease mechanism for easy care textiles such shirts and blouses; for minimum ironing effort. The result depends on the type and quality of textiles. (The loading volume corresponds to approx. 5 to 7 shirts.) Recommendation: Place textiles in the dryer straight after spinning. Once dried, immediately remove textiles and place on clothes hanger.
For leisure clothing, such as jeans, sweat-shirts, etc., of different material thicknesses (e.g. at the neck, cuffs and seams).
WOL is special programme for briefly treating woollens with warm air after they have been dried naturally, worn or stored for long periods. Wool fibres are aligned and the wool becomes soft and snugly.
|
|
when dry) |
|
Programmes |
|
(weightloadmax. |
Additional functions/op- |
|
|
tions |
|
|
|
|
|
|
|
|
|
OPFRISSEN |
|
|
|
(COOL- |
|
7 kg |
ZOEMER (BUZZER) |
ING) |
|
|
|
|
|
|
|
1)In accordance with IEC61121
2)select LAGE TEMP. option
3)Automatic
electrolux 9
Care mark
Application/properties
Special programme, lasting around 10 minutes, for refreshing or gently cleaning textiles with commercially available dry cleaning sets. (Only use those products which are declared as suitable for the drier by the manufacturer; please observe the manufacturer’s instructions for use.)
DAILY USE
SWITCHING APPLIANCE ON
Turn the programme dial to one of the programmes. The appliance is on.
DOOR OPENING AND LAUNDRY LOADING
1.Open loading door:
Push against the loading door (push point)
2. Load your laundry (do not force it in).
Caution! Do not jam laundry in between the loading door and rubber seal.
3.Close loading door securely. Lock must audibly lock.
SELECTING THE PROGRAMME
Use the programme selector to set the programme you require. The estimated time to end of the programme appears in the LCD in h:mm format (hours:minutes).
10 electrolux
during the cycle time elapses by steps of one minute; less than 1 hour the leading zeros are not shown (ex. “59”, “5”, “0”);
SELECTING ADDITIONAL FUNCTIONS
You can choose from the additional functions:
1 |
2 |
3 |
4 |
button 1 - LAGE TEMP.
(DELICATE) button 2 - ANT-IKREUK
(LONG ANTICREASE)
button 3 - ZOEMER
(BUZZER) button 4- TIJD
(TIME)
button 6- STARTUITSTEL (DELAY START)
LAGE TEMP. (DELICATE)
Pressing this button allows drying to be performed at a lower temperature, for delicate items. The corresponding pilot light comes on. This option can also be used for time controlled drying.
ANT-IKREUK (ANTICREASE)
A long anti-crease phase lengthen the anticrease phase (30 min.) at the end of the drying additionally by 60 minutes. The drum rotates at intervals during this phase. This keeps the laundry loose and free of creases. Phase lasts in total 90 minutes. The laundry can be removed at any time during the anti-crease phase.
When the option is active, the ANT-IKREUK light is on.
ZOEMER (BUZZER)
When the drying cycle has finished, an intermittent audible signal will sound. By depressing button ZOEMER the acoustic signal is switched off in the following cases:
• when selecting the programme
•when depressing the buttons
•when the programme selector dial is turned to another position during the programme or when you depress an option button during the cycle
•at the end of the programme.
The corresponding light comes on.
TIJD (TIME)
Use the Time (Time) button to select the programme duration after setting the TIME programme. You can select a programme duration from 20 min. to 3 hours in 10-mi- nute steps.
1.Turn the programme selector to the TIJD (Time) programme.
2.Press the TIJD (Time) button repeatedly until the desired programme duration is
shown in the display, e.g.
for a programme of 20 minutes.
If the programme duration is not selected, the duration is automatically set to 10 mins.
STARTUITSTEL (DELAY START)
With the STARTUITSTEL (delay) button, you can delay the start of a programme by between 30 minutes (30') and a maximum of 20 hours (20h).
1.Select the programme and additional functions.
2.Press the STARTUITSTEL (Delay) button as many times as necessary until
the required time of the delay appears
on the display, e.g.
H if the programme is to be started in 12 hours.
If the display is showing
H and you press the button again, the time delay will be cancelled. The display will show 0 and then the duration of the selected programme.
3.To activate the delay timer, press the START/PAUZE (Start/Pause) button. The amount of time remaining until the programme is set to start is continuously displayed (e.g. 15h, 14h, 13h, … 30' etc).
SETTING CHILD LOCK
The child lock can be set to prevent a programme being accidentally started or a programme in operation being accidentally
changed. The child lock function locks all buttons and the programme knob. The child lock can be activated or deactivated by holding down the ZOEMER (BUZZER) and TIJD (TIME) buttons simultaneously for 5 seconds.
– Before programme is started: Appliance cannot be used
–After programme is started: Programme in operation cannot be changed
The
icon appears in the display to indicate that the child safety device is activated.
The child safety device is not deactivated once the programme comes to an end. If you want to set a new programme, you
must first deactivate the child safety device.
STARTING THE PROGRAMME
Press the START/PAUZE (START / PAUSE) button. The programme is started.
The programme phase is shown in display by appropriate icons. From left to the right, from drying
,anticrease
, to cooling
.
CHANGING PROGRAMME
To change a programme which has been selected by mistake once the programme has started, first turn the programme selector to " O" (OFF) position. The programme is cancelled.
The programme can no longer be changed directly once the programme has started. If nevertheless there is an attempt to change the programme on the programme knob or if an function button (excluding the BUZZER button) is pressed, led above START/PAUSE
electrolux 11
button starts flashing temporarily in yellow. The drying programme is not however affected by this (laundry protection).
DRYING CYCLE COMPLETE / REMOVING LAUNDRY
Once the drying cycle is complete, display shows a blinking "0", under anti-crease
and filter
icon appear dash. If the ZOEMER (Buzzer) button has been pressed, an acoustic signal sounds intermittently for about one minute.
The drying cycles are automatically followed by an anti-crease phase which lasts around 30 minutes. The drum rotates at intervals during this phase. This keeps the laundry loose and free of creases. The laundry can be removed at any time during the anti-crease phase. (The laundry should be taken out towards the end of the anti-crease phase at the latest to prevent creases from forming.) If ANT-IKREUK (Long anticrease)
function has been selected, the anti-crease phase is lengthened by 60 minutes.
1.Open door.
2.Remove laundry.
3.Remove filter after clothes has been removed. Clean the filter.
Warning! Before You place the filter, please check it there is nothing inside the filter seat.
4.Turn the programme selector to "O" (OFF) .
Important! Clean the filter after each drying cycle.
5. Close the door.
CLEANING AND MAINTENANCE
Warning! The tumble dryer is not to be used if industrial chemicals have been used for cleaning!
CLEANING FLUFF FILTER
The filter collect all the fluff which accumulates during drying. To ensure that the dryer
works perfectly, the fluff filter must be cleaned after every drying cycle.
The warning light FILTER
, is on to remind you this operation.
Caution! Never operate the dryer without fluff filter or with damaged or blocked fluff filter.
12 electrolux |
|
1. |
4. The filter can be positioned only to one |
|
side. If position is wrong, the filter over- |
|
hangs. |
|
If the filter will not snap into place, the |
|
loading door cannot be closed. |
|
CLEANING THE DOOR |
|
Clean periodically the interior part of the |
|
door to remove any fluff. Accurate cleaning |
|
ensures correct drying. |
|
CLEANING THE DRUM |
Open loading door and remove laundry.
2.Remove the filter which is built into the lower part of the loading aperture.
3.
Open the filter pressing the button, among two slots on fingers. Clean the filter using dump hand or cloth. After a period of time, a patina due to detergent residue on laundry forms on the filters. When this occurs, clean the filter with warm water using a brush.
Close the filter and do not forget to put it back.
Warning! Before You place the filter, please check it there is nothing inside the filter seat.
Caution! Do not use abrasives or steel wool to clean the drum.
Lime in the water or cleaning agents may form a barely visible lining on the inside of the drum. The degree to which the laundry has been dried is then no longer detected reliably. The laundry is damper than expected when removed from the dryer.
Use a standard domestic cleaner (e.g. vinegar-based cleaner) to wipe down the inside of the drum and drum ribs.
CLEAN OPERATING SCREEN AND HOUSING
Caution! Do not use furniture cleaners or aggressive cleaning agents to clean the machine.
Use a damp cloth to wipe down the operating screen and housing.
WHAT TO DO IF ...
TROUBLESHOOTING BY YOURSELF
If, during operation, the error code E... plus number or letter) appears on the LCD: Switch the machine off and on again. Reset
programme. Press the START/PAUZE (START / PAUSE) button If the error is still displayed, please inform your local Service Force Centre and quote the error code.
Problem |
|
Possible cause |
|
Remedy |
|
|
|
|
|
Dryer does not work.
Drying results unsatisfactory.
Loading door does not close.
When a button is pressed, Err appears on the LCD.
Drum light does not work.
Displayed programme time changes erratically or stays unchanged for a long time.
Drying cycle ends shortly after programme starts.
Drying cycle lasts an unusually long time. Note: After around 5 hours the drying cycle ends automatically.
Mains plug is not plugged in or fuse is not working correctly.
Loading door is open.
Have you pressed the START/ PAUZE (START / PAUSE) button?
Wrong programme selected.
Filter clogged.
Overloading of laundry.
Ventilation slots covered up.
Residue on inside surface of drum or drum ribs.
Conductance of water at installation site differs from standard setting of machine.
Filter not in place.
Washing protection. After the start of the programme, the option can no longer be set.
Programme selector in "O" (OFF) position.
Defective light bulb.
Programme time is corrected automatically depending on type and volume of laundry and level of dampness.
Not enough washing loaded or washing loaded is too dry for selected programme.
Filter clogged.
Load volume too big.
Laundry insufficiently spun.
electrolux 13
Plug in at mains socket. Check fuse in fuse box (domestic installation).
Close loading door.
Press the START/PAUZE (START / PAUSE) button again.
Select a different programme the next time you dry (see “Programme chart” chapter).
Clean filter.
Observe recommended loading volumes.
Uncover ventilation slots.
Clean inside surface of drum and drum ribs.
Re-programme standard setting for degree of drying (see ‘Programming options’ chapter).
Install filter into place.
Turn the programme knob to "O" (OFF) . Set the programme again.
Turn programme selector to any programme.
Replace light bulb (see next section).
Automatic process; this is not a machine fault.
Select time programme or higher drying level (e.g. EXTRA DROOG (EXTRA DRY) instead of KASTDROOG (STORAGE DRY) ).
Clean filter.
Reduce load volume.
Laundry must be adequately spun.
CHANGING THE BULB FOR INTERIOR LIGHTING
Only use a special bulb which is designed specially for dryers. The special bulb can be obtained from your local Service Force centre.
Warning! When the appliance is switched on, the interior lighting
switches itself off after 4 minutes when the door is open.
Warning! Do not use standard bulbs! These develop too much heat and may damage the machine!
Warning! Before replacing the bulb, disconnect the mains plug.
14 electrolux
1.Unscrew cover above the bulb (this can be found directly behind the loading aperture, at the top; refer to “Description of machine” section.)
2.Replace defective bulb.
3.Screw cover back down.
Check the correct positioning of o-ring gasket before screwing back the door light
cover. Do not operate the dryer when missing o-ring gasket on door light cover.
Warning! For safety reasons, the cover must be screwed down tightly. If this is not done, the dryer must not be operated.
MACHINE SETTINGS
ZOEMER SIGNAL PERMANENT OFF
1.Turn the programme selector to any programme.
2.Press simultaneously the ANT-IKREUK (LONG ANTI-CREASE) and ZOEMER (BUZZER) buttons and hold down for approx. 5 seconds.
3.The buzzer is by default always off. You can use ZOEMER button to activate or deactivate sound but machine does not memorize your selection.
WATER HARDNESS
Water contains, a variable quantity of limestone and mineral salts of which quantities vary according to geographical locations thus varying its conductivity values. Relevant variations of the conductivity of the water compared to those prefixed by the factory could slightly influence the residual humidity of the laundry at the end of the cy-
cle. Your dryer allows you to regulate the sensitivity of the drying sensor based on conductivity values of the water.
1.Turn the programme selector to any programme.
2.Press simultaneously the ZOEMER (BUZZER) and START/PAUZE (START PAUSE) buttons and hold down for approx. 5 seconds. The current setting is
on the display: |
– low conduc- |
tivity <300 micro S/cm, |
– me- |
dium conductivity 300-600 micro S/cm,
– high conductivity >600 micro
S/cm
3.Press the START/PAUZE (START PAUSE) button sequentially until you set desired level.
4.To memorize setting press simultaneously the ZOEMER (BUZZER) and START/PAUZE (START PAUSE) buttons or turn knob to "O" (OFF) position
TECHNICAL DATA
Dimensions (mm) |
Width / Height / Depth |
85 x 60 x 58 cm |
Max. depth |
|
1090 mm |
(with the appliance door open) |
|
|
Max. width |
|
950 mm |
(with the appliance door open) |
|
|
Electrical connection |
Voltage |
230 V |
|
Frequency |
50 Hz |
|
Fuse |
16 A |
|
Total power |
2600 W |
Drum volume |
|
108 l |
Weight of the appliance |
|
32,5 kg |
Laundry: max. weight |
|
7 kg |
Type of use |
|
Household |
Ambient temperature |
Min. |
5 °C |
|
Max. |
35 °C |
|
|
|
electrolux 15
Energy consumption 1) |
kWh/cycle |
4,25 kWh |
Annual energy consumption 2) |
|
614,56 kWh |
Energy efficiency class |
|
C |
Power consumption |
Left-on mode |
0,70 W |
|
Off-mode |
0,70 W |
|
|
|
1)With reference to EN 61121. 7 kg of cotton and a spin speed at 1000 rpm.
2)Energy consumption per year in kWh, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used (REGULATION (EU) No 392/2012).
INSTALLATION
Important! The appliance must be moved in vertical position for transport.
APPLIANCE POSITIONING
•It is recommended that, for your convenience, the machine is positioned close to your washing machine.
•The tumble dryer must be installed in a clean place, where dirt does not build up.
•Air must be able to circulate freely all round the appliance. Do not obstruct the front ventilation grille or the air intake grilles at the back of the machine.
•To keep vibration and noise to a minimum when the dryer is in use, it should be placed on a firm, level surface.
•Once in its permanent operating position, check that the dryer is absolutely level with the aid of a spirit level. If it is not, raise or lower the feet until it is.
•The feet must never be removed. Do not restrict the floor clearance through deeply carpets, strips of wood or similar. This might cause heat built-up which would interfere with the operation of the appliance.
Important! The hot air emitted by the tumble dryer can reach temperatures of up to 60°C. The appliance must therefore not be installed on floors which are not resistant to high temperatures.
When operating the tumble dryer, the room temperature must not be lower than +5°C and higher than +35°C, as it may affect the performance of the appliance.
Warning! Should the appliance be moved, it must be transported vertically.
Warning! The appliance must not be installed behind the lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance.
REMOVING TRANSPORT SAFETY PACKAGING
Caution! Before use all parts of the transport packaging must be removed.
1.Open loading door.
2.Pull off adhesive strips from inside machine on top of drum.
3.Remove foil hose and polystyrene padding from the machine.
16 electrolux
A
FITTING THE VENT HOSE
To simplify the installation, there is a choice of vent outlets: one at the back, the others in the left and right-hand side. Connect the hose to whichever is the more convenient by pulling the ring nut (A) from the vent outlet at the back, screwing it on to the hose and pushing it firmly back into place. The unused vents should now be sealed with the special snap covers provided.
A
If the hose is long and the room temperature low, the moisture might condense to water inside the hose. This is an unavoidable natural phenomenon. To prevent this water from Iying in the hose or flowing back into the tumble dryer, it is advisable to drill a small hole (via. 3 mm) in the lowest point of the hose and to place a small container below it. (See picture, point B).
B
Once connected to the dryer, run the vent hose to the desired outlet point, ensuring that the run’s overall length is less than 2 m, and that it contains no more than two bends. As to the outlet itself, if you have decided on a fixed wall/window grille, a good local builder’s merchant should be able to supply you with the necessary fittings and installation advice.
Warning! It is important not to connect the vent hose to, for example, a cooker hood, or a chimney or flue pipe designed to carry the exhaust from a fuel burning appliance.
Note that to avoid condensation problems, it is essential that the dryer be fitted with the flexible hose to carry its “exhaust” at least beyond the kitchen units; preferable outside the kitchen. In order to prevent the appliance from overheating, it is important that the steam exhaust is unobstructed. Therefore, in case of a permanent hose fitted to an exterior wall or ceiling, it must be ensured an exhaust capacity of at least 150 m3/ h. If the dryer is fitted next to kitchen units, make sure that the vent hose is not squashed. If the hose is partially squashed, drying efficiency will be reduced, resulting in longer drying times and higher energy consumption. If the hose is completely squashed, the safety cut-outs with which the machine is fitted may operate. When operating the tumble dryer, the room temperature must not be lower than +5°C and higher than +35°C, as it may affect the performance of the appliance.
DOOR REVERSAL
To make it easier to load or unload the laundry, the door can be reversed. The door must only be reversed by an authorised service engineer. Please contact your local Service Force Centre. The engineer will carry out the door reversal at your cost.
electrolux 17
ELECTRICAL CONNECTION
Details on mains voltage, type of current and the fuses required should be taken from the type plate. The type plate is fitted near the loading aperture (see “Product description” chapter).
Connect the machine to an earthed socket, in accordance with current wiring regulations.
Warning! The manufacturer declines any responsibility for damage or injury through failure to comply with the above safety precautions.
Should the appliance power supply cable need to be replaced, this must be carried out by our Service Center.
Warning! The plug must be accessible after installing the machine.
SPECIAL ACCESSORIES
Stacking kit
A special stacking kit is available through your dealer, to enable the mounting of the dyer on top of a front loading washing machine with cover’s depth between 48 and 60 cm. Read carefully the instructions supplied with the kit.
18 electrolux
ENVIRONMENT
The symbol
on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.
PACKAGING MATERIAL
The packaging materials are environmentally friendly and can be recycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the
packaging materials in the appropriate container at the community waste disposal facilities.
Warning! When disposing of old appliances, remove the mains cable and dispose of together with the plug. Remove the door hook and ensure it is no longer lockable to prevent young children being trapped inside.
ENVIRONMENTAL TIPS
•In the dryer, laundry becomes fluffy and soft. Fabric softeners are not therefore needed when washing.
•Your dryer will function most economically if you:
–always keep the ventilation slots on the base of the dryer unobstructed;
–use the loading volumes specified in the programme overview;
–clean the filter after each drying cycle;
–spin the laundry well before drying.
SERVICE
In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the operating instructions - see chapter What to do if….
If you were not able to remedy the problem yourself, please contact the Customer Care Department or one of our service partners. In order to be able to assist you quickly, we require the following information:
–Model description
–Product number (PNC)
–Serial number (S No. is on rating plate stuck to the product - to find it see chapter
Product description))
–Type of fault
–Any error messages displayed by the appliance
So that you have the necessary reference numbers from your appliance at hand, we recommend that you write them in here:
Model description:
PNC:
S No:
electrolux 19
Electrolux. Thinking of you.
Ga voor meer van onze ideeën naar www.electrolux.com
INHOUD
Belangrijke veiligheidsinformatie |
19 |
Reiniging en onderhoud |
28 |
Productbeschrijving |
21 |
Wat moet u doen als… |
29 |
Bedieningspaneel |
22 |
Machine-instellingen |
31 |
Voordat u de droger in gebruik neemt |
22 |
Technische gegevens |
31 |
Wasgoed sorteren en voorbereiden |
22 |
Installatie |
32 |
Programmatabel |
24 |
Milieu |
35 |
Dagelijks gebruik |
26 |
Onderhoud |
35 |
Wijzigingen voorbehouden.
BELANGRIJKE VEILIGHEIDSINFORMATIE
Belangrijk! In het belang van uw veiligheid en om een correct gebruik te kunnen waarborgen is het van belang dat u, alvorens het apparaat te installeren en in gebruik te nemen, deze gebruiksaanwijzing, inclusief de tips en waarschuwingen, grondig doorleest. Om onnodige vergissingen en ongevallen te voorkomen is het belangrijk ervoor te zorgen dat alle mensen die het apparaat gebruiken, volledig bekend zijn met de werking ervan en de veiligheidsvoorzieningen Bewaar deze instructies en zorg ervoor dat zij bij het apparaat blijven als het wordt verplaatst of verkocht, zodat iedereen die het apparaat gedurende zijn hele levensduur gebruikt, naar behoren is geïnformeerd over het gebruik en de veiligheid van het apparaat.
ALGEMENE VEILIGHEID
•Het is gevaarlijk om de specificaties te wijzigen of om te proberen op enigerlei wijze veranderingen aan te brengen aan dit apparaat.
•Dit apparaat is niet bedoeld voor gebruik door personen (met inbegrip van kinderen) met beperkte lichamelijke of verstandelijke vermogens of een gebrek aan ervaring en kennis, tenzij dit onder toezicht gebeurt van een voor hun veiligheid verantwoordelijke persoon of tenzij zij van een dergelijke persoon instructie hebben ontvangen over het gebruik van het apparaat.
•Zorg ervoor dat kleine huisdieren niet in de trommel klimmen. Controleer om dit te voorkomen de trommel vóór gebruik.
•Voorwerpen als munten, veiligheidsspelden, spijkers, schroeven, stenen of andere harde, scherpe materialen kunnen grote schade aan het apparaat toebrengen en mogen niet in het apparaat terechtkomen.
•Om brandgevaar te voorkomen door te lang drogen, dient het apparaat niet gebruikt te worden om de volgende voorwerpen te drogen: Kussens, gewatteerde dekens en dergelijke (deze artikelen zorgen voor ophoping van hitte).
•Artikelen van schuimrubber (latexschuim), douchemutsjes, waterdichte kleding, artikelen met een rubberbinnenkant en kleding of kussens met vulling van schuimrubber dienen niet in de droogtrommel te worden gedroogd.
•Het apparaat dient na gebruik, bij reiniging en bij onderhoud altijd afgesloten te worden van stroomvoorziening.
•Probeer in geen geval zelf de machine te repareren. Reparaties die door niet-des- kundige personen uitgevoerd worden, kunnen tot schade of letsel leiden. Neem contact op met een Klantenservice bij u in de buurt. Vraag altijd om originele vervangingsonderdelen.
•Artikelen die zijn bevuild met stoffen als spijsolie, aceton, benzine, petroleum, vlekkenverwijderaars terpentine, boenwas en boenwasverwijderaars dienen alvorens in de droogtrommel te worden gedroogd, te worden gewassen in heet
20 electrolux
water met een extra hoeveelheid wasmiddel.
•Explosiegevaar: droog nooit voorwerpen in de wasdroger die in aanraking zijn geweest met ontvlambare oplosmiddelen (petroleum, spiritus, producten voor chemische reiniging en dergelijke). Aangezien deze bestanddelen vluchtig zijn, kunnen ze een explosie veroorzaken. Droog alleen voorwerpen in de wasdroger die met water gewassen zijn.
•Brandgevaar: voorwerpen die vlekken bevatten of gedrenkt zijn in plantaardige of bakolie vormen een gevaar voor brand en mogen niet in de wasdroger geplaatst worden.
•Als u uw was met vlekkenverwijderaar heeft gewassen, moet u een extra spoelcyclus uitvoeren voordat u uw was in de wasdroger laadt.
•Zorg ervoor dat er geen aanstekers of lucifers in de zakken zijn achtergebleven van kleding die in de wasdroger geladen wordt
Waarschuwing! Stop een wasdroger nooit voor het einde van een droogcyclus, tenzij alle voorwerpen snel uit de trommel verwijderd en uitgehangen worden, zodat de hitte wordt verdreven. Brandgevaar!
•Gevaar voor elektrische schokken!
Spuit geen waterstralen op het apparaat.
•Het laatste deel van een droogcyclus vindt plaats zonder warmte (koelcyclus) om ervoor te zorgen dat de artikelen uiteindelijk een temperatuur hebben waarbij is gewaarborgd dat de artikelen niet worden beschadigd.
•Zorg voor een goede ventilatie in de ruimte waar het apparaat geïnstalleerd is om het terugstromen van gassen van apparaten in de ruimte die op andere brandstoffen werken, zoals open haarden, te voorkomen.
INSTALLATIE
•Dit apparaat is zwaar. Wees voorzichtig als u het apparaat verplaatst.
•Controleer bij het uitpakken van het apparaat of dit niet is beschadigd. Gebruik het apparaat bij twijfel niet en neem contact op met de Klantenservice.
•Alle verpakkingsmaterialen en transportbouten moeten vóór het gebruik worden verwijderd. Als dit wordt nagelaten kan dit ernstige schade aan het product en andere eigendommen tot gevolg hebben. Zie het desbetreffende hoofdstuk in de gebruiksaanwijzing.
•Eventuele voor de installatie van het apparaat noodzakelijke elektrotechnische werkzaamheden, moeten worden uitgevoerd door een gekwalificeerde elektricien.
•Er moet voor gezorgd worden dat het apparaat niet op het aansluitsnoer komt te staan.
•Als het apparaat op een tapijtvloer wordt geplaatst, dient de hoogte van de stelpootjes te worden aangepast om de lucht toch goed te kunnen laten circuleren.
•Controleer na de installatie van het apparaat dat het niet op het aansluitsnoer of de toevoerslang staat of drukt.
•Als de wasdroger bovenop een wasmachine wordt geplaatst, is het noodzakelijk de stapelkit te gebruiken (optioneel accessoire).
GEBRUIK
•Dit apparaat is bestemd voor huishoudelijk gebruik. Het is niet toegestaan het apparaat te gebruiken voor andere doeleinden dan waarvoor het is bestemd.
•Was alleen textiel dat geschikt is voor machinaal drogen. Volg de instructies op het wasvoorschrift in de kleding.
•Droog geen ongewassen artikelen in de wasdroger.
•Doe niet te veel wasgoed in de machine. Zie het desbetreffende hoofdstuk in de gebruiksaanwijzing.
•Kleding die druipnat is mag niet in de droger worden geplaatst.
•Kledingstukken die in aanraking zijn geweest met vluchtige aardolieproducten mogen niet in de wasdroger gedroogd worden. Als vluchtige reinigingsvloeistoffen zijn gebruikt, dient u ervoor te zorgen dat de vloeistof uit het kledingstuk is verwijderd voordat u het in de machine doet.
•Trek de stekker nooit aan het snoer uit het stopcontact; maar aan de stekker zelf.
•Gebruik de wasdroger nooit als het elektrische snoer, het bedieningspaneel, het bovenblad of de sokkel beschadigd zijn, zodat de binnenkant van de wasmachine toegankelijk is.
•Wasverzachters of soortgelijke producten dienen te worden gebruikt zoals gespecificeerd in de wasverzachterinstructies.
•Let op – heet oppervlak : Raak het oppervlak van het dekseltje van de deurverlichting niet aan wanneer de verlichting ingeschakeld is. 2)
•
Heet oppervlak: Raak de achterkant van het apparaat niet aan wanneer het in gebruik is!
KINDERSLOT
•Deze machine is niet bedoeld voor gebruik door jonge kinderen of verstandelijk gehandicapten zonder toezicht.
electrolux 21
•Kinderen herkennen de gevaren die bij elektrische apparaten horen vaak niet. Houd kinderen uit de buurt om te voorkomen dat ze met het apparaat gaan spelen.
Waarschuwing!
•De verpakkingsmaterialen (zoals plasticfolie en polystyreen) kunnen een gevaar opleveren voor kinderen - verstikkingsgevaar! Houd deze materialen buiten het bereik van kinderen.
•Berg alle wasmiddelen op een veilige plaats, buiten het bereik van kinderen, op.
•Zorg ervoor dat kinderen of huisdieren niet in de trommel kunnen klimmen.
PRODUCTBESCHRIJVING
8
7 |
6 |
1Bedieningspaneel
2Deur
3Pluisfilter
4Typeplaatje
1
2
3
4
5
5Verstelbare pootjes
6Ventilatieopeningen aan de zijkanten/ ventilatieopeningen aan de achterkant
7Ringmoer
2) Alleen drogers die zijn uitgerust met inwendige trommelverlichting.
22 electrolux
8 Lampje voor binnenverlichting
BEDIENINGSPANEEL |
|
|
|
|
6 |
5 |
4 |
1 |
2 |
3 |
|
1Programmaknop en "O" (UIT)-schake- laar
2Functietoetsen
3START / PAUZE -toets
4FILTER -lampje
5STARTUITSTEL -toets
6Display
WAT ER OP HET DISPLAY WORDT WEERGEGEVEN
SYMBOOL BESCHRIJVING
Eindtijd (tijd tijdprogramma, tijd uitgestelde start)
Kinderslot
Startuitstel
Droogfase
Afkoelfase
Anti-kreukfase
Fout, verkeerde keuze
VOORDAT U DE DROGER IN GEBRUIK NEEMT
Om eventuele restanten, die ontstaan zijn tijdens de fabricage, te verwijderen, de trommel van de droger afvegen met een
vochtige doek of een korte cyclus ( ca. 30 min.) met vochtige lappen in de trommel laten draaien.
WASGOED SORTEREN EN VOORBEREIDEN
HET WASGOED SORTEREN
•Sorteer op weefseltype:
–Katoen/linnen voor programma's in de programmagroep KATOEN.
–Gemengde en synthetische stoffen voor programma's in de programmagroep SYNTHETISCH.
•Sorteren op onderhoudslabel: De onderhoudslabels betekenen:
Drogen in de wasdroger in principe mogelijk
Drogen op normale temperatuur
Drogen op een lagere temperatuur (druk op de LAGE TEMP. -toets!)
Drogen in de wasdroger is niet mogelijk
Belangrijk! Stop geen nat wasgoed in de machine als niet op het onderhoudslabel vermeld is dat het geschikt is om gedroogd te worden in een wasdroger.
Deze machine kan gebruikt worden voor al wasgoed dat voorzien is van het label "geschikt om gedroogd te worden in een wasdroger".
•Droog nieuw, gekleurd textiel niet samen met lichtgekleurd wasgoed. De kleur van textiel kan afgeven.
•Droog geen katoenen jersey en gebreide kleding met het programma EXTRA DROOG . Deze stukken kunnen krimpen!
•Wollen en wolachtige stoffen kunnen gedroogd worden met het WOL -program-
ma.
Wasgoed voorbereiden
•Om te voorkomen dat was verstrikt raakt: sluit ritsen, knoop dekbedovertrekken dicht en sluit losse riemen of strikken (bijv. van schorten).
•Maak zakken leeg. Verwijder metalen voorwerpen (paperclips, veiligheidsspelden etc.).
•Keer voorwerpen met dubbellaagse weefsels binnenstebuiten (bijv. met ka-
electrolux 23
toen afgewerkte anoraks, de katoenlaag moet aan de buitenkant zitten). Deze weefsels drogen dan beter.
Belangrijk! Doe niet te veel wasgoed in de machine. Houd de max. belading van 7 kg aan.
HET GEWICHT VAN WASGOED
Type was- |
|
Gewicht |
goed |
|
|
Badjas |
|
1200 gram |
Servet |
|
100 gram |
Dekbedover- |
|
700 gram |
trek |
|
|
Laken |
|
500 gram |
Kussensloop |
|
200 gram |
Tafelkleed |
|
250 gram |
Badstof hand- |
|
200 gram |
doek |
|
|
Theedoek |
|
100 gram |
Nachthemd |
|
200 gram |
Damesslips |
|
100 gram |
Herenover- |
|
600 gram |
hemd |
|
|
Herenover- |
|
200 gram |
hemd |
|
|
Herenpyjama |
|
500 gram |
Bloes |
|
100 gram |
Herenonder- |
|
100 gram |
goed |
|
|
|
|
|
Loading...
