Delfield N8000, N8000-R, N8100B, N8100-BR, N8100-FA Service Manual
...
™
DELFIELD®
N8000, N8000-R, N8100B, N8100-BR, N8100-FA, 8100-EF, N8200, N8200G, N8600, N8700-D, N8700-R, N8800 Drop Ins
Service, Installation and Care Manual
Please read this manual completely before attempting to install or operate this equipment! Notify carrier of damage! Inspect all components immediately.
Hot Food Wells, Cold Pans, Granite Cold Slabs,
Frost Tops and Hot/Cold Food Wells
|
|
|
|
INFORMATION |
||
IMPORTANT |
|
|
USE |
|||
|
READ |
BEFORE |
|
|||
|
|
|
INSTRUCTIONS! |
|||
|
SAVE |
THESE |
||||
|
|
|
||||
PLEASE |
|
|
|
|
|
|
|
|
|
|
|
|
|
May 2010
N8000 Series Drop-In Installation and Operation Manual
Important Warning And Safety Information
WARNING Read This Manual Thoroughly Before Operating, Installing, Or Performing Maintenance On The Equipment.
WARNING Failure To Follow Instructions In This Manual Can Cause Property Damage, Injury Or Death.
WARNING Do Not Store Or Use Gasoline Or Other Flammable Vapors Or Liquids In The Vicinity Of This Or Any Other Appliance.
WARNING Unless All Cover And Access Panels Are In Place And Properly Secured, Do Not Operate This Equipment.
WARNING Do Not Clean With Water Jet.
CAUTION Observe the following:
•Minimum clearances must be maintained from all walls and combustible
materials.
•Keep the equipment area free and clear of combustible material.
•Adequate clearance for air openings.
•Operate equipment only on the type of electricity indicated on the specification plate.
•Retain this manual for future reference.
|
|
™ |
|
|
® |
|
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
DELFIELD |
|
Contents |
|
Receiving And Inspecting Unit .................................................... |
3 |
Specifications ......................................................................... |
4-7 |
Installation |
|
Curved Drop-In Cutout Details .................................................. |
8 |
N8000, N8000N, N8000-R, N8100B, N8100NB, N8100-BR, N8200, |
|
N8200G, 8100-FA, 8100-EF Series ............................................ |
9 |
N8600 Series ........................................................................... |
9 |
N8700-D, N8700N, N8700-R & N8800 Series ........................... |
10 |
Operation |
|
N8100B, N8100NB, N8100-BR ................................................ |
11 |
N8100-FA .............................................................................. |
11 |
8100-EF ................................................................................ |
12 |
N8200 & N8200G ................................................................... |
12 |
N8600 ................................................................................... |
13 |
N8700-D, N8700N, N8700-R & N8800 Series ........................... |
14 |
Maintenance ............................................................................ |
15 |
Unit Assembly N8100-FA .......................................................... |
16 |
Wiring Diagram |
|
N8100-FA .............................................................................. |
16 |
N8100B, N8100NB & N8100-BR .............................................. |
17 |
8100-EF & 8100-EFN .............................................................. |
17 |
N8200 & N8200G ................................................................... |
17 |
N8600 .............................................................................. |
18-19 |
N8800 ................................................................................... |
19 |
N8700-D, N8700N & N8700-R ................................................ |
20 |
Louver Diagram ....................................................................... |
21 |
Miscellaneous Replacement Parts ............................................. |
21 |
N8100-FA Replacement Parts List ............................................. |
22 |
Condensing Unit Assembly Parts List ................................... |
23-26 |
Food Well Assembly Parts List ............................................. |
27-28 |
Standard Labor Guidelines........................................................ |
29 |
Standard Warranties ........................................................... |
30-31 |
N8000 Series Drop-In Installation and Operation Manual
Serial Number Location
The serial number on self-contained refrigerated units is on the electrical speciications tag located near the condensing unit.
The serial number on remote refrigerated units is on the outside bottom of the food well.
On hot food pans and hot/cold combination pans, the serial number tag is located on the back of the control raceway or remote panel.
The serial number tag also lists the refrigerant used and the amount of charge.
Always have the serial number of your unit available when calling for parts or service.
This manual covers only standard 8000 series units. If you have a custom designed unit, you should contact our parts/service department at (800) 7 -88 9 for questions.
© 010 The Delield Company. All rights reserved. Reproduction without written permission is prohibited. “Delield” is a registered trademark of The Delield Company.
Receiving And Inspecting The Equipment
Even though most equipment is shipped crated, care should be taken during unloading so the equipment is not damaged while being moved into the building.
1. Visually inspect the exterior of the package and skid or container. Any damage should be noted and reported to the delivering carrier immediately.
. If damaged, open and inspect the contents with the carrier.
. In the event that the exterior is not damaged, yet upon opening, there is concealed damage to the equipment notify the carrier. Notiication should be made verbally as well as in written form.
4.Request an inspection by the shipping company of the damaged equipment. This should be done within 10 days from receipt of the equipment.
5.Also open the compressor compartment housing and visually inspect the refrigeration package. Be sure lines are secure and base is still intact.
6.Freight carriers can supply the necessary damage forms upon request.
7.Retain all crating material until an inspection has been made or waived.
Uncrating The Equipment
First cut and remove the banding from around the crate. Remove the front of the crate material, use of some tools will be required.
™
DELFIELD |
® |
|
|
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
|
||
|
N8000 Series Drop-In Installation and Operation Manual
Specifications
N8100B Series Self-Contained Mechanically Cooled Pans - R134A
|
|
|
|
Counter Cutout |
|
|
|
|
Evap BTU/ |
Sys |
Ship |
Refrig. |
NEMA |
12”x20” |
Model |
L |
D |
H |
Dimensions |
V/Hz/Ph |
Amps |
H.P. |
BTU |
TD/TEMP |
Cap |
Weight |
Charge |
Plug |
Pans |
N8118B |
18” |
26” |
21.87” |
17” X 25” |
115/60/1 |
4.0 |
1/5 |
204 |
19/38º/-3º |
708 |
100lbs |
8.0oz |
5-15P |
1 |
|
(45.7cm) |
(66cm) |
(55.5cm) |
(43.2cm x 63.5cm) |
|
|
|
|
|
|
(45kg) |
|
|
|
N8130B |
30.75” |
26” |
21.87” |
29.75” x 25” |
115/60/1 |
4.0 |
1/5 |
379 |
26/31º/4° |
812 |
140lbs |
8.0oz |
5-15P |
2 |
|
(78.1cm) |
(66cm) |
(55.5cm) |
(75.6cm x 63.5cm) |
|
|
|
|
|
|
(64kg) |
|
|
|
N8143B |
43.5” |
26” |
21.87” |
42.50” X 25” |
115/60/1 |
4.0 |
1/5 |
569 |
35/26º/9º |
889 |
173lbs |
8.0oz |
5-15P |
3 |
|
(110.5cm) |
(66cm) |
(55.5cm) |
(108.6cm x 63.5cm) |
|
|
|
|
|
|
(78kg) |
|
|
|
N8156B |
56.25” |
26” |
21.87” |
55.25” x 25” |
115/60/1 |
7.0 |
1/4 |
758 |
43/32º/3º |
1373 |
205lbs |
16.0oz |
5-15P |
4 |
|
(142.9cm) |
(66cm) |
(55.5cm) |
(140.3cm x 63.5cm) |
|
|
|
|
|
|
(93kg) |
|
|
|
N8169B |
69” |
26” |
21.87” |
68” X 25” |
115/60/1 |
7.0 |
1/4 |
948 |
51/29º/6º |
1469 |
225lbs |
16.0oz |
5-15P |
5 |
|
(175.3cm) |
(66cm) |
(55.5cm) |
(172.7cm x 63.5cm) |
|
|
|
|
|
|
(102kg) |
|
|
|
N8181B |
81.75” |
26” |
21.87” |
80.75” x 25” |
115/60/1 |
8.0 |
1/3 |
1138 |
59/32º/3º |
1921 |
258lbs |
11.5oz |
5-15P |
6 |
|
(208cm) |
(66cm) |
(55.5cm) |
(205.1cm x 63.5cm) |
|
|
|
|
|
|
(117kg) |
|
|
|
N8100NB Series Self-Contained Mechanically Cooled Pans Narrow Style - R134A
N8146NB |
46.75” |
18” |
21.81” |
45.75” x 17” |
115/60/1 |
4.0 |
1/5 |
454 |
17/40º/-5º |
680 |
175lbs |
8.0oz |
5-15P |
2 |
|
(118.7cm) |
(45.7cm) |
(55.4cm) |
(113.7cm x 43.2cm) |
|
|
|
|
|
|
(80kg) |
|
|
|
N8168NB |
67.5” |
18” |
21.81” |
66.5” x 17” |
115/60/1 |
4.0 |
1/5 |
676 |
26/31º/4º |
804 |
240lbs |
8.0oz |
5-15P |
3 |
|
(171.5cm) |
(45.7cm) |
(55.4cm) |
(168.9cm x 43.2cm) |
|
|
|
|
|
|
(109kg) |
|
|
|
N8100BR Series Curved Self-Contained Mechanically Cooled Pans - R134A
|
|
|
|
Counter Cutout |
|
|
|
|
Evap BTU/ |
Sys |
Ship |
Refrig. |
NEMA |
12”x20” |
Model |
L |
D |
H |
Dimensions |
V/Hz/Ph |
Amps |
H.P. |
BTU |
TD/TEMP |
Cap |
Weight |
Charge |
Plug |
Pans |
N8144-BR |
40.43” |
26.05” |
21.81” |
see drawing on |
115/60/1 |
4.0 |
1/5 |
379 |
26/31º/4° |
812 |
161lbs |
8.0oz |
5-15P |
2 |
|
(103cm) |
(66cm) |
(55cm) |
page 8 |
|
|
|
|
|
|
(72kg) |
|
|
|
N8159-BR |
57.22” |
26.05” |
21.81” |
see drawing on |
115/60/1 |
4.0 |
1/5 |
569 |
35/26º/9º |
889 |
184lbs |
8.0oz |
5-15P |
3 |
|
(145cm) |
(66cm) |
(55cm) |
page 8 |
|
|
|
|
|
|
(83kg) |
|
|
|
N8176-BR |
73.68” |
26.05” |
21.81” |
see drawing on |
115/60/1 |
7.0 |
1/4 |
758 |
43/32º/3º |
1373 |
233lbs |
16.0oz |
5-15P |
4 |
|
(187cm) |
(66cm) |
(55cm) |
page 8 |
|
|
|
|
|
|
(105kg) |
|
|
|
N8194-BR |
89.86” |
26.05” |
21.81” |
see drawing on |
115/60/1 |
7.0 |
1/4 |
948 |
51/29º/6º |
1469 |
243lbs |
16.0oz |
5-15P |
5 |
|
(228cm) |
(66cm) |
(55cm) |
page 8 |
|
|
|
|
|
|
(109kg) |
|
|
|
N8100-FA Series Forced Air Drop-In Mechanically Cooled Cold Pans - R404A
|
|
|
|
Counter Cutout |
|
|
|
|
Evap BTU/ |
Sys |
Ship |
Refrig. |
NEMA |
12”x20” |
|
Model |
L |
D |
H |
Dimensions |
V/Hz/Ph |
Amps |
H.P. |
BTU |
TD/TEMP |
Cap |
Weight |
Charge |
Plug |
Pans |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
N8131-FA |
31.25” |
26.67” |
26.62” |
30.25” x 25.5” |
115/60/1 |
7.8 |
1/4 |
1339 |
140/15º/20º |
2154 |
168lbs |
16.0oz |
5-15P |
2 |
|
(79.4cm) |
(67.7cm) |
(68cm) |
(76.8cm x 64.8cm) |
(76kg) |
|||||||||||
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
N8144-FA |
44” |
26.67” |
26.62” |
43” x 25.5” |
115/60/1 |
9.2 |
1/2 |
2035 |
140/22º/13º |
3142 |
175lbs |
32.0oz |
5-15P |
3 |
|
(111.8cm) |
(67.7cm) |
(68cm) |
109.2cm x 64.8cm) |
(79kg) |
|||||||||||
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
N8157-FA |
56.75” |
26.67” |
26.62” |
55.75” x 25.5” |
115/60/1 |
9.2 |
1/2 |
2731 |
280/14º/21° |
3806 |
225lbs |
32.0oz |
5-15P |
4 |
|
(144.1cm) |
(67.7cm) |
(68cm) |
(141.6cm x 64.8cm) |
(102kg) |
|||||||||||
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
N8169-FA |
69.5” |
26.67” |
28.62” |
68.5” x 25.5” |
115/60/1 |
14.8 |
3/4 |
3374 |
280/20º/15° |
5545 |
235lbs |
48.0oz |
5-20P |
5 |
|
(176.5cm) |
(67.7cm) |
(72.7cm) |
174.0cm x 64.8cm) |
(107kg) |
|||||||||||
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
N8182-FA |
82.25” |
26.67” |
28.62” |
81.25” x 25.5” |
115/60/1 |
14.8 |
3/4 |
4070 |
280/20º/15° |
5545 |
406lbs |
48.0oz |
5-20P |
6 |
|
|
(208.9cm) |
(67.7cm) |
(72.7cm) |
206.4cm x 64.8cm) |
(184kg) |
||||||||||
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
™ |
|
|
® |
4 |
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
DELFIELD |
|
N8000 Series Drop-In Installation and Operation Manual
Specifications
8100-EF Series LiquiTec® Eutetic Fluid Refrigerated Cold Pans - R404A
|
|
|
|
Counter Cutout |
|
|
|
BTU |
Evap BTU/ |
Sys |
Ship |
Refrig. |
NEMA |
12x20 |
Model |
L |
D |
H |
Dimensions |
V/Hz/Ph |
Amps |
H.P. |
Load |
TD/TEMP |
Cap |
Weight |
Charge |
Plug |
Pans |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8118-EF |
18.20” |
26” |
23.25” |
17” x 25” |
115/60/1 |
7.5 |
1/4 |
204 |
19/50º/-15° |
928 |
169lbs |
24.0oz |
5-15P |
1 |
|
(46.2cm) |
(66cm) |
(59.1cm) |
(43.2cm x 63.5cm) |
|
|
|
|
|
|
(77kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8132-EF |
31.76” |
26” |
23.25” |
30.75” x 25” |
115/60/1 |
7.5 |
1/4 |
379 |
26/42º/-7° |
1112 |
215lbs |
24.0oz |
5-15P |
2 |
|
(80.7cm) |
(66cm) |
(59.1cm) |
(78.1cm x 63.5cm) |
|
|
|
|
|
|
(98kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8145-EF |
45.32” |
26” |
23.25” |
44.25” x 25” |
115/60/1 |
7.5 |
1/4 |
569 |
35/36º/-1° |
1259 |
265lbs |
24.0oz |
5-15P |
3 |
|
(115.1cm) |
(66cm) |
(59.1cm) |
(112.4cm x 63.5cm) |
|
|
|
|
|
|
(120kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8159-EF |
58.88” |
26” |
23.25” |
57.87” x 25” |
115/60/1 |
7.5 |
1/4 |
758 |
43/32º/3° |
1373 |
285lbs |
24.0oz |
5-15P |
4 |
|
(149.6cm) |
(66cm) |
(59.1cm) |
(147cm x 63.5cm) |
|
|
|
|
|
|
(130kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8172-EF |
72.44” |
26” |
23.25” |
71.5” x 25” |
115/60/1 |
7.5 |
1/4 |
948 |
51/29º/6° |
1469 |
295lbs |
24.0oz |
5-15P |
5 |
|
(184cm) |
(66cm) |
(59.1cm) |
(181.6cm x 63.5cm) |
|
|
|
|
|
|
(134kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8186-EF |
86” |
26” |
23.25” |
85” x 25” |
115/60/1 |
7.5 |
1/4 |
1138 |
59/26º/9° |
1529 |
394lbs |
24.0oz |
5-15P |
6 |
|
(218.4cm) |
(66cm) |
(59.1cm) |
(215.9cm x 63.5cm) |
|
|
|
|
|
|
(179kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8100-EFN Series LiquiTec® Slim Line Eutetic Fluid Refrigerated Cold Pans - R404A
|
|
|
|
Counter Cutout |
|
|
|
BTU |
Evap BTU/ |
Sys |
Ship |
Refrig. |
NEMA |
12x20 |
Model |
L |
D |
H |
Dimensions |
V/Hz/Ph |
Amps |
H.P. |
Load |
TD/TEMP |
Cap |
Weight |
Charge |
Plug |
Pans |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8148-EFN |
47.66” |
18” |
23.25” |
46.88” x 17.25” |
115/60/1 |
7.5 |
1/4 |
379 |
26/42º/-7° |
1112 |
235lbs |
24.0oz |
5-15P |
2 |
|
(121.1cm) |
(45.7cm) |
(59.1cm) |
(119.1cm x 43.8cm) |
|
|
|
|
|
|
(107kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8169-EFN |
69.22” |
18” |
23.25” |
68.5” x 17.25” |
115/60/1 |
7.5 |
1/4 |
569 |
35/36º/-1° |
1259 |
285lbs |
24.0oz |
5-15P |
3 |
|
(175.8cm) |
(45.7cm) |
(59.1cm) |
(174cm x 43.8cm) |
|
|
|
|
|
|
(130kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8191-EFN |
90.78” |
18” |
23.25” |
90” x 17.25” |
115/60/1 |
7.5 |
1/4 |
758 |
43/32º/13° |
1373 |
295lbs |
24.0oz |
5-15P |
4 |
|
(230.6cm) |
(45.7cm) |
(59.1cm) |
(228.6cm x 43.8cm) |
|
|
|
|
|
|
(134kg) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
N8000 Series Ice Cooled Cold Pans
|
|
|
|
Counter Cutout |
Ship |
12”x20” |
Model |
L |
D |
H |
Dimensions |
Weight |
Pans Held |
N8018 |
18” |
26” |
10.75” |
17” x 25” |
38lbs |
1 |
|
(45.7cm) |
(66cm) |
(27.3cm) |
(43.2cm x 63.5cm) |
(17kg) |
|
|
|
|
|
|
|
|
N8030 |
30.75” |
26” |
10.75” |
29.75” x 25” |
84lbs |
2 |
|
(78.1cm) |
(66cm) |
(27.3cm) |
(75.6cm x 63.5cm) |
(38kg) |
|
|
|
|
|
|
|
|
N8043 |
43.5” |
26” |
10.75” |
42.5” x 25” |
110lbs |
3 |
|
(110.5cm) |
(66cm) |
(27.3cm) |
(107.9cm x 63.5cm) |
(50kg) |
|
|
|
|
|
|
|
|
N8056 |
56.25” |
26” |
10.75” |
55.25” x 25” |
139lbs |
4 |
|
(142.9cm) |
(66cm) |
(27.3cm) |
(140.3cm x 63.5cm) |
(63kg) |
|
|
|
|
|
|
|
|
N8069 |
69” |
26” |
10.75” |
68” x 25” |
160lbs |
5 |
|
(175.3cm) |
(66cm) |
(27.3cm) |
(172.7cm x 63.5cm) |
(73kg) |
|
|
|
|
|
|
|
|
N8081 |
81.75” |
26” |
10.75” |
80.75” x 25” |
197lbs |
6 |
|
(208cm) |
(66cm) |
(27.3cm) |
(205.1cm x 63.5cm) |
(89kg) |
|
|
|
|
|
|
|
|
N8000N Series Narrow Ice Cooled Cold Pans
N8046N |
46.75” |
18” |
10.75” |
45.75” x 17” |
100lbs |
2 |
|
(118.8cm) |
(45.7cm) |
(27.3cm) |
(116.2cm x 43.2cm) |
(45kg) |
|
N8068N |
67.5” |
18” |
10.75” |
66.50” x 17” |
120lbs |
3 |
|
(171.5cm) |
(45.7cm) |
(27.3cm) |
(168.9cm x 43.2cm) |
(55kg) |
|
™
DELFIELD |
® |
|
|
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
5 |
||
|
N8000 Series Drop-In Installation and Operation Manual
Specifications
N8000-R Series Curved Ice Cooled Cold Pans
|
|
|
|
Counter Cutout |
Ship |
12”x20” |
Model |
L |
D |
H |
Dimensions |
Weight |
Pans Held |
N8044-R |
40.48” |
26.05” |
10.77” |
see drawing on page 8 |
100lbs |
2 |
|
(103cm) |
(66cm) |
(27cm) |
|
(45kg) |
|
|
|
|
|
|
|
|
N8059-R |
57.22” |
26.05” |
10.77” |
see drawing on page 8 |
118lbs |
3 |
|
(145cm) |
(66cm) |
(27cm) |
|
(53kg) |
|
|
|
|
|
|
|
|
N8076-R |
73.68” |
26.05” |
10.77” |
see drawing on page 8 |
145lbs |
4 |
|
(187cm) |
(66cm) |
(27cm) |
|
(65kg) |
|
|
|
|
|
|
|
|
N8094-R |
89.89” |
26.05” |
10.77” |
see drawing on page 8 |
164lbs |
5 |
|
(228cm) |
(66cm) |
(27cm) |
|
(74kg) |
|
|
|
|
|
|
|
|
N8200 Series Self-Contained Frost Tops - R404A
|
|
|
|
Counter Cutout |
|
|
|
|
Evap BTU/ |
Sys |
|
Refrig. |
NEMA |
Model |
L |
D |
H |
Dimensions |
V/Hz/Ph |
Amps |
H.P. |
BTU |
TD/TEMP |
Cap |
Ship Weight |
Charge |
Plug |
N8231 |
31.75" |
26” |
15.75” |
30.75” x 25" |
115/60/1 |
7.5 |
1/4 |
379 |
26/42º/-7° |
1112 |
142lbs |
24.0oz |
5-15P |
|
|
|
|
||||||||||
|
(80.6cm) |
(66cm) |
(40cm) |
(78.1cm x 63.5cm) |
|
|
|
|
|
|
(64kg) |
|
|
N8245 |
45.63” |
26” |
15.75” |
44.63” x 25” |
115/60/1 |
7.5 |
1/4 |
569 |
35/36º/-1° |
1259 |
168lbs |
24.0oz |
5-15P |
|
(115.9cm) |
(66cm) |
(40cm) |
(113.3cm x 63.5cm) |
|
|
|
|
|
|
(76kg) |
|
|
N8259 |
59.5” |
26” |
15.75” |
58.50” x 25” |
115/60/1 |
7.5 |
1/4 |
758 |
43/32º/3° |
1373 |
193lbs |
24.0oz |
5-15P |
|
|
|
|
||||||||||
|
(151.1cm) |
(66cm) |
(40cm) |
(148.6cm x 63.5cm) |
|
|
|
|
|
|
(88kg) |
|
|
N8273 |
73.38" |
26” |
15.75” |
72.38” x 25” |
115/60/1 |
8.0 |
1/4 |
948 |
51/29º/6° |
1469 |
209lbs |
24.0oz |
5-15P |
|
(186.4cm) |
(66cm) |
(40cm) |
(183.8cm x 63.5cm) |
|
|
|
|
|
|
(95kg) |
|
|
N8287 |
87.25" |
26” |
15.75” |
86.25" x 25" |
115/60/1 |
8.0 |
1/3 |
1138 |
59/30º/5° |
1787 |
239lbs |
24.0oz |
5-15P |
|
(221.6cm) |
(66cm) |
(40cm) |
(219.1cm x 63.5cm) |
|
|
|
|
|
|
(108kg) |
|
|
N8200G Series Self-Contained Granite Cold Slabs
|
|
|
|
Counter Cutout |
|
|
|
|
Evap BTU/ |
Sys |
|
Refrig. |
NEMA |
Model |
L |
D |
H |
Dimensions |
V/Hz/Ph |
Amps |
H.P. |
BTU |
TD/TEMP |
Cap |
Ship Weight |
Charge |
Plug |
N8231G |
31.75” |
25.87” |
19” |
30.75” X 25” |
115/60/1 |
7.5 |
1/4 |
379 |
26/42º/-7° |
1112 |
219lbs |
24.0oz |
5-15P |
|
|
|
|
||||||||||
|
(80.6cm) |
(65.7cm) |
(48.3cm) |
(78.1cm x 63.5cm) |
|
|
|
|
|
|
(99kg) |
|
|
N8245G |
45.63” |
25.87” |
19” |
44.63” x 25” |
115/60/1 |
7.5 |
1/4 |
569 |
35/36º/-1° |
1259 |
284lbs |
24.0oz |
5-15P |
|
(115.9cm) |
(65.7cm) |
(48.3cm) |
(113.4cm x 63.5cm) |
|
|
|
|
|
|
(129kg) |
|
|
N8259G |
59.5” |
25.87” |
19” |
58.5” x 25” |
115/60/1 |
8.0 |
1/3 |
758 |
43/37º/-2° |
1572 |
338lbs |
24.0oz |
5-15P |
|
|
|
|
||||||||||
|
(151.1cm) |
(65.7cm) |
(48.3cm) |
(148.6cm x 63.5cm) |
|
|
|
|
|
|
(153kg) |
|
|
N8273G |
73.38” |
25.87” |
19” |
72.38” x 25” |
115/60/1 |
9.0 |
1/2 |
948 |
51/43º/-8° |
2183 |
425lbs |
32.0oz |
5-15P |
|
(186.4cm) |
(65.7cm) |
(48.3cm) |
(183.8cm x 63.5cm) |
|
|
|
|
|
|
(193kg) |
|
|
N8600 Series Self Contained Combination Hot/Cold Food Wells - R404A
|
|
|
|
Counter Cutout |
Control Panel Cutout |
|
|
|
|
Evap |
Sys |
Ship |
Refrig. |
12”x20” |
Model |
|
|
|
Dimensions |
V/Hz/Ph |
Amps |
H.P. |
BTU |
BTU/TD |
Cap |
Weight |
Charge |
Pans |
|
L |
D |
H |
Dimensions |
|||||||||||
N8630 |
30.75” |
26” |
23.75” |
29.75” X 25” |
12.25” x 4.25” x 7.00” |
120/60/1 |
24.0 |
1/4 |
379 |
26/42º/-7° |
1112 |
164lbs |
16.0oz |
2 |
|
|
|
||||||||||||
|
(78.1cm) |
(66cm) |
(60.3cm) |
(75.5cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
|
|
|
|
|
|
(74kg) |
|
|
N8643 |
43.5” |
26” |
23.75” |
42.50” x 25” |
12.25” x 4.25” x 7.00” |
120/240 |
21.0 |
1/4 |
569 |
35/36º/-1° |
1259 |
198lbs |
16.0oz |
3 |
|
(110.5cm) |
(66cm) |
(60.3cm) |
(107.9cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
/60/1 |
|
|
|
|
|
(90kg) |
|
|
N8656 |
56.25” |
26” |
23.75” |
55.25” x 25” |
12.25” x 4.25” x 7.00” |
120/240 |
21.0 |
1/4 |
758 |
43/32º/3° |
1373 |
233lbs |
16.0oz |
4 |
|
|
|
||||||||||||
|
(142.9cm) |
(66cm) |
(60.3cm) |
(140.3cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
/60/1 |
|
|
|
|
|
(106kg) |
|
|
N8669 |
69” |
26” |
23.75” |
68” x 25” |
12.25” x 4.25” x 7.00” |
120/240 |
42.0 |
1/4 |
948 |
51/29º/6° |
1469 |
266lbs |
16.0oz |
5 |
|
(175.3cm) |
(66cm) |
(60.3cm) |
(172.7cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
/60/1 |
|
|
|
|
|
(121kg) |
|
|
N8681 |
81.75” |
26” |
23.75” |
80.75” x 25” |
12.25” x 4.25” x 7.00” |
120/240 |
42.0 |
1/3 |
1138 |
59/30º/5° |
1787 |
301lbs |
24.0oz |
6 |
|
(207.6cm) |
(66cm) |
(60.3cm) |
(205.1cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
/60/1 |
|
|
|
|
|
(137kg) |
|
|
|
|
™ |
|
|
® |
6 |
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
DELFIELD |
|
N8000 Series Drop-In Installation and Operation Manual
Specifications
N8700D Series Individually Controlled Heated Food Wells
|
|
|
|
Counter Cutout |
Control Panel Cutout |
|
|
Ship |
12”x20” |
Model |
|
|
|
Dimensions |
V/Hz/Ph |
Amps |
Weight |
Pans |
|
L |
D |
H |
Dimensions |
||||||
N8717-D |
17.88” |
26” |
9.5” |
16.88” X 25” |
7.00” x 4.62” x 7.00” |
120/60/1 |
8.3 |
41lbs |
1 |
|
(45.4cm) |
(66cm) |
(24cm)* |
(42.8cm x 63.5cm) |
(17.8cm x 11.7cm x 17.8cm) |
|
|
(19kg) |
|
|
|
|
|
|
|
|
|
|
|
N8731-D |
31.75” |
26” |
9.5” |
30.75” x 25” |
10.31” x 4.62” x 7.00” |
120/60/1 |
16.6 |
99lbs |
2 |
|
(80.6cm) |
(66cm) |
(24cm)* |
(78.1cm x 63.5cm) |
(26.2cm x 11.7cm x 17.8cm) |
|
|
(45kg) |
|
|
|
|
|
|
|
|
|
|
|
N8745-D |
45.63” |
26” |
9.5” |
44.62” x 25” |
14.5” x 4.62” x 7.00” |
208-230 |
15.0/16.0 |
134lbs |
3 |
|
(115.9cm) |
(66cm) |
(24cm)* |
(113.3cm x 63.5cm) |
(36.8cm x 11.7cm x 17.8cm) |
/60/1 |
|
(61kg) |
|
|
|
|
|
|
|
|
|
|
|
N8759-D |
59.5” |
26” |
9.5” |
58.5” x 25” |
18.69” x 4.62” x 7.00” |
208-230 |
20.0/22.0 |
166lbs |
4 |
|
(151.1cm) |
(66cm) |
(24cm)* |
(148.6cm x 63.5cm) |
(47.5cm x 11.7cm x 17.8cm) |
/60/1 |
|
(75kg) |
|
|
|
|
|
|
|
|
|
|
|
N8773-D |
73.38” |
26” |
9.5” |
72.37” x 25” |
22.88” x 4.62” x 7.00” |
208-230 |
24.0/27.0 |
186lbs |
5 |
|
(186.4cm) |
(66cm) |
(24cm)* |
(183.8cm x 63.5cm) |
(58.1cm x 11.7cm x 17.8cm) |
/60/1 |
|
(84kg) |
|
|
|
|
|
|
|
|
|
|
|
N8787-D |
87.25” |
26” |
9.5” |
86.25” x 25” |
27” x 4.62” x 7.00” |
208-230 |
29.0/32.0 |
236lbs |
6 |
|
(221.4cm) |
(66cm) |
(24cm)* |
(219.1cm x 63.5cm) |
(68.6cm x 11.7cm x 17.8cm) |
/60/1 |
|
(107kg) |
|
|
|
|
|
|
|
|
|
|
|
*14” Overall height including drain connection
N8700-R Series Curved Individually Controlled Heated Food Wells
|
|
|
|
Counter Cutout |
Control Panel Cutout |
|
|
Ship |
12”x20” |
Model |
|
|
|
Dimensions |
V/Hz/Ph |
Amps |
Weight |
Pans |
|
L |
D |
H |
Dimensions |
||||||
N8744-R |
40.48” |
26.05” |
9.5” |
see drawing on page 8 |
10.31” x 4.62” x 7.00” |
120/60/1 |
16.6 |
99lbs |
2 |
|
(103cm) |
(66cm) |
(24cm)* |
|
(26cm x 12cm x 18cm) |
|
|
(45kg) |
|
|
|
|
|
|
|
|
|
|
|
N8759-R |
57.22” |
26.05” |
9.5” |
see drawing on page 8 |
14.5” x 4.62” x 7.00” |
208-230 |
15.0/16.0 |
134lbs |
3 |
|
(145cm) |
(66cm) |
(24cm)* |
|
(37cm x 12cm x 18cm) |
/60/1 |
|
(61kg) |
|
|
|
|
|
|
|
|
|
|
|
N8776-R |
73.68” |
26.00” |
9.5” |
see drawing on page 8 |
18.69” x 4.62” x 7.00” |
208-230 |
20.0/22.0 |
166lbs |
4 |
|
(187cm) |
(66cm) |
(24cm)* |
|
(47cm x 12cm x 18cm) |
/60/1 |
|
(75kg) |
|
|
|
|
|
|
|
|
|
|
|
N8794-R |
89.80” |
25.91” |
9.5” |
see drawing on page 8 |
22.88” x 4.62” x 7.00” |
208-230 |
24.0/27.0 |
186lbs |
5 |
|
(228cm) |
(66cm) |
(24cm)* |
|
(58cm x 12cm x 18cm) |
/60/1 |
|
(84kg) |
|
|
|
|
|
|
|
|
|
|
|
*14” Overall height including drain connection
N8700N Series Individually Controlled Heated Narrow Food Wells
|
|
|
|
Counter Cutout |
Control Panel Cutout Dimen- |
|
|
Ship |
12”x20” |
Model |
L |
D |
H |
Dimensions |
sions |
V/Hz/Ph |
Amps |
Weight |
Pans |
N8746N |
45.61” |
15.87” |
9.5” |
44.62” x 15.0” |
10.31” x 4.62” x 7.00” |
120/60/1 |
17.0 |
100lbs |
2 |
N8746ND |
(116cm) |
(40cm) |
(24cm) |
(113.3cm x 38.1cm) |
(26.2cm x 11.7cm x 17.8cm) |
|
|
(45kg) |
|
N8768N |
67.48” |
15.87” |
9.5” |
66.50” x 15.0” |
14.50” x 4.62” x 7.00” |
208-230 |
15.0/16.0 |
130lbs |
3 |
N8768ND |
(172cm) |
(40cm) |
(24cm) |
(168.9cm x 38.1cm) |
(36.8cm x 11.7cm x 17.8cm) |
/60/1 |
|
(59kg) |
|
|
|
|
|
|
|
*ND Models are standard with drains
N8800 Series Single Tank Electric Hot Food Wells
|
|
|
|
|
Counter Cutout |
Control Panel Cutout Dimen- |
|
|
Ship |
12”x20” |
|
|
Model |
|
L |
D |
H |
Dimensions |
sions |
V/Hz/Ph |
Amps |
Weight |
Pans |
|
|
N8831 |
|
31.75” |
26” |
11” |
30.75” X 25” |
12.25” x 4.25” x 7.00” |
120/60/1 |
17.0 |
100lbs |
2 |
|
|
|
|
(80.6cm) |
(66cm) |
(27.9cm) |
(78.1cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
|
|
(45kg) |
|
|
|
N8845 |
|
45.63” |
26” |
11” |
44.63” x 25” |
12.25” x 4.25” x 7.00” |
208-230 |
15.0/16.0 |
136lbs |
3 |
|
|
|
|
(115.9cm) |
(66cm) |
(27.9cm) |
(113.4cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
/60/1 |
|
(62kg) |
|
|
|
N8859 |
|
59.5” |
26” |
11” |
58.5” x 25” |
12.25” x 4.25” x 7.00” |
208-230 |
20.0/22.0 |
158lbs |
4 |
|
|
|
|
(151.1cm) |
(66cm) |
(27.9cm) |
(148.6cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
/60/1 |
|
(72kg) |
|
|
|
N8873 |
|
73.38” |
26” |
11” |
72.38” x 25” |
12.25” x 4.25” x 7.00” |
208-230 |
24.0/27.0 |
195lbs |
5 |
|
|
|
|
(186.4cm) |
(66cm) |
(27.9cm) |
(183.8cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
/60/1 |
|
(88kg) |
|
|
|
N8887 |
|
87.25” |
26” |
11” |
86.25” x 25” |
12.25” x 4.25” x 7.00” |
208-230 |
29.0/32.0 |
224lbs |
6 |
|
|
|
|
(221.6cm) |
(66cm) |
(27.9cm) |
(219.1cm x 63.5cm) |
(31.1cm x 10.8cm x 17.8cm) |
/60/1 |
|
(102kg) |
|
|
|
|
™ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
® |
|
|
|
|
|
|
|
|
|
|
DELFIELD |
|
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
7 |
||||||||
|
|
|
|
|
||||||||
N8000 Series Drop-In Installation and Operation Manual
Curved Drop-In Cutout Details
pan standard curved drop-in cutout detail Models:
• |
N8044-R |
19.75” |
|
50CM |
|||
|
|
||
• |
N8144-BR |
|
|
• |
N8744-R |
|
|
|
|
85˚ |
|
|
25.10” |
25.00” |
|
|
64CM |
||
|
64CM |
|
|
|
|
95˚ |
|
|
|
15.92” |
|
|
|
40CM |
19.75” 50CM
172.50˚ |
85˚ |
|
25.00”
64CM 25.10”
64CM
95˚
172.50˚
15.92” 40CM
pan standard curved drop-in cutout detail |
|
|
|
|
|||
Models: |
|
|
|
17.06” |
|
|
|
|
N8059-R |
|
19.56” |
|
19.56” |
|
|
• |
|
|
43CM |
|
|||
|
50CM |
|
50CM |
|
|||
|
N8159-BR |
|
|
|
|
||
• |
|
|
|
|
|
|
|
• |
N8759-R |
|
|
172.50˚ |
|
172.50˚ |
|
|
|
|
|
|
85˚ |
||
|
|
|
85˚ |
|
|
||
|
|
|
|
|
|
||
|
|
|
25.00” |
|
25.00” |
25.00” |
|
|
|
|
|
64CM |
|
||
|
|
|
64CM |
|
64CM |
|
|
|
|
25.10” |
|
|
25.10” |
||
|
|
|
|
|
|
||
|
|
64CM |
|
|
|
|
64CM |
|
|
|
95˚ |
|
|
95˚ |
|
|
|
|
|
|
|
|
|
|
|
|
15.73” |
|
13.78” |
15.73” |
|
|
|
|
|
35CM |
|
||
|
|
|
40CM |
|
40CM |
|
|
|
|
|
|
|
|
||
4 pan standard curved drop-in cutout detail Models:
• |
N8076-R |
19.56” |
|
• |
N8176-BR |
||
50CM |
|||
• |
N8776-R |
|
|
|
|
172.50˚ |
|
|
|
85˚ |
|
|
|
25.00” |
|
|
|
64CM |
|
|
|
25.10” |
|
|
|
64CM |
|
|
|
95˚ |
|
|
|
15.73” |
|
|
|
40CM |
17.06” |
17.06” |
|
43CM |
43CM |
19.56” |
|
|
|
|
|
50CM |
|
172.50˚ |
172.50˚ |
|
|
|
|
|
85˚ |
25.00” |
25.00” |
|
64CM |
64CM |
25.00” |
|
|
64CM |
|
|
25.10” |
|
|
64CM |
|
|
95˚ |
13.78” |
13.78” |
|
35CM |
35CM |
15.73” |
|
|
40CM |
5 pan standard curved drop-in cutout detail Models:
• |
N8094-R |
19.50” |
|
N8194-BR |
|
• |
50CM |
|
• |
N8794-R |
172.50˚ |
|
|
|
|
|
85˚ |
|
|
25.00” |
|
|
64CM |
|
|
25.10” |
|
|
64CM |
|
|
95˚ |
|
|
15.67” |
|
|
40CM |
17.06” |
17.06” |
17.06” |
|
|
43CM |
|
|||
43CM |
43CM |
|
||
|
|
|||
|
|
|
19.50” |
|
172.50˚ |
|
172.50˚ |
50CM |
|
|
|
|||
|
|
|
172.50˚ |
|
|
|
|
85˚ |
|
25.00” |
25.00” |
25.00” |
|
|
64CM |
|
|||
|
|
|||
64CM |
64CM |
|
||
|
25.00” |
|||
|
|
|||
|
|
|
64CM |
|
|
|
|
25.10” |
|
|
|
|
64CM |
|
|
|
|
95˚ |
|
13.78” |
13.78” |
13.78” |
|
|
35CM |
|
|||
35CM |
35CM |
15.67” |
||
|
||||
|
|
|
40CM |
|
|
™ |
|
|
® |
8 |
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
DELFIELD |
|
N8000 Series Drop-In Installation and Operation Manual
Installation N8000, N8000N, N8000-R, N8100B, N8100NB, N8100-BR, N8200, N8200G, N8100-FA & 8100-EF
Drop In Procedure
These units are intended for indoor use only. A room temperature of no more than 86°F ( 0°C) is recommended. Be sure the location chosen has a counter strong enough to support the total weight of the unit and contents. A fully loaded model may weigh as much as 600 pounds! Reinforce the counter as necessary to provide maximum loading.
Unit requires that the sides and bottom are not any closer than 3” (7.6cm) to any combustible
material.
D A N G E R
The counter cut-out sizes and power requirements are shown on the speciication pages. A gasket is installed in the lange of each unit. The weight of the unit on the gasket forms a seal preventing liquids from seeping into the cut-out opening.
Louvers
Self-contained refrigerated units (N8100, N8100NB, N8100-BR, N8 00 and N8 00G Series) require airlow to the compressor. A 1 ” x 5” ( cm x 6 .5 cm) louver is provided by Delield and must be installed in the counter in front of the condenser. The louver cutout dimension is 11” x ” ( 7.9 cm x 55.9 cm). The rear must have an opening to permit removal of heated air. The opening must be at least 8” x 11”, a total of 88 square inches ( 0. cm x 7.9 cm, a total of 566 square centimeters).
Plumbing
The units drain must have an outlet to an appropriate drainage area or container. A drain trap must be installed. N8 00 series have 1/ ” drain and N8 00G series have /4” drain located on end/center. The 1” diameter drain on N8000, N8000-R, N8100, N8100NB, N8100-BR, N8100-FA and 8100-EF Series units is shipped loose and must be connected during installation. N8157-FA, N8169-FA, and N818 -FA have two drains.
Moisture collecting from improper drainage can create a slippery surface on the floor and a hazard to employees. It is the owner’s responsibility to provide a container or outlet
CAUTION |
for drainage. |
|
Some N8000, N8000N, N8000-R, N8100B, N8100NB and N8100-BR may have polyethylene insulation in the drain hole. This can easily be cut out without any contact or damage to the units interior insulation or refrigeration lines.
Electrical connection
Refer to the amperage data on the speciication pages, the serial tag or your local code to be sure the unit is connected to the proper power source. A protected circuit of the correct voltage and amperage must be run for connection of the line cord.
Some units have an ON/OFF switch located behind the louvered panel in the machine compartment. Simply turn the switch to ON to begin operation.
Some units have an OFF position on the thermostat dial which is located behind the louvered panel in the machine compartment. Simply turn the dial to begin operation.
The unit must be disconnected from the power source whenever performing service or maintenance functions.
Never operate the unit without the louvered panel in place!
Installation N8600
Drop In Procedure
These units are intended for indoor use only. A room temperature of no more than 86°F ( 0°C) is recommended. Be sure the location chosen has a counter strong enough to support the total weight of the unit and contents. A fully loaded model may weigh as much as 600 pounds! Reinforce the counter as necessary to provide for maximum loading.
x ” ( 7.9 cm x 55.9 cm). The rear must have an opening to permit removal of heated air. The opening must be at least 8” x 11”, a total of 88 square inches ( 0. cm x 7.9 cm, a total of 566 square centimeters).
Plumbing
The units 1” ( .54cm) drain must have an outlet to an appropriate drainage area or container.
|
Unit requires that the sides and bottom are not |
|
|
|
||
|
any closer than 3” (7.6cm) to any combustible |
|
Moisture collecting from improper drainage |
|||
D A N G E R |
material. |
|
|
can create a slippery surface on the |
floor |
|
|
|
|
and a hazard to employees. It is the owner’s |
|||
|
|
|
|
|||
The counter cut-out sizes and power requirements are shown |
CAUTION |
responsibility to provide a container or outlet |
||||
on the speciication pages. A gasket is installed in the lange |
|
for drainage. |
|
|||
of each unit. The weight of the unit on the gasket forms a seal |
|
|
|
|||
preventing liquids from seeping into the cut-out opening. |
Electrical connection |
|
||||
|
|
|
Refer to the amperage data on the speciication pages, the |
|||
The cut-out dimensions for the control box on N8600 Series |
serial tag or your local code to be sure the unit is connected to |
|||||
units is 4. 5” x 1 . 5” (10.8 cm x 1.1 cm). |
the proper power source. |
|
||||
Louvers |
|
|
|
The unit must be disconnected from the |
||
For proper refrigerated operation, N8600 Series units require |
|
|||||
|
power source whenever performing service |
|||||
airlow to the compressor. A 1 ” x 5” louver is ( .0 cm x 6 .5 |
|
|||||
|
or maintenance functions. |
|
||||
cm) is provided by Delield and must be installed in the counter |
|
|
||||
|
|
|
||||
in front of the condenser. The louver cutout dimension is 11” |
|
Never operate the unit without the louvered |
||||
|
|
|
|
|||
™ |
|
|
|
panel in place! |
|
|
DELFIELD |
® |
|
|
|
||
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
9 |
|||||
|
|
|||||
N8000 Series Drop-In Installation and Operation Manual
Installation N8700-D, N8700N, N8700-R & N8800 Series
Drop In Procedure
These units are intended for indoor use only. Be sure the location chosen has a counter strong enough to support the total weight of the unit and contents. A fully loaded model may weigh as much as 600 pounds! Reinforce the counter as necessary to provide maximum loading.
Unit requires that the sides and bottom are not any closer than 3” (7.6cm) to any combustible
D A N G E R material.
The counter cut-out sizes and power requirements are shown on the speciication pages. A gasket is installed in the lange of each unit. The weight of the unit on the gasket forms a seal preventing liquids from seeping into the cut-out opening.
N8700 Series pans should be installed with the drains at the back, away from the operator’s sides.
The controls on N8700-D, N8700-R and N8800 series units are mounted in a control panel, designed to be installed at a “remote” location. The control panel should be installed so that the indicator light for each control is to the right of the control. N8700, N8700N and N8700-R series units have 48” (1 1.9cm) of conduit and N8800 Series units have 4” (61.0cm) of conduit between the pans and the remote control panel to facilitate this installation.
Plumbing
N8700-D, N8700N-D and N8700-R Plumbing: Unit is equipped with 1/ ” (1. cm) drains, (one per well located in right rear corner 1/ ” (1. cm) female N.P.T.) manifold and 1/ ” (1. cm) gate valve.
N8800 Plumbing: Well is sloped to a 1.00” ( .5cm) male N.P.T. stainless steel drain.
Moisture collecting from improper drainage can create a slippery surface on the floor and a hazard to employees. It is the owner’s
CAUTION responsibility to provide a container or outlet for drainage.
Electrical connection
Refer to the amperage data on the speciication pages, the serial tag or your local code to be sure the unit is connected to the proper power source.
The unit must be disconnected from the power source whenever performing service or maintenance functions.
Control Panel Installation, N8700-D, N8700N & N8700-R Series
The control panel is designed to be installed on the side opposite the drains.
If you choose to install the control panel on the same side as the drains the control panel will either be upside down or the knobs will control the opposite wells.
Control panel installed opposite drains
Drains
|
|
™ |
|
|
® |
10 |
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com |
DELFIELD |
|
Loading...
