Transport Data Logger TDL 110
Kurzanleitung
Die ausführliche Beschreibung zum TDL 110 findet sich im Downloadbereich unter: www.bosch-connectivity.com/TDL110
Verbindung mit dem TDL (Bild 1)
1.Starten Sie die Transport Data Logger-App, die Sie unter dem Begriff „Bosch Transport Data Logger“ in Ihrem Apple App Store oder Google Play Store kostenlos finden.
2.Aktivieren Sie Bluetooth an Ihrem Smartphone.
3.Zur Aktivierung des TDL drücken Sie den Button an Ihrem Gerät für 0,3 bis 1,5 Sekunden.
4.Drücken Sie „Search“, um aktivierte TDL zu finden.
5.Wählen Sie den gewünschten TDL und bestätigen Sie die Verbindung durch Drücken auf „Pair“ (Koppeln).
Einrichten des TDL (Bild 2)
|
|
HINWEIS |
Kein Zugriff auf den TDL! |
|
|
|
Ohne PIN ist die Konfiguration des TDL nicht möglich. Die PIN kann |
||
DE |
||||
|
auch werksseitig nicht zurückgesetzt werden. |
|||
|
|
Notieren Sie sich immer die vergebene PIN für den jeweiligen TDL |
||
|
||||
|
|
und bewahren Sie diese an einem sicheren Ort auf. |
||
|
|
|
|
|
|
|
HINWEIS |
Zeichenkonvention |
|
Für Mail-Adresse und Gerätename können nur bestimmte Zeichen verwendet werden.
Verwenden Sie nur die Zeichen [A-Z][a-z][0-9][@.,;/\|+-*_]
1.Folgen Sie den Schritten in der App, um den TDL zu konfigurieren (optionale E-Mail-Adresse für Datenversand, Gerätename, PIN, Überwachungsparameter).
2.Drücken Sie „Start logging and disconnect“, um die Aufzeichnung sofort zu starten.
Für einen späteren Start drücken Sie „Disconnect“ in der App. Zum gewünschten Startzeitpunkt drücken Sie den Button am TDL für 2 bis 5 Sekunden, um die Aufzeichung erst dann zu starten. Ein dreimaliges grünes Blinken des TDL signalisiert, dass der Logging-Vorgang gestartet wurde.
Datentransfer (Bild 3)
Verbinden Sie Ihr Smartphone mit dem eingerichteten TDL und folgen Sie den einzelnen Schritten zur Anzeige und zum Download der Daten in der App.
VORSICHT! Lithium-Batterie!
Das Gerät enthält eine Lithium-Batterie. Unsachgemäße Behandlung kann zu einem Brand führen.
Verwenden Sie nur freigegebene Batterien.
Beachten Sie gegebenenfalls die geltenden Transportvorschriften.
HINWEIS Garantieverlust!
Unbefugtes Öffnen des Gehäuses kann das Gerät beschädigen. Der Garantieanspruch, soweit vorhanden, erlischt.
Öffnen Sie das Gehäuse nicht.
Verwenden Sie nur originales oder freigegebenes Zubehör.
Entsorgungshinweis gemäß ElektroG und WEEE Richtlinie 2012/19/EU
Der TDL darf nicht im Hausmüll entsorgt werden. Sie sind verpflichtet, den TDL nach Gebrauch einer Rückgabestelle oder einer Sammlung für die Annahme und das Recycling von elektrischen und elektronischen Altgeräten zuzuführen.
EU-Konformitätserklärung
Hiermit erklärt Bosch Connected Devices and Solutions GmbH, dass der Funkanlagentyp „Transport Data Logger TDL 110“ der Richtlinie 2014/53/EU (Radio Equipment Directive) entspricht.
•Sendeleistung max. 4 mW
•Frequenzband 2400 – 2483,5 MHz
Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: www.bosch-connectivity.com/TDL110
Quick Start Guide
The full description of the TDL 110 is available at:
www.bosch-connectivity.com/TDL110
Connection to TDL (Figure 1)
1.Start the Data Logging App. You will find the App “Bosch Transport Data Logger” in your Apple App Store or Google Play Store free of charge.
2.Activate Bluetooth on your smartphone.
3.To activate the TDL press the button on the device from 0.3 to 1.5 seconds.
4.To find the activated TDL tap “Search”.
5.Choose the TDL and confirm the connection by tapping “Pair”.
Configure the TDL (Figure 2)
|
|
NOTICE |
No TDL Access! |
|
EN |
||||
|
You cannot configure the TDL without a valid PIN. It is impossible to |
|||
|
||||
|
|
reset the PIN; even at the factory. |
||
|
|
Always make a note of the PIN and store it on a safe place. |
||
|
|
|
|
|
|
|
NOTICE |
Convention for Characters |
|
|
|
|
||
For e-mail and device name only defined characters are usable.
These characters are allowed:[A-Z][a-z][0-9][@.,;/\|+-*_]
1.To configure your app follow the steps shown in the app (e-mail (option) for data transfer, device name, PIN, logging parameter).
2.To start logging immediately tap “Start logging and disconnect”.
To start logging later, tap “Disconnect” in the app. When desired, press the button between 2 and 5 seconds on the TDL to start logging. The TDL blinks three times green to confirm that logging has started.
Data Transfer (Figure 3)
Connect your smartphone with the configured TDL. Follow the steps in the app to display and download the desired data.
CAUTION Lithium Battery!
The device contains a lithium battery. Handling the battery incorrectly could cause a fire.
Use only original or approved batteries.
Read and follow the valid transportation regulations, if necessary.
NOTICE Forfeiting the Warranty!
Opening the casing without authorization could present risks to the user and will void any warranty.
Do not open the housing.
Use only original or approved accessories.
Disposal according to the WEEE Directive 2012/19/EU
The unit, accessories and packaging should be sorted for environmental-friendly recycling. Do not dispose of the device into household waste! According to the European Guideline 2012/19/EU, electric and electronic devices that are no longer usable must be collected separately and disposed of in an environmentally correct manner.
EU Declaration of conformity
Hereby, Bosch Connected Devices and Solutions GmbH declares that the radio equipment type “Transport Data Logger TDL 110“ is in compliance with Directive 2014/53/EU (Radio Equipment Directive).
•Radio power max. 4 mW
•Frequency band 2400 – 2483.5 MHz
The full text of the EU declaration of conformity is available at the following internet address: www.bosch-connectivity.com/TDL110
Transport Data Logger TDL 110
Federal Communications Commission (FCC) Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)this device must accept any interference received,
including interference that may cause undesired operation. The manufacturer is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications may void the FCC authorization to operate this equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
ISED Canada (IC) Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
IMDA Singapore Notice |
|
Complies with |
|
|
IMDA standards |
|
DB101762 |
Japanese Radio Law ( ) Notice
This device is granted pursuant to the Japanese Radio Law ( ) and registered as radio equipment R: 202-LSE086.
This device should not be modified (otherwise the granted designation number will become invalid)”.
China Notice
This device has passed the type approval by SRRC and has been grated the CMIIT ID 2016DJ6299.
Australia Notice
This device complies with the requirements of the relevant ACMA Standards made under the Radiocommunications Act 1992 and the Telecommunications Act 1997.
Malaysia Notice
This device complies with the Standard MCMC MTSFB TC T007:2014 under the Common ID CIDF17000080.
Philippines Notice
Type acceptance of this device is issued to Bosch Connected Devices and Solutions GmbH for use in the Philippines subject to existing NTC rules and regulations: Certificate N°. ESD-1714430C.
Thailand Notice
Declaration of Conformity has been confirmed for this device by Thailand NBTC.
Bosch Connected Devices and Solutions GmbH Ludwig-Erhard-Straße 2
72760 Reutlingen Germany
