Poly-Tex CD3000 User Manual
CD3000 3-level circle display
ASSEMBLY INSTRUCTIONS
IMPORTANT
Please read these instructions carefully before beginning to
assemble this display. Save instructions for future reference.
P.O. Box 458
27725 Danville Avenue
Castle Rock, MN 55010
www.poly-tex.com
REV: AB-120329
U.S. & Canada Toll Free
800-852-3443
(651) 463-7009
fax (651) 463-2479
PARTS IDENTIFICATION
CD4005
20" SHELF
CD4003
28" SHELF
CD4001
BASE
CD4002
POST
NB1848
5/16" x 2" HEX BOLT
(2)
NB1978
5/16" SET SCREW
(4)
NB1979
5/32" HEX WRENCH
OPTIONAL COMPONENTS
NB1903
5/16" WING NUT
(2)
CD4006
SIGN POST 22 1/2"
TOOLS & EQUIPMENT REQUIRED
No additional tools are required.
CD4007
SIGN HOLDER, 3 SIDE
2
