INSTALLATIONINSTRUCTION
S
K
O
O
L
H
O
U
S
E
P.O.Box45827725DanvilleAvenueCastleRock,MN55010
www.poly-tex.co
m
U.S.&CanadaTollFree800-852-3443(651)463-700
9
fax(651)463-247
9
REV:AC-120529
Page 2
SAFETYGUIDELINE
S
PLEASEREADTHEINSTALLATIONINSTRUCTIONSCAREFULLYBEFOREBEGINNINGTOASSEMBLETHESTRUCTURE.SAVETHESEINSTRUCTIONSFORFUTUREREFERENCE
.
Thisstructureisintendedtobeself-supporting,provideditisconstructedwithallframes,hardware,sheathing,sheeting,bracing,cables,andmembraneinplace,andsecuredtothefoundationasshowninthemanual.Stabilityduringconstruction,fromwindsandloadsimposedduringerection,isthesoleresponsibilityoftheinstaller.Observesafetycodesrequiredbyyourjurisdiction,andrelevantsafetypracticesforworkingatheights.Avoidth
e
riskofelectricalshockfromoverheadlinesorelectricalstorms.Poly-Texrecommends
contractingalicensedelectriciantoperformelectricalwork.Eyeprotectionisrecommendedunderallcircumstancesandhearingprotectionisrecommendedwhencuttingcomponentswithpowertools.FoundationsTheseinstructionsincludeminimumguidanceforfoundationsbasedontheInternationalBuildingCode.Theseminimumsaresuitableforsomeareasofthecountrybutnotall.Obtainabuildingpermitifrequiredinthelocaljurisdiction.EngineeredandCertifiedfoundationplansmayberequiredbyabuildingofficialbeforeissuingapermit.Evenifnotrequired,seekingguidancefromaqualifiedstructuralorcivilengineerforthefoundationdesignmayimprovethelifeofthestructure.Nopartofthisstructureisengineeredtofunctionasananchoragepointforafallarrestsystem.Useasafetynetorworkfromasafeworkplatform(i.e.scaffolding).Selectacalmdayforwork.Windcanbesufficientenoughtoknockmaterialsorworkersoffaworkplatformorladder,resultinginapotentiallydeadlyfall.OverviewofassemblyprocedureWhileeachstructureandsiteisunique,andmayrequirespecialconsiderations,theseinstructionsareforatilt-upmethod(whereframesareassembledonthegroundandtiltedontogroundstakesoranchorrodsusingropesorlifts).Ifinstallerisnotconfidenttoerectthestructure,Poly-Texsuggestshiringageneralcontractor,carpenter,orsimilarlicensedbusinessfamiliarwithconstruction,toassembleanderectthestructure.Donotoverloadstructure.ConsultwithaPoly-Texrepresentativepriortoaddinganyamountofweightoverthespecifiedcapacityofthisstructure.Basketpurlins,shelvingoranyobjectsofsignificantweightshallnotbehung,attached,orsecuredtoroofortrussmembersinamannerthatwilloverloadthestructure.Donotwalkonpolycarbonatesheets.Ifstructureistobecoveredwithpolycarbonatesheets,alwaysusescaffoldingfortheerectionprocesstoavoiddamagetosheetingandtoensuresafety.PolycarbonatesheetinghasUVcoatingprotectedwithvinylfilmontheexterior
surface.Installsheetswiththefilmintactandtowardtheexterior.Removefilmonceth
e
sheethasbeenfastenedinplace
.
REV:AC-120529
WARNINGWARNINGDANGERDANGE
R
Page 3
PLAINBOW20'(KH1120)SWAGEDBOW20'(KH3120)SIDEBOW16'(KH2116)TOPBOW16'(KH1116)TOPBOW18'(KH1118)SIDEBOW18'(KH2118)
PARTSIDENTIFICATION-SHEET1ONE
REV:AC-120529510964-2
16ftKOOLHOUSE20ftKOOLHOUSE18ftKOOLHOUSE
Page 4
GROUNDSTAKE(GS2408)9'-8"TRUSSPURLINW/SWAGE-RED(HP3340)9'-8"R.F.UCHANNELW/SWAG
E
(RR2109
)
18"SPIKE(BMS1130)KHLEGSTAND(KH1001)(FOR6'HOOPSPACING)DIAGONALBRACE-BLACK(GM2940)VERTICAL(KH3018)ENDBASE(KH4018)CENTERBASE(KH5000)HEADER(KH6000)HEADERWITHWIGGLEBASE
(KH6500
)
R.F."L"BRACKET(FT1990)R.F.JAMBCLAMP(FT1998)U-CLAMP(FT2104
)
R.F.CORNERMOUNT
(FT2000)LONGSPEEDHOOK(FT2080)UNI-CLAMP(FT2113)PURLINFASTENER(KH1000)DRIVINGTOOL
(KH1005
)
(FOR4'HOOPSPACING)DIAGONALBRACE-ORANGE(GM2950
)
PARTSIDENTIFICATION-SHEET2T
W
O
REV:AC-120529610577-1
KOOLHOUSE
STOPTAB(FT2570)SCREWSELF-DRILLING#12-14x3/4"(NB1802)SELFDRILLINGSCREW#12-14x11/2"(NB1805)5/16"x1-1/4"CARRIAGEBOLT(NB1832)5/16"LOCKWASHER(NB1862)5/16"HEXNUT(NB1872)5/16"FLATWASHER(NB1886)1/4"x1-1/2"LAGSCREW(NB1810)WIGGLEBASE(WWBASE9)WIGGLEWIRE(WIGLWIRE)28INCHAINFORROLL-UPGUIDE(RC1307)ROLL-UPTUBECLIP(RC1010)GEARBOXEXTENSION(RC1009)L-FLASHING
Page 5
(PT3926
)
3/8"x33/4"ANCHORBOLT(NB1929)FLATWASHER1-1/8"NEOPRENE(NB1869)CRADLEWITH"S"HOOK(RC1310)RAILSIDE5(RC1306)GUIDEMOUNTBRACKET(RC1301)ROLL-UPCURTAINGEARBOXGUIDE(RC1305)BRACKETWITH"S"HOOK(RC1311)ROLLUPUNITMV1000
PARTSIDENTIFICATION-SHEET3THREE
REV:AC-120529610578-1
KOOLHOUSE
PARTSIDENTIFICATION-OPTIONALROLL-UPCURTAINS
1/4"POLYESTERROPE(RS5049)
Page 6
18'-0"
20'-0"
16'-0"
4'-0" C TO C
16'-0"
6'-0" C TO C
18'-0"
4'-0" C TO C
20'-0"
6'-0" C TO C
4'-0" C TO C
6'-0" C TO C
18"
6"
LENGTH OF GREENHOUSE CENTER
TO CENTER OF GROUND STAKES.
16' WITH 4' HOOP SPACING
5'-11"
4'-2"
5'-11"
5'-11"
4'-2"
5'-11"
16' WITH 6' HOOP SPACING
LENGTH OF GREENHOUSE CENTER
TO CENTER OF GROUND STAKES.
LENGTH OF GREENHOUSE CENTER
TO CENTER OF GROUND STAKES.
18' WITH 4' HOOP SPACING
6'-11"
4'-2"
6'-11"
6'-11"
4'-2"
6'-11"
LENGTH OF GREENHOUSE CENTER
TO CENTER OF GROUND STAKES.
18' WITH 6' HOOP SPACING
LENGTH OF GREENHOUSE CENTER
TO CENTER OF GROUND STAKES.
20' WITH 4' HOOP SPACING
7'-11"
4'-2"
7'-11"
7'-11"
4'-2"
7'-11"
20' WITH 6' HOOP SPACING
LENGTH OF GREENHOUSE CENTER
TO CENTER OF GROUND STAKES.
GROUND STAKE
STRING LINE
LINE LEVEL
NOTE: ALL MEASUREMENTS CENTER-TO-CENTER OF GROUND STAKES.
STRING LINES
STAKES
GROUND
ONE OF THE FASTEST AND EASIEST
WAYS TO SQUARE UP THE STRUCTURE
IS TO MEASURE DIAGONALLY. THESE
MEASUREMENTS SHOULD BE THE SAME.
ONCE THIS IS COMPLETE, CHECK ALL
FOUR SIDES OF THE LAYOUT FOR
CORRECT MEASUREMENTS.
LL
LL
L L
L L
L L
L L
6"
18"
USE THE DRIVING TOOL TO DRIVE THE GROUND STAKES 18 INCHES INTO THE GROUND
LEAVING APPROXIMATELY 6 INCHES ABOVE GROUND FOR SECURING HOOP.
POLY-TEX RECOMMENDS CONCRETE FOOTINGS TO BE USED IN LOOSE SOIL OR
EXTREMELY WINDY CONDITIONS.
FOR MODERATE WIND AND SOIL CONDITIONS, INSTALL GROUND STANDS. DIG AND SET
GROUND STANDS APPROXIMATELY 18 INCHES IN THE GROUND LEAVING APPROXIMATELY
6 INCHES ABOVE THE GROUND FOR SECURING THE HOOP. COMPACT FILL.
OPPOSITE END
DIMENSIONS
ARE IDENTICAL
OPPOSITE END
DIMENSIONS
ARE IDENTICAL
OPPOSITE END
DIMENSIONS
ARE IDENTICAL
OPPOSITE END
DIMENSIONS
ARE IDENTICAL
OPPOSITE END
DIMENSIONS
ARE IDENTICAL
OPPOSITE END
DIMENSIONS
ARE IDENTICAL
GROUND
STAKE
GROUND
STAKE
GROUND
STAND
6"
18"
COMPACTED
FILL
DRIVING
TOOL
LAYOUT & GROUND STAKE INSTALLATION
FOUR
REV: AC-120529
KOOL HOUSE
#4 VERTICAL
REBAR (3)
"24"
MINIMUM
"1-3/4" MINIMUM EMBEDMENT
A A
KH1012
1.315"x3/8"
CORNER LEG STAND
NB1929
EXPANSION ANCHOR
3/8 x 3 3/4" (2)
NB1929 EXPANSION ANCHOR 3/8 x 3 3/4" (3)
KH1011
1.315"x3/8" LEG STAND
(4 HOLE)
FT1562
BASE PLATE
5"x5"X3/8" (9/16') 4H
FT1558
BASE PLATE
5"x5"X3/8" (9/16') 4H
12'-0"
CONCRETE
PIER
ALTERNATELY: PLATE MAY BE ANCHORED TO A
5" MINIMUM CONCRETE SLAB.
SECTION A-A
Page 7
SIDE HOOP
SIDE HOOP
TOP HOOP
#12-14 x 3/4" SELF
DRILLING SCREW
4'6'#12-14 x 3/4" SELF
DRILLING SCREW
AFTER HOOPS ARE RAISED, SECURE THEM TO THE GROUND
STAKES WITH (2) - #12-14 x 3/4" SELF DRILLING SCREWS.
PURLIN FASTENER
OPTIONAL
SIDE PURLIN
#12-14 x 3/4" SELF
DRILLING SCREW
HOOP
HOOP
GROUND STAKE
RIDGE PURLINS
4'
OPTIONAL
SIDE PURLINS
LONG SPEED
HOOK
DIAGONAL
BRACE
HOOP
ASSEMBLE THE HOOP SECTIONS NEAR THE GROUND STAKES
THE FRAMES WILL STAND ON.
(FIGURE ONE)
NOTE:
20' KOOL HOUSE IS CONSTRUCTED WITH
A FOUR PIECE HOOP.
IT MAY BE NECESSARY TO PUSH HOOP
ENDS TOGETHER TO SLIDE OVER GROUND
STAKES.
IF OPTION INCLUDES 4' HOOP SPACING, RAISE THREE HOOPS
THEN ATTACH DIAGONAL BRACES TO THE FIRST AND
THIRD HOOPS USING LONG SPEED HOOKS.
(FIGURE TWO)
IF OPTION INCLUDES 6' SPACING, RAISE TWO HOOPS THAN
ATTACH DIAGONAL BRACES USING LONG SPEED HOOKS.
(FIGURE THREE)
ATTACH THE RIDGE PURLIN JUST BELOW THE CENTER OF THE
TOP HOOP USING PURLIN FASTENERS.
(FIGURE TWO)
FOR
ADDITIONAL SIDE PURLINS
(OPTIONAL)
REFER TO
(FIGURE
THREE)
.
CONTINUE RAISING HOOPS AND ATTACHING PURLINS UNTIL
DESIRED LENGTH OF HOUSE IS REACHED. ATTACH DIAGONAL
BRACES TO OPPOSITE END OF HOUSE AS DIRECTED ABOVE.
FIGURE ONE
FIGURE TWO
FIGURE THREE
IMPORTANT
EVENLY SPACED ON
BOTH SIDE HOOPS
LONG SPEED
HOOK
HOOP
DIAGONAL
BRACE
DIAGONAL BRACE
PURLIN FASTENER
RIDGE PURLIN
#12-14 x 3/4" SELF
DRILLING SCREW
HOOP
RIDGE PURLINS
OPTIONAL
SIDE PURLINS
GM2950
DIAGONAL BRACE
GM2940
HOOP ASSEMBLY
FIVE
REV: AC-120529 35345-0
KOOL HOUSE
Page 8
ROLL
FORM
ROLL FORM
"L" BRACKET
FOR WOOD SIDE
RAIL APPLICATIONS
PLACE WOOD ON
OUTSIDE OF STRUCTURE
(2) 1/4" x 1 1/2"
LAG SCREW
HOOP
1.66" "U" CLAMP
#12-14 x 3/4" SELF
DRILLING SCREW
KOOL HOUSE
FRAME SECTION
(2) LONG
SPEED HOOKS
(2) 5/16" x 1 1/4"
CARRIGE BOLT,
LOCK WASHER
& NUT
1 1/2" VERTICAL
INSIDE VIEW
POSITIONING OF ROLL FORM
1 1/2" VERTICAL & HOOP ASSEMBLY
CORNER ASSEMBLY
VERTICAL ASSEMBLY
IMPORTANT NOTE:
IF THE RAIL EXTENDS BEYOND THE END
HOOP OF THE STRUCTURE, CUT THE RAIL
FLUSH WITH THE OUTSIDE EDGE OF THE
END HOOP. USE THE CUT OFF PIECE TO
BEGIN THE NEXT ROW.
NOTE:
WHEN ANY PART OF THE OVAL INSERT IS TOO NEAR A
POST TO ATTACH UNI-CLAMPS, CUT A PORTION (8" - 12")
FROM THE PLAIN END OF THE ROLL FORM AND
PROCEED WITH THE INSTALLATION.
ROLL FORM
CONNECTION
ROLL FORM
SWAGE END
ROLL FORM
PLAIN END
#12-14 x 3/4" SELF
DRILLING SCREWS
#12-14 x 3/4" SELF
DRILLING SCREW
ROLL FORM
IMPORTANT: DO NOT TIGHTEN
WITH SCREW DRIVER. USE A 3/8"
SOCKET FOR MAXIMUM STRENGTH
1/4" X 1-1/2" HEX
HEAD BOLT & NUT
FRAME
UNI-CLAMPS
(1) STOP TAB, 5/16"
WASHER, AND NUT
KOOL HOUSE
FRAME SECTION
ROLL FORM
END BASE
#12-14 x 3/4" SELF
DRILLING SCREW
ROLL FORM
CORNER MOUNT
OPTIONAL END FRAME WITHOUT DOOR
SIX
REV: AC-120529 57086-3
KOOL HOUSE
(4) #12-14 x 3/4" SELF
DRILLING SCREW
1-1/2" VERTICAL
Page 9
ROLL
FORM
ROLL FORM
"L" BRACKET
FOR WOOD SIDE
RAIL APPLICATIONS
PLACE WOOD ON
OUTSIDE OF STRUCTURE
(2) 1/4" x 1 1/2"
LAG SCREW
HOOP
1.66" "U" CLAMP
#12-14 x 3/4" SELF
DRILLING SCREW
KOOL HOUSE
FRAME SECTION
(2) LONG
SPEED HOOKS
(2) 5/16" x 1 1/4"
CARRIGE BOLT,
LOCK WASHER
& NUT
1 1/2" VERTICAL
INSIDE VIEW
POSITIONING OF ROLL FORM
1 1/2" VERTICAL & HOOP ASSEMBLY
CORNER ASSEMBLY
VERTICAL ASSEMBLY
IMPORTANT NOTE:
IF THE RAIL EXTENDS BEYOND THE END
HOOP OF THE STRUCTURE, CUT THE RAIL
FLUSH WITH THE OUTSIDE EDGE OF THE
END HOOP. USE THE CUT OFF PIECE TO
BEGIN THE NEXT ROW.
NOTE:
WHEN ANY PART OF THE OVAL INSERT IS TOO NEAR A
POST TO ATTACH UNI-CLAMPS, CUT A PORTION (8" - 12")
FROM THE PLAIN END OF THE ROLL FORM AND
PROCEED WITH THE INSTALLATION.
ROLL FORM
CONNECTION
ROLL FORM
SWAGE END
ROLL FORM
PLAIN END
#12-14 x 3/4" SELF
DRILLING SCREWS
#12-14 x 3/4" SELF
DRILLING SCREW
ROLL FORM
IMPORTANT: DO NOT TIGHTEN
WITH SCREW DRIVER. USE A 3/8"
SOCKET FOR MAXIMUM STRENGTH
1/4" X 1-1/2" HEX
HEAD BOLT & NUT
FRAME
UNI-CLAMPS
(1) STOP TAB, 5/16"
WASHER, AND NUT
KOOL HOUSE
FRAME SECTION
ROLL FORM
END BASE
#12-14 x 3/4" SELF
DRILLING SCREW
ROLL FORM
CORNER MOUNT
OPTIONAL END FRAME WITH DOOR
SEVEN
REV: AC-120529 57087-3
KOOL HOUSE
(4) #12-14 x 3/4" SELF
DRILLING SCREW
1-1/2" VERTICAL
6'-8 1/2"
Page 10
12"60
"
OPTIONALROLL-UPCURTAININSTRUCTIONSEIGHT
REV:AC-120529610573-1
KOOLHOUSE
WIGGLEWIREBASESIDERAILINSTRUCTIONS1.ATTACHROLLFORMRAILSTOHOOPSUSINGUNI-CLAMPS.2.BOTTOMRAILISABOUT12"UPFROMBOTTOMOFHOOP.3.TOPRAILIS60"BETWEENTHERAILS.4.ATTACHWIGGLEWIREBASEUSING#12-14x3/4"SELFDRILLINGSCREWSSPACEDABOUTEVERY12".5.ATTACHSIDERAILUSINGSTOPTABS,LOCKWASHERSANDHEXNUTS.SIDERAILIS12"FROMINSIDEEDGEOFCORNERHOOP.6.INSTALLPOLYON12"LOWERSECTION.7.INSTALLPOLYBETWEENENDFRAMEANDSIDERAILS.8.INSTALLENDFRAMEPOLY.SIDERAILSIDEPOLYLOWERPOL
Y
101/2
"
UNI-CLAMP#12-14x3/4"SELFDRILLINGSCREWUNI-CLAMP1/4"x1/2"HEXBOLT&HEXNUT#12-14x3/4"SELFDRILLINGSCREW
VIEWFROMINSIDEOFSTRUCTURE
Page 11
OPTIONALROLL-UPCURTAININSTRUCTIONSNIN
E
REV:AC-120529610574-1
KOOLHOUSE
2"2
"
74"
POLYCURTAINLENGTHASREQUIREDPOLYCURTAIN#12-14x3/4"SELFDRILLINGSCREWCF1014INSTRUCTIONS9.ASSEMBLEBOTTOMTUBE.SECUREWITH#12-14x3/4"SELFDRILLINGSCREWS.10.INSTALLROLLUPCURTAINPOLY.EXTENDCURTAINPOLYABOUT2"BEYONDHOOPANDABOUT2"ABOVEUPPERRAIL.KEEPASEVENASPOSSIBLE.AFTERPOLYISSECUREMEASUREDOWN74"FROMTOPRAILANDPLACEAMARKONPOLYUSINGAMARKINGPEN.11.USETHEMARKTOALIGNROLLUPTUBEWHILEFASTENINGTUBECLIPS.FASTENCURTAINTOTUBEUSINGCLIPSEVERY3'KEEPINGTUBESTRAIGHTWITHMARKS.TUBECLIPMARKFORROLLUPTUBE
Page 12
OPTIONALROLL-UPCURTAININSTRUCTIONSTEN
REV:AC-120529610575-1
KOOLHOUSE
GEARBOXEXTENSIONINSTRUCTIONS12.ATTACHGEARBOXEXTENSIONTOGEARBOXUSINGTHEBOLTPROVIDED.ATTACHGEARBOXTOTUBEASSEMBLYUSING#12x3/4"SELFDRILLINGSCREW.13.SLIDEGEARBOXGUIDETHROUGHGEARBOXANDBOLTGUIDETOGUIDEMOUNTINGBRACKET.14.ATTACHCHAINTOHOOPBYDRILLING3/8"HOLETHROUGHTHESIDEOFHOOPABOUT77"UPFROMTHEBOTTOMOFTHEHOOP.USEA5/16"x2-1/2"HEXBOLT,FLATWASHER,LOCKWASHER,ANDHEXNUTTOATTACHTOHOOP.15.ATTACHCHAINTOGEARBOXGUIDEUSING5/16"x3/4"HEXBOLT,FLATWASHER,LOCKWASHER,&HEXNUT.5/16"x21/2"HEXBOLT,FLATWASHER,LOCKWASHER,&HEXNUT5/16"x3/4"HEXBOLT,FLATWASHER,LOCKWASHER,&HEXNUTGEARBOXGUIDE77"3/8"THROUGHHOLE(FIELDDRILL)GUIDEMOUNTINGBRACKET5/16"x2"HEXBOLT,LOCKWASHER,&HEXNUTGEARBOXGUIDESIDEPOLYGUIDEMOUNTINGBRACKET12"LOWERPOLYROLL-UPCURTAINROOFPOLYUPPERRAILTUBEASSEMBLYLOWERRAIL
Page 13
OPTIONALROLL-UPCURTAININSTRUCTIONSELEVE
N
REV:AC-120529610576-1
KOOLHOUSE
#12-14x1-1/2"SELFDRILLINGSCREW#12-14x3/4"SELFDRILLINGSCREWROLLFORMRAILROLLFORMRAILINSTRUCTION
S
16.RAISECURTAINABOUTHALFWAYUP.SETCRADLESJUSTINSIDETHE
SIDEGUIDEONBOTHENDSOFTHEHOUSEANDEVERY12'THEREAFTER.ATTACHCRADLESUSING#12x3/4"SELFDRILLINGSCREWS.17.ROPEBRACKETSAREPLACEDEVERY12'BETWEENTHECRADLESWITHLARGEHOLEFACINGDOWN.ATTACHUSING#12x1-12"SELFDRILLINGSCREW.18.ROLLCURTAINDOWNSOITRESTSINTHECRADLES.SECUREGUID
E
MOUNTINGBRACKETTOTHEGROUNDUSING18"SPIKES.
19.THREADROPETHROUGHTHECRADLES&ROPEBRACKETS,CONTINUETOTHEENDOFTHEHOUSE.ROPESHOULDBEKEPTFAIRLYTIGHT.18"SPIKEGUIDEMOUNTINGBRACKETBRACKETWITH"S"HOOK
CRADLEWIT
H
"S"HOOK
Page 14
1 1/2" VERTICAL
DOOR FRAME
DOOR
#12-14 x 3/4" SELF
DRILLING SCREW
HINGE
WIGGLE
WIRE BASE
DOOR CATCH
#12-14 x 3/4" SELF
DRILLING SCREW
#12-14 x 3/4" SELF
DRILLING SCREW
WIGGLE WIRE
BASE (OPTIONAL)
1/4"
CLEARANCE
1/4"
CLEARANCE
DOOR
HEADER
DOOR
STOP
DOOR
(SHADED)
DRIP EDGE OF
DOOR HEADER
GROUND
LEVEL
ROLL FORM
END BASE
ROLL FORM
END BASE
WIGGLE
WIRE
POLY
POLY-FASTENER
OVERLAP
ONE SECTION
SECOND
WIGGLE
WIRE
SECTION
FIRST WIGGLE
WIRE SECTION
RIGHT
FIGURE 2
SIDE VIEW OF
END WALL DOOR
TOP VIEW OF END WALL DOOR
FIGURE 1
SECOND WIGGLE
WIRE SECTION
FIRST WIGGLE
WIRE SECTION
WRONG
FIGURE 3
8"-12" WIGGLE
WIRE
NOTE: AFTER THE WIGGLE WIRE BASE IS ATTACHED, POSITION THE POLY FILM OVER THE
KOOL HOUSE
FRAME (
BEING SURE TO
HAVE EQUAL EXCESS FILM ON ALL SIDES
) THEN INSTALL THE WIGGLE WIRE. USE AN UP & DOWN MOTION WHILE SEATING THE
WIRE INTO THE BASE. (
SEE FIGURE 1
) WHEN INSTALLING WIGGLE WIRE BE SURE TO OVERLAP ONE SECTION. (
SEE FIGURE 2
)
AFTER ALL WIGGLE WIRE IS INSTALLED, CUT REMAINING WIRES INTO 8"-12" PIECES AND USE TO REINFORCE ALL CORNERS.
(
SEE FIGURE 3
)
1 1/2" VERTICAL
WIGGLE WIRE
BASE (OPTIONAL)
#12-14 x 3/4" SELF
DRILLING SCREW
KOOL HOUSE
FRAME SECTION
POLY DROOP
WIGGLE WIRE
INSTALLED
WIGGLE WIRE
NOT INSTALLED
TENSIONED POLY
NOTE
: IF THE ROOF POLY IS INSTALLED ON A COOL
DAY, IT MAY EXPAND AS THE TEMPERATURE WARMS.
IT MIGHT BE NECESSARY TO RETENTION THE SHEET
OF PLASTIC. ALSO, AFTER THE WIGGLE WIRE HAS
BEEN INSTALLED, USING A BLUNT OBJECT, PRESS ALL
WIGGLE WIRE FIRMLY INTO BASE TO ENSURE IT HAS
BEEN SEATED PROPERLY.
WIGGLE WIRE
BASE
KOOL HOUSE
FRAME SECTION
LONG SPEED HOOK
1 1/2" VERTICAL
TO INSTALL
WIGGLE WIRE
BASE, BEND
BASE OVER
THE LONG
SPEED HOOKS
OPTIONAL PARTS
TWELVE
REV: AC-120529 57089-3
KOOL HOUSE
Page 15
FIGURE 4
WRONG
RIGHT
FIGURE 3
FIGURE 2
When installing poly roof and/or
ends use one layer of wiggle except
on all corners and when joining end
poly and roof poly in the same poly
fastener base. Use two layers of
wiggle wire in these two situations.
(SEE FIGURE 3)
When installing wiggle wire, be sure
to overlap your wiggle wire one
section.
(SEE FIGURE 3)
After the poly fastener base is secured to
your greenhouse frame, install your foam
tape. Do not peel off paper backing.
Next, position your poly over the
greenhouse frame (being sure to have
equal amount of film on all sides) and
install one layer of wiggle wire. Use a
back and forth motion while seating the
wire into the base. (SEE FIGURE 2)
(OPTIONAL)
USE THESE INSTRUCTIONS ONLY FOR DOUBLE POLY APPLICATIONS. FOR SINGLE POLY
APPLICATIONS SEE PAGE TWELVE
After all wiggle wire is installed, cut
remaining wires into 8" to 12" pieces
and use to reinforce all corners.
(SEE FIGURE 4)
DOUBLE POLY INSTALLATION
THIRTEEN
REV: AC-120529 48426-6
KOOL HOUSE
Page 16
PLAN VIEW
OF
GREENHOUSE
2
*
FIGURE 1
FIGURE 2
FIGURE 3
END POLY
END POLY
NOTE: Place two strips of quality greenhouse patching tape on the inside of
the outside layer where the air from the blower hits the film. This will
prevent rapid drying of the poly and will make it last longer.
Install the inflation blower as the drawing indicates. (FIGURE 1) Location is optional, but, it must be located on a side wall. Next, install the jumper tubes approximately half way up the roof (FIGURE 2)
using the white foam gaskets provided. Four gaskets are required per jumper. One is to be located on the bottom of the inside layer. The other is located on the top of the inside layer. (FIGURE 2)
This can be accomplished by placing one gasket on the inside layer. Now cut the poly out of the gasket on the inside layer only. Use caution during this procedure. Do not cut the outside poly.
Next, insert another gasket (wax paper removed) through the center of the first gasket and stick it on top of the inside layer of poly. (FIGURE 3) You now have sandwiched the poly between the
gaskets and formed an air seal for the jumper.
Before you install the jumper, staple the gaskets together using an ordinary office stapler. Complete all jumpers and turn on inflation blower. The damper on this blower is commonly closed about half
way. Adjust damper to the desired poly tension, using an manometer as an inflation guide.
NOTE: When installing the inflation motor wire it in a fashion to ensure continuous runtime.
END WALL
POLY
END FRAME
SECTION
(POLY FASTENER
NOT SHOWN)
3" x 2'-0" JUMPER
ROOF POLY
FOAM
GASKET
DAMPER
INSIDE
LAYER
GASKET
GASKET
OUTSIDE LAYER
(2) STOP TABS
INFLATION
MOUNT
ROOF POLY
(2) AIR TRANSFER
GASKETS
3" FLEX HOSE
HOSE
CLAMP
AIR
OUTLET
ROOF
POLY
DOUBLE
POLY
ROOF &
SIDE POLY
INFLATION
BLOWER
JUMPER
TUBE
INFLATING ROOF & END POLY
FOURTEEN
REV: AC-120529 5455-91
KOOL HOUSE
Loading...
